YI7HES2E4A0THOME ENERGY GATEWAY

NUCLEUS™ ENERGY MANAGER Operating Instructions and Limited Warranty gebrillion.com 49-50271 10-10 GE NUCLEUS™ OVERVIEW The Nucleus™ energy manager (Nucleus™) provides you with the insight to make better energy decisions that will reduce your energy consumption and save you money. The Nucleus™ does this by communicating with your utility’s Smart Meter to show your total energy consumption in kilowatt hours (kWh) as reported to your utility. It also provides you with an estimate of the cost of that total energy (this estimate will vary from your actual bill because it is established on base pricing for electricity and does not include the taxes, surcharges and recovery fees added by your utility when it calculates your monthly bill). Use the Nucleus™ to become better educated about your home energy consumption. Measure a device’s power and approximate cost to operate with the Nucleus™ while you experiment turning electricity-consuming devices on and off in your home. Also use it to track your daily approximate energy consumption as you work towards your energy savings goals. Knowledge of your energy consumption and the related costs of operation can assist you in making better choices about how to spend your energy dollar. In addition, the Nucleus™ can also provide an estimate of the energy consumed and the cost to operate other connected Brillion™-enabled devices, such as appliances and thermostats. These estimates, based upon GE product testing (which may be at variance from your actual energy consumption due to installation and usage differences) provide great insight into the energy required to run a load of dishes or to keep your refrigerator cold – information that can assist in pointing the way to energy savings. For example, by knowing the approximate cost of running a load of laundry, you can better appreciate the value of running only full loads. Use the Nucleus™ as your tool for discovering ways to save energy, reduce costs and decrease your carbon footprint. Before you begin – Read these instructions completely and carefully. For your safety – Read and observe all information in this manual. Note to Consumer – Keep these instructions with your Quick Start Guide for future reference. Completion time – about 1 hour IMPORTANT SAFETY INSTRUCTIONS WARNING: RISK OF ELECTRICAL SHOCK OR FIRE. MAY CAUSE INJURY AND/OR DEATH. • Operate this device only at the specified voltage and frequency as indicated on the Nucleus™ product label. • When connecting or disconnecting this device, always hold it by its sides. Keep fingers away from the metal part of the plug. • This device is a high-voltage component and therefore should not be opened for any reason. No user-serviceable parts are located inside the device. • This device is not intended for use in bathrooms, laundry areas, or similar indoor high humidity locations. • Keep this device away from all liquids. • Unplug this device from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. NOTICE: • This device shall only be used for its intended purpose as described in this Owner’s Manual. • Never force a connector into the Ethernet port. If the connector does not attach with a reasonable amount of force, they do not match. Verify the connector matches the port and that it is oriented correctly. • During standard use of this device, it is normal for the case to get warm. The case functions as a cooling surface that transfers heat from inside the unit to the cooler air outside. • The only way to turn off power to this device is to unplug it from the electrical outlet SAVE THESE INSTRUCTIONS SYSTEM REQUIREMENTS In order to install the Nucleus™ energy manager, you must have the following: Meter Requirements • AMI Zigbee™ Smart Energy Meter. Consult your local electricity provider to determine if the technology is available in your area. Operating System Requirements • Processor: Intel Pentium III 1 GHz or faster, Intel Core Duo 1.83 GHz or faster. • PC: Windows 7, Vista Home or Business with SP1, XP Home or Professional with SP3. • Macintosh: Mac OS 10.4, 10.5, or 10.6 • Ram: 512MB Minimum, 1GB Recommended • CD or CD/DVD drive. Network Requirements • A router is required in order to access the Nucleus™ energy manager on multiple home computers. • In order to access the Nucleus™ energy manager via wireless network, the computer must have a compatible 802.11 b/g wireless adapter AC Plug Provides power to the Nucleus™ energy manager. Ethernet Port The Ethernet Port is used to connect to an existing Ethernet Network. Reset Button This button is used to cycle power and also reset the password and network parameters of the Nucleus™ energy manager. LED Indicators These indicators are used to represent system status and will provide diagnostics in the unlikely event of a system malfunction INSTALLATION INSTRUCTIONS Insert the CD into the computer’s CD-ROM drive. Click “Setup Nucleus™ energy manager”. If you do not see this screen, access the setup CD directly. To do so, perform the following steps for your specific operating system: • Windows 7 Go to START then COMPUTER. Double click on your CD-Rom drive. • Windows Vista Go to START then COMPUTER. Double click on your CD-Rom drive. • Windows XP Go to START then MY COMPUTER and select your CD-ROM drive. Double click on SETUP.EXE. LED Indicator Ethernet Port Reset Button AC Plug (under unit) • MAC OS X Double click the CD on your desktop. Double click on SETUP. Follow the steps as outlined in the Getting Started Installation CD. CARE AND CLEANING First unplug the Nucleus™ energy manager, then wipe the module surface with a clean, damp cloth as needed. DO NOT submerse or hold under running water. IMPORTANT NOTE: FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between th…

Text truncated - open the document above for the full version.

eZEX Corporation Rm 508, Ssangyong IT Twin-tower 2, 442-5, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, South Korea TEL No : +82-31 - 608 - 4700 FAX No : +82-31-608 - 4701 October 08, 2012 Timco Engineering, Inc. 849 NW State Road 45 P.O.Box 370 Newberry,m Florida 32669 LETTER OF AUTHORIZATION To whom it may concern: We, the undersigned, hereby authorize LTA Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization for FCC ID: YI7HES2E4A0T. including signing of all documents relating to these matters. Any and all acts carried out by LTA Co., Ltd., on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from eZEX Corporation LTA Co.,LTD. (Contact Person) Contact name: Kyu-Hyun, LEE Position: Manager Phone:(82)31-323-6008 E-mail: [email protected] Sincerely, Suk Bum MOK Manager

eZEX Corporation Rm 508, Ssangyong IT Twin-tower 2, 442-5, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, South Korea TEL No : +82-31 - 608 - 4700 FAX No : +82-31-608 - 4701 October 08, 2012 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : eZEX Corporation FCC ID: YI7HES2E4A0T Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, eZEX Corporation. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give eZEX Corporation. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: Exhibit Type File Name Schematics CONF APPENDIX YI7HES2E4A0T SCH DIA.pdf Parts list CONF APPENDIX YI7HES2E4A0T PL.pdf Block diagram CONF APPENDIX YI7HES2E4A0T BLK DIA.pdf CONFIDENTIAL Operational description CONF APPENDIX YI7HES2E4A0T OpDes.pdf Internal Photos SHORT-TERM CONF YI7HES2E4A0T INT Photo.pdf User’s Manual SHORT-TERM CONF YI7HES2E4A0T Manual.pdf EXT Photo SHORT-TERM CONF YI7HES2E4A0T EXT Photo.pdf SHORT-TERM CONFIDENTIAL Test Photo SHORT-TERM CONF YI7HES2E4A0T Test Photo.pdf The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Suk Bum MOK Manager

eZEX Corporation Rm 508, Ssangyong IT Twin-tower 2, 442-5, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, South Korea TEL No : +82-31 - 608 - 4700 FAX No : +82-31-608 - 4701 October 08, 2012 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 In re : eZEX Corporation FCC Application for FCC ID: YI7HES2E4A0T To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite filing. Regards, Sincerely, Suk Bum MOK Manager

FCC ID: YI7HES2E4A0T Copyright ○ c 2012, LTA Co., Ltd. Page 1 of 3 M/N: HES2E4A0T Upper Lower FCC ID: YI7HES2E4A0T Copyright ○ c 2012, LTA Co., Ltd. Page 2 of 3 Front Rear FCC ID: YI7HES2E4A0T Copyright ○ c 2012, LTA Co., Ltd. Page 3 of 3 Side Side

FCC ID: YI7HES2E4A0T Copyright Ⓒ 2012, LTA Co., Ltd. SAMPLE LABEL & LOCATION

FCC ID: YI7HES2E4A0T Copyright ○ c 2012, LTA Co., Ltd. Page 1 of 5 Main Board - Front Main Board - Rear FCC ID: YI7HES2E4A0T Copyright ○ c 2012, LTA Co., Ltd. Page 2 of 5 Sub Board - Front Sub Board - Rear FCC ID: YI7HES2E4A0T Copyright ○ c 2012, LTA Co., Ltd. Page 3 of 5 Power Board - Front Power Board - Rear FCC ID: YI7HES2E4A0T Copyright ○ c 2012, LTA Co., Ltd. Page 4 of 5 Antenna (WLAN) Antenna (Zigbee 1) FCC ID: YI7HES2E4A0T Copyright ○ c 2012, LTA Co., Ltd. Page 5 of 5 Antenna (Zigbee 2) Internal photo

FCC ID: YI7HES2E4A0T ATTACHMENT ** MPE Calculations ** The MPE calculation for this exposure is shown below. The peak radiated output power (EIRP) is calculated as follows: EIRP = P + G EIRP = 22.09 dBm +3.75 dBi EIRP = 25.84 dBm Where, P = Power input to the antenna (mW) G = Power gain of the antenna (dBi) Power density at the specific separation: S = PG/(4R 2 π) S = (161.81 * 2.37) / (4 * 20 2 * π) S = 0.0764 mW/cm 2 Where, S = Maximum power density (mW/cm 2 ) P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm = limit for MPE) The Maximum permissible exposure (MPE) for the general population is 1 mW/cm 2 . The power density does not exceed the 1 mW/cm 2 limit. Therefore, the exposure condition is compliant with FCC rules. Estimated safe separation: R = √(PG / 4π) R = √(161.81 * 2.37/ 4π) R = 5.53 Cm Where, P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm = limit for MPE) The numeric gain(G) of the antenna with a gain specified in dB is determined by: G = Log -1 (dB antenna gain / 10) G = Log -1 (3.75 / 10) G = 2.37

Ref. No.: LR500111208E Copyright ○ c 2012, LTA Co., Ltd. Page 1 of 89 243 Jubug-Ri,Yangji-Myeon, Yongin-Si, Gyeonggi-Do, Korea 449-822 Tel: +82-31-323-6008 Fax: +82-31-323-6010 http://www.ltalab.com Dates of Tests : August 01~20, 2012 Test Report S/N: LR5001111208E Test Site : LTA CO., LTD CERTIFICATION OF COMPLIANCE FCC ID APPLICANT Equipment Class : Digital Transmission System (DTS) Manufacturing Description : Home Energy Gateway Manufacturer : SEP CO., LTD. Brand Name : General Electric (GE) Model Name : HES2E4A0T Test Device Serial No.: : Identical prototype Rule Part(s) : FCC Part 15.247 Subpart C; ANSI C-63.4-2003 Frequency Range : 2412MHz ~ 2462MHz (802.11b/g/n) 2405MHz ~ 2480MHz (Zigbee 1, 2) Max. Output Power : Max 20.92dBm - Conducted (802.11b) Max 22.09dBm - Conducted (802.11g) Max 20.87dBm - Conducted (802.11n) Max 21.67dBm - Conducted (Zigbee 1) Max 21.57dBm - Conducted (Zigbee 2) Data of issue : August 16, 2012 This test report is issued under the authority of: The test was supervised by: Kyu-Hyun Lee, Manager Jung-Moo Her, Test Engineer This test result only responds to the tested sample. It is not allowed to copy this report even partly without the allowance of the test laboratory. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. NVLAP LAB Code.: 200723-0 YI7HES2E4A0T eZEX Corporation Ref. No.: LR500111208E Copyright ○ c 2012, LTA Co., Ltd. Page 2 of 89 TABLE OF CONTENTS 1. GENERAL INFORMATION ---------------------------------------------------------------------------- 2. PRODUCT INFORMATION -------------------------------------------------------------------------- 3. TEST REPORT --------------------------------------------------------------------------------------------- 3.1 SUMMARY OF TESTS ------------------------------------------------------------------------------ 3.2 TECHNICAL CHARACTERISTICS TEST(802.11b/g/n) ----------------------------------------- 3.2.1 6dB BANDWIDTH ------------------------------------------------------------------------------ 3.2.2 PEAK OUTPUT POWER ----------------------------------------------------------------------- 3.2.3 POWER SPECTRAL DENSITY --------------------------------------------------------------- 3.2.4 BAND – EDGE & SPURIOUS ----------------------------------------------------------------- 3.2.5 FIELD STRENGTH OF HARMONICS ---------------------------------------------------------- 3.2.6 AC CONDUCTED EMISSIONS -------------------------------------------------------------- 3.3 TECHNICAL CHARACTERISTICS TEST(Zigbee) ------------------------------------------------- 3.3.1 6dB BANDWIDTH ------------------------------------------------------------------------------ 3.3.2 PEAK OUTPUT POWER ----------------------------------------------------------------------- 3.3.3 POWER SPECTRAL DENSITY --------------------------------------------------------------- 3.3.4 BAND – EDGE & SPURIOUS ----------------------------------------------------------------- 3.3.5 FIELD STRENGTH OF HARMONICS ---------------------------------------------------------- 3.3.6 AC CONDUCTED EMISSIONS -------------------------------------------------------------- APPENDIX APPENDIX TEST EQUIPMENT USED FOR TESTS -------------------------------------------- 3 4 6 6 7 7 17 24 31 45 50 53 53 60 64 68 78 83 88 Ref. No.: LR500111208E Copyright ○ c 2012, LTA Co., Ltd. Page 3 of 89 1. General information 1-1 Test Performed Company name : LTA Co., Ltd. Address : 243, Jubug-ri,Yangji-Myeon,Youngin-Si, Kyunggi-Do, Korea. 449-822 Web site : http://www.ltalab.com E-mail : [email protected] Telephone : +82-31-323-6008 Facsimile +82-31-323-6010 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. 1-2 Accredited agencies LTA Co., Ltd. is approved to perform EMC testing by the following agencies: Agency Country Accreditation No. Validity Reference NVLAP U.S.A 200723-0 2013-09-30 ECT accredited Lab. RRL KOREA KR0049 2013-04-24 EMC accredited Lab. FCC U.S.A 610755 2014-04-27 FCC filing FCC U.S.A 649054 2013-04-13 FCC CAB VCCI JAPAN R2133(10m), C2307 2014-06-21 VCCI registration VCCI JAPAN T-2009 2013-12-23 VCCI registration VCCI JAPAN G-563 2015-05-28 VCCI registration IC CANADA 5799A-1 2015-06-21 IC filing Ref. No.: LR500111208E Copyright ○ c 2012, LTA Co., Ltd. Page 4 of 89 2. Product Information 2-1 Applicant Company name : eZEX Corporation Address : Rm 508, Ssangyong IT Twin-tower 2, 442-5, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, South Korea Tel / Fax : +82-31-608-4700 / +82-31-608-4701 2-2 Manufacturer Company name : SEP CO., LTD. Address : 2B-19LOT, 930, Gosaek-Dong, Gwonseon-gu, Suwon-si Gyeonggi-do, 441-813 Tel / Fax : +82-31-546-2200 / +82-31-546-2201 2-3 Equipment Under Test (EUT) Trade name : Home Energy Gateway Brand name : General Electric (GE) Model name : HES2E4A0T Serial number : Identical prototype Date of receipt : August 1, 2012 EUT condition : Pre-production, not damaged Antenna type : Chip antenna (M/N: SDBTPTR3015) with Max. 3.75 dBi gain Frequency Range : 2412MHz ~ 2462MHz (802.11b/g/n) 2405MHz ~ 2480MHz (Zigbee 1, 2) RF output power : Max 20.92dBm - Conducted (802.11b) Max 22.09dBm - Conducted (802.11g) Max 20.87dBm - Conducted (802.11n) Max 21.67dBm - Conducted (Zigbee 1) Max 21.57dBm - Conducted (Zigbee 2) Number of channels : 802.11b/g/n for 11 and Zigbee 1, 2 for 16 Type of Modulation : CCK, DQPSK, DBPSK for DSSS 64QAM, 16QAM, QPSK, BPSK for OFDM O-QPSK for Zigbee Transfer Rate : 11, 5.5, 2, 1 Mbps for 802.11b 54, 48, 36, 24, 18, 12, 9, 6 Mbps for 802.11g 65/72.2, 58.5/65, 52/57.8, 39/43.3, 26/28.9, 19.5/21.7, 13/14.4, 6.5/7.2Mbps for 802.11n Power Source : 120VAC Firmware Version : V1.0.0 Ref. No.: LR500111208E Copyright ○ c 2012, LTA Co., Ltd. Page 5 of 89 2-4 Tested frequency LOW MID HIGH Frequency (MHz) for 802.11b/g/n 2412 …

Text truncated - open the document above for the full version.

*Test Set-up Information EUT NOTE BOOK PRINTER Input: AC 120V LAN Cable RJ45 USB Cable AC Line FCC ID: YI7HES2E4A0T Copyright ○ c 2012, LTA Co., Ltd. Page 1 of 4 Radiated Emission (9kHz ~ 30MHz) FCC ID: YI7HES2E4A0T Copyright ○ c 2012, LTA Co., Ltd. Page 2 of 4 Radiated Emission (30MHz ~ 1GHz) FCC ID: YI7HES2E4A0T Copyright ○ c 2012, LTA Co., Ltd. Page 3 of 4 Radiated Emission (above 1GHz) FCC ID: YI7HES2E4A0T Copyright ○ c 2012, LTA Co., Ltd. Page 4 of 4 Conducted Emission
