YQ7-TN-UHF-Q150UHF RFID read/write device

1 A5060 SlimLine™ CP RAIN (UHF) RFID ANTENNA Ordering Information (please quote product code, band / cable type & part no.) *Antenna Product Code Band Part No. A5060 ETSI 865-868 MHz 71876 A5060 FCC 902-928 MHz 71875 Mounting Accessories Product Code Part No. Mo un ting Plate (A5060) ETSI an d FCC 72095 Cable Accessories Product code Cable Type Part No. Cable 2 m, SMA to RPTNC T7195 / 240 / 400 71436 / 71782 / 72042 Cable 4 m, SMA to RPTNC T7 240 / 400 71784 / 72043 Cable 6 m, SMA to RPTNC T7 240 / 400 71904 / 72044 Cable 8 m, SMA to RPTNC T7 240 / 400 71788 / 72045 *ROHS & CE co mp liant. View the Times-7 Cable Accessory datasheet here Ordering Information An exciting new addition to the SlimLine™ range of multi-purpose antennas, the A5060 is a circular polarized high gain antenna with an ultra-low profile, offering a read range of up to 10 m / 33 ft. The A5060 is designed with a multi-element array to avoid distortion for maximum readability in a highly reflective and densely populated tag environment. This makes the A5060 ideal for industrial portal applications. Its standard physical size (600 mm x 300 mm / 2’ x 1’) allows the A5060 to be readily mounted behind ceiling tiles, in cabinets or to cover large bench tops. The A5060 can be either flush mounted using the six integrated mounting holes or VESA mounted using the Times-7 Mounting Plate. The A5060 multi-purpose antenna High Gain, up to 10m / 33 ft. read range Multi-element array, ideal for reflective environments ABOUT TIMES- 7 We are a high-tech company specializing in the design and manufacture of RAIN (UHF) RFID antennas. Founded in 2006, Times-7 has developed the largest portfolio of fixed RAIN RFID reader antennas. Based in Lower Hutt, New Zealand we export all over the world through an authorized network. Times-7 antennas are famous for their quality and performance. In addition to our world-class products and in-depth expertise, our customers appreciate Times-7’s customer service and technical support. We are responsive in supporting a large global customer base and ensuring the success of our customer's implementations. T im es- 7 Resear ch Ltd 10 Te Puni Street Lower Hutt 5012 New Z ea la nd NE W Z E ALAND P: +64 4 974 6566 USA/CANADA P: +1 408 769 5025 E: s a les @ tim es- 7. com www. tim es- 7. com 2 A5060 XZ Plane A5060 YZ Specifications A5060 SlimLine™ CP RAIN (UHF) RFID ANTENNA Physical / Environmental Specifications Dimen sions un boxed: Len g th (x) x Width (y) x Dep th (z) 600 mm x 300 mm x 9 mm 1.96" x 0.98" x 0.34" Boxed unit d imensions: (L x W x D) 650 mm x 360 mm x 30 mm 2.13" x 1.18" x 1.18" Weig ht: Net: 1.48 kg / 3.3 lbs. G ro s s: 1.79 kg / 3.9 lbs Rad o me Material: Fire retard ant ABS En vironmental Rating: IP54 Op erating / Sto rage Temperature: -20° to +55°C / -30° to +6 0°C -4° to +131°F / -22° to +140°F Mo un ting: In teg rated flush mounting h oles o r VESA mount Co n n ector type / p o sition: SMA female sid e fly lead Cable typ e/ len gth: RG316 / 270 mm / 10.6" Freq uen cy Ran ge: 865-868 MHz (ETSI) / 902-928 MHz (FCC) Po larisation: RHCP (Right Hand Circular Po larized) Far-field Gain: 10.5 d BiC typical Far-field 3d B beamwidth: * 25° in XZ-p lane, 60° in YZ-plane VSW R: 1.4 typical Fro n t to back ratio: -25 dB Axial Ratio: 2 d B typical No min al Imp edance: 50 Ω An ti-static p rotection: Yes, DC g ro unded An ten n a Detection: 10 K Ω resistance Maximum In p ut Po wer: 3 W Azimuth Planes Electrical Specifications Radiation Pattern 3 Mounting Information A5060 SlimLine™ CP RAIN (UHF) RFID ANTENNA Flush mount The A5060 antenna has 7 pre-drilled mounting holes on the rear side, which can be drilled fully through without damaging the antenna. For further instructions please click here. Bracket mount The Times-7 Mounting Plate for the A5060 is designed to support VESA brackets. Each mounting plate comes with a screw kit. For instructions on how to attach the bracket to the antenna please click here . Installation Instructions • Ensure that only finger tightness is used for the SMA connector. Use of tools to tighten the connector will apply excessive force and will damage the connector. • Avoid any load or bending force from the cable on the connector. 6 Laundry Applications With its high gain, the A5060 antenna has th e potential to read through densely packed laundry items. The antennas can either be configured as a standalone industrial portal to track trolleys full of laundry goods or can be used in a conveyor to track movement. The antenna’s confined RF emission elimin ates stray tag reads. The antennas can also be used over the bench tops in packing/folding stations. In du strial Portal Th e IP54 rating and the 10.5 dBiC gain makes this antenna highly suitable for industrial applications. A densely packed asset with numerous tags can be identified accurately with almost no effort. A standalone portal can be realized with four A5060 antennas (see pictures) All possible tag orientations will be captured due to th e A5060’s circular polarization and A5060 antennas’ locations. The antennas on the sides are offset such that the antennas do not face each other and induce maximum coverage within the portal. Almost all assets can be tracked with greater accuracy using our A5060 antenna. Applications The vertical configuration is recommended for high density asset tracking (such as palatized boxes, trolley of laundry goods, etc) where you will need a larger RF zone to efficiently read all the tagged items. The RF read window is expanded in and out of the portal. A5060 SlimLine™ CP RAIN (UHF) RFID ANTENNA The horizontal configuration is recommended to avoid the stray reads due to an expanded read window. The read zone/area is restricted within the width of the portal. Assets that are not densely packed can be read efficiently using this configuration. 7 Vehicle Tolling/Vehicle Access Control The A5060’ 10.5 dBiC gain is powerful enough to read vehicular tags, e.g., embedded in the windscreen or the…

Text truncated - open the document above for the full version.

Hans Turck GmbH & Co. KG | 45466 Mülheim an der Ruhr, Germany | T +49 208 4952-0 | F +49 208 4952-264 | [email protected] | www.turck.com1|1 TB-UHF-ANT-Q250-FCC | 29-03-2021 10-05 | Technical modifications reserved TB-UHF-ANT-Q250-FCC Accessories – External Passive UHF Antenna Technical data TypeTB-UHF-ANT-Q250-FCC ID no.100028598 Region (UHF)USA, Canada, Mexico (902...928 MHz) Antenna polarizationRHCP Antenna gain FCC8.5 dBic Antenna HPBW68 ° Ambient temperature0...+65 °C Storage temperature0...+65 °C Dimensions250 x 250 x 14 mm Housing materialPolycarbonate/ABS Protection classIP67 Electrical connectionSMA Input impedance50 Ohm Packaging unit1 Features Functional principle The UHF read/write heads form a transmission zone, the size of which may vary depending on the combination of read/write head and tag used. Attainable distances may vary due to component tolerances, mounting conditions, ambient conditions and material qualities, especially when mounted in metal. Testing of the application under real operating conditions is therefore essential, especially with on-the-fly reading and writing!

Hans Turck GmbH & Co. KG | 45466 Mülheim an der Ruhr, Germany | T +49 208 4952-0 | F +49 208 4952-264 | [email protected] | www.turck.com1|2 TN-UHF-ANT-Q250-FCC | 17-01-2024 09-28 | Technical modifications reserved TN-UHF-ANT-Q250-FCC Accessories – External Passive UHF Antenna Technical data Type TN-UHF-ANT-Q250-FCC ID100028600 Region (UHF)FCC (902...928 MHz) Antenna polarizationRHCP Antenna gain FCC8.5 dBic Antenna HPBW68° Ambient temperature0...+65 °C Storage temperature0...+65 °C Dimensions250 x 250 x 30 mm Housing materialPolycarbonate/ABS Protection classIP67 Electrical connectionSMA Input impedance50 Ohm Packaging unit1 Features ■ Passive far-field antenna, compatible with VESA 100 brackets Functional principle The UHF read/write heads form a transmission zone, the size of which may vary depending on the combination of read/write head and tag used. Attainable distances may vary due to component tolerances, mounting conditions, ambient conditions and material qualities, especially when mounted in metal. Testing of the application under real operating conditions is therefore essential, especially with on-the-fly reading and writing! Accessories TN-UHF-ACCSY-Q250-PROTECT100028606 Protective plate for SMA connector of TN-UHF-ANT-Q250... antenna TN-UHF-ACCSY-VESA100-MOUNT100029071 VESA100 bracket Accessories Dimension drawingTypeID TN-UHF-CBL-HF240-RPTNC-1- SMA 100028191HF240 coaxial cable, length 1 m TN-UHF-CBL-HF240-RPTNC-2- SMA 100028192HF240 coaxial cable, length 2 m Hans Turck GmbH & Co. KG | 45466 Mülheim an der Ruhr, Germany | T +49 208 4952-0 | F +49 208 4952-264 | [email protected] | www.turck.com2|2 TN-UHF-ANT-Q250-FCC | 17-01-2024 09-28 | Technical modifications reserved Dimension drawingTypeID TN-UHF-CBL-HF240-RPTNC-4- SMA 100028193HF240 coaxial cable, length 4 m TN-UHF-CBL-HF240-RPTNC-6- SMA 100028194HF240 coaxial cable, length 6 m TN-UHF-CBL-HF240-RPTNC-8- SMA 100028195HF240 coaxial cable, length 8 m TN-UHF-CBL-HF240-RPTNC-10- SMA 100028196HF240 coaxial cable, length 10 m TN-UHF-CBL-HF240-RPTNC-12- SMA 100028197HF240 coaxial cable, length 12 m

Hans Turck GmbH & Co. KG | 45466 Mülheim an der Ruhr, Germany | T +49 208 4952-0 | F +49 208 4952-264 | [email protected] | www.turck.com1|2 TN-UHF-ANT-Q150-MR-FCC | 17-01-2024 09-29 | Technical modifications reserved TN-UHF-ANT-Q150-MR-FCC Accessories – External Passive UHF Antenna Technical data Type TN-UHF-ANT-Q150-MR-FCC ID100047589 Region (UHF)FCC (902...928 MHz) Antenna polarizationRHCP Antenna gain FCC-3 dBic Antenna HPBW115° Ambient temperature-40...+65 °C Storage temperature-40...+65 °C Dimensions150 x 150 x 14.5 mm Housing materialPolycarbonate/ABS Protection classIP67 Electrical connectionSMA Input impedance50 Ohm Packaging unit1 Features ■ Passive mid-range antenna, compatible with VESA 100 brackets Functional principle The UHF read/write heads form a transmission zone, the size of which may vary depending on the combination of read/write head and tag used. Attainable distances may vary due to component tolerances, mounting conditions, ambient conditions and material qualities, especially when mounted in metal. Testing of the application under real operating conditions is therefore essential, especially with on-the-fly reading and writing! Accessories TN-UHF-ACCSY-Q150-PROTECT100028607 Protective plate for SMA connector of TN-UHF-ANT-Q150... antenna Accessories Dimension drawingTypeID TN-UHF-CBL-HF240-RPTNC-1- SMA 100028191HF240 coaxial cable, length 1 m TN-UHF-CBL-HF240-RPTNC-2- SMA 100028192HF240 coaxial cable, length 2 m Hans Turck GmbH & Co. KG | 45466 Mülheim an der Ruhr, Germany | T +49 208 4952-0 | F +49 208 4952-264 | [email protected] | www.turck.com2|2 TN-UHF-ANT-Q150-MR-FCC | 17-01-2024 09-29 | Technical modifications reserved Dimension drawingTypeID TN-UHF-CBL-HF240-RPTNC-4- SMA 100028193HF240 coaxial cable, length 4 m TN-UHF-CBL-HF240-RPTNC-6- SMA 100028194HF240 coaxial cable, length 6 m TN-UHF-CBL-HF240-RPTNC-8- SMA 100028195HF240 coaxial cable, length 8 m TN-UHF-CBL-HF240-RPTNC-10- SMA 100028196HF240 coaxial cable, length 10 m TN-UHF-CBL-HF240-RPTNC-12- SMA 100028197HF240 coaxial cable, length 12 m

TURCK GmbH | 45472 Mülheim an der Ruhr, Germany | T +49 208 4952-0 | [email protected] | www.turck.com1|4 Type designationTN-UHF-ANT-Q150-LX-FCC Ident-No.100047591 Technical data Electrical data Antenna gain FCC8 dBic Antenna HPBW115° Antenna polarizationlinear Region (UHF)FCC (902...928 MHz) Mechanical data Dimensions150 mm x 150 mm x 14,5 mm Housing materialPlastic, Polycarbonate/ABS Electrical connectionSMA Input impedance50 Ohm Ambient conditions Ambient temperature-40...+65 °C Storage temperature-40...+65 °C Protection classIP67 Comments Packaging unit1 • Features Passive far-field antenna, compatible with VESA 100 brackets Functional principle The UHF read/write heads form a transmission zone, the size of which may vary depending on the combination of read/ write head and tag used. The achievable distances may be different due to component tolerances, mounting location in the application, ambient conditions and the effect of materials (particularly metal). Testing of the application under real operating conditions is therefore essential, especially with on-the-fly reading and writing! TN-UHF-ANT-Q150-LX-FCC Accessories External passive UHF antenna | 25-06-2026 09:06 | Subject to technical changes | TURCK GmbH | 45472 Mülheim an der Ruhr, Germany | T +49 208 4952-0 | [email protected] | www.turck.com2|4 Mounting accessories TN-UHF-ACCSY-Q150- PROTECT 100028607 Protective plate for SMA connector of TN-UHF-ANT- Q150... antenna | 25-06-2026 09:06 | Subject to technical changes | TURCK GmbH | 45472 Mülheim an der Ruhr, Germany | T +49 208 4952-0 | [email protected] | www.turck.com3|4 Connection accessories TN-UHF-CBL-HF240-RPTNC-1-SMA100028191 HF240 coaxial cable, length 1 m TN-UHF-CBL-HF240-RPTNC-2-SMA100028192 HF240 coaxial cable, length 2 m TN-UHF-CBL-HF240-RPTNC-4-SMA100028193 HF240 coaxial cable, length 4 m TN-UHF-CBL-HF240-RPTNC-6-SMA100028194 HF240 coaxial cable, length 6 m TN-UHF-CBL-HF240-RPTNC-8-SMA100028195 HF240 coaxial cable, length 8 m TN-UHF-CBL-HF240-RPTNC-10-SMA100028196 HF240 coaxial cable, length 10 m TN-UHF-CBL-HF240-RPTNC-12-SMA100028197 | 25-06-2026 09:06 | Subject to technical changes | TURCK GmbH | 45472 Mülheim an der Ruhr, Germany | T +49 208 4952-0 | [email protected] | www.turck.com4|4 Connection accessories HF240 coaxial cable, length 12 m | 25-06-2026 09:06 | Subject to technical changes |

V2-03/24 A5020NF ©2024 Times-7 Research Ltd. All rights reserved. Specifications are subject to change without notice. 1 The A5020NF Near-Field antenna is part of our versatile and high-performing A5020 family. These antennas are known for their robustness and compact design, making them some of our best-selling solutions for various applications. The A5020NF is designed to operate in ‘tap and go’ environments where only objects that come into close contact with the antenna will be tracked. This prevents stray reads and is ideal for situations where accuracy is paramount, like access control and point-of-sale. It is specifically tuned to read only in the near-field zone of 100mm ( 3.94”). The A5020 range is built to Times-7’s high standard for quality and ruggedness. Being rated IP68, the A5020NF can also be used for permanent outdoor applications. As well as being durable, its pleasing and timeless design blends beautifully with most interiors and makes the A5020NF suitable for customer- facing environments. Note: Please quote product code, band, cable type & part number Antenna Product Code Band Part Number A5020NF 865-928 MHz / Wide Band 72057 Cable Accessories Product Code Cable Type Part Number Cable 2m, SMA to RPTNC T7 195 / 240 / 400 71436 / 71782 / 72042 Cable 4m, SMA to RPTNC T7 240 / 400 71784 / 72043 Cable 6m, SMA to RPTNC T7 240 / 400 71904 / 72044 Cable 8m, SMA to RPTNC T7 240 / 400 71788 / 72045 Other Accessories Compatibility Part Number A5020 Connector Protection Backplate A5020 LX / CP / MR / NF 72394 For additional information such as RoHS, CE, Reach, please contact us at [email protected]. View the Times-7 Cable Accessory datasheet here A5020NF Near-Field Antenna Ordering Information A5020NF NearField Antenna Product Datasheet ABOUT TIMES-7 We are a high-tech company specializing in the design and manufacture of RAIN (UHF) RFID antennas. Our journey began in 2006, when Times-7 was founded. Since then, we have developed the largest portfolio of fixed RAIN RFID reader antennas, which are famous for their quality and performance. We are based in Lower Hutt, New Zealand, but our reach extends worldwide as we export our products through our authorized partner network. In addition to our world-class products and in-depth expertise, our customers appreciate Times-7’s customer service and technical support. We are responsive in supporting a large global customer base and ensuring the success of our customer's implementations. Times-7 Research Ltd 10 Te Puni Street, Lower Hutt Wellington 5012 New Zealand NEW ZEALAND P: +64 4 974 6566 E: [email protected] W: www.times-7.com Patent Info: www.times-7.com/patents V2-03/24 A5020NF ©2024 Times-7 Research Ltd. All rights reserved. Specifications are subject to change without notice. 2 Unboxed Dimensions: *Length (x) x Width (y) x Depth (z): 150.7 x 149.4 x 14.5mm 5.93 x 5.88 x 0.57" Boxed Unit Dimensions: (L x W x D) 180 x 155 x 25mm 7.09 x 6. 10 x 0.98" Weight: Net: 0.18kg / 0.38lbs. Gross: 0.23kg / 0.5lbs. Radome Material and Color: Flame retardant and UV resistant white ABS Environmental Rating: IP68 Operating and Storage Temperature: -30° to +65°C / -22° to +149°F Mounting: Flush or 100 x 100mm VESA mount using the four mounting holes Connector Type SMA female (Jack) side connector A5020 Flush Screws 30mm 8g Phillips, white wood screws Frequency Range: 865-928 MHz (ETSI & FCC) Polarization: Near-Field Far-Field Gain: Equivalent to -30dBi Far-Field 3dB Beamwidth: Not Applicable VSWR: 1.4 typical Front-To-Back Ratio: Not Applicable Axial Ratio: Not Applicable Nominal Impedance: 50Ω Anti-Static Protection: Yes, DC Grounded Antenna Detection: 100Ω resistance Maximum Input Power: 3W *Azimuth Planes Physical / Environmental Specifications Electrical Specifications A5020NF NearField Antenna Product Datasheet V2-03/24 A5020NF ©2024 Times-7 Research Ltd. All rights reserved. Specifications are subject to change without notice. 3 Applications Tap ‘n’ Go Payment The A5020NF antenna impresses with an extremely close read range of ⩽10 0mm (3.94”) from the antenna’s surface, suitable for purchase and payment applications. Although the A5020NF cannot read credit/debit cards, which are equipped with HF RFID, it is widely used to scan proprietary UHF badges for purchase of goods. For example, employees can scan their badges to pay for food bought from their cafeteria. Access Control With the increasing prevalence of UHF RFID technology being deployed, many opt for a unified RFID system to streamline functions such as inventory management, asset tracking, people tracking, access control, and anti-theft measures. When it comes to 'Tap and Authenticate' enabled doors, the A5020NF stands out as the perfect choice, as it fully aligns with RFID technology standards. This antenna's precision ensures that it exclusively only reads designated tags, preventing any unintended detection, such as someone merely passing through the door. Direct Contact Reads The A5020NF antenna excels where there is a need to read data from objects in close proximity to the antenna. To record the usage of a high-value precision instrument or tools it would need to be scanned before the lock can be released. Only an antenna with a proximity read is suitable for these applications. A5020NF NearField Antenna Product Datasheet V2-03/24 A5020NF ©2024 Times-7 Research Ltd. All rights reserved. Specifications are subject to change without notice. 4 In situations where stress may impact the antenna’s connector or cable, we recommend using our Connector Protection Backplate. This backplate safeguards the connector, especially when the antenna is mounted on a bracket in free space. It is compatible with both right-angled and straight cables. Please note the following precautions: • Ensure that only finger tightness is used for the SMA connector. • Use of tools to tighten the connector will apply excessive force and will damage the connector. • Avoid any load or bending force from the cab…

Text truncated - open the document above for the full version.

1 Equipped with the familiar and industry leading Times-7 ultra-low profile, the A5020 offers a compact footprint of only 150 mm / 5.9 inch square in a very smart-looking design. With a 1.5 ft. wider read range than most other antennas of similar size in the market, the circularly polarized A5020 antenna creates a new benchmark for multi-purpose UHF RFID antennas. IP68 rated and built to Times-7’s high standard for quality and robustness, the A5020 can be used for permanent outdoor applications. Its pleasing aesthetics and timeless design blends beautifully with most interiors, which makes the A5020 very suitable for customer facing environments. The SlimLine A5020 A5020 SlimLine CP RAIN (UHF) ANTENNA 150 mm / 5.9 in. square footprint IP68 rating for permanent outdoor use and industrial applications Aesthetically appealing design A B O U T T I M E S-7 Times-7 is a high-tech company specialising in the design and manufacture of RAIN (UHF) RFID antennas, based in Lower Hutt, New Zealand. We export all over the world either direct or through our distributor, authorized reseller and integrated solutions provider network. Our brand is well-established in the global RFID market, and we are known for high quality and reliability, as well as our significant RF expertise. Founded in 2006, Times-7 has developed the largest portfolio of fixed RAIN RFID reader antennas. As well as standard antennas for all applications, Times-7 also offers a custom antenna development service, when the requirements are not fully satisfied by our catalogue antennas. Times-7 Research Ltd 29 Railway Avenue Lower Hutt 5010 New Zealand NEW ZEALAND P: +64 4 974 6566 USA/CANADA P: +1 408 769 5025 E: [email protected] www.times-7.com 2 Physical / Environmental Specifications Dimensions (L x W x D): (X x Y x Z) 150.7 mm x 149.4 mm x 14.5 mm 5.93 “x 5.88 “x 0.57 “ Boxed unit dimensions: (L x W x D) 185 mm x 155 mm x 25 mm 7.2” x 6.1” x 0.98” Weight: Net: 0.25 kg / 0.55 lbs.; Gross: 0.27 kg / 0.6 lbs. Radome Material: UV-Resistant ABS Environmental Rating: IP68 Operating / Storage Temperature: -40° to +65°C -40° to +149°F Mounting: Flush or VESA mount (mounting info on page 3) Connector type / position: SMA female side connector Electrical Specifications Frequency Range: 865-868 MHz / 902-928 MHz Polarization: RHCP (Right Hand Circular Polarized) Far-field Gain: 5.5 dBiC typical Far-field 3dB beamwidth:* 115 in both planes VSWR: 1.4 typical Front to back: -10 dB Axial Ratio: 2 dB typical Nominal Impedance: 50 Ω Anti-static protection: Yes, DC Grounded Antenna Detection 10K Ω resistance Maximum Input Power: 3 W *Far field 3dB beam width in xz-plane is always along the longer side (L) of the antenna. Specifications Order Information • Ordering Information (please quote product code, band / cable type & part no.) *Antenna Product Code Band Part No. A5020 FCC 902-928 MHz 60010 A5020 ETSI 865-868 MHz 60011 Cable Accessories Product Code Cable Type Part No. Cable 2 m, SMA to RPTNC LMR 195 / 240 / 400 71436 / 71782 / 72042 Cable 4 m, SMA to RPTNC LMR 240 / 400 71784 / 72043 Cable 6 m, SMA to RPTNC LMR 240 / 400 71904 / 72044 Cable 8 m, SMA to RPTNC LMR 240 / 400 71788 / 72045 *Built in New Zealand. ROHS & CE compliant. Patent Pending View the Times-7 Cable Accessory datasheet here A5020 SlimLine CP RAIN (UHF) ANTENNA 3 E-field Radiation Pattern XZ-plane YZ-plane A5020 SlimLine CP RAIN (UHF) ANTENNA Mounting Information The mounting holes of the A5020 support VESA spaced mounting brackets as shown in the picture. For more information on the Mounting Bracket in the picture, please click here. The A5020 is designed to support either flush or VESA mount in one SKU. The flush mounting holes are VESA spaced and can accommodate M6 and ¼” type bolts and M4 screws. Installation Instructions Ensure that only a firm finger tightness is used for the SMA connector. Use of tools to tighten the connector will apply excessive force and likely damage the connector. Avoid any load or bending force from the cable on the connector. 4 Test Standard Duration Temp. C° Notes IPX Dust AS60529 - 2004 8Hrs Severity: Vacuum, up to -2KPa IPX8 Immersion AS60529 - 2004 30 min Severity: 1.5 Depth Basic vibration IEC60068 - 2 - 64 1 Hrs per axis - 3 axis Severity: Vehicle vibration 10-500 MHz 1.04g rms Shock Test MIL-STD-810G 5 pulses/direction - 6 direction Severity: Half sine 10g, 11ms Thermal Shock IEC60068 - 2 - 14 5 Cycles - 2 Hrs precondition -65° to +65° Salt Fog ASTMB117 24 Hrs +35° A5020 SlimLine CP RAIN (UHF) ANTENNA Environmental Test All reliability and performance measurement have been performed by certified, independent labs. Full report is available on request. 5 Mechanical Drawing for the A5020 6 The technical data contained in this publication is not a guarantee for which Times-7 Research Ltd assumes legal accountability. It is indicative of typical performance, and if required should be relied on for specific applications only after due verification. All technical data, specifications and other information contained herein are deemed to be the proprietary intellectual property of Times-7 Research Ltd. No reproduction, copy or use thereof may be made without the express written consent of Times-7 Research Ltd. Times-7, and the stylized T-7 Antennas logo are trademarks or registered trademarks of Times-7 Research Ltd. All other trademarks are the property of their respective owners. © 2019 Times-7 Research Ltd. All rights reserved. Specifications are subject to change without notice. Datasheet v2.1 A5020 SlimLine CP RAIN (UHF) ANTENNA G L O B A L S U P P O R T In addition to our world-class products and in-depth expertise, Times-7 is known for their quality of customer service and technical support. We place emphasis on our responsiveness in supporting a large global customer base and ensuring the success of our customer's implementations. Times-7 Research Ltd 29 Railway Avenue Lower Hutt 5010 New Zealand NEW ZEALAND P: +64 4 974 6566 USA/CANADA P: …

Text truncated - open the document above for the full version.

1 The Times-7 industry leading ultra-low profile design is now available in a compact 250 mm / approx.10 in. square footprint. IP67 rated for permanent outdoor use and built to Times-7’s high standard for quality and robustness, the circularly polarized A5010 creates a new benchmark for multi-purpose UHF RFID antennas. A B O U T T I M E S-7 Times-7 is a high-tech company specialising in the design and manufacture of RAIN (UHF) RFID antennas, based in Lower Hutt, New Zealand. We export all over the world either direct or through our distributor, authorized reseller and integrated solutions provider network. Our brand is well-established in the global RFID market, and we are known for high quality and reliability, as well as our significant RF expertise. Founded in 2006, Times-7 has developed the largest portfolio of fixed RAIN RFID reader antennas. As well as standard antennas for all applications, Times-7 also offers a custom antenna development service, when the requirements are not fully satisfied by our catalogue antennas. Times-7 Research Ltd 29 Railway Avenue Lower Hutt 5010 New Zealand NEW ZEALAND P: +64 4 974 6566 USA/CANADA P: +1 408 769 5025 E: [email protected] www.times-7.com The SlimLine A5010 A5010 SlimLine CP RAIN (UHF) RFID ANTENNA Up to 9m / 29 ft. read range Just 14mm / 0.55 in. thick High performance & rugged design IP67 rating for permanent outdoor use And industrial applications 2 Physical / Environmental Specifications Dimensions (L x W x D): 250 mm x 250 mm x 14 mm 9.85 “ x 9.85 “ x 0.55 “ Boxed unit dimensions: (L x W x D) Flush: 280 mm x 255 mm x 20 mm 11.02” x 10.03” x 0.78” Stud: 310 mm x 280 mm x 40 mm 14.96” x 11.02” x 1.57” Weight: Net: 0.575 kg / 1.26 lbs. Gross: NZ 0.695Kg / 1.53 lb Gross: US 0.728Kg / 1.60 lb Radome Material: UV-Resistant ABS Environmental Rating: IP67 Operating / Storage Temperature: 0° to +65°C / 0° to +65°C -4° to +131°F / -22° to +149°F Mounting: Flush or VESA mount (mounting info on page 4) Connector type / position: SMA female side connector Electrical Specifications Frequency Range: 865-868 MHz / 902-928 MHz Polarization: RHCP (Right Hand Circular Polarized) Far-field Gain: 8.5 dBiC typical Far-field 3 dB beamwidth:* 68 in both planes VSWR: 1.3 typical Front to back ratio: -20 dB Axial ratio: 1 dB typical Nominal impedance: 50 Ω Anti-static protection: Yes, DC grounded Antenna detection 10 K Ω resistance Maximum Input Power: 3 W *Far field 3dB beam width in xz-plane is always along the longer side (L) of the antenna. (please quote both product code & part no.) *Antenna Product Code Band Part No. A5010 (Flush Mounted) FCC 902-928 MHz 60001 A5010 (Flush Mounted) ETSI 865-868 MHz 60002 A5010 (Stud Mounting) FCC 902-928 MHz 60003 A5010 (Stud Mounting) ETSI 865-868 MHz 60004 Cable Accessories Cable Type Part No. Cable 2 m, SMA to RPTNC LMR 195 / 240 71436 / 71782 Cable 4 m, SMA to RPTNC LMR 195 / 240 71437 / 71784 Cable 6 m, SMA to RPTNC LMR 240 71904 Cable 8 m, SMA to RPTNC LMR 195 / 240 71438 / 71788 A5010 SlimLine CP RAIN (UHF) RFID ANTENNA Order Information • Specifications: View the Times-7 Cable Accessory datasheet here *Built in New Zealand. ROHS & CE compliant. 3 A5010 SlimLine CP RAIN (UHF) RFID ANTENNA E-field Radiation Pattern YZ-plane XZ-plane 3D E-field radiation 4 A5010 SlimLine CP RAIN (UHF) RFID ANTENNA Test Standard Duration Temperature Notes Thermal Shock (non op) 1 Hr. -45 / 70° C 3 cycles Humidity 72 Hours 85° C RH Dust Resistance IEC 60529 8 Hrs. with vacuum Solar Radiation 4 Days 340 nm Impact Resistance 1 lb ball drop at 24'' X 6 (top/bottom/sides) Salt Fog Mil-Std-810G 24 Hrs. in-24 Hrs out 2 cycles Vibration Vehicle Mil-Std-810G 1 Hr. X 3 axes 10-500 Hx, 1.04 Grms, Shock-Half Sine Mil-Std-810G 10 G / 11 ms, 5 shocks x 6 directions Shock-Drop Mil-Std-810G 26 drops @ 48" HighTemp Storage 24 Hrs. each temp 60C, 65C, 70C, 80C, 85C, 90C & 95C All reliability and performance measurement have been performed by certified, independent laboratories. Full reports are available on request. Environmental Test The 5010 is designed to support either flush or VESA mount. To accommodate both approaches, versions with either flush or studded backplates are supported. With part numbers 60001 and 60002, flush mounting can be accommodated by attaching via screws or bolts through the corner holes in the housing or by using double sided industrial tape on the backpla…

Text truncated - open the document above for the full version.
