YQ6-AG201300045.8G USB Dongle

Logitech Far East Ltd
5.8G USB Dongle - FCC ID YQ6-AG20130004 - Logitech Far East Ltd
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Sep 10, 2013
Application Purpose
Original Equipment
Date of Application
Jul 29, 2013
Equipment Note
5.8G USB Dongle
Frequency Range
5736.00000000 - 5814.00000000
Company
Logitech Far East Ltd
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗
↗

Test Report

↗

Test Setup Photos

↗
↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

INSTRUCTION MANUAL PC WIRELESS HEADSET A50 ASTRO Gaming's A50 Wireless Headset offers a solution for the audio-savvy citizen who equally measures business and pleasure. Professionally-tuned Astro Audio paired with Dolby® 7.1 surround sound to pack aural one-two punch, while three unique EQ modes provide fully customizable transitions between media and gaming. Whether you're gaming, enjoying a feature film, or have tunes in need of heavy rotation-- control over bass and ambient noise is all just a touch away. Congratulations on your sound investment. The A50's are equipped with KleerNet's 5.8 GHz wireless technology, designed for unimpaired performance amongst the array of other RF traffic. ASTRO Gaming's integrated MixAmp™ technology allows for precise control of game to voice balance, all fitting neatly into the contoured design of the A50. This guide will point to the various ways in which your A50's can be adjusted to a setup that's all your own. A50 WIRELESS SYSTEM 5.8 GHZ EQ PRESETS USB CHARGING CABLE Charges your A50 Wireless Headset from the TxD unit. DISPLAY STAND Holds Transmitter and headset for storage and charging. Package Contents Contents So... you’ve breached the boxy exterior, and you’re working your way along the inside. Revel in what you’ve uncovered. ASTRO GAMING CONFIDENTIAL 2013 EYES ONLY 010185 ASTRO AUDIO SUPERIOR TOURNAMENT COMPETITIVE System Configuration // PC The USB Tx is 2D/1U; Receiving both stereo game and voice audio, while outputting voice chat. ASTRO GAMING CONFIDENTIAL 2013 EYES ONLY 010185 Connect USB Tx directly to your PC via USB Port. Game Audio In the Control Panel, select: ¬ Sound > Playback ¬ Select “ASTRO USB Audio Tx” then “Set Default” Voice Chat In the Control Panel, select: ¬ Sound > Recording ¬ Select” ASTRO USB Voice Rx” then “Set Default” ASTRO GAMING CONFIDENTIAL 2013 EYES ONLY 010185 ASTRO AUDIO SUPERIOR TOURNAMENT COMPETITIVE System Configuration // MAC Connect USB Tx directly to your Mac via USB Port. Game Audio (Mac OSX) In System Preferences, select: ¬ Sound > Output ¬ Select “ASTRO USB Audio Tx” Voice Chat In System Preferences, select: ¬ Sound > Input ¬ Select “ASTRO USB Voice Rx" ASTRO GAMING CONFIDENTIAL 2013 EYES ONLY 010185 LED Indicator on A50 Headset: Solid Red, USB connected: Charging finished. Solid Red, USB disconnected: Powered on. Blinking Red + Audible Beep: Low Power, Charge Immediately. Solid Orange: Charging Lithium-Ion Battery. Blinking White: Pairing mode. A50 LED BEHAVIOR LED Indicators on USB Tx: USB Tx Top Off: Powered off. Solid White: Powered on. Blinking White: Pairing mode. *For Dolby 7.1 Surround Sound processing, please download the software here: astrogaming.com/A50-USB-PC-Dongle ASTRO GAMING CONFIDENTIAL 2013 EYES ONLY 010185 Xbox LIVE® Cable Port USB Charging Port Microphone Power / Pairing EQ Mode Select 1. Media Mode 2. Core Mode 3. Pro Mode Master Volume Game / Voice Balance A50 User INTERFACE A50 USER INTERFACE A50 Controls Game/Voice Balance: The A50’s integrated game and voice mixing functions are located on your right earpiece. The A50s come preset to a 50/50 balance. To adjust, press the button for the audio function you wish to incrementally increase. Holding down “Game” will cause the mixing function to isolate game sounds, quieting the voice. Pressing “Voice” will cause the mixer to decrease game sounds, amplifying voice. While using this feature you may find your A50 emits a series of intermittent beeps. Rest assured, you haven't been tricked into an ASTRO hearing test. A50 Game/Voice Balance Beeps: ∆ At 50/50 Game + Voice: Emits a single beep ∆ At 100% Voice: Emits a two-tone beep (unique to max voice) ∆ At 100% Game: Emits a two-tone beep (unique to max game) Master Volume: The Master Volume wheel located on the bottom of the right earpiece adjusts overall volume control. Use the Master Volume in conjunction with Game/Voice Balance for total audio domination. Lecherous laughter is optional (but encouraged). Microphone: The A50 fixed microphone operates when in the down/forward position. To activate the microphone's mute feature, simply swing the microphone arm up to the vertical (12 o'clock) position, where the microphone will click into place. Equalizer (EQ) Modes: EQ modes are controlled by a switch located on the back of the right earpiece. The A50s come equipped with three separate EQ modes for better listening: 1. Media: Enhanced bass, for movies and music 2. Core: Balanced for single player gaming 3. Pro: Boosted high frequencies for competitive gameplay ASTRO GAMING CONFIDENTIAL 2013 EYES ONLY 010185 ASTRO AUDIO SUPERIOR TOURNAMENT COMPETITIVE USB TX USER INTERFACE USB Tx – Top: Power/Pairing light indicator USB Tx – Under: Pairing Button - Begin pairing mode by holding this button *For Dolby 7.1 Surround Sound processing, please download the software here: astrogaming.com/A50-USB-PC-Dongle ASTRO GAMING CONFIDENTIAL 2013 EYES ONLY 010185 PAIRING Begin pairing mode by holding the pairing button on the underside of the USB Tx until logo blinks white. USB Tx is now in pairing mode. 1. Hold power button on A50 until it also blinks white and then release. A50 is now in pairing mode. Pairing is confirmed by both devices when A50 LED and logo are solid white. 2. 3. When pairing is complete, A50 power button will turn Red. USB Tx logo will be solid white. 4. ASTRO GAMING CONFIDENTIAL 2013 EYES ONLY 010185 BATTERY & CHARGING ASTRO GAMING CONFIDENTIAL 2013 EYES ONLY 010185 Charging To Charge your A50, attach the USB Charging Cable to the charging port on the A50 headset. The USB Tx does not necessitate charging. Battery Life The non-removable lithium-Ion battery built into your A50s requires a five hour charging cycle to reach full power. Once fully charged, the battery is good for 8 -10 hours of on-head action time, depending on your degree of use. USB Charging Cable ASTRO GAMING CONFIDENTIAL 2013 EYES ONLY 010185 DISPLAY STAND Display Stand - Permanent Assembly Your display stand arrives i…

Text truncated - open the document above for the full version.

Cover Letter(s)

Declaration Letter about Identity of Products Date: 2013-3-23 American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: *WE (SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd) HEREBY DECLARED THAT Product Description: 5.8G USB Dongle Model No. (型号): USB TX Manufacturer’s Name: Astro Gaming, Inc. Manufacturer’s Address: 348 6th St. San Francisco, CA 94103 The device meets the guidelines of the specific KDB Inquiry (Tracking Number 259825), and the operation frequency range/ bandwidth/ modulation technique are identical with the specific KDB Inquiry Note: The definition of identical should be “electrically identical”. A device will be considered to be electrically identical if no changes are made to the devices’ schematics, board layouts, component layouts, chip sets, resistors and all other electrical aspects of the device are identical. Sincerely, Signature: Print Name: Zenger Zhang Position/Title: Projcet Supervisor Contact Number: +86-21-61915664 Email: [email protected]

Cover Letter(s)

121611-20a Authority to Act as Agent I appoint ______ SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd ________ to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in Industry Canada’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by American Certification Body, Inc. (ACB), still resides with ___ Astro Gaming, Inc Dated this _______25________day of ___6________, 20_13___. Agency Agreement Expiration Date: (Typically 8-12 months) By: ___________ ____ Robert Jetter ______ (Signature) (Print name) Title: __________Director of Enginer________________ email: [email protected]___________________ On behalf of :________Astro Gaming, Inc___ ______________ (Company Name) Telephone: ______4154264023____________________

Cover Letter(s)

121611-20a Authority to Act as Agent I appoint ______ SGS-CSTC Standards Technical Services (Shanghai) Co., Ltd ________ to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in Industry Canada’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by American Certification Body, Inc. (ACB), still resides with ___ Astro Gaming, Inc Dated this _______25________day of ___6________, 20_13___. Agency Agreement Expiration Date: (Typically 8-12 months) By: ___________ ____ Robert Jetter ______ (Signature) (Print name) Title: __________Director of Enginer________________ email: [email protected]___________________ On behalf of :________Astro Gaming, Inc___ ______________ (Company Name) Telephone: ______4154264023____________________

Cover Letter(s)

This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. Member of the SGS Group (SGS SA) SGS IECC Limited Units 303-305, 3/F., 31 Lok Yip Road, On Lok Tsuen, Fanling, N.T., Hong Kong Telephone: +852 23052570 Fax: +852 27564480 FEDERAL COMMUNICATIONS COMMISSION CAB Registration number: 446297 No. VF59870 Verification of Conformity for FCC DoC Procedure It is herewith confirmed and found the following designated product Product Name: 5.8G USB Dongle Model : USB TX ( Product Identification ) to comply with the technical requirements set up by ANSI C63.4 & CFR 47 FCC PART 15 regulations for the evaluation of electromagnetic compatibility with. Test Report Number(s): 59870 issued on: September 06, 2013 ( Identification of regulations / standards ) Applicant : Astro Gaming, Inc. Address : 348 6th St. San Francisco, CA 94103 ( Applicant Identification ) TEST LABORATORY This is the test result, that was carried out based on the submitted sample(s) of the product in conformity with the specification of the respective standards. LOKE Sai Kit, Wilson Senior Manager September 06, 2013 This verification is related to the submitted sample(s) and in conjunction with the test data detailed in the above test report.

External Photos

SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1303000415RF -Appendix B Page: 1 of 6 Page 1 of 6 USB TX External Photos Application No.: SHEM1303000415RF Applicant: Astro Gaming, Inc. Address of Applicant: 348 6th St. San Francisco, CA 94103 Equipment Under Test (EUT): Product Name: 5.8G USB Dongle Brand Name: ASTRO Model No.: USB TX FCC ID: YQ6-AG20130004 IC: 9207A-AG2010004 SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1303000415RF -Appendix B Page: 2 of 6 Page 2 of 6 1 Contents Page 1 CONTENTS..........................................................................................................2 2 EXTERNAL PHOTOS........................................................................................3 SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1303000415RF -Appendix B Page: 3 of 6 Page 3 of 6 2 External Photos SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1303000415RF -Appendix B Page: 4 of 6 Page 4 of 6 SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1303000415RF -Appendix B Page: 5 of 6 Page 5 of 6 SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1303000415RF -Appendix B Page: 6 of 6 Page 6 of 6 End

Internal Photos

SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1303000415RF -Appendix B Page: 1 of 4 Page 1 of 4 USB TX Internal Photos Application No.: SHEM1303000415RF Applicant: Astro Gaming, Inc. Address of Applicant: 348 6th St. San Francisco, CA 94103 Equipment Under Test (EUT): Product Name: 5.8G USB Dongle Brand Name: ASTRO Model No.: USB TX FCC ID: YQ6-AG20130004 IC: 9207A-AG2010004 SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1303000415RF -Appendix B Page: 2 of 4 Page 2 of 4 1 Contents Page 1 CONTENTS..........................................................................................................2 2 INTERNAL PHOTOS.........................................................................................3 SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1303000415RF -Appendix B Page: 3 of 4 Page 3 of 4 2 Internal Photos SGS-CSTC Standards Technical Services (Shanghai)Co., Ltd. Report No.: SHEM1303000415RF -Appendix B Page: 4 of 4 Page 4 of 4 E EE En nn nd dd d

RF Exposure Info

USB TX Report No. RXA1303-0334SAR01R1 Page 1 of 67 TESTING No. L2264 OET 65 TEST REPORT Product Name 5.8G USB Dongle Model Brand Name ASTRO FCC ID YQ6-AG20130004 Client Astro Gaming, Inc. Manufacturer Shenzhen Grandsun Electronic Co.,Ltd Date of issue May 16, 2013 TA Technology (Shanghai) Co., Ltd. TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1303-0334SAR01R1 Page 2 of 67 GENERAL SUMMARY Reference Standard(s) FCC 47CFR §2.1093 Radiofrequency Radiation Exposure Evaluation: Portable Devices ANSI C95.1, 1992: Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz.(IEEE Std C95.1-1991) SUPPLEMENT C Edition 01-01 to OET BULLETIN 65 Edition 97-01 June 2001 including DA 02-1438, published June 2002: Evaluating Compliance with FCC Guidelines for Human Exposure to Radio frequency Electromagnetic Fields Additional Information for Evaluation Compliance of Mobile and Portable Devices with FCC Limits for Human Exposure to Radio frequency Emissions. KDB 865664 D01 SAR measurement 100 MHz to 6 GHz v01 SAR Measurement Requirements for 100 MHz to 6 GHz KDB 447498 D01 Mobile Portable RF Exposure v05: Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies KDB 447498 D02 SAR Procedures for Dongle Xmtr v02: SAR Measurement Procedures for USB Dongle Transmitters. Conclusion This portable wireless equipment has been measured in all cases requested by the relevant standards. Test results in Chapter 7 of this test report are below limits specified in the relevant standards for the tested bands only. General Judgment: Pass Comment The test result only responds to the measured sample. Approved by Director Revised by SAR Manager Performed by SAR Engineer TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1303-0334SAR01R1 Page 3 of 67 TABLE OF CONTENT 1. General Information ........................................................................................................................ 4 1.1. Notes of the Test Report ............................................................................................................. 4 1.2. Testing Laboratory ...................................................................................................................... 4 1.3. Applicant Information ................................................................................................................... 5 1.4. Manufacturer Information ............................................................................................................ 5 1.5. Information of EUT ...................................................................................................................... 6 1.6. The Maximum Reported SAR 1g ................................................................................................... 7 1.7. Test Date ..................................................................................................................................... 7 2. SAR Measurements System Configuration ..................................................................................... 8 2.1. SAR Measurement Set-up ........................................................................................................... 8 2.2. DASY5 E-field Probe System ...................................................................................................... 9 2.2.1. EX3DV4 Probe Specification ............................................................................................ 9 2.2.2. E-field Probe Calibration ................................................................................................. 10 2.3. Other Test Equipment ................................................................................................................ 10 2.3.1. Device Holder for Transmitters ....................................................................................... 10 2.3.2. Phantom .......................................................................................................................... 11 2.4. Scanning Procedure .................................................................................................................. 11 2.5. Data Storage and Evaluation ..................................................................................................... 13 2.5.1. Data Storage ................................................................................................................... 13 2.5.2. Data Evaluation by SEMCAD ......................................................................................... 13 3. Laboratory Environment ................................................................................................................ 15 4. Tissue-equivalent Liquid ............................................................................................................... 16 4.1. Tissue-equivalent Liquid Ingredients ......................................................................................... 16 4.2. Tissue-equivalent Liquid Properties ........................................................................................... 16 5. System Check ............................................................................................................................... 17 5.1. Description of System Check .................................................................................................... 17 5.2. System Check Results .............................................................................................................. 18 6. Operational Conditions during Test ............................................................................................... 19 6.1. General Description of Test Procedures .................................................................................... 19 6.2. Measurement Variability .......................................................................................…

Text truncated - open the document above for the full version.

RF Exposure Info

USB TX Report No. RXA1303-0334SAR01R2 Page 1 of 67 TESTING No. L2264 SAR TEST REPORT Product Name 5.8G USB Dongle Model Brand Name ASTRO FCC ID YQ6-AG20130004 Client Astro Gaming, Inc. Manufacturer Shenzhen Grandsun Electronic Co.,Ltd Date of issue August 29, 2013 TA Technology (Shanghai) Co., Ltd. TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1303-0334SAR01R2 Page 2 of 67 GENERAL SUMMARY Reference Standard(s) FCC 47CFR §2.1093 Radiofrequency Radiation Exposure Evaluation: Portable Devices ANSI C95.1, 1992: Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz.(IEEE Std C95.1-1991) KDB 865664 D01 SAR measurement 100 MHz to 6 GHz v01 SAR Measurement Requirements for 100 MHz to 6 GHz KDB 447498 D01 Mobile Portable RF Exposure v05: Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies KDB 447498 D02 SAR Procedures for Dongle Xmtr v02: SAR Measurement Procedures for USB Dongle Transmitters. Conclusion This portable wireless equipment has been measured in all cases requested by the relevant standards. Test results in Chapter 7 of this test report are below limits specified in the relevant standards for the tested bands only. General Judgment: Pass Comment The test result only responds to the measured sample. Approved by Director Revised by SAR Manager Performed by SAR Engineer TA Technology (Shanghai) Co., Ltd. Test Report Report No. RXA1303-0334SAR01R2 Page 3 of 67 TABLE OF CONTENT 1. General Information ........................................................................................................................ 4 1.1. Notes of the Test Report............................................................................................................. 4 1.2. Testing Laboratory ...................................................................................................................... 4 1.3. Applicant Information................................................................................................................... 5 1.4. Manufacturer Information ............................................................................................................ 5 1.5. Information of EUT ...................................................................................................................... 6 1.6. The Maximum Reported SAR 1g ................................................................................................... 7 1.7. Test Date..................................................................................................................................... 7 2. SAR Measurements System Configuration ..................................................................................... 8 2.1. SAR Measurement Set-up........................................................................................................... 8 2.2. DASY5 E-field Probe System ......................................................................................................9 2.2.1. EX3DV4 Probe Specification ............................................................................................ 9 2.2.2. E-field Probe Calibration ................................................................................................. 10 2.3. Other Test Equipment................................................................................................................ 10 2.3.1. Device Holder for Transmitters ....................................................................................... 10 2.3.2. Phantom ..........................................................................................................................11 2.4. Scanning Procedure .................................................................................................................. 11 2.5. Data Storage and Evaluation.....................................................................................................13 2.5.1. Data Storage...................................................................................................................13 2.5.2. Data Evaluation by SEMCAD ......................................................................................... 13 3. Laboratory Environment................................................................................................................ 15 4. Tissue-equivalent Liquid ............................................................................................................... 16 4.1. Tissue-equivalent Liquid Ingredients ......................................................................................... 16 4.2. Tissue-equivalent Liquid Properties........................................................................................... 16 5. System Check ............................................................................................................................... 17 5.1. Description of System Check ....................................................................................................17 5.2. System Check Results .............................................................................................................. 18 6. Operational Conditions during Test ............................................................................................... 19 6.1. General Description of Test Procedures.................................................................................... 19 6.2. Measurement Variability ............................................................................................................ 19 6.3. Test Positions ............................................................................................................................ 20 7. Test Results .................................................................................................................................. 21 7.1. Conducted Power Results ........................…

Text truncated - open the document above for the full version.

Test Report

\ SGS-CSTC Standards Technical Services( (( (Shanghai) )) ) Co., Ltd. 588 West Jindu Road,Songjiang District,Shanghai,China Telephone: +86 (0) 21 6191 5666 Fax: +86 (0) 21 6191 5678 [email protected] Report No.: SHEM130300041501 Page: 1 of 39 Tony Wu E&E Section Manager SGS-CSTC (Shanghai) Co., Ltd. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only TEST REPORT Application No. : SHEM1303000415RF Applicant: Astro Gaming, Inc. Equipment Under Test (EUT): NOTE: The following sample(s) submitted was/were identified on behalf of the client as EUT Name: 5.8G USB Dongle Brand Name: ASTRO Model No: USB TX FCC ID: YQ6-AG20130004 IC ID: 9207A-AG2010004 Standards: FCC PART 15 SUBPART C, Section 15.247:2012 RSS-210 Issue 8 (December 2010) RSS-Gen Issue 3 (December 2010) Date of Receipt: March 20, 2013 Date of Test: March 22, 2013 to March 23, 2013 Date of Issue: June 03, 2013 Test Result: PASS * * In the configuration tested, the EUT (Equipment under test) complied with the standards specified above. SGS-CSTC Standards Technical Services( (( (Shanghai) )) ) Co., Ltd. Report No.: SHEM130300041501 Page: 2 of 39 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without …

Text truncated - open the document above for the full version.

Contact Information

Applicant

Paul Zahra(Senior Manager, Compliance Engineering)
[email protected]+15107135436Fax: 3608171331

Technical Contact

Astro Gaming, IncRobert Jetter
[email protected]4154264023

348 6th St. · San Francisco · United States

Non-Technical Contact

Astro Gaming, IncRobert Jetter
[email protected]4154264023

Test Firm

SGS-CSTC Standards Technical Services Co.,Ltd.Zenger Zhang
[email protected]86(0)2161915654Fax: 8602161915655

Technical Specifications

#Rule PartsFrequency RangePower Output
115C5.74 GHz - 5.81 GHz29.90 mW
Confidentiality
Long Term
Grant Notes
Power Output is conducted. The SAR data in this filing is applicable to demonstrate compliance for the USB Dongle only as shown in this filing. End-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The highest reported SAR values are: Body: 0.32 W/kg.
