Z9UMOMO9CTablet PC

English User Manual This manual is to introduce the functions of the device, as well as matters which need attention. Please read this manual before you use the device. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. Content 1. Announcements .......................................Page 1 2. Introduction ..........................................Page 3 2.1 Packing Details....................................Page 3 2.2 Instructions on Keys. ......... ...............Page 3 2.3 Features Overview.................................Page 4 2.4 Technical Specifications.....................Page 6 3. Quick Guidance ............... .....................Page 7 3.1 About Touch Panel..............................Page 7 3.2 Switch On/Off. ............... ..................Page 7 3.3 Power Save Modes and lock screen............Page 8 3.4 Battery management and charging. .........Page 9 3.5 Definition for the icons of the Functions...Page 10 3.6 USB HOST Function.............................. Page 12 3.7 TF Card Storage..................................Page 12. 4. Network Access ...................................Page 13 4.1 Network Access by Wi-Fi.................... Page 13 4.2 Network Access by 3G............................ Page 13 5. Storage File Copy & Delete f rom PC............Page 14 6. Main Functions Introduction .....................Page 15 6.1 Audio Function...................................Page 15 6.2 Video Function....................................Page 17 6.3 Picture Function..................................Page 17 6.4 Record Fu nction................................ Page 18 6.5 File Man ager.................................Page 19 6.6 E-book Function..............................Page 19 6.7 Internet Br owser...........................Page 19 6.8 Email Function..............................Page 20 6.9 Calendar.....................................Page 22 6.10 Calculator.......................................Page 23 6.11 Alarm Clock.................................Page 24 6.12 APK Inst aller..............................Page 24 7. System Settings....................................Page 26 8. FAQ...................................................Page 29 -- Page 1 -- 1. Announcements 1. Please keep the device away from moist and dust. 2. Do not put the device in high-temperature environment, especially closed car in hot weather. 3. Do not drop or strike the device. 4. Do not shake the device violently, especially the LCD Screen part. Or, it will cause abnormal display on the screen. 5. Please choose a proper volume when using the earphone which will be good for your ear. 6. Please charge the device when (1) The power icon shows lowest power. (2) The device is turned off automatically, and when you turn on it, it is turned off automatically again. (3) No response when operating the buttons. Attention: Please use the charger offered by manufacturer to charge, other charges may causes damage to the device. 7. Do not disconnect the device from PC when downloading, uploading or formatting, or it will cause -- Page 2 -- programming errors of the device. 8. Do not dismounting the device privately without professional guidance. 9. Do not use alcohol, thinner or benzene-chemical to clean the surface of the device. 10. Do not use the device in forbidden place, like airplane. 11. Please back-up your files in device’s memory always. The manufacturer is not responsible for the clear of files after damage or repair of the device. 12. The manufacture reserves all right of device’s technology and design, and will have no obligation to inform the user if there are new versions or designs been developed. 13. The device is NOT water-proof, please keep it away from water. The turn on time of this device is about 30 seconds, please don’t operate t he device w hen it is turned on i n 30 seconds. -- Page 3 -- 2. Introduction 2.1 Packing Details. Each unit has the following items: Tablet PC device*1, charger*1, earphone*1, USB cable*1, and user manual*1. All items are packed in gift box. 2.2 Instructions on Keys. Name Description RESET Press this button shortly to reset the system when the device is halted POWER Press this button shortly to enter sleeping/wake up mode, long press to switch ON/OFF MENU Press this button shortly to enter the submenu -- Page 4 -- ESC Press shortly to return, long press to the touch screen calibration TF Card Slot For external TF…

Text truncated - open the document above for the full version.

Authorization Letter We, (the approval holder) Company name Shenzhen Ployer Electronics Co.,Ltd Addresss 6F, Building 8, Yusheng Industrial Park, Gushu, Xixiang Town, Baoan District, , City Shenzhen Country China declare that the following representative (agent): Name (person) Bovey.yang Company name NTEK Testing Technology Co., Ltd. Addresss 1/F, Building E, Fenda Science Park Sanwei Community, Xixiang Street, Baoan District City Shenzhen Country China to act on our behalf on all matters concerning the application and documents submitted to PHOENIX TEST-LAB for product certification below Product Description Tablet pc Type or Model(s) MOMO9C, CM007, MOMO13, MOMO9R, MOMO9 Tradename or Brand(s) We also authorize BZT – TCP Certification GmbH, Ms.Wanida Patthanavoj (address: Hermann - Loens - Weg 6, 15859 Storkow b. Berlin Germany) to process the application. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) China 2011/11/05 Brian chou Manager

Ersteller: D. Brandhorst Revision: 00 Erstelldatum: 07.03.2008 Datum: 00.00.00 Seite 1 von 1 PHOENIX TEST-LAB GmbH Product Certification Königswinkel 10 D 32825 Blomberg Date:2011-11-25 FCC ID: Z9U MOMO9C Subject: Attestation Letter “Declaration of Conformity” Dear Sirs, Our products with the above FCC ID are defined as composite device. The transmitter is authorized under the “Certification” procedure. The device is also defined as “PC Periphery” acc to §15.101 Equipment authorization of unintentional radiators, where we hereby declare, that we apply and follow the “Declaration of Conformity” procedure. If you have any questions, please feel free to contact me at the address shown below. Yours sincerely, Signatory Signature Name Brian chou Title Manager 6F, Building 8, Yusheng Industrial Park, Gushu, Xixiang Town, Baoan District, Shenzen, China

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

L* H=45 *50cm

Photo 7 Photo 8 Photo 9 Photo 10 Photo 11 Photo 12 Photo 13 Photo 14 Photo 15

Page 1 of 78 Report No.: NTEK-2011NT1111583E FCC RADIO TEST REPORT Report Reference No. ............... : NTEK-2011NT1111583E Compiled by (+ signature) ........... Tom Zhang Approved by (+ signature) ........... Bovey Yang Applicant’s name........................... : Shenzhen Ployer Electronics Co.,Ltd Address....................................... : 6F, Building 8, Yusheng Industrial Park, Gushu, Xixiang Town, Baoan District, Shenzhen, China Manufacture's Name...................... : Shenzhen Ployer Electronics Co.,Ltd Address....................................... : 6F, Building 8, Yusheng Industrial Park, Gushu, Xixiang Town, Baoan District, Shenzhen, China Test specification: Standard ..................................... : FCC Part15.247 Test procedure............................... : ANSI C63.4-2003 Test item description Product name ........................ : Tablet PC FCC ID Z9UMOMO9C Trademark ............................ : N/A Model and/or type reference : MOMO9C, CM007, MOMO13, MOMO9R, MOMO9 Rating(s) ................................ : DC 5V, 1.5A Testing Laboratory information: Testing Laboratory Name ..... : NTEK Testing Technology Co., Ltd Address ................................ : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao ＇an District, Shenzhen P.R. China. This device described above has been tested by NTEK Testing Technology Co., Ltd, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK Testing Technology Co., Ltd, this document may be altered or revised by NTEK Testing Technology Co., Ltd, personal only, and shall be noted in the revision of the documen Testing....................................................: Date of receipt of test item ......................: 10 Nov. 2011 Date (s) of performance of tests .............: 08 Nov. 2011 ~18 Nov. 2011 Date of Issue ...........................................: 18 Nov. 2011 Test Result...............................................: Pass Page 2 of 78 Report No.: NTEK-2011NT1111583E Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 8 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 9 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 10 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 11 3 . EMC EMISSION TEST 12 3.1 CONDUCTED EMISSION MEASUREMENT 12 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 12 3.1.2 TEST PROCEDURE 13 3.1.3 DEVIATION FROM TEST STANDARD 13 3.1.4 TEST SETUP 13 3.1.5 EUT OPERATING CONDITIONS 13 3.1.6 TEST RESULTS 14 3.2 RADIATED EMISSION MEASUREMENT 16 3.2.1 RADIATED EMISSION LIMITS 16 3.2.2 TEST PROCEDURE 17 3.2.3 DEVIATION FROM TEST STANDARD 17 3.2.4 TEST SETUP 18 3.2.5 EUT OPERATING CONDITIONS 19 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 20 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 21 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 23 4 . POWER SPECTRAL DENSITY TEST 47 4.1 APPLIED PROCEDURES / LIMIT 47 4.1.1 TEST PROCEDURE 47 4.1.2 DEVIATION FROM STANDARD 47 4.1.3 TEST SETUP 47 4.1.4 EUT OPERATION CONDITIONS 47 4.1.5 TEST RESULTS 48 5 . BANDWIDTH TEST 56 5.1 APPLIED PROCEDURES / LIMIT 56 5.1.1 TEST PROCEDURE 56 Page 3 of 78 Report No.: NTEK-2011NT1111583E Table of Contents Page 5.1.2 DEVIATION FROM STANDARD 56 5.1.3 TEST SETUP 56 5.1.4 EUT OPERATION CONDITIONS 56 5.1.5 TEST RESULTS 57 6 . PEAK OUTPUT POWER TEST 66 6.1 APPLIED PROCEDURES / LIMIT 66 6.1.1 TEST PROCEDURE 66 6.1.2 DEVIATION FROM STANDARD 66 6.1.3 TEST SETUP 66 6.1.4 EUT OPERATION CONDITIONS 66 6.1.5 TEST RESULTS 67 7 . ANTENNA CONDUCTED SPURIOUS EMISSION 68 7.1 APPLIED PROCEDURES / LIMIT 68 7.1.1 TEST PROCEDURE 68 7.1.2 DEVIATION FROM STANDARD 68 7.1.3 TEST SETUP 68 7.1.4 EUT OPERATION CONDITIONS 68 7.1.5 TEST RESULTS 69 8 . EUT TEST PHOTO 77 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 4 of 78 Report No.: NTEK-2011NT1111583E 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (c) Antenna conducted Spurious Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Power Spectral Density PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 5 of 78 Report No.: NTEK-2011NT1111583E 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC FRN Registration Nombre:238937; IC Registration Nombre:9270A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 Radiated Emission Test ±3.17dB 3 RF power,conducted ±0.16dB 4 Spurious emissions,conducted ±0.21dB 5 All emissions,radiated(<1G) ±4.68dB 6 All emissions,radiated(>1G) ±4.89dB Page 6 of 78 Report No.: NTEK-2011NT1111583E 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Tablet PC Trade Name N/A Model Name MOMO9C, CM007, MOMO13, MOMO9R, MOMO9 OEM Brand/Model Name N/A Model Difference N/A Product Description The EUT is a Tablet PC Operation Frequency: 2412~2462 MHz Modulation Type: CCK, DQPSK, DBPSK, OFDM Bit Rate of Transmitter 802.11b:11/5.5/2/1 Mbps 802.11g:54/48/36/24/18/12/9/6 Mbps 802.11n(20M):54/48/36/24/18/12/ 9/6 Mbps 802.11n(40M):300/270/240/180/1 50/120/108/90 Mbps Number Of Channel 11 CH, Please see Note 2. Antenna Designation: Please see Note 3. Antenna Gain(Peak) Please see Note 3.…

Text truncated - open the document above for the full version.

Page 74 of 75 Report No.: NTEK-2011NT1111583E 8. EUT TEST PHOTO Radiated Measurement Photos Page 75 of 75 Report No.: NTEK-2011NT1111583E Conducted Measurement Photos
