Chapter 3: Operation494 AttributeMeaning RF uinThis field indicates the number of unicast packets received by the bridge control block on the radio interface RF uoutThis field indicates the number of unicast packets sent by the bridge control block on the radio interface RF utossThis field indicates the number of unicast packets tossed by the bridge control block on the radio interface RF utosscapThis field indicates the number of unicast packets tossed out at the radio interface due to MIR cap being exceeded. Bridge Error Stats ErrNI1QSendThis field indicates that a packet which was sourced from the radio network stack interface 1 (Ethernet interface) could not be sent because the radio bridge queue was full. The packet was tossed out. ErrNI2QSendThis field indicates that a packet which was sourced from the radio network stack interface 2 (RF interface) could not be sent because the radio bridge queue was full. The packet was tossed out. ErrBridgeFullThis field indicates the total number of times the bridging table was full and could not accept new entries. ErrSendMsgThis field displays the error message from bridge core call back routine. ErrApFecQSendThis field indicates that a packet which was received on the Ethernet interface could not be processed because the radio bridge queue was full and packet was tossed out. ErrApRfQSendThis field indicates that a packet which was received on the RF interface could not be processed because the radio bridge queue was full. The packet was tossed out. Interpreting Pass Through Statistics The Statistics > Pass Through Statistics page displays radius related statistics. The page is applicable for PMP 450 Platform Family - AP only. The Pass Through Statistics page is explained in below table. Chapter 3: Operation495 Table 147: Pass Through Statistics page attributes – AP AttributeMeaning IdentityReqSentThis field indicates the number of EAP Identity requests sent through the AP with respect to an SM. PktsEncapsulated This field indicates no of packets received from the SM which are encapsulated by the AP. PktsDecasulatedThis field indicates no of packets received from the radius server and are decapsulated by the AP with respect to an SM AccessAcceptRcvd This field indicates no of RADIUS Access Accept message received by the AP with respect to an SM. Interpreting SNMPv3 Statistics The Statistics > SNMPv3 Statistics page displays all SNMPv3 related statistics. The page is applicable for all type of ODUs of PMP 450 Platform. The SNMPv3 Statistics page is explained in below table. Chapter 3: Operation496 Table 148: SNMPv3 Statistics page attributes – AP AttributeMeaning Statistics for snmpMPDStats groupSNMP Message Processing and Dispatching RFC 3412 snmpUnknownSecurityModelsThe total number of packets received by the SNMP engine which were dropped because they referenced a securityModel that was not known to or supported by the SNMP engine. snmpInvalidMsgsThe total number of packets received by the SNMP engine which were dropped because there were invalid or inconsistent components in the SNMP message. Chapter 3: Operation497 AttributeMeaning snmpUnknownPDUHandlersThe total number of packets received by the SNMP engine which were dropped because the PDU contained in the packet could not be passed to an application responsible for handling the pduType, e.g. no SNMP application had registered for the proper combination of the contextEngineID and the pduType. usmStatsUnsupportedSecLevelsThe total number of packets received by the SNMP engine which were dropped because they requested a securityLevel that was unknown to the SNMP engine or otherwise unavailable. usmStatsNotInTimeWindowsThe total number of packets received by the SNMP engine which were dropped because they appeared outside of the authoritative SNMP engine's window. usmStatsUnknownUserNamesThe total number of packets received by the SNMP engine which were dropped because they referenced a user that was not known to the SNMP engine. usmStatsUnknownEngineIDsThe total number of packets received by the SNMP engine which were dropped because they referenced a snmpEngineID that was not known to the SNMP engine. usmStatsWrongDigestsThe total number of packets received by the SNMP engine which were dropped because they didn't contain the expected digest value. usmStatsDecryptionErrorsThe total number of packets received by the SNMP engine which were dropped because they could not be decrypted. snmpTargetSpinLockThis object is used to facilitate modification of table entries in the SNMP-TARGET-MIB module by multiple managers. snmpUnavailableContextsThe total number of packets received by the SNMP engine which were dropped because the context contained in the message was unavailable. snmpUnknownContextsThe total number of packets received by the SNMP engine which were dropped because the context contained in the message was unknown. usmUserSpinLockThe use of usmUserSpinlock is to avoid conflicts with another SNMP command generator application which may also be acting on the usmUserTable. Chapter 3: Operation498 AttributeMeaning vacmViewSpinLockAn advisory lock used to allow cooperating SNMP Command Generator applications to coordinate their use of the Set operation in creating or modifying views. snmpEngineBootsIt is a count of the number of times the SNMP engine has re-booted/re-initialized since snmpEngineID was last configured snmpEngineTime time since engine is upwhich is the number of seconds since the snmpEngineBoots counter was last incremented Interpreting syslog statistics The Statistics > Syslog Statistics page displays statistics of syslog messages. The page is applicable for all modules (AP/SM/BHM/BHS). The Syslog Statistics page is explained in below table. Table 149: Syslog statistics page attributes – AP/SM/BH AttributeMeaning Syslog ServerThis displays dotted decimal or DNS name (if the DNS is enabled) of the syslog server address. Syslog Server PortThe syslog server port (default 514)…

Text truncated - open the document above for the full version.

Chapter 1: Configuration242 Radio page - PMP 450 AP 3.5 GHz Figure 35:PMP 450 AP Radio attributes - 3.5 GHz Chapter 1: Configuration243 AttributeMeaning See PMP/PTP 450i Series – Configuring Radio for all parameters details. Note The PMP 450 AP supports up to 119 Data Channels (instead of 238 Data Channels) when configured for 30 MHz channel bandwidth or 5 ms Frame Period. This limitation is not applicable for PMP 450i/450m Series. Radio page - PMP 450 AP 2.4 GHz Table 58: Table 64 PMP 450 AP Radio attributes - 2.4 GHz Chapter 1: Configuration244 AttributeMeaning See PMP/PTP 450i Series – Configuring Radio for all parameters details. Note The PMP 450 AP supports up to 119 Data Channels (instead of 238 Data Channels) when configured for 30 MHz channel bandwidth or 5 ms Frame Period. This limitation is not applicable for PMP 450i/450m Series. Chapter 1: Configuration245 Radio page - PMP 450 SM 5 GHz Table 59: PMP 450 SM Radio attributes – 5 GHz Chapter 1: Configuration246 AttributeMeaning Custom Radio Frequency Scan Selection List Check the frequencies that SM has to scan for AP transmissions. See Radio Frequency Scan Selection List See PMP 450i SM Radio attributes – 5 GHz Note The frequencies that a user can select are controlled by the country or a region and the Channel Bandwidth selected. There can be a case where a user adds a custom frequency (from the Custom Frequencies page ) and cannot see it in the pull down menu. Chapter 1: Configuration247 Radio page - PMP 450 SM 3.65 GHz Table 60: PMP 450 SM Radio attributes – 3.65 GHz Chapter 1: Configuration248 AttributeMeaning Custom Radio Frequency Scan Selection List Check the frequencies that SM has to scan for AP transmissions. See Radio Frequency Scan Selection List See PMP 450i SM Radio attributes – 5 GHz Note The frequencies that a user can select are controlled by the country or a region and the Channel Bandwidth selected. There can be a case where a user adds a custom frequency (from the Custom Frequencies page ) and cannot see it in the pull down menu. Radio page - PMP 450 SM 3.5 GHz Table 61: PMP 450 SM Radio attributes – 3.5 GHz Chapter 1: Configuration249 AttributeMeaning Custom Radio Frequency Scan Selection List Check the frequencies that SM has to scan for AP transmissions. See Radio Frequency Scan Selection List See PMP 450i SM Radio attributes – 5 GHz Note The frequencies that a user can select are controlled by the country or a region and the Channel Bandwidth selected. There can be a case where a user adds a custom frequency (from the Custom Frequencies page ) and cannot see it in the pull down menu. Chapter 1: Configuration250 Radio page - PMP 450 SM 2.4 GHz Table 62: PMP 450 SM Radio attributes – 2.4 GHz Chapter 1: Configuration251 AttributeMeaning Custom Radio Frequency Scan Selection List Check the frequencies that SM has to scan for AP transmissions. See Radio Frequency Scan Selection List See PMP 450i SM Radio attributes – 5 GHz Radio page - PMP 450 SM 900 MHz Table 63: PMP 450 SM Radio attributes –900 MHz Chapter 1: Configuration252 AttributeMeaning Custom Radio Frequency Scan Selection List See PMP 450i SM Radio attributes – 5 GHz. Channel Bandwidth Scan Cyclic Prefix AP Selection Method Color Code 1 Installation Color Code Large Data Channel data Q Color Code MIMO Rate Adapt Algorithm Downlink Maximum Modulation Rate Uplink Maximum Modulation Rate Nomadic Mode External Gain Enable Max Tx Power Reference Downlink EVM Current Downlink EVM Reference Uplink EVM Current Uplink EVM Access Point MAC Address Channel Frequency Channel Bandwidth Receive Quality Debug Chapter 1: Configuration253 Radio page - PTP 450 BHM 5 GHz Table 64: PTP 450 BHM Radio attributes –5 GHz AttributeMeaning Refer PTP 450i BHM Radio page attributes – 5 GHz for all parameters details. Chapter 1: Configuration254 Radio page - PTP 450 BHS 5 GHz Table 65: PTP 450 BHS Radio attributes –5 GHz Chapter 1: Configuration255 AttributeMeaning Refer PTP 450i BHS Radio attributes – 5 GHz for all parameters details. Note The PMP 450 AP supports up to 119 Data Channels (instead of 238 Data Channels) when configured for 30 MHz channel bandwidth or 5 ms Frame Period. This limitation is not applicable for PMP 450i/450m Series. Radio Frequency Scan Selection List The SM or BHS scans complete spectrum as per Full Spectrum Band Scan feature. SMs or BHS first boot into the smallest selected channel bandwidth (10 MHz, if selected) and scan all selected frequencies across both the 5.4 GHz and 5.7 GHz frequency bands. After this scan, if a wider channel bandwidth is selected (20 MHz), the SM/BHS automatically changes to 20 MHz channel bandwidth and then scans for APs/BHSs. After the SM/BHS finishes this final scan it will evaluate the best AP/BHM with which to register. If required for registration, the SM/BHS changes its channel bandwidth back to 10 MHz to match the best AP/BHM. Chapter 1: Configuration256 The SM/BHS will attempt to connect to an AP/BHM based on power level (which affects the modulation state), channel bandwidth (which affects throughput) and number of SM/BHS registrations to the AP/BHM (which affects system contention performance). If it is desired to prioritize a certain AP/BHM over other available APs/BHMs, operators may use the Color Code Priority feature on the SM/BHS. Utilization of the Color Code feature on the AP/BHM is recommended to further constrain the AP selection. If the SM does not find any suitable APs/BHMs for registration after scanning all channel bandwidths, the SM restarts the scanning process beginning with the smallest configured channel bandwidth. Selecting multiple frequencies and multiple channel bandwidths impacts the SM/BHS scanning time. The biggest consumption of time is in the changing of the SM/BHS channel bandwidth setting. The worst case scanning time is approximately two minutes after boot up (SM/BHS with all frequencies and channel bandwidths selected and registering to an AP/BHM at 10 MHz). If only one channel band…

Text truncated - open the document above for the full version.
