YXQI30AMOBILE TV RECEIVER

FCC Notice FCC N This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in Notice accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures : ‐ Reorient or relocate the receiving antenna. ‐ Increase the separation between the equipment and receiver. ‐ Connect the equipment into an outlet on a circuit difference from that to which the receiver is connected. Clt th dl f id di /TV thii f hl ‐ C onsu lt th e d ea l er o f an exper i ence d ra di o /TV t ec h n i c i an f or h e l p. NOTE : The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user's authority to operate the equipment. THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND FCC ID : YXQI30A (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDERSIRED OPERATION. Thank you for choosing Cydle Introd We hope you will find the instruc tions in this owner’s manual i s clear and easy to follow. Please take a few minutes to look through the user manual to le arn how to use all the features of your new Cydle i30A. How the i30A Works duction How the i30A Works The i30A is a dock type attachment that receives broadcasting f rom the air and transmits it to the iPhone. The i30A’s built-in ATSC MH module catches local mobile channel signals and sends it to the iPhone thru the Wi-Fi connection. Note: The i30A will connect to the iPhone via the internal Wi - Fi, and no other Wi - Fi connection is necessary. n Note: The i30A will connect to the iPhone via the internal Wi Fi, and no other Wi Fi connection is necessary. The i30A Cradle is equipped with a rechargeable battery, so whe n connected to the AC Adaptor you are able to charge the i30A Cradle and the iPhone simultaneously. The i30A Cradle can also serve as a backup battery when the iPhone battery runs low. Before usin g the i30A, p lease download the C y dle ATSC-MH Mobile TV from the A pp Store at no cost. gp y pp Mobile TV cannot be received while using the i30A as a battery pack, due to the limitation of the power supply. Web site Please visit our website or contact a Cydle representative if y ou have any inquires while using the Cydle i30A. Contact http://www.cydle.com or e-mail to [email protected] Please visit Cydle’s official website for further information an d detailed contents of the i30A. - Get the latest software update at the Cydle website for free- Register for a FREE Cydle Membership for the latest updates, pr omotions and new products. - Cydle Customer Service Toll Free No. : 1-877-810-5818 1 Cydle America Corp. Copy 4030 N. Palm Street #305, Fullerton, CA 92835Cydle Corp. 12th floor, Kofomo Tower, Sunae-Dong, Bundang-Gu, Seongnam-City, Kyonggi-Do, Korea All rights reserved by Cydle Corp. right All rights reserved. Copyright and intellectual property rights of all documents written by Cydle Corporation are the property of the Cydle Corporation. Cydle Corporation has copyright and intellectual pr operty rights of our software and documents including this manual, dth f d tf ll li t an d th e use o f pro d uc t f o ll ows li cense agreemen t . No part of this manual can be copied, reproduced, transmitted w ithout the prior written consent of Cydle Corporation . Cydle grants permission to download a copy of this manual into a hard drive or other electronic storage to be viewed and to be printed on copy, which must cont ain this copyright notice. “ Cydle “ is the Cydle Corporation ' s own brand and is a registered trademark Cydle is the Cydle Corporation s own brand and is a registered trademark . All names are trademarks or registered trademarks of their resp ective owners. You cannot infringe ownership without permission. Information in this document is subject to change without prior notice. Cydle reserve the right to change or improve the products and change the contents without notice Visit Cydle Website to check the current update and the products and change the contents without notice . Visit Cydle Website to check the current update and supplemental information concerning the use and operation of Cy dle’s products. All other trademarks, whether claimed or registered, are the ex clusive property of their respective owners. “Made for iPhone” means that an electronic accessory has been d esigned to connect specifically to iPhone and has been certified by the develo per to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regu latory standards. Apple is a trademark of Apple Inc registered in the U S and other countriesApple is a trademark of Apple Inc , registered in the U . S and other countries . iPhone is a trademark of Apple In c, registered in the U.S and ot her countries. 2 Be sure to carefully read the operating instructions an d adhere to the safety precautions before using your Cydle i dfdl llb blfdh Safety and Handling Information i 30A to ensure correct usa g e an d user sa f ety. Cy dl e Corporation wi ll not b e responsi bl e f or inci d ents t h at occur due to failing to follow instructions presented. This information applie…

Text truncated - open the document above for the full version.

Rev 11/20/07 12th Floor, Kofomo Tower, 16-3, Sunae-dong, Bundang-Gu, Sungnam-City, Kyonggi-Do, Korea Tel. : +82) 31 726 9970, Fax. : +82) 31 713 9773 http://www.cydle.com Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: YXQI30A Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Schematics CONF APPENDIX i30A Schem.pdf Parts list CONF APPENDIX i30A PartsLst.pdf Block diagram CONF APPENDIX i30A BlkDia.pdf Operational Description(Theory of Operation)CONF APPENDIX i30A OpDes.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name External Photos CONF APPENDIX i30A ExtPho.pdf Internal Photos CONF APPENDIX i30A IntPho.pdf Sincerely, ------------------------------------- Jinny Rho / Assistance Manager E-mail : [email protected]

12th Floor, Kofomo Tower, 16-3, Sunae-dong, Bundang-Gu, Sungnam-City, Kyonggi-Do, Korea Tel. : +82) 31 726 9970, Fax. : +82) 31 713 9773 http://www.cydle.com POWER OF ATTORNEY DATE : May 16. 2011. Federal Communications Commission Authorization and Evaluation Division 7435 Oskland Mills Road, Columbia, MD 21046 To Whom It May Concern : We the undersigned, hereby authorize Korea EMC Laboratory Co., Ltd. on our behalf, to apply to the FEDERAL COMMUNICATIONS COMMISSION on our equipment. Any and all acts carried out by Korea EMC Laboratory Co., Ltd. on our behalf shall have the same effect as acts of our own. This authorization expires on MAY 16. 2012. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Cydle Corp. . Jinny Rho / Assistance Manager E-mail : [email protected]

External Photographs

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDERSIRED OPERATION . Made in Korea

Internal Photographs of EUT

Dielectric Chip Antenna - Application Frequency Band[MHz] Bluetooth2400 ~ 2485 WiFi / Zigbee2400 ~ 2485 S-DMB2630 ~ 2655 Wibro 2300 ~ 2390 band1 : 2300 ~ 2327 band2 : 2331.5 ~ 2358.5 bnad3 : 2363 ~ 2390 Original Design Chip Antenna Data Sheet - P/N : SDBTPTR3015 - Dielectric Chip Antenna ■ SDBTPTR3015 Dimension ParameterLWTABCDE Value[mm] 3.0 ±0.1 1.5 ±0.1 1.2 ±0.1 1.00.550.41.10.65 Unless Specified tolerances are ± 0.05 mm Dielectric Chip Antenna ■ AutoCAD Drawing of Reference PCB Design for SDBTPTR3015 Product 41 2 3 Dielectric Chip Antenna ■ PCB Drawing Top View Case #1 <Default> 12 3 4 Case #2 12 3 4 Case #3 12 3 4 Case #4 12 3 4 Bottom View <Equivalent Circuit> Dielectric Chip Antenna ■ Matching Value Band (MHz) Matching Value (Default) Bluetooth / WiFi / Zigbee (2400 ~ 2485) Connector N/C Ant. 100pF 1.8pF 100 pF N/C S-DMB ( 2630 ~ 2655) Connector N/C Ant. 100pF 1.0nH 100 pF N/C Wibro (2300 ~ 2390) band1:2300~2327 band2:2331.5~2358.5 bnad3:2363~2390 Connector N/C Ant. 100pF 2.0pF 100 pF N/C Dielectric Chip Antenna - 3D Passive Gain For Bluetooth / WiFi / Zigbee ■ Test Result for Ver 0.0 SWR & Smith chart3D Peak [dBi] Average [dBi] Efficiency [%] 2400MHz1.96-0.9780.18 2425MHz1.99-0.6685.92 2445MHz1.74-0.8582.42 2465MHz1.27-1.2575.12 2485MHz0.86-1.6468.59 ■ Radiation PatternVer 0.0 3D Passive Dielectric Chip Antenna - 3D Passive Gain For S-DMB ■ Test Result for Ver 0.0 SWR & Smith chart3D Peak [dBi] Average [dBi] Efficiency [%] 2627MHz4.33-0.3891.80 2642MHz4.67-0.3692.06 2657MHz4.71-0.5688.02 ■ Radiation PatternVer 0.0 3D Passive Dielectric Chip Antenna - 3D Passive Gain For Wibro ■ Test Result for Ver 0.0 SWR & Smith chart3D Peak [dBi] Average [dBi] Efficiency [%] 2300MHz2.51-0.8482.52 2322.5MHz 2.68-0.7883.71 2345MHz3.15-0.4590.20 2367.5MHz 3.02-0.7883.76 2390MHz3.09-0.8682.12 ■ Radiation PatternVer 0.0 3D Passive

KEL-D-QP-25-24/2 Page of Pages: 2/22 FCC ID : YXQI30A Report Ref. No : KEL10-F12051 Korea EMC Laboratory Co., Ltd. KEL Korea EMC Laboratory 0. REPORT REVISION HISTORY Date Revision Page no. March 18, 2011 Issued All This report shall not be reproduced except in full, without the written approval of Korea EMC Laboratory Co., Ltd. This document may be altered or revised by Korea EMC Laboratory Co., Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by Korea EMC Laboratory Co., Ltd. will constitute fraud and shall nullify the document. KEL-D-QP-25-24/2 Page of Pages: 3/22 FCC ID : YXQI30A Report Ref. No : KEL10-F12051 Korea EMC Laboratory Co., Ltd. KEL Korea EMC Laboratory TABLE OF CONTENTS 0. REPORT REVISION HISTORY 2 1. TEST LABORATORY 5 1.1 General 5 1.2 Certificate of designated testing laboratory 5 2. DESCRIPTION OF THE EQUIPMENT UNDER TEST 6 2.1 Characteristic 6 2.2 Applied standard 6 2.3 Submitted documents 6 2.4 Channel chart 7 3. TEST COMDITIONS 8 3.1 Description of test configuration 8 3.2 List of peripherals 8 3.3 Uncertainty 8 3.4 Environment condition 8 4. SUMMARY OF TEST RESULTS 9 5. TEST AND RESULTS 10 5.1 AC Power conducted emission 10 5.1.1 Test procedures 10 5.1.2 Limits of AC power conducted emission 10 5.1.3 Test instruments 10 5.1.4 Test results 11-12 5.2 Out of band emission & Band edge 13 5.2.1 Test procedures 13 5.2.2 Limits of out of band emission 13 5.2.3 Test instruments 14 5.2.4 Test results 14-16 5.3 Minimum 6 dB bandwidth 17 5.3.1 Test procedures 17 5.3.2 Limit of minimum 6 dB bandwidth 17 5.3.3 Test instruments 17 5.3.4 Test results 17-18 5.4 Maximum peak out power 19 5.4.1 Test procedures 19 5.4.2 Limit of maximum peak out power 19 5.4.3 Test instruments 19 5.4.4 Test results 19 KEL-D-QP-25-24/2 Page of Pages: 4/22 FCC ID : YXQI30A Report Ref. No : KEL10-F12051 Korea EMC Laboratory Co., Ltd. KEL Korea EMC Laboratory 5.5 Peak power spectral density 20 5.5.1 Test procedures 20 5.5.2 Limit of peak power spectral density 20 5.5.3 Test instruments 20 5.5.4 Test results 20-21 5.6 Antenna requirement 22 5.6.1 Regulation 22 5.6.2 Antenna connected construction 22 5.7 RF exposure 22 KEL-D-QP-25-24/2 Page of Pages: 5/22 FCC ID : YXQI30A Report Ref. No : KEL10-F12051 Korea EMC Laboratory Co., Ltd. KEL Korea EMC Laboratory 1. TEST LABORATORY 1.1 General Name of Test Laboratory Korea EMC Laboratory Co., Ltd. President Won-Hyang Oh Address 390 Bora-dong, Giheung-gu, Yongin-si, Gyeonggi-do, Republic of Korea (446-904) TEL +82-31-286-5881 FAX +82-31-286-2661 e-mail [email protected] 1.2 Certificate of designated testing laboratory Area and Category Regulation Registration & Certification No. Mark. Radio Research Agency EMI(Radiated & Conducted emission) EMS(Radiated Immunity) Safety Radio Communication Part No. 2011-12 (2011. 02. 18) KR0002 Korea Laboratory Accreditation Scheme (KOLAS) EMI(Radiated & Conducted emission) EMS(Radiated Immunity) Safety Road Vehicle component test(EMC) Military EMC(MIL-STD-461E) KS Q ISO/IEC 17025:2006 No. 154 FCC Part 15 & 18 EMI(Radiated & Conducted emission) ANSI 63.4:2003 90751 (KR0002) VCCI EMI(Radiated & Conducted emission) VCCI C-2314 R-2139 R-2140 UL Korea Ltd. Safety Star Alliance Program - European Conformity EMC & Safety 2004/108/EC 2006/95/EC - TUV SUD Certification after Recognition of Agent’s Testing EMC ISO/IEC 17025:2005 ROK1006C KEL-D-QP-25-24/2 Page of Pages: 6/22 FCC ID : YXQI30A Report Ref. No : KEL10-F12051 Korea EMC Laboratory Co., Ltd. KEL Korea EMC Laboratory 2. DESCRIPTION OF THE EQUIPMENT UNDER TEST The product specification described herein was obtained from the product data sheet or user’s manual 2.1 Characteristics Product name Mobile TV Receiver Model no. i30A FCC ID YXQI30A Operation frequency 2412 MHz(802.11 b) RF power 8.55 dBm(9.31 mW) Spread spectrum method DSSS(802.11 b) Modulation type CCK, DQPSK, DBPSK Data rate 11.0 / 5.5 / 2.0 / 1.0 Mbps Number of channel 1 Channel Antenna type / max. gain Chip Antenna / 1.99 dBi Power source DC 5.0 V(Adapter) DC 3.7 V(Battery) Size 67 mm X 111 mm X 10 mm Interface ports - Accessory Adaptor(AC-DC), Car Adaptor, Suction Mount, ROD Antenna(ATSC M/H), External Antenna, Stand, Bracket 2.2 Applied standard - FCC part 15, subpart C(15.247_DTS) - ANSI C63.4_2003 Note : It has been verified to comply with requirements of FCC part 15, subpart B, Class B(DoC). The test report has been issued separately 2.3 Submitted documents - Block diagram - Schematic diagram - Antenna specification - Part list(B.O.M) - User manual KEL-D-QP-25-24/2 Page of Pages: 7/22 FCC ID : YXQI30A Report Ref. No : KEL10-F12051 Korea EMC Laboratory Co., Ltd. KEL Korea EMC Laboratory 2.4 Channel chart 802.11 b(1 Channel) Channel Freq. (MHz) Channel Freq. (MHz) Channel Freq. (MHz) Channel Freq. (MHz) 1 2412 - - - - - - - - - - - - - - - - - - - - ▪ Measurement Channel : 1 Channel(2412 MHz) ▪ Test rate : 11 Mbps KEL-D-QP-25-24/2 Page of Pages: 8/22 FCC ID : YXQI30A Report Ref. No : KEL10-F12051 Korea EMC Laboratory Co., Ltd. KEL Korea EMC Laboratory 3. TEST CONDITIONS 3.1 Description of test configuration The EUT has been tested as an independent unit with other necessary accessories or support unit. The following support units or accessories were used to form a representative test configuration during the tests. 3.2 List of peripherals Type Model no. Serial no. Manufacturer EUT(Multi PAD) i30A - Cydle Corp. Adaptor PA-050200SN - Perfect Power iphone A1241 - Apple Inc. 3.3 Uncertainty Measurement Frequency Uncertainty Conducted Emission 150 kHz ~ 30 MHz 1.5 Radiated Emission 30 MHz ~ 1 GHz 4.4 1 GHz ~ 40 GHz 4.1 3.4 Environment condition Measurement Temperature Humidity Atmospheric pressure Conducted emission 25 ± 4 °C 30 – 60 % R.H. 101.4 kPa Radiated emission 22 ± 4 °C 30 – 60 % R.H. 101.4 kPa This uncertainty represents an expanded uncertainty expressed at approximately the 95 % confidence level using a coverage factor if k=2. KE…

Text truncated - open the document above for the full version.

Test Setup Photographs
