Z7ZMAXMEDIAWIFI2WLAN 11n Dual Band Dongle

IEEE802.11a/b/g/n WLANClient Adapter USER’S GUIDE VERSION 1.0 © All rights reserved. All trade names are registered trademarks of respective manufacturers listed. This manual may not be copied in any media or form withou tthe written consent of original maker. 1. Introduction ..................................................................... 1 2. Wireless LAN Basics ............................................................ 3 3. IP ADDRESS ........................................................................ 4 4. Install Driver/Utility ............................................................. 5 4.1 Windows XP/Vista/7................................................... 5 5. Wireless Network Configuration ............................................ 7 5.1 Utility Icon .............................................................. 7 5.2 Client Mode (Default Setting)........................................ 7 6. Technical Specifications ................................................... 14 7. Troubleshooting .............................................................. 16 8. Glossary ....................................................................... 17 1 Thank you for your purchase of the WLAN Adapter. Featuring wireless technology, this wireless networking solution has been designed for both large and small businesses, and it is scalable so that you can easily add more users and new network features depending on your business scale. FEATURES � Support Microsoft XP(32bit/64bit) / Vista(32bit/64bit) / 7(32bit/64bit) � Operating distance of up to 300 meters in free space. � 300/270/240/180/120/90/60/54/48/36/30/24/22/18/12/11/6/5.5/2/1 Mbps selectable Data Rate according to client adapter default antennas. � 64/128-bit WEP , WPA, WPA2, WPS � 2.400GHz ~ 2.4835GHz unlicensed ISM Frequency Band. Modulation Method. 5GHz UNII, Midband, ISM bands. � IEEE 802.11b : DSSS (Direct Sequence Spread Spectrum). � IEEE 802.11a/g n : OFDM (Orthogonal Frequency Division Multiplexing). � Easy operation and setting up. SYSTEM REQUIREMENTS Windows System : XP(32bit/64bit) / Vista(32bit/64bit) / 7(32bit/64bit).PCs must have a device driver installed. It allows you to communicate with WLAN 11n USB Client Adapter. 2 BEFORE YOU START 1. Confirm Box Contents � WLAN 11n USB Client Adapter � Quick Start Guide � Driver CD CONNECTING YOUR WLAN 11n USB Client Adapter TO PC Quick Start Guide Connect your WLAN 11n USB Client Adapter to your PC. Install driver. GETTING TO KNOW WIRELESS LAN ADAPTER LED Status � ON – Adapter connects to remote. � BLINKING - WLAN Adapter is active. 3 Wireless LAN network defined by IEEE 802.11a/b/g standard committee could be configured as : Ad Hoc wireless LAN. Infrastructure wireless LAN. Ad Hoc network is a group of PCs installed with wireless LAN cards, this group of PCs is called a BSS (Basic Service Set). PCs in this group can use their wireless LAN cards to communicate with each other, but can not connect to the Internet. Ad HocWireless NetworkInfrastructureWireless Network The most obvious difference between Infrastructure wireless network and Ad Hoc wireless network is that the PCs in Infrastructure wireless network can access the resource in the Internet through Access Point. Depending on your requirement, you can easily set up your PC’s network to be a “Ad Hoc” or “Infrastructure” wireless network. Generally speaking, if in your network, there is an Access Point in it, we recommend you to set your network as an “Infrastructure”, so it can connect to the Internet. 4 To use the WLAN 11n USB Client Adapter with a computing device, the WLAN Adapter must be equipped with a proper Interface. All drivers and supporting software for the WLAN Adapter must be installed and configured first. Ask your system administrator for the following information, which you may need to provide during driver installation : � Your Wireless Client Name. � Your Wireless SSID. � Your computer’s unique client name and workgroup name. For your network account, your user name and password. � Your IP address, gateway address, and subnet mask if you’re not using a DHCP client. Any computer on a network is identified by a unique network address. There are two methods to assign a network address to a computer on a TCP/IP network : � Static IP addressing. � Dynamic IP addressing (DHCP Client). In network with static IP addressing, the network administrator manually assigns an IP address to each computer. Once a static IP address is assigned, a computer uses the same IP address every time it reboots and logs on to the network. You may manually change the IP address in the Network Properties dialog box. Network using static IP address is easy to set up and do not require additional network management software . In network with dynamic IP addressing, a DHCP server in the network dynamically assigns IP addresses to all clients every time they log on to the network. Network using dynamic IP address requires setting up and running a DHCP Server. 5 The installation& driver CD will automatically activate the autorun installation program after you insert the disk into your CD drive. Step 1 : Insert the installation CD into your CD-ROM. Choose the Setup Language and click Nextbutton. Step 2 : Installation descriptions shown. Click Nextto continue. Click Installto begin the installation 6 Installing & configuring WLAN utility Installing Drivers. Step 3 : ClickFinishto complete installation 7 WLAN 11n USB Client Adapter uses its own management software. All functions controlled by users are provided by this application. When you insert the WLAN Adapter into your laptop or desktop, a icon should appear in the Windows System Tray automatically. 5.1 Utility Icon ▓ Client mode utility running but no WLAN Adapter plugged ▓Client mode utility running and WLAN Adapter scan available network. ▓Client mode utility running and WLAN Adapter can not scan any AP 5.2 Client Mode (Default Setting) Wireless Device Control : ▓Show T…

Text truncated - open the document above for the full version.

Maxmedia Technology Limited

CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued Date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-8200 Page No. : A1 of A3 Appendix A. Photographs of EUT

Label and Label Location Label content: model: WL-6210-V3 FCC ID: Z7ZMAXMEDIAWIFI2

CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued Date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-8200 Page No. : A2 of A3 CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued Date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-8200 Page No. : A3 of A3

MPE Calculation FCC ID: Z7ZMAXMEDIAWIFI2 Typical use distance: d ≥ 20 cm Power density limit for mobile devices at 2.4 and 5 GHz: S ≤ 1 mW/cm 2 Remark: Average ≤ Peak, which means that calculating the power density applying Peak power is worst case. The worst case operation mode generating the highest power in each frequency range is taken for calculation. For DTS: Frequency range: 2412-2462MHz Frequency range: 2422-2452MHz Frequency range: 5745-5825MHz Frequency range: 5755-5755MHz The highest peak power measured in all these bands is 19.88 dBm, and we take this value as worst case for calculation. The antennas used in these bands are 0 dBi, 4.2 dBi, and 3.6 dBi, and 6.91 for n mode (see RF report). We take the worst case for calculation. We combine both worst case valuse to prove the device stays in any case under the limit. Note that the calculated radiated powers may not exist in reality, but they indicate compliance to the limit only: Maximum measured conducted power (Peak): P conducted = 19.88 dBm Antenna Gain: G = 6.91 dBi Calculation: P radiated = P conducted + G linear = 19.88 dBm + 6.91 dBi = 26.97 dBm = 477.53 mW Power density S = (P radiated ) / (4π x d 2 ) =0.096 mW/cm 2 which is below limit, pass. For UNI: Frequency range: 5180-5240MHz Frequency range: 5190-5230MHz The highest peak power measured in all these bands is 19.88 dBm, and we take this value as worst case for calculation. The antennas used in these bands are 0 dBi, 4.2 dBi, and 3.6 dBi, and 6.91 for n mode (see RF report). We take the worst case for calculation. We combine both worst case valuse to prove the device stays in any case under the limit. Note that the calculated radiated powers may not exist in reality, but they indicate compliance to the limit only:: Maximum measured conducted power (Peak): P conducted = 9.08 dBm Antenna Gain: G = 6.91 dBi Calculation: P radiated = P conducted + G linear = 9.08 dBm + 6.91 dBi = 15.99 dBm = 39.72 mW Power density S = (P radiated ) / (4π x d 2 ) =0.0079 mW/cm 2 which is below limit, pass. Remark: this card cannot transmit simultaneously in more than one band.

CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-8200 Page No. : 1 of 215 FCC ID : Z7ZMAXMEDIAWIFI2 FCC TEST REPORT According to FCC Rules and Regulations Part 15 Subpart C Applicant : MaxMedia Technology Limited Address : 5F., No. 113, Jian 2nd Rd., Zhonghe Dist., New Taipei City 235, Taiwan (R.O.C.) Equipment : WLAN 11n Dual Band Dongle Model No. : WL-6210-V3 Trade Name : MaxMedia FCC ID : Z7ZMAXMEDIAWIFI2  The test result refers exclusively to the test presented test model / sample.,  Without written approval of Cerpass Technology Corp., the test report shall not be reproduced except in full.  The EUT is also considered as a kind of computer peripheral, because the connection to computer is necessary for typical use. It has been verified to comply with the requirements of FCC Part 15, Subpart B, Class B (DoC). The test report has been issued separately. CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-8200 Page No. : 2 of 215 FCC ID : Z7ZMAXMEDIAWIFI2 Contents 1. Report of Measurements and Examinations .................................................................................... 6 1.1 List of Measurements and Examinations ................................................................................... 6 2. Test Configuration of Equipment under Test ................................................................................... 7 2.1 Feature of Equipment under Test ............................................................................................... 7 2.2 Carrier Frequency of Channels .................................................................................................. 8 2.3 Test Mode and Test Software ..................................................................................................... 9 2.4 Description of Test System ....................................................................................................... 10 2.5 General Information of Test ...................................................................................................... 11 2.6 Measurement Uncertainty ........................................................................................................ 11 3. Antenna Requirements ..................................................................................................................... 12 3.1 Standard Applicable ................................................................................................................. 12 3.2 Antenna Construction and Directional Gain ............................................................................. 12 4. Test of Conducted Emission ............................................................................................................ 13 4.1 Test Limit .................................................................................................................................. 13 4.2 Test Procedures ....................................................................................................................... 13 4.3 Typical Test Setup .................................................................................................................... 14 4.4 Measurement Equipment ......................................................................................................... 14 4.5 Test Result and Data ................................................................................................................ 15 4.6 Test Photographs ..................................................................................................................... 27 5. Test of Radiated Emission ............................................................................................................... 28 5.1 Test Limit .................................................................................................................................. 28 5.2 Test Procedures ....................................................................................................................... 28 5.3 Typical Test Setup .................................................................................................................... 29 5.4 Measurement Equipment ......................................................................................................... 29 5.1 Test Result and Data (9kHz ~ 30MHz) ..................................................................................... 30 5.2 Test Result and Data ................................................................................................................ 30 5.3 Test Photographs (30MHz~1000MHz) ..................................................................................... 94 5.4 Test Photographs (1000MHz~40000MHz) ............................................................................... 95 6. 6dB Bandwidth Measurement Data ................................................................................................. 96 6.1 Test Limit .................................................................................................................................. 96 6.2 Test Procedures ....................................................................................................................... 96 6.3 Test Setup Layout .................................................................................................................... 96 6.4 Measurement Equipment ......................................................................................................... 96 6.5 Test Result and Data ................................................................................................................ 97 7. Maximum Peak and Average Output Power ................................................................................. 118 7.1 Test Limit ........…

Text truncated - open the document above for the full version.

CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-8200 Page No. : 84 of 215 FCC ID : Z7ZMAXMEDIAWIFI2 Power : From System Pol/Phase : VERTICAL Test Mode 5 : 802.11an HT20, CH165 Temperature : 25 °C Memo : Humidity : 67 % CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-8200 Page No. : 85 of 215 FCC ID : Z7ZMAXMEDIAWIFI2 Power : From System Pol/Phase : HORIZONTAL Test Mode 5 : 802.11an HT20, CH165 Temperature: 25 °C Memo : Humidity : 67 % CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-8200 Page No. : 86 of 215 FCC ID : Z7ZMAXMEDIAWIFI2 Power : From System Pol/Phase : VERTICAL Test Mode 6 : 802.11an HT40, CH151 Temperature : 24 °C Memo : Humidity : 62 % CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-8200 Page No. : 87 of 215 FCC ID : Z7ZMAXMEDIAWIFI2 Power : From System Pol/Phase : VERTICAL Test Mode 6 : 802.11an HT40, CH151 Temperature : 24 °C Memo : Humidity : 62 % CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-8200 Page No. : 88 of 215 FCC ID : Z7ZMAXMEDIAWIFI2 Power : From System Pol/Phase : HORIZONTAL Test Mode 6 : 802.11an HT40, CH151 Temperature : 24 °C Memo : Humidity : 62 % CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-8200 Page No. : 89 of 215 FCC ID : Z7ZMAXMEDIAWIFI2 Power : From System Pol/Phase : HORIZONTAL Test Mode 6 : 802.11an HT40, CH151 Temperature : 24 °C Memo : Humidity : 62 % CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-8200 Page No. : 90 of 215 FCC ID : Z7ZMAXMEDIAWIFI2 Power : From System Pol/Phase : VERTICAL Test Mode 6 : 802.11an HT40, CH151 Temperature : 25 °C Memo : Humidity : 67 % CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-8200 Page No. : 91 of 215 FCC ID : Z7ZMAXMEDIAWIFI2 Power : From System Pol/Phase : HORIZONTAL Test Mode 6 : 802.11an HT40, CH151 Temperature : 25 °C Memo : Humidity : 67 % CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-8200 Page No. : 92 of 215 FCC ID : Z7ZMAXMEDIAWIFI2 Power : From System Pol/Phase : VERTICAL Test Mode 6 : 802.11an HT40, CH159 Temperature : 25 °C Memo : Humidity : 67 % CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-8200 Page No. : 93 of 215 FCC ID : Z7ZMAXMEDIAWIFI2 Power : From System Pol/Phase : HORIZONTAL Test Mode 6 : 802.11an HT40, CH159 Temperature : 25 °C Memo : Humidity : 67 % CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-8200 Page No. : 96 of 215 FCC ID : Z7ZMAXMEDIAWIFI2 6. 6dB Bandwidth Measurement Data 6.1 Test Limit The minimum of 6dB Bandwidth Measurement is 0.5 MHz. 6.2 Test Procedures a. The transmitter output was connected to the spectrum analyzer. b. Set RBW of spectrum analyzer to 1~5% of the emission bandwidth and VBW ≥ 3x RBW. c. The 6 dB bandwidth is defined as the total spectrum the power of which is higher than peak power minus 6 dB. d. The 6dB Bandwidth was measured and recorded. 6.3 Test Setup Layout 6.4 Measurement Equipment Instrument/Ancillary Manufacturer Model No.Serial No.Calibration Date Valid Date Spectrum Analyzer R&S FSP40 100219 2011/11/24 2012/11/23 CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-8200 Page No. : 97 of 215 FCC ID : Z7ZMAXMEDIAWIFI2 6.5 Test Result and Data Test Date: Jun. 25, 2012 Temperature: 25°C Atmospheric pressure: 1020 hPa Humidity: 65% Modulation Standard Channel Frequency (MHz) 6dB Bandwidth (MHz) ANT A ANT B 802.11b (11Mbps) 01 2412 10.4 10.4 06 2437 10.8 10.9 11 2462 11.0 10.4 802.11g (54Mbps) 01 2412 16.7 16.7 06 2437 16.8 16.7 11 2462 16.7 16.7 802.11n HT20 (130Mbps) 01 2412 17.8 18.1 06 2437 17.9 18.0 11 2462 17.9 18.1 802.11n HT40 (270Mbps) 03 2422 36.6 36.6 06 2437 36.6 36.4 09 2452 36.6 36.6 Test Date: Jun. 28, 2012 Temperature: 25°C Atmospheric pressure: 1020 hPa Humidity: 65% Modulation Standard Channel Frequency (MHz) 6dB Bandwidth (MHz) ANT R ANT L 802.11a (54Mbps) 149 5745 16.7 16.7 157 5785 16.7 16.8 165 5825 16.7 16.8 802.11an HT20 (130Mbps) 149 5745 17.9 18.1 157 5785 17.9 18.0 165 5825 17.9 18.0 802.11n HT40 (270Mbps) 151 5755 36.8 36.6 159 5795 36.8 36.6 CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-8200 Page No. : 98 of 215 FCC ID : Z7ZMAXMEDIAWIFI2 Modulation Standard: 802.11b (11Mbps), ANT A Channel: 01 Modulation Standard: 802.11b (11Mbps), ANT A Channel: 06 CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-8200 Page No. : 99 of 215 FCC ID : Z7ZMAXMEDIAWIFI2 Modulation Standard: 802.11b (11Mbps), ANT A Channel: 11 Modulation Standard: 802.11g (54Mbps), ANT A Channel: 01 CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-8200 Page No. : 100 of 215 FCC ID : Z7ZMAXMEDIAWIFI2 Modulation Standard: 802.11g (54Mbps), ANT A Channel: 06 Modulation Standard: 802.11g (54Mbps), ANT A Channel: 11 CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-820…

Text truncated - open the document above for the full version.

CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-8200 Page No. : 25 of 213 FCC ID : Z7ZMAXMEDIAWIFI2 4.6 Test Photographs Front View Rear View CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-8200 Page No. : 92 of 213 FCC ID : Z7ZMAXMEDIAWIFI2 5.3 Test Photographs (30MHz~1000MHz) Front View Rear View CERPASS TECHNOLOGY CORP. Report No.: TEFI1202096 Cerpass Technology Corp. Issued date : Jul. 19, 2012 Tel:886-2-2655-8100 Fax:886-2-2655-8200 Page No. : 93 of 213 FCC ID : Z7ZMAXMEDIAWIFI2 5.4 Test Photographs (1000MHz~40000MHz) Front View Rear View
