YZHMDLNRF24L0102Module

User Manual Module MDL NRF24L01+ 02 Table of Contents Introduction ................................................................................................................................................... 1 List of Applicable FCC Rules ........................................................................................................................... 1 Allowable Antennas to Use with the SiP Module .......................................................................................... 3 Required Regulatory Wording for User Guide ............................................................................................... 3 FCC Compliance Information ..................................................................................................................... 4 Module Statement ..................................................................................................................................... 5 Module Integration Instructions .................................................................................................................... 5 Document History .......................................................................................................................................... 8 Introduction The MDL NRF24L01+ 02 Transceiver Module (the module) is a System in Package (SiP) module used to transmit and receive in the 2.4GHz band. The module has Nordic Semiconductor nRF24L01+ Single Chip 2.4GHz Transceiver on‐board to perform RF send and receive functions on the front end with a SPI interface and input/output buffers to communicate with a microprocessor. List of Applicable FCC Rules This module must comply with all guidelines specified for Single Modular Transmitters as defined by FCC 47 CFR § 15.212(a) (1): (a) Single modular transmitters consist of a completely self‐contained radiofrequency transmitter device that is typically incorporated into another product, host or device. Split modular transmitters consist of two components: a radio front end with antenna (or radio devices) and a transmitter control element (orspecific hardware on which the software that controls the radio operation resides). All single or split modular transmitters are approved with an antenna. All of the following requirements apply, except as provided in paragraph (b) of this section. (1) Single modular transmitters must meet the following requirements to obtain a modular transmitter approval. (i) The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. (ii) The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with part 15 requirements under conditions of excessive data rates or over‐modulation. (iii) The modular transmitter musthave its own power supply regulation. (iv) The modular transmitter must comply with the antenna and transmission system requirements of §§ 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of § 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. (v) The modular transmitter must be tested in a stand‐alone configuration, i.e., the module must not be inside another device during testingforcompliancewithpart15requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in § 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see § 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see § 15.31(i)). (vi) The modular transmitter must be equippedwith either a permanently affixed label or must be capable of electronically displaying its FCC identification number. (A) If using a permanently affixed label, themodular transmitter must be labeled with its own FCC identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: YZHMDLNRF24L0102” or “Contains FCC ID: YZHMDLNRF24L0102”. Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the lattercase, a copy of these instructions must be included in the application for equipment authorization. (B) If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronicdisplay. A copy of these instructions must be …

Text truncated - open the document above for the full version.

Raffel Systems, LLC Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020.08. 28 Subject; Request for Long Term Confidentiality FCC ID: YZHMDLNRF24L0102 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Edward Nowak Title: Electrical Engineer

Raffel Systems, LLC Agent Authorization Company: Raffel Systems, LLC Address: N112 W14600 Mequon Road, Germantown, Wisconsin 53022, United States Product Name: Module Model Number(s): MDL NRF24L01+ 02 Product Description: Module We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Date: 2020-08-28 Signature: Name: Edward Nowak Title: Electrical Engineer Company: Raffel Systems, LLC

Raffel Systems, LLC FCC Modular Approval Request Rev 3.0 Federal Communications Commission Equipment Authorization Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020-08-28 Subject; Modular Transmitter Application Company name: Raffel Systems, LLC FCC ID: YZHMDLNRF24L0102 Dear Sir/Madam, This letter includes the FCC application requirements for Modular Transmitter Approval Request for;- FCC KDB 996369 D01 ‘Module Certification Guide v02; and FCC KDB 996369 D03 OEM Manual v01 In accordance with 47CFR 15.212 Modular Transmitters and KDB 996369 D01 ‘Module Equip Auth Guide v02’. FCC ID: YZHMDLNRF24L0102 has been examined against the following requirements. Requirement per 15.212 and KDB 996369 D01 Explanation from Grantee (do not write yes/no, but explain why product complies/how it is achieved) The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly. The modular have RF own shielding The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal. The modular transmitter have buffered modulation/data inputs The module must contain power supply regulation on the module. The modular transmitter have its own power supply regulation. The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per §§ 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b). The modular has a 30mm Quarter Wave Monopole Wire Antenna which has a unique antenna connector. The module must demonstrate compliance in a stand-alone configuration. The module compliance in a stand-alone configuration. The module must be labeled with its permanently affixed FCC ID label, or use an electronic display (see KDB Publication 784748). The FCC identification number can put on the modular with either a permanently affixed label The module must comply with all specific rules applicable to the transmitter, including all the conditions provided in the integration instructions by the grantee. The instructions will be provided and apply to a complete transmitter and comply with specific rule. The module must comply with RF exposure requirements The total power density of modular transmitter final configuration comply with FCC RF Exposure Raffel Systems, LLC FCC Modular Approval Request Rev 3.0 Integration Instructions for host product manufacturers The following items are submitted in support of application for Modular Transmitter FCC ID as noted above as required by the FCC KDB 996369 D03 OEM Manual v01. These items are provided as integration instructions for host product manufacturers (e.g., OEM instruction manual) to use when integrating a module in a host product. Any requirements that are not applicable to the Module are as indicated below. Summary of requirements and Checklist.Refer to the KDB for description of the complete requirements; KDB Ref Sect Requirements of KDB 996369 D03 User Manual Page Number reference 2.2 List of applicable FCC rules Page 1 2 4 5 2.3 Summarize the specific operational use conditions Page 5 2.4 Limited module procedures Not compliance 2.5 Trace antenna designs Not compliance 2.6 RF exposure considerations Page 4 2.7 Antennas Page 6 2.8 Label and compliance information Page 2 2.9 Information on test modes and additional testing requirements Page 5 2.10 Additional testing, Part 15 Subpart B disclaimer Page 4 5 Date: 2020-08-28 Name: Edward Nowak Title: Electrical Engineer Signature of applicant

Page 1 of 1 Appendix B: Photographs of EUT Product: Module Model: MDL NRF24L01+ 02 External Photos

Label Artwork and Location Model: MDL NRF24L01+ 02 Label: Size: L*W=14*4.5mm FCC ID: YZHMDLNRF24L0102 Location

Page 1 of 1 Appendix B: Photographs of EUT Product: Module Model: MDL NRF24L01+ 02 Internal Photos Antenna

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID: YZHMDLNRF24L0102 Product: Module Model No.: MDL NRF24L01+ 02 Additional Model No.: N/A Trade Mark: N/A Report No.: TCT200730E014 Issued Date: Sep. 07, 2020 Issued for: Raffel Systems, LLC N112 W14600 Mequon Road, Germantown, Wisconsin 53022, United States Issued By: Shenzhen Tongce Testing Lab. 1B/F., Building 1, Yibaolai Industrial Park, Qiaotou, Fuyong, Baoan District, Shenzhen, Guangdong, China TEL: +86-755-27673339 FAX: +86-755-27673332 Note:This report shall not be reproduced except in full, without the written approval of Shenzhen Tongce Testing Lab. This document may be altered or revised by Shenzhen Tongce Testing Lab. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT200730E014 Page 2 of 32 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TABLE OF CONTENTS 1. Test Certification ................................................................................................... 3 2. Test Result Summary ........................................................................................... 4 3. EUT Description .................................................................................................... 5 4. General Information ............................................................................................. 7 4.1. Test Environment and Mode ........................................................................................... 7 4.2. Description of Support Units .......................................................................................... 7 5. Facilities and Accreditations ............................................................................. 8 5.1. Facilities...............................................................................................................................8 5.2. Location................................................................................................................................8 5.3. Measurement Uncertainty...............................................................................................8 6. Test Results and Measurement Data .............................................................. 9 6.1. Antenna Requirement ....................................................................................................... 9 6.2. Conducted Emission ...................................................................................................... 10 6.3. Radiated Emission Measurement ............................................................................... 14 6.4. 20dB Occupied Bandwidth ........................................................................................... 26 Appendix A: Photographs of Test Setup Appendix B: Photographs of EUT Report No.: TCT200730E014 Page 3 of 32 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. Test Certification Product:Module Model No.:MDL NRF24L01+ 02 Additional Model No.: N/A Trade Mark: N/A Applicant:Raffel Systems, LLC Address: N112 W14600 Mequon Road, Germantown, Wisconsin 53022, United States Manufacturer:Xiamen Wellness Technology Co., Ltd. Address:No.3 Houbin Road, Xiang'an District, Xiamen, China Date of Test:Jul. 31, 2020 – Sep. 07, 2020 Applicable Standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249 ANSI C63.10:2013 The above equipment has been tested by Shenzhen Tongce Testing Lab. and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Tested By:Date:Sep. 07, 2020 Brave Zeng Reviewed By: Date:Sep. 07, 2020 Beryl Zhao Approved By: Date:Sep. 07, 2020 Tomsin Report No.: TCT200730E014 Page 4 of 32 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary RequirementCFR 47 SectionResult Antenna Requirement§15.203PASS AC Power Line Conducted Emission §15.207PASS Field Strength of Fundamental §15.249 (a)PASS Spurious Emissions§15.249 (a) (d)/ §15.209PASS Band Edge§15.249 (d)/ §15.205PASS 20dB Occupied Bandwidth§15.215 (c)PASS Note: 1. Pass: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Report No.: TCT200730E014 Page 5 of 32 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. EUT Description Product:Module Model No.:MDL NRF24L01+ 02 Additional Model No.:N/A Trade Mark:N/A Hardware Version:REV A Software Version:V1.0 Operation Frequency:2404.6MHz - 2479.6MHz Number of Channel:76 Modulation Technology: GFSK Antenna Type:30mm Quarter Wave Monopole Wire Antenna Antenna Gain:5.19dBi Power Supply:DC 5V Note:The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. Report No.: TCT200730E014 Page 6 of 32 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Operation Frequency Each of Channel ChannelFrequencyChannelFrequencyChannelFrequencyChannelFrequency 0 2404.6MHz 19 2423.6MHz 38 2442.6MHz 57 2461.6MHz 1 2405.6MHz 20 2424.6MHz 39 2443.6MHz 58 2462.6MHz ... .................. ... 8 2412.6MHz 27 2431.6MHz 46 2450.6MHz 65 2469.6MHz 9 2413.6MHz 28 2432.6MHz 47 2451.6MHz 66 2470.6MHz ... .................. ... 17 2421.6MHz 36 2440.6MHz 55 2459.6MHz 74 2478.6MHz 18 2422.6MHz 37 2441.6MHz 56 2460.6MHz 75 2479.6MHz Note: In section 15.31(m), regards to the operating frequency range over 10 MHz,the Lowest frequency, the middle frequency, and the h…

Text truncated - open the document above for the full version.

Page 1 of 2 Appendix A: Photographs of Test Setup Product: Module Model: MDL NRF24L01+ 02 Radiated Emission Page 2 of 2 CE
