YS2OPSTI3W-TI3WPSEmbedded Computer

OPS-Ti3W-PS Option Slot PC Technovare Systems, Inc. 3000 MacArthur Blvd. Suite 330 Irvine, CA 92704 714-966-9 099 Product specification subject to change. 4/27/20 © 2020 Technovare Systems, Inc, Inc. All rights reserved. Overview The OPS-Ti3W-PS is a full-featured Windows PC in OPS form factor for integration into Commercial Displays. Targeted for Commercial Applications such as Digital Signage, Quick Service Restaurant, and/or Display Walls, the OPS-Ti3W-PS is based the latest Intel Whiskeylake CPU architecture with integrated Intel HD620 Graphics. The OPS-Ti3W-PS supports true 1080P an 4K video with hardware assisted support for formats such as MPEG2, H.264, and WM9. The OPS-Ti3W-PS external connections include 2 USB 2.0, 2 USB 3.0 for connection to keyboard, mouse, flash, or touch screen, 10/100/1000 LAN, Wifi, and HDMI Port for connection to a second screen. Applications Digital Signage Quick Service Restaurants Display Walls Large Venue/Stadiums Education Medical IPTV Hospitality OS CPU Windows 10 Pro 2.1 GHz Intel Whiskeylake Dual Core I3 CPU (8145U) Features TPM V2.0 Memory8 GB DDR4 (dualchannel) Storage128 GB M.2 SSD Video OutputHDMI 2.0 (OPS Conn), Display Port 1.2 (OPS Conn) Audio OutputStereo (OPS Conn), HDMI 2.0 (EXT Conn) NetworkLAN: 100/1000Base T WIFI: 802.11 ac ControlUSB2.0 x2, USB3.0 x2 (EXT Conn) USB2.0 x2, USB3.0 x1 (OPSConn) UART (OPS Conn) PowerInput Voltage: 16 VDC Power Dissipation: 60 Watts EnvironmentalOperating Temp: 0 to 40 C Operating Humidity: 80% maximum relative humidity; non condensing GeneralDimensions: 200mm x 119mm x 30mm Weight: 2.5 lb OPSconnector (TX25A) CertificationsFCCSection 15,CE Specification Windows PC for Commercial Display Applications Based upon Whiskeyake CPU FCC Statement： T his device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. T his equipment has been tested and found to comply with the limits for a Class B digital device, pursuant t o P art 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try correct the interference by one or more of the following measures: -R eorient the receiving antenna. -I ncrease the separation between the equipment and receiver. -C onnect the equipment into and outlet on a circuit different from that to which the receiver is connected. -C onsult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. The distance between user and products should be no less than 20cm

Technovare Systems Inc. Statement We Technovare Systems Inc. Hereby Declare that The product Embedded Computer, models no. OPS-TI3W, OPS-TI3W-PS, OPS-Ti3W, OPS-Ti3W-PS are all identical in interior structure, electrical circuits and components, and just model names are different for the marketing requirement. Your assistance on this matter is highly appreciated. Yours sincerely, <Signature>： Name：Grant Stockton Title：President Company：Technovare Systems Inc.

June 18, 2020 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: YS2OPSTI3W-TI3WPS Product Name: Embedded Computer Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature>： Name：Grant Stockton Title：President Company：Technovare Systems Inc.

June 18, 2020 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen Timeway Testing Laboratories/ Zone C, 1st Floor, Zone C, 1st Floor, Block B, Jun Xiang Da Building, Zhongshan Park Road West, Tong Le Village, Nanshan District, Shenzhen, China (Name of Agent company name and address) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Technovare Systems Inc./ 16815 Von Karman Ave., Suite 175, Irvine, Ca 92606, USA <Signature>： Name：Grant Stockton Title：President Company：Technovare Systems Inc.

Technovare Systems, Inc. Model No.: OPS-TI3W FCC ID: YS2OPSTI3W-TI3WPS Contain FCC ID: PD93160NG This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions(1) This device may not cause harmful interference,and(2)this device must accept any interference received, Including interference that may cause undesired operation

Label Location

Report No.: FCC 2004363 File Reference No.: 2020-05-21 Applicant:Technovare Systems Inc. Product:Embedded Computer Brand Name: Technovare TNET-PC Model No.: OPS-TI3W, OPS-TI3W-PS, OPS-Ti3W, OPS-Ti3W-PS Test Standards: FCC Part 15 Subpart B Test Result: It is herewith confirmed and found to comply with the requirements set up by ANSI C63.4&FCC Part 15 regulations for the evaluation of electromagnetic compatibility Approved By Terry Tong Manager Dated:May 21, 2020 Results appearing herein relate only to the sample tested The technical reports is issued errors and omissions exempt and is subject to withdrawal at SHENZHEN TIMEWAY TESTING LABORATORIES. Zone C, 1st Floor, Block B, Jun Xiang Da Building, Zhongshan Park Road West, Tong Le Village, Nanshan District, Shenzhen, China Tel (755) 83448688 Fax (755) 83442996 Email: [email protected] Report No.: FCC2004363 Page 2 of 49 Date: 2020-05-21 "The report refers only to the sample tested and does not apply to the bulk production. This report is issued in confidential to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for illegal purpose. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES reserves the rights to withdraw it and to adopt any other remedies which may be appropriate." Special Statement˖ The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19. The testing quality system of our laboratory meet with ISO/IEC-17025 requirements, which is approved by CNAS. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: CNAS-LAB Code: L2292 The EMC Laboratory has been assessed and in compliance with CNAS-CL01 accreditation criteria for testing Laboratories (identical to ISO/IEC 17025:2005 General Requirements) for the Competence of testing Laboratories. FCC-Registration No.: 744189 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. The acceptance letter from the FCC is maintained in our files. Registration No.: 744189. Industry Canada (IC) —Registration No.:5205A The EMC Laboratory has been registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing with Registration No.: 5205A. A2LA (Certification Number:5013.01) The EMC Laboratory has been accredited by the American Association for Laboratory Accreditation (A2LA). Certification Number:5013.01 Report No.: FCC2004363 Page 3 of 49 Date: 2020-05-21 "The report refers only to the sample tested and does not apply to the bulk production. This report is issued in confidential to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for illegal purpose. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES reserves the rights to withdraw it and to adopt any other remedies which may be appropriate." Content 1.0 General Details ................................................................................................................................................ 4 1.1 Test Lab Details ........................................................................................................................................ 4 1.2 Applicant Details ...................................................................................................................................... 4 1.3 Description of EUT ................................................................................................................................... 4 1.4 Submitted Sample ..................................................................................................................................... 4 1.5 Test Duration ............................................................................................................................................ 4 1.6 Test Uncertainty ........................................................................................................................................ 4 1.7 Test Engineer ............................................................................................................................................ 4 2.0 List of Measurement Equipment ................................................................................................................... 5 2.1 Conducted Emission Test .......................................................................................................................... 5 2.2 Radiated electromagnetic disturbance test ................................................................................................ 5 2.3 Auxiliary Equipment ................................................................................................................................ 5 3.0 Technical Details ..........................................................…

Text truncated - open the document above for the full version.

Conducted Emission Te s t Setup: Radiated Emission Te s t Setup:
