YPC-VULKANO-LCVideo streaming box

Congratulations, setup is complete 1. Connect Vulkano to Your Set-Top Box (STB)Your STB has output connectors on the back for Component, Composite, or both. If you have both, use Component for better video quality. ( You will need a Set-Top Box to use Vulkano)
Connect audio and video cables from the STB “Output” co nnectors to Vulkano’s video and audio “Input” connectors as shown. For Component, yo u will use two cables. For Composite, you will only use one
Write down your STB brand and model number. You wil l need it later in the Setup ComponentComposite 3. Power
Plug the power adapter into Vulkano and a wall plug or power strip as shown 4. Vulkano Player
Download Vulkano Player from http://www.monsoonmultimedia.com/players.html . Click on the “Download now” button for the PC Player
Save Vulkano Player to your computer
After download is complete, run Vulkano Player . (It t akes a few minutes to download, and then a few more minutes to install)
When asked, select “Run Vulkano Setup Wizard”
Vulkano Setup Wizard will start and lead you through th e remaining steps If you have wireless setup problemsIf you see the “Network Connection Lost” screen more than once, connect the Ethernet cable as described in the Mac/XP Setup process on the back of this Quick Start Guide 2. Connect Vulkano to Your TVYour TV has audio and video “Input” connectors on the b ack or side for Component, Composite, or both. Make sure you use the same cable types, either Component or Composite for this connection as used in Step 1
Connect audio and video cables from the Vulkano “Output ” connectors to your TV’s video and audio “Input” connectors as shown. For Component, yo u will use two cables. For Composite, you will only use oneComponentComposite PlayersPC• Download Vulkano PC Player to your PC from www.myvulkano.com/players.html • Install and run Vulkano Player • Select Run Vulkano Player if you already set up Vulkan o using your TV • Enter the name and password of Vulkano • Select Watch TV to get started Mac• Download Vulkano Mac Player to your Mac from www.myvulkano.com/players.html • Install and run Vulkano Player • Go to Player > Add/Select Player > Add to enter the n ame and password of Vulkano • Go back to the Home screen and push Watch TV to get star ted iPhone/iPad• Download Vulkano Player to your iPhone or iPad from the App Store • Go to Settings>Select to enter the name and password of Vulkano • Go back to the Home screen and push Live TV to get start ed Android• Download Vulkano Player to your phone from Android M arket • Install and run Vulkano Player • Go to Settings > Selected Vulkano > Add Vulkano • Enter the name and password of Vulkano • Go back to the Home screen and push Live TV to get start ed TroubleshootingIf your STB is too far from Vulkano, or hidden from i t, you can use the included IR Blasters. Plug the pin in the back of Vulkano and place the IR ‘paddles’ in front of the remote window on your STB. Additional information and technical support available at www.myvulkano.com/support.html Support9:00 AM to 9:00 PM PST (Monday – Friday)phone: +1 (866) 937-4282 e-mail: [email protected] Vulkano unit Pow er adapter IR blaster cable 2 Composite cables Ethernet cable 2 Component cables Vulkano Setup for Windows 7 and VistaCongratulations on buying Vulkano. We will take you t hrough a few simple steps to get you up and running.These steps are for setting up your Vulkano from a Windows 7 PC or Windows Vista PC. If you are using a Windows XP PC or a Mac, please follow the steps on the other side of this Quick St art Guide. What’s in the Box Quick Start Guide VULKANO FLOW LC Windows 7 and Vista Compliance note:• Changes or modifications not expressly approved by the part y responsible for compliance could void the user ’ s authority to operate the equipment. • This equipment has been tested and found to comply with the li mits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provi de reasonable protection against harmful interference in a residential installation. This equipmen t generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the i nstructions, may cause harmful interference to radio communications. However, there is no guarantee that i nterference will not occur in a particular installation. If this equipment does cause harmful interfe rence to radio or television reception, which can be determined by turning the equipment off and on, the user is en couraged to try to correct the interference by one or more of the followingmeasures:— Reorientor relocate the receivingantenna. — Increase the separation betweenthe equipmentand receiver . — Connectthe equipmentinto an outleton a circuitdifferentf rom that to which the receiveris connected. — Consultthe dealeror an experienced radio/TV technician fo rhelp. • The antennas used for this transmitter must be installed to p rovide a separation distance of at least 20cm from all persons and must not be located or operating in conju nction with any other antenna or transmitter. • Operation is subject to the following two conditions: (1) th is device may not cause interference, and (2) this device must accept any interference, including interferen ce that may cause undesired operation of the device Congratulations, setup is complete Vulkano Setup for Windows XP and MacCongratulations on buying Vulkano. We will take you t hrough a few simple steps to get you up and running.These steps are for setting up your Vulkano from a Windows XP PC or Mac. If you are using a Windows 7 PC or a Windows Vista PC, please follow the steps on the other side of this Quick St art Guide. What’s in the Box Ethernet cable 1. Network and Power
During this first portion of the setup, we will use an Ethernet cable to connect to your Vulkano to your home WiFi network. Once it is on the ne twork we will disconnect the cable and Vulkano can be used wirelessly
Use…

Text truncated - open the document above for the full version.

Date: 21-December-2012 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: YPC-VULKANO-LC To Whom It May Concern: This letter is to ascertain that Monsoon Multimedia Inc. Product VULKANO FLOW LC has been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. If you have any question or concerns, pls. contact us. Sincerely, Keshava Murthy VP of Hardware Engineering Monsoon Multimedia Inc. 1730 S. Amphlett Blvd., Suite-101 San Mateo, CA 94402, USA Email: [email protected] Ph: 650-235-3519

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 19-November-2012 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Monsoon Multimedia Inc., hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Video place-shifting & streaming box, VULKANO FLOW LC We affirm that between SIEMIC and Monsoon Multimedia Inc., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Keshava Murthy VP of Hardware Engineering Monsoon Multimedia Inc. 1730 S. Amphlett Blvd., Suite-101 San Mateo, CA 94402, USA

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 19-November-2012 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: YPC-VULKANO-LC We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Keshava Murthy VP of Hardware Engineering Monsoon Multimedia Inc. 1730 S. Amphlett Blvd., Suite-101 San Mateo, CA 94402, USA

EUT External picture EUT - Top View EUT - Back View EUT - Front View EUT - Rear View EUT - Right View EUT - Left View EUT – Power Adapter Top View EUT - Power Adapter Bottom View

EUT Internal picture EUT – Cover Off View EUT – Main PCB Top View Antenna EUT – Main PCB Bottom View EUT – Sub-PCB Top View EUT – Sub-PCB Bottom View

MPE CALCULATION FCC ID: YPC-VULKANO-LC RF Exposure Requirements: 47 CFR §1.1307(b) RF Radiation Exposure Limits: 47 CFR §1.1310 RF Radiation Exposure Guidelines: FCC OST/OET Bulletin Number 65 EUT Frequency Band: 2412~2462 MHz Limits for General Population/Uncontrolled Exposure in the band of: 300 – 1500 GHz Power Density Limit: 1 mW/ cm 2 ; Equation: S = PG / 4R 2 or R = √PG / 4S Where, S = Power Density P = Power Input to Antenna G = Antenna Gain R = distance to the center of radiated antenna ______________________________________________________________________________________________________________________ 802.11b Mid Channel (2437 MHz): Power = 16.82 dBm, Antenna Gain = 2.5 dBi, Prediction distance 20cm S = 0.017 mW/cm 2 802.11n-20MHz BW Mid Channel (2437 MHz): Power = 22.35 dBm, Antenna Gain = 2.5 dBi, Prediction distance 20cm S = 0.06 mW/cm 2 Result The Above Result had shown that Device complied with 1 mW/cm 2 Power density requirement for distance of 20cm. Completed By : David Zhang Date : Nov1st, 2012

MONSOON MULTIMEDIA INC. Media Center Box Model: VULKANO FLOW LC Issued Date: Dec 2nd, 2012 Report No.: SL12091701*MON*006*R_RF (FCC_IC) Rev1.0 (This report supersedes SL12091701*MON*006*R_RF (FCC_IC) ) Modifications made to the product : None This Test Report is Issued Under the Authority of: David Zhang Compliance Engineer Choon Sian Ooi Engineering Reviewer This test report may be reproduced in full only. Test result presented in this test report is applicable to the representative sample only. Title: RF Test Report Monsoon Multimedia Inc. Model : VULKANO FLOW LC To FCC 15.247:2012,RSS(210 Issue 8:2010 Serial# SL12091701(MON(006(R_RF (FCC_IC) Rev1.0 Issue Date Dec 2nd, 2012 Page 2 of 95 www.siemic.com Laboratory Introduction ATION SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one(stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/Region Accreditation Body Scope USA FCC, A2LA EMC , RF/Wireless , Telecom Canada IC, A2LA, NIST EMC, RF/Wireless , Telecom Taiwan BSMI , NCC , NIST EMC, RF, Telecom , Safety Hong Kong OFTA , NIST RF/Wireless ,Telecom Australia NATA, NIST EMC, RF, Telecom , Safety Korea KCC/RRA, NIST EMI, EMS, RF , Telecom, Safety Japan VCCI, JATE, TELEC, RFT EMI, RF/Wireless, Telecom Mexico NOM, COFETEL, Caniety Safety, EMC , RF/Wireless, Telecom Europe A2LA, NIST EMC, RF, Telecom , Safety Accreditations for Product Certifications Country Accreditation Body Scope USA FCC TCB, NIST EMC , RF , Telecom Canada IC FCB , NIST EMC , RF , Telecom Singapore iDA, NIST EMC , RF , Telecom EU NB EMC & R&TTE Directive Japan MIC (RCB 208) RF , Telecom HongKong OFTA (US002) RF , Telecom Title: RF Test Report Monsoon Multimedia Inc. Model : VULKANO FLOW LC To FCC 15.247:2012,RSS(210 Issue 8:2010 Serial# SL12091701(MON(006(R_RF (FCC_IC) Rev1.0 Issue Date Dec 2nd, 2012 Page 3 of 95 www.siemic.com This page has been left blank intentionally. Title: RF Test Report Monsoon Multimedia Inc. Model : VULKANO FLOW LC To FCC 15.247:2012,RSS(210 Issue 8:2010 Serial# SL12091701(MON(006(R_RF (FCC_IC) Rev1.0 Issue Date Dec 2nd, 2012 Page 4 of 95 www.siemic.com CONTENTS 1 EXECUTIVE SUMMARY & EUT INFORMATION ............................................................................................................. 6 2 TECHNICAL DETAILS .................................................................................................................................................. 7 3 REPORT REVISION HISTORY ....................................................................................................................................... 9 4 TEST SUMMARY ........................................................................................................................................................ 10 5 MEASUREMENTS, EXAMINATION AND DERIVED RESULTS ...................................................................................... 11 ANNEX A. TEST INSTRUMENT & METHOD......................................................................................................................... 30 ANNEX B EUT PHOTOGRAPHS ........................................................................................................................................ 35 ANNEX C. TEST SETUP ...................................................................................................................................................... 36 ANNEX D USER MANUAL, BLOCK & CIRCUIT DIAGRAM ................................................................................................... 39 ANNEX E USER MANUAL, BLOCK & CIRCUIT DIAGRAM ................................................................................................... 40 ANNEX E SIEMIC ACCREDITATION ................................................................................................................................... 70 Title: RF Test Report Monsoon Multimedia Inc. Model : VULKANO FLOW LC To FCC 15.247:2012,RSS(210 Issue 8:2010 Serial# SL12091701(MON(006(R_RF (FCC_IC) Rev1.0 Issue Date Dec 2nd, 2012 Page 5 of 95 www.siemic.com This page has been left blank intentionally. Title: RF Test Report Monsoon Multimedia Inc. Model : VULKANO FLOW LC To FCC 15.247:2012,RSS(210 Issue 8:2010 Serial# SL12091701(MON(006(R_RF (FCC_IC) Rev1.0 Issue Date Dec 2nd, 2012 Page 6 of 95 www.siemic.com 1 Executive Summary & EUT information The purpose of this test programme was to demonstrate compliance of the Monsoon Multimedia Inc., Media Center Box, and Model: VULKANO FLOW LC against the current Stipulated Standards. The Media Center Box have demonstrated compliance with the FCC 15.247:2012 & IC RSS210 Issue 8: 2010. Applicant & EUT Information Applicant Information Applicant / Client Monsoon Multimedia Inc. 1730 S. Amphlett Blvd., suite 101 San Mateo, CA 94402 Manufacturer1 Monsoon Multimedia Inc. 1730 S. Amphlett Blvd., suite 101 San Mateo, CA 94402 EUT Information EUT Description : Media Center Box Model Name : VULKANO FLOW LC Serial No : N/A Input Power : 9VDC/2A Operating Frequency : 802.11b/g/n: 2412MHZ ( 2462MHz /20MHz BW 802.11n: 2422MHz – 2452MHz /40MHz BW Radiated power : WLAN (2.4GHz): 0.172W (22.35 dBm) Modulation : DSSS/OFDM Classification Per Stipulated Test Standard : Spread Spectrum System / Device Title: RF Test Report Monsoon Multimedia Inc. Model : VULKANO FLOW LC To FCC 15.247:2012,RSS(210 Issue 8:2010 Serial# SL12091701(MON(006(R_RF (FCC_IC) Rev1.0 Issue Date Dec 2nd, 2012 Page 7 of 95 www.siemi…

Text truncated - open the document above for the full version.

Part 15C Conducted Emission Front View Part 15C Conducted Emission Back View Part 15C Radiated Emission Below 1 GHz Front View Part 15C Radiated Emission Below 1 GHz Back View Radiated Emission Above 1 GHz Front View Radiated Emission Above 1 GHz Back View
