YQ6-AG20130005A38 WIRELESS

INSTRUCTION MANUAL BLUETOOTH HEADSET A38 ASTRO Gaming's A38 Wireless Headset offers a solution for the audio-savvy citizen who equally measures business and pleasure. Professionally-tuned Astro Audio paired with Active Noise Canceling audio and microphone. APTx Bluetooth sound packs an aural one-two punch. Whether you're gaming, enjoying a feature film, or have tunes in need of heavy rotation-- control over bass and ambient noise is all just a touch away. Congratulations on your sound investment. A38 HEADSET ANC APTx USB CHARGING CABLE Charges your A38 Headset. CARRYING CASE For safe transport and storage. Package Contents Contents So... you've breached the boxy exterior, and you're working your way along the inside. You'll find that your A38 comes simply bundled. ASTRO GAMING CONFIDENTIAL 2013 EYES ONLY 010185 ASTRO AUDIO SUPERIOR TOURNAMENT COMPETITIVE ASTRO GAMING CONFIDENTIAL 2013 EYES ONLY 010185 ASTRO AUDIO SUPERIOR TOURNAMENT COMPETITIVE UI/IO Power Power / Pairing LEDs Volume USB Port Charging LED Multi- Function Control Mute (Red: Muted White: Mic On) POWER & PAIRING POWER To turn on: Press Power Button once (Audio Wake Up Tone Confirmation) To turn off: Hold Power Button for 1s (Audio Power Down Tone Confirmation) ASTRO GAMING CONFIDENTIAL 2013 EYES ONLY 010185 Blinks Blue: On Pairing 1. Enable Bluetooth Pairing / Scanning on device host 2. Hold Power Button on A38 for 3s to enter pairing mode (Series Beep Confirmation, LED alternates red and blue) Pairing Successful: (Audio Rising Tone Confirmation) Pairing Failed: (Audio Failture Tone Confirmation) Device is listed as “ASTRO A38” To connect to previous device, turn on A38 and hold power button for 2s. For optimal connectivity, minimize obstructions between Bluetooth device and Bluetooth Antenna on A38 A38 will auto power off after 5 minutes of inactivity If you need technical support please submit a support ticket at astrogaming.com/support NFC PAIRING NFC PAIRING 1. Enable NFC on device 2. Hold NFC device to A38 left ear cup To disconnect from NFC device: Hold NFC device to A38 left ear cup To power A38 on and pair with NFC: If A38 is off, enable NFC on device Hold NFC device to A38 left ear cup A38 will turn on and pair. *Success may vary between devices ASTRO GAMING CONFIDENTIAL 2013 EYES ONLY 010185 NFC Tag Bluetooth Antenna Left Side ASTRO GAMING CONFIDENTIAL 2013 EYES ONLY 010185 ASTRO AUDIO SUPERIOR TOURNAMENT COMPETITIVE CONTROLS Power Power / Pairing LEDs Volume USB Port Charging LED Multi- Function Control Mute (Red: Muted White: Mic On) Solid Amber: Charging Amber Off: Charge Complete Volume Control Increase Volume: Press or Hold + Decrease Volume: Press or Hold - Multi Function Control Pick up / End Call: Press once Reject Call / Call Waiting: Hold for 1s Answer Call Waiting: Press once Track Forward: Press twice Track Back: Hold for 1s and release Play / Pause: Press once Airplane Mode On / Off: Hold for 5s (Red + Blue) Charging Plug in USB to any power source Troubleshooting See FAQ: http://www.astrogaming.com/a50/a50-wireless-system All products purchased directly from ASTRO Gaming comes with an automatic 1 year warranty on defective parts or faulty workmanship. No registration is required. That being said, if you register your product with us, we will be able to provide you with even better customer service *and* we’ll cover your shipping in both directions if a repair is needed for domestic customers. Furthermore, if you purchased one of our products from a retailer other than ASTRO Gaming, you’ll need to register it with us otherwise we’ll have no idea who you are. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Register ASTRO products here: http://www.astrogaming.com/register ASTRO GAMING CONFIDENTIAL 2013 EYES ONLY 010185 SUPPORT Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Warning words used in IC : Need both French and English; This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. This ClassB digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada ASTRO GAMING CONFIDENTIAL 2013 EYES ONLY 010185 FCC STATEMENT

Astro Gaming, Inc. 655 4th St. San Francisco California 94107 United States Request for Confidentiality Date: 2013.09.04 Subject: Confidentiality Request for: _FCC ID:YQ6-AG20130005_____ Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operational Description/Theory of Operation Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: ______(Insert Explanation as Necessary)______ Astro Gaming ，Inc has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify PHOENIX in the event information regarding the product or the product is made available to the public. PHOENIX will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: Robert Jetter ________________________ (Signature/Title3) (Print name) 1 - The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.” 2 - Please refer to http://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead. Robert Jetter

Astro Gaming, Inc. 655 4th St. San Francisco California 94107 United States Authority to Act as Agent Date: 2013.9.04 To Whom It May Concern: We, the undersigned, hereby authorize SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Shenzhen Branch and Hellen Wang in SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Shenzhen Branch to act on our behalf in all matters relating to all processes required in FCC approval and any communication needed with the national authority, shall have the same legal authority as acts on our own behalf. We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: 12 months By: Robert Jetter (Signature1) (Print name) Title: Director of Engineering On behalf of: Astro Gaming ，Inc (Company Name) Telephone: + 1 415 426- 4010________ 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.
