ZC4X250Smart Phone

Corporativo Lanix S.A. de C.V.

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Dec 07, 2015
Application Purpose: Original Equipment
Date of Application: Dec 06, 2015
Equipment Note: Smart Phone
Frequency Range: 2402.00000000 - 2480.00000000
Company: Corporativo Lanix S.A. de C.V.
Country: Mexico

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1 1. UNDERSTANDING YOUR DEVICE 1.1 General info ILIUM X250 is a smart phone, such as Android version 4.4, 1.2 GHz Quad Core Processor, 2 MP Digital Camera, etc. 2 3 Position of Keys 1. USB Port 2. Front Camera Lens 3. Volume Control Key 4. Touch Screen 5. Menu Key 6. Home Key 4 7. Back Key 8. Earpiece 9. Earphone Jack 10. Power Key 11. Flash 12. Battery Cover 13. Camera Lens 2. PREPARING YOUR PHONE 2.1 Inserting the SIM card Turn your cell phone over and remove the back cover and the battery. Insert the SIM card correctly in the slot for the card 5 2.2 Inserting the memory card Insert the memory card into the slot until it snaps into place as indicated in the image below. 3. BASIC FUNCTIONS 3.1 Turning ON/OFF Make sure that the SIM card, the battery and the Micro SD card are installed and then press the Power Key to turn on the cell phone. Turning Off the Device, long press the Power Key. Three options will be shown, Select “OK” to confirm. 6 3.2 Notifications Notification bar: At the top of the screen, the status bar displays the time, the status and the notifications. Move the status bar down to display the notification page. Here you can review missed calls, new messages, etc. Finally, slide the status bar up to restore it. 3.3 Accessing the launcher Tap the launcher icon on the home page to open the main menu, and press the home key or back key to return to the home page. 4. CUSTOMIZING 4.1 Setting the wallpaper You can customize the wallpaper of your Home screen with 7 default wallpaper or with pictures taken from your device.  In the idle mode, tap Menu Key > WALLPAPERS. 4.2 Customizing the home page with widgets and more icons Take the following steps: On idle screen press Menu Key and the option WIDGETS, long press the widget or icon until the phone vibrates > release. 4.3 Relocating or removing widgets, and more on the home page Press and hold the widget or icon you want to relocate or remove. The phone will vibrate and display "Remove" next to the phone's receiver. Move the widget or icon you want to delete or relocate. 8 5. APPLICATIONS 5.1 Email Your device allows you to compose, read and send emails. 5.2 Browser The Browser is the tool which enables you to access the Internet. 5.3 Calculator Calculator helps you perform basic arithmetic functions, such as addition, subtraction, multiplication and division. 5.4 Clock This function gives you an access to the alarm clock.  Go to  Clock, Tap > tap to add alarm. 5.4 Gallery You can view the captured images, recorded video clips, and downloaded images in the Gallery. The picture folder and video folder will be displayed. Select to view the camera pictures or camera videos. The images or videos will be displayed in thumbnails. 9 5.5 Camera Your device is equipped with a camera and camcorder that enable you to capture photos and videos. 6. SPECIFICATIONS Screen 4.0 inch （WVGA） Battery 1400mAh Dimensions 124.6x64.4x9.95 mm Weight 106.5 g Standby Time Up to 300 hours* Maximum Talk Time Up to 5 hours* Power Adapter Input: 100-240V～50/60Hz 120mA 10 Output: 5V/700mA 7. ALL RIGHTS RESERVED ©2015. All rights are reserved. No part of this document can be reproduced without permission. While all the efforts have been made to ensure the accuracy of contents in this manual, we presume no responsibility for errors or omissions or statements of any kind, whether such errors are omissions or statements resulting from negligence, accidents, or any other cause. We operate a policy of continuous development and reserve the right to make changes, modifications and improvements to the device, device features / specifications or any of its parts without prior 11 notice. ENVIRONMENTAL CONCERN Help us save Our Environment...GO GREEN..!! All our endeavors are directed towards providing environment friendly products to you. The materials used in our devices are recyclable and can be reused to make new products. We strive to make products that are safe for our consumers as well as the environment. Come join hands with us and make world a better place to live. Preserve natural resources for future generations by recycling your phone. The phone contains some metals, when recycled properly these can be put back into circulation, decreasing the need for new metal mining. Recycling reduces the need for raw materials, saves energy, helps mitigate Global Warming and reduces pollution, reduces waste products in landfills; therefore preserving natural resources for the future and saving the planet. Federal Communication Commission Interference Statement This device complies with part 15 of the FCC Rules. Operation 12 is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. 13 FCC Caution: Any Changes or modifications not expressly approved by the party responsible for…

Text truncated - open the document above for the full version.

Cover Letter(s)

Corporativo Lanix S.A. de C.V. Carrtera internacional Hermosillo-Nogale Km 8.5, Hermosillo 83000, Mexico Date: November 27, 2015 Federal Communications Commission 7435 Oakland Mills Road - Gate A Columbia, Maryland 21046 Subject: Request for Confidentiality FCC ID: ZC4X250 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47CFR§§0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely.  Schematic Diagram  Block Diagram  Parts List  Tune-up Procedure  Operational Description Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’ s policy, in order to comply with the marketing regulations in 47 CFT §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days after the Grant Date of Equipment Authorizations.  External Photos  Internal Photos  Test Setup Photos  Users Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards, Oscar Guzman / Product Manager Corporativo Lanix S.A. de C.V. Tel: 6621090800 Fax: 6621090848 E-mail: [email protected]

Cover Letter(s)

Corporativo Lanix S.A. de C.V. Carrtera internacional Hermosillo-Nogale Km 8.5, Hermosillo 83000, Mexico Date: November 27, 2015 Label Location Declaration We, Corporativo Lanix S.A. de C.V., state that there is no other space for putting the label on our device, FCC ID: ZC4X250, except for the space of the battery compartment of this device. The label will be put under the battery compartment and it is visible to the users as they purchase the product and install the battery. If you have any question regarding the declaration, please don’t hesitate to contact us. Thank you! Sincerely yours, _________________________ Oscar Guzman / Product Manager Corporativo Lanix S.A. de C.V. Tel: 6621090800 Fax: 6621090848 E-mail: [email protected]

Cover Letter(s)

Corporativo Lanix S.A. de C.V. Carrtera internacional Hermosillo-Nogale Km 8.5, Hermosillo 83000, Mexico Date: November 27, 2015 Power of Attorney To whom it may concern, Please be notified that I, Oscar Guzman, have designated Daniel Lee of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan Branch) of Taiwan and name in Corporativo Lanix S.A. de C.V. as the persons being responsible for this project and to sign the form 731 and other documentation. Any and all acts carried out by Daniel Lee of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan Branch) of Taiwan and name in Corporativo Lanix S.A. de C.V. on the matters relating to all processes required in the FCC approval and any communication needed with the national authority, shall have the same legal authority as acts on our own behalf. As defined in 47 CFR Ch. 1.2002 (b), we further certify that neither the applicant nor any party to this application is subject to a denial to Federal benefits, including FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act. This authorization is limited to the product of as following: FCC ID: ZC4X250 If you have any acknowledgement and response, please send it to Daniel Lee of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan Branch) of Taiwan directly. Should you have any question or comment regarding this matter, please have my best attention. Sincerely yours, Oscar Guzman / Product Manager Corporativo Lanix S.A. de C.V. Tel: 6621090800 Fax: 6621090848 E-mail: [email protected]

External Photos

ID Label/Location Info

FCC ID: ZC4X250 Label Sample: FCC ID: ZC4X250 Label Location: BACK OF THE DEVICE - Battery compartment Label Location

Internal Photos

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 6 Report Version 1 Reference No.: 151118W002 PHOTOGRAPHS OF THE EUT Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 6 Report Version 1 Reference No.: 151118W002 BT/WLAN/GPS Antenna WWAN Main Antenna Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 3 of 6 Report Version 1 Reference No.: 151118W002 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 4 of 6 Report Version 1 Reference No.: 151118W002 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 5 of 6 Report Version 1 Reference No.: 151118W002 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel.: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 6 of 6 Report Version 1 Reference No.: 151118W002

RF Exposure Info

FCC SAR Test Report Report Format Version 5.0.0 Page No. : 1 of 40 Report No. : SA151123C06 Issued Date : Dec. 01, 2015 FCC SAR Test Report Report No. : SA151123C06 Applicant : Corporativo Lanix S.A. de C.V. Address : Carretera Internacional KM 8.5 Nogales- Hermosillo Product : Smart Phone FCC ID : ZC4X250 Brand : LANIX Model No. : ILIUM X250 Standards : FCC 47 CFR Part 2 (2.1093) / IEEE C95.1:1992 / IEEE Std 1528:2013 KDB 865664 D01 v01r04 / KDB 865664 D02 v01r02 / KDB 248227 D01 v02r02 KDB 447498 D01 v06 / KDB 648474 D04 v01r03 KDB 941225 D01 v03r01 / KDB 941225 D06 v02r01 Sample Received Date : Nov. 23, 2015 Date of Testing : Nov. 23, 2015 ~ Nov. 24, 2015 CERTIFICATION: The above equipment have been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch – Lin Kou Laboratories, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. Prepared By : Evonne Liu / Specialist Approved By : Eli Hsu / Supervisor This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. FCC SAR Test Report Report Format Version 5.0.0 Page No. : 2 of 40 Report No. : SA151123C06 Issued Date : Dec. 01, 2015 Table of Contents Release Control Record ............................................................................................................................................................... 3 1. Summary of Maximum SAR Value ....................................................................................................................................... 4 2. Description of Equipment Under Test ................................................................................................................................. 5 3. SAR Measurement System ................................................................................................................................................... 6 3.1 Definition of Specific Absorption Rate (SAR) ............................................................................................................... 6 3.2 SPEAG DASY System ................................................................................................................................................. 6 3.2.1 Robot .................................................................................................................................................................. 7 3.2.2 Probes ................................................................................................................................................................ 8 3.2.3 Data Acquisition Electronics (DAE) .................................................................................................................... 8 3.2.4 Phantoms ........................................................................................................................................................... 9 3.2.5 Device Holder ................................................................................................................................................... 10 3.2.6 System Validation Dipoles ................................................................................................................................ 10 3.2.7 Tissue Simulating Liquids ................................................................................................................................. 11 3.3 SAR System Verification ............................................................................................................................................ 14 3.4 SAR Measurement Procedure ................................................................................................................................... 15 3.4.1 Area & Zoom Scan Procedure ......................................................................................................................... 15 3.4.2 Volume Scan Procedure ................................................................................................................................... 15 3.4.3 Power Drift Monitoring ...................................................................................................................................... 16 3.4.4 Spatial Peak SAR Evaluation .....................................................................................................................…

Text truncated - open the document above for the full version.

Test Report

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 55 Test Report No.: RF151118W002-1 FCC TEST REPORT (Bluetooth EDR) Product: Smart Phone Model Name: ILIUM X250 FCC ID: ZC4X250 Applicant: Corporativo Lanix S.A. de C.V. Address: Carretera Internacional KM 8.5 Nogales- Hermosillo Manufacturer: Shenzhen Konka Telecommunications Technology Co., Ltd. Address: No.9008 Shennan Road, Overseas Chinese Town, ShenZhen, Guangdong, China Prepared by: Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch Lab Location: No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China TEL: +86 769 8593 5656 FAX: +86 769 8593 1080 E-MAIL: [email protected] Report No.: RF151118W002-1 Received Date: Nov. 18, 2015 Test Date: Nov. 18, 2015 ~ Nov. 29, 2015 Issued Date: Nov. 30, 2015 Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by A2LA or any government agencies. Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 34, Chenwulu Section, Guantai Rd., Houjie Town, Dongguan City, Guangdong 523942, China Tel: +86 769 8593 5656 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 55 Test Report No.: RF151118W002-1 TABLE OF CONTENTS RELEASE CONTROL RECORD ............................................................................................................ 5 1 CERTIFICATION ............................................................................................................................... 6 2 SUMMARY OF TEST RESULTS ...................................................................................................... 7 2.1 MEASUREMENT UNCERTAINTY ............................................................................................. 7 3 GENERAL INFORMATION ............................................................................................................... 8 3.1 GENERAL DESCRIPTION OF EUT ........................................................................................... 8 3.2 DESCRIPTION OF TEST MODES ............................................................................................. 9 3.2.1 ONFIGURATION OF SYSTEM UNDER TEST ................................................................. 10 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ................................... 10 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS .......................................................... 12 3.4 DESCRIPTION OF SUPPORT UNITS ..................................................................................... 12 4 TEST TYPES AND RESULTS ........................................................................................................ 13 4.1 CONDUCTED EMISSION MEASUREMENT ........................................................................... 13 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ................................................. 13 4.1.2 TEST INSTRUMENTS....................................................................................................... 13 4.1.3 TEST PROCEDURES ....................................................................................................... 14 4.1.4 DEVIATION FROM TEST STANDARD ............................................................................. 14 4.1.5 TEST SETUP ..................................................................................................................... 15 4.1.6 EUT OPERATING CONDITIONS ...................................................................................... 15 4.1.7 TEST RESULTS ................................................................................................................ 16 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT .................................................. 18 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT ........................ 18 4.2.2 TEST INSTRUMENTS....................................................................................................... 19 4.2.3 TEST PROCEDURES ....................................................................................................... 20 4.2.4 DEVIATION FROM TEST STANDARD ............................................................................. 20 4.2.5 TEST SETUP ..................................................................................................................... 21 4.2.6 EUT OPERATING CONDITIONS ...................................................................................... 21 4.2.7 TEST RESULTS ..................…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC SAR Test Report Report Format Version 5.0.0 Issued Date : Dec. 01, 2015 Report No. : SA151123C06 Appendix D. Photographs of EUT and Setup FCC SAR Test Report Report Format Version 5.0.0 Report No. : SA151123C06 <Photographs of EUT> FCC SAR Test Report Report Format Version 5.0.0 Report No. : SA151123C06 <Antenna Location> The separation distance for antenna to edge: Antenna To Top Side (mm) To Bottom Side (mm) To Left Side (mm) To Right Side (mm) WWAN 114 0 0 19 WLAN / BT 0 108 0 45 Bottom Side Top Side Left Side Right Side <EUT Rear View> WLAN / BT Antenna WWAN Antenna FCC SAR Test Report Report Format Version 5.0.0 Report No. : SA151123C06 <Photographs of SAR Setup> Right Cheek Right Tilted Left Cheek Left Tilted FCC SAR Test Report Report Format Version 5.0.0 Report No. : SA151123C06 Front Face of EUT with 1 cm Gap Rear Face of EUT with 1 cm Gap Left Side of EUT with 1 cm Gap Right Side of EUT with 1 cm Gap Top Side of EUT with 1 cm Gap Bottom Side of EUT with 1 cm Gap
