YQD-GV55VCGPS Locator

GV55VC User manual TRACGV3SUM001 1 - - CDMA2000-1X/GPS Tracker GV55VC User Manual TRACGV55VCUM001 Revision: 1.00 http://www.queclink.com [email protected] TRACGV55VCUM001 - 2 - GV55VC User manual Document Title GV55VC User Manual Version 1.00 Date 2014-10-30 Status Release Document Control ID TRACGV55VCUM001 General Notes Queclink offers this information as a service to its customers, to support application and engineering efforts that use the products designed by Queclink. The information provided is based upon requirements specifically provided to Queclink by the customers. Queclink has not undertaken any independent search for additional relevant information, including any information that may be in the customer’s possession. Furthermore, system validation of this product designed by Queclink within a larger electronic system remains the responsibility of the customer or the customer’s system integrator. All specifications supplied herein are subject to change. Copyright This document contains proprietary technical information which is the property of Queclink Limited., copying of this document and giving it to others and the using or communication of the contents thereof, are forbidden without express authority. Offenders are liable to the payment of damages. All rights reserved in the event of grant of a patent or the registration of a utility model or design. All specification supplied herein are subject to change without notice at any time. Copyright © Queclink Wireless Solutions Co., Ltd. 2014 WARNING: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC RF Exposure Statement: For the product, under normal use condition is at least 20cm away from the body of the user, the user must keeping at least 20cm distance to the product. TRACGV55VCUM001 - 3 - GV55VC User manual NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Contents 1 Introduction .................................................................................................................................... 7 1.1. Reference ............................................................................................................................ 7 1.2. Terms and Abbreviations ..................................................................................................... 7 2 Product Overview .......................................................................................................................... 8 2.1. Check Part List .................................................................................................................... 8 2.2. Parts List ............................................................................................................................. 9 2.3. Interface Definition ............................................................................................................. 9 2.4. GV55VC User Cable Colour ............................................................................................ 11 3 .Getting Started ............................................................................................................................ 12 3.1. Opening the Case .............................................................................................................. 12 3.2. Closing the Case ............................................................................................................... 12 3.3. Power Connection ............................................................................................................. 13 3.4. Ignition Detection ............................................................................................................. 13 3.5. Digital Inputs .................................................................................................................... 14 3.6. Digital Outputs .................................................................................................................. 14 3.7. Device Status LED ............................................................................................................ 16 3.8. Motion Sensor direction .................................................................................................... 17 TRACGV55VCUM001 - 4 - GV55VC User manual Table Index TABLE 1. GV55VC PROTOCOL REFERENCE............................................................................7 TABLE 2. TERMS AND ABBREVIATIONS..................................................................................7 TABLE 3. PART LIST.......................................................................................…

Text truncated - open the document above for the full version.

Model Name: GV55VC Report Number: UL12620141016 FCC 020-6 Page 1 of 3 EUT PHOTOS View of EUT-1 View of EUT-2 Model Name: GV55VC Report Number: UL12620141016 FCC 020-6 Page 2 of 3 View of EUT-3 View of EUT-4 1 1 Model Name: GV55VC Report Number: UL12620141016 FCC 020-6 Page 3 of 3 View of EUT-5 1

IN1 IGN OUT2 OUT1 VIN GND 1 2 3 4 5 6 Designed by Queclink Operating V oltage: THIS SIDE TOWARDS SKY GV55VC DC 8-32V MEID: A1000043D40001 FCC ID:YQD-GV55VC

Model Name: GV55VC Report Number: UL12620141016 FCC 020-7 Page 1 of 5 EUT INTERNALPHOTOS View of EUT-1 View of EUT-2 1 Model Name: GV55VC Report Number: UL12620141016 FCC 020-7 Page 2 of 5 View of EUT-3 View of EUT-4 Model Name: GV55VC Report Number: UL12620141016 FCC 020-7 Page 3 of 5 View of EUT-5 View of EUT-6 Model Name: GV55VC Report Number: UL12620141016 FCC 020-7 Page 4 of 5 View of EUT-7 View of EUT-8 1 Model Name: GV55VC Report Number: UL12620141016 FCC 020-7 Page 5 of 5 View of EUT-9 View of EUT-10 1 1

Report No. : UL12620141016FCC020-5 Page: 1 of 4 RF Exposure Evaluation Declaration Product Name : GPS Locator Model No. : GV55VC FCC ID: YQD-GV55VC Applicant : Queclink Wireless Solutions Co.,Ltd Address : Room 501, Building 9, No 99, TianZhou Road, Shanghai, China Date of Receipt : 17-10-2014 Issued Date : 28-10-2014 Report No. : UL12620141016FCC020-5 Report Version : V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF, CNAS or any agency of the Government. The test report shall not be reproduced except in full without the written approval of Unilab Corporation. Report No. : UL12620141016FCC020-5 Page: 2 of 4 RF Exposure Evaluation Declaration Issued Date : 28-10-2014 Report No. : UL12620141016FCC020-5 Product Name : GPS Locator Applicant : Queclink Wireless Solutions Co.,Ltd Address : Room 501, Building 9, No 99, TianZhou Road, Shanghai, China Manufacturer : Queclink Wireless Solutions Co.,Ltd. Address : Room 501, Building 9, No 99, TianZhou Road, Shanghai, China Model No. : GV55VC EUT Voltage Extreme Low:8V,Normal:12V, Extreme High:32V Brand Name : Queclink Applicable Standard : FCC OET Bulletin 65 Supplement C (Edition 01-01) Test Result : Complied Performed Location : Unilab (Shanghai) Co.,Ltd. FCC 2.948 register number is 714465 No.1350, Lianxi Road, Pudong New District, Shangha, China TEL:+86-21-5027-5125/FAX:+86-21-5027-5126-876 Documented By : (Technical Engineer: Jingwei Li) Reviewed By : (Senior Engineer: Forest Cao) Approved By : (Supervisor: Eva Wang) Report No. : UL12620141016FCC020-5 Page: 3 of 4 1. EUT Description 2. RF Exposure Evaluation 2.1 Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range(MHz) Electric Filed Strength (V/m) Magnetic Filed Strength (A/m) Power Density (mW/cm2) Average Time (Minutes) (A)Limits for Occupation/Control Exposures 300-1500 -- --F/3006 1500-100,000 -- --56 (B)Limits for General Occupation/UnControlled Exposures 300-1500 -- --F/15006 1500-100,000 -- --130 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*Pi*R^2) Where Pd = power density in mW/cm2 Pout = output power to antenna in mW Product Name: GPS Locator Model Name: GPS Locator Hardware Version: 1.01 Software Version: GV55VCR00A01V01M128_MXIC RF Exposure Environment: Uncontrolled CDMA2000 Support Band: CDMA2000 BC0/BC1 Tx Frequency Range: CDMA2000 BC0: 824.70 MHz to 848.31MHz CDMA2000 BC1: 1851.25MHz to 1908.75MHz Rx Frequency Range: CDMA2000 BC0: 869.70 MHz to 893.31MHz CDMA2000 BC1: 1931.25MHz to 1988.75MHz Type of modulation: QPSK Antenna Type: Touch spring Antenna Peak Gain: CDMA2000 BC0/BC1: 1dBi Report No. : UL12620141016FCC020-5 Page: 4 of 4 G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. 2.2.Test Result of RF Exposure Evaluation This device is evaluated by mobile device with general population/uncontrolled exposure condition For this device, the calculation is using the most conservative values, and the results are as follows: Test Mode ERP (dBm) EIRP (dBm) Peak EIRP (mW) Calculated RF Exposure at d = 20cm (mW/cm2) MPE Limit (mW/cm2) CDMA2000 BC0 22.14 24.29 268.5 0.05 0.55 CDMA2000 BC1 / 23.12 205.1 0.04 1.00 Test Mode Antenna Gain (dBi) Maximum Output Power (dBm) Maximum Output Power From Antenna (mW) Calculated RF Exposure at d = 20cm (mW/cm2) MPE Limit (mW/cm2) CDMA2000 BC0 1 25 398.11 0.08 0.55 CDMA2000 BC1 1 25 398.11 0.08 1.00 This device can pass RF exposure limit.

Queclink Confidential Queclink Confidential Queclink Confidential Queclink Confidential Queclink Confidential Queclink Confidential

RF Test Report Test in accordance with Federal Communications Commission(FCC) CFR TITLE 47, Parts 2, 22, 24 Product Name : GPS Locator Model No. : GV55VC FCC ID : YQD-GV55VC Applicant : Queclink Wireless Solutions Co.,Ltd Address : Room 501, Building 9, No 99, TianZhou Road, Shanghai, China Date of Receipt : 16-10-2014 Test Date : 17-10-2014~23-10-2014 Issued Date : 28-10-2014 Report No. : UL12620141016FCC020-3 Report Version : V1.0 Notes： The test results only relate to these samples which have been tested. Partly using this report will not be admitted unless been allowed by Unilab. Unilab is only responsible for the complete report with the reported stamp of Unilab. Unilab(Shanghai) Co.,Ltd. Report No. : UL126 20141016 FCC 020-3 Page 2 of 39 Page: 2 of 39 Test Report Certification Issued Date : 16-10-2014 Report No. : UL12620141016 FCC 020-3 Product Name : GPS Locator Applicant : Queclink Wireless Solutions Co.,Ltd Address : Room 501, Building 9, No 99, TianZhou Road, Shanghai, China Manufacturer : Queclink Wireless Solutions Co.,Ltd. Address : Room 501, Building 9, No 99, TianZhou Road, Shanghai, China Model No. : GV55VC EUT Voltage : Extreme Low:8V, Normal:12V, Extreme High:32V Brand Name : Queclink FCC ID: YQD-GV55VC Applicable Standard : FCC CFR Title 47 Part 2; FCC CFR Title 47 Part 22 Subpart H; FCC CFR Title 47 Part24 Subpart E; ANSI/TIA-603-D-2010; FCC KDB 971168 D01 Power Meas. License Digital Systems v02 Test Result : Complied Performed Location : Unilab (Shanghai) Co., Ltd. FCC 2.948 register number is 714465 No. 1350, Lianxi Rd. Pudong New District, Shanghai, China TEL: +86-21-50275125 FAX: +86-21-50277862 Documented By : (Technical Engineer: Jingwei Li) Reviewed By : (Senior Engineer: Forest Cao) Approved By : (Supervisor: Eva Wang) Unilab(Shanghai) Co.,Ltd. Report No. : UL126 20141016 FCC 020-3 Page 3 of 39 Page: 3 of 39 TABLE OF CONTENTS SUMMARY OF TEST RESULT ....................................................................................................................................... 4 1. General Information ........................................................................................................................................ 5 1.1. EUT Description ...................................................................................................................................... 5 1.2. Mode of Operation ................................................................................................................................. 7 1.3. Tested System Details .......................................................................................................................... 9 1.4. Configuration of Tested System ........................................................................................................... 9 1.5. EUT Exercise Software ......................................................................................................................... 7 2. Technical Test ..................................................................................................................................................... 8 2.1. Test Environment .................................................................................................................................... 8 3. Peak Output Power ........................................................................................................................................... 9 3.2. Test Setup ................................................................................................................................................ 9 3.3. Limit ......................................................................................................................................................... 10 3.4. Test Procedure ...................................................................................................................................... 11 3.5. Uncertainty ............................................................................................................................................. 11 3.6. Test Result ............................................................................................................................................. 12 4. Occupied Bandwidth ........................................................................................................................................ 16 4.1. Test Equipment ..................................................................................................................................... 16 4.2. Test Setup .............................................................................................................................................. 16 4.3. Limit ......................................................................................................................................................... 17 4.4. Test Procedure ...................................................................................................................................... 17 4.5. Uncertainty ............................................................................................................................................. 17 4.6. Test Result ............................................................................................................................................. 18 5.Spurious Emission At Antenna Terminals (+/- 1MHz) ................................................................................. 22 5.1. Test Equipment ..................................................................................................................................... 22 5.2. Test Setup .............................................................................................................................................. 22 5.3. Limit ...............................................................................................................................…
