YNFBB6GSM MOBILE PHONE-GSM PORTION

BB6 User Manual I Contents 1.Getting to know your phone ............................ 1 1.1 Your Phone .................................................. 1 1.2 Status icons .................................................. 1 1.3 Installing SIM card and battery ..................... 1 1.4 Installing Storage card ................................. 2 1.5 Battery charging ........................................... 2 1.6 Power on/ off ................................................ 3 1.6.1 Power on ............................................... 3 1.6.2 Power off ............................................... 3 1.7 Using shortcut keys ...................................... 3 2.Using Call Function .......................................... 4 2.1 Making a call ................................................ 4 2.1.1 Directly call on Home Screen ................ 4 2.1.2 Make an international call ...................... 4 2.1.3 Dial an extension number ...................... 4 2.2 Answering or rejecting a call ........................ 4 2.2.1 Answer a call ......................................... 4 2.2.2 Reject a call ........................................... 4 2.3 Adjusting call volume ................................... 4 2.4 Ending a call ................................................ 4 3.Call logs ............................................................ 5 3.1 Dialed calls................................................... 5 3.2 Received calls .............................................. 5 3.3 Missed calls ................................................. 5 3.4 Rejected calls ............................................... 5 3.5 Delete all ...................................................... 5 3.6 Call timers .................................................... 5 3.7 Call cost ....................................................... 5 3.8 GPRS counter ............................................. 5 4.Profiles .............................................................. 6 4.1 Standard ...................................................... 6 4.2 Vibrate ......................................................... 6 4.3 High ring and vibrate ................................... 6 4.4 Low ring ....................................................... 6 4.5 Silent ........................................................... 6 5.Contacts ............................................................ 7 5.1 View a contact ............................................. 7 5.2 Adding a new contact .................................. 7 6.Message ............................................................ 8 6.1 Write message ............................................. 8 6.1.1 New SMS .............................................. 8 6.1.2 New MMS ............................................. 8 6.2 Inbox ............................................................ 8 6.3 Outbox ......................................................... 8 6.4 Drafts ........................................................... 8 6.5 Sentbox ....................................................... 8 6.6 Message setting .......................................... 8 6.6.1 Templates .............................................. 8 6.6.2 Voice mail server ................................... 8 6.6.3 Broadcast message .............................. 9 6.6.4 SMS settings ......................................... 9 6.6.5 MMS settings ........................................ 9 6.6.6 Message capacity ............................... 10 7.Internet ............................................................ 11 7.1 Input URL ................................................... 11 7.2 Homepage .................................................. 11 II 7.3 Bookmark .................................................. 11 7.4 History ....................................................... 11 7.5 Offline ........................................................ 11 7.6 WAP settings ............................................. 12 7.6.1 Browser settings .................................. 12 7.6.2 Network account ................................. 12 7.6.3 Preferred storage ................................ 12 7.6.4 GPRS setting ...................................... 12 7.6.5 Restore default .................................... 12 8.Multimedia ...................................................... 13 8.1 Camera ...................................................... 13 8.2 Video recorder ........................................... 13 8.3 Audio player ............................................... 13 8.3.1 Background audio player .................... 13 8.4 Video player ............................................... 14 8.5 Image browser ........................................... 14 8.6 Recorder .................................................... 14 8.7 FM radio .................................................... 14 8.8 File list ....................................................... 15 9.Tools ................................................................ 16 9.1 Alarm ......................................................... 16 9.2 Calendar .................................................... 16 10.Extra .............................................................. 17 10.1 Calculator ................................................ 17 10.2 Bluetooth ................................................. 17 10.3 E-Book reader ......................................... 17 11.Settings ......................................................... 18 11.1 Dual-SIM .................................................. 18 11.2 Call setup ................................................. 18 11.2.1 Network selection .............................. 18 11.2.2 Call divert ........................................... 19 11.2.3 Call barring......................................... 19 11.2.4 Call waiting......................................... 20 11.2.5 Hide ID ..............…

Text truncated - open the document above for the full version.

Antenna Switch Power Amplifier TRANSCEIVER Crystal 26MHz PMU MCU 128Mbit FLASH 32Mbit SRAM Crystal 32.768kHz GSM&DCS SAW filter SIM Block Audio Vibrator LCD Baseband part RF part FM BT

Newport Wholesale FCC ID: YNFBB6 POWER OF ATTORNEY December 14, 2010 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We, Newport Wholesale, hereby authorize Most Technology Service Co., Ltd. (Terry YANG/ Manager) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Most Technology Service Co., Ltd. (Terry YANG/ Manager) on our behalf shall have the same effect as acts of our own. This authorization expires on December 31, 2010. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, Newport Wholesale, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Newport Wholesale Golzar Yaghoubpour General Manager December 14, 2010

FCC ID: YNFBB6 Report No.: STS101203F4 FRONT VIEW OF SAMPLE BACK VIEW OF SAMPLE FCC ID: YNFBB6 Report No.: STS101203F4 LEFT VIEW OF SAMPLE RIGHT VIEW OF SAMPLE FCC ID: YNFBB6 Report No.: STS101203F4 TOP VIEW OF SAMPLE BOTTOM VIEW OF SAMPLE FCC ID: YNFBB6 Report No.: STS101203F4 PHOTO OF POWER SUPPLY PHOTO OF USB CABLE FCC ID: YNFBB6 Report No.: STS101203F4 PHOTO OF HEADPHONE PHOTO OF BATTERY FCC ID: YNFBB6 Report No.: STS101203F4 PHOTO OF THE ENTIRE SAMPLE

FCC ID: YNFBB6 Report No.: STS101203F4 INTERNAL PHOTO OF SAMPLE – 1 INTERNAL PHOTO OF SAMPLE –2 FCC ID: YNFBB6 Report No.: STS101203F4 INTERNAL PHOTO OF SAMPLE –3 INTERNAL PHOTO OF POWER SUPPLY-1 FCC ID: YNFBB6 Report No.: STS101203F4 INTERNAL PHOTO OF POWER SUPPLY-2

1/2 Operation Description OPERATIONAL DESCRIPTION APPLICANT: Newport Wholesale Manufacturer: HK ZHIXINDA TECHNOLOGY Co., LTD FCC ID: YNFBB6 Instruction Book: Users Manual Frequency Range GSM Transmit Frequency Band: 824.2-848.8 MHz Receive Frequency Band: 849.2-893.8 MHz Transmit Frequency Band: 1850.2-1909.8 MHz Receive Frequency Band: 1930.2-1989.8 MHz Specific Operating Power Range: Power Class 1; Power Control Level 0 +30dBm +2.0dB/-2.0dB Power Control Level 1 +28dBm +3.0dB/-3.0dB Power Control Level 2 +26dBm +3.0dB/-3.0dB Power Control Level 3 +24dBm +3.0dB/-3.0dB Power Control Level 4 +22dBm +3.0dB/-3.0dB Power Control Level 5 +20dBm +3.0dB/-3.0dB Power Control Level 6 +18dBm +3.0dB/-3.0dB Power Control Level 7 +16dBm +3.0dB/-3.0dB Power Control Level 8 +14dBm +3.0dB/-3.0dB Power Control Level 9 +12dBm +4.0dB/-4.0dB Power Control Level 10 +10dBm +4.0dB/-4.0dB Power Control Level 11 +8dBm +4.0dB/-4.0dB Power Control Level 12 +6dBm +4.0dB/-4.0dB Power Control Level 13 +4dBm +4.0dB/-4.0dB Power Control Level 14 +2dBm +5.0dB/-5.0dB Power Control Level 15 +0dBm +5.0dB/-5.0dB Note; Effective radiation efficiency is –3.7dB DC Voltage and Current into the Final Amplifier Module: Supply Voltage = 3.6Vdc Supply Current = ~0.8Amp. Tune-up Procedure: Tune-up Procedure Equipment Identification: Equipment's Identification label and its intended Location are as shown in EXHIBIT Type “ID Label / Location Information” (FCC ID Nameplate), and in EXHIBIT Type “Internal Photo”(Photograph of inside) Photographs: A complete set of the Photographs showing External and Internal Views of Circuit Details and Construction are provided by from EXHIBIT Type “External Photos” and “Internal Photos”. Accessories: 2/2 Operation Description Figure 1.2: Terminal Components (Accessories) Technical Descriptions TX synthesizer uses an Offset-PLL circuit. The Offset-PLL circuit consists of PLL-IC and TX_VCO and loop filter. Reference frequency of the above synthesizers is 26MHz and generated by VCTCXO. Control signal is sent from Baseband section and keeps frequency stability. TX IQ signal is input from Baseband section to MT6225, The Bluetooth signal is input form MT6601 and FM signal is input form MT6188C section to MT6225. TX IQ signal is applied to the quadrature up-converter, and the up-converter LO signal is generated from the transceiver VCO within MT6139B. This up-converter translates the GMSK-modulated signal to an intermediate frequency (IF) that forms one input to a frequency/phase detector circuit. This IF signal is the reference input to an Offset-PLL circuit. The feedback path of this Offset-PLL circuit includes a down-conversion from the RF output frequency range to the IF range. The two inputs to this down-conversion mixer are formed the TX_VCO output and the LO generation circuits. The mixer output is the offset feedback signal that forms the variable input to a frequency/phase detector circuit. The detector compares its variable input to its reference input and generates an error signal that is low-pass filtered by the loop filter and applied to TX_VCO to force the RF frequency in the direction that minimizes errors. The TX_VCO output passes PA, Antenna SW, Coaxial connector with switch and emitted from embedded antenna. Digital Modulation: Analog speech produced by a microphone is encoded to digital PCM samples using a CODEC. The PCM samples are passed to a Vocoder for AMR (Advanced Multi Rate) encoding, to compress the speech samples. The encoding rate is determined by the Vocoder which formats the speech samples as data packets. A new data packet with data rate information is read by the microprocessor every 20 ms. The speech CODEC becomes AMR, FR(Full Rate), EFR(Enhanced FR) and HR(Half Rate). The microprocessor then sends the data packet to the transmit subsystem, and passed DAC to covert analog signal. I/Q base band signal is filtered and is inputted into RTR6250 containing quadrature phase modulator. The Data Required (EXHIBIT “Test Report”): (2.1046) RF power output (2.1047) Modulation characteristics (2.1049) Occupied bandwidth (2.1051) Spurious emission at antenna terminals (2.1053) Field strength of spurious radiation (2.1055) Frequency stability (2.1057) Frequency spectrum to be investigated Battery AC Charger Accessories

P/ANUM 主料15 主料1 主料1 主料11 主料2 主料2 主料11 主料3 主料3 主料1 主料1 主料4 主料1 主料2 主料3 主料1 主料1 主料1 主料27 替代 料 27 替代 料 27 主料3 替代 料 3 主料4 主料4 主料1 主料4 主料1 主料1 主料3 主料3 主料4 主料3 主料4 主料1 主料10 主料1 主料2 主料1 主料3 主料6 主料16 主料1 主料16 主料8 主料2 主料7 主料1 替代1 主料1 替代1 主料3 替代3 主料1 替代1 替代1 主料2 替代2 替代2 主料1 替代1 替代1 主料6 替代6 主料3 替代3 主料1 替代 料 1 主料1 替代1 主料7 替代7 替代7 替代7 主料3 替代3 替代3 主料1 替代1 替代1 替代1 主料1 替代1 主料1 主料1 替代1 主料1 替代1 主料1 主料1 主料1 替代1 替代1 主料1 主料1 主料1 替代1 主料1 滤波器(850),EFCH881MTDA1,PANASONICPCS 滤波器(PCS),EFCH1960TDA1,PANASONICPCS U401 093H-2107-300362-000 电池连接器,普通,3.0pitch,8.4x3.5x6.2mmH,PAN30-03626-1500,LCN PCSJ301 096H-1800-881MTD-A10 电容,2.7pF,±0.25pF,50V,COG,0402PCS U400 095H-1800-140881-550滤波器(850),SF14-0881M5UB50/A1,KYOCERAPCSU401 094H-1800-001960-000 BOM C442 093H-1800-141960-550滤波器(PCS),SF14-1960M5UB50/A1,KYOCERAPCSU400 025H-0602-27FJ8A-B00 NO. 001H-0502-000JB0-B00R403,R411,R414,R503-R504,R521,R706,R800-R801,R810,R1202,R120 1,R1205- R1207 电阻,0 ohm,±5%,1/16W,0402PCS REF.DescriptionUNITCODE 002H-0502-036FE0-D00R300电阻,0.36 ohm,±1%,1/4W,0805PCS 003H-0502-100JB0-B00R310电阻,10 ohm,±5%,1/16W,0402PCS 004H-0502-330JB0-B00R202-R203,R903-R904,R1002-R1004,R1009,R1012-R1014电阻,33 ohm,±5%,1/16W,0402PCS 005H-0502-101JB0-B00R600,R604电阻,100 ohm,±5%,1/16W,0402PCS 006H-0502-511JB0-B00R605-R606电阻,510 ohm,±5%,1/16W,0402PCS 007H-0502-102JB0-B00R231,R405-R408,R601,R615,R941,R942,R1000,R1203电阻,1K ohm,±5%,1/16W,0402PCS 008H-0502-152JB0-B00R208,R608-R609电阻,1.5K ohm,±5%,1/16W,0402PCS 009H-0502-202JB0-B00R614,R802-R803电阻,2K ohm,±5%,1/16W,0402PCS 010H-0502-512JB0-B00R1245电阻,5.1K ohm,±5%,1/16W,0402PCS 011H-0502-622FB0-B00R201电阻,6.2K ohm,±1%,1/16W,0402PCS 012H-0502-103JB0-B00R206,R505,R523,R525电阻,10K ohm,±5%,1/16W,0402PCS 013H-0502-153JB0-B00R401电阻,15K ohm,±5%,1/16W,0402PCS 014H-0502-203JB0-B00R621,R622电阻 20K ohm,±5%,1/16W,0402PCS 015H-0502-473JB0-B00R623,R1115-R1116电阻,47K ohm,±5%,1/16W,0402PCS 016H-0502-753JB0-B00R624电阻,75K ohm,±5%,1/16W,0402PCS 017H-0502-104JB0-B00R1133电阻,100K ohm,±5%,1/16W,0402PCS 018H-0502-154JB0-B00R213电阻,150K ohm,±5%,1/16W,0402PCS 019H-0504-502050-B00VR600-VR605,VR701,VR902-VR904,VR1000-VR1004,VR1101-VR1108,VR 1113- VR1116 ESD,压敏电阻,0402,AVLC5S02050,AMOTECHPCS 020H-0504-050550-000VR600-VR605,VR701,VR902-VR904,VR1000-VR1004,VR1101-VR1108,VR 1113- VR1116 ESD压敏电阻,ICVS0505500FR,0402,ICTPCS 021H-0504-100555-400VR600-VR605,VR701,VR902-VR904,VR1000-VR1004, VR1101-VR1108 ,V R1113-VR1116 ESD,压敏电阻,0402,SDV1005E5R5C400NPTF,SunlordPCS 022H-0504-AVRC5S-050RCN701-RCN7034路EMI+ESD保护(25pF+100 ohm),AVRC5S05Q050,AMOTECHPCS 023H-0504-210542-501RCN701-RCN7034路EMI+ESD保护(25pF+100 ohm),ICVE21054E250R101FR,ICTPCS 024H-0602-15FC8A-B00C414-C417电容,1.5pF,±0.25pF,50V,COG,0402PCS 025H-0602-22FC8A-B00C404-C405,C432-C433电容,2.2pF,±0.25pF,50V,COG,0402PCS 026H-0602-33FC8A-B00C425-C426,C428-C429电容,3.3pF,±0.25pF,50V,COG,0402PCS 027H-0602-39FB8A-B00C440电容,3.9pF,±0.1pF,50V,COG,0402PCS 028H-0602-47FD8A-B00C418电容,4.7pF,±0.5pF,50V,COG,0402PCS 029H-0602-100J8A-B00C401,C1204-C1205电容,10pF,±5%,50V,COG,0402PCS 030H-0602-220J8A-B00C203-C204,C456电容,22pF,±5%,50V,COG,0402PCS 031H-0602-270J8A-B00C431,C912,C1100,C1103电容,27pF,±5%,50V,COG,0402PCS 032H-0602-330J8A-B00C410-C411,C441电容,33pF,±5%,50V,COG,0402PCS 033H-0602-470J8A-B00C312,C435,C619,C622电容,47pF,±5%,50V,COG,0402PCS 034H-0602-560J8A-B00C455电容,56pF,±5%,50V,COG,0402PCS 035H-0602-101J8A-B00C406-C407,C409,C413,C601,C605,C607,C609,C1207,C1243电容,100pF,±5%,50V,COG,0402PCS 036H-0602-471K8A-B00C209电容,470pF,±10%,50V,X7R,0402PCS 037H-0602-681K8D-B00C402-C403电容,680pF,±10%,50V,COG,0402PCS 038H-0602-102K8D-B00C202电容,1nF,±10%,50V,X7R,0402PCS 039H-0602-103K4D-B00C201,C300,C436电容,10nF,±10%,16V,X7R,0402PCS 040H-0602-223K3D-B00C602-C604,C606,C661,C662电容,22nF,±10%,16V,X7R,0402PCS 041H-0602-104K3C-B00C200,C330,C400,C501,C502,C503,C600,C663,C701,C702,C800-C801, C905 ,C1245,C1248-C1249 电容,100nF,±10%,10V,X5R,0402PCS 042H-0602-105K3C-C00C205电容,1uF,±10%,10V,X5R,0603PCS 043H-0602-105K2C-B00C206-C208,C301-C302,C420-C423,C1134,C1201-C1203,C1210-1211,R526电容,1uF,±10%,6.3V,X5R,0402PCS 044H-0602-225K2C-C00C304-C305,C307-C310,C628,C664电容,2.2uF,±10%,6.3V,X5R,0603PCS 045H-0602-475K2C-C00C210,C1206电容,4.7uF,±10%,6.3V,X5R,0603PCS 046H-0602-106M2C-D00C211,C303,C311,C437,C623-C625电容,10uF,±20%,6.3V,X5R,0805PCS 047H-0701-24FSB1-001L404电感,2.4nH,±0.3nH,0402,SDCL1005C2N4STDF,SUNLORDPCS 048H-0701-24FSB1-000L404电感,2.4nH,±0.3nH,0402,LQG15HS2N4S02D,MURATAPCS 049H-0701-39FSB1-001L1201电感,3.9nH,±0.3nH,0402,SDCL1005C3N9STDF,SunlordPCS 050H-0701-39FSB1-000L1201电感,3.9nH,±0.3nH,0402,LQG15HS3N9S02,MurataPCS 051H-0701-62FSB1-001L405-L407电感,6.2nH,±0.3nH,0402,SDCL1005C6N2STDF,SUNLORDPCS 052H-0701-62FSB1-000L405-L407电感,6.2nH,±0.3nH,0402,LQG15HS6N2J02D,MURATAPCS 053H-0701-100JB1-001L400电感,10nH,±5%,0402,SDCL1005C10NJTDF,SunlordPCS 054H-0701-100JB0-000L400电感,10nH,±5%,0402,,HK100510NJ-T,Taiyo-yudenPCS 055H-0701-100JB1-000L400电感,10nH,±5%,0402,LQG15HS10NJ02D,MurataPCS 056H-0701-150JB1-001L402-L403电感,15nH,±5%,0402,SDCL1005C15NJTDF,SunlordPCS 057H-0701-150JB1-000L402-L403电感,15nH,±5%,0402,LQG15HS15NJ02D,MurataPCS 058H-0701-150JB0-000L402-L403电感,15nH,±5%,0402,,HK100515NJ-T,Taiyo-yudenPCS 059H-0701-121JB1-001L913电感,120nH,±5%,0402,SDCL1005CR12JTDF,SUNLORDPCS 060H-0701-121JB1-002L913电感,120nH,±5%,0402,HK1005R12J,TAIYO-YUDENPCS 061H-0701-121JB1-010L913电感,120nH,±5%,0402,LQG15HSR12J02,MURATAPCS 062H-0801-100575-000B600-B6050402磁珠(75 ohm),600mA,SZ1005G750TF,SUNLORDPCS 063H-0801-15750S-000B600-B6050402磁珠(75 ohm),300mA,BLM15BB750SN1D,MURATAPCS 064H-0801-100510-201B901-B9030402磁珠(1000 ohm),250mA,HZ1005K102TFB01,SUNLORDPCS 065H-0801-15102S-000B901-B9030402磁珠 (1000 ohm),250mA,BLM15HD102SN1,MURATAPCS 066H-1401-TPCF8B-010Q301场效应管,TPCF8B01,TOSHIBAPCS 067H-1401-02005B-000Q301MOSFET WITH SCHOTTKY,WPM2005B-8/TR,DFN3x2-8L,WILLPCS 068H-1401-SI1305-DLTQ1101P-FET,0.28ohm,-0.86A,0.29W,SI1305DL-T1-E3,SC-70-3,VISHAYPCS 069H-1401-004101-100Q1101P-FET(-20V,-1.37A),SIS4101PT1G,SOT-323,SIGPCS 070H-1501-HZ336G-L80D1008,D1011-D1013,D1015-D10170603 LED(白),BL-HZ336G-L8-TRB,BRIGHTPCS 071H-1501-0603W0-009D1008,D1011-D1013,D1015-D10170603 LE…

Text truncated - open the document above for the full version.

Tune Up Description a. Frequency Range GSM 850 TX 824-849 MHz RX 869-894 MHz GSM 900 TX 880-915 MHz RX 925-960MHz DCS 1800 TX 1710-1785MHz RX1805-1880MHz PCS 1900 TX 1850-1910MHz RX 1930-1990MHz b. Channel Space:200KHz C. Total Channel Number: Carriers*8(TDMA) d. Modulation:GMSK e. Frequency Tolerance:≤+/- 0.1ppm 1) Frequency Distribution GSM 850 EGSM900 DCS1800 PCS1900 Transmit (TX): 824-849MHZ 880-915MHZ 1710-1785MHZ 1850-1910MHZ Receive( RX): 869-894MHZ 925-960MHZ 1805-1880MHZ 1930-1990MHZ 2) Absolute channel Number:128-251 1-124 512-885 512-810 3) TX RX Space: 45MHZ 45MHZ 95MHZ 80MHZ 4) TX/RX time solt Differential: 3 3 3 3 5) Modulation bit rate: 270.833kbit 270.833kbit 270.833kbit 270.833kbit 6) Frame Cycle: 4.615ms 4.615ms 4.615ms 4.615ms 7) Slot Cycle: 576.9us 576.9us 576.9us 576.9us 8) Bit Cycle time: 3.692us 3.692us 3.692us 3.692us 9) Channel Space: 200KHZ 200KHZ 200KHZ 200KHZ 10. Time slot /Frame: 8 8 8 8 11. Modulation Type: GMSK GMSK GMSK GMSK 12 Max TX Power: 2W (33dbm) 2W (33dbm) 2W (33dbm) 2W (33dbm) 13. Min TX Power: 2.0mW 3.3mW 1mW 1.3mW 14 RF Impedance: 50Ω 50Ω 50Ω 50Ω 15. Synthesizer Frequency: T X : 3296-3396MHZ 3520-3660MHZ 3420-3570MHZ 3700-3820MHZ R X 3476-3576MHZ 3700-3840MHZ 3610-3760MHZ 3860-3980MHZ 18.Crystal Frequency: 26MHZ 19.Operating Voltage: Max:4.2V Normal:3.8V Min:3.6V 20. Demodulation Type: I/Q 21.Max Frequency Tolerance:<±0.1PPM 22. Max Phase Error: Peak Value <20 degree RMS<5 degree 23.. RX bit error rate:（-102dbm: 2.44% 24. Conduct Spurious: 9Khz-1GHZ ≤-36dbm 1GHZ-12.75GHZ ≤-30dbm 25.Class3 Bluetooth Frequency 2.4-2.5Ghz

Report No: KS101206B03 Page 1 Date of measurement:12/14/2010 Area Scan: 7 x 7 x 1 dx=15mm dy=15mm Zoom Scan: 5 x 5 x 7 dx=5mm dy=5mm dz=5mm Z Axis Scan: 1 x 1 x 21 dx=20mm dy=20mm dz=5mm A. Experimental conditions. Phantom File surf_sam_plan.txt, Adaptative 2 max Phantom Validation plane Device Position Body Band GSM850 Channels Middle Signal CW B. Instrumentations. PC HP (Pentium(R) V3.06GHz, SN:375052-AA1) Calibration Due: N/A Wireless Communication Test Set R&S (CMU200, SN:B23-03291) Calibration Due: 05/25/2011 Network Analyzer Agilent(E5071B, MY42301382) Calibration Due: 03/24/2011 Voltmeter Keithley (2000, SN:1015843) Calibration Due: 05/25/2011 Signal Generator Agilent (E8257C, SN:MY43321570)Calibration Due: 03/24/2011 Amplifier Mini-Circuits (ZHL-42, SN:110405)Calibration Due: 07/29/2011 Power Meter Agilent (E4416A, SN:QB41292714)Calibration Due: 03/24/2011 Probe Antennessa (SN:SN_1109_EP_100)Calibration Due: 05/04/2011 DIPOLE 835 Antennessa (DIPC32,SN 48/05) Calibration Due: 02/09/2011 Phantom Antennessa (SN:SN41_05_SAM29)Calibration Due: N/A Liquid Antennessa Calibration Due: N/A Measurement SW OPEN SAR V2.1 Calibration Due: N/A System Performance Check Data (850MHz Head) Report No: KS101206B03 Page 2 C. SAR Measurement Results Frequency (MHz) 835.000024 Relative permitivity (real part) 41.097999 Relative permitivity (imaginary part) 20.020350 Conductivity (S/m) 0.908279 Variation (%) -0.470000 Ambient Temperature: 21.2 °C Liquid Temperature: 20.3°C ConvF: 20.66, 20.51, 28.36 Crest factor： 1:1 SURFACE SAR VOLUME SAR Maximum location: X=0.00, Y=-5.00 SAR 10g (W/Kg) 6.331547 SAR 1g (W/Kg) 9.374512 Z Axis Scan Report No: KS101206B03 Page 3 Date of measurement:12/14/2010 Area Scan: 7 x 7 x 1 dx=15mm dy=15mm Zoom Scan: 5 x 5 x 7 dx=5mm dy=5mm dz=5mm Z Axis Scan: 1 x 1 x 21 dx=20mm dy=20mm dz=5mm A. Experimental conditions. Phantom File surf_sam_plan.txt, Adaptative 2 max Phantom Validation plane Device Position Body Band GSM850 Channels Middle Signal CW B. Instrumentations. PC HP (Pentium(R) V3.06GHz, SN:375052-AA1) Calibration Due: N/A Wireless Communication Test Set R&S (CMU200, SN:B23-03291) Calibration Due: 05/25/2011 Network Analyzer Agilent(E5071B, MY42301382) Calibration Due: 03/24/2011 Voltmeter Keithley (2000, SN:1015843) Calibration Due: 05/25/2011 Signal Generator Agilent (E8257C, SN:MY43321570)Calibration Due: 03/24/2011 Amplifier Mini-Circuits (ZHL-42, SN:110405)Calibration Due: 07/29/2011 Power Meter Agilent (E4416A, SN:QB41292714)Calibration Due: 03/24/2011 Probe Antennessa (SN:SN_1109_EP_100)Calibration Due: 05/04/2011 DIPOLE 835 Antennessa (DIPC32,SN 48/05) Calibration Due: 02/09/2011 Phantom Antennessa (SN:SN41_05_SAM29)Calibration Due: N/A Liquid Antennessa Calibration Due: N/A Measurement SW OPEN SAR V2.1 Calibration Due: N/A System Performance Check Data (850MHz Body) Report No: KS101206B03 Page 4 C. SAR Measurement Results Frequency (MHz) 835.000024 Relative permitivity (real part) 54.707999 Relative permitivity (imaginary part) 21.866249 Conductivity (S/m) 0.971052 Variation (%) -0.740000 Ambient Temperature: 21.2 °C Liquid Temperature: 20.3°C ConvF: 20.00, 19.88, 27.77 Crest factor： 1:1 SURFACE SAR VOLUME SAR Maximum location: X=0.00, Y=-5.00 SAR 10g (W/Kg) 6.821470 SAR 1g (W/Kg) 9.320154 Z Axis Scan Report No: KS101206B03 Page 5 Date of measurement:12/14/2010 Area Scan: 7 x 7 x 1 dx=15mm dy=15mm Zoom Scan: 5 x 5 x 7 dx=5mm dy=5mm dz=5mm Z Axis Scan: 1 x 1 x 21 dx=20mm dy=20mm dz=5mm A. Experimental conditions. Phantom File surf_sam_plan.txt, Adaptative 2 max Phantom Validation plane Device Position Body Band GSM1900 Channels Middle Signal CW B. Instrumentations. PC HP (Pentium(R) V3.06GHz, SN:375052-AA1) Calibration Due: N/A Wireless Communication Test Set R&S (CMU200, SN:B23-03291) Calibration Due: 05/25/2011 Network Analyzer Agilent(E5071B, MY42301382) Calibration Due: 03/24/2011 Voltmeter Keithley (2000, SN:1015843) Calibration Due: 05/25/2011 Signal Generator Agilent (E8257C, SN:MY43321570)Calibration Due: 03/24/2011 Amplifier Mini-Circuits (ZHL-42, SN:110405)Calibration Due: 07/29/2011 Power Meter Agilent (E4416A, SN:QB41292714)Calibration Due: 03/24/2011 Probe Antennessa (SN:SN_1109_EP_100)Calibration Due: 05/04/2011 DIPOLE 1900 Antennessa (DIPG35,SN 48/05) Calibration Due: 02/09/2011 Phantom Antennessa (SN:SN41_05_SAM29)Calibration Due: N/A Liquid Antennessa Calibration Due: N/A Measurement SW OPEN SAR V2.1 Calibration Due: N/A System Performance Check Data (1900MHz Head) Report No: KS101206B03 Page 6 C. SAR Measurement Results Frequency (MHz) 1900.000000 Relative permitivity (real part) 40.901999 Relative permitivity (imaginary part) 13.506150 Conductivity (S/m) 1. 350642 Variation (%) -0.460000 Ambient Temperature 21 °C Liquid Temperature 20.3 °C ConvF 41.05, 42.35, 55.45 Crest factor 1:1 SURFACE SAR VOLUME SAR Maximum location: X=0.00, Y=-5.00 SAR 10g (W/Kg) 21.131205 SAR 1g (W/Kg) 40.320144 Z Axis Scan Report No: KS101206B03 Page 7 Date of measurement:12/14/2010 Area Scan: 7 x 7 x 1 dx=15mm dy=15mm Zoom Scan: 5 x 5 x 7 dx=5mm dy=5mm dz=5mm Z Axis Scan: 1 x 1 x 21 dx=20mm dy=20mm dz=5mm A. Experimental conditions. Phantom File surf_sam_plan.txt, Adaptative 2 max Phantom Validation plane Device Position Body Band GSM1900 Channels Middle Signal CW B. Instrumentations. PC HP (Pentium(R) V3.06GHz, SN:375052-AA1) Calibration Due: N/A Wireless Communication Test Set R&S (CMU200, SN:B23-03291) Calibration Due: 05/25/2011 Network Analyzer Agilent(E5071B, MY42301382) Calibration Due: 03/24/2011 Voltmeter Keithley (2000, SN:1015843) Calibration Due: 05/25/2011 Signal Generator Agilent (E8257C, SN:MY43321570)Calibration Due: 03/24/2011 Amplifier Mini-Circuits (ZHL-42, SN:110405)Calibration Due: 07/29/2011 Power Meter Agilent (E4416A, SN:QB41292714)Calibration Due: 03/24/2011 Probe Antennessa (SN:SN_1109_EP_100)Calibration Due: 05/04/2011 DIPOLE 1900 Antennessa (DIPG35,SN 48/05) Calibration Due: 02/09/2011 Phantom Antennessa (SN:SN41_05_SAM29)Calibration Due: N…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No: KS101206B03 FCC ID: YNFBB6 Date of Issue: December 14, 2010 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 Total Page: 31 Rev. 00 ANSI/IEEE Std. C95.1-1992 In accordance with the requirements of FCC Report and Order: ET Docket 93-62, and OET Bulletin 65 Supplement C FCC SAR TEST REPORT For GSM MOBILE PHONE Model: BB6 Trade Name: MAXWEST Issued to Newport Wholesale 11037 Warner Ave #201, Fountain Valley, CA, 92708, USA Issued by Compliance Certification Services Inc. Kunshan Laboratory No.10 Weiye Rd., Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China TEL: 86-512-57355888 FAX: 86-512-57370818 http://www.ccsrf.com [email protected] Compliance Certification Services Inc. Report No.: KS101206B03 FCC ID: YNFBB6 Date of Issue: December 14, 2010 Page 2 Rev. 00 TABLE OF CONTENTS 1. CERTIFICATE OF COMPLIANCE (SAR EVALUATION)..................................................... 3 2. EUT DESCRIPTION.............................................................................................................4 3. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC ....................... 5 4. DOSIMETRIC ASSESSMENT SETUP ................................................................................ 5 4.1 MEASUREMENT SYSTEM DIAGRAM ......................................................................... 6 4.2 SYSTEM COMPONENTS ............................................................................................. 7 5. EVALUATION PROCEDURES .......................................................................................... 10 6. MEASUREMENT UNCERTAINTY ..................................................................................... 14 7. EXPOSURE LIMIT ............................................................................................................. 15 8. EUT ARRANGEMENT ....................................................................................................... 16 8.1 ANTHROPOMORPHIC HEAD PHANTOM.................................................................. 16 8.2 DEFINITION OF THE “CHEEK/TOUCH” POSITION................................................... 17 8.3 DEFINITION OF THE “TILTED” POSITION ................................................................ 18 9. MEASUREMENT RESULTS .............................................................................................. 19 9.1 SYSTEM PERFORMANCE CHECK............................................................................ 19 9.2 TEST LIQUIDS CONFIRMATION................................................................................ 19 9.3 EUT TUNE-UP PROCEDURES .................................................................................. 23 9.4 SAR MEASUREMENT RESULTS ............................................................................... 24 10. EQUIPMENT LIST & CALIBRATION STATUS .................................................................. 33 11. FACILITIES ........................................................................................................................ 34 12. REFERENCES ................................................................................................................... 34 13. ATTACHMENTS................................................................................................................. 35 Compliance Certification Services Inc. Report No.: KS101206B03 FCC ID: YNFBB6 Date of Issue: December 14, 2010 Page 3 Rev. 00 1. CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Applicant: Newport Wholesale 11037 Warner Ave #201, Fountain Valley, CA, 92708, USA Manufacturer: Newport Wholesale 11037 Warner Ave #201, Fountain Valley, CA, 92708, USA Equipment Under Test: GSM MOBILE PHONE Trade Name: MAXWEST Model Number: BB6 Devices supporting GPRS:Class B Description Test Modes(worst case ): The EUT was pretested, then the SIM1 was found to transmit the highest SAR value after tested dual SIM1 an…

Text truncated - open the document above for the full version.
