YQD-GL500GPS Locator

GV300 User manual GSM/GPRS/GPS Tracker GL500 User Manual TRACGL500UM001 Revisio n: 1.00 http://www.queclink.com [email protected] TRACGV3SUM001 - 1 - GL500 User manual TRACGL500UM001 - 2 - Document Title GL500 User Manual Version 1.00 Date 2012-6-11 Status Release Document Control ID TRACGL500UM001 General Notes Queclink offers this information as a service to its customers, to support application and engineering efforts that use the products designed by Queclink. The information provided is based upon requirements specifically provided to Queclink by the customers. Queclink has not undertaken any independent search for additional relevant information, including any information that may be in the customer’s possession. Furthermore, system validation of this product designed by Queclink within a larger electronic system remains the responsibility of the customer or the customer’s system integrator. All specifications supplied herein are subject to change. Copyright This document contains proprietary technical information which is the property of Queclink Limited., copying of this document and giving it to others and the using or communication of the contents thereof, are forbidden without express authority. Offenders are liable to the payment of damages. All rights reserved in the event of grant of a patent or the registration of a utility model or design. All specification supplied herein are subject to change without notice at any time. Copyright © Shanghai Queclink Wireless Solutions Co., Ltd. 2011 GL500 User manual TRACGL500UM001 - 3 - Contents 1 Introduction....................................................................................................................................7 1.1. Reference................................................................................................................................. 7 1.2. Terms and Abbreviations..........................................................................................................7 2 Product Overview..........................................................................................................................8 2.1. Check Parts List.......................................................................................................................8 2.2. Parts List.................................................................................................................................. 9 2.3. Interface Definition..................................................................................................................9 3 Getting Started............................................................................................................................. 11 3.1. Opening the Case................................................................................................................... 11 3.2. Closing the Case..................................................................................................................... 11 3.3. Installing a SIM Card............................................................................................................. 11 3.4. Installing the Internal Backup Battery...................................................................................12 3.5. Power On the Device.............................................................................................................13 3.6. Device Status LED.................................................................................................................14 GL500 User manual TRACGL500UM001 - 4 - Table Index TA B L E 1 . GL500 PROTOCOL REFERENCE................................................................................ 7 TA B L E 2 . TERMS AND ABBREVIATIONS.................................................................................. 7 TA B L E 3 . PARTS LIST.................................................................................................................... 9 TA B L E 4 . DESCRIPTION OF 8 PIN CONNECTIONS................................................................ 10 TA B L E 5 . DEFINITION OF DEVICE STATUS AND LED......................................................... 14 GL500 User manual TRACGL500UM001 - 5 - Figure Index FIGURE 1. APPEARANCE OF GL500............................................................................................. 8 FIGURE 2. THE 8 PIN CONNECTOR ON THE GL500................................................................ 10 FIGURE 3. OPENING THE CASE.................................................................................................. 11 FIGURE 4. CLOSING THE CASE.................................................................................................. 11 FIGURE 5. SIM CARD INSTALLATION....................................................................................... 12 FIGURE 6. BACKUP BATTERY INSTALLATION....................................................................... 12 FIGURE 7. GL500 STATUS LED.................................................................................................... 13 GL500 User manual TRACGL500UM001 - 6 - Revision History Revision Date Author Description of change 1.00 2012-6-11 Cid Xu Initial GL500 User manual 1 Introduction GL500 is a powerful GPS tracker designed for fixed asset tracking applications.GL500 work with two CR123A lithium-batterys.GL500 wakes up every 1-40hours and sends the info and then return to deepsleep.GL500 can standby 1000days. With built-in motion sensor, GL500 can also detect the motion of asset all the time and give a warning message. Based integrated @track protocol, the GL500 can communicate with a backend server through the GPRS/GSM network to transfer reports of emergency, geo-fence boundary crossings, low battery or scheduled GPS position along with many other useful functions. System Integrators can easily setup their tracking systems based on the full-featured @Track protocol. This device complies with par…

Text truncated - open the document above for the full version.

775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Queclink Wireless Solutions Co., Ltd ________________________________________________________________________ 2013.03.28 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: YQD-GL500 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description - Tune up Procedure - Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature ： Client’s name / title： Wei Peng/ Manager Address ：Room 501, Building 9, No 99 ,TianZhou Road ,Shanghai ,China Tel: +86 21 51082965 Extension: 805 E-mail: [email protected]

Title: RF Test Report for GPS Tracker Main Model: GL500 Serial Model: GL505 To: FCC Part 22(H) & FCC Part 24(E): 2012 Report No: 13050158-FCC-R1 Issue Date: March 25, 2013 Page: 35 of 46 www.siemic.com.cn Annex B. EUT AND TEST SETUP PHOTOGRAPHS Annex B.i. Photograph 1: EUT External Photo EUT - Front View EUT - Rear View Title: RF Test Report for GPS Tracker Main Model: GL500 Serial Model: GL505 To: FCC Part 22(H) & FCC Part 24(E): 2012 Report No: 13050158-FCC-R1 Issue Date: March 25, 2013 Page: 36 of 46 www.siemic.com.cn EUT - Top View EUT - Bottom View Title: RF Test Report for GPS Tracker Main Model: GL500 Serial Model: GL505 To: FCC Part 22(H) & FCC Part 24(E): 2012 Report No: 13050158-FCC-R1 Issue Date: March 25, 2013 Page: 37 of 46 www.siemic.com.cn EUT - Left View EUT - Right View

label location label location

Title: RF Test Report for GPS Tracker Main Model: GL500 Serial Model: GL505 To: FCC Part 22(H) & FCC Part 24(E): 2012 Report No: 13050158-FCC-R1 Issue Date: March 25, 2013 Page: 38 of 46 www.siemic.com.cn Annex B.ii. Photograph 2: EUT Internal Photo Cover Off - Top View1 Cover Off - Top View2 Title: RF Test Report for GPS Tracker Main Model: GL500 Serial Model: GL505 To: FCC Part 22(H) & FCC Part 24(E): 2012 Report No: 13050158-FCC-R1 Issue Date: March 25, 2013 Page: 39 of 46 www.siemic.com.cn EUT – Main PCB Board Front View EUT – Main PCB Board Rear View GPS Antenna Title: RF Test Report for GPS Tracker Main Model: GL500 Serial Model: GL505 To: FCC Part 22(H) & FCC Part 24(E): 2012 Report No: 13050158-FCC-R1 Issue Date: March 25, 2013 Page: 40 of 46 www.siemic.com.cn GSM Antenna – Front View GSM Antenna

Queclink Wireless Solutions Co., Ltd GPS Tracker Main Model: GL500 Serial Model: GL505 March 27, 2013 Report No.: 13020158-FCC-H1 (This report supersedes NONE) Modifications made to the product : None This Test Report is Issued Under the Authority of: William Long Compliance Engineer Alex Liu Technical Manager This test report may be reproduced in full only. Test result presented in this test report is applicable to the representative sample only. Title: RF Exposure Evaluation Report for GPS Tracker Main Model: GL500 Serial Model: GL505 To: FCC 2.1091: 2012 Report No: 13020158-FCC-H1 Issue Date: March 27, 2013 Page: 2 of 9 www.siemic.com.cn Laboratory Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/Region Accreditation Body Scope USA FCC, A2LA EMC , RF/Wireless , Telecom Canada IC, A2LA, NIST EMC, RF/Wireless , Telecom Taiwan BSMI , NCC , NIST EMC, RF, Telecom , Safety Hong Kong OFTA , NIST RF/Wireless ,Telecom Australia NATA, NIST EMC, RF, Telecom , Safety Korea KCC/RRA, NIST EMI, EMS, RF , Telecom, Safety Japan VCCI, JATE, TELEC, RFTEMI, RF/Wireless, Telecom Mexico NOM, COFETEL, Caniety Safety, EMC , RF/Wireless, Telecom Europe A2LA, NIST EMC, RF, Telecom , Safety Accreditations for Product Certifications Country/Region Accreditation Body Scope USA FCC TCB, NIST EMC , RF , Telecom Canada IC FCB , NIST EMC , RF , Telecom Singapore iDA, NIST EMC , RF , Telecom EU NB EMC & R&TTE Directive Japan MIC, (RCB 208) RF , Telecom Hong Kong OFTA (US002) RF , Telecom Title: RF Exposure Evaluation Report for GPS Tracker Main Model: GL500 Serial Model: GL505 To: FCC 2.1091: 2012 Report No: 13020158-FCC-H1 Issue Date: March 27, 2013 Page: 3 of 9 www.siemic.com.cn This page has been left blank intentionally. Title: RF Exposure Evaluation Report for GPS Tracker Main Model: GL500 Serial Model: GL505 To: FCC 2.1091: 2012 Report No: 13020158-FCC-H1 Issue Date: March 27, 2013 Page: 4 of 9 www.siemic.com.cn CONTENTS 1. EXECUTIVE SUMMARY & EUT INFORMATION ........................................................................................... 5 2. TECHNICAL DETAILS .......................................................................................................................................... 6 3. MAXIMUM PERMISSIBLE EXPOSURE (MPE) .................................................................................................. 7 FCC §2.1091 - MAXIMUM PERMISSIBLE EXPOSURE (MPE) ................................................................................... 7 Title: RF Exposure Evaluation Report for GPS Tracker Main Model: GL500 Serial Model: GL505 To: FCC 2.1091: 2012 Report No: 13020158-FCC-H1 Issue Date: March 27, 2013 Page: 5 of 9 www.siemic.com.cn 1. EXECUTIVE SUMMARY & EUT INFORMATION The purpose of this test programme was to demonstrate compliance of the Queclink Wireless Solutions Co., Ltd, GPS Tracker and model: GL500 against the current Stipulated Standards. The GPS Tracker has demonstrated compliance with the FCC 2.1091: 2012. EUT Information EUT Description : GPS Tracker Main Model : GL500 Serial Model GL505 Antenna Gain : GSM850: 1.52 dBi PCS1900: 2.67 dBi GPS: 2.46 dBi Input Power : 2*3V battery Maximum Conducted Peak Power to Antenna : GSM850: 32.33 dBm PCS1900: 30.33 dBm Classification Per Stipulated Test Standard : FCC 2.1091: 2012 Title: RF Exposure Evaluation Report for GPS Tracker Main Model: GL500 Serial Model: GL505 To: FCC 2.1091: 2012 Report No: 13020158-FCC-H1 Issue Date: March 27, 2013 Page: 6 of 9 www.siemic.com.cn 2. TECHNICAL DETAILS Purpose Compliance testing of GPS Tracker with stipulated standard Applicant / Client Queclink Wireless Solutions Co., Ltd Room 501, Building 9, No 99 ,TianZhou Road ,Shanghai ,China Manufacturer Queclink Wireless Solutions Co., Ltd Room 501, Building 9, No 99 ,TianZhou Road ,Shanghai ,China Laboratory performing the tests SIEMIC Nanjing (China) Laboratories NO.2-1,Longcang Dadao, Yuhua Economic Development Zone, Nanjing, China Tel:+86(25)86730128/86730129 Fax:+86(25)86730127 Email:[email protected] Test report reference number 13020158-FCC-H1 Date EUT received March 07, 2013 Standard applied FCC 2.1091: 2012 Dates of test March 19, 2013 No of Units #1 Equipment Category PCT Trade Name Queclink RF Operating Frequency (ies) GSM850 TX : 824.2 ~ 848.8 MHz; RX : 869.2 ~ 893.8 MHz PCS1900 TX : 1850.2 ~ 1909.8 MHz; RX : 1930.2 ~ 1989.8 MHz GPS:1575.42MHz(Rx) Number of Channels 299CH (PCS1900) and 124CH (GSM850) Modulation GSM/GPRS: GMSK FCC ID YQD-GL500 Title: RF Exposure Evaluation Report for GPS Tracker Main Model: GL500 Serial Model: GL505 To: FCC 2.1091: 2012 Report No: 13020158-FCC-H1 Issue Date: March 27, 2013 Page: 7 of 9 www.siemic.com.cn 3. MAXIMUM PERMISSIBLE EXPOSURE (MPE) FCC §2.1091 - MAXIMUM PERMISSIBLE EXPOSURE (MPE) Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. Limits for General Population/Uncontrolled Exposure Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Averaging Time (minutes) 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f2) 30 …

Text truncated - open the document above for the full version.

Queclink Wireless Solutions Co., Ltd GPS Tracker Main Model: GL500 Serial Model: GL505 March 25, 2013 Report No.: 13050158-FCC-R1 (This report supersedes NONE) Modifications made to the product : None This Test Report is Issued Under the Authority of: William Long Compliance Engineer Alex Liu Technical Manager This test report may be reproduced in full only. Test result presented in this test report is applicable to the representative sample only. Title: RF Test Report for GPS Tracker Main Model: GL500 Serial Model: GL505 To: FCC Part 22(H) & FCC Part 24(E): 2012 Report No: 13050158-FCC-R1 Issue Date: March 25, 2013 Page: 2 of 46 www.siemic.com.cn Laboratory Introduction SIEMIC, headquartered in the heart of Silicon Valley, with superior facilities in US and Asia, is one of the leading independent testing and certification facilities providing customers with one-stop shop services for Compliance Testing and Global Certifications. In addition to testing and certification, SIEMIC provides initial design reviews and compliance management through out a project. Our extensive experience with China, Asia Pacific, North America, European, and international compliance requirements, assures the fastest, most cost effective way to attain regulatory compliance for the global markets. Accreditations for Conformity Assessment Country/Region Accreditation Body Scope USA FCC, A2LA EMC , RF/Wireless , Telecom Canada IC, A2LA, NIST EMC, RF/Wireless , Telecom Taiwan BSMI , NCC , NIST EMC, RF, Telecom , Safety Hong Kong OFTA , NIST RF/Wireless ,Telecom Australia NATA, NIST EMC, RF, Telecom , Safety Korea KCC/RRA, NIST EMI, EMS, RF , Telecom, Safety Japan VCCI, JATE, TELEC, RFTEMI, RF/Wireless, Telecom Mexico NOM, COFETEL, Caniety Safety, EMC , RF/Wireless, Telecom Europe A2LA, NIST EMC, RF, Telecom , Safety Accreditations for Product Certifications Country/Region Accreditation Body Scope USA FCC TCB, NIST EMC , RF , Telecom Canada IC FCB , NIST EMC , RF , Telecom Singapore iDA, NIST EMC , RF , Telecom EU NB EMC & R&TTE Directive Japan MIC, (RCB 208) RF , Telecom Hong Kong OFTA (US002) RF , Telecom Title: RF Test Report for GPS Tracker Main Model: GL500 Serial Model: GL505 To: FCC Part 22(H) & FCC Part 24(E): 2012 Report No: 13050158-FCC-R1 Issue Date: March 25, 2013 Page: 3 of 46 www.siemic.com.cn This page has been left blank intentionally. Title: RF Test Report for GPS Tracker Main Model: GL500 Serial Model: GL505 To: FCC Part 22(H) & FCC Part 24(E): 2012 Report No: 13050158-FCC-R1 Issue Date: March 25, 2013 Page: 4 of 46 www.siemic.com.cn CONTENTS 1. EXECUTIVE SUMMARY & EUT INFORMATION ........................................................................................... 5 2. TECHNICAL DETAILS .......................................................................................................................................... 6 3. MODIFICATION ..................................................................................................................................................... 7 4. TEST SUMMARY .................................................................................................................................................... 8 5. MEASUREMENTS, EXAMINATION AND DERIVED RESULTS ................................................................... 9 ANNEX A. TEST INSTRUMENT & METHOD ........................................................................................................ 32 ANNEX B. EUT AND TEST SETUP PHOTOGRAPHS ........................................................................................... 35 ANNEX C. TEST SETUP AND SUPPORTING EQUIPMENT ................................................................................ 42 ANNEX D. USER MANUAL / BLOCK DIAGRAM / SCHEMATICS / PART LIST ............................................ 45 ANNEX E. DECLARATION OF SIMILARITY ........................................................................................................ 46 Title: RF Test Report for GPS Tracker Main Model: GL500 Serial Model: GL505 To: FCC Part 22(H) & FCC Part 24(E): 2012 Report No: 13050158-FCC-R1 Issue Date: March 25, 2013 Page: 5 of 46 www.siemic.com.cn 1. EXECUTIVE SUMMARY & EUT INFORMATION The purpose of this test programmed was to demonstrate compliance of the Queclink Wireless Solutions Co., Ltd, GPS Tracker and model: GL500 against the current Stipulated Standards. The GPS Tracker has demonstrated compliance with the FCC Part 22(H) & FCC Part 24(E): 2012. EUT Information EUT Description : GPS Tracker Main Model : GL500 Serial Model : GL505 Antenna Gain : GSM850: 1.52 dBi PCS1900: 2.67 dBi GPS: 2.46 dBi Input Power : 2*3V battery Maximum Conducted Peak Power to Antenna : GSM850: 32.33 dBm PCS1900: 30.33 dBm Maximum Radiated ERP/EIRP : GSM850: 30.55 dBm / ERP PCS1900: 27.91 dBm / EIRP Classification Per Stipulated Test Standard : FCC Part 22(H) & FCC Part 24(E): 2012 Note: the GL500 and GL505 models are identical in interior structure, electrical circuits and components, and just model names are different. Title: RF Test Report for GPS Tracker Main Model: GL500 Serial Model: GL505 To: FCC Part 22(H) & FCC Part 24(E): 2012 Report No: 13050158-FCC-R1 Issue Date: March 25, 2013 Page: 6 of 46 www.siemic.com.cn 2. TECHNICAL DETAILS Purpose Compliance testing of GPS Tracker with stipulated standard Applicant / Client Queclink Wireless Solutions Co., Ltd Room 501, Building 9, No 99 ,TianZhou Road ,Shanghai ,China Manufacturer Queclink Wireless Solutions Co., Ltd Room 501, Building 9, No 99 ,TianZhou Road ,Shanghai ,China Laboratory performing the tests SIEMIC Nanjing (China) Laboratories NO.2-1,Longcang Dadao, Yuhua Economic Development Zone, Nanjing, China Tel:+86(25)86730128/86730129 Fax:+86(25)86730127 Email:[email protected] Test report reference number 13050158-FCC-R1 Date EUT received March 07, 2013 Standard applied FCC Part 22(H) & FCC Part 24(E): 2012 Dates of test March 19, 2013 No of Units #1 Equipment Category PCT Trade Nam…

Text truncated - open the document above for the full version.

Title: RF Test Report for GPS Tracker Main Model: GL500 Serial Model: GL505 To: FCC Part 22(H) & FCC Part 24(E): 2012 Report No: 13050158-FCC-R1 Issue Date: March 25, 2013 Page: 41 of 46 www.siemic.com.cn Annex B.iii. Photograph 3: Test Setup Photo Radiated Spurious Emissions Test Setup Below 1GHz - Front View Radiated Spurious Emissions Test Setup Above 1GHz –Front View
