YNFWT8000MOBILE PHONE WITH BT/WI-FI

WT8000 User Manual Contents Getting started Menus 1. Phonebook 1.1 Quick Search 1.2 Add a Contact 2. Information 2.1 Write information 2.2 Inbox 2.3 Drafts 2.4 Outbox 2.5 MMS 2.6 E-mail 2.7 Cell Broadcast 2.8 Template 2.9 SMS Settings 3. Call Center 3.1 Call History 3.2 Call settings 4. Set 4.1 Mode Setting 4.2 Touch screen calibration 4.3 Phone Settings 4.4 SMS Settings 4.5 Call settings 4.6 Data Accounts 4.7 Wallpaper 4.8 LCD backlight 4.9 Music Settings 4.10 Network settings 4.11 Security Settings 4.12 External links 4.13 Restore factory settings 4.14 Sound 4.15 Sensor Set 5. Book 5.1 Open the e-book 5.2 Update 5.3 System Settings 5.4 Information 5.5 Remove 5.6 Delete all files 5.7 Sort 5.8 Execution System Settings 5.9 Help 6 Network Services 6.1STK 6.2 Internet Services 6.3 Baidu search 6.4UCWEB browser 7. Multimedia 7.1 Video Chat 7.2 Camera 7.2.1 Album 7.2.2 Camera Settings 7.2.3 Photo Settings 7.2.4 White Balance 7.2.5 Situational Model 7.2.6 Effects Set 7.2.7 Storage location 7.2.8 Restore Default 7.3 Album 7.4 video recording device 7.2 Video Player 7.3 Music Player 7.4 Recording 7.5 FM radio 7.6 Slide 7.7 TV 7.7.1 Add to my channel 7.7.2 Channel List 7.7.3 My Channel 7.7 4 channel search 7.7.5 Search Area 7.7.6 Display Settings 8. Toolbox 8.1 Calendar 8.2 Task 8.3 Alarm Clock 8.4 World Time 9. Scenarios 9.1 Standard Mode 9.2 Meeting mode 9.3 Outdoor Model 9.4 Indoor Model 9.5 Headset Mode 9.6 Bluetooth Mode 10. Exchange rate conversion 11. Document Management 11.1 Use function 11.2 Folders feature 12. Calculator 13. Stopwatch 13.1 General code table 13.2 Multi-oriented code table 14 Telephone 14.1 The phone features 14.2 Call Options 15. Bluetooth 15.1 Bluetooth menu, settings 15.2 to establish a Bluetooth connection 16. Fun & Games 16.1 Java 16.2 Java Set 16.3 Game 16.4 Dynamic Game 17. Wireless Network 18 calls Background Music 18.1 Choose to call 18.2 Play Set 18.3 Background Music List 19.MSN 20.Art Fonts Frequently Asked Questions Know Before You Use Phone keypad description Power button (on \ off button): The bond length for the switch by machine; in the call or the caller interface Click button to hang up; Click button on any interface can be a direct return to the standby interface. Side button: standby interface can be realized quickly adjust the function of the size of ring volume; in tone or MP3 player interface that enables adjustment , ringtone volume size or the size of features Rackball: You can use the trackball to navigate the various interfaces. Battery installation / removal Exchange the battery, make sure you have closed the phone, at the same time disconnected from the charger links. SIM card installation / removal Installation, make sure you have closed the phone and remove the battery. If you do not properly insert the SIM card can only use the device in offline mode. T card installation / removal Installation, make sure you have closed the phone and remove the battery. Mobile Phone Charger In the charge before, make sure the battery has been correctly loaded mobile phones, and make sure the use of compatible charger. 1. will be compatible with cell phone charger jack into the port. 2. Connect the charger plug into the power socket on the device screen shows the battery charging icon was rolling. 3. If the battery is completely depleted or long-term unused lead to the battery voltage is too low, charging, you may need to wait some time before a charge screen. 4. Charging is complete, charge prompt the state to stop at full grid at this time, please disconnect the charger and the device link, and then unplug the charger from the electrical outlet. 5. Please completely exhausted after the first fully charged before use, so easy to achieve the best use of the battery condition. Note: While charging, the circuit in order to avoid serious burning mobile phone, do not move or remove the battery. Users not in a closed environment or in flammable and explosive environment charge. On / Off 1, long press the power button to open or close the phone. 2, if asked to enter mobile phone boot password, please enter the correct number, then select "Confirm", mobile phones default density Code is "1122." Input Method Description In the input interface, you can enter numbers, words or symbols, and more. 1, switching input method: enter the editing interface, the options menu select the input method into the input method list, and press OK key to select the desired input method, your cell phone to provide you with pinyin input, strokes input, uppercase English, lowercase English, digital input , punctuation input in the six input; also available on the editing interface, click the interface in the input region to switch input methods. 2, Pinyin input method: Click on the letter keys input alphabet, and then click on the text you want can be. 3, stroke input method: Click the needs of stroke, and then click on the text you want can be. 4, English case input method: Click the letter you need direct input. 5, digital input method: Click on the number you need direct input. 6, punctuation: In the punctuation list, click on the symbol you need a direct input. Menus 1. Telephone Directory 1.1 Quick Find Click on a telephone book entry, which indicates that phone book browsing interface, the bottom of the window provides a search input box, you can enter the appropriate information to the telephone records of screening, select a record, enter the option, the menu is as follows: 1.1.1 View: See this article for details. 1.1.2 Send SMS: send SMS to this number. 1.1.3 to send MMS: Send MMS to this number. 1.1.4 Call: Call the current number. 1.1.5 IP Call: call this number to IP. 1.1.6 Edit: Edit this article entry. 1.1.7 Delete: delete the clause entry. 1.1.8 Copy: Copy this article entry. 1.1.9 Mobile: Mobile this article entry. 1.1.10 Send Contact Person: 1, text messages: Use SMS to send this article entry. 2, MMS: Using MMS for sending this article. 3, e-mail: Use e-mail this ar…

Text truncated - open the document above for the full version.

Block Diagram

WLAN Module Block Diagram

Newport Wholesale 11037 Warner AVE#201,Fountain Valley,CA92708,USA Tel: 714-470-3900 AGENCY AUTHORIZATION LETTER FCC ID: YNFWT8000 Date: Oct 18, 2010 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: We, the undersigned, hereby authorize Shenzhen VITE Technology Co., Ltd (MR. Tracy Qi) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Shenzhen VITE Technology Co., Ltd (MR. Tracy Qi) on our behalf shall have the same effect as acts of our own. This authorization expires on Oct 17, 2011. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, Newport Wholesale are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, Golzar Yaghoubpour / General Manager

Newport Wholesale 11037 Warner AVE#201,Fountain Valley,CA92708,USA Tel: 714-470-3900 Attestation Letter FCC ID: YNFWT8000 Date: Oct 25, 2010 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: WT8000 is a GSM Mobile Phone with WLAN function of FCC ID: YNFWT8000. This device does not support simultaneously work WLAN and GSM/GPRS. We, Newport Wholesale don’t offer any software or other mechanisms setup control the device to simultaneously transmit WLAN and GSM/GPRS for users. Should you have any questions, please have my best attention. Sincerely yours, Golzar Yaghoubpour / General Manager

External Photos of EUT

Applicant: Newport Wholesale FCC ID: YNFWT8000 Model Name: WT8000 Proposed Label Location on EUT

Internal Photos of EUT Antenna Location

Operation Description 1. GSM Transceiver The MT6235 is an integral component including RF CMOS transceiver IC. MT6235 is highly integrated and fulfill specific functions; functional requirements are partitioned between the ICs to yield complete and optimal multiband, multimode transceiver implementations. Overall transceiver performance depends upon the combined, complementary performance of all the ICs in the chipset.The MT6235 IC supports multiband, multimode phones with five receiver signal paths, four transmitter signal paths, and one dedicated calibration receive path. Receiver paths: ❒ GSM 850 ❒ GSM 900 ❒ GSM 1800 ❒ GSM 1900 Transmitter paths: ❒ Two low-band Tx paths for: – GSM 850 – GSM 900 ❒ Two high-band Tx paths for: – GSM 1800 – GSM 1900 The MT6235 zero-IF architecture and highly integrated implementation minimizes handset PCB size and material cost. 2. Power Amplifier Module The SKY77518 is a small, GSM PAM for handset applications. This module has been optimized for excellent amplify efficiency , ACPR and EVM in an open loop polar modulation environment operation while maintaining high GSM/GPRS efficiency. The SKY77518 was optimized for operation with the Qualcomm MT6235 regarding input power range and Rx band performance. 3. Antenna Switch and SAW Filter The antenna switch and Low-loss SAW for mobile telephone system Covering GSM850/GSM900/GSM1800/GSM1900 bands. The TX Signals from the PAM are transmitted to the antenna via the TX path with integrated TX band pass filters, switches and diplexer. The RX Signals from the antenna are balanced output to transceiver through DC blocking capacitors at the antenna 4. GSM Baseband Processor MT6235 based on a dual-processor architecture, MT6235 integrates both an ARM926EJ-S core and a digital signal processor core. ARM926EJ-S is the main processor responsible for running high-level GSM/GPRS protocol software as well as multi-media applications. The digital signal processor manages the low-level MODEM as well as advanced audio unctions. Except for a few mixed-signal circuitries, the other building blocks in MT6235 are connected to either the microcontroller or the digital signal processor. 5. GSM Power Management IC The MT6235 integrate PMU. It was optimized for operation with the Qualcomm SKY77518 regarding input power range and Rx band performance. Mode Control pins are provided for high efficiency improvement of the low output power range. 6. Audio CODEC Audio codec is a highly integrated input/output device designed for mobile computing and communications. The chip is a Hi-Fi DAC with 0.8W stereo class D speaker drivers and headphone drivers , supporting Hi-Fi stereo Codec function via the AC97 interface. All device functions are accessed and controlled through a I2C interface. The chip can connect directly to mono or stereo microphones, stereo headphones and mono speakers, reducing total component count in the system. 7. Bluetooth and WIFI module The chip is a single-chip, Bluetooth2.0-compliant, stand-alone baseband processor with an integrated 2.4-GHz transceiver. The baseband and radio subsystems are designed specifically for single chip requirements, for low power consumption. The chip is the optimal solution for any voice and/or data application that requires the Bluetooth SIG standard HCI via either UART and PCM audio interfaces. Alternative HCI interfaces ,including SDIO and SPI, are also supplied. The same module also is 802.11b/g standard module, by same TCXO 26MHz, baseband processor and integrated 2.4-GHz transceiver. The baseband and radio subsystems are designed specifically for 802.11b/g standard, for low power consumption. It is fully compatible with any of the standard 2.4G/5.8G frequencies device, such as Bluetooth device. They are Time Division and provides different encode mode. Its radio is compatibility to operate simultaneously with cellular radios. The module supplies the SDIO interface for communication with Application processor.

Report No：109S086R-HP-US-P03V01 Page: 1 of 126 SAR Test Report Product Name : Mobile Phone Model No. : WT8000, WT8001, WT8002 FCC ID : YNFWT8000 Applicant : Newport Wholesale Address : 11037 Warner AVE#201, Fountain Valley, CA92708, USA Date of Receipt : 24. Sep, 2010 Date of Test : 26. Sep, 2010 ~ 29. Sep, 2010 Issued Date : 15. Oct, 2010 Report No. : 109S086R-HP-US-P03V01 Report Version : V1.1 The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of Quie Tek Corporation. Report No：109S086R-HP-US-P03V01 Page: 2 of 126 Test Report Certification Issued Date: 15.Oct, 2010 Report No: 109S086R-HP-US-P03V01 Product Name : Mobile Phone Applicant : Newport Wholesale Address : 11037 Warner AVE#201, Fountain Valley, CA92708, USA Manufacturer : Newport Wholesale Address : 11037 Warner AVE#201, Fountain Valley, CA92708, USA FCC ID : YNFWT8000 Model No. : WT8000, WT8001, WT8002 Trade Name : MAXWEST EUT Voltage : DC 3.7V Applicable Standard : FCC OET65 Supplement C June 2001 IEEE Std. 1528-2003, 47CFR § 2.1093 Test Result : Max. SAR Measurement (1g) Head: 0.302 W/kg Body: 1.110 W/kg Performed Location : SuZhou EMC Laboratory No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., SuZhou, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 FCC Registration Number: 800392 Documented By : (Engineering ADM: Alice Ni) Tested By : (Engineering Supervisor: Marlin Chen) Approved By : (Engineering Manager: Dream Cao) Report No：109S086R-HP-US-P03V01 Page: 3 of 126 Laboratory Information We , QuieTek Corporation, are an independent EMC and safety consultancy that was established the whole facility in our laboratories. The test facility has been accredited by the following accreditation Bodies in compliance with ISO 17025, EN 45001 and Guide 25: The related certificate for our laboratories about the test site and management system can be downloaded from QuieTek Corporation’s Web Site : http://tw.quietek.com/modules/myalbum/ The address and introduction of QuieTek Corporation’s laboratories can be founded in our Web site : http://www.quietek.com/ If you have any comments, Please don’t hesitate to contact us. Our contact information is as below: HsinChu Testing Laboratory : No.75-2, 3rd Lin, Wangye Keng, Yonghxing Tsuen, Qionglin Shiang, Hsinchu County 307, Taiwan, R.O.C. TEL:+886-3-592-8858 / FAX:+886-3-592-8859 E-Mail : [email protected] LinKou Testing Laboratory : No. 5-22, Ruei-Shu Valley, Ruei-Ping Tsuen, Lin-Kou Shiang, Taipei, Taiwan, R.O.C. TEL : 886-2-8601-3788 / FAX : 886-2-8601-3789 E-Mail : [email protected] Suzhou (China) Testing Laboratory : No. 99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., Suzhou,China. TEL : +86-512-6251-5088 / FAX : +86-512-6251-5098 E-Mail : [email protected] Taiwan R.O.C. :BSMI, NCC, TAF Germany :TUV Rheinland Norway :Nemko, DNV USA :FCC, NVLAP Japan :VCCI Report No：109S086R-HP-US-P03V01 Page: 4 of 126 TABLE OF CONTENTS Description Page 1. General Information .................................................................................................... 6 1.1. EUT Description .................................................................................................. 6 1.2. Test Environment ................................................................................................. 7 2. SAR Measurement System ........................................................................................ 8 2.1. DASY5 System Description ................................................................................. 8 2.1.1. Applications ..................................................................................................... 9 2.1.2. Area Scans ...................................................................................................... 9 2.1.3. Zoom Scan (Cube Scan Averaging) ................................................................ 9 2.1.4. Uncertainty of Inter-/Extrapolation and Averaging ........................................... 9 2.2. DASY5 E-Field Probe ........................................................................................ 10 2.2.1. Isotropic E-Field Probe Specification ............................................................. 10 2.3. Boundary Detection Unit and Probe Mounting Device ...................................... 11 2.4. DATA Acquisition Electronics (DAE) and Measurement Server ........................ 11 2.5. Robot ................................................................................................................. 12 2.6. Light Beam Unit ................................................................................................. 12 2.7. Device Holder .................................................................................................... 13 2.8. SAM Twin Phantom ........................................................................................... 13 3. Tissue Simulating Liquid ........................................................................................... 14 3.1. The composition of the tissue simulating liquid ................................................. 14 3.2. Tissue Calibration Result ................................................................................... 15 3.3. Tissue Dielectric Parameters for Head and Body Phantoms ............................. 17 4. SAR Measurement Procedure .................................................................................. 18 4.1. SAR System Validation ...................................................................................... 18 4.1.1. Validation Dipoles .......................................................................................... 18 4.1.2. Validation Result ............................................................................................ 19 4.2. SAR Measurement Procedure ..........................................................…

Text truncated - open the document above for the full version.

Shenzhen VITE Technology Co., Ltd Tel: +86-755-89486194 Fax: +86-755-89486187 FCC PART 15 SUBPART C TEST REPORT FCC Part 15.247 Report Reference No......................: VITE10016W Compiled by ( position+printed name+signature)..: File administrators Andy Zhang Name of the organization performing the tests ( position+printed name+signature)..: Test Engineer Kendy Wang Approved by ( position+printed name+signature)..: Manager Tracy Qi Date of issue.....................................: Oct 18, 2010 Representative Laboratory Name.: Shenzhen VITE Technology Co., Ltd Address.............................................: Suite 2123, Building 4, Hongfa Centre, Central Area Baoan, Baoan District, Shenzhen, Guangdong, 518101, P.R. China Test Firm..........................................: Bontek Compliance Testing Laboratory Ltd Address.............................................: 1/F, Block East H-3, OCT Eastern Ind. Zone, Qiaocheng East Road, Nanshan, Shenzhen, China Applicant’s name............................: Newport Wholesale Address.............................................: 11037 Warner AVE#201,Fountain Valley,CA92708,USA Test specification: Standard ...........................................: FCC Part 15.247: Operation within the bands 902–928 MHz, 2400– 2483.5 MHz, and 5725–5850 MHz. TRF Originator ..................................: Shenzhen VITE Technology CO., Ltd Master TRF.......................................: Dated 2009-03 Shenzhen VITE Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen VITE Technology Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen VITE Technology Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Mobile Phone Trade Mark .......................................: MAXWEST Model/Type reference.......................: WT8000 Listed Models ..................................: WT8001, WT8002 Difference description.......................: Only the model name is difference Modulation .......................................: DSSS, OFDM Work Frequency Range..................: 2412~2462MHz Antenna Type..............................: Internal FCC ID.......................................: YNFWT8000 Result................................................: Positive V1.0 Page 2 of 52 Report No.: VITE10016W T E S T R E P O R T Test Report No. : VITE10016W Oct 18, 2010 ______________________________________________________________________________________________ Date of issue Equipment under Test : Mobile Phone Model /Type : WT8000 Listed Models : WT8001, WT8002 Applicant : Newport Wholesale Address : 11037 Warner AVE#201,Fountain Valley,CA92708,USA Manufacturer Newport Wholesale Address 11037 Warner AVE#201,Fountain Valley,CA92708,USA Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 52 Report No.: VITE10016W Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY............................................................................. 5 2.1. General Remarks 5 2.2. Equipment Under Test 5 2.3. Short description of the Equipment under Test (EUT) 5 2.4. EUT operation mode 5 2.5. EUT configuration 5 2.6. NOTE 6 2.7. Related Submittal(s) / Grant (s) 6 2.8. Modifications 6 3. TEST ENVIRONMENT............................................................... 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 7 3.4. Configuration of Tested System 7 3.5. Statement of the measurement uncertainty 8 3.6. Equipments Used during the Test 8 3.7. Summary of Test Result 9 4. TEST CONDITIONS AND RESULTS ............................................ 10 4.1. Conducted Emissions Test 10 4.2. Radiated Emission Test 15 4.3. 6dB Bandwidth Measurement 25 4.4. Maximum Peak Output Power 29 4.5. Band Edge Measurement 32 4.6. Power Spectral Density Measurement 41 4.7. Antenna Requirement 46 4.8. RF Exposure 47 5. TEST SETUP PHOTOS OF THE EUT .......................................... 48 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 49 V1.0 Page 4 of 52 Report No.: VITE10016W 1. TEST STANDARDS The tests were performed according to following standards: FCC Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.4-2003 KDB Publication No. 558074 Guidance on Measurements for Digital Transmission Systems V1.0 Page 5 of 52 Report No.: VITE10016W 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Sep 16, 2010 Testing commenced on : Sep 18, 2010 Testing concluded on : Oct 17, 2010 2.2. Equipment Under Test Power supply system utilised Power supply voltage : o 120V / 60 Hz o 115V / 60Hz o 12 V DC o 24 V DC z Other (specified in blank below) DC 3.7V from Battery 2.3. Short description of the Equipment under Test (EUT) GSM mobile phone with Bluetooth and Wi-fi function. For more details, refer to the user’s manual of the EUT. Serial number: Prototype 2.4. EUT operation mode Test Mode: 1. The EUT has been tested under normal operating condition. 2. Test program used to control the EUT for staying in continuous transmitting and receiving mode is programmed. Channel low (2402MHz), mid (2441MHz) and high (2480MHz) with highest data rate are chosen for full testing. 2.5. EUT configuration The following peripheral devices and interface cables were connected during the measurement: o - supplied by the manufacturer o - supplied by the lab o Manufacturer : Model No. : o Manufacturer : Model …

Text truncated - open the document above for the full version.

Test Setup Photos of EUT
