YQD-GL200GPS Locator

GPS Locator GL200 User Manual TRACGL200UM001 Revision: 1.01 GL200 User manual TRACGL200UM001- 1 - Document TitleGL200 User manual Version1.01 Date2010-08-03 StatusRelease Document Control IDTRACGL200UM001 General Notes Queclink offers this information as a service to its customers, to support application and engineering efforts that use the products designed by Queclink. The information provided is based upon requirements specifically provided to Queclink by the customers. Queclink has not undertaken any independent search for additional relevant information, including any information that may be in the customer’s possession. Furthermore, system validation of this product designed by Queclink within a larger electronic system remains the responsibility of the customer or the customer’s system integrator. All specifications supplied herein are subject to change. Copyright This document contains proprietary technical information which is the property of Queclink Limited., copying of this document and giving itto others and the using or communication of the contents thereof, are forbidden without express authority. Offenders are liable to the payment of damages. All rights reserved in the event of grant of a patent or the registration of a utility model or design. All specification supplied herein are subject to change without notice at any time. Copyright © Queclink Wireless Solutions Ltd. 2009 GL200 User manual TRACGL200UM001- 2 - Contents Contents............................................................................................................................................. 2 0. Revision history............................................................................................................................. 3 1. Introduction................................................................................................................................... 4 2. Product Overview.......................................................................................................................... 5 2.1. Appearance.......................................................................................................................... 5 2.2. Buttons/Mini USB Interface Description............................................................................ 5 2.3. Two Triple-Color LEDs Description................................................................................... 6 2.4. External Power Interface.....................................................................................................6 2.4.1.External DC Charger Interface.......................................................................... 6 2.4.2.External Battery Interface.................................................................................. 7 2.5. External GPS antenna specification.....................................................................................7 2.6. Ignition Detection................................................................................................................ 8 3. Getting Started............................................................................................................................... 9 3.1. Parts List.............................................................................................................................. 9 3.2. Battery Charging.................................................................................................................. 9 3.3. Install SIM Card................................................................................................................ 10 3.4. Turn on/Turn off................................................................................................................ 10 4. Troubleshooting and Safety info..................................................................................................11 4.1. Troubleshooting................................................................................................................. 11 4.2. Safety info.......................................................................................................................... 11 GL200 User manual TRACGL200UM001- 3 - 0. Revision history RevisionDateAuthorDescription of change 1.012010-08-03 Ella HUANG Initial GL200 User manual TRACGL200UM001-4- 1. Introduction GL200 is a powerful GPS locator which is designed for vehicle, pets and assets tracking. With superior receiving sensitivity, fastTTFF and GSM frequencies850/1900. Its location can be real time or schedule tracked by backend server or specified terminals. Based on the embedded @Track protocol, GL200 can communicate with the backend server through GPRS/GSM network, and transfer reports of emergency, Geo-fencing, device status and scheduled GPS position etc... Service provider is easy to setup their tracking platform based on the functional @Track protocol. This device complies with part 22 and part 24 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference (2) this device must accept any interference, including interference that may cause undesired operation. GL200 User manual TRACGL200UM001-5- 2. Specification GSM/GPS Specifications GPS ChipsetuBlox All-In-One GPS Receiver Sensitive, Fast and Accurate Sensitivity Cold start -147dBm Reacquisition -160dBm Tracking -160dBm Position Accuracy Autonomous: <2.5 m SBAS : 2.0 m TTFF(Open Sky) Cold start 29s Warm start <29s Hot start <1s User Interfaces Mini USB Connector Include external power and UART Power ButtonFor power on and power off. Can be disabled by the air interface protocol. Function ButtonFor SOS alarm or quick setting of Geo-Fence. Gerneral Specifications Dimension67.5mm* 40mm * 21mm Weight60g Backup BatteryLi-Polymer 1300 mAh , 3.7V Standby TImeWithout reporting :300 to 400 Hours 5 minutes reporting :100 to 150 Hours 10 minutes reporting:150 to 200 Hours Charge Voltage5V DC Water Re…

Text truncated - open the document above for the full version.

Attestation letter We hereby declaration that, the model of GPS locator GL200 does not have the potential to be used as a Class B computer peripheral and cannot exchange data with a PC through the USB port. We ensure that the port is only for power and will not be changed later on to provide data connectivity and will never be used to deliver data. Queclink Wireless Solutions Room 501, Building 9, No.99 Tianzhou Road Shanghai, China 200233 Tel: +86-21-51082965 Fax: +86-21-54451990

Internal photos for GL200 Top View GSM antenna position GSM antenna Bottom View

S00012100172 UMK105CG4R7CW-F CAP COG 4.7pF +/- 0.25pF 50V CH0402RO S00012100090 GRM1555C1H4R7BZ01D CAP CM1 4.7pF +/-0.1pF 50V CH0402 R0 2 S00012100022 CC0402JRNPO9BN220 CAP COG 22PF +/-5% 50V CH0402 RO 2 6EA C101 C102 C308 C316 C327C328 C329 C345 C413 C414 C219 C222 C223 C235C436 GRM1555C1H470JZ01DCC0402JRNPO9BN470UMK105CG820JV-FC1005C0G1H820JTCC0402KRX7R9BB102GRM155R71H102kA01D SW0012000065 GRM188R72A102KA01D CAP X7R 1NF 100V +/-10% CH0603 RO SW0012000058 C1608X7R2A102KT CAP X7R 1NF 100V +/-10% CH0603 RO CC0402KRX7R7BB103GRM155R71C103KA01DGRM155R61A104KA01DCC0402KRX5R6BB104CC0402KRX5R7BB104EMK105BJ104KV-FGRM155R60J105KE19DJMK105BJ105KV-FC1608X5R0J225KTJMK107BJ225KA-TGRM219R60J226ME47DJMK212 BJ226MD-T 12 S00012100372 572D107X0010T2T CAP TAN 100UF 10V 3528-1.0+/-0.2ESR=0.5OHM RO 6 EA C315 C215 C216 C232 C233C234 24 CAP X5R 1UF X5R 10% 6.3V CH0402 RO EA 7EA C127 C203 C326 C205 C206C207 EA C226 C213 C214 C217 C238 C330 C402 C404 C112 C121C429 C241 C119C116 C126 C212 C230C239 C240 C106 C115 C118 C120 C122C123 C124 C125 C209 C340C407 C408 C409 C410 C411C412 C415 C416 C417 C418C103 C104 C105 C107 C108C109 C110 C111 C114 C129C130 C131 C204 C208 C211C227 C332 C333 C334 C336C337 C338 C339 C344 C354C419 C320 11 5EA C220 C420 S00012100318 CAP X5R 2.2UF +/-10% 6.3V CH0603 RO 10 8EA S00012100088 8 S00012100298 CAP X5R 100NF +/-10% CH0402 16V RO EA 9 S00012100140 CAP X5R 22UF +/-20% 6.3V CH0805 RO S00012100003 CAP X5R 100NF +/-10% 10V CH0402 RO 33 C229 7 S00012100289 CAP X7R 10NF +/-10% 16V CH0402 RO C201 56 1 S00012100276 CAP X7R 1NF +/-10% 50V CH0402 RO 4 EA C202 C306 C325 C 343 3 CAP COG 47PF +/-5% 50V CH0402 RO S00012100047 4 S00012100264 CAP COG 82PF +/-5% 50V CH0402 RO EA C319 C322 C311 C221 5 EA C405 R323 R335 L308 L309 EA C353 C432 C434 C132 C133C210 C228 C309 C310 C403C431 1 11 3 RC0402JR-070RLMCR01MZPJ000 S00011000205 RC0805JR-070RL RES MF 0R +/-5% 1/8W CH 0805 RO S00011000189 MCR10EZHJ000 RES MF 0R +/-5% 1/4W CH0805 RO MCR01-MZS-J-100RC0402JR-0710RLMCR01-MZS-J-220RC0402JR-0722RLMCR01-MZS-J-820RC0402JR-0782RLMCR01-MZS-J-102RC0402JR-071KLMCR01-MZS-J-202RC0402JR-072KLMCR01-MZS-J-103RC0402JR-0710KLMCR01-MZS-J-473RC0402JR-0747KLMCR01MZPJ513RC0402JR-0751KLMCR01-MZS-J-104RC0402JR-07100KLLQG15HS2N2S02DHK1005 2N2S-T IND HIGH 2.2NH +/-0.3NH CH0402 RO L301 R409 13 EA R303 R404 R307 R308 R412 S00011000112 15 S00011000011 RES MF 10R +/-5% 1/16W CH 0402 RO 14 1EA EA R238 RES MF 0R +/-5% 1/16W CH 0402 RO S00011000094 10 R304 R306 R309 R315 R316R318 L315 R410 RES MF 82R +/-5% 1/16W CH 0402 RO S00011000064 8EA R202 R203 R232 R233 R235R317 R205 R234 2 EA R310 R415 1617 RES MF 22R +/-5% 1/16W CH 0402 RO 8 R101 R102 R305 R313 R402 R214 EA R215 R216 R217 19 S00011000043 RES MF 2KR +/-5% 1/16W CH 0402 RO 10 EA R104 R105 R107 R301 R302R325 R326 R209 R413 R206 S00011000044 EA R110 R111 R223 R224 R330R401 R329 R407 R211 R247 R243 22 RES MF 51KR +/-5% 1/16W CH0402 RO 20 RES MF 10KR +/-5% 1/16W CH 0402 RO 18 RES MF 1KR +/-5% 1/16W CH 0402 RO 6 S00011000025 117 EA R108 R109 R112 R113 R408 R207 R246 S00011000001 RES MF 100KR +/-5% 1/16W CH 0402 RO 23 13 EA R225 R403 R416 R418 R210 R212 R213 R236R241 R242 R231 R237R244 S00014100370 24 6EA L316 L318 L302 L317 L307L313R417 R114 R115 R249 S00011000002S00011000015 21 RES MF 47KR +/-5% 1/16W CH 0402 RO 4 EA LQG15HS8N2J02DMLK1005S8N2DT000 S00014100091 LQW15AN22NG00D IND HIGH 22NH +/-2% CH0402 RO S00014100380 LQG15HS22NJ02 IND HIGH 22NH +/-5% CH0402 RO S00014100016 LQW15AN33NG00D IND HIGH 33NH +/-5% CH0402 RO S00014100382 HK1005 33NJ-T IND HIGH 33NH +/-5% CH0402 RO 28 S00014100043 LQW15AN47NG00D IND HIGH 47NH +/-2% CH0402 RO 1 EA L10 5 29 S00014100222 BLM15BD102SN1 磁珠（0402）1000OHM RO 4 EA FB101 FB201 FB2 FB402 RB520S-30FJTE611PS79SB30 31 SW0015100004 EDZTE613.9B ZENER VZ=3.9V SOD-523 1 EA D201 S00015300029 AOT-0603BL31A-N0-N-3-M DIO BLUE LED CH0603 RO S00015300023 LTST-C193TBKT-5A LED BLUE 5V CH0603 RO S00015100013 DF2S6.8FS（TL3,T) DIO ZENER ESD 1.0*0.6 RO S00013500049 ESD9X5VD-2/TR ESD Protection Diode 5V SOD-923 RO S00013500018 PESD12VS1UB TVS 12V SOD523 RO S00013500046 ESD5Z12T1G ESD TVS 12V SOD-523 240W RO S00013500017 ESDA6V1-5W6(E) 5路单向，ESD保护器 RO S00013500035 ESDA6V1-5W6-6/TR TVS-5 6.1V 100W SOT323-6L RO 36 SW0016100016 1981959-1 SIM card connector 1 EA J201 37 S00016800009 KIU81010S1R USBC KIU81010S1R 10PIN 0.4MM 3.1MMRO 1 EA J202 38 S00016200098 5791003-991R BAT CONNECTOR 5791003-991R RO 1 EA J203 39 S00016400001 LS10N2-T SideKey SWITCH RO 2 EA J204 J205 S00016500002 C90-101-0004 RFC 6PIN 3*3*1.76MM RO S00016200016 MM8430-2610RB3 RFC 3X3X1.75 RO 25 EA L404 L303 L311 IND HIGH 8.2NH +/-5% CH0402 RO EA L401 L405 2 S00014100375 26 3 L402 27 1EA DIODE SCHOTTKY 200MA 30V SOD523 RO D401 D101 D102 D206 D207 D208 30 S00015100030 6EA D202 D203 D204 33 6 EA TVS202 TVS203 TVS204 TVS205 TVS207 TVS401 32 3EA U201 U202 40 1 EA J301 35 2EA TVS201 TVS208 34 2EA S00015200023 DTC143ZETL TRI NPN 100MA 50V EMT3 RO S00015200051 DTC143ZEBTL AUD NPN 100MA 50V EMT3F RO 42 S00015200037 2SK3019TL N-MOS 30V 100mA VTH=0.8~1.5V EMT3 RO 4 EA Q 204 Q205 Q207 Q212 43 SW0015400004 SiA433EDJ-T1-GE3 P-MOS 20V VTH=-0.5~-1.2V PowerPAKSC-70-6L-Sin g le RO 4 EA Q208 Q209 Q210 Q211 44 S00013600163 XC6221A302MR 射频 LDO(电压3V),SOT-23-5 RO 1 EA U402 45 S00013100199 XC6221A282MR PMIC LDO 2.8V SOT23_5PIN RO 1 EA U206 46 SW0013100012 BQ24073RGTT PMIC POWERPATH CHARGER QFN-16PIN RO 1 EA U204 47 S00013100100 MC9S08QG4CFFE IC MICROCONTROLLER 4K MEMORY QFN RO 1 EA U207 48 SW0013000008 MMA7361LR1 IC MOTION SENSOR 1.5G 6G LGA-14 RO 1 EA U2 08 49 S00013700014 MT6223DA/AN-L IC BAS DIG MTK MT6223DA/AN-L TFBGARO 1 EA U101 50 S00013400005 SST34HF3284-70-4E-L1PE IC MERO 32M FLASH+8M SRAM 8MM*10MMRO 1 EA U102 51 S00013600122 AD6548BCPZ-RL RF Transciever IC RO 1 EA U305 52 S00013600217 RF7161 IC TRANSMIT MODULE Q-BAND 6.63*5.24RO 1 EA U301 B39182-B9500-L310SAWEN942MCN0F00SAFEA1G96FA0F00R12SF14-1960M5UB50B39202-B9403-K610SAFEA881MFL0F00R12SF14-0881M5UB50B39881-B9400-K610 56 SW0013600031 AS179-92LF IC RF ASM BROADCOM SC70 RO 1 EA U4…

Text truncated - open the document above for the full version.

Dipole 1900MHz Dipole 850MHz

校准证书编号：2009J10-10-912004 Calibrated certificate series No. 第 2 页 共 22 页 Page of total pages 校准证书续页专用 Continued page of calibration certificate 国家法定计量检定机构计量授权证书号（中心/院）：（国）法计（2007）01039 号/（2007）01019 号 The number of the Certificate of Metrological Authorization to The Legal Metrological Verification Institution is No.（2002）01039 / No.（2002）01019 中国实验室国家认可委员会（CNAL）实验室认可证书号：No.L0134 The number of the certificate accredited by CNAL is No.L0134 本次校准所依据的技术规范（代号、名称）： Reference documents for the calibration (code 、name) JCJ/J101001.1/0-2007 SAR电场探头校准规范 (SAR E-FIELD PROBE calibration criterion) IEC 62209-1：2003 Procedure to measure the Specific Absorption Rate (SAR) in the frequency range of 300 MHz to 3 GHz Part 1: hand-held mobile wireless communication IEEE 1528：2003 IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques 本次校准所使用的主要计量标准器具： Main measurement standards used in this calibration 参见附录一 (Refer to attachment 1) 以上计量标准器具的量值溯源至国家基准。 Quantity values of above measurement standards used in this calibration are traced to those of the national primary standards in the P.R. China. 校准地点及环境条件： Location and environmental condition for the calibration 地点： Location 宜山路716号 (No. 716 Yishan Road, Shanghai) 温度： Ambient temperature 21 °C； 湿度： Relative humidity 50 %RH； 其它： Others / 本次校准结果的扩展不确定度： Expanded uncertainty Antenna factor (Voltage): k=2, U=2U c (E)=0.92dB 校准结果/说明： Results of calibration and additional explanation Pass The requirements of the calibration criterion: Linearity less than 0.25dB Isotropy less than 0.25dB Sensitivity less than the Low limit detection（12mW/Kg） 本证书提供的结果仅对本次被校的器具有效。 The data are valid only for the instrument(s). 校准证书编号：2009J10-10-912004 Calibrated certificate series No. 第 3 页 共 22 页 Page of total pages 校准证书续页专用 Continued page of calibration certificate 校准结果/说明（续页）： Results of calibration and additional explanation（continued page） 1. Production description Frequency Range: 100 MHz - 3 GHz Probe length: 330 mm Length of one dipole: 4.4 mm Maximum external diameter: 8 mm Probe extremity diameter: 6.3 mm Distance between dipoles/probe extremity: < 2.7 mm Resistance of the three dipole (at the connector): Dipole 1: R1=1.181M Dipole 2: R2=1.186M Dipole 3: R3=1.183M Connector (HIROSE series SR30): 6 wire male (Hirose SR30series) 2. Calibration Results 2.1 Calibration Frequency: 835.00MHz BODY 2.1.1 Calibration basic information S/N Calibration 1 Epsilon: 54.50 2 Sigma: 1.00S/m 3 Temperature: 21°C 4 Cable loss: 0.20dB 5 Coupler loss: 19.77dB 6 Waveguide Return Loss: -17.75dB 2.1.2 Calibration parameters 2.1.2.1 Sensitivity (Low limit detection): 0.81V/m（0.66mW/Kg） 校准证书编号：2009J10-10-912004 Calibrated certificate series No. 第 4 页 共 22 页 Page of total pages 校准证书续页专用 Continued page of calibration certificate 校准结果/说明（续页）： Results of calibration and additional explanation（continued page） 2.1.2.2 Linearity: 0.04dB Calibration curves of Probe: Calibration curves ei=f(V) (i=1,2,3) allow to obtain E-field value using the formula: E=(e1*e1+e2*e2+e3*e3)pow(1/2) Remark: Dipole 1: calibration curves of the dipole 1; Dipole 2: calibration curves of the dipole 2; Dipole 3: calibration curves of the dipole 3 校准证书编号：2009J10-10-912004 Calibrated certificate series No. 第 5 页 共 22 页 Page of total pages 校准证书续页专用 Continued page of calibration certificate 校准结果/说明（续页）： Results of calibration and additional explanation（continued page） Calibration data of probe Factor v 1 (V) e 1 （V/m） v 2 (V) e 2 （V/m） v 3 (V) e 3 （V/m） 0.736397 416.278843 0.755159 419.744116 0.791775 415.708791 0.587520 337.358527 0.605268 341.452638 0.638480 339.858135 0.476409 278.378344 0.490802 281.589452 0.518454 280.403248 0.378406 226.251419 0.394181 230.967220 0.412711 227.935923 0.303133 186.093545 0.313865 188.771824 0.332361 187.968897 0.244274 154.561105 0.250836 155.525019 0.268297 155.992470 0.196185 128.647987 0.203919 130.643241 0.216363 129.944620 0.156181 106.911595 0.161882 108.178946 0.174679 108.896938 0.124762 89.643300 0.129403 90.634435 0.140821 91.644337 0.099806 75.716752 0.103885 76.653196 0.111779 76.655442 0.064716 55.629510 0.066425 55.629510 0.071887 55.629510 0.058448 51.797075 0.060057 51.856743 0.065085 51.856743 0.051319 47.512211 0.052782 47.512211 0.057306 47.512211 0.043597 42.687944 0.044882 42.687944 0.048852 42.687944 0.036561 38.133375 0.037672 38.133375 0.041138 38.133375 0.030305 33.986405 0.031281 33.986405 0.034202 33.947300 0.024945 30.220749 0.025776 30.220749 0.028280 30.220749 0.020386 26.841404 0.021102 26.872324 0.023187 26.841404 0.016549 23.839944 0.017154 23.839944 0.018875 23.839944 0.013405 21.198505 0.013911 21.198505 0.015378 21.198505 0.010806 18.849734 0.011226 18.849734 0.012436 18.849734 0.008677 16.741919 0.009020 16.761205 0.010013 16.761205 0.006944 14.886933 0.007214 14.904082 0.008027 14.886933 0.005548 13.252727 0.005779 13.267993 0.006399 13.267993 0.004421 11.797914 0.004623 11.811505 0.005116 11.811505 0.003491 10.514902 0.003661 10.514902 0.004086 10.514902 0.002779 9.339774 0.002902 9.360633 0.003249 9.343200 0.002194 8.333901 0.002279 8.297689 0.002540 8.292290 0.001745 7.470562 0.001825 7.459682 0.002058 7.494168 0.001353 6.625471 0.001432 6.649532 0.001566 6.580398 0.001061 5.918051 0.001133 5.959843 0.001272 5.967953 0.000825 5.277457 0.000847 5.215486 0.000973 5.272626 0.000620 4.649929 0.000685 4.742304 0.000796 4.813916 0.000480 4.167421 0.000522 4.212899 0.000579 4.183466 0.000380 3.785302 0.000383 3.702113 0.000421 3.656673 0.000281 3.364523 0.000283 3.285894 0.000363 3.443129 0.000195 2.950691 0.000221 2.998967 0.000242 2.948251 0.000124 2.559095 0.000143 2.593287 0.000145 2.481249 校准证书编号：2009J10-10-912004 Calibrated certificate series No. 第 6 页 共 22 页 Page of total pages 校准证书续页专用 Continued page of calibration certificate 校准结果/说明（续页）： Results of calibration and additional explanation（continued page） v 1 (V) e 1 （V/m） v 2 (V) e 2 （…

Text truncated - open the document above for the full version.

校准证书编号：2009J10-10-912007 Calibrated certificate series No. 第 2 页 共 22 页 Page of total pages 校准证书续页专用 Continued page of calibration certificate 国家法定计量检定机构计量授权证书号（中心/院）：（国）法计（2007）01039 号/（2007）01019 号 The number of the Certificate of Metrological Authorization to The Legal Metrological Verification Institution is No.（2002）01039 / No.（2002）01019 中国实验室国家认可委员会（CNAL）实验室认可证书号：No.L0134 The number of the certificate accredited by CNAL is No.L0134 本次校准所依据的技术规范（代号、名称）： Reference documents for the calibration (code 、name) JCJ/J101001.1/0-2007 SAR电场探头校准规范 (SAR E-FIELD PROBE calibration criterion) IEC 62209-1：2003 Procedure to measure the Specific Absorption Rate (SAR) in the frequency range of 300 MHz to 3 GHz Part 1: hand-held mobile wireless communication IEEE 1528：2003 IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques 本次校准所使用的主要计量标准器具： Main measurement standards used in this calibration 参见附录一 (Refer to attachment 1) 以上计量标准器具的量值溯源至国家基准。 Quantity values of above measurement standards used in this calibration are traced to those of the national primary standards in the P.R. China. 校准地点及环境条件： Location and environmental condition for the calibration 地点： Location 宜山路716号 (No. 716 Yishan Road, Shanghai) 温度： Ambient temperature 21 °C； 湿度： Relative humidity 50 %RH； 其它： Others / 本次校准结果的扩展不确定度： Expanded uncertainty Antenna factor (Voltage): k=2, U=2U c (E)=0.92dB 校准结果/说明： Results of calibration and additional explanation Pass The requirements of the calibration criterion: Linearity less than 0.25dB Isotropy less than 0.25dB Sensitivity less than the Low limit detection（12mW/Kg） 本证书提供的结果仅对本次被校的器具有效。 The data are valid only for the instrument(s). 校准证书编号：2009J10-10-912007 Calibrated certificate series No. 第 3 页 共 22 页 Page of total pages 校准证书续页专用 Continued page of calibration certificate 校准结果/说明（续页）： Results of calibration and additional explanation（continued page） 1. Production description Frequency Range: 100 MHz - 3 GHz Probe length: 330 mm Length of one dipole: 4.4 mm Maximum external diameter: 8 mm Probe extremity diameter: 6.3 mm Distance between dipoles/probe extremity: < 2.7 mm Resistance of the three dipole (at the connector): Dipole 1: R1=1.181M Dipole 2: R2=1.186M Dipole 3: R3=1.183M Connector (HIROSE series SR30): 6 wire male (Hirose SR30series) 2. Calibration Results 2.1 Calibration Frequency: 1880.00MHz BODY 2.1.1 Calibration basic information S/N Calibration 1 Epsilon: 54.37 2 Sigma: 1.57S/m 3 Temperature: 21°C 4 Cable loss: 0.30dB 5 Coupler loss: 19.46dB 6 Waveguide Return Loss: -19.46dB 2.1.2 Calibration parameters 2.1.2.1 Sensitivity (Low limit detection): 0.83V/m（1.07mW/Kg） 校准证书编号：2009J10-10-912007 Calibrated certificate series No. 第 4 页 共 22 页 Page of total pages 校准证书续页专用 Continued page of calibration certificate 校准结果/说明（续页）： Results of calibration and additional explanation（continued page） 2.1.2.2 Linearity: 0.05dB Calibration curves of Probe: Calibration curves ei=f(V) (i=1,2,3) allow to obtain E-field value using the formula: E=(e1*e1+e2*e2+e3*e3)pow(1/2) Remark: Dipole 1: calibration curves of the dipole 1; Dipole 2: calibration curves of the dipole 2; Dipole 3: calibration curves of the dipole 3 校准证书编号：2009J10-10-912007 Calibrated certificate series No. 第 5 页 共 22 页 Page of total pages 校准证书续页专用 Continued page of calibration certificate 校准结果/说明（续页）： Results of calibration and additional explanation（continued page） Calibration data of probe Factor v 1 (V) e 1 （V/m） v 2 (V) e 2 （V/m） v 3 (V) e 3 （V/m） 0.690048 426.988679 0.583670 356.639131 0.719914 426.861135 0.556062 349.591675 0.474500 294.959194 0.581147 349.747459 0.446593 286.259916 0.376683 239.583518 0.468655 287.150584 0.355528 233.453203 0.301109 196.671627 0.378364 236.809953 0.284007 191.838840 0.241730 162.813199 0.305027 195.806732 0.227197 158.623536 0.194542 135.748328 0.242120 160.488211 0.182009 132.025076 0.154565 112.627880 0.194900 133.819295 0.147319 111.420605 0.124479 95.030624 0.155712 111.506761 0.119718 94.835012 0.099940 80.465628 0.125532 94.133523 0.096119 80.432830 0.064298 58.726747 0.101802 80.280275 0.061903 58.929933 0.057200 54.179619 0.066004 58.794398 0.054869 54.304515 0.050442 49.812226 0.058645 54.242031 0.048300 49.869607 0.043541 45.220561 0.051746 49.869607 0.041647 45.324805 0.036869 40.675785 0.044708 45.272653 0.035238 40.769553 0.030770 36.377759 0.037941 40.722642 0.029389 36.461619 0.025468 32.421712 0.031689 36.419665 0.024284 32.533886 0.020865 28.829423 0.026234 32.496452 0.019838 28.929168 0.016976 25.635155 0.021516 28.895881 0.016137 25.723849 0.013795 22.821067 0.017532 25.664686 0.013073 22.900024 0.011160 20.292518 0.014229 22.847356 0.010570 20.362727 0.008998 18.064916 0.011518 20.339297 0.008500 18.127418 0.007221 16.081848 0.009288 18.106560 0.006795 16.137489 0.005725 14.250691 0.007471 16.118920 0.005387 14.299997 0.004565 12.715573 0.005934 14.283543 0.004290 12.744886 0.003629 11.319727 0.004743 12.730221 0.003407 11.358892 0.002888 10.088717 0.003773 11.332767 0.002703 10.094430 0.002281 8.988795 0.003001 10.094150 0.002128 8.998130 0.001795 8.013492 0.002361 8.997520 0.001697 8.079423 0.001403 7.130286 0.001864 8.043436 0.001333 7.212956 0.001115 6.404247 0.001459 7.172725 0.001043 6.439732 0.000866 5.702497 0.001150 6.429586 0.000802 5.718152 0.000667 5.072334 0.000882 5.707225 0.000614 5.084652 0.000502 4.483163 0.000665 5.047141 0.000464 4.515903 0.000378 3.983448 0.000508 4.509729 0.000347 4.016758 0.000287 3.572524 0.000397 4.087356 0.000260 3.601023 0.000212 3.194357 0.000285 3.611453 0.000194 3.250359 0.000154 2.867918 0.000207 3.238974 0.000134 2.894946 0.000104 2.553223 0.000131 2.829266 校准证书编号：2009J10-10-912007 Calibrated certificate series No. 第 6 页 共 22 页 Page of total pages 校准证书续页专用 Continued page of calibration certificate 校准结果/说明（续页）： Results of calibration and additional explanation（continued page） v 1 (V) e 1 （V/m） v 2 (V) e 2…

Text truncated - open the document above for the full version.

检测报告编号：2010J10-30-108056 Test report series No. 检测报告续页专用 第 1 页 共 50 页 Continued page of test report Page of total pages TEST REPORT 上海市计量测试技术研究院 华东国家计量测试中心 中国上海测试中心 检 测 报 告 Queclink Wireless Solutions Co., Ltd 委 托 者 Customer Room 501, Building 9, No.99 TianZhou Road, Shanghai, China 委托者地址 Address of customer GPS Locator 样品名称 Name of sample Queclink Wireless Solutions Co., Ltd 制造厂 Manufacturer GL200 型号/规格 Model/Specification 359464036000110 样品编号 No. of sample 批准人/ 职务 Approved by / Functions 核验员 Checked by 检测员 Tested by 检测日期 2010 年 10 月 10 日 Date for test Year Month Day 投诉电话：021-50798262 地址：上海市张衡路1500号(总部) 电话：021-38839800 传真：021-50798390 邮编： 201203 Tel. For complaint Address No.1500 Zhangheng Road，Shanghai(headquarters) Tel. Fax. Post Code 上海市宜山路716号(分部) 电话：021-64701390 传真：021-64701810 邮编： 200233 No. 716 Yishan Road，Shanghai(branch) Tel. Fax. Post Code 未经本院批准，部分采用本报告内容无效。 Partly using this report will not be admitted unless allowed by SIMT. (机构检测专用章) 检测报告编号：2010J10-30-108056 Test report series No. 检测报告续页专用 第 2 页 共 50 页 Continued page of test report Page of total pages 国家法定计量检定机构计量授权证书号（中心/院）：（国）法计（2007）01039号/（2007）01019号 The number of the Certificate of Metrological Authorization to The Legal Metrological Verification Institution is No.（2007）01039 / No.（2007）01019 中国合格评定国家认可委员会实验室认可证书号：No. CNAS L0134 The number of the certificate accredited by CNAS is No.L0134 中国国家认证认可监督管理委员会资质认定计量认证证书（CMA）号：2009000597E The number of the metrology accreditation certificate by CNCA is No. 2009000597E 本次检测所依据的技术规范（代号、名称）： Reference documents for the test (code 、name) IEEE 1528: 2003 IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques FCC OET Bulletin 65 Supplement C: 2001 Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields 本次检测所使用的主要测量仪器： Main measuring instruments used in this test Refer to Attachment 1 检测地点及环境条件： Location and environmental condition for the test 地点： Location No. 716 Yishan Road 温度： Ambient temperature (23-24) °C； 湿度： Relative humidity 52 %RH； 其它： Others / 检测结果/说明： Results of test and additional explanation The testing results are in compliance with IEEE 1528: 2003, FCC OET Bulletin 65 Supplement C: 2001 (see the continued pages) (Test date: 2010.08.30-2010.10.10) (Date of report: 2010.10.11) 本报告提供的结果仅对本次被测的样品有效。 The data are valid only for the sample(s). 检测报告编号：2010J10-30-108056 Test report series No. 检测报告续页专用 第 3 页 共 50 页 Continued page of test report Page of total pages 检测结果/说明（续页）： Results of test and additional explanation（continued page） 1. Specific Absorption Rate Test 1.1 EUT Description Product Name GPS Locator Model No. GL200 FCC ID YQD-GL200 Antenna Type Soldered on PCB GPRS Class 12 GPRS Timeslots of Test 4 up 1 down Modulation Mode GMSK Tx Frequency range 824.2 MHz~848.8 MHz 1850.2 MHz ~1909.8 MHz Rx Frequency range 869.2 MHz~893.8 MHz 1930.2 MHz~1989.8 MHz Maximum RF Conducted Power GSM 850+GPRS: 31.58dBm PCS 1900+GPRS: 25.70dBm 1.2 Test Environment during SAR test Temperature Min. =19°C, Max. =23°C Relative humidity Min. =30%, Max. =70% Ground system resistance <0.5Ω Ambient noise is checked and found very low and in compliance with requirement of standards. Reflection of surrounding objects is minimized and in compliance with requirement of standards. 检测报告编号：2010J10-30-108056 Test report series No. 检测报告续页专用 第 4 页 共 50 页 Continued page of test report Page of total pages 检测结果/说明（续页）： Results of test and additional explanation（continued page） 1.3 Tissue Simulating Liquid 1.3.1 The composition of the tissue simulating liquid The parameters of the simulating solution strongly influence the SAR values. The different normalization organizations have defined adapted solutions for the each mobile system. GSM liquid is made of 1-2 Propylene Glycol, de-ionized water and NaCl, reconstituting the electric properties of human tissues at 850 MHz/900 MHz; DCS/PCS Liquid is made of de-ionized water, DGBE, Triton X 100 and NaCl, reconstituting the electric properties of human tissues at 1800 MHz/1900 MHz; UMTS Liquid is made of de-ionized water, DGBE, Triton X 100 and NaCl, reconstituting the electric properties of human tissues at 2000 MHz; Bluetooth Liquid is made of de-ionized water, DGBE, Triton X 100 and NaCl, reconstituting the electric properties of human tissues at 2450 MHz; 1.3.2 Tissue Calibration Result The dielectric parameters of the liquids were verified prior to the SAR evaluation using the Calibration Kits and R&S® ZVB8 Vector Network Analyzers. Body Tissue simulating Measurement Dielectric Parameters Frequency [MHz] Description εr σ (S/m) Tissue Temp.(°C) Reference result +/-5% 55.20 0.97 N/A 836 MHz 2010-08-30 55.15 0.98 21.5 Reference result +/-5% 53.30 1.52 N/A 1900 MHz 2010-09-30 55.55 1.50 21.0 检测报告编号：2010J10-30-108056 Test report series No. 检测报告续页专用 第 5 页 共 50 页 Continued page of test report Page of total pages 检测结果/说明（续页）： Results of test and additional explanation（continued page） 1.4 SAR Measurement System This SAR Measurement System uses a Computer-controlled 3-D stepper motor system (SAR Handset Assessment Systems from Antennessa). An E-field probe is used to determine the internal electric fields. The SAR can be obtained from the equation SAR=σ (|Ei|2)/ ρ where σ and ρ are the conductivity and mass density of th…

Text truncated - open the document above for the full version.
