YJKTSX6TTX6Touch Probe 2.4 GHz

7/2013 TT 460 Mounting Instructions Montageanleitung Instructions de montage Istruzioni di montaggio Instrucciones de montaje 取付説明書 安装说明 安裝指導手冊 설치 지침 preliminary Índice Página 4 Notas de aviso 8 Approval for radio transmission 12 Elementos suministrados 16 Dimensiones 20 Protocol of log 20 Montaje elemento de palpación 22 Montaje 26 cambiar palpador / vástago de unión 30 Battery exchange 32 Centering 34 Signal sequence Indice Pagina 4 Avvertenze 8 Approval for radio transmission 12 Standard di fornitura 16 Dimensioni 20 Protocol of log 22 Montaggio dell’elemento di tastatura 24 Montaggio 26 Sostituzione di spina di collegamento / elemento di tastatura 30 Battery exchange 32 Centering 34 Signal sequence Sommaire Page 4 Avertissement 8 Approval for radio transmission 12 Objet de la fourniture 16 Dimensions 20 Protocol of log 22 Montage élément de palpage 24 Montage 26 Remplacer la tige d’assemblage / élément de palpage 30 Battery exchange 32 Centering 34 Signal sequence Inhalt Seite 4 Warnhinweise 8 Funkerlaubnis 12 Lieferumfang 16 Abmessungen 20 Darstellung des Protokolls 22 Montage Antastelement 24 Montage 26 Verbindungsstift / Antastelement wechseln 30 Batteriwechsel 32 Zentrieren 34 Signalfolge 2 Contents Page 4 Warnings 8 Approval for radio transmission 12 Items supplied 16 Dimensions 20 Protocol of log 22 Mounting the probe contact 24 Mounting 26 Exchanging the connection pin / probe contact 30 Battery exchange 32 Centering 34 Signal sequence 목차 페이지 5 경고 10 Approval for radio transmission 14 제공 품목 18 규격 21 Protocol of log 23 Mounting the probe contact 25 Mounting 28 Exchanging the connection pin / probe contact 31 Battery exchange 33 Centering 35 Signal sequence 目錄 頁碼 5 警告 10 Approval for radio transmission 14 供應的項目 18 尺寸 21 Protocol of log 23 Mounting the probe contact 25 Mounting 28 Exchanging the connection pin / probe contact 31 Battery exchange 33 Centering 35 Signal sequence 目录 页 5 提示 10 Approval for radio transmission 14 零部件 18 尺寸 21 Protocol of log 23 Mounting the probe contact 25 Mounting 28 Exchanging the connection pin / probe contact 31 Battery exchange 33 Centering 35 Signal sequence 目次 ページ 5 注意事項 10 Approval for radio transmission 14 梱包品 18 寸法 21 Protocol of log 23 Mounting the probe contact 25 Mounting 28 Exchanging the connection pin / probe contact 31 Battery exchange 33 Centering 35 Signal sequence 3 Page 5 Warnings 10 Approval for radio transmission 14 Items supplied 18 Dimensions 21 Protocol of log 23 Mounting the probe contact 25 Mounting 28 Exchanging the connection pin / probe contact 31 Battery exchange 33 Centering 35 Signal sequence Contents Notas de aviso Atención: El montaje y la puesta en marcha deben ser realizados por un especialista cualificado, observando las prescripciones locales de seguridad. Calibrar el palpador, antes de la puesta en marcha, con el ciclo de calibración del control. Avvertenze Attenzione: Il montaggio e la messa in funzione devono essere eseguite da personale qualifucato nel rispetto delle norme di sicurezza locali. Calibrare il tastatore prima della messa in funzione con il ciclo di calibrazione del controllo numerico. Avertissement Attention: le montage et la mise en service doivent être assurés par un personnel qualifié dans le respect des consignes de sécurité locales. Avant la mise en service, étalonner le palpeur avec le cycle d’étalonnage de la commande. Warnhinweise Achtung: Die Montage und Inbetriebnahme ist von einer qualifizierten Fachkraft unter Beachtung der örtlichen Sicherheitsvorschriften vorzunehmen. Tastsystem vor Inbetriebnahme mit Kalibrierzyklus der Steuerung kalibrieren. 4 Warnings Note: Mounting and commissioning is to be conducted by a qualified specialist under compliance with local safety regulations. Calibrate the touch probe with the calibration cycle of the control before commissioning. 경고 주의: 설치 및 조정은 한국의 안전도 규정에 의하여 작업을 수행할 수 있는 공인된 기술자에 의해 수행되어야 합니다. Calibrate the touch probe with the calibration cycle of the control before commissioning. 警告 Calibrate the touch probe with the calibration cycle of the control before commissioning. 注意:安裝與調整要經由已認證的專業人員指導以符合當地安全規範要求。 提示 Calibrate the touch probe with the calibration cycle of the control before commissioning. 注意： 安装和调试时必须符合当地安全要求并由具有资质的专业人员操作 注意事項 注意：取付け及び試運転は設置国の安全規格のもとで有資格の専門家により実施するようにし てください。 Calibrate the touch probe with the calibration cycle of the control before commissioning. 5 Warnings Note: Mounting and commissioning is to be conducted by a qualified specialist under compliance with local safety regulations. Calibrate the touch probe with the calibration cycle of the control before commissioning. No dejar caer el palpador. Non far cadere il tastatore. Ne pas laisser tomber le palpeur. Tastsystem nicht fallen lassen. 6 Do not drop the touch probe. 터치 프루브를 떨어뜨리면 않됩니다. 探針請勿掉落. 请不要使测头跌落. タッチプローブを落とさないでください. 7 Do not drop the touch probe. USA FCC User information (USA only) acc. Section 15.19 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. acc. Section 15.21 Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. acc. Section 15.105 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communica- tions. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or tel…

Text truncated - open the document above for the full version.

7/2013 TS 460 TS 462 Mounting Instructions Montageanleitung Instructions de montage Istruzioni di montaggio Instrucciones de montaje 取付説明書 安装说明 安裝指導手冊 설치 지침 preliminary Índice Página 4 Notas de aviso 8 Funkerlaubnis 10 Elementos suministrados 14 Dimensiones 16 Darstellung des Protokolls 20 Montaje del cono 22 Cambio del vástago 24 Cambio de la batería 28 Centrado 32 Funktionsweise des Kollisionsschutz 34 Información técnica 36 Secuencia de la señal Indice Pagina 4 Avvertenze 8 Funkerlaubnis 10 Standard di fornitura 14 Dimensioni 16 Darstellung des Protokolls 20 Montaggio del cono 22 Sostituzione dello stilo 24 Sostituzione delle batterie 28 Centraggio 32 Funktionsweise des Kollisionsschutz 34 Dati tecnici 36 Treno di segnali Sommaire Page 4 Avertissement 8 Funkerlaubnis 10 Contenu de la fourniture 14 Dimensions 16 Darstellung des Protokolls 20 Montage du cône 22 Changement de la tige de palpage 24 Changement des batteries 28 Centrage 32 Funktionsweise des Kollisionsschutz 34 Caractéristiques techniques 36 Diagramme des signaux Inhalt Page 4 Warnings 8 Approval for radio transmission 10 Items Supplied 14 Dimensions 16 Protocol of log 20 Taper Mounting 22 Stylus Exchange 24 Battery Exchange 28 Centering 32 Functional principle of collision protection 34 Specifications 36 Signal Sequence 2 Contents Seite 4 Warnhinweise 8 Funkerlaubnis 10 Lieferumfang 14 Abmessungen 16 Darstellung des Protokolls 20 Kegelmontage 22 Taststiftwechsel 24 Batterienwechsel 28 Zentrieren 32 Funktionsweise des Kollisionsschutz 34 Technische Kennwerte 36 Signalfolge 페이지 5 경고 9 12 제공 품목 15 규격 18 21 테이퍼 설치 23 스타일러스 교체 26 배터리 교체 30 센터링 33 35 사양 37 신호 순서 頁碼 5 警告 9 12 供應的項目 15 尺寸 18 21 安裝刀把 23 探針更換 26 電池更換 30 中心定位 33 35 規格 37 信號程序 页 5 提示 9 12 零部件 15 尺寸 18 21 安装锥柄 23 更换测针 26 更换电池 30 定心 33 35 技术参数 37 信号顺序 ページ 5 注意事項 9 12 梱包品 15 寸法 18 21 シャンクへの取付け 23 スタイラスの交換 26 電池交換 30 センタリング（校正） 33 35 仕様 37 信号シーケンス 3 목차 目錄 目录 目次 ContentsPage 5 Warnings 9 Approval for radio transmission 12 Items Supplied 15 Dimensions 18 Protocol of log 21 Taper Mounting 23 Stylus Exchange 26 Battery Exchange 30 Centering 33 Functional principle of collision protection 35 Specifications 37 Signal Sequence   Notas de aviso Atención: El montaje y la puesta en marcha deben ser realizados por un especialista cualificado, observando las prescripciones locales de seguridad. No dejar caer el palpador. Avvertenze Attenzione: Il montaggio e la messa in funzione devono essere eseguite da personale qualifucato nel rispetto delle norme di sicurezza locali. Non far cadere il tastatore. Avertissement Attention: le montage et la mise en service doivent être assurés par un personnel qualifié dans le respect des consignes de sécurité locales. Ne pas laisser tomber le palpeur. Warnhinweise Achtung: Die Montage und Inbetriebnahme ist von einer qualifizierten Fachkraft unter Beachtung der örtlichen Sicherheitsvorschriften vorzunehmen. Tastsystem nicht fallen lassen. 4 Warnings Note: Mounting and commissioning is to be conducted by a qualified specialist under compliance with local safety regulations. Do not drop the touch probe. 경고 주의: 설치 및 조정은 한국의 안전도 규정에 의하여 작업을 수행할 수 있는 공인된 기술자에 의해 수행되어야 합니다. 터치 프루브를 떨어뜨리면 않됩니다. 警告 注意:安裝與調整要經由已認證的專業人員指導以符合當地安全規範要求。 探針請勿掉落. 提示 注意： 安装和调试时必须符合当地安全要求并由具有资质的专业人员操作   请不要使测头跌落. 注意事項 注意：取付け及び試運転は設置国の安全規格のもとで有資格の専門家により実施するようにし てください。 タッチプローブを落とさないでください. 5 Warnings Note: Mounting and commissioning is to be conducted by a qualified specialist under compliance with local safety regulations. Do not drop the touch probe. Retirar la tapa de protección de la batería antes de la primera puesta en marcha. Batteriefach mit einer Münze öffnen. Positionsmessgeräte nur aus PELV-Systemen (EN 50178) speisen. Hochfrequent niederohmige Erdung (EN 60204-1 Kap. EMV) vorsehen. Prima della messa in funzione rimuovere la protezione della batteria. Batteriefach mit einer Münze öffnen. Positionsmessgeräte nur aus PELV-Systemen (EN 50178) speisen. Hochfrequent niederohmige Erdung (EN 60204-1 Kap. EMV) vorsehen.  Enlever le capot de protection de la batterie avant la première mise en service. Batteriefach mit einer Münze öffnen. Positionsmessgeräte nur aus PELV-Systemen (EN 50178) speisen. Hochfrequent niederohmige Erdung (EN 60204-1 Kap. EMV) vorsehen. Vor erster Inbetriebnahme die Schutzkappe der Batterie entfernen. Batteriefach mit einer Münze öffnen. Positionsmessgeräte nur aus PELV-Systemen (EN 50178) speisen. Hochfrequent niederohmige Erdung (EN 60204-1 Kap. EMV) vorsehen. 6 Remove the battery’s protective cap before initial operation. Use a coin to open the battery compartment. Provide power to position encoders only from PELV systems (EN 50178). Provide high-frequency grounding with low impedance (EMC chapter in EN 60204-1).  초기 가동 전 보호 캡을 제거하세요. Use a coin to open the battery compartment. Provide power to position encoders only from PELV systems (EN 50178). Provide high-frequency grounding with low impedance (EMC chapter in EN 60204-1). “初始操作必須先行拆下電池保護蓋.” Use a coin to open the battery compartment. Provide power to position encoders only from PELV systems (EN 50178). Provide high-frequency grounding with low impedance (EMC chapter in EN 60204-1). 开始工作前拆下电池保护盖。 Use a coin to open the battery compartment. Provide power to position encoders only from PELV systems (EN 50178). Provide high-frequency grounding with low impedance (EMC chapter in EN 60204-1). 初期運転の前にバッテリーの保護キャップを取り外してください。 Use a coin to open the battery compartment. Provide power to position encoders only from PELV systems (EN 50178). Provide high-frequency grounding with low impedance (EMC chapter in EN 60204-1). 7 Remove the battery’s protective cap before initial operation. Use a coin to open the battery compartment. Provide power to position encoders only from PELV systems (EN 50178). Provide high-frequency grounding with low impedance (EMC chapter in EN 60204-1). USA FCC User information (USA only) acc. Section 15.19 This device complies with Part 15 of t…

Text truncated - open the document above for the full version.

Request for Confidentiality Date: 25.07.2013 Subject: Confidentiality Request for: FCC ID: YJKTSX6TTX6 IC: 11148A-TSX6TTX6 ______ Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: ______(Insert Explanation as Necessary)______ Dr. Johannes Heidenhain GmbH has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of (180) days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: Manager Certification Thomas Ring 1 - The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.”

FCC ID: YJKTSX6TTX6 IC: 11148A-TSX6TTX6 mikes-testingpartners gmbh File No. T36611-00-03HS, page 28 of 34 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.2, 2010-09-09 A t t a c h m e n t A Touch probe TS460 External view: FCC ID: YJKTSX6TTX6 IC: 11148A-TSX6TTX6 mikes-testingpartners gmbh File No. T36611-00-03HS, page 29 of 34 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.2, 2010-09-09 Internal view: FCC ID: YJKTSX6TTX6 IC: 11148A-TSX6TTX6 mikes-testingpartners gmbh File No. T36611-00-03HS, page 31 of 34 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.2, 2010-09-09 Touch probe TT460 External view: Internal view:

IC: 11148A-TSX6TTX6

FCC ID: YJKTSX6TTX6 IC: 11148A-TSX6TTX6 mikes-testingpartners gmbh File No. T36611-00-03HS, page 28 of 34 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.2, 2010-09-09 A t t a c h m e n t A Touch probe TS460 External view: FCC ID: YJKTSX6TTX6 IC: 11148A-TSX6TTX6 mikes-testingpartners gmbh File No. T36611-00-03HS, page 29 of 34 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.2, 2010-09-09 Internal view: FCC ID: YJKTSX6TTX6 IC: 11148A-TSX6TTX6 mikes-testingpartners gmbh File No. T36611-00-03HS, page 30 of 34 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.2, 2010-09-09 FCC ID: YJKTSX6TTX6 IC: 11148A-TSX6TTX6 mikes-testingpartners gmbh File No. T36611-00-03HS, page 31 of 34 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.2, 2010-09-09 Touch probe TT460 External view: Internal view: FCC ID: YJKTSX6TTX6 IC: 11148A-TSX6TTX6 mikes-testingpartners gmbh File No. T36611-00-03HS, page 32 of 34 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.2, 2010-09-09 FCC ID: YJKTSX6TTX6 IC: 11148A-TSX6TTX6 mikes-testingpartners gmbh File No. T36611-00-03HS, page 33 of 34 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.2, 2010-09-09 FCC ID: YJKTSX6TTX6 IC: 11148A-TSX6TTX6 mikes-testingpartners gmbh File No. T36611-00-03HS, page 34 of 34 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.2, 2010-09-09

FCC ID: YJKTSX6TTX6 IC: 11148A-TSX6TTX6 mikes-testingpartners gmbh File No. T36611-00-03HS, page 1 of 37 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.2, 2010-09-09 EMI − T E S T R E P O R T - FCC Part 15.249, RSS210 - Test Report No. : T36611-00-03HS 31. July 2013 ______________________________________________________________________________________________ Date of issue Type / Model Name : TS460, TS462, TT460 Product Description : Touch probe 2.4 GHz Applicant : Dr. Johannes Heidenhain GmbH Address : Dr. Johannes-Heidenhain-Str. 5 83301 TRAUNREUT Manufacturer : Dr. Johannes Heidenhain GmbH Address : Dr. Johannes-Heidenhain-Str. 5 83301 TRAUNREUT Licence holder : Dr. Johannes Heidenhain GmbH Address : Dr. Johannes-Heidenhain-Str. 5 83301 TRAUNREUT Test Result according to the standards listed in clause 1 test standards: POSITIVE The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test results without the written permission of the test laboratory. FCC ID: YJKTSX6TTX6 IC: 11148A-TSX6TTX6 mikes-testingpartners gmbh File No. T36611-00-03HS, page 2 of 37 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.2, 2010-09-09 Contents 1 T E S T S T A N D A R D S 3 2 S U M M A R Y 4 2.1 GENERAL REMARKS: 4 2.1 Test result summery 5 2.2 FINAL ASSESSMENT: 5 3 E Q U I P M E N T U N D E R T E S T 6 3.1 Photo documentation of the EUT – Please see attachment A 6 3.2 Power supply system utilised 6 3.3 Short description of the equipment under test (EUT) 6 4 T E S T E N V I R O N M E N T 7 4.1 Address of the test laboratory 7 4.2 Environmental conditions 7 4.3 Statement of the measurement uncertainty 7 4.4 Measurement protocol for FCC and IC 8 4.5 Determination of worst case measurement conditions 8 5 T E S T C O N D I TI O N S A N D R E S U L T S 9 5.1 Conducted emissions 9 5.2 Radiated emission of the fundamental wave 9 5.3 Spurious emissions radiated 11 5.4 EBW and OBW 22 5.5 Correction for pulse operation (duty cycle) 27 5.6 Antenna application 28 6 U S E D T E S T E Q U I P M E N T A N D A C C E S S O R I E S 29 A t t a c hm e n t A 30 FCC ID: YJKTSX6TTX6 IC: 11148A-TSX6TTX6 mikes-testingpartners gmbh File No. T36611-00-03HS, page 3 of 37 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.2, 2010-09-09 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules and Regulations Part 15, Subpart A - General (September, 2012) Part 15, Subpart A, Section 15.31 Measurement standards Part 15, Subpart A, Section 15.33 Frequency range of radiated measurements Part 15, Subpart A, Section 15.35 Measurement detector functions and bandwidths FCC Rules and Regulations Part 15, Subpart C - Intentional Radiators (September, 2012) Part 15, Subpart C, Section 15.203 Antenna requirement Part 15, Subpart C, Section 15.204 External radio frequency power amplifiers and antenna modifications Part 15, Subpart C, Section 15.205 Restricted bands of operation Part 15, Subpart C, Section 15.207 Conducted limits Part 15, Subpart C, Section 15.209 Radiated emission limits, general requirements Part 15, Subpart C, Section 15.249 Operation within the bands 902 - 928 MHz, 2400 - 2483.5 MHz, 5725 - 5875 MHz, and 24.0 - 24.25 GHz ANSI C63.4: 2003 Methods of Measurement of Radio-Noise Emissions from Low- Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. ANSI C95.1:2005 IEEE Standard for Safety Levels with respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz CISPR 16-4-2: 2003 Uncertainty in EMC measurement CISPR 22: 2005 Information technology equipment EN 55022: 2006 FCC ID: YJKTSX6TTX6 IC: 11148A-TSX6TTX6 mikes-testingpartners gmbh File No. T36611-00-03HS, page 4 of 37 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.2, 2010-09-09 2 S U M M A R Y 2.1 GENERAL REMARKS: The EUT is a 2.4 GHz – transceiver for low power data transmission in the operating band of 2.4 GHz to 2.4835 GHz supporting 16 channels. Special test software is used for setting the test modes. Variants of the EUT For testing the TS460 was used. Antennas The following integrated antenna is used with the EUT: - PCB meander antenna. Operation frequency and channel plan The operating frequency is 2400 MHz to 2483.5 MHz. Transmit operating modes The EUT use O-QPSK and provide following data rate: 250 kbps (kbps = kilobits per second) TypeComment TS460Touch probe TS462Touch probe TT460Touch probe Channel Nof 02405 12410 22415 32420 42425 52430 62435 72440 82445 92450 102455 112460 122465 132470 142475 152480 FCC ID: YJKTSX6TTX6 IC: 11148A-TSX6TTX6 mikes-testingpartners gmbh File No. T36611-00-03HS, page 5 of 37 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.2, 2010-09-09 2.1 Test result summery Operating in the 2400 MHz – 2483.5 MHz band: FCC Rule Part RSS Rule Part Description Result 15.35(c) RSS-Gen, 4.5 Pulsed operation not applicable 15.203 RSS Gen, 7.1.2 Antenna requirement passed 15.204 RSS Gen, 7.1.1 External radio frequency power amplifiers passed 15.205(a) RSS-Gen, 7.2.2 Emissions in restricted bands passed 15.207(a) RSS Gen, 7.2.4 AC power line conducted emissions not applicable 15.215(c) EBW passed RSS-Gen, 4.6.1 OBW passed 15.249(a) RSS-210, A2.9(a) Field strength of fundamental passed 15.249(d) RSS Gen, 7.2.5 Out-of-band emission, radiated passed RSS-Gen, 7.2.6 Transmitter frequency stability not applicable The mentioned RSS Rule Parts in the above table are related to: RSS Gen, Issue 3, December 2010 RSS 210, Issue 8, December 2010 RSS 102, Issue 4, March 2010 2.2 FINAL ASSESSMENT: The equipment under test fulfills the EMI requirements cited in clause 1 test standards. Date of receipt of test sample : acc. to storage records Testing commenced on…

Text truncated - open the document above for the full version.

FCC ID: YJKTSX6TTX6 IC: 11148A-TSX6TTX6 mikes-testingpartners gmbh File No. T36611-00-03HS, page 9 of 35 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.2, 2010-09-09 5 T E S T C O N D I T I O N S A N D R E S U L T S 5.1 Conducted emissions For test instruments and accessories used see section 6 Part A 4. 5.1.1 Description of the test location Test location: NONE Remarks: Not applicable, the EUT is battery powered only. 5.2 Radiated emission of the fundamental wave For test instruments and accessories used see section 6 Part CPR 3. 5.2.1 Description of the test location Test location: Anechoic chamber 2 Test distance: 3 m 5.2.2 Photo documentation of the test set-up FCC ID: YJKTSX6TTX6 IC: 11148A-TSX6TTX6 mikes-testingpartners gmbh File No. T36611-00-03HS, page 11 of 35 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.2, 2010-09-09 5.3 Spurious emissions radiated For test instruments and accessories used see section 6 Part SER1, SER 2, SER 3. 5.3.1 Description of the test location Test location: OATS 1 Test location: Anechoic chamber 2 Test distance: 3 m 5.3.2 Photo documentation of the test set-up FCC ID: YJKTSX6TTX6 IC: 11148A-TSX6TTX6 mikes-testingpartners gmbh File No. T36611-00-03HS, page 12 of 35 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.2, 2010-09-09 FCC ID: YJKTSX6TTX6 IC: 11148A-TSX6TTX6 mikes-testingpartners gmbh File No. T36611-00-03HS, page 13 of 35 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.2, 2010-09-09 5.3.3 Applicable standard According to FCC Part 15C, Section 15.249 (d): Emission radiated outside of the specified frequency bands, except harmonics, shall be attenuated by at least 50 dB below the level of the fundamental or to the general radiated limit in FCC Part 15C, Section 15.209, whichever is the lesser attenuation. 5.3.4 Description of Measurement The radiated emissions from the EUT are measured in the frequency range of 9 kHz to 1000 MHz using a tuned receiver and appropriate broadband linearly polarized antennas. The set up of the EUT will be in accordance to ANSI C63.4. In the frequency range above 1 GHz a spectrum analyser is used with appropriate linear polarized antennas. If the emission level in peak mode complies with the average limit then testing will be stopped and peak values of the EUT will be reported, otherwise, the emission will be measured in average mode again and reported. During the test, the EUT was set into continuous transmitting mode modulated. Instrument settings: 9 kHz – 150 kHz RBW: 200 Hz 150 kHz - 30 MHz RBW: 9 kHz 30 MHz – 1000 MHz: RBW: 120 kHz 1000 MHz – 40 GHz RBW: 1 MHz FCC ID: YJKTSX6TTX6 IC: 11148A-TSX6TTX6 mikes-testingpartners gmbh File No. T36611-00-03HS, page 22 of 35 Ohmstrasse 2-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481240 Rev. No. 1.2, 2010-09-09 5.4 EBW and OBW For test instruments and accessories used see section 6 Part MB. 5.4.1 Description of the test location Test location: AREA4 5.4.2 Photo documentation of the test set-up 5.4.3 Applicable standard According to FCC Part 15, Section 15.215(c): Intentional radiators operating under the alternative provisions to the general emission limits, as contained in Section 15.217 through Section 15.257, must be designed to ensure that the 20 dB bandwidth of the emission is contained within the frequency band designated in the rule section under which the equipment is operated. 5.4.4 Description of Measurement The bandwidth is measured at an amplitude level reduced from the reference level by a specified ratio of -20 dB. The reference level is the level of the highest signal amplitude observed from the transmitter at the fundamental frequency. Alternative is the x-dB-down function of the analyser used. The EBW is than directly shown in the marker display. The measurement is performed with normal modulation and a transfer rate means the worst case. Spectrum analyser settings: RBW: 30 kHz, VBW: 100 kHz, Span: 6 MHz, Sweep time: auto, Detector: max. peak;
