YN5LK716BKeyboard

Bluetooth Keyboard Manual Item : LK-716B 1. Overview of keyboard: 2. Features: 1） Support iPad or iPhone OS4.0 or later, Android 3.1 or later 2） mobile phone(with bluetooth HID profile or driver, supporting bluetooth HID keyboard) 3） Support computer based on Windows XP/Vista/7/Mac etc 4） Using with non-BT equipped PC or Laptop require a USB bluetooth adapter 5） Universal wireless Bluetooth 3.0 connectivity 6） Dustproof, washable, and made by silicone 7） Built-in Li-battery charged by portable USB cable 8） Working range : 10m 3. Package Contents 1)Mini Bluetooth keyboard 2) User manual 3) USB cable Pairing iPad Bluetooth keyboard with iPad Preparation: Pls make sure your iPad has adequate battery and full charge your iPad keyboard prior to proceeding ( For first use ,pls charge it with supplied USB cable for at least 3 hours) Step 1: Toggle on the Power switch, the Power and Bluetooth Indicators should be lit for approximately 3 seconds. It is now in idle mode. Press the connect button 3-5seconds ,the Bluetooth Indicator should be flashing. It is now in pairing mode. Remark : The Bluetooth Indicator LED is blue, The charge Indicator LED is red, The Battery low indicator LED is Red. Step 2: On the iPad, tap setting, within the General tab, select Bluetooth. If Bluetooth is turned off by default, swipe to turn it on. The iPad should now be searching for all Bluetooth devices within range. Wait for Bluetooth Wireless keyboard to appear under devices. Step 3:Tap on Bluetooth wireless keyboard to connect, it is required to type in the 4-digit code according to the on-screen instruction. Hit enter, it should now be connected. Notice: 1. When low power, the LED will light up for 1 second and be blinking intermittently. 2. When charging, the LED will light up, and be off when full charging. Recharge the battery: Connect the mini Bluetooth Keyboard to your computer’s USB port by the power USB cable( you can find the cable in the retail box). FCC Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FC C Rules. These limits are desi gned to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. FCC Caution Any change or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.

Ersteller: D. Brandhorst Revision: 00 Erstelldatum: 07.03.2008 Datum: 00.00.00 Seite 1 von 1 PHOENIX TEST-LAB GmbH Product Certification Königswinkel 10 D 32825 Blomberg Date:2012-07-11 FCC ID: YN5LK716B Subject: Attestation Letter “Declaration of Conformity” Dear Sirs, Our products with the above FCC ID are defined as composite device. The transmitter is authorized under the “Certification” procedure. The device is also defined as “PC Periphery” acc to §15.101 Equipment authorization of unintentional radiators, where we hereby declare, that we apply and follow the “Declaration of Conformity” procedure. If you have any questions, please feel free to contact me at the address shown below. Yours sincerely, Signatory Signature Run Wang Title Compliance Engineer Shenzhen Lantian Electronics Co., Ltd.

Shenzhen Lantian Electronics Co., Ltd. PHOENIX TEST-LAB GmbH Product Certification Königswinkel 10 D 32825 Blomberg Date: 11.07.2012 Authority to Act as an Agent We declare that the following representative (agent) Name Mark Wen Position General Manager Company Name Most Technology Service Co., Ltd. Address No.5, 2 nd Langshan Road, North District, Hi-Tech Industrial Park, Nanshan, Shenzhen, Guangdong, China Tel / Fax 86-755-86170306/86-755-86170310 E-Mail [email protected] to act on our behalf on all matters concerning the application and documents submitted to PHOENIX TEST-LAB for product certification below Product Name Wireless Bluetooth Keyboard Model Name LK-716B Brand Name N/A We also authorize BZT – TCP Certification GmbH, Ms.Wanida Patthanavoj (address: Hermann - Loens - Weg 6, 15859 Storkow b. Berlin Germany) to process the application. Yours sincerely, Signatory Name Run Wang Position Engineer Company Name Shenzhen Lantian Electronics Co., Ltd. Address Building A2, Area 4, Fuqiao Industrial Park, Qiaotou Village, Fuyong Town, Bao’an Zone, Shenzhen Tel / Fax 86-755-29604957-333 /86-755-29604957-835 E-Mail [email protected] In case of FCC, we certify that we are not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance.

Shenzhen Lantian Electronics Co., Ltd. Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality Company name: Shenzhen Lantian Electronics Co., Ltd. FCC ID: YN5LK716B FCC Part 15 Certification Gentlemen, Pursuant to 47 CFR 0.457(d)(1)(ii) and 0.459 we hereby requests permanent confidentiality of the following documents for the subject application: Exhibit Type Description ☒ Schematics All circuitry of devices and component values ☐ Block Diagrams Details of device showing the frequency of all oscillators Bill Of Materials Parts list of the product for the radio device Operational Description Description of the circuit functions Note: Exhibit types that are commonly held confidential are: (1) Schematics, (2) Block Diagrams, (3) Bill Of Materials, (4) Operational Descriptions. Any exhibit NOT granted confidentiality is viewable on the FCC website as soon as a grant is issued. These documents contain detailed system and equipment description and related information about the product which we considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, we consider that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Yours sincerely, Signatory Name Run Wang Position Engineer Company Name Shenzhen Lantian Electronics Co., Ltd. Address Building A2, Area 4, Fuqiao Industrial Park, Qiaotou Village, Fuyong Town, Bao’an Zone, Shenzhen Tel / Fax 86-755-29604957-333 /86-755-29604957-835 E-Mail [email protected] ☒ ☒

FRONT VIEW OF SAMPLE BACK VIEW OF SAMPLE

Model Name:LK-716B FCC ID:YN5LK716B This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1)this device may not cause harmful interference, and (2)this device must accept any interference received,including interference that may cause undesired operation. MADE IN CHINA

INTERNAL PHOTO OF SAMPLE – 1 INTERNAL PHOTO OF SAMPLE – 2 INTERNAL PHOTO OF SAMPLE –3 INTERNAL PHOTO OF SAMPLE –4 INTERNAL PHOTO OF SAMPLE –5 INTERNAL PHOTO OF SAMPLE –6 PHOTO OF BATTERY

FCC 47 CFR PART 15 SUBPART C TEST REPORT For Applicant: Shenzhen Lantian Electronics Co., Ltd. Address: Building A2, Area 4, Fuqiao Industrial Park, Qiaotou Village, Fuyong Town, Bao’an Zone, Shenzhen Product Name: Wireless Bluetooth Keyboard Model Name: LK-716B Brand Name: N/A FCC ID: YN5LK716B Report No.: MTE/DAL/D12070898 Date of Issue: Jul. 10, 2012 Issued by:Most Technology Service Co., Ltd. Address: No.5, 2nd Langshan Road, North District, Hi-tech Industrial Park, Nanshan, Shenzhen, Guangdong, China Tel: 86-755-8617 0306 Fax : 86-755-8617 0310 The report consists 37 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by MOST. The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. FCC ID: YN5LK716B Report No.:MTE/DAL/D12070898 Page 2 of 37 TABLE OF CONTENTS 1. VERIFICATION OF CONFORMITY ............................................................................................................... 3 2. GENERAL INFORMATION ............................................................................................................................ 4 2.1 Product Information ...................................................................................................................................... 4 2.2 OBJECTIVE ................................................................................................................................................. 5 2.2 TEST STANDARDS AND RESULTS ............................................................................................................ 5 2.3 ENVIRONMENTAL CONDITIONS ............................................................................................................... 5 2.5 MEASUREMENT UNCERTAINTY ............................................................................................................... 5 3. TEST METHODOLOGY ................................................................................................................................. 6 3.1TEST FACILITY............................................................................................................................................. 6 3.2 Test Conditions ............................................................................................................................................. 6 3.3 Channel List ................................................................................................................................................. 7 3.4 Description of Test Modes ............................................................................................................................ 7 3.5 Table of Parameters of Text Software Setting............................................................................................... 8 3.6 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS..................................................................... 9 4. SETUP OF EQUIPMENT UNDER TEST ..................................................................................................... 10 4.1 SUPPORT EQUIPMENT............................................................................................................................ 10 4.2 TEST EQUIPMENT LIST ............................................................................................................................11 5. 47 CFR Part 15C 15.249 Requirements....................................................................................................... 12 5.1 SPURIOUS EMISSION TEST .................................................................................................................... 12 5.1.1 REQUIREMENT...................................................................................................................................... 12 5.1.2 TEST DESCRIPTION.............................................................................................................................. 13 5.1.3 TEST DESCRIPTION.............................................................................................................................. 14 5.1.4 TEST RESULT ................................................................................................................................... 14 5.2 BAND EDGE .............................................................................................................................................. 27 5.2.1 REQUIREMENT...................................................................................................................................... 27 5.2.2 TEST DESCRIPTION.............................................................................................................................. 27 5.2.3TEST RESULT ......................................................................................................................................... 27 5.3 LINE CONDUCTED EMISSION TEST ....................................................................................................... 30 5.3.1. LIMITS OF LINE CONDUCTED EMISSION TEST ................................................................................ 30 5.3.2. BLOCK DIAGRAM OF TEST SETUP..................................................................................................... 30 5.3.3. PRELIMINARY PROCEDURE OF LINE CONDUCTED EMISSION TEST ............................................ 31 5.3.4. FINAL PROCEDURE OF LINE CONDUCTED EMISSION TEST .......................................................... 31 5.3.5. TEST RESULT OF LINE CONDUCTED EMISSION TEST .................................................................... 32 5.4 20 dB Bandwidth ..............................................................…

Text truncated - open the document above for the full version.

CONDUCTED TEST SETUP RE TEST SETUP
