YZHWCPBA01Embedded Wireless Charger

Manual Product Instruction For your safety, please read this manual carefully before using this product. First: In order to prevent injury or damage to property, please strictly comply with the following guidelines: A) Warning! It may cause serious injuries or even casualties. People should consult the doctor before using implantable medical devices (such as using pacemaker). Please install your equipment 50 centimeters away from this product because it may influence the operation of implantable medical device. B) Attention! It may cause fever, fire and electric shock. 1) Do not put the product in water or other liquids, avoid water into the product; 2) Do not touch the AC adapter with wet hands to ensure the safety and integrity of the adapter 3) Do not let dust accumulate on this product and adapter 4) Do not use this product under ambient -10 degree C and over 40 degree C.; 5) Do not use it in the places of direct sunlight or high temperature; 6) Do not use the product where is slippery to avoid break down. 7) Do not charge too close to magnetic sheets, magnetic recording media and precision instruments 8) Do not decompose and transform this product 9) Do not put anything between the wireless charging transmitter board and the charging mobile phone 10) When using plugs and other connections, do not exceed the rated value 11) When using, please make sure that you have connected the AC adapter correctly to avoid any damage. Unplug AC adapter from plug when stopping using it. 12) Do not use travel converters 13) Do not let your children use it until they know how to use it. Second: Charging method of wireless charging The product can be embedded in office furniture and sofa armrests. Diagram for using and installing: 1) Connect the product to an adapter that with the characteristics of “ 40 degree C max. and altitude of operation at 2000m whose output meets ES1, and rated "5 Vdc 2A" or “9 Vdc 1.65A” or “12 Vdc 1.2A”only and marked LPS”, blue and green lights will alternately flicker when power is turned on; 2) If the wireless charging product detects that there is no equipment to be charged in the charging area, the product will be on standby. 3) Place the equipment (mobile phone) that needs to be charged in the charging area of the product, the green light is on; then the blue light will be on when it enters charging condition. 4) After charging, the product is standby, the blue light is on, then take it away. 5) If there is a metal thing in the charging area (the center of the coil), blue and green light flicker alternately and will disconnect wireless charging to protect equipment Third: Product parameter: P/N: WCP XXXX 01 and WCP XXXX 01-YY Product name: Embedded wireless charger Dimension: outer diameter is 92mm,inner diameter is 57mm,and height is 30mm Weigth: 55 g Main function: Wireless charging launcher Product application: All wireless charging devices under QI standard Charging type: One-to-one charging in corresponding area Input voltage: DC 2A/5V，DC 1.65A/9V，DC 1.2A/12V； Launch distance: 2-6mm Charging power: Input：5V/2A，Output：5W(Max)； Input：9V/1.65A，Output：10W(Max)； Input：12V/1.2A，Output：10W(Max)； Conversion efficiency：＞70% Charging way: Induction mode Working frequency: 110.5—148KHz FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference. (2)This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipmemt does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC RF Exposure Statement This equipment complied with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 cm between the device and your body.

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process : Company Name: Raffel Systems, LLC FRN:0020284428 Contact Name: Edward A Nowak Address:N112 W14600 Mequon Road, Germantown, WI 53022 Telephone No: 2625021011-1013 Email:[email protected] Applicant: Company name:Raffel Systems, LLC Product Description: Embedded Wireless Charger FRN:0020284428 Grantee code:YZH FCC ID:YZHWCPBA01 Contact Name: Edward A Nowak Address:N112 W14600 Mequon Road, Germantown, WI 53022 Telephone No:2625021011-1013 Email:[email protected] [Raffel Systems, LLC] certifies that, as of the date of this filing of the application with the TCB, [Raffel Systems, LLC] is our designated US agent for service of process for the above referenced FCC ID. [Raffel Systems, LLC] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [Raffel Systems, LLC accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2024/04/28 Applicant’s Name: Edward A Nowak US Agent’s Name: Edward A Nowak Title: Electrical Engineer Title: Electrical Engineer SignatureSignature

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Raffel Systems, LLC Grantee code: YZH FCC ID:YZHWCPBA01 Contact Name: Edward A Nowak Address:N112 W14600 Mequon Road, Germantown, WI 53022 Telephone No: 2625021011-1013 Fax No:2625021010 Email:[email protected] i.[Raffel Systems, LLC] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii.[Raffel Systems, LLC] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [ Raffel Systems, LLC ] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List as an entity producing “covered” equipment. Date: 2023-04-28 Applicant’s Name: Edward A Nowak Title: Electrical Engineer Signature: 1 The Commission’sCovered Listis published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment.https://www.fcc.gov/supplychain/coveredlist

Raffel Systems, LLC Product Similarity Declaration Product name: Embedded Wireless Charger Model name: WCP XXXX 01, WCP XXXX 01-YY, WCP XXXX 02, WCP XXXX 02-YY (Where XXXX represents casing surface finish, X may be A-Z or blank. Where YY represents the lengthen of power input cord (less than 2m) and type of power input connector, Y may be 0-9 or blank.) FCC ID: YZHWCPBA01 We (Raffel Systems, LLC) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), the only differences are model number, appearance design, casing surface finish, indicator light, the lengthen of power input cord (less than 2m) and type of power input connector due to trading purpose. (if any difference). Demonstrate the detail (descriptions and pictures) as to the difference list above. Model Number: WCP XXX 01, WCP XXX 01-YY WCP XXX 02, WCP XXX 02-YY Appearance Design: The lengthen of power input cord 0.3m 0.2m Signature: Name: Edward A Nowak Title: Electrical Engineer Place, date Raffel Systems, LLC / 2024-05-06

C5266091_X8_Ed.1 1/1 Letter of Authorization Company:Raffel Systems, LLC Address:N112 W14600 Mequon Road, Germantown, WI 53022 Product Name:Embedded Wireless Charger Model Number:WCP XXXX 01, WCP XXXX 01-YY, WCP XXXX 02, WCP XXXX 02-YY FCC Identifier:YZHWCPBA01 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name:Edward A Nowak Date: 04/28/2024 Title:Electrical Engineer Signature of applicant:

C5266091_X10_Ed.1 1/1 Raffel Systems, LLC Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 04/28/2023 Subject: Request for Confidentiality FCC ID: YZHWCPBA01 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. ExhibitsLong-Term Confidentiality Short-Term Confidentiality ID Label/LocationNoNo Attestation StatementNoNo External PhotosNo Block Diagram Schematics Test ReportNoNo Test Setup PhotosNo User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s)NoNo SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Edward A Nowak Title: Electrical Engineer

FCC ID: YZHWCPBA01 External photos M/N: WCP XXXX 01 FCC ID: YZHWCPBA01 FCC ID: YZHWCPBA01 M/N: WCP XXXX 02 FCC ID: YZHWCPBA01 FCC ID: YZHWCPBA01

Input:5Vdc 2A,Output:5W Max Input:9Vdc 1.65A,Output:10W MaxInput:12Vdc 1.2A,Output:10W Max P/N:WCP XXXX 01FCC ID:YZHWCPBA01 Made in China PO XXXX MM/YY This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1.This device may not cause harmful interference, and 2.This device must accept any interference received, lncluding interference that may cause undesired operation. LABEL Input:5Vdc 2A,Output:5W Max Input:9Vdc 1.65A,Output:10W MaxInput:12Vdc 1.2A,Output:10W Max FCC ID:YZHWCPBA01 P/N:WCP XXXX 02 Made in China PO XXXX MM/YY This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1.This device may not cause harmful interference, and 2.This device must accept any interference received, lncluding interference that may cause undesired operation. LABEL

FCC ID: YZHWCPBA01 Internal photos M/N: WCP HCP 01 RF Chip FCC ID: YZHWCPBA01 RF Coil FCC ID: YZHWCPBA01 FCC ID: YZHWCPBA01 FCC ID: YZHWCPBA01 M/N: WCP BL 02 FCC ID: YZHWCPBA01 RF Chip FCC ID: YZHWCPBA01 RF Coil

Report No.: NTC2404195F-1 Dongguan Nore Testing Center Co., Ltd. Address: Building D, Gaosheng Science and Technology park, Hongtu road, Nancheng dist rict, Dongguan city, Guangdong province, China Web: www.ntc-c.com Tel:+86-769-2202 2444 Fax:+86-769-2202 2799 Page 1 of 17 RF EVALUATION TEST REPORT Applicant.......................... : Raffel Systems, LLC Address............................ : N112 W14600 Mequon Road Germantown, WI 53022 Manufacturer..................... : Xiamen Raffel Electronic Technology Co., LTD Address............................ : Room 1902, Tianshou Operations Center, NO.5 Yilan Road, Guanyinshan CBD Siming District, Xiamen, Fujian, China Factory............................. : Fortress Electronics (Xiamen) Co., LTD Address........................... : East Of The Fifth Floor, 181 Banqiao Road, Jimei District, Xiamen, Fujian, China Product Name................... : Embedded Wireless Charger Brand Name...................... : Raffel Systems Model No. ........................ : WCP XXXX 01, WCP XXXX 01-YY, WCP XXXX 02, WCP XXXX 02-YY (For model difference re fers to section 2.) FCC ID........................... .. : YZHWCPBA01 Measurement Standard....... : 47 CFR PART 2, Section 2.1091 Receipt Date of Samples.... : April 13, 2024 Date of Tested.................. : April 13, 2024 to April 18, 2024 Date of Report.................. : April 29, 2024 This report shows that above equipment is technically compliant with the requirements of the standards above. All test results in this report apply only to the tested sample(s). Without prior written approval of Dongguan Nore Testing Center Co., Ltd, this report shall not be reproduced except in full. Prepared by Jenny Liu / Project Engineer Approved by Iori Fan / Authorized Signatory Report No.: NTC2404195F-1 Page 2 of 17 Table of Contents 1. General Description of EUT ............................................................................................................................... 4 2. Test Facility and Location .................................................................................................................................. 6 3. Test Modes Detail .............................................................................................................................................. 7 4. Configuration of EUT .......................................................................................................................................... 7 5. Modification of EUT ............................................................................................................................................ 7 6. Description of Support Device............................................................................................................................ 8 7. Deviations and Abnormalities from Standard Conditions .................................................................................. 8 8. Applicable Standards and References............................................................................................................... 8 9. Measurement Uncertainty .................................................................................................................................. 9 10. Maximum Permissible Exposure .................................................................................................................... 10 11. Test Equipment List ....................................................................................................................................... 14 12. Test Photos .................................................................................................................................................... 15 Report No.: NTC2404195F-1 Page 3 of 17 Revision History Report Number Description Issued Date NTC2404195F-1 Initial Issue 2024-04-29 Report No.: NTC2404195F-1 Page 4 of 17 1. General Description of EUT Product Information Product Name: Embedded Wireless Charger Main Model Name: WCP XXXX 01 Additional Model Name: WCP XXXX 01-YY, WCP XXXX 02, WCP XXXX 02-YY (Where XXXX represents casing surface finish, X may be A-Z or blank. Where YY represents the lengthen of power input cord (less than 2m) and type of power input connector, Y may be 0-9 or blank.) Model Difference: These models have the same circuit schematic, construction, and critical components. The difference s are model number, appearance design, casing surface finish, indicator light, the lengthen of power input cord and type of power input connector due to trading purpose. S/N: 2404-1819~1820 Brand Name: Raffel Systems Hardware Version: Not stated Software Version: Not stated Rating: DC 5V 2A, 5W DC 9V 1.65A, 10W DC 12V 1.2A, 10W Typical Arrangement: Table-top I/O Port: Refer to user manual Accessories Information Cable: DC Line: 0.30m, unshielded, undetachable Other: N/A Additional Information Note: According to the model difference and the requirements of the manufacturer, all tests were performed on model WCP HCP 01, WCP BL 02. Both of two models have been tested but only model WCP HCP 01 was exhibited in report. Remark: All the information above are provided by the manufacturer. More detailed feature of the EUT please refers to the user manual. Report No.: NTC2404195F-1 Page 5 of 17 Technical Specification Frequency Range: 110.5-148KHz Modulation Type: FSK Antenna Type: Coil antenna Output power for coil: 5W, 10W Report No.: NTC2404195F-1 Page 6 of 17 2. Test Facility and Location Test Site : Dongguan Nore Testing Center Co., Ltd. (Dongguan NTC Co., Ltd.) Accreditations and Authorizations : The Laboratory has been assessed and proved to be in compliance with CNAS/CL01 Listed by CNAS, August 13, 2018 The Certificate Registration Number is L5795. The Certificate is valid until August 13, 2024 The Laboratory has been assessed and proved to be in compliance with ISO17025 Listed by A2LA, November 01, 2017 The Certificate Registration Number is 4429.01 Li…

Text truncated - open the document above for the full version.

Page1 of 4 DongguanFANYAElectronicsCo.,LTD 东莞市泛亚电子有限公司TEL：0769-22490287FAX：0769-22499451FY-GZ001 承認書 SPECIFICATIONFORAPPROVAL 客戶： CUSTOMER: N041 客戶料號： CUSTP/N: 泛亞料號： FINEP/N: 産品型號： DESC: FYN04112024042301S 日期： DATE: 2024/04/23 版本： Version: A.0 擬制 PREPAREDBY 審核 CHECKEDBY 批准 APPROVEDBY 客戶承認 CUSTOMERAPPROVE 尹艺王镇生蔡纪雨 东莞市泛亚电子有限公司 DongguanFANYAElectronicsCo.,LTD 公司地址：东莞市石碣镇刘屋科技东路194号 TEL：0769-22490287/22452492 FAX：0769-22499451 E-mail：[email protected] Page2 of 4 DongguanFANYAElectronicsCo.,LTD 东莞市泛亚电子有限公司TEL：0769-22490287FAX：0769-22499451FY-GZ001 版本變更履歷 VersionChangeHistory 版本 Rev. 變更前 BeforeChange 變更後 AfterChange 更改日期 ChangeDate 批准 ApprovedBy A.0 新发行 ----2024/04/23 蔡纪雨 Page3 of 4 DongguanFANYAElectronicsCo.,LTD 东莞市泛亚电子有限公司TEL：0769-22490287FAX：0769-22499451FY-GZ001 SPECIFICATION 産品型號： DESC FYN04112024042301S 版本 Rev：A.0 客戶CUST:N041 泛亚料号FineP/N： 客户料号CUSTP/N: 一、尺寸DIMENSION:(mm) 二、原理图SCHEMATICDIAGRAM: A 40.5±1.0 B 20.5±0.5 C 1.25Max D 45±1.5 E 2-4 F 50±1 G 5.3±0.5 H 2.4Max （不含离型纸及引线) 注： 1.线圈交叉出线； 2.线圈出线位置贴8mm宽高 温胶； 3.线圈反贴硬磁片，硬磁片 尺寸φ50*5.3*1.0mm，开孔开 L双线槽； 4.磁片背面贴φ 48*6*0.08mm开孔带手撕位普 通双面背胶。 三、绕线参数WindingSpecification: 序号 NO. 端子 TERMINAL 线径 WIRE 圈数 Turns 绕线方向 WindingDirection 1SF丝包线0.078*105P10TsCCW 四、电气特性ELECTRICALCHARACTERISTICS: 温度TEMPERATURE:25±10°C,湿度RELATIVEHUMIDITY:65±20% 序号 NO. 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TESTFREQUENCY 测试仪器 TESTEQUIPMENTS 1IND.S-F6.5uH±10%100KHz/1.0V TH2829LX 2 DCRS-F60mΩMax @25°CTH2829LX 擬制 / 日期 PREPAREDBY/DATE 審核 / 日期 CHECKEDBY/DATE 尹艺 2024/04/23 蔡纪雨 2024/04/23 Page4 of 4 DongguanFANYAElectronicsCo.,LTD 东莞市泛亚电子有限公司TEL：0769-22490287FAX：0769-22499451FY-GZ001 SPECIFICATION 産品型號： DESC FYN04112024042301S 版本 Rev：A.0 客戶CUST:N041 泛亚料号FineP/N： 客户料号CUSTP/N: 五、包装PACKING: 5.1包装图片Packingpictures: 5.2包装数量及规格PackingQuantity: 5.3包装以现有包装盘为参照标准，以实际出货包装为准,如有特需要求可以定制。 Thepackagingshallbebasedontheexistingpackingplateandtheactualdeliverypackageshallprevail.If thereisanyrequirement,wecancustomizeit. 六、材料清单Materiallist: 序号 number 材料名称 Materialname 品名描述 Description 制造商 Manufacturer 1 丝包线0.078*105P丝包线0.078*105P 2 无铅锡条无铅锡条 3 磁片Φ50*5.3*1.0mm，开孔开L双线槽 4 高温胶8mm宽的高温胶 5 普通背胶Φ48*6*0.08mm开中孔带手撕位普通背胶 项目Item数量Quantity材料规格Material 盘Box 200Pcs370*265*55mm 箱BigCarton 1000Pcs420*270*310mm 擬制/日期 PREPAREDBY/DATE 審核/日期 CHECKEDBY/DATE 尹艺2024/04/23蔡纪雨2024/04/23

Report No.: NTC2404195FV00 Dongguan Nore Testin g Center Co., Ltd. Address: Building D, Gaosheng Science and Technology park, Hongtu road, Nancheng district, Dongguan city, Guangdong province , China Web: www.ntc-c.com Tel:+86- 769- 2202 2444 Fax:+86-769-2202 2799 Page 1 of 30 FCC RADIO TEST REPORT Applicant.......................... : Raffel Systems, LLC Address............................ : N112 W14600 Mequon Road Germantown, WI 53022 Manufacturer..................... : Xiamen Raffel Electronic Technology Co., LTD Address........................... : Room 1902, Tianshou Operations Center, NO.5 Yilan Road, Guanyinshan CBD, Siming District, Xiamen, Fujian, China Factory............................. : Fortress Electronics (Xiamen) Co., LTD Address........................... : East Of The Fifth Floor, 181 Banqiao R oad, Jimei District, Xiamen, Fujian, China Product Name................... : Embedded Wireless Charger Brand Name...................... : Raffel Systems Model No. ........................ : WCP XXXX 01, WCP XXXX 01-YY, WCP XXXX 02, WCP XXXX 02-YY (For model dif ference refers to section 2.) FCC ID............................. : YZHWCPBA01 Measurement Standard....... : 47 CFR FCC Part 15, Subpart C Receipt Date of Samples...... : April 13, 2024 Date of Tested.................. : April 13, 2024 to April 18, 2024 Date of Report.................. : April 29, 2024 This report shows that above equipment is technically compliant with the requirements of the standards above. All test results in this report apply only to the tested sample(s). Without prior written approval of Dongguan Nore Testing Center Co., Ltd, this report shall not be reproduced except in full. Prepared by Jenny Liu / Project Engineer Approved by Iori Fan / Authorized Signatory Report No.: NTC2404195FV00 Page 2 of 30 Table of Contents 1. Summary of Test Result ...................................................................................................................................... 4 2. General Description of EUT ................................................................................................................................ 5 3. Test Channels and Modes Detail ........................................................................................................................ 7 4. Configuration of EUT ........................................................................................................................................... 7 5. Modification of EUT ............................................................................................................................................. 7 6. Description of Support Device ............................................................................................................................. 8 7. Test Facility and Location ................................................................................................................................... 9 8. Applicable Standards and References .............................................................................................................. 10 9. Deviations and Abnormalities from Standard Conditi ons ................................................................................. 10 10. Test Conditions ............................................................................................................................................... 10 11. Measurement Uncertainty ............................................................................................................................... 11 12. Sample Calculations ....................................................................................................................................... 12 13. Test Items and Results ................................................................................................................................... 13 13.1 Conducted Emissions Measurement ....................................................................................................................................... 13 13.2 Radiated Spurious Emissions and Restricted Bands Measurement ........................................................................................ 17 13.3 20dB Bandwidth Measurement................................................................................................................................................ 27 13.4 Antenna Requirement .............................................................................................................................................................. 29 14. Test Equipment List......................................................................................................................................... 30 Report No.: NTC2404195FV00 Page 3 of 30 Revision History Report Number Description Issued Date NTC2404195FV00 Initial Issue 2024-04-29 Report No.: NTC2404195FV00 Page 4 of 30 1. Summary of Test Result FCC Rules Description of Test Result Remarks §15.207 (a) AC Power Conduct ed Emission PASS --- §15.209 Radiated Emissions PASS --- §15.215(c) 20dB Bandwidth PASS --- §15.203 Antenna Requirement PASS --- Report No.: NTC2404195FV00 Page 5 of 30 2. General Description of EUT Product Information Product Name: Embedded Wireless Charger Main Model Name: WCP XXXX 01 Additional Model Name: WCP XXXX 01-YY, WCP XXXX 02, WCP XXXX 02-YY (Where XXXX represents casing surface finish, X may be A-Z or blank. Where YY represents the lengthen of power input cord (less than 2m) and type of power input connector, Y may be 0-9 or blank.) Model Difference: These models have the same circuit schematic, construction, and critical components. The differences are model number, appearance design, casing surface finish, indicator light, the lengthen of power input cord and type of power input connector due to trading purpose. S/N: 2404-1819~1820 Brand Name: Raffel Systems Hardware Version: Not stated Software Version: Not st…

Text truncated - open the document above for the full version.

FCC ID: YZHWCPBA01 Test Photo Radiated emission (Below 30MHz) Radiated emission (30-1000MHz) FCC ID: YZHWCPBA01 Conducted Emission
