YYRKPADBRFID access control system

The HiRes Video Company US www.mobotix.com HiRes Video Innovations The German company MOBOTIX AG is known as the leading pioneer in network camera technology and its decentralized concept has made high-resolution video systems cost-efficient. MOBOTIX CORP • Manhattan (NY) • Phone: 888-MOBOTIX (662 6849) • [email protected] • Made in Germany KeypadRFID: Regulatory Notice Federal Communications Commission (FCC) and Industry Canada (IC) Notice for MX-Keypad1-EXT (M/N: Keypad-B) (FCC ID: YYRKPADB, IC ID: 9357A-KPADB) NOTICE: This device complies with Part 15 of the FCC Rules [and with ICES-003 of Industry Canada]. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTICE: Le présent appareil est conforme aux CNR d‘Industrie Canada applicables aux appareils radio exempts de licence. L‘exploitation est autorisée aux deux conditions suivantes: (3) l‘appareil ne doit pas produire de brouillage, et (4) l‘utilisateur de l‘appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d‘en compromettre le fonctionnement. NOTICE: Changes or modifications made to this equipment not expressly approved by MOBOTIX AG may void the FCC authorization to operate this equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Radiofrequency Radiation Exposure Information: The radiated output power of the device is far below the FCC radio frequency exposure limits. Nevertheless, the device shall be used in such a manner that the potential for human contact during normal operation is minimized. Ministry of Internal Affairs and Communications Notice for MX-Keypad1-EXT NOTICE: • This device has been granted a designation number by Ministry of Internal Affairs and Communications • This device should not be modified (otherwise the granted designation number will be invalid) Keypad with Contactless RFID Technology MOBOTIX KeypadRFID MX-Keypad1-EXT (in triple frame silver) RFID cards for keyless entry IP Video Door Station MX-Keypad1-EXT 31.287_US_V3_07/2013 Weatherproof (IP65) –30 to +60°C/–22 to +140°F The HiRes Video Company US www.mobotix.com HiRes Video Innovations The German company MOBOTIX AG is known as the leading pioneer in network camera technology and its decentralized concept has made high-resolution video systems cost-efficient. MOBOTIX CORP • Manhattan (NY) • Phone: 888-MOBOTIX (662 6849) • [email protected] • Made in Germany KeypadRFID: Conformity 2013 • Declaration of Conformity: www.mobotix.com > Support > Media Library > Certificates Copyright © MOBOTIX AG 2013 • Made in Germany • Technical information subject to change without notice. Hersteller Manufacturer: Fabricant : MOBOTIX AG Produkt: Product: Produit : MxBus-Modul MxBus module Module MxBus Typ: Type: Type : MX-Keypad1-EXT Bei bestimmungsgemäßer Verwendung erfüllt das bezeichnete Produkt die Bestimmungen gemäß Artikel 3 der R&TTE-Richtlinie 1999/5/EG. The product identified above complies with the essential requirements of article 3 of the guideline R&TTE 1999/5/EG. Le produit désigné ci-dessus est conforme aux exigences fondamentales de l’article 3 de la directive R&TTE 1999/5/EG. Angewendete harmonisierte Normen: Harmonised standards applied: Normes harmonisées : SafetyEN 60950-1:2006/A11:2009/ A1:2010/A12:2011 HealthEN 62311:2008 EMCEN 301 489-1 (V1.9.2) EN 301 489-3 (V1.4.1) ERM-SRDEN 300 330-1 (V1.7.1) EN 300 330-2 (V1.5.1) Weitere angewendete Normen: Other harmonised standards applied: Autres normes harmonisées : FCC Part 15B, Part 15C RSS 210 Item 3 of Article 44-1 of the Radio Ordinance Adresse: Address: Adresse: MOBOTIX AG Kaiserstrasse 67722 Langmeil Germany + TK-Nr. Phone number N° de communication: Fon: Fax: E-Mail: +49 6302 981 6-103 +49 6302 981 6-190 [email protected] Langmeil, July 23, 2013 Ort, Datum Place & date of issue Lieu et date Dr. Ralf Hinkel CEO, MOBOTIX AG Name und Unterschrif t Name and signature Nom et signature Notes • Please follow the notes on installing and operating the device in the MOBOTIX T24 System Manual (www.mobotix.com in the Support > Manuals section). • The MOBOTIX KeypadRFID is only to be used in the original frames of the IP Video Door Station. • Before Installing, make sure that the seal on the back of the KeypadRFID has been properly attached. • When inserting the module into the frame, only press at the edge, never at the center of the module. • Make sure the device is not operated outside of its operating temperature range of –30 to +60°C/–22 to +140°F. 99 mm/3.9 in 99 mm/3.9 in Declaration of Conformity DimensionsBack

The HiRes Video Company EN KeypadRFIDQuick Install www.mobotix.com HiRes Video Innovations The German company MOBOTIX AG is known as the leading pioneer in network camera technology and its decentralized concept has made high-resolution video systems cost-efficient. MOBOTIX AG • D-67722 Langmeil • Tel: +49 6302 9816-103 • Fax: +49 6302 9816-190 • [email protected] Keypad with Contactless RFID Technology Module for MOBOTIX IP Video Door Station Keyless access to buildings using RFID transponder card or PIN code • Keypad module with 1 admin and 5 user RFID cards • Mailbox control • Integrated RFID technology for keyless entry • Available colors: white, silver, dark gray, black, amber • Up to 60 hrs backup power supply using DoorMaster (accessory) Click 1 2 Installing the KeypadRFID Installing the module follows the procedure described in the T24 System Manual Part 1, in Section 2.4.2, "Installing the KeypadRFID". For more information on other connection variants (e.g. without DoorMaster), please see Section 2.1, "Overview: Connection and Wiring Diagrams". When installing the module in the frame, make sure that you insert the right side of the module first and then press on the lef t edge (and not on the center) to click the module into place. Operation After installing, make sure that you follow the steps in the T24 System Manual Part 2 in Section 2, "Initial Operation without PC". This chapter shows you how to configure the entire system (including the RFID admin and user cards) in a few simple steps. Replacing the KeypadRFID If the KeypadRFID needs to be replaced against all expectations, you need a current backup of the system configuration. This will ensure that you can seamlessly integrate the new KeypadRFID into the system later on. Please follow the steps outlined in the T24 System Manual Part 2 in Section 5.2, "Backup & Restore". To dismount the KeypadRFID, follow the steps in the T24 System Manual Part 1 in Section 2.4.6, "Removing and Exchanging Modules". Make sure that you deactivate the theft protection before dismounting the module and that you activate the theft protection again after re-installing. MOBOTIX KeypadRFID MX-Keypad1-EXT (in triple frame silver) RFID cards for keyless entry included (1 admin card, 5 user cards) I/O terminal Sealing plug Seal MxBus terminal Back view with cover removed OutdoorIndoor Door 2 6 MxBus (YSTY 0.8 mm – max. length: 50 m/55 yd) Theft protection (YSTY 0.8 mm – max. length: 50 m/55 yd) Door opener, door sensor, lock sensor (YSTY 0.8 mm – max. length: 50 m/55 yd) DoorMaster IP Video Door Station 2 For additional information on the other connection variants and for installing, see the T24 System Manual Part 1 on www.mobotix.com > Support > Manuals. KeypadRFID InfoModule Standard Connection: KeypadRFID with IP Video Door Station, InfoModule and DoorMaster MX-Keypad1-EXT 31.468_EN_V3_07/2013 Weatherproof (IP65) –30 to +60°C/–22 to +140°F The HiRes Video Company EN KeypadRFIDQuick Install www.mobotix.com HiRes Video Innovations The German company MOBOTIX AG is known as the leading pioneer in network camera technology and its decentralized concept has made high-resolution video systems cost-efficient. MOBOTIX AG • D-67722 Langmeil • Tel: +49 6302 9816-103 • Fax: +49 6302 9816-190 • [email protected] 2013 • Declaration of Conformity: www.mobotix.com > Support > MX Media Library > Certificates Copyright © MOBOTIX AG 2013 • Made in Germany • Technical information subject to change without notice. Operation: Keys and Signaling Leave a message (standard mailbox) 1 Press envelope key > welcome message plays > keep envelope key pressed and leave message Play back messages* 1 Hold up user card > keys 0 to 9 are blinking: 0 to 9 new messages > play back with key 0 to 9 Record new welcome message for mailbox* 1 Press OK/MENU and hold the key > hold up user card > press bell key > press bell key again > keep envelope key pressed and leave message > let go of envelope key > welcome message is activated 1 Only in combination with MOBOTIX IP Video Door Station. WelcomeMessage keep pressed hold Messages 09 Zutritts PIN OK hold keep pressed keep pressed Open door with blue user card Hold up user card > door is unlocked Open door with PIN code Enter PIN code > press key button > door is unlocked Open door on power failure (red LED is blinking) 2 Press ESC/ALARM (until illumination is on) > opening door with card or PIN is now possible for about 10 seconds 2 Only in combination with MOBOTIX DoorMaster. PIN code 09 Zutritts PIN keep pressed ESC hold (2nd beep) Technical Specifications InterfaceMxBus Inputs 2 galvanically separated inputs (AC/DC, self-powered, up to 50 V) Outputs 1 isolated relay output (AC/DC, up to 50 V/60 W/2 A) Protection classIP65 (DIN EN 60529) Operating temperature –30 to +60°C/–22 to +140°F (DIN EN 50125) Power SupplyMxBus Power consumptionTypically 1 W RFID cards: Type/ Encryption MIFARE DESFire EV1 3K3DES/AES Notes • Please follow the notes on installing and operating the device in the T24 System Manual (www.mobotix.com in the Support > Manuals section). This manual also contains wiring diagrams for the different scenarios. • The MOBOTIX KeypadRFID is only to be used in the original frames of the IP Video Door Station. • Before Installing, make sure that the seal on the back of the KeypadRFID has been properly attached. • When inserting the module into the frame, only press at the edges, never at the center of the module. • Make sure the device is not operated outside of its operating temperature range of –30 to +60°C/–22 to +140°F. • BellRFID and KeypadRFID can only be used on one MxBus with a later software version of the camera. 99 mm/3.9 in 99 mm/3.9 in MOBOTIX KeypadRFID Order no.: MX-Keypad1-EXT Open door, messages, doorbell Function keys 10-key keypad Admin card Order no.: MX-AdminCard1 (1 included) User card Order no.: MX-UserCard1 (5 included) MOBOTIX RFID cards Status LED OnNormal status OnDevice error BlinkingPower failure SealCove…

Text truncated - open the document above for the full version.

Test report no.: 1-5412/12-01-11-B_AnnexA 2013-07-12 Page 1 of 6 Annex A This test report annex is electronically signed and valid without handwriting signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report annex authorised: Stefan Bös Senior Testing Manager Test report no.: 1-5412/12-01-11-B_AnnexA 2013-07-12 Page 2 of 6 External photos of the EUT Photo documentation: Photo 1: Photo 2: Test report no.: 1-5412/12-01-11-B_AnnexA 2013-07-12 Page 3 of 6 Photo 3: Photo 4: Test report no.: 1-5412/12-01-11-B_AnnexA 2013-07-12 Page 4 of 6 Photo 5: Photo 6: Test report no.: 1-5412/12-01-11-B_AnnexA 2013-07-12 Page 5 of 6 Photo 7: Test report no.: 1-5412/12-01-11-B_AnnexA 2013-07-12 Page 6 of 6 Document history Version Applied changes Date of release 1.0 Initial release 2013-07-12

N N 2 2 3 3 4 4 5 5 6 6 7 7 8 8 D CC BB AA MOBOTIX:AG Kaiserstrasse 67722:Langmeil www.mobotix.com Germany KeypadNREXT N 22P/4P2/N3 Size Drawn0byDate Rev A4 Title MarcelmZimmer Tel::+49:6302:9816:0 Fax.::+49:6302:9816:190 MOBOTIX .com X Security0Vision0Systems mmUnitN:NScale LabelmLocation 総務省指定 第 XX-XXXXX 号 MIC KS N234567m|mMOBOTIXmAGm|mMXRKeypadNREXT 1234567 400mm 60mm FCCRID:mYYRKPADBICRID:m9357ARKPADB M9N:mKeypadRB N234567m|mMOBOTIXmAGm|mMXRKeypadNREXT 1234567 400mm 60mm FCCRID:mYYRKPADB ICRID:m9357ARKPADB M9N:mKeypadRB

Test report no.: 1-5412/12-01-11-B_AnnexB 2013-07-12 Page 1 of 4 Annex B This test report annex is electronically signed and valid without handwriting signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report annex authorised: Stefan Bös Senior Testing Manager Test report no.: 1-5412/12-01-11-B_AnnexB 2013-07-12 Page 2 of 4 Internal photos of the EUT Photo documentation: Photo 1: Photo 2: Test report no.: 1-5412/12-01-11-B_AnnexB 2013-07-12 Page 3 of 4 Photo 3: Test report no.: 1-5412/12-01-11-B_AnnexB 2013-07-12 Page 4 of 4 Document history Version Applied changes Date of release 1.0 Initial release 2013-07-12

2013-07-12 Page 1 of 24 TEST REPORT Test report no.: 1-5412/12-01-11-B Testing laboratory Applicant CETECOM ICT Services GmbH Untertuerkheimer Strasse 6 – 10 66117 Saarbruecken / Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 Internet: http://www.cetecom.com e-mail: [email protected] Accredited Testing Laboratory: The testing laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 (2005) by the Deutsche Akkreditierungsstelle GmbH (DAkkS) The accreditation is valid for the scope of testing procedures as stated in the accreditation certificate with the registration number: D-PL-12076-01-01 Area of Testing: Radio/Satellite Communications Mobotix AG Kaiserstr. 67722 Winnweiler / GERMANY Phone: +49 6302 9816-0 Contact: Thomas Kern e-mail: [email protected] Phone: +49 6302-9816-0 Manufacturer Mobotix AG Kaiserstr. 67722 Winnweiler / GERMANY Test standard/s 47 CFR Part 15 Title 47 of the Code of Federal Regulations; Chapter I Part 15 - Radio frequency devices RSS - 210 Issue 8 Spectrum Management and Telecommunications - Radio Standards Specification Low-power Licence-exempt Radiocommunication Devices (All Frequency Bands): Category I Equipment For further applied test standards please refer to section 3 of this test report. Test Item Kind of test item: RFID Reader Model name: Keypad-B FCC ID: YYRKPADB IC: 9357A-KPADB Frequency: 13.56 MHz Technology tested: RFID Antenna: Integrated loop antenna Power Supply: 48V DC by external power supply Temperature Range: -20°C to +55°C This test report is electronically signed and valid without handwriting signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report authorised: Test performed: p.o. Christoph Schneider Tobias Wittenmeier Expert Expert Test report no.: 1-5412/12-01-11-B 2013-07-12 Page 2 of 24 1 Table of contents 1 Table of contents ............................................................................................................................................ 2 2 General information ....................................................................................................................................... 3 2.1 Notes and disclaimer .......................................................................................................................... 3 2.2 Application details ............................................................................................................................... 3 3 Test standard/s ............................................................................................................................................... 3 4 Test environment ............................................................................................................................................ 4 5 Test item .......................................................................................................................................................... 4 6 Test laboratories sub-contracted ................................................................................................................. 4 7 Additional information ................................................................................................................................... 4 8 Summary of measurement results ............................................................................................................... 5 9 RF measurements .......................................................................................................................................... 6 9.1 Description of test setup .................................................................................................................... 6 9.1.1 Radiated measurements............................................................................................................. 6 9.2 AC conducted ...................................................................................................................................... 8 9.3 Conducted measurements ................................................................................................................. 9 9.4 Additional comments .......................................................................................................................... 9 9.5 RSP100 test report cover sheet / performance test data .............................................................. 10 10 Measurement results ............................................................................................................................ 11 10.1 Timing of the transmitter ............................................................................................................... 11 10.2 Field strength of the fundamental ................................................................................................ 12 10.3 99 % emission bandwidth ............................................................................................................. 13 10.4 Field strength of the harmonics and spurious ........................................................................... 14 10.5 Frequency tolerance ...................................................................................................................... 19 10.6 Conducted emissions < 30 MHz (AC line conducted) ................................................................ 20 11 Test equipment and ancillaries used for tests ................................................................................... 22 12 Observations ......................................................................................................................................... 22 Annex A Document history .......................................................................................................................... 23 Annex B Further information ............................................................…

Text truncated - open the document above for the full version.

Test report no.: 1-5412/12-01-11-B_AnnexC 2013-07-12 Page 1 of 6 Annex C This test report annex is electronically signed and valid without handwriting signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report annex authorised: Stefan Bös Senior Testing Manager Test report no.: 1-5412/12-01-11-B_AnnexC 2013-07-12 Page 2 of 6 Photographs of the test setup Photo documentation: Photo 1: Photo 2: Test report no.: 1-5412/12-01-11-B_AnnexC 2013-07-12 Page 3 of 6 Photo 3: Photo 4: Test report no.: 1-5412/12-01-11-B_AnnexC 2013-07-12 Page 4 of 6 Photo 5: Photo 6: Test report no.: 1-5412/12-01-11-B_AnnexC 2013-07-12 Page 5 of 6 Photo 7: Test report no.: 1-5412/12-01-11-B_AnnexC 2013-07-12 Page 6 of 6 Document history Version Applied changes Date of release 1.0 Initial release 2013-07-12
