YE48CSIn-vehicle Infortainment System

All product names, logos, and brands are property of their respective owners. All company, product and service names used in this document are for identification purposes only. INFOTAINMENT USER MANUAL VERSION: 230515.01 CT90118CS General Infor mation & Setup Guide Before using this product, please read this manual fully to ensure correct operation. Keep the manual at hand for future reference. Copyright © 2023 Xite Solutions North America. All Rights Reserved | User Manual Version 230515.01 TABLE OF CONTENTS Warnings & Safety Information .............................................................................. 1-3 Display................................................................................................................................. 4 Monitor Display............................................................................................................. 4-6 Main Menu......................................................................................................................... 6 Settings............................................................................................................................. 7-9 Video Setup........................................................................................................................ 10 Audio Setup....................................................................................................................... 11 Radio Operation........................................................................................................ 12-13 Media Center.............................................................................................................. 14-15 Copy, Paste, Delete, Select All, File View................................................................... 14 Play Audio/Video Files.................................................................................................... 15 Bluetooth Operation................................................................................................ 16-20 Bluetooth Setup............................................................................................................... 16 Pairing Your Phone................................................................................................... 17-18 Incoming Calls................................................................................................................. 19 Outgoing Calls................................................................................................................ 19 Phonebook Dialing..................................................................................................... 20 AV (A2DP Audio Playback over Bluetooth)................................................................. 20 Camera............................................................................................................................... 21 Camera Control........................................................................................................... 21 Navigation (optional)...................................................................................................... 22 Notes................................................................................................................................... 23 Copyright © 2023 Xite Solutions North America. All Rights Reserved | User Manual Version 230515.01 Page 1 DISCLAIMER THIS IS A DISCLAIMER OF LIABILITY AND DAMAGE RESPONSIBILITY IN REGARDS TO THE INFOTAINMENT CENTER MANUFACTURER AND YOUR USE OF THE PRODUCT. YOU ASSUME TOTAL RESPONSIBILITY AND RISK FOR USING THIS SYSTEM. Failure to properly focus on the operation of your motor vehicle can result in death, serious injury and property damage. The Infotainment Center should never be used at a time or in a manner that distracts you from properly focusing on operation of the motor vehicle in which it is installed. Always operate the vehicle in a safe manner and in full compliance with speed limits, road safety signs and all other laws and devices which regulate operation of a motor vehicle. Always remain aware of driving conditions at all times when using this system while operating a motor vehicle. Operation of this unit, including its camera, audio and other features can be distracting to your operation of the motor vehicle. While the system is intended to provide both entertainment and helpful vehicle information, it is not intended to, nor should you allow it to, distract you from properly focusing on operating the motor vehicle in which it is installed. It is up to you to minimize or prevent such distraction. Learn how to use this system before placing the vehicle in operation. Minimize the amount of time spent viewing the screen of the unit while driving and use voice prompts whenever possible. Do not attempt to adjust settings of the system or resolve any malfunction with it while driving. Instead, pull o the road in a safe and legal manner, and then adjust its settings or deal with any malfunction. In the event of serious malfunction, disable the unit (turn power o or remove power from the system) and contact qualified service personnel. IT IS YOUR RESPONSIBILITY TO ENSURE THE ROADS YOU ARE TRAVELING ARE APPROPRIATE FOR THE VEHICLE YOU ARE DRIVING. If your Infotainment Center includes optional navigation features please refer to your navigation user manual for further specific information regarding its features, warnings, instructions and disclaimers. CAUTION: RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. CAUTION: FOLLOW THE LAWS AND REGULATIONS OF YOUR STATE, PROVINCE OR COUNTRY FOR INSTALLATION. Look for this icon for help tips on many screens. Note: Some screens may appear dierent, depending on device and model. For Technical and Warranty questions please contact our Techni…

Text truncated - open the document above for the full version.

CERTIFICATE OF COMPLIANCE  Supplier’s Declaration of Conformity with The Part2 and Part15 of FCC 47 CFR Requirement Product Name In-vehicle Infortainment System Model Name : CT90118CS Add Model Name : - Manufactures Name : Glosys Inc. (Address) #510 Venture Valley B/D, 958, GosaekDong, GwonseonGU, Suwon-si, South Korea Responsible party : Xite Solutions USA LLC (Address) 1620 Commerce Drive, South Bend, Indiana, 46628, USA (Telephone Number) Rule Part(s) : FCC Part 15 subpart B Test Procedure(s) : ANSI C63.4(2014) Reference Test Report : DST-23E-0686(1) by DSTech Co., Ltd. This document declare that this device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operating. Date of issued : August. 13, 2024 Signature of authorized person : Youngjin Choi / Head of Sales & Marketing Glosys Inc.

Glosys Inc. Address : #510 Venture Valley DB/D, 40 Omokcheon-Ro 152 Beon-gil, Gwonseon-Gu, Suwon-si, Gyeonggi-do, Korea Certification Attestation Statements Attn: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: August 7, 2024 FCC ID : YE48CS Applicant FRN : 0019831015 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing Glosys Inc. ("the applicant") certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Signature (Please add) Name: Youngjin Choi Title: Project Manager Company: Glosys Inc. Tel # +82-31-377-1450 Glosys Inc. Address : #510 Venture Valley DB/D, 40 Omokcheon-Ro 152 Beon-gil, Gwonseon-Gu, Suwon-si, Gyeonggi-do, Korea Attn: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: August 7, 2024 FCC ID : YE48CS Applicant FRN : 0019831015 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing Glosys Inc. ("the applicant") certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Signature (Please add) Name: Youngjin Choi Title: Project Manager Company: Glosys Inc. Tel # +82-31-377-1450

Glosys Inc. #510 Venture Valley DB/D, 40 Omokcheon-Ro 152 Beon-gil, Gwonseon-Gu, Suwon-si, Gyeonggi-do, Korea T el: +82-31-291-1450 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: August 06, 2024 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID : YE48CS Applicant FRN : 0019831015 Glosys Inc. certifies that, as of the date of the filing of the application, FCC US AGENT, LLC. is our designated U.S. agent for service of process for the above referenced FCC ID. Glosys Inc. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. FCC US AGENT, LLC. accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: FCC US AGENT, LLC. U.S. Agent FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Tel.: 708-571-3148 Email: [email protected] Sincerely, Glosys Inc. FCC US AGENT, LLC. Young jin Choi // Project Manager Tim Payne Rev 1/26/2023

Glosys Inc. #510 Venture Valley DB/D, 40 Omokcheon-Ro 152 Beon-gil, Gwonseon-Gu, Suwon-si, Gyeonggi-do, Korea Tel: +82-31-291-1450 Date: June 28, 2023 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: YE48CS Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: PERMANENT Exhibit Type File Name Part List Part List.pdf Schematics Diagram(s) Schematics.pdf Operation description Operational Description.pdf Block diagram Block diagram.pdf And the above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Young jin Choi / Project Manager Glosys Inc.

Glosys Inc. #510 Venture Valley DB/D, 40 Omokcheon-Ro 152 Beon-gil, Gwonseon-Gu, Suwon-si, Gyeonggi-do, Korea Tel: +82-31-291-1450 Date: June 28, 2023 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 FCC ID : YE48CS To whom it may concern: I, the undersigned, hereby authorize Young-Jin, Lee of KES Co., Ltd. and hereafter referred to as KES Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Young-Jin, Lee of KES Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing KES Co., Ltd. as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; Glosys Inc. #510 Venture Valley DB/D, 40 Omokcheon-Ro 152 Beon-gil, Gwonseon-Gu, Suwon-si, Gyeonggi-do, Korea Tel: +82-31-291-1450 h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Young jin Choi / Project Manager Glosys Inc. REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee1 code contact in FCC database.

Model No.: CT90118CS Page 1 of 2 External photos Model No.: CT90118CS Page 2 of 2

Model No.: CT90118CS Page 1 of 1 Label photo

Model No.: CT90118CS Page 1 of 6 Internal photos Model No.: CT90118CS Page 2 of 6 Model No.: CT90118CS Page 3 of 6 Model No.: CT90118CS Page 4 of 6 Model No.: CT90118CS Page 5 of 6 Model No.: CT90118CS Page 6 of 6 PCB Antenna

Model Name : CT90118CS Page 1 of 1 RF exposure FCC ID : YE48CS According to FCC part 1.1310 : The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in § 1.1307(b) Limits for Maximum Permissible Exposure (MPE) f= frequency in ㎒ Friis transmission formula: Pd = (Pout×G)/(4×pi×R 2 ) Where, Pd = power density in ㎽/㎠ Pout = output power to antenna in ㎽ G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd the limit of MPE, 1 ㎽/㎠. If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Results Operation mode Frequency (㎒) Output Tune-up Average Max power (㏈m) Antenna gain (㏈i) Power density at 20 ㎝(㎽/㎠) Limit (㎽/㎠) BDR 2 402 ~ 2 480 -7.0 -4.54 0.000 014 1 EDR 2 402 ~ 2 480 -10.5 -4.54 0.000 006 1 Frequency range (㎒) Electric field strength(V/m) Magnetic field strength (A/m) Power density (㎽/㎠) Average time (A) Limits for Occupational / Control Exposures 300 – 1 500 -- -- f/300 6 1 500 - 100000 -- -- 5 6 (B) Limits for General Population / Uncontrol Exposures 300 – 1 500 -- -- f/1500 6 1 500 – 100 000 -- -- 1 30

DSTech Co., Ltd. EHRQJLO-XQJEXGDHUR<DQJMLP\XQ&KHRLQJX<RQJLQVL*\HRQJJLGR.RUHD 7(/)$; G DST-QP-16-F-TRF-03(1)200520 Prohibits the copying and re-issue of this report without DSTech approval. Pages: 1 / 49 TEST REPORT 1. Report No : DST-23E-0686(1)G G 2. Date of incoming : 2023.05.03 G 3. Applicant G • Name : Glosys Inc. G • Address : #510 Venture Valley B/D, 958, GosaekDong, GwonseonGU, Suwon-si, South Korea G 4. Manufacturer : Glosys Inc. G 5. Equipment G • Product Name : In-vehicle Infortainment System G • Model Name : CT90118CS G • Add Model Name : N/A G 6. Purpose of a report : FCC Marking G 7. Test Method Used : ANSI C63.4:2014 FCC Part 15 Subpart B (Class A digital device) IC ICES-003 Issue 6 (Class A) G 8. Date of Test : 2023.05.09 G 9. Test Result : Refer to the attached Test Result G G Affirmation Tested by :G Reviewed by: G Name : KIM, Yerin (Signature)G Name : KIM, JooHo (Signature)  The test results presented in this test report are limited only to the sample supplied by applicant and the use of this test report is inhibited other than its purpose. This test report shall not be reproduced except in full, without the written approval of DSTech Co., Ltd.   2024.08.13  DSTech Co., Ltd. G     Ȅ This test report is not related to KS Q ISO/IEC 17025 and KOLAS Scheme & procedure   (S(S(S(S(S(SS(SSigigigigiggigggiggggnanananananananananananananatututututututututututrerererererererererereeee) applicant and D ᜽ ᱱ ⪶ ᯙ ⦥ ᱶ ᇡ ᜽ ᱱ ⪶ ᯙ ᖝ ░ ḥᅙ ڎڌڈړڋڈڏڍڋڍ ڌڐڕڏڌڕڐڌ گڮڦ Report No.: DST-23E-0686(1) DST-QP-16-F-TRF-03(1)200520 Prohibits the copying and re-issue of this report without DSTech approval. Pages: 2 / 49 6GUV4GRQTV4GXKUKQP*KUVQT[  Revisions Issue Report No. Issued Date Description Approved by 0 DST-23E-0686 2023.05.19 Initial Release C.Y. Kim 1 DST-23E-0686 (1) (Reception number DST-24E-1647) 2024.08.13 Change of address J.H.Kim   D Report No.: DST-23E-0686(1) DST-QP-16-F-TRF-03(1)200520 Prohibits the copying and re-issue of this report without DSTech approval. Pages: 3 / 49  TABLE OF CONTENTS 1. Test Laboratory ......................................................................................................................... 4 2. General Information of EUT...................................................................................................... 5 2.1 Basic description of EUT ........................................................................................................ 5 2.2 Alternative type(s)/model(s); also covered by this test report. ................................................ 5 3. Test Summary ........................................................................................................................... 6 3.1 Applied standards and test results ......................................................................................... 6 4. Test Conditions ......................................................................................................................... 7 4.1 EUT and supporting equipment used during test ................................................................... 7 4.2 Description of EUT modification ............................................................................................. 8 4.3 Variations covered by this report ............................................................................................ 8 4.4 Additional information related to Testing ................................................................................ 8 4.5 EUT Operation Modes ........................................................................................................... 9 4.6 Test System layout on EUT and peripherals ........................................................................ 10 5. Test Results : Emission .......................................................................................................... 11 5.1 Conducted Emission Test .................................................................................................... 11 5.1.1 Test Condition .............................................................................................................. 11 5.1.2 Test Limits .................................................................................................................... 11 5.1.3 Test Equipment List ..................................................................................................... 11 5.1.4 Test Result of Conducted Emission ........................................................................... 11 5.2 Radiated Emission Test ....................................................................................................... 12 5.2.1 Test Condition .............................................................................................................. 12 5.2.2 Test Limits .................................................................................................................... 12 5.2.3 Test Equipment List ..................................................................................................... 13 5.2.4 Test Result of Radiated Emission............................................................................... 14 6. Photographs of Test Configuration ....................................................................................... 44 6.1 Photographs of Conducted Emission Test Configuration ........................................... 44 6.2 Photographs of Radiated Emission Test Configuration .............................................. 45 7. Photographs of EUT ............................................................................................................... 47 G D Report No.: DST-23E-0686(1) DST-QP-16-F-TRF-03(1)200520 Prohibits the copying and re-issue of this report without DSTech approval. Pages: 4 / 49 1. Test Laboratory G This report contains the resul…

Text truncated - open the document above for the full version.

ANT measurement results Table of contents 1. Product Information 1.1 General Features 1.2 Electrical Specifications 2. Pattern Specifications 3. Electrical Characteristics 4. Measurement Process 1. Product Information 1.1 General Features PART NUMBER BT ANT ANTENNA TYPE PCB Pattern Antenna APPLICATIONS Bluetooth 1.2 Electrical Specifications Frequency Range (TX) 2400MHz~2485MHz Frequency Range (RX) 2400MHz~2485MHz RADIATION PATTERN Omni-directional POLARIZATION Linear 2. Pattern Specifications 3. Electrical Characterristics 4. Measurement Process □ View of the measuring room Inside the measuring room Room Configuration □ Measuring instrument Set Condition Network Agilent 8753ES Analyzer Cable Semi-ridid (40mm, 60mm)

The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : RF-230254 Page 43 / 47 KES-QP16-F01(00-23-01-01) KES Co., Ltd. 3.7. Conducted band edge and out of band emissions Test procedure KDB 558074 v05r02 & ANSI 63.10-2013 Test setup EUT Attenuator Spectrum analyzer Test setting 1. Span = wide enough to capture the peak level of the in-band emission and all spurious emissions(e.g., harmonics) from the lowest frequency generated in the EUT up through the 10th harmonic. 2. RBW = 100 ㎑ 3. VBW ≥ 300 ㎑ 4. Detector = Peak 5. Number of sweep points ≥ 2 × Span/RBW 7. Trace mode = max hold 8. Sweep time = auto couple 9. The trace was allowed to stabilize Limit According to 15.247(d), in any 100 ㎑ bandwidth outside the frequency band in which the spread spectrum or digitally modulated intentional radiator is operating, the radio frequency power that is produced by the intentional radiator shall be at least 20 ㏈ below that in the 100 ㎑ bandwidth within the band that contains the highest level of the desired power, based on either an RF conducted or a radiated measurement, provided the transmitter demonstrates compliance with the peak conducted power limits. If the transmitter complies with the conducted power limits based on the use of RMS averaging over a time interval , as permitted under paragraph(b)(3) of this section , the attenuation required under this paragraph shall be 30 ㏈ instead of 20 ㏈. Attenuation below the general limits specified in section 15.209(a) is not required. In addition, radiated emission which in the restricted band, as define in section 15.205(a), must also comply the radiated emission limits specified in section 15.209(a) (see section 15.205(c)) The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : RF-230254 Page 44 / 47 KES-QP16-F01(00-23-01-01) KES Co., Ltd. Test result BDR(1Mbps) 2402 ㎒ 2442 ㎒ 2480 ㎒ The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : RF-230254 Page 45 / 47 KES-QP16-F01(00-23-01-01) KES Co., Ltd. EDR(3Mbps) 2402 ㎒ 2442 ㎒ 2480 ㎒ The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : RF-230254 Page 46 / 47 KES-QP16-F01(00-23-01-01) KES Co., Ltd. Hopping mode_BDR(1Mbps) Hopping mode_EDR(3Mbps) The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : RF-230254 Page 47 / 47 KES-QP1 6-F01(00-23-01-01) KES Co., Ltd. Appendix A. Measurement equipment Equipment Man u f actu rer Mod el S erial No. Calibration interval Calibration due. EMI Test R eceiver R &S ES U26 100552 1 year 2024.02.13 Spectrum Analyzer R&S FSV40 101002 1 year 2023.12.06 Spectrum Analyzer R&S FSV40 101725 1 year 2024.06.12 AT T ENUAT OR KEYSIGHT 8493C 82506 1 year 2024.01.17 Power Meter Anritsu ML2495A 1438001 1 year 2024.01.13 Pulse Power Sensor Anritsu MA2411B 1339205 1 year 2024.01.13 SIGNAL GENERAT OR KEYSIGHT N5182B MY59100115 1 year 2024.04.27 SIGNAL GENERAT OR Anritsu 68369B 002118 1 year 2024.01.14 BAND REJECT FILT ER MICRO-T RONICS BRM50702 G272 1 year 2024.01.12 Attenuator KEYSIGHT - - 1 year 2024.03.21 Loop Antenna Schwarzbeck FMZB1513 1513-257 2 years 2023.03.18 Horn Antenna A.H SAS-571 414 1 year 2024.01.16 Horn Antenna SCHWARZBECK BBHA9170 BBHA 9170550 1 year 2024.01.16 TRILOG- BROADBAND ANT ENNA VULB9163 Schwarzbeck 714 2 years 2024.04.19 Amplifier SONOMA INSTRUMENT 310N 186549 1 year 2025.02.13 PREAMPLIFIER HP 8449B 3008A00538 1 year 2024.04.30 BROADBAND AMP LIF IER SCHWARZBECK BBV9721 PS9721-003 1 year 2024.01.16 DC POWER SUPPLY AGILENT 6632B MY43004130 1 year 2024.06.17 Pe ri pheral de vices Device Man u f actu rer Mod el No. S erial No. Notebook computer LG Electronics Inc., LG15N54 504NZJV027828 Jig board - - - The end of test report

The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : RF-230254 Page 27 / 47 KES-QP16-F01(00-23-01-01) KES Co., Ltd. Duty cycle Regarding to KDB 558074 D01_v05 r02, 6. Measurements of duty cycle and transmission duration shall be performed using one of the following techniques: a) A diode detector and an oscilloscope that together have sufficiently short response time to permit accurate measurements of the on- and off-times of the transmitted signal. b) The zero-span mode on a spectrum analyzer or EMI receiver if the response time and spacing between bins on the sweep are sufficient to permit accurate measurements of the on- and off-times of the transmitted signal. Mode T on time (㎳) Period (㎳) Duty cycle (Linear) Duty cycle (%) Duty cycle correction factor (㏈) BDR(1 Mbps) 2.880 7.510 0.383 38.35 4.16 EDR(3 Mbps) 2.880 3.770 0.764 76.39 1.17 Duty cycle (Linear) = T on time/Period DCF(Duty cycle correction factor (㏈)) = 10log(1/duty cycle) BDR (1 Mbps) EDR (3 Mbps) The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : RF-230254 Page 28 / 47 KES-QP16-F01(00-23-01-01) KES Co., Ltd. Test results (Below 30 ㎒) Mode: BDR Distance of measurement: 3 meter Channel: 00 (Worst case) Parallel The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : RF-230254 Page 29 / 47 KES-QP16-F01(00-23-01-01) KES Co., Ltd. Test results (Below 1 000 ㎒) – Worst case Mode: BDR Distance of measurement: 3 meter Channel: 00 (Worst case) Horizontal // Vertical The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : RF-230254 Page 30 / 47 KES-QP16-F01(00-23-01-01) KES Co., Ltd. Test results (Above 1 000 ㎒) Mode: BDR Distance of measurement: 3 meter Channel: 00 - Spurious Frequency (㎒) Level (㏈㎶) Detect mode Ant. Pol. (H/V) CF (㏈) DCF (㏈) Field strength (㏈㎶/m) Limit (㏈㎶/m) Margin (㏈) 1 257.52 48.10 Peak H -8.16 - 39.94 74.00 34.06 1 398.52 53.93 Peak V -6.98 - 46.95 74.00 27.05 1 596.45 51.82 Peak V -6.06 - 45.76 74.00 28.24 1 731.20 49.75 Peak H -4.39 - 45.36 74.00 28.64 4 803.46 42.98 Peak H 5.16 - 48.14 74.00 25.86 4 803.93 43.13 Peak V 5.16 - 48.29 74.00 25.71 - Band edge Frequency (㎒) Level (㏈㎶) Detect mode Ant. Pol. (H/V) CF (㏈) DCF (㏈) Field strength (㏈㎶/m) Limit (㏈㎶/m) Margin (㏈) 2 354.01 44.78 Peak H -1.87 - 42.91 74.00 31.09 2 325.36 45.55 Peak V -1.88 - 43.67 74.00 30.33 Restricted band // Horizontal // Peak Restricted band // Vertical // Peak The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : RF-230254 Page 31 / 47 KES-QP16-F01(00-23-01-01) KES Co., Ltd. Horizontal // Peak for 1 ㎓ to 3 ㎓ Vertical // Peak for 1 ㎓ to 3 ㎓ Horizontal // Peak for 3 ㎓ to 18 ㎓ Vertical // Peak for 3 ㎓ to 18 ㎓ Note. 1. Average test would be performed if the peak result were greater than the average limit. The authenticity of this test report can be found on the verification page of our website (www.kes.co.kr). Report No. : RF-230254 Page 32 / 47 KES-QP16-F01(00-23-01-01) KES Co., Ltd. Mode: BDR Distance of measurement: 3 meter Channel: 40 Frequency (㎒) Level (㏈㎶) Detect mode Ant. Pol. (H/V) CF (㏈) DCF (㏈) Field strength (㏈㎶/m) Limit (㏈㎶/m) Margin (㏈) 1 061.34 47.18 Peak H -9.57 - 37.61 74.00 36.39 1 195.21 52.42 Peak V -8.68 - 43.74 …
