Z9O-53007129Battery Powered BLE Senso

GRAPHIC ENGINEERING LABEL SPECIFICATIONS 655 Lone Oak Drive Eagan, MN 55121 Form Number: Part Number: Description: Stock: Trim Size: Ink Colors: Pages: Printed By: Other Information: 63267_8800_1025 53008141 MODEL: RT STANDARD IR SENSOR FCC STATEMENT This device(s) complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAN ICES-003 (B)/ NMB-003 (B) 1 Ecolab Place St Paul, MN USA 1-800-352-5326

Page 1 63334_8800_1125 For Ecolab Internal Use Only – Confidential 53008240 © 2025 Ecolab USA Inc. All rights reserved. 001/0425 IR-Sensor Installation and Operation Manual Installation & Operation Manual Retain this manual for installation, operations, and servicing information. P 2 63334_8800_1125 For Ecolab Internal Use Only – Confidential 53008240 © 2025 Ecolab USA Inc. All rights reserved. 001/0425 WARNING – Read all instructions carefully before attempting to service or install an Ecolab IR Sensor device. WARNING – Device contains non-rechargeable Lithium Metal battery. Misusing or mishandling lithium can pose a serious risk of personal injury, property damage, or both. Protect batteries from damage and extreme heat conditions during all storage and transportation tasks. Do not puncture, cut, crush, short circuit, attempt to recharge, or expose the battery to liquids or high temperatures (in excess of 85C per battery supplier SDS). Use only ER14505 replacement batteries supplied by Ecolab. Dispose of depleted battery cells as directed by local regulations after taping the terminals to avoid any accidental short circuiting. CAUTION – Device is sealed for use in wet environments, however is not constructed for use in locations where flammable vapor or explosive dust is likely to exist. In addition to any specific customer installation restrictions, this device should not be installed directly over surfaces where food is exposed, processed or prepared. NOTICE – Device designed for installation in environments with prolonged temperatures between +32 and +120 Fahrenheit (0 and 50 Celsius). Exposures to temperatures outside of these ranges might have impacts on device life or functionality. Suitable for installations with wet and/or humid conditions without adverse impacts on device life, however certain performance metrics might be impacted. When used in high altitude, it is recommended to briefly open the battery door prior to installation to ensure pressure is allowed to equalize on interior of the device. P 3 63334_8800_1125 For Ecolab Internal Use Only – Confidential 53008240 © 2025 Ecolab USA Inc. All rights reserved. 001/0425 DEVICE OVERVIEW The Ecolab Infrared (IR) Sensor is a modular digitally connected sensing device capable of detecting and alerting to the presence of a wide variety of potential target pests. Whether used as a stand-alone device positioned along Rodent runways or installed inside of the patented Connected Cockroach enclosure, the IR Sensor is an IP67 environmentally sealed design with a replaceable battery that will deliver many years of service without the need for replacement. Working on the principle of Active IR, the device pulses its IR LEDs and detects changes in levels of reflected light arriving back at the central IR Sensor to determine if a target pest has crossed its path. By thoughtfully monitoring baselines and interaction events, we are able to accurately generate activity alerts and deploy our team of elimination specialists at the first sign of an infestation. Magnet Swipe Sensor IR LED IR Sensor Status LEDs P 4 63334_8800_1125 For Ecolab Internal Use Only – Confidential 53008240 © 2025 Ecolab USA Inc. All rights reserved. 001/0425 INSTALLATION OF CONNECTED COCKROACH PPE Required: Gloves Bump Cap Knee Pads Safety Glasses Installation Tools Required: Drill, Bits and Mounting Screws Magnetic Pickup Tool Grease Monkey Cleaning Wipes Checkpoint Key Optional Glueboard, Attractant Tablet, Bait Power Data: ER14505 – 3.6V AA Lithium Battery 2600 mAh Note: device will not work with standard alkaline batteries Weight: 0.3 kg (12 oz.) INSTALLATION INSTRUCTIONS AND OPERATING PROCEDURE 1. Determine the appropriate wall location to install the unit. It is highly recommended to screw the device to the wall instead of only using the adhesive backing (except for installations onto stainless steel – see below) to limit false alerts and lost devices. The combination of available food, water, and lik elihood of introductions will help guide installation location selection. Refer to the Cockroach QRG for more information on selecting locations. Critical Installation Location Notes: Ensure adequate clearance for removal using Checkpoint key NOT on/above food prep areas NOT on hot surfaces (wall behind oven and fryers are typically acceptable) NOT in Front of House areas that are readily visible or accessible to guests NOT within 18” of the floor or on mobile equipment 2. Once a location is selected, thoroughly clean and dry the installation surface carefully using a combination of Grease Monkey wipes, a degreaser cleaner, etc. and paper towels. FOR STAINLESS STEEL INSTALLATIONS – this cleaning step is critical to keep the device on the wall and prevent ESRs due to P 5 63334_8800_1125 For Ecolab Internal Use Only – Confidential 53008240 © 2025 Ecolab USA Inc. All rights reserved. 001/0425 false alerts. Any dust, grease or other residue on the stainless will reduce the holding strength of our adhesive. 3. Once the wall is fully dry (use paper towels if needed!) remove the adhesive backing from the Mounting Plate to expose the foam tape and press the device against the wall, holding pressure for a minimum of 20-seconds for the pressure-sensitive adhesive to take hold. This should hold your device in position temporarily until screws are installed. Devices s hould be mounted in a horizontal orientation (with Checkpoint service key access oriented towards the ground) as this orientation will minimize false alerts due to water or debris and allow for easy servicing. See Step 1. 4. Remove the Cover and IR-Sensor from the Mounting Plate using your Checkpoint service key, leaving only the Mounting Plate on the wall. The snap release should only require minimal upward force on the key and the device should hinge out-and-away from the wall as shown below. With practice this can be accomplished one-handed by positioning your thumb on the friction features of the cover while ins…

Text truncated - open the document above for the full version.

Date: 10/21/2025 Federal Communications Commissions Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 RE: CFR 47 §2.911 (d)(5) Attestation FCC ID: Z9O-53007129 1. Ecolab Inc. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. 2. Ecolab Inc. (“the applicant”) certifies that, the device does not have cybersecurity and / or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, identified on the Covered List installed on the device, nor will it be installed by the applicant anytime after certification. 3. Ecolab Inc. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment and is not an affiliate or subsidiary of an entity identified on the Covered List. Sincerely yours, Name: Sherri Tischler Job Title: Director, Regulatory Affairs Company Name: Ecolab Inc.

Date: 10/21/2025 Federal Communications Commissions Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 RE: CFR 47 §2.911 (d)(7) Agent Designation Attestation FCC ID: Z9O-53007129 Applicant (Grantee) FRN: 0021282710 To whom it may concern: Ecolab Inc. (“the applicant”) as required by section §2.911(d)(7), will also serve as the agent for service of process for the above referenced FCC ID. The applicant acknowledges that they will maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility under CFR 47 §2.929(c) to inform the FCC whenever the agent information changes. U.S. Agent Information: Sherri Tischler Ecolab Inc. FCC FRN: 0021282710 1 Ecolab Pl, St Paul, MN 55102 [email protected] Sincerely yours, Sherri Tischler Ecolab Inc. 1 Ecolab Pl, St Paul, MN 55102

Date: 10/21/2025 Attn: FCC Office of Engineering and Technology / UL Verification Services TCB Subject: Request for Confidentiality FCC ID: Z9O-53007129 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. • Schematic Diagram • Block Diagram • Operation Description Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 30 days after grant • External Photos • Internal Photos • Test Setup Photos • User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards, Sherri Tischler Director, Regulatory Affairs

Ecolab RT Standard BLE Sensor External Photo 1 – Front Ecolab RT Standard BLE Sensor External Photo 2 – Rear Ecolab RT Standard BLE Sensor External Photo 3 – Rear (Battery Door Removed) Ecolab RT Standard BLE Sensor External Photo 4 – Left Side Ecolab RT Standard BLE Sensor External Photo 5 – Right Side Ecolab RT Standard BLE Sensor External Photo 6 – To p Side Ecolab RT Standard BLE Sensor External Photo 7 – Bottom Side

For FCC Filing The label is affixed with high performance permanent acrylic adhesive.

Ecolab RT Standard BLE Sensor Internal Photo 1 Ecolab RT Standard BLE Sensor Internal Photo 2

RF EXPOSURE REPORT Report Number: R15899798-E3 Applicant : Ecolab Inc 655 LONE OAK DR BLDG F MS F6 EAGAN, MN, USA 55121 Model : RT Standard IR Sensor FCC ID : Z9O-53007129 IC : 10060A-53007129 EUT Description : Battery Powered BLE Sensor Test Standard(s) : FCC Part 1 Subpart I FCC Part 2 Subpart J RSS 102 ISSUE 6 Date Of Issue: 2026-01-21 Prepared by: UL LLC 12 Laboratory Dr. Durham, NC 27713 U.S.A. TEL: (919) 549-1400 REPORT NO: R15899798-E3 DATE: 2026-01-21 FCC ID: Z9O-53007129 IC: 10060A-53007129 Page 2 of 10 UL LLC FORM NO: 03-EM-F00858 12 Laboratory Dr., DURHAM, NC 27713 TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC. Revision History Rev. Issue Date Revisions Revised By V1 2026-01-14 Initial Issue Noah Bennett V2 2026-01-21 Updated section 7. Noah Bennett REPORT NO: R15899798-E3 DATE: 2026-01-21 FCC ID: Z9O-53007129 IC: 10060A-53007129 Page 3 of 10 UL LLC FORM NO: 03-EM-F00858 12 Laboratory Dr., DURHAM, NC 27713 TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS ......................................................................................................... 4 2. TEST METHODOLOGY ............................................................................................................................. 5 3. REFERENCES ........................................................................................................................................... 5 4. FACILITIES AND ACCREDITATION ......................................................................................................... 5 5. DECISION RULES AND MEASUREMENT UNCERTAINTY...................................................................... 5 5.1. METROLOGICAL TRACEABILITY..................................................................................................... 5 5.2. DECISION RULES ............................................................................................................................. 5 6. MAXIMUM PERMISSIBLE EXPOSURE (LIMITS AND EQUATIONS) ....................................................... 6 6.1. FCC RULES ....................................................................................................................................... 6 6.2. ISED RULES ...................................................................................................................................... 7 6.3. EQUATIONS ...................................................................................................................................... 8 7. RF EXPOSURE RESULTS ...................................................................................................................... 10 REPORT NO: R15899798-E3 DATE: 2026-01-21 FCC ID: Z9O-53007129 IC: 10060A-53007129 Page 4 of 10 UL LLC FORM NO: 03-EM-F00858 12 Laboratory Dr., DURHAM, NC 27713 TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: Ecolab Inc 655 LONE OAK DR BLDG F MS F6 EAGAN, MN, USA 55121 EUT DESCRIPTION: Battery Powered BLE Sensor MODEL: RT Standard IR Sensor SAMPLE RECEIPT DATE: 2025-08-05 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 1 SUBPART I & PART 2 SUBPART J RSS 102 ISSUE 6 Complies Complies UL LLC. tested the above equipment in accordance with the requirements set forth in the above standards. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. All samples tested were in good operating condition throughout the entire test program. Measurement Uncertainties are published for informational purposes only and were not taken into account unless noted otherwise. This document may not be altered or revised in any way unless done so by UL LLC. and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by UL LLC. will constitute fraud and shall nullify the document. Approved & Released For UL LLC By: Prepared By: Michael Antola Noah Bennett Senior Staff Engineer Engineer Project Associate Consumer, Medical and IT Segment Consumer, Medical and IT Segment UL LLC UL LLC REPORT NO: R15899798-E3 DATE: 2026-01-21 FCC ID: Z9O-53007129 IC: 10060A-53007129 Page 5 of 10 UL LLC FORM NO: 03-EM-F00858 12 Laboratory Dr., DURHAM, NC 27713 TEL: (919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC. 2. TEST METHODOLOGY All calculations were made in accordance with FCC Parts 1.1310, 2.1091, 2.1093, KDB 447498 D01 v06, KDB 447498 D03 V01, IEEE Std C95.1-2005, and IEEE Std C95.3-2002, IC Safety Code 6 and RSS 102 Issue 6. 3. REFERENCES Refer to UL report R15899798-E1 for the BLE test results. 4. FACILITIES AND ACCREDITATION UL LLC is accredited by A2LA, certification # 0751.06, for all testing performed within the scope of this report. Testing was performed at the locations noted below. Address ISED CABID ISED Company Number FCC Registration ☐ Building: 12 Laboratory Dr RTP, NC 27709, U.S.A US0067 2180C 825374 ☒ Building: 2800 Perimeter Park Dr. Suite B Morrisville, NC 27560, U.S.A 27265 5. DECISION RULES AND MEASUREMENT UNCERTAINTY 5.1. METROLOGICAL TRACEABILITY The measuring equipment utilized to perform the tests documented in this report has been calibrated in accordance with the manufacturer's recommendations, and is traceable to recognized national standards. 5.2. DECISION RULES For all tests where the applicable U LAB <= U MAX the Decision Rule is based on …

Text truncated - open the document above for the full version.

TEST REPORT Report Number. : R15899798-E1 Applicant : Ecolab Inc 655 LONE OAK DR BLDG F MS F6 EAGAN, MN, USA 55121 Model : RT Standard IR Sensor FCC ID : Z9O-53007129 IC : 10060A-53007129 EUT Description : Battery Powered BLE Sensor Test Standard(s) : FCC 47 CFR PART 15 SUBPART C ISED RSS-247 ISSUE 4 ISED RSS-GEN ISSUE 5 + A1 + A2 Date Of Issue: 2026-01-08 Prepared by: UL LLC 12 Laboratory Dr. Durham, NC 27713 U.S.A. TEL: (919) 549-1400 REPORT NO: R15899798-E1 DATE: 1/8/2026 FCC ID: Z9O-53007129 IC: 10060A-53007129 Page 2 of 79 UL LLC 12 LABORATORY PARK DR. DURHAM, NC 27513; USA TEL:(919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC REPORT REVISION HISTORY Rev. Issue Date Revisions Revised By -- 2026-01-08 Initial Issue Noah Bennett REPORT NO: R15899798-E1 DATE: 1/8/2026 FCC ID: Z9O-53007129 IC: 10060A-53007129 Page 3 of 79 UL LLC 12 LABORATORY PARK DR. DURHAM, NC 27513; USA TEL:(919) 549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC TABLE OF CONTENTS REPORT REVISION HISTORY ......................................................................................................................... 2 TABLE OF CONTENTS .................................................................................................................................... 3 1. ATTESTATION OF TEST RESULTS ......................................................................................................... 5 2. TEST RESULTS SUMMARY ..................................................................................................................... 6 3. TEST METHODOLOGY ............................................................................................................................. 6 4. FACILITIES AND ACCREDITATION ......................................................................................................... 6 5. DECISION RULES AND MEASUREMENT UNCERTAINTY...................................................................... 7 5.1. METROLOGICAL TRACEABILITY..................................................................................................... 7 5.2. DECISION RULES ............................................................................................................................. 7 5.3. MEASUREMENT UNCERTAINTY ..................................................................................................... 7 5.4. SAMPLE CALCULATION ................................................................................................................... 7 6. EQUIPMENT UNDER TEST ...................................................................................................................... 8 6.1. EUT DESCRIPTION .......................................................................................................................... 8 6.2. MAXIMUM OUTPUT POWER ............................................................................................................ 8 6.3. DESCRIPTION OF AVAILABLE ANTENNAS .................................................................................... 8 6.4. SOFTWARE AND FIRMWARE .......................................................................................................... 8 6.5. WORST-CASE CONFIGURATION AND MODE ................................................................................ 9 6.6. DESCRIPTION OF TEST SETUP ...................................................................................................... 9 7. MEASUREMENT METHOD ..................................................................................................................... 10 8. TEST AND MEASUREMENT EQUIPMENT ............................................................................................. 11 9. ANTENNA PORT TEST RESULTS ......................................................................................................... 14 9.1. ON TIME AND DUTY CYCLE .......................................................................................................... 14 9.2. 99% BANDWIDTH ........................................................................................................................... 16 9.2.1. BLE (1Mbps) ............................................................................................................................ 16 9.2.2. BLE (2Mbps) ............................................................................................................................ 17 9.2.3. BLE (125Kbps) ......................................................................................................................... 18 9.2.4. BLE (500Kbps) ......................................................................................................................... 19 9.3. 6 dB BANDWIDTH ........................................................................................................................... 20 9.3.1. BLE (1Mbps) ............................................................................................................................ 21 9.3.2. BLE (2Mbps) ............................................................................................................................ 22 9.3.3. BLE (125Kbps) ......................................................................................................................... 23 9.3.4. BLE (500Kbps) ......................................................................................................................... 24 9.4. OUTPUT POWER ............................................................................................................................ 25 9.4.1. BLE (1Mbps) ............................................................................................................................ 26 REPORT NO: R15899798-E1 DATE: 1/8/2026 FCC ID: Z9O-53007129 IC: 10060A-53007129 Page 4 of 79 UL LLC 12 LABORATORY PARK DR. DUR…

Text truncated - open the document above for the full version.

This report must not be used to claim product certification, approval, or endorsement by A2LA or any agency of the U.S. Government. This Report shall not be reproduced, except in full without written approval of the laboratory. Ecolab RT Standard IR Sensor OTA Report Report: F3EN0276.0 Rev. 01 Issue Date: January 28, 2026 Approved by: Trevor Buls, Principal EMC Test Engineer Signed for and on behalf of Element TABLE OF CONTENTS 2023.04.17 Section Page Number Revision History .............................................................................................. 3 Facilities .......................................................................................................... 4 Product Description ......................................................................................... 5 Modifications ................................................................................................... 6 OTA Measurement Summary .......................................................................... 7 Passive 3D Antenna Pattern Measurements................................................... 9 End of Report .................................................................................................. 12 Report No. F3EN0276 Rev. 012/12 REVISION HISTORY 2025.07.22 Revision Number Description Date (yyyy-mm-dd) Page Number 01 Corrected Issue Date 2026-01-28 Cover Report No. F3EN0276 Rev. 013/12 FACILITIES 2025.07.17 Testing was performed at the following location(s) Location Labs (1) Address A2LA (2) ISED (3) BSMI (4) VCCI (5) CAB FDA (6) ☐ California OC01-17 41 Tesla Irvine, CA 92618 (949) 861-8918 3310.04 2834B SL2-IN-E-1154R A-0029 US0158 TL-55 ☒ Minnesota MN01-11 9349 W Broadway Ave. Brooklyn Park, MN 55445 (612) 638-5136 3310.05 2834E SL2-IN-E-1152R A-0109 US0175 TL-57 ☐ Oregon EV01-12 6775 NE Evergreen Pkwy #400 Hillsboro, OR 97124 (503) 844-4066 3310.02 2834D SL2-IN-E-1017 A-0108 US0017 TL-56 ☐ Washington NC01-05 19201 120th Ave NE Bothell, WA 98011 (425) 984-6600 3310.06 2834F SL2-IN-E-1153R A-0110 US0157 TL-67 ☐ Offsite N/A See Product Description N/A N/A N/A N/A N/A N/A See data sheets for specific labs (1) The lab designations denote individual rooms within each location. (OC01, OC02, OC03, etc.) (2) A2LA Certificate No. (3) ISED Company No. (4) BSMI No. (5) VCCI Site Filing No. (6) FDA ASCA No. Report No. F3EN0276 Rev. 014/12 PRODUCT DESCRIPTION 2018-07-17 Client and Equipment under Test (EUT) Information Company Name: Ecolab Address: 655 Lone Oak Drive City, State, Zip: Eagan, MN 55121 Test Requested By: Jon Campbell EUT: RT Standard IR Sensor First Date of Test: February 24, 2025 Last Date of Test: February 24, 2025 Receipt Date of Samples: February 24, 2025 Equipment Design Stage: Production Equipment Condition: No Damage Purchase Authorization: Verified Information Provided by the Party Requesting the Test Functional Description of the EUT: Battery Powered Active IR Sensor with BLE. This contains an Inverted-F PCB Trace Antenna. Ground Plane = 83.5mm x 29mm. Testing Objective: To obtain 3D antenna pattern measurements and calculated antenna performance values (gain, efficiency, TRP, etc) EUT Photo: Report No. F3EN0276 Rev. 015/12 MODIFICATIONS 2018-07-17 Equipment Modifications Item Date Test Modification Note Disposition of EUT 1 2025-02-24 Active 3D Antenna Pattern Measurements Tested as delivered to test Station. No EMI suppression devices were added or modified during this test. Scheduled testing was completed. Report No. F3EN0276 Rev. 016/12 OTA MEASUREMENT SUMMARY TEST DEFINITIONS Phi Polarity The detector antennas that are pointing in the same direction as the phi axis positioner rotates. See following page for photos. Theta Polarity The detector antennas that are pointing in the same direction as when the ring of detector antennas. See following page for photos. Phi Angle The position of the phi axis positioner, usually between 0° and 180° Theta Angle The position of the detector antenna, usually between -165° and 165° Antenna Port Input Power (APIP) The absolute power going into the antenna. This is used to calculate Efficiency and Gain. Effective Isotropic Radiated Power (EIRP) After combining phi and theta polarity measurements, the highest reading seen at any phi and theta angle during the measurement is the Effective Isotropic Radiated Power. Total Radiated Power (TRP) The sum of the power seen at all measuring antennas at all Theta and Phi angles and at both polarities. Represented in equation form by: 푇푅푃= 1 4휋 ∫∫(퐸퐼푅푃 휃 ( 휃,휙 ) +퐸퐼푅푃 휙 ( 휃,휙 ) )∗sin ( 휃 ) 푑휃 휋 0 푑휙 2휋 0 Where 휃 is the theta angle of the measurement, 휙 is the phi angle of the measurement, 퐸퐼푅푃 휃 ( 휃,휙 ) is the reading on the theta polarity at a given theta and phi angle, and 퐸퐼푅푃 휙 ( 휃,휙 ) is the reading on the phi polarity at a given theta and phi angle. Minimum Effective Isotropic Sensitivity (Min. EIS) After finding the inverse of the sum of the inverses of the phi and theta polarity measurements for each single phi and theta angle, the lowest value is the Min. EIS. EIS is represented in equation form as: 퐸퐼푆= ( 퐸퐼푆 휃 ( 휃 푛 ,휙 푛 ) −1 +퐸퐼푆 휙 ( 휃 푛 ,휙 푛 ) −1 ) −1 Where 휃 is the theta angle of the measurement, 휙 is the phi angle of the measurement, 퐸퐼푆 휃 ( 휃,휙 ) is the reading on the theta polarity at a given theta and phi angle, and 퐸퐼푆 휙 ( 휃,휙 ) is the reading on the phi polarity at a given theta and phi angle. The lowest value found across all EIS values is the Minimum Effective Isotropic Sensitivity. Total Isotropic Sensitivity (TIS) The inverse of the sum of the inverses of all the individual EIS readings. Represented in equation form as: 푇퐼푆= 4휋 ∫∫ ( 퐸퐼푆 휃 ( 휃,휙 ) −1 +퐸퐼푆 휙 ( 휃,휙 ) −1 ) ∗sin ( 휃 ) 푑휃 휋 0 푑휙 2휋 0 Where 휃 is the theta angle of the measurement, 휙 is the phi angle of the measurement, 퐸퐼푆 휃 ( 휃,휙 ) is the reading on the theta polarity at a given theta and phi angle, and 퐸퐼푆 휙 ( 휃,휙 ) is the reading on the phi polarity at a given theta and phi angle. Directivity The…

Text truncated - open the document above for the full version.

SETUP PHOTOS EXHIBIT Report Number: R15899798-EP1 Applicant : Ecolab Inc 655 LONE OAK DR BLDG F MS F6 EAGAN, MN, USA 55121 Model : RT Standard IR Sensor FCC ID : Z9O-53007129 IC : 10060A-53007129 EUT Description : Battery Powered BLE Sensor Test Standard(s) : FCC 47 CFR PART 15 SUBPART C ISED RSS-247 ISSUE 4 ISED RSS-GEN ISSUE 5 + A1 + A2 Date Of Issue: 2026-01-07 Prepared by: UL LLC 12 Laboratory Dr. Durham, NC 27713 U.S.A. TEL: (919) 549-1400 REPORT NO: R15899798-EP1 DATE: 2026-01-07 FCC ID: Z9O-53007129 IC: 10060A-53007129 Page 2 of 13 UL LLC FORM NO: CCSUP4701I 12 Laboratory Dr., DURHAM, NC 27713; USA TEL:(919)549-1400 This report shall not be reproduced except in full, without the written approval of UL LLC REVISION HISTORY Rev. Issue Date Revisions Revised By V1 2026-01-07 Initial Issue Noah Bennett REPORT NO: R15899798-EP1 DATE: 2026-01-07 FCC ID: Z9O-53007129 IC: 10060A-53007129 Page 3 of 13 UL LLC FORM NO: CCSUP4701I 12 Laboratory Dr., DURHAM, NC 27713; USA TEL:(919)549-1400 This report shall not be r…

Text truncated - open the document above for the full version.
