WirelessChargerusermanual WirelessCharger Model：WD-268C Contents 1.Whatisinthebox 2.ProductIntroduction 3.Specification 4.Howtouse 5.ImportantNotification 6.FCCStatement&Warning 7.TrademarkAcknowledgments ThanksforpurchasingthisfantasticQiWirelesscharger.Please readthemanual indetailforproperoperationbeforeyougettostarttouse. Whatisinthebox 1)QiWirelessChargerx1pc 2)QuickUserManualx1pc Manufacturer:SHENZHENDNSINDUSTRIESCO.,LTD. Address:23/FBuildingA,ShenzhenInternationalInnovation Center,No.1006ShennanRoad,Futian,Shenzhen,China ProductIntroduction MicroUSBCChargingPort LEDindicator Antiskidstrip Specification Features: Mainfunctions:singlecoilwirelesschargertransmitter; Productsapplicable:allwirelesschargingequipmentaccordedwith Qistandard; Chargingtype:one-on-onechargecorrespondingarea; Specification: Mainfunctions:singlecoilwirelesschargertransmitter; Standardversion:WPC-1.2.4; Productsapplicable:allwirelesschargingequipmentaccordedwithQIstandard; Chargingtype:one-on-onechargecorrespondingarea; Theinputvoltage:5V2A;9V2A,12V1.5A Output ： 5W,7.5W,10W,15W Launchdistance:3to8MM; Conversionefficiency:≥70%; Chargingmethods:inductionmodel; Workingfrequency:110.1-205kHz; FCCID:ZBCWD268C HowtoUSE 1,PlugYourQiWirelessChargertothePowerSource Plugthesmallend(microUSBBport)oftheUSBcordintothe sideoftheQicharger.Youcanthenplugthelargerend(USBA port)oftheUSBcordintothewallcharger,andthenplugthe chargerintothewall,oryoucanplugthelargerendintoaPC 2,PlaceYourCellphoneontheQiCharger Afteryouhaveconnectedthechargertoapowersource(either yourcomputerorawalloutlet),allyouneedtodotochargeyour phoneissimplyplaceyourphoneontopofthecharger. Beforeyoutrytochargeyourphonewiththecharger,ensurethat yourphoneiscompatiblewithQichargersandmakesurethatthe phoneiswelllocatedatthechargingareaofwirelesscharger. 3,ChargingStatusIndicator 1)Theindicatorgreenlightisonfor4s,thenentersthestandby status,thegreenlightgoesout. 2)Pleaselaythedevicedirectlyonwirelesschargerforcharging,the greenlightalwaysstaysonwhenthechargerisinchargingstatus 3)Whenthedeviceisfullofpower,thegreenlightgoesout. 4)Thetransmitterhasthefunctionofdetectingforeignobjects(FOD). Ifthereisaforeignobjectonthetransmitter,thegreenlightwill flash. ImportantNotification Thefirst:Toprotectpeoplefromharmandpropertyloss,wemakeaclear explanationonwhatyoudoshouldobey: A.Warning!Thereareconcerningthepossibilitiesofdeathandsevere wound: Peoplewhouseheart-birth-makershouldconsultyourdoctorbefore youusethisproduct; Andpleaseleaveitatadistanceof22cmfromtheplacewhereyou installyourheart-birth-maker,theelectromagneticwavehaveinfluence onheart-birth-maker’swork. B.Attention!Itmayledtoheat,fireandelectricshock: 1Donotputitintowateroranyotherliquid,Donotmakeitwet; 2DonotpulltheACadapteroutwithwethands,ensurethesafetyand integrityoftheadapter; 3DonotletthedustorotherthingsaccumulateontheproductandtheAC adapter; 4Donotusetheproductoutsidethetemperature-20 °C to40 °C ; 5Donotchargeinplaceswherethesunshinedirectlyorwithhigh temperature; 6Donotusethisproductinplacesthatareeasytofall,soasnottobreak; 7Donotlaythemagneticcard,magneticrecordmediaandprecisemachinetoo closetotheprotect; 8Donotdecomposeandremold; 9Donotlayanythingbetweenthenon-connectionchargingpadandthe chargingmachine; 10Donotsurpasstheratedvaluewhenusingtheplugandotherwiring layout.; 11DonotmakeanybreakageontheACadapter,pleasemakesureyouconnect theACadapterfullyandtaketheACadapterofftheplugwhenit’snot used; 12Donotusetravelconverter; 13Pleaseteachyourchildrentouse ThisdevicecomplieswithPart15oftheFCCRules.Operationis subjecttothe followingtwoconditions: (1)thisdevicemaynotcauseharmfulinterference,and (2)thisdevicemustacceptanyinterferencereceived,including interferencethatmaycauseundesiredoperation. NOTE:Thisequipmenthasbeentestedandfoundtocomplywiththe limitsfora ClassBdigitaldevice,pursuanttopart15oftheFCCRules.These limitsare designedtoprovidereasonableprotectionagainstharmful interferenceina residentialinstallation.Thisequipmentgeneratesusesandcan radiate radiofrequencyenergyand,ifnotinstalledandusedinaccordance withthe instructions,maycauseharmfulinterferencetoradiocommunications. However, thereisnoguaranteethatinterferencewillnotoccurinaparticular installation. Ifthisequipmentdoescauseharmfulinterferencetoradioor television reception,whichcanbedeterminedbyturningtheequipmentoffand on,the userisencouragedtotrytocorrecttheinterferencebyoneormore ofthe followingmeasures: -Reorientorrelocatethereceivingantenna. -Increasetheseparationbetweentheequipmentandreceiver. -Connecttheequipmentintoanoutletonacircuitdifferentfrom thattowhich thereceiverisconnected. -Consultthedealeroranexperiencedradio/TVtechnicianforhelp Changesor modificationsnotexpresslyapprovedbythepartyresponsiblefor compliance couldvoidtheuser'sauthoritytooperatetheequipment. ThisequipmentcomplieswithFCCradiationexposurelimitssetforth foranuncontrolledenvironment.Thisequipmentshouldbeinstalled andoperatedwithminimumdistance20cmbetweentheradiatorandyour body.Thistransmittermustnotbeco-locatedoroperatingin conjunctionwithanyotherantennaortransmitter. CAUTION:Changesormodificationsnotexpresslyapprovedbytheparty responsibleforcompliancecouldvoidtheuser’sauthoritytooperatethe product. ThisdevicecomplieswithIndustryCanadalicense-exemptRSSstandard(s). Operationissubjecttothefollowingtwoconditions:(1)thisdevicemaynot causeinterference,and(2)thisdevicemustacceptanyinterference,including interferencethatmaycauseundesiredoperationofthedevice. LeprésentappareilestconformeauxCNRd'IndustrieCanadaapplicablesaux appareilsradioexemptsdelicence.L'exploitationestautoriséeauxdeux conditionssuivantes:(1)l'appareilnedoitpasproduiredebrouillage,et(2) l'utilisateurdel'appareildoitacceptertoutbrouillageradioélectriquesubi,même silebrouillageestsusceptibled'encompromettrelefonctionnement.

FCCID:ZBCWD268C

LabelLocationOnEUT Label ProductName:WirelessCharger ModelNo.:WD-268C FCCID:ZBCWD268C ThisdevicecomplieswithPart15oftheFCCRules.Operation issubjecttothefollowingtwoconditions: (1)Thisdevicemaynotcauseharmfulinterference,and (2)Thisdevicemustacceptanyinterferencereceived,including interferencethatmaycauseundesiredoperation.

FCCID:ZBCWD268C ANT

version01 SHENZHENDNSINDUSTRIESCO.,LTD. DeclarationconcerningAntennaSpecification Itisherebydeclaredthattheproduct ModelNo.:WD-268C FCCID:ZBCWD268C fulfillstherequirementinFCCtestrelatingtotheantennatype. ThedevicespecifiedaboveconfirmstotheFCCrecommendationsforinternalantennatype(s) describedbelow: ModelNo.ofantenna:N/A Typeofantenna:InductiveloopcoilAntenna Gainoftheantenna:0dBi Frequencyrange:110.1-205KHz Themountingoftheantennaisfixedtotheradiomoduleandnootherantennashouldbeused. Companyname:SHENZHENDNSINDUSTRIESCO.,LTD. Address:23/FBuildingA,ShenzhenInternationalInnovationCenter,No.1006ShennanRoad,Futian, Shenzhen,China City:Shenzhen ZIP/Postalcode:N/A Country:China Place:ChinaDate: 2021-05-21 Signature:
