YJW-12300PGPureGear Universal Cradle Vent Mount

PureGear Universal Cradle Vent Mount Type-C charging cable *1 User Manual *1 1. Connect the power supply and power up the product. 2. Place the phone/ear- phone/watch in the corresponding charging position and charge it normally. 1. Smartphone For non-MagSafe phones, please use an extra magnetic ring or MagSafe case to use this product. 2. Input compatibility: PD2.0-3.0 and other protocols 3. When the input is greater than 15V/3A, charge the phone 25W, headphones 5W, and watch 2.5W simultaneously 4. The maximum charging power is 25W for the iPhone 16-17 series and 15W for the iPhone 12-15 series; Samsung phones have a maximum charging power of 10W; The maximum charging power supported by Huawei Android and other mobile phones are 5W. Package Functional component Applicable Devices LED intelligent indicator Use steps Product specification 1. Do not over-squeeze or collide with the equipment. Caution 2. Please do not place it too close to the magnetic card (ID card, bank card, etc.) with a magnetic stripe or chip to avoid magnetic card failure. 3.Do not use 5V adapter as insufficient power which may cause charging interruption. Please use15V adapter for power supply. Size: 60x90mm Material: 105G copperplate paper Folding: Folding Double-sided printing 1. Power On: Indicator light illuminates. 2. Standby: Indicator light remains on. 3. Charging Indicator: Indicator light is off while the phone is charging. 4. Metal Detection: Indicator light flashes when a foreign object is detected while the phone is charging. 1.Mobile phone Wireless PureGear Universal Cradle Vent Mount Charging Area 2.Apple Watch USER MANUAL Wireless Charging Area 3.Charging indicator light 4.Earphone charging area 5.Type-C interface 1 2 3 4 5 • Material: PC+ABS+UV • Input9V⎓3A, 12V⎓3A, 15V⎓3A • Earphone output: 5W • Watch output: 2.5W • Phone output: 5W, 7.5W, 10W, 15W, 25W • Transmission Distance: ≤6mm • Charging Efficiency: 86% MAX • Frequency: Earphone: 115-205KHz Mobile phone: 115-205KHz, 360KHz Watch: 320-330KHz • Magnet: 16*N52 Magnets • Pulling Force: 1.2kg MAX FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Note: The Grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. such modifications could void the user's authority to operate the equipment. The device has been evaluated to meet general RF exposure requirement. To maintain compliance with FCC's RF exposure guidelines, the distance must be at least 20 cm between the radiator and your body, and fully supported by the operating and installation configurations of the transmitter and its antenna(s). *1

Superiorcommunications. Address:5027IrwindaleAve,Suite900IrwindaleAve,CA91706 Date:2026-08-13 FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Ref:AttestationStatementsPart2.911(d)(7)Filing SUBJECT:FCCApplicationforFCCID:YJW-12300PG FRN:0019944727 (“Superiorcommunications.”)certifiesthat,asofthedateofthefilingoftheapplication, Superiorcommunications.isourdesignatedU.S.agentforserviceofprocessfortheabove referencedFCCID.(“Superiorcommunications.”)acceptstomaintainanagentfornoless thanoneyearafterthegranteehasterminatedallmarketingandimportationorthe conclusionofanyCommission-relatedproceedinginvolvingtheequipment. Superiorcommunications.accepts,asofthedateofthefilingoftheapplication,the obligationofthedesignatedU.S.agentforserviceofprocessfortheabovereferencedFCC ID. DesignatedU.S.AgentInformation: Name:Superiorcommunications. Address:5027IrwindaleAve,Suite900IrwindaleAve,CA91706 FRN:0019944727 ContactPerson:GeorgeChen Tel.:818-636-4985 Email:[email protected] Sincerely, Signedonbehalfof（Superior communications.） SignedonbehalfofSuperior communications. Name:GeorgeChenName:GeorgeChen Title:VPProductDevelopmentTitle:VPProductDevelopment Date:2026-08-13Date:2026-08-13

Rev1/26/2023 (Superiorcommunications.) FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:8-12-2026 Ref:AttestationStatementsPart2.911(d)(5)(i)Filing FCCID:YJW-12300PG (“Superiorcommunications.”)certifiesthattheequipmentforwhichauthorizationissoughtisnot “covered”equipmentprohibitedfromreceivinganequipmentauthorizationpursuanttosection2.903of theFCCrules. (“Superiorcommunications.”)certifiesthattheequipmentforwhichauthorizationissoughtdoesnot includecybersecurityoranti-virussoftwareproducedorprovidedbyKasperskyLab,Inc.oranyofits successorsandassignees,includingequipmentwithintegratedKasperskyLab,Inc.(oranyofits successorsandassignees)cybersecurityoranti-virussoftwarepursuanttoDA-24-886andKDB986446 D01CoveredEquipmentGuidancesectionB(2a). Deviceisinherentlycompliantbasedonhardwarelimitationsorsoftwarecontrols. or ASoftwareBillofMaterials(SBOM)isprovidedtotheTCBforreview,and Theend-userorthirdpartiescannotinstalladditionalsoftwareonthisdevice. Sincerely, (Applicantsignature): (Applicantprintedname):GeorgeChen Rev1/26/2023 (Superiorcommunications.) FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:8-12-2026 Ref:AttestationStatementsPart2.911(d)(5)(ii)Filing FCCID:YJW-12300PG (“Superiorcommunications.”)certifiesthat,asofthedateofthefilingoftheapplication,Superior communications.isnotidentifiedontheCoveredList(asaspecificallynamedentityoranyofits subsidiariesoraffiliates)asanentityproducing“covered”equipment. Sincerely, (Applicantsignature): (Applicantprintedname):GeorgeChen

Superiorcommunications. Date:August13,2026 ProductModelNumber:12300PG FCCID:YJW-12300PG Towhomitmayconcern, Re:ProductCertificationRepresentativeAuthorizationLetter WeauthorizeQAILaboratoriesLtd.3980NorthFraserWay,BurnabyB.C. CanadaV5J5K5toactonourbehalfonallmattersconcerningtheabove namedequipment. Thisshallincludethefollowing: Testing Approvalapplicationsandprocedures WedeclarethatQAILaboratoriesLtd.isallowedtoforwardallinformation relatedtotheapprovalprojecttotheappliedcertificationbodyandtothe notificationentitiesandtodiscussanyissuesconcerningtheapproval application.AnyandallactscarriedoutbyQAILaboratoriesLtd.onour behalfshallhavethesameeffectasactsofourown. By: ContactListedonFCCWesbite Title:Manager Email:[email protected] Telephone:818-636-4985 Onbehalfof:Superiorcommunications.

Superiorcommunications. OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:August17,2026 Subject;RequestforConfidentiality FCCID:YJW-12300PG ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthese documentsmightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantage inthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure SoftwareSecurityRequirementsforUNIIdevices Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulations inTitle47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:GeorgeChen Title:VPProductDevelopment

FCCID:YJW-12300PG EUTPHOTOSExternalPhotos FCCID:YJW-12300PG FCCID:YJW-12300PG FCCID:YJW-12300PG FCCID:YJW-12300PG ※※※※※ENDOFREPORT※※※※※

30mm 3.6mm 28.4mm laser engraving laser engraving 41.2mm 36.7mm Model: 12300PG Input: 9V⎓3A, 12V⎓3A, 15V⎓3A Output: Wireless: 25W Smart watch: 2.5W Wireless earbuds: 5W Total: 32.5W (Max) FCC ID: YJW-12300PG Made in China G7NCD 20.7mm 21.8mm White film Mobile phone charging white silicone patch White silicone Character silk screen silver 877C Center alignment Positive Silk screen content White material Bottom shell silver metallic paintCharacters centered left and right Shaft missing Centered horizontally

FCCID:YJW-12300PG EUTPHOTOSInternalPhotos FCCID:YJW-12300PG FCCID:YJW-12300PG FCCID:YJW-12300PG FCCID:YJW-12300PG PhoneANT FCCID:YJW-12300PG . FCCID:YJW-12300PG FCCID:YJW-12300PG FCCID:YJW-12300PG FCCID:YJW-12300PG FCCID:YJW-12300PG AppleWatchANT FCCID:YJW-12300PG AirPodsANT FCCID:YJW-12300PG ※※※※※ENDOFREPORT※※※※※

ProjectNo.:ZHT-260707129W01-2 Page 1 of 12 RFExposureEvaluation FCCID: YJW-12300PG ApplicantName...............:Superiorcommunications. Address............................:5027IrwindaleAve,Suite900IrwindaleAve,CA91706 ManufacturerName.........:DongguanGaoyiElectronicCo.,Ltd Address............................:Room401,Building2,No.211HuanchangSouthRoad,ChangpingTown, Dongguan,Guangdong,China. Product............................:PureGearUniversalCradleVentMount Model(s)...........................:12300PG AdditionalModel(s)..........:/ Trademark.......................:PureGear ModelDifference..............:/ Preparedby.....................:GuangdongZhonghanTestingTechnologyCo.,Ltd. Address............................:Room104/201,Building1,YibaolaiIndustrialPark,Qiaotou,Fuhai Subdistrict,Bao'anDistrict,Shenzhen,Guangdong,China DateofReceipt................:July7,2026 DateofTest(s).................:July7,2026-July17,2026 DateofIssue....................:July17,2026 TestRequested...............:Selecttest(s)asrequestedbytheclient. TestStandard(s)..............: KDB680106D01WirelessPowerTransferv04 Intheconfigurationtested,theEUTcompliedwiththestandardsspecifiedabove. Preparedby:Reviewedby:Approvedby: KimiLu/EngineerBaretWu/DirectorLeviLee/Manager Note:Theresultsshowninthistestreportreferonlytothesample(s)testedunlessotherwisestated.Thistest reportshallnotbereproducedexceptinfull,withoutpriorwrittenapprovalofZHT.Thisdocumentmaybe alteredorrevisedbyZHT,personnelonly,andshallbenotedintherevisionofthedocument. ProjectNo.:ZHT-260707129W01-2 Page 2 of 12 TABLEOFCONTENTSPAGE 1.GENERALINFORMATION................................................................................................................................3 1.1.GENERALDESCRIPTIONOFEUT.......................................................................................................3 1.2.TESTMODES.........................................................................................................................................4 1.3.AUXILIARYEQUIPMENT.......................................................................................................................4 2.RFEXPOSURETEST........................................................................................................................................7 2.1.MEASURINGSTANDARD.....................................................................................................................7 2.2.REQUIREMENTS...................................................................................................................................7 2.3.LIMITS....................................................................................................................................................7 2.4.TESTSETUP..........................................................................................................................................8 2.5.TESTPROCEDURE...............................................................................................................................8 2.6.MEASUREMENTUNCERTAINTY.........................................................................................................8 2.7.TESTINSTRUMENTSLIST...................................................................................................................9 2.8.TESTRESULT........................................................................................................................................9 2.9.TESTPHOTOS.....................................................................................................................................10 ProjectNo.:ZHT-260707129W01-2 Page 3 of 12 1.GENERALINFORMATION 1.1.GENERALDESCRIPTIONOFEUT ProductName: PureGearUniversalCradleVentMount TestModelNo.: 12300PG Hardwareversion:V1.0 Softwareversion:V1.0 OperationFrequency:Phone:115-205kHz,360kHz AirPods:115-205kHz AppleWatch:320-330kHz Modulationtype:FSK AntennaType:InductiveloopcoilAntenna Antennagain:0dBi Powersupply:Input:9V3A,12V3A,15V3A Power:32.5WMAX PhoneOutput:5W,7.5W,10W,15W,25WMAX AirPods:Output:5W AppleWatchOutput:2.5W SampleNumber:260707129YP001 Remark:Theantennagainisprovidedbythecustomer,ifthedataprovidedbythecustomerisnotaccurate, GuangdongZhonghanTestingTechnologyCo.,Ltd.doesnotassumeanyresponsibility. ProjectNo.:ZHT-260707129W01-2 Page 4 of 12 1.2.TESTMODES TestModes: Mode1 ACMains+Phonechargingport(115-205kHz)-5W+AirPodschargingport-5W +AppleWatchchargingport-2.5W(BatteryStatus:≤1%) Mode2 ACMains+Phonechargingport(115-205kHz)-5W+AirPodschargingport-5W +AppleWatchchargingport-2.5W(BatteryStatus:50%) Mode3 ACMains+Phonechargingport(115-205kHz)-5W+AirPodschargingport-5W +AppleWatchchargingport-2.5W(BatteryStatus:≥98%) Mode4 ACMains+Phonechargingport(115-205kHz)-7.5W+AirPodschargingport-5W +AppleWatchchargingport-2.5W(BatteryStatus:≤1%) Mode5 ACMains+Phonechargingport(115-205kHz)-7.5W+AirPodschargingport-5W +AppleWatchchargingport-2.5W(BatteryStatus:50%)-5W Mode6 ACMains+Phonechargingport(115-205kHz)-7.5W+AirPodschargingport-5W +AppleWatchchargingport-2.5W(BatteryStatus:≥98%) Mode7 ACMains+Phonechargingport(115-205kHz)-10W+AirPodschargingport-5W +AppleWatchchargingport-2.5W(BatteryStatus:≤1%) Mode8 ACMains+Phonechargingport(115-205kHz)-10W+AirPodschargingport-5W +AppleWatchchargingport-2.5W(BatteryStatus:50%) Mode9 ACMains+Phonechargingport(115-205kHz)-10W+AirPodschargingport-5W +Watchchargingport-2.5W(BatteryStatus:≥98%)-5W Mode10 ACMains+Phonechargingport(360kHz)-MPP15W+AirPodschargingport-5W +AppleWatchchargingport-2.5W(BatteryStatus:≤1%) Mode11 ACMains+Phonechargingport(360kHz)-MPP15W+AirPodschargingport-5W +AppleWatchchargingport-2.5W(BatteryStatus:50%) Mode12 ACMains+Phonechargingport(360kHz)-MPP15W+AirPodschargingport-5W +AppleWatchchargingport-2.5W(BatteryStatus:≥98%) Mode13 ACMains+Phonechargingport(360kHz)-25W+AirPodschargingport-5W +AppleWatchchargingport-2.5W(BatteryStatus:≤1%) Mode14 ACMains+Phonechargingport(360kHz)-25W+AirPodschargingport-…

Text truncated - open the document above for the full version.

产 品 规 格 书/Product Specification Document 20240904002 2024/9/4 Customer Name P 鑫永源/Xin yong yuan roduct type DZ-RC25-K5.4-L6M Part N 苹果手表硬磁/Apple Watch magnetic material umber M TN221-ZBCP-00 Customer part number 1 编制/Compile审核/Review批准/Approval / 广东顶智电子科技有限公司 Guangdong Dingzhi Electronic Technology Co., Ltd. 工厂地址：广东省惠州市龙门县迎宾大道1231号一楼 Factory Address: 1st Floor, No. 1231, Yingbin Avenue, Longmen County, Huizhou City, Guangdong Province TEL :13147097490 Antenna type: Coil Antenna 产 品 规 格 书 Customer Name鑫永源/Xin yong yuan TN221-ZBCP-001 DZ-RC25-K5.4-L6M Part Number M20240904002 发行/修订记录/Release/Revision History VersionEffective Date 变更内容/原因/Change content / reason 0 核准/Approval 12024/9/4 新规格发行/New specification release Customer part number Specificati on Number 产 品 规 格 书 ♦、外形尺寸 (单位: mm) A7.6 ±1.0 B14.5 ±1.0 C20.0 ±1.0 D25.0 ±1.0 E10.0 ±1.0 F2.0 ±1.0 K6.0 ±1.5 H2.60 ±0.3 ♦、电气特性/Electrical Characteristics: 参数/Parameters规格/Specification测试条件/Test conditions L(W1 测试仪器/Testing instrument )5.4-5.6μH100KHz/1V■TH2816B DCR(W1)<200mΩ@ 25°C■CH-502BC Q>20 min100KHz/1V■TH1816B Customer Name鑫永源/Xin yong yuan TN221-ZBCP-001 DZ-RC25-K5.4-L6M Part Number M20240904002 Customer part number Specificati on Number Dimensions of the shape

承 认 书 SPECIFICATION FOR APPROVAL 客 户 名 称 深圳市高易电子有限公司 ： CUSTOMER`S NAME 客 户 料 号 EL.X.XQ00000015 ： CUSTOMER`S P/N 产 品 规 格 Y.A11.442 ： PRODUCT SPEC 制 作 日 期 2025年4月8日 ： ISSUE DATE 拟制 PREPARED BY 审核 CHECKED BY 批准 APPROVED BY 客户承认 CUSTOMER APPROVE 东莞市博红科技有限公司 DONGGUAN BOHONG TECHNOLOGY CO., LTD *本承认书请在首批下单生产此机种前回签 ，否则视为贵方默认此承认书内所有内容 * This acknowledgement form must be signed and returned before the first batch of orders for this model are placed. Otherwise, it will be regarded as your implicit acceptance of all the contents in this acknowledgement form. 工程部专用章 科 红 博 市 莞 东 技 有 限 公 司 Shenzhen high easy Electronics Co., LTD ADD：东莞市大朗镇富民中路533号4楼ADD:533 Fumin Middle Road, Dalang Town, Dongguan City TEL：0769-82866410 FAX：0769-82866409 Antenna type: Coil Antenna 东莞市博红科技有限公司 DONGGUAN BOHONG TECHNOLOGY CO., LTD SPECIFICATION FOR APPROVAL CUSTOMERCUSTOMER`S P/N EL.X.XQ00000015 ISSUE DATEPRODU 2025.4.8 CT SPEC Y.A11.442 SPECIFICATION CONTROL DRAWING REVISIONS REV DESCRIPTIONDATEISSUE BY APPROVAL BY A INITIAL2025年4月8日 工程部专用章 科 红 博 市 莞 东 技 有 限 公 司 东莞市博红科技有限公司 DONGGUAN BOHONG TECHNOLOGY CO., LTD SPECIFICATION FOR APPROVAL CUSTOMERCUSTOMER`S P/N EL.X.XQ00000015 ISSUE DATEPRODUCT SPEC Y.A11.442 2.DIMENSION： ISSUE 1.线圈之间需紧密绕线，间隙不得大于1/2线径；/The winding between the coils should be tightly wound, and the gap should not be greater than 1 /2 wire diameter; 2.线圈不得超出铁氧体磁片边缘；/The coil shall not exceed the edge of the ferrite disc; 3.线圈外观整洁，且产品所用之部品符合环境规范要求 ：RoHS，HF；/The coi Note： l appearance is clean, and the parts used in the product meet the environmental specifications: RoHS, HF; 4.高温胶带使用8mm宽度；/High temperature tape using 8mm width; CHECKAPPROVAL BYBYBY 工程部专用章 科 红 博 市 莞 东 技 有 限 公 司 2025.4.8 unitmm 东莞市博红科技有限公司 DONGGUAN BOHONG TECHNOLOGY CO., LTD SPECIFICATION FOR APPROVAL CUSTOMERCUSTOMER`S P/N EL.X.XQ00000015 ISSUE DATEPRODUCT SPEC Y.A11.442 4.CIRCUIT DIAGRAM 5.WINDING NOWINDINGWIRETURNSTAPEWINDING CONDITION N1S-FØ0.08*105P10 / CCW 6.CHARACTERISTIC ITEMMEASURED POINTTECHNICAL DATATESTING CONDITION & INSTRUMENT LS S-F6.5uH±10% LCR1062 100KHz/1V AT 25°C±2°C Q S-F60 Min LCR1062 100KHz/1V AT 25°C±2°C DCR S-F48mΩ Max LCR1062 1KHz/0.3V AT 25°C±2°C 工程部专用章 司 公 限 有 技 科 红 博 市 莞 东 工程部专用章 司 公 限 有 技 科 红 博 市 莞 东 2025.4.8 东莞市博红科技有限公司 DONGGUAN BOHONG TECHNOLOGY CO., LTD SPECIFICATION FOR APPROVAL CUSTOMERCUSTOMER`S P/N EL.X.XQ00000015 ISSUE DATEPRODUCT SPEC Y.A11.442 7.THE PACKING WAY 工程部专用章 司 公 限 有 技 科 红 博 市 莞 东 工程部专用章 司 公 限 有 技 科 红 博 市 莞 东 Pearl-cotton specification 2025.4.8 东莞市博红科技有限公司 DONGGUAN BOHONG TECHNOLOGY CO., LTD SPECIFICATION FOR APPROVAL CUSTOMERCUSTOMER`S P/N EL.X.XQ00000015 ISSUE DATEPRODUCT SPEC Y.A11.442 1 2 3 4 5 6 7 8 9 10 工程部专用章 司 公 限 有 技 科 红 博 市 莞 东 2025.4.8 No.

ProjectNo.:ZHT-260707129W01-1 Page 1 of 26 FCCTESTREPORT FCCID:YJW-12300PG ApplicantName...............:Superiorcommunications. Address............................:5027IrwindaleAve,Suite900IrwindaleAve,CA91706 ManufacturerName.........:DongguanGaoyiElectronicCo.,Ltd Address............................:Room401,Building2,No.211HuanchangSouthRoad,ChangpingTown, Dongguan,Guangdong,China. Product............................:PureGearUniversalCradleVentMount Model(s)...........................:12300PG AdditionalModel(s)..........:/ Trademark........................:PureGear ModelDifference..............:/ Preparedby.......................:GuangdongZhonghanTestingTechnologyCo.,Ltd. Address.............................:Room104/201,Building1,YibaolaiIndustrialPark,Qiaotou,Fuhai Subdistrict,Bao'anDistrict,Shenzhen,Guangdong,China DateofReceipt.................:July7,2026 DateofTest(s)...................:July7,2026-July17,2026 DateofIssue.....................:July17,2026 TestRequested...............:Selecttest(s)asrequestedbytheclient. TestStandard(s)................:FCCCFRTitle47Part15SubpartC Testprocedure.................. : ANSIC63.10-2020+Cor.1-2023+C63.10a-2024+ErratatoC63.10a-2024 Intheconfigurationtested,theEUTcompliedwiththestandardsspecifiedabove. Preparedby:Reviewedby:Approvedby: KimiLu/EngineerBaretWu/DirectorLeviLee/Manager Note:Theresultsshowninthistestreportreferonlytothesample(s)testedunlessotherwisestated.Thistest reportshallnotbereproducedexceptinfull,withoutpriorwrittenapprovalofZHT.Thisdocumentmaybe alteredorrevisedbyZHT,personnelonly,andshallbenotedintherevisionofthedocument. ProjectNo.:ZHT-260707129W01-1 Page 2 of 26 TABLEOFCONTENTS 1.TESTSUMMARY......................................................................................................................................3 2.GENERALINFORMATION......................................................................................................................4 2.1GENERALDESCRIPTIONOFEUT...................................................................................................4 2.2TESTMODE.......................................................................................................................................5 2.3BLOCKDIAGRAMOFEUTCONFIGURATION................................................................................7 2.4TESTCONDITIONS...........................................................................................................................7 2.5DESCRIPTIONOFSUPPORTUNITS...............................................................................................7 3.TESTFACILITYANDTESTINSTRUMENTUSED.................................................................................8 3.1TESTFACILITY..................................................................................................................................8 3.2INSTRUMENTLISTFORALLTESTITEMS.....................................................................................8 3.3TESTINGSOFTWARE.......................................................................................................................9 3.4MEASUREMENTUNCERTAINTY...................................................................................................10 4.CONDUCTEDEMISSIONTEST............................................................................................................11 4.1CONDUCTEDEMISSIONMEASUREMENT...................................................................................11 4.1.1POWERLINECONDUCTEDEMISSIONLimits...........................................................................11 4.1.2TESTPROCEDURE......................................................................................................................11 4.1.3DEVIATIONFROMTESTSTANDARD.........................................................................................11 4.1.4TESTSETUP.................................................................................................................................12 4.1.5EUTOPERATINGCONDITIONS..................................................................................................12 4.1.6TESTRESULT...............................................................................................................................13 5.RADIATEDEMISSIONMEASUREMENT..............................................................................................15 5.1RADIATEDEMISSIONLIMITS........................................................................................................15 5.2ANECHOICCHAMBERTESTSETUPDIAGRAM...........................................................................16 5.3TESTPROCEDURE.........................................................................................................................16 5.4DEVIATIONFROMTESTSTANDARD............................................................................................16 5.5TESTRESULT..................................................................................................................................17 6.BANDWIDTHTEST................................................................................................................................21 7.ANTENNAREQUIREMENT...................................................................................................................25 8.TESTSETUPPHOTO............................................................................................................................26 9.EUTCONSTRUCTIONALDETAILS......................................................................................................26 ProjectNo.:ZHT-260707129W01-1 Page 3 of 26 1.TESTSUMMARY TestItemSectioninCFR47Result Antennarequirement15.203Pass ACPowerLineConductedEmission15.207Pass SpuriousEmission15.209(a)(f)Pass 20dBBandwidth15.215Pass NOTE: (1)”N/A”denotestestisnotapplicableinthisTestReport ProjectNo.:ZHT-260707129W01-1 Page 4 of 26 2.GENERALINFORMATION 2.1GENERALDESCRIPT…

Text truncated - open the document above for the full version.

Page1 of 4 承认书 SPECIFICATIONFORAPPROVAL 客戶： CUSTOMER: C006 客 戶 料 号： EL.X.XQ00000067 CUST P/N: 泛 亚 料 号： FINEP/N: FYC006014 产 品 型 号： DESC: FYC0062025082201 日期： DATE: 2026/01/07 版本： Version: A.2 CUSTOMER AUTHORIZEDSIGNATURE/客户承认签核 拟制 PREPARED BY 审核 CHECKED BY 批准 APPROVED BY 东莞市泛亚电子有限公司 DONGGUANFineElectronicCO..LTD. 刘屋科技东路 194 地址：东莞市石碣镇 Address: No. 194, Science and Technology East Road, Liuwu Town, Shijie District, Dongguan City 号 TEL ： 0769-22490287 / 224524 FAX ： 92 0769-22499451 E-mail ： [email protected] m Antenna type: Coil Antenna Page2 of 4 版本变更履历 VersionChangeHistory 版本 Rev. 变更前 BeforeChange 变更后 AfterChange 更改日期 ChangeDate 批准 ApprovedBy A.0--- 新发行/New release - 2025/08/26胡伟/Wei Hu The small adhesive tape has been changed from +15*0.08mm to a 18*0.08mm ordinary double-sided adhesive tape with a tear-off section (internal A.1 更新版本/ Updated version ) 2025/12/13胡伟/Wei Hu A.2 更新版本/ Updated version The size of lead D has been changed from 25 ± 2 to lead 25 ± 2, connected to AWG40*65P, L = 117 mm, ref. The total length of the D size is 140 ± 2. 2026/01/07胡伟/Wei Hu Page3 of 4 SPECIFICATION 产品型号： DESC FYC0062025082201 版本 Rev：A.2 客戶CUST: C006 泛亚料号FineP/N： FYC006014 客户料号CUSTP/N: EL.X.XQ00000067 一、尺寸DIMENSION:(mm) 二、原理图SCHEMATICDIAGRAM: A21.8±0.5 B39.3±0.5 C42.5±0.5 D125±2 D2140±2 E2-4 F0.85-0.95 G 三、绕线参数WindingSpecification 2.35 Max : 序号 NO. 端子 TERMINAL 线径 WIRE 圈数 Turns 绕线方向 WindingDirection 1SFAWG40*65P11TsCCW 四、电气特性ELECTRICALCHARACTERISTICS: 温度TEMPERATURE:25±10°C,湿度RELATIVEHUMIDITY:65±20% 序号 NO. 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TESTFREQUENCY 测试仪器 TESTEQUIPMENTS 1IND.S-F8.4uH±5%100KHz/1.0VTH2829LX 2DCRS-F≤85mΩ100KHz/1.0VTH2829LX 拟制 / 日期 PREPAREDBY/DATE 审核 / 日期 CHECKEDBY/DATE 批准 / 日期 APPROVEDBY/DATE Page4 of 4 SPECIFICATION 产品型号： DESC FYC0062025082201 版本 Rev：A.2 客戶CUST: C006 泛亚料号FineP/N： FYC006014 客户料号CUSTP/N: EL.X.XQ00000067 五、包装PACKONG: 5.1包装图片Packingpictures: 5.2包装数量及规格PackingQuantity: 5.3包装以现有包装盘为参照标准，以实际出货包装为准,如有特需要求可以定制。 Thepackagingshallbebasedontheexistingpackingplateandtheactualdeliverypackageshallprevail.If thereisanyrequirement,wecancustomizeit. 项目Item数量Quantity材料规格Material 盒Box 200PCS370*265*55mm 箱BigCarton 1000PCS420*270*310mm 拟制 / 日期 PREPAREDBY/DATE 审核 / 日期 CHECKEDBY/DATE 批准 / 日期 APPROVEDBY/DATE

FCCID:YJW-12300PG EUTTESTPHOTOS FCCID:YJW-12300PG ※※※※※ENDOFREPORT※※※※※
