YQVHHH001Smart Navigator

Dipl.-Ing. H. Horstmann GmbH

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Nov 03, 2010
Application Purpose: Original Equipment
Date of Application: Nov 03, 2010
Equipment Note: Smart Navigator
Frequency Range: 2400.50000000 - 2482.50000000
Company: Dipl.-Ing. H. Horstmann GmbH
Country: Germany

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Dipl.-Ing. H. Horstmann GmbH Humboldtstraße 2 42579 Heiligenhaus www.horstmanngmbh.com Instructions for Use SMART NAVIGATOR 14 September 2010 Dipl.-Ing. H. Horstmann GmbH Instructions for Use 2 SMART NAVIGATOR CONTENTS Compliance Statements .......................................................................................................................... 4 Regulatory Information for the United States of America .................................................................... 4 Regulatory Information for Canada ..................................................................................................... 4 Regulatory Information for Europe ...................................................................................................... 4 Part 1 - Introduction ................................................................................................................................. 5 1.1 Introduction .................................................................................................................................... 5 1.2 Abbreviations ................................................................................................................................. 5 1.3 Intended use .................................................................................................................................. 5 1.4 Product Overview .......................................................................................................................... 6 Part 2 - Functionality ................................................................................................................................ 7 2.1. Device Description ........................................................................................................................ 7 2.2. fault detection, indication and reset .............................................................................................. 8 2.2.1 Fault Detection .......................................................................................................................... 8 2.2.2 Fault Indication and Reset......................................................................................................... 8 2.2.3 Fault Indication and Line Monitoring by Radio Signal ............................................................... 9 2.3. Wireless Communication .............................................................................................................. 9 2.3.1 Priority Events communicate by exception ............................................................................... 9 2.3.2 Reports communicate by routine interval .................................................................................. 9 2.4. TEST/RESET Contacts .............................................................................................................. 10 2.4.1 Test & Reset Magnet ............................................................................................................... 10 2.4.2 Test & Reset Magnet allocated functions ................................................................................ 10 2.5. Energy Supply ............................................................................................................................ 11 Part 3 - Installation & Operation ............................................................................................................ 12 3.1. Safety Instructions ...................................................................................................................... 12 3.2. Mechanical Installation ............................................................................................................... 12 3.3. SMART NAVIGATOR - operation ............................................................................................. 13 3.3.1 Priority events = report by exception ....................................................................................... 13 3.3.2 Other events ............................................................................................................................ 13 3.3.3 Analog data ............................................................................................................................. 13 3.5 SMART NAVIGATOR @Smart receiver Registration Procedure ............................................... 14 Part 4 - Technical Data .......................................................................................................................... 15 4.1. Product Foto & Label Information ............................................................................................... 16 Instructions for Use Dipl.-Ing. H. Horstmann GmbH SMART NAVIGATOR 3 General Information! Before installing and operating this instrument carefully read and understand the contents of this manual. Store this manual in a safe place for any possible questions in the future. Please, enter the type and ordering number of the device here: _______________________________. You will find all data on the name plate attached to the housing of the instrument. The content of this operating manual reflects the current state of the art at the date of printing. We reserve the right to make technical changes at any time and without prior notice as necessary in the framework of ongoing developments. Please visit your local representative to get updated versions of our operating manuals. This technical documentation becomes invalid when a new issue appears. Dipl.-Ing. H. Horstmann GmbH Instructions for Use 4 SMART NAVIGATOR COMPLIANCE STATEMENTS REGULATORY INFORMATION FOR THE UNITED STATES OF AMERICA Warning Installation, connection and commissioning of the SMART NAVIGATOR must be carried out exclusively by a skilled/qualified electrician observing the applicable safety rules and regulations. Attention This device complies with Part 15 of the FCC Rules. Operation is subjec…

Text truncated - open the document above for the full version.

Cover Letter(s)

ELEKTROTECHNISCHE GERÄTE UND ANLAGEN DIPL.-ING H. HORSTMANN GMBH 42579 HEILlGENHAUS • HUMBOLDTSTRASSE 2 • TELEFON +49 2056 976-0 • TELEFAX +49 2056 976-140 INTERNET: www.horstmanngmbh.com·E-MAlL:[email protected] H.Horstmann GmbH Humboldtstrasse 7 42579 Heiligenhaus 26.August 2010 T 0 whom it may concern Commercial Power of Attorney for type approval in several countries The company 71ayers AG has been contracted by H.Horstmann GmbH to obtain "Radio Type Approvals" for the following electronic component manufactured and/or released by H.Horstmann GmbH: -Smart Controller -Smart Navigator -Smart Receiver The following persons at 7 layers AG will be authorized: Mr. Bernhard Retka Mr. Holger Leutfeld Unless future correspondence from H. Horstmann GmbH directs otherwise, please extend your full cooperation to 7 layers regarding matters to the above mentioned products for the period beginning 2010 Aug 25 through end of the project date. Thank you .

External Photos

Annex I: Photo Report test set-up photos & external photos Test report reference: MDE_HORST_1001_FCCb Date: 2010-09-13 Annex I: Photo Report Test report reference: MDE_HORST_1001_FCCb Page 2 of 4 1 Photo Report Photo 1: Test setup for radiated measurements (Enclosure, below 30 MHz) Photo 2: Test setup for radiated measurements (Enclosure, 30 MHz to 1 GHz) Annex I: Photo Report Test report reference: MDE_HORST_1001_FCCb Page 3 of 4 Photo 3: Test setup for radiated measurements (Enclosure, above 1 GHz) Photo 4: EUT (front side) Annex I: Photo Report Test report reference: MDE_HORST_1001_FCCb Page 4 of 4 Photo 5: EUT (side view) Photo 6: EUT (side view)

ID Label/Location Info

Internal Photos

Test Report

7 layers AG Aufsichtsratsvorsitzenderh Registergerichth registered in: Borsigstrasse 11 Chairman of the Supervisory Board: Düsseldorf, HRB 44096 40880 Ratingen, Germany Markus Becker USt-IdNr h VAT No.: Phone: +49 (0) 2102 749 0 Vorstandh Board: DE 203159652 Fax: +49 (0) 2102 749 350 Dr. H.-J. Meckelburg TAX No. 147/5869/0385 www.7Layers.com Wilfried Klassmann FCC Measurement/Technical Report on Overhead Fault Indicator Smart Navigator FCC ID: YQVHHH001 IC CN: 9199A-HHH001 Report Reference: MDE_HORST_1001_FCCb Test Laboratory: 7 layers AG Borsigstrasse 11 40880 Ratingen Germany email: [email protected] DGA-PL-192/99-02 Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the testing laboratory. Test report Reference: MDE_HORST_1001_FCCb Page 2 of 31 Table of Contents 0 Summary 3 0.1 Technical Report Summary 3 0.2 Measurement Summary 4 1 Administrative Data 5 1.1 Testing Laboratory 5 1.2 Project Data 5 1.3 Applicant Data 5 1.4 Manufacturer Data 5 2 Test object Data 6 2.1 General EUT Description 6 2.2 EUT Main components 7 2.3 Ancillary Equipment 7 2.4 Auxiliary Equipment 7 2.5 EUT Setups 8 2.6 Operating Modes 8 2.7 Product labelling 8 3 Test Results 9 3.1 Occupied bandwidth 9 3.2 Peak power output 10 3.3 Spurious radiated emissions 11 4 Test Equipment 17 5 Photo Report 25 6 Setup Drawings 25 7 Annex measurement plots 26 7.1 Occupied bandwidth 26 7.2 Peak power output 28 7.3 Verification of band edge emissions 30 Test report Reference: MDE_HORST_1001_FCCb Page 3 of 31 0 Summary 0.1 Technical Report Summary Type of Authorization Certification for an Intentional Radiator (Digital Transmission Systems DTS). Applicable FCC Rules Prepared in accordance with the requirements of FCC Rules and Regulations as listed in 47 CFR Ch.1 Parts 2 (10-1-09 Edition) and 15 (10-1-09 Edition). The following subparts are applicable to the results in this test report. Part 2, Subpart J - Equipment Authorization Procedures, Certification Part 15, Subpart C – Intentional Radiators § 15.201 Equipment authorization requirement § 15.207 Conducted limits § 15.209 Radiated emission limits; general requirements § 15.215 Additional provisions to the general radiated emission limitations. § 15.249 Operation within the bands 902-928 MHz, 2400-2483.5 MHz and 5725-5850 MHz Note: Additionally the following Public Notice was considered: "Measurement of radiated emissions at the edge of the band for a Part 15 RF Device" Publication Number KDB913591 Summary Test Results: The EUT complied with all performed tests as listed in chapter 0.2 Measurement Summary. Test report Reference: MDE_HORST_1001_FCCb Page 5 of 31 1 Administrative Data 1.1 Testing Laboratory Company Name: 7 Layers AG Address Borsigstr. 11 40880 Ratingen Germany This facility has been fully described in a report submitted to the FCC and accepted under the registration number 96716. The test facility is also accredited by the following accreditation organisation: - Deutscher Akkreditierungs Rat DAR-Registration no. DGA-PL-192/99-02 Responsible for Accreditation Scope: Dipl.-Ing. Bernhard Retka Dipl.-Ing. Robert Machulec Dipl.-Ing. Thomas Hoell Dipl.-Ing. Andreas Petz Report Template Version: 2010-09-03 1.2 Project Data Responsible for testing and report: Dipl.-Ing. Robert Machulec Date of Test(s): 2010-08-11 to 2010-09-03 Date of Report: 2010-09-13 1.3 Applicant Data Company Name: Dipl.-Ing. H. Horstmann GmbH Address: Humboldtstraße 2 D-42579 Heiligenhaus Germany Contact Person: Mr. Frank Langenberg 1.4 Manufacturer Data Company Name: please see applicant data Address: Contact Person: Test report Reference: MDE_HORST_1001_FCCb Page 6 of 31 2 Test object Data 2.1 General EUT Description Equipment under Test: Overhead Fault Indicator Type Designation: Smart Navigator Kind of Device: (optional) Transceiver operating in the 2.4 GHz range Voltage Type: DC (internal battery Li-SOCL2) Voltage level: 3.6 V General product description: The Transceiver is operating in the 2.4 GHz ISM band at carrier frequencies 2400.5 and 2482.5 MHz. Modulation: MSK, Data Rate: 250 kbps Specific product description for the EUT: The SMART NAVIGATOR is an Overhead Fault Circuit Indicator that is designed and engineered for Smart Grid – Distribution Automation applications. The SMART NAVIGATOR is installed on Overhead Distribution Circuits and transmits event based fault information in addition to continuous circuit status information. The SMART NAVIGATOR is also able to receive signals from a Control Unit. The EUT provides the following ports: Ports Enclosure The main components of the EUT are listed and described in Chapter 2.2. Test report Reference: MDE_HORST_1001_FCCb Page 7 of 31 2.2 EUT Main components Type, S/N, Short Descriptions etc. used in this Test Report Short Description Equipment under Test Type Designation Serial No. HW Status SW Status Date of Receipt EUT A (Code: UN000a01) Overhead Fault Indicator Smart Navigator - B ID251 2010-08-11 Remark: EUT A is equipped with an internal antenna. NOTE: The short description is used to simplify the identification of the EUT in this test report. 2.3 Ancillary Equipment For the purposes of this test report, ancillary equipment is defined as equipment which is used in conjunction with the EUT to provide operational and control features to the EUT. It is necessary to configure the system in a typical fashion, as a customer would normally use it. But nevertheless Ancillary Equipment can influence the test results. Short Description Equipment under Test Type Designation Serial no. HW Status SW Status FCC ID - - - - - – – 2.4 Auxiliary Equipment For the purposes of this test report, auxiliary equipment is defined as equipment which is used temporarily to enable operational and control features especially used for the tests of the EUT which is not used during normal operation or equipment that is used during the tests in combination with t…

Text truncated - open the document above for the full version.

Test Setup Photos
