Z6X-N550580MineCast RF Video System

1 Table of Contents Disclaimer...................................................................................................................................................... 2 Description .................................................................................................................................................... 4 1. Overview ................................................................................................................................................... 4 2. Required Tools & Components ................................................................................................................. 5 3. Connection Overview ................................................................................................................................ 5 4. Power and Ground Connections ............................................................................................................... 6 5. Pan-Based Camera Control and Signal Logic ............................................................................................. 6 Control Signal Overview ............................................................................................................................ 6 Connection Instructions ............................................................................................................................ 7 Latched Panning Behavior ........................................................................................................................ 7 6. Mounting & Cable Routing ........................................................................................................................ 7 Steer Angle Sensor Installation ................................................................................................................. 7 Alignment: ................................................................................................................................................. 7 Pedestal Mounting .................................................................................................................................... 8 Cable Management Best Practices ........................................................................................................... 8 7. Pedestal Dimensions ................................................................................................................................. 9 8. Steer Angle Sensor Dimension .................................................................................................................. 9 9. Camera positioning and Field of view (FOV) ........................................................................................... 10 10. Monitor Operation ................................................................................................................................ 12 Powering On............................................................................................................................................ 12 Battery Power ......................................................................................................................................... 12 Integrated Stand ..................................................................................................................................... 12 11. Lens Replacement Procedure ............................................................................................................... 13 Tools Required .................................................................................................................................. 13 Step-by-Step Instructions ................................................................................................................. 13 1. Power Down the System ........................................................................................................... 13 2. Remove Top Cap Bolts ............................................................................................................... 13 3. Lift Top Cap Carefully ................................................................................................................. 13 4. Remove Old Lens ....................................................................................................................... 13 5. Inspect and Reinstall/Replace O-Rings ...................................................................................... 13 6. Insert New Lens ......................................................................................................................... 13 7. Reinstall Top O-Ring .................................................................................................................. 13 2 8. Replace Top Cap ........................................................................................................................ 14 9. Reinstall and Torque Bolts ......................................................................................................... 14 10. Final Check ............................................................................................................................ 14 12. Replacing the Antenna .......................................................................................................................... 15 Tools Required .................................................................................................................................. 15 Step-by-Step Instructions........................................................................................................................ 16 1. Power Down the System ........................................................................................................... 16 2. Remove Clamping Block Bolts ................................................................................................... 16 3. Disconnect the N-Type Connector ........................................…

Text truncated - open the document above for the full version.

(Minewise Technology Ltd.) (2026.1.12) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for(FCC ID: Z6X-N550580) [Minewise Technology Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, (Applicant signature) (Applicant printed name) Everett James Henderson (Minewise Technology Ltd.) (2026.1.12) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for(FCC ID: Z6X-N550580) [Minewise Technology Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Everett James Henderson

Rev 1/26/2023 Minewise Technology Ltd. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 1-13-2026 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID ：Z6X-N550580 Applicant FRN: 0021242169 [Minewise Technology Ltd.] certifies that, as of the date of the filing of the application, [FCC US Agent, LLC] is our designated U.S. agent for service of process for the above referenced FCC ID. [Minewise Technology Ltd.] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. [FCC US Agent, LLC] accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Company Name: FCC US Agent, LLC FRN: 0033402884 Address: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA Contact Person: Tim Payne Phone: 708-571-3148 Email: [email protected] Sincerely, [申请商] Minewise Technology Ltd. FCC US Agent, LLC [联系人] Everett James Henderson Tim Payne

Minewise Technology Ltd. 2026.1.12 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR EUT NAME: MineCast RF Video System MODEL : N55-0580 FCC ID: Z6X-N550580 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : Everett James Henderson / Technical Manager Contact information / address: 162 MacKenzie St, Sudbury, ON P3C 4X8, Canada

Minewise Technology Ltd. 2026.1.12 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION EUT NAME: MineCast RF Video System MODEL : N55-0580 FCC ID: Z6X-N550580 To Whom It May Concern: We, the undersigned, hereby authorize SHENZHEN STS TEST SERVICES CO., LTD to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : Everett James Henderson / Technical Manager Contact information / address: 162 MacKenzie St, Sudbury, ON P3C 4X8, Canada

External Photos Antenna

Size:25*10mm FCC ID: Z6X-N550580 Label location Size:25*10mm Model: A1104 IC : 20208-A1103 FCC ID: 2AD99-A1103 Label location

Internal Photos

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. MPE Report Report No.: STS2512373H01 Issued for Minewise Technology Ltd. 162 MacKenzie St, Sudbury, ON P3C 4X8, Canada Product Name: MineCast RF Video System Brand Name: Model Name: N55-0580 Series Model(s): N/A FCC ID: Z6X-N550580 Test Standard: FCC 47CFR §2.1091 Page 2 of 8 Report No.: STS2512373H01 TEST REPORT Applicant’s Name ................. : Minewise Technology Ltd. Address ................................. : 162 MacKenzie St, Sudbury, ON P3C 4X8, Canada Manufacturer's Name ........... : Minewise Technology Ltd. Address ................................. : 162 MacKenzie St, Sudbury, ON P3C 4X8, Canada Product Description Product Name ........................ : MineCast RF Video System Brand Name .......................... : Model Name .......................... : N55-0580 Series Model(s) ...................... : N/A Test Standards ..................... : FCC 47CFR §2.1091 447498 D01 Interim General RF Exposure Guidance v06 The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ...................... : 22 Nov. 2025 Date (s) of performance of tests ............. : 22 Nov. 2025 to 22 Dec. 2025 Date of Issue .......................................... : 22 Dec. 2025 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 8 Report No.: STS2512373H01 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 6 2. FCC 47CFR §2.1091 REQUIREMENT 7 2.1 TEST STANDARDS 7 2.2 LIMIT 7 2.3 TEST RESULT 8 Page 4 of 8 Report No.: STS2512373H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 22 Dec. 2025 STS2512373H01 ALL Initial Issue Page 5 of 8 Report No.: STS2512373H01 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name MineCast RF Video System Brand Name Model Name N55-0580 Series Model(s) N/A Model Difference N/A Product Description The EUT is a MineCast RF Video System Operation Frequency: 908-921 MHz Modulation Type: LoRa Number Of Channel: 3 Antenna Type: External antenna Antenna Gain (dBi) 8.55 Power Rating 9-36V Adapter N/A Battery N/A Hardware Version N/A Software Version N/A Page 6 of 8 Report No.: STS2512373H01 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 7 of 8 Report No.: STS2512373H01 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm²) Limits for Occupational / controlled Exposures 300 - 1500 -- -- F/300 3.0-30 1842/f 4.89/f *(900/f²) 1500 – 100000 -- -- 5.0 Limits for General population / Uncontrolled Exposure 300 - 1500 -- -- F/1500 1.34-30 824/f 2.19/f *(180f²) 1500 – 100000 -- -- 1.0 F= Frequency in MHz Friss Formula Friss Transmission Formula: Pd = (Pout * G) / (4*pi*r²) Where Pd = power density in mW/cm² Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = Distance between observation point and the center of radiator in cm If we know the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know MPE value at distance 20cm. Page 8 of 8 Report No.: STS2512373H01 2.3 TEST RESULT Tune up Mode Detector Tune up Power GFSK AV 22±1dBm Note: 1. The Maxinum power is less than the limit, complies with the exemption requirements. 2. The Bluetooth and WLAN can’t simultaneous transmission at the same time. 3. ERP = EIRP - 2.15 ※※※※※END OF THE REPORT※※※※※ Protocol Fre. (GHz) Separati on distance (cm) Max Tune up power (dBm) ANT Gain (dBi) Max EIRP (dBm) Max EIRP (mW) Power Density (mW/cm²) Limit (mW/ cm²) Ratio Result GFSK 0.908 20 23 8.55 31.55 1429 0.2843 0.6 0.2843 Pass

INFRASTRUCTURE ANTENNAS PC TEL’s BMOY yagis have been optimized using a genetic algorithm to achieve superior performance over the entire 800/900 MHz and UHF frequency bands. These antennas feature solid 3/8” elements attached to a seamless aluminum boom with 360° welds, and are finished with a black polyester powder coating. Each antenna has a type N termination located at the end of the boom, with a fully sealed driven element for complete protection against humidity, acid rain, or salt spray. A solid aluminum mounting bracket allows for either vertical or horizontal polarization. The BMOY’s sturdy construction and advanced engineering design provides outstanding durability and superior performance in all weather conditions. Features •Br oadband performance covering all 800/900 MHz frequencies and no tuning required. Provides optimal performance, minimizes inventory requirements, and reduces installation time. •360° welds at element and boom interface provide complete protection of the antenna’s internal mechanism against moisture. •Solid aluminum mounting clamps with stainless steel hardware. Ensures a robust installation and allows the antenna to be mounted for horizontal or vertical polarization. • End-f ed type N connector. Makes connector accessible for easier installations and protects the electrical connection from moisture and other extreme weather influences. • F ully enclosed low loss feed system. No exposed gamma match to corrode or deteriorate. •Black polyester powder-coated finish. Provides an added layer of protection, maximizing performance and durability under the toughest weather conditions. •DC grounded Black Optimized Yagi Antennas, No Tune BMOY Series W elded Yagi, 400 MHz & 900 MHz ELECTRICAL SPECIFICATIONS - RF ANTENNA M odel Frequency Range Gain Bandwidth @ 1.5:1 VSWR Azimuth Half Power Beamwidth Elevation Half Power Beamwidth Front to Back Ratio Maximum Power Nominal Impedance BMOY4065406-440 MHz11.15dBi34 MHz52°45°> 15 dB150 watts50 ohms BMOY4405440-480 MHz11.15dBi40 MHz52°45°> 15 dB150 watts50 ohms BMOY4705470-512 MHz11.15dBi42 MHz52°45°> 15 dB150 watts50 ohms BMOY8905890-960 MHz11.15dBi70 MHz52°45°> 15 dB150 watts50 ohms BMOY8903890-960 MHz8.55dBi70 MHz100°54°> 20 dB150 watts50 ohms STANDARD CONFIGURATION ModelCableConnectorElementsMount BMOY4065 Mating cable assembly sold separately (all models) N Female5 BWC1001 Clamp bracket for 1/2"-7/8" diameter yagis. Mounts to masts 1.25"-2.4" OD (included with all models) BMOY4405N Female5 BMOY4705N Female5 BMOY8905N Female5 BMOY8903N Female3 BMO Y4065 BMOY8905 BMOY8903 B WC1001 mount R oHS COMPLIANT www.Talleycom.com | [email protected] | 800.949.7079 PCTEL, Inc. 471 Brighton Dr.Bloomingdale Illinois 60108,USA INFRASTRUCTURE ANTENNAS PCTEL, Inc. WEB: www.antenna.com ENVIRONMENTAL SPECIFICATIONS ModelWind Load RatingESD Protection BMOY4065wind survival: 200 mph with no ice. It will survive up to 110 mph with 0.5” radial ice build-up.DC grounded BMOY4405wind survival: 200 mph with no ice. It will survive up to 110 mph with 0.5” radial ice build-up.DC grounded BMOY4705wind survival: 200 mph with no ice. It will survive up to 110 mph with 0.5” radial ice build-up.DC grounded BMOY8905wind survival: 200 mph with no ice. It will survive up to 110 mph with 0.5” radial ice build-up.DC grounded BMOY8903wind survival: 200 mph with no ice. It will survive up to 110 mph with 0.5” radial ice build-up.DC grounded MECHANICAL SPECIFICATIONS ModelDimensionsWeightRadiator Material BMOY4065Boom Length: 34”, Boom Diameter: .75”2 lbs (0.91 kg)3/8” solid 6061-T6 aluminum BMOY4405Boom Length: 34”, Boom Diameter: .75”2 lbs (0.91 kg)3/8” solid 6061-T6 aluminum BMOY4705Boom Length: 34”, Boom Diameter: .75”2 lbs (0.91 kg)3/8” solid 6061-T6 aluminum BMOY8905Boom Length: 20.5”, Boom Diameter: .75”0.9 lbs (0.41 kg)3/8” solid 6061-T6 aluminum BMOY8903Boom Length: 14”, Boom Diameter: .75”0.7 lbs (0.32 kg)3/8” solid 6061-T6 aluminum MECHANICAL SPECIFICATIONS Model Bending Moment @ 125 mph Wind Lateral Thrust @ 125 mph Wind Equivalent Flat Plate Area Boom Length Boom Diameter BMOY406532.4 ft-lbs24.2 lbs.31 sq ft34”.75” BMOY440532.4 ft-lbs24.2 lbs.31 sq ft34”.75” BMOY470532.4 ft-lbs24.2 lbs.31 sq ft34”.75” BMOY89059.5 ft-lbs12.6 lbs.16 sq ft20.5”.75” BMOY89033.9 ft-lbs7.9 lbs.10 sq ft14”.75” Black Optimized Yagi Antennas, No Tune BMOY Series Welded Yagi, 400 MHz & 900 MHz RoHS COMPLIANT INFRASTRUCTURE ANTENNAS Black Optimized Yagi Antennas Radiation Pattern PCTEL, Inc. WEB: www.antenna.com 10 190 20 200 30 210 40 220 50 230 60 240 70 250 80 260 90 270 100 280 110 290 120 300 130 310 140 320 150 330 160 340 170 350 1800 −20−20−15−15−10−10−5−500551010 10 190 20 200 30 210 40 220 50 230 60 240 70 250 80 260 90 270 100 280 110 290 120 300 130 310 140 320 150 330 160 340 170 350 1800 −20−20−15−15−10−10−5−500551010 BMOY8905 Elevation Cut BMOY8903 Elevation Cut BMOY8905 Azimuth Cut BMOY8903 Azimuth Cut 10 190 20 200 30 210 40 220 50 230 60 240 70 250 80 260 90 270 100 280 110 290 120 300 130 310 140 320 150 330 160 340 170 350 1800 −35−35−30−30−25−25−20−20−15−15−10−10−5−5 10 190 20 200 30 210 40 220 50 230 60 240 70 250 80 260 90 270 100 280 110 290 120 300 130 310 140 320 150 330 160 340 170 350 1800 −35−35−30−30−25−25−20−20−15−15−10−10−5−5 AA BB 1 1 2 2 3 3 4 4 SEE COMPONENT PRINTS SEE COMPONENT PRINTS IP MATERIAL: CHECKED DRAWN FINISH: 8/25/2016 DATE BMOY8903 PCTEL, INC. 471 BRIGHTON DRIVE BLOOMINGDALE, IL 60108 PH. 630-372-6800 FAX. 630-372-8077 B SCALE SHEET 1 OF 1 DRAWING NO. DESCRIPTION 1:2 8/25/2016 SIZE FOR TOLERANCES NOT SPECIFIED USE: UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN MILLIMETERS CE [X.X mm B.3 mm] ANGULARB 1` DATE [X mm B3 mm] [ X.XX mm B.13 mm] OPT, YAGI, 890-960 MHz, 5 ELEMENT, 8.55dBi THE INFORMATION AND/OR DRAWINGS CONTAINED IN THIS DOCUMENT IS CONFIDENTIAL AND PROPRIETARY TO PCTEL, INC. AND MAY NOT BE USED, REPRODUCED, IN WHOLE OR IN PART, OR MODIFIED IN ANY WAY WITHOUT THE EXPRESS WRITTEN PERMISSION OF AN AUTHORIZED REPRESENTATI…

Text truncated - open the document above for the full version.

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.: STS2512373W01 Issued for Minewise Technology Ltd. 162 MacKenzie St, Sudbury, ON P3C 4X8, Canada Product Name: MineCast RF Video System Brand Name: Model Name: N55-0580 Series Model(s): N/A FCC ID: Z6X-N550580 Test Standards: FCC Part15.247 Page 2 of 44 Report No.: STS2512373W01 TEST REPORT Applicant’s Name ................. : Minewise Technology Ltd. Address ................................. : 162 MacKenzie St, Sudbury, ON P3C 4X8, Canada Manufacturer's Name .......... : Minewise Technology Ltd. Address ................................. : 162 MacKenzie St, Sudbury, ON P3C 4X8, Canada Product Description Product Name ....................... : MineCast RF Video System Brand Name .......................... : Model Name .......................... : N55-0580 Series Model(s) .................... : N/A Standards ............................. : FCC Part15.247 Test Procedure ...................... : ANSI C63.10-2020 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ..................... : 22 Nov. 2025 Date (s) of performance of tests ............. : 22 Nov. 2025 to 22 Dec. 2025 Date of Issue .......................................... : 22 Dec. 2025 Test Result.............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 44 Report No.: STS2512373W01 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 11 2.6 EQUIPMENTS LIST 12 RF RADIATION TEST EQUIPMENT 12 3. EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.2 TEST PROCEDURE 14 3.3 TEST SETUP 14 3.4 EUT OPERATING CONDITIONS 14 3.5 TEST RESULTS 14 4. RADIATED EMISSION MEASUREMENT 15 4.1 RADIATED EMISSION LIMITS 15 4.2 TEST PROCEDURE 18 4.3 TEST SETUP 19 4.4 EUT OPERATING CONDITIONS 19 4.5 FIELD STRENGTH CALCULATION 20 4.6 TEST RESULTS 21 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 27 5.1 LIMIT 27 5.2 TEST PROCEDURE 27 5.3 TEST SETUP 27 5.4 EUT OPERATION CONDITIONS 27 5.5 TEST RESULTS 27 6. POWER SPECTRAL DENSITY TEST 28 6.1 LIMIT 28 6.2 TEST PROCEDURE 28 Page 4 of 44 Report No.: STS2512373W01 Table of Contents Page 6.3 TEST SETUP 28 6.4 EUT OPERATION CONDITIONS 28 6.5 TEST RESULTS 28 7. BANDWIDTH TEST 29 7.1 LIMIT 29 7.2 TEST PROCEDURE 29 7.3 TEST SETUP 29 7.4 EUT OPERATION CONDITIONS 29 7.5 TEST RESULTS 29 8. PEAK OUTPUT POWER TEST 30 8.1 LIMIT 30 8.2 TEST PROCEDURE 30 8.3 TEST SETUP 31 8.4 EUT OPERATION CONDITIONS 31 8.5 TEST RESULTS 31 9. ANTENNA REQUIREMENT 32 9.1 STANDARD REQUIREMENT 32 9.2 EUT ANTENNA 32 APPENDIX 1-TEST DATA 33 APPENDIX 2- EUT TEST PHOTO 44 Page 5 of 44 Report No.: STS2512373W01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 22 Dec. 2025 STS2512373W01 ALL Initial Issue Page 6 of 44 Report No.: STS2512373W01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- Note: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. Page 7 of 44 Report No.: STS2512373W01 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.751dB 2 Unwanted Emissions, conducted ±2.888dB 3 All emissions, radiated 9K-30MHz ±2.48dB 4 All emissions, radiated 30M-1GHz ±2.52dB 5 All emissions, radiated 1G-18GHz ±3.48dB 6 All emissions, radiated>18GHz ±4.18dB 7 Conducted Emission (9KHz-150KHz) ±2.48dB 8 Conducted Emission (150KHz-30MHz) ±2.52dB 9 Occupied Channel Bandwidth ±3.6% 10 Power Spectral Density, conducted ±1.214dB 11 Duty Cycle ±3.2% Page 8 of 44 Report No.: STS2512373W01 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name MineCast RF Video System Brand Name Model Name N55-0580 Series Model(s) N/A Model Difference N/A Product Description The EUT is a MineCast RF Video System Operation Frequency: 908-921 MHz Modulation Type: GFSK Number Of Channel: 3 Antenna Type: External antenna Antenna Gain (dBi) 8.55 Channel List Please refer to the Note 3. Power Rating 9-36V Adapter N/A Battery N/A Hardware version number N…

Text truncated - open the document above for the full version.

Page 1 of 1 FCC ID:Z6X-N550580 30MHz-1GHz Spurious emissions
