YVJSPS23WCFL

User Manual Dear Customer, Thank you for buying ZHEJIANG Joinan Lighting CO., LTD (ZHEJIANG JIUYang PHOTOELECTRIC CO.,LTD ) CFL. Please read carefully the product instruction before using! The models of SP9S 9W, SP13S 13W, SP23S 23W use only on 120 volt, 60 Hz circuit. The wattage marked on the lamp. And the operating Frequency is more than 50kHz and less than 60kHz Features Energy Saves up to 75% compared to common incandescent Lamps One years limited warrant; Rapid on/off with silent operation; Reduces Carbon Dioxide Electromagnetic Volume Consumes natural resources Generate less heat in the building Note & Attention Always turn-off power before re-lamping; Avoid installing lamp by gripping the glass tube; Do not use with electronic timers Reliable operating temperature -15°C~50°C Not suitable for damp surroundings or sealed occasions Risk of electric shock-use in dry locations For best result use in proper voltage range as mentioned on lamp base Applications: Home, Office, Hotel, Shop, Restaurant...and so on lighting Warning: For use in 120V/60HZ circuits only. Do not expose to moisture or water. Not for use in totally enclosed recessed luminaries. Do not open-no user-serviceable parts inside. Do not use with dimmer. To install or remove, handle bulb by grasping base--Do not grasp glass portion. This bulb is not intended for use with:emergency Exit Fixtures or Emergency Exit Lights,Photocells,and electronic timers. And enclosed fixtures is required for outdoor use. Optimum operating temperatures -18'C (-15'F) to 50'C (122'F). Starting temperature -18'C (-15'F). This bulb complies with Part 18 of FCC Rules (ICES-005 CLASS B),but may cause interference to radios,Tvs,Wireless phones and Remote controls. If interference occurs,Move Bulb away from affected device, or plug device into another outlet. Do not install this product near maritime safety equipment or other critical navigation or communication equipment operating between 0.45-30 MHz. FCC Information 1.This device complies with Part 18 of the FCC Rules. 2.Information on the following matters shall be provided to the user in the Instruction manual: (a) The interference potential of the device or system; (b) Maintenance of the system; (c) Simple measures that can be taken by the user to correct interference; (d) Manufacturers of RF lighting devices must provide an advisory statement, either on the product packaging or with other user documentation, similar to the following: This product may cause interference to radio equipment and should not be installed near maritime safety communications equipment or other critical navigation or communication equipment operating is between 0.43kHz and 30kHz. Variations of this language are permitted provided all the points of the statement are addressed and may be presented in any legible font or text style. . CORRECT WAY WRONG WAY (JUST GRASP BASE PLASTIC PART) (DO NOT GRASP GLASS PART) Don't TOUCH GLASS AND BASE HEAD.

Company: Zhejiang Joinan Lighting Co., LTD Address: 18 XINGGONG 7TH RD SHANGYU TOWN JIANGSHAN,ZHEJIANG,CHINA FCC Confidential Authorization Date: 2010-11-22 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: YVJSPS23W. In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Zhejiang Joinan Lighting Co., LTD hereby requests long-term confidential treatment of information accompanying this application as outlined below: • Block Diagram • Schematics • Operation Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Client’s signature: Client’s name/ title: Zhixiong Shao/Manager Contact information/address: Zhejiang Joinan Lighting Co., LTD 18 XINGGONG 7TH RD SHANGYU TOWN JIANGSHAN,ZHEJIANG,CHINA

EXHIBIT B – EUT EXTERNAL PHOTOGRAPHS EUT - Front View EUT - Side View

EXHIBIT A – FCC LABELING AND LABEL LOCATION FCC ID Label FCC ID Label Location on EUT Label here

EXHIBIT C – EUT INTERNAL PHOTOGRAPHS EUT - Uncovered View EUT – PCB Front View EUT – PCB Rear View

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP*, NIST, or any agency of the Federal Government. * This report may contain data that are not covered by the NVLAP accreditation and are marked with an asterisk “*” (Rev.2) FCC PART 18 MEASUREMENT AND TEST REPORT For Zhejiang Joinan Lighting Co., LTD Xiaoyue Town,Shangyu City, Zhejiang Province, China This Report Concerns: Original Report Equipment Type: CFL July Yang Test Engineer: Fisher He Report Number: RSH101011001 Report Date: 2010-10-19 Reviewed By: David Li Prepared By: Bay Area Compliance Laboratories Corp. (Chengdu) 5040, HuiLongWan Plaza, No. 1, ShaWan Road, JinNiu District, ChengDu, Sichuan, China www.baclcorp.com FCC ID: YVJSPS23W Model: SPS23W Zhejiang Joinan Lighting Co., LTD FCC ID: YVJSPS23W Report #: RSH101011001 Page 2 of 13 FCC Part 18 Test Report TABLE OF CONTENTS GENERAL INFORMATION ..........................................................................................................................................3 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ......................................................................................3 OBJECTIVE.......................................................................................................................................................................3 RELATED SUBMITTAL(S)/GRANT(S)................................................................................................................................ 3 TEST METHODOLOGY......................................................................................................................................................3 TEST FACILITY................................................................................................................................................................3 SYSTEM TEST CONFIGURATION.............................................................................................................................4 DESCRIPTION OF TEST CONFIGURATION.........................................................................................................................4 EUT EXERCISE SOFTWARE.............................................................................................................................................4 SPECIAL ACCESSORIES....................................................................................................................................................4 EQUIPMENT MODIFICATIONS..........................................................................................................................................4 EXTERNAL I/O CABLE.....................................................................................................................................................4 CONFIGURATION OF TEST SYSTEM................................................................................................................................. 4 TEST SETUP BLOCK DIAGRAM........................................................................................................................................ 5 SUMMARY OF TEST RESULTS ..................................................................................................................................6 FCC§ 18.307 – AC LINE CONDUCTED EMISSIONS ............................................................................................... 7 MEASUREMENT UNCERTAINTY.......................................................................................................................................7 EUT SETUP......................................................................................................................................................................7 EMI TEST RECEIVER SETUP............................................................................................................................................8 TEST EQUIPMENT LIST AND DETAILS.............................................................................................................................8 TEST PROCEDURE............................................................................................................................................................8 SUMMARY OF TEST RESULTS..........................................................................................................................................8 CONDUCTED EMISSIONS TEST DATA & PLOTS...............................................................................................................9 FCC §18.305 – FIELD STRENGTH.............................................................................................................................12 MEASUREMENT UNCERTAINTY.....................................................................................................................................12 EUT SETUP....................................................................................................................................................................12 EMI TEST RECEIVER SETUP..........................................................................................................................................12 TEST EQUIPMENT LIST AND DETAILS...........................................................................................................................12 TEST PROCEDURE..........................................................................................................................................................12 CORRECTED AMPLITUDE & MARGIN CALCULATION....................................................................................................13 TEST RESULTS SUMMARY...............…

Text truncated - open the document above for the full version.

EXHIBIT D – TEST SETUP PHOTOGRAPHS Conducted Emission Test Setup Front View Conducted Emission Test Setup Side View
