ZCANP750XFGNotebook PC

www.samsung.com User Manual 2 Getting started 4 Device layout and functions 10 Turning the computer on and off 12 Unl ocking the screen 12 Windows Basics 13 Keyboard 15 Touchpad 18 Wir eless LAN 20 Bluetooth 22 Fingerprint recognition 25 Memory card slot 27 E xternal display 29 S ecurity slot Apps and features 30 Using apps 31 Samsung Account 32 Samsung S ettings 33 Samsung Notes 34 Samsung Update 35 Samsung Flow 35 Samsung Studio Plus 36 Samsung Gallery 37 Samsung Care+ 38 Samsung D evice Care 39 Bixby 40 Galaxy Book Smart Switch 41 Galax y Book Experience 42 Onl ine Support(S Service) 43 Stud io mode 44 S creen Recorder 45 Quick Search 46 SmartThings 47 Quick Share 47 Second Screen 48 Priv ate Share Settings & Upgrade 49 Display brightness 51 Volume 52 BIOS (Setup utility) 59 Battery Table of contents 3 Table of contents Troubleshooting 63 Samsung Recovery 68 Windows recovery function 68 Q&A Usage notices 71 Precautions for using the device 75 Ergonomic tips 79 Saf ety precautions Appendix 89 Product specifications 90 Important safety information 93 R eplacement parts and accessories 96 Regulatory compliance statements 104 WEEE symbol information 106 Samsung p ackage Take-Back program (USA only) 4 Getting started Device layout and functions Leaving the screen idle for extended periods may result in afterimages (screen burn-in) or ghosting. Turn off the screen, or turn on the screen saver or power saving mode when you are not using the computer. • Features or options may differ depending on the model. • The items marked as optional may not be provided or may be provided in different locations. • Since some space on the storage device is reserved for system recovery and operations, the available space on the storage device may be less than the actual capacity. Getting started 5 Number/NameDescription 1 Microphone • You can use the built-in microphone. 2 Camera indicator light • This indicates the camera operating status. 3 Camera • Using this camera, you can take still pictures and record video. 4 Display • The screen’s images are displayed here. 5 Power button/ Fingerprint recognition sensor • Turns the computer on and off. • The fingerprint recognition sensor recognizes fingerprints. Scans a fingerprint to sign in to Windows, apps, and services. 6 Numeric keypad • Enter numbers. 7 Keyboard • Enter text or control computer functions. 8 Touchpad • Moves the cursor and selects options. • Functions as a mouse. Front view 4 3 2 1 8 5 6 7 Getting started 6 Number/NameDescription 1 Memory card slot • Insert a memory card into the slot. 2 Earpiece/ Headset jack • Connect an earpiece or a headset to the computer to listen to audio. 3 USB 3.2 port • Connect various accessories, such as a mouse, camera, or keyboard. 4 Security slot • Secure the computer by connecting an optional lock and cable to it. Right view 1342 Getting started 7 Number/NameDescription 1 Operating status LED • Shows the operating status of the computer. ‒ Red: Charging ‒ Green: Fully charged ‒ Blue: Turned on 2 USB Type-C port • Connect the adapter to charge the computer. You can also use or charge USB Type-C devices. Also, you can connect external display devices. 3 HDMI port • Used to connect an HDMI cable to an external device. 4 USB 3.2 port • Connect various peripheral devices, such as a mouse, camera, or keyboard. Left view 14232 Getting started 8 • It may take longer to charge the battery when charging a connected device. • The battery power level may be reduced when charging a connected device while the computer is powered by the battery. • The charging status of the connected device is not displayed on the computer. • This charging feature may not be available on some devices. The charging feature of the USB Type-C port Charging the computer Connect an external power supply (sold separately) to the USB Type-C port to use it as the auxiliary power or charge the computer. Use an external power supply (sold separately) with a rating level higher than 10 W (5 V, 2 A) that supports USB Type-C or USB BC 1.2. Charging a USB Type-C device Connect and charge your USB Type-C device by connecting it to the computer. Getting started 9 Bottom view 2 33 1 Number/NameDescription 1 Fan vents • Sucks in outside air and discharges heat generated inside the computer through these holes. • If the vents are blocked the computer may overheat. Avoid blocking the vents as this may be dangerous. 2 Internal battery • Provides power to the computer when not connected to an adapter. • To remove or replace the internal battery, take it to a Samsung Service Center. You will be charged for this service. 3 Speaker • Sound is emitted from the speakers. If the case at the bottom of the device is replaced, the laser-carved model name, serial number, and various logos will not be displayed anymore. For more information, contact a Samsung Service Center. Getting started 10 Turning the computer on and off Fully charge the battery using the supplied adapter before using the computer for the first time. Turning the computer on 1 Before turning on the computer, check that the battery is charged and charge it if necessary. 2 Open the display panel. 3 The computer turns on automatically when the display panel is opened. If the computer does not turn on automatically, press the Power button. Set the device to not turn on the computer automatically when the display panel is opened. 1. SelecttheStartbutton( ) → All apps → Samsung Settings . 2. Select Advanced features → Auto booting, and then select the switch to deactivate it. Getting started 11 Turning the computer off 1 Select the Start button (). 2 Select → Shut down. Save all data before turning off the computer. About Windows Activation When you turn the computer on for the first time, the Windows Activation screen appears. Follow the activation procedures according to the instructions on the screen to use the computer. The computer’s date and time may be incorrect when you turn it on for the first …

Text truncated - open the document above for the full version.

Samsung Electronics Co., Ltd. 19 Chapin Rd.,Building D Pine Brook, NJ 07058 Tel: +1-201-937-4203 Authority to Act as Agent Date: __1205,2022_____ American Certification Body, Inc. 6731 Whit tier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: ______(CTTL,Telecommunication Technology Labs,CAICT)_ _____ is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b) , to the application is subject t o denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: _____12 months_____ By: ____________ _____Jenni Chun_________ (Signature 1 ) (Print name) Title: ______General M anager________ On behalf of: __Samsung Electronics Co., Ltd. ___ (Company Na me) Telephone: ___973-808-6375____ 022818 – 11 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead. Samsung Electronics Co., Ltd. 19 Chapin Rd.,Building D Pine Brook, NJ 07058 Tel: +1-201-937-4203 Request for Confidentiality Date: _1205,2022__ Subject: Confidentiality Request for: ____ZCANP750XFG____ Pursuant to FCC 47 CFR 0.457(d) and 0.459 and IC RSP-100, Section 9.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit ☐Short Term☒Permanent Block Diagrams ☒Short Term External Photos ☒Short Term☐Permanent * 2 Internal Photos ☐Short Term☒Permanent Operation Description/Theory of Operation ☐Short Term☒Permanent Parts List & Placement/BOM ☐Short Term☒Permanent Tune-Up Procedure ☐Short Term☒Permanent Schematics ☒Short Term Test Setup Photos ☒Short Term☐Permanent * 3 User’s Manual _____SAMSUNG Electronics______ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of __180___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: regarding specific information that must accompany these requests. 022818 – 11 Samsung Electronics Co., Ltd. 19 Chapin Rd.,Building D Pine Brook, NJ 07058 Tel: +1-201-937-4203 IC currently only distinguishes Permanent Confidentiality exhibits as shown above. Short Term confidentiality is not considered applicable to IC applications. Sincerely, By: ______ /General Manager______ ___Jenni Chun____ (Signature/Title 3 ) (Print name) 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead. 022818 – 11

PRODUCT EQUALITY DECLARATION We, Samsung Electronics Co., Ltd., declare that the “NP754XFG,NP750XFT,NP754XFT” are the variant products of the “NP750XFG And declare on our sole responsibility that the product (variant) The only difference between the NP754XFG,NP750XFT,NP754XFT and the NP750XFG is: Only differences are model names for trading purpose Author Information Signature Name Shreya Matta Place of Duty SRI-N Protocol Certification Part Tel +91-9015-662-883 E-mail [email protected]

Intel Corporation S.A .S . 425 Rue de Goa – Le Cargo B6 – 06600 Antibes – France Tel. +33 (0)4 93 00 14 00 - Fax +33 (0)4 93 00 14 01 SAS au capital de 5 208 026,16 Euros – RCS Nanterre 302 456 199 – Siret 302 456 199 00256 - TVA FR54302456199 Letter of authorization INTEL CORPORATION SAS 425 route de Goa le Cargo B6 06600 Antibes, FRANCE With this letter we are authorizing Samsung to duplicate the initial modular test reports and the report numbers: 180717-03.TR01, 180717-03.TR02, 180717-03.TR03, 180717-03.TR04, 180717-03.TR05, 180717-03.TR06, 180717-03.TR07, 180717-03.TR08, 180717-03.TR09 of the INTEL module AX201D2W with FCC ID: PD9AX201D2 which was granted on 11/20/2018 and IC: 1000M-AX201D2 on 11/26/2018, for Samsung project request of FCC ID: ZCANP750XFG and IC: 25314-NP750XFG. Sincerely, ------------------------------------------------------ Date: November 30, 2022 Wireless Product Regulatory Engineer Mobile Wireless Group Intel Corporation

Date: Dec. 05, 22 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request permission to use Wi-Fi/BT/USB partial test results from model AX201D2W in our applications for model NP750XFG FCC ID: ZCANP750XFG To whom it may concern: We request permission to use Wi-Fi/BT/USB test results from model AX201D2W (FCC ID: PD9AX201D2) in our applications for model NP750XFG (FCC ID: ZCANP750XFG). The detail information of changes are as below. NP750XFG is that host integrator for the module AX201D2W, the power class of NP750XFG is not bigger than AX201D2W, no other change for the module. For the above, we performed the test which is as below for the required bands of all. The rest test results all come from AX201D2W. The detail information of Retest: Retest or not Comments 1、SAR Full test 2、part 15C BT/BLE/WIFI (2.4g/ 5g/5.8G) Spot check the conducted power. Radiated TCs full test Spot check results of the conducted power are shown in the SAR test report. 3、part 15B Full test 4、Part 22/24/27 N/A. 5、HAC、T-coil N/A 6、DFS Radiated TCs full test Sincerely yours, Yin Feng

US/CAN Charger1: FCC/CAN Charger2: Cable:

Model : NP750XFG Input : 20 V 2.25 A (45 W) FCC ID : ZCANP750XFG Designed by Samsung Manufactured in China NP750XFG-XXXXX S/N : XXXXXXXXXXXXXXX MM.YYYY QR Code Area

No.I22Z70451-SEM02 ©Copyright. All rights reserved by CTTL. Page 1 of 90 SAR TEST REPORT No. I22Z70451-SEM02 For Samsung Electronics Co., Ltd. Notebook PC Model name: NP750XFG, NP754XFG, NP750XFT, NP754XFT With Hardware Version: REV1.0 Software Version: Windows11 FCC ID: ZCANP750XFG Issued Date: 2022-12-9 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the U.S.Government. Test Laboratory: CTTL, Telecommunication Technology Labs, CAICT No. 52, Huayuan North Road, Haidian District, Beijing, P. R. China 100191. Tel:+86(0)10-62304633-2512, Fax:+86(0)10-62304633-2504 Email: [email protected], website: www.caict.ac.cn No.I22Z70451-SEM02 ©Copyright. All rights reserved by CTTL. Page 2 of 90 REPORT HISTORY Report Number Revision Issue Date Description I22Z70451-SEM02 Rev.0 2022-12-7 Initial creation of test report I22Z70451-SEM02 Rev.1 2022-12-9 1.Revise the conductive power of WIFI5G MIMO on page27. No.I22Z70451-SEM02 ©Copyright. All rights reserved by CTTL. Page 3 of 90 TABLE OF CONTENT 1 TEST LABORATORY .................................................................................................................... 5 1.1 TESTING LOCATION ................................................................................................................................. 5 1.2 TESTING ENVIRONMENT .......................................................................................................................... 5 1.3 PROJECT DATA......................................................................................................................................... 5 1.4 SIGNATURE .............................................................................................................................................. 5 2 STATEMENT OF COMPLIANCE .................................................................................................. 6 3 CLIENT INFORMATION ................................................................................................................ 8 3.1 APPLICANT INFORMATION ........................................................................................................................ 8 3.2 MANUFACTURER INFORMATION ............................................................................................................... 8 4 EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ................................. 9 4.1 ABOUT EUT ............................................................................................................................................ 9 4.2 INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ...................................................................... 9 4.3 INTERNAL IDENTIFICATION OF AE USED DURING THE TEST......................................................................... 9 5 TEST METHODOLOGY .............................................................................................................. 10 5.1 APPLICABLE LIMIT REGULATIONS ...........................................................................................................10 5.2 APPLICABLE MEASUREMENT STANDARDS ...............................................................................................10 6 SPECIFIC ABSORPTION RATE (SAR) ...................................................................................... 11 6.1 INTRODUCTION ....................................................................................................................................... 11 6.2 SAR DEFINITION .................................................................................................................................... 11 7 TISSUE SIMULATING LIQUIDS ................................................................................................. 12 7.1 TARGETS FOR TISSUE SIMULATING LIQUID ................................................................................................12 7.2 DIELECTRIC PERFORMANCE ....................................................................................................................12 8 SYSTEM VERIFICATION ............................................................................................................ 14 8.1 SYSTEM SETUP .......................................................................................................................................14 8.2 SYSTEM VERIFICATION ...........................................................................................................................15 9 MEASUREMENT PROCEDURES .............................................................................................. 16 9.1 TESTS TO BE PERFORMED ........................................................................................................................16 9.2 GENERAL MEASUREMENT PROCEDURE ....................................................................................................18 9.3 BLUETOOTH & WI-FI MEASUREMENT PROCEDURES FOR SAR ..................................................................19 9.4 POWER DRIFT .........................................................................................................................................19 10 CONDUCTED OUTPUT POWER.............................................................................................. 20 10.1 WI-FI AND BT MEASUREMENT RESULT ..................................................................................................20 11 SIMULTANEOUS TX SAR CONSIDERATIONS ....................................................................... 28 11.1 TRANSMIT ANTENNA SEPARATION DISTANCES .......................................................................................28 11.2 SAR MEASU…

Text truncated - open the document above for the full version.

No.I22Z70451-SEM02 ©Copyright. All rights reserved by CTTL. Page 72 of 90 No.I22Z70451-SEM02 ©Copyright. All rights reserved by CTTL. Page 73 of 90 No.I22Z70451-SEM02 ©Copyright. All rights reserved by CTTL. Page 74 of 90 No.I22Z70451-SEM02 ©Copyright. All rights reserved by CTTL. Page 75 of 90 No.I22Z70451-SEM02 ©Copyright. All rights reserved by CTTL. Page 76 of 90 No.I22Z70451-SEM02 ©Copyright. All rights reserved by CTTL. Page 77 of 90 5 GHz Dipole Calibration Certificate No.I22Z70451-SEM02 ©Copyright. All rights reserved by CTTL. Page 78 of 90 No.I22Z70451-SEM02 ©Copyright. All rights reserved by CTTL. Page 79 of 90 No.I22Z70451-SEM02 ©Copyright. All rights reserved by CTTL. Page 80 of 90 No.I22Z70451-SEM02 ©Copyright. All rights reserved by CTTL. Page 81 of 90 No.I22Z70451-SEM02 ©Copyright. All rights reserved by CTTL. Page 82 of 90 No.I22Z70451-SEM02 ©Copyright. All rights reserved by CTTL. Page 83 of 90 No.I22Z70451-SEM02 ©Copyright. All rights reserved by CTTL. Page 84 of 90 No.I22Z70451-SEM02 ©Copyright. All rights reserved by CTTL. Page 85 of 90 No.I22Z70451-SEM02 ©Copyright. All rights reserved by CTTL. Page 86 of 90 No.I22Z70451-SEM02 ©Copyright. All rights reserved by CTTL. Page 87 of 90 No.I22Z70451-SEM02 ©Copyright. All rights reserved by CTTL. Page 88 of 90 No.I22Z70451-SEM02 ©Copyright. All rights reserved by CTTL. Page 89 of 90 No.I22Z70451-SEM02 ©Copyright. All rights reserved by CTTL. Page 90 of 90 ANNEX I Accreditation Certificate

2022-12-6 Regulatory WLAN Antenna Information 1/22 Regulatory WLAN Antenna Information (English Language Required for Intel Regulatory Review / Approval) (OEM/ODM or antenna vendor is required to complete this document with platform antenna information. Remove Intel references and make this your own document) Platform information Brand ODM *****Platform model name Platform type (ex: regular NB, convertible PC, AIO...etc) ̇SAR minimum separation (mm) Samsung HuaQin NB6099 NB 5.1mm *****Please fill in exact product model name and make sure the model name is visible on product cover or any parts for end users recognize for authority inspection. Antenna information Peak gain w/ cable loss (dBi) Vendor Type Antenna Part number (Main/ Tx1) Antenna Part number (Aux/Tx2) 2.4GHz 2400-2500MHz 5.2GHz 5150-5350MH z 5.5GHz 5470-5725M Hz 5.8GHz 5725-5850M Hz RX PIFA F00167213110001 0.64 1.33 0.27 0.27 RX PIFA F00167213110001 -2.36 -0.67 -1.93 -1.64 Module information (Please check with "x" when applies, or to fill-in proper model in empty column) Please specify (manual key-in) if you use non-regular sku, ie. Low power sku or mid power sku. Model Form factor and suffixes 7265 (StP2) NGW D2W 9560 (JfP2) NGW √ D2W D2W (LTE) AN NB BN 9461 (JfP1) NGW D2W 3165 (StP1) NGW 9462 (JfP1 DIV) NGW D2W 3168 (SdP) NGW AX201(HrP2) NGW √ D2W D2W (LTE) 8265 (WsP) NGW D2W AX200(CcP2) NGW D2W (LTE) 9260 (ThP2) NGW D2W (LTE) Intel Reference Gain/Type/ Separation distance Antenna Type Antenna Peak gain (In dBi) Distance to the end user ( mm) 2.4GHz 2400-2500MH z 5.2GHz 5150-5350MHz 5.5GHz 5470-5725MHz 5.8GHz 5725-5850MHz PIFA (Tx1-Ant) 2.23 2.98 2.95 2.22 >12(8260 generic sku) >8 (generic sku) >5 (low power sku) PIFA (Tx2-Ant) 2.94 0.49 1.75 1.65 >12(8260 generic sku) >8 (generic sku) >5 (low power sku) Notes (marked with ̇) ̇SAR minimum separation (mm) - Regular NB: Minimum antenna-to-body (from antenna bottom to the bottom of the device) - Tablet / Convertible PC: Minimum antenna-to-edge (5 sides of the device) 2022-12-6 Regulatory WLAN Antenna Information 2/22 Antenna Sample / Antenna Data Requirements for worldwide regulatory approval Section Description of Required OEM / ODM Antenna Information US / IC EU Japan Taiwan S.Korea 1A Part Number for Antenna only Required Required Required Required Required 1B Antenna Manufacturer Name Required Required Required Required Required 1C Description of Antenna Type Required N/A N/A N/A N/A 1D Part number of Antenna Assembly / cable impedance, length & diameter. Required Desired Desired Desired Desired 1E Tx1, Tx2 & Tx3 antenna (Peak Gain W/ cable loss) * Required Required Required Required Required 1E OR 1F, 1G, 1H 1F Tx1, Tx2 & Tx3 antenna (Peak Gain only) * Required Required Required Required Required 1G VSWR of cable including connector Required Required Required Required Required 1H Tx1, Tx2 & Tx3 antenna (Cable loss W/ connector) * Required Required Required Required Required 2 Dimensioned Photographs and Drawings of Tx1, Tx2, and Tx3 (or Rx3) antennas Required Required Required Required Required 3 Radiation patterns of antennas loaded in the host platform. Required Desired Required NA Required 4 Platform model name / number - correlated to antenna manufacturer and antenna part number Required Required Desired Required Desired 5 Photograph(s) or Drawings showing location of antennas in platform. (S. Korea requires photographs of antennas for approval submission). Taiwan requires pictures of each antenna type shown in the system. Required Required Desired Required (Photos) Required (Photos) 6 Mech. drawings / photos with dimensions of antenna locations and distance from end-user (For evaluation of SAR testing requirement). Required N/A N/A N/A N/A 7 Photograph(s) or Drawings showing the location of all antennas (WLAN, other) and distance between those transmitting antennas. Information will be used to evaluate whether co-location testing is required. Required N/A N/A N/A N/A 8 Local representative contact information for LMA/ PARS process. Required N/A N/A N/A N/A 2022-12-6 Regulatory WLAN Antenna Information 3/22 Antenna Information Section 1. Antenna Assembly Specifications  Antenna Peak Gain required being test in system basis.  1E frame contend absolutely peak antenna gain include H/V 1A 1B Manufacture 1C Antenna Type 1D 1E 1F 1G 1H Antenna Part Number Cable Assembly Part Number and Information *Peak Gain W/ Cable loss (dBi) Peak Gain w/o Cable Loss (dBi) VSWR Cable Loss (dBi) (P/N： F00167213110001 Tx1/ Rx1 Antenna Black RX Electronics Co., Ltd PIFA 1）RX 2）50 ohm Coaxial 3)length:301mm diameter:1.13mm 2400-2500MHz 0.64dBi (peak) 2400-2500MHz 1.77 dBi (peak) 2400-2500MHz 2.0 max 2400-2500MHz 1.13 dBi (peak) 5150-5350MHz 1.33dBi (peak) 5150-5350MHz 3.08dBi (peak) 5150-5350MHz 2.5 max 5150-5350MHz 1.75 dBi (peak) 5470-5725MHz 0.27 dBi (peak) 5470-5725MHz 2.09 dBi (peak) 5470-5725MHz 2.5 max 5470-5725MHz 1.82 dBi (peak) 5725-5850MHz 0.27 dBi (peak) 5725-5850MHz 2.15dBi (peak) 5725-5850MHz 2.5 max 5725-5850MHz 1.88dBi (peak) (P/N： F00167213110001 Tx2/ Rx2 Antenna Grey RX Electronics Co., Ltd PIFA 1）RX 2）50 ohm Coaxial 3)length:377mm diameter: 1.13mm 2400-2500MHz -2.36 dBi (peak) 2400-2500MHz -1.43 dBi(peak) 2400-2500MHz 2.0 max 2400-2500MHz 0.93 dBi (peak) 5150-5350MHz -0.67dBi (peak) 5150-5350MHz 0.94dBi (peak) 5150-5350MHz 2.5 max 5150-5350MHz 1.61 dBi (peak) 5470-5725MHz -1.93 dBi (peak) 5470-5725MHz -0.16dBi (peak) 5470-5725MHz 2.5 max 5470-5725MHz 1.77 dBi (peak) 5725-5850MHz -1.64 dBi (peak) 5725-5850MHz 0.22 dBi (peak) 5725-5850MHz 2.5 max 5725-5850MHz 1.86 dBi (peak) 2022-12-6 Regulatory WLAN Antenna Information 4/22 Antenna Peak Gain Table: Frequency (MHz) Tx1 antenna Tx2 (or Rx2) Antenna Horizontal Vertical Horizontal Vertical (dBi) (dBi) (dBi) (dBi) 2400 -0.86 -3.54 -4.45 -2.36 2450 0.64 -3.39 -3.29 -4.1 2500 -0.59 -2.65 -3.12 -3.72 5150 0.23 -3.29 -2.4 -2.83 5250 0.29 -1.24 -3.96 -0.67 5350 1.33 -2.12 -3.49 -3.17 5470 -0.53 -2.38 -2.41 -2.45 5600 -0.51 -1.54 -1.…

Text truncated - open the document above for the full version.

2022-12-6 Regulatory WLAN Antenna Information 1/21 Regulatory WLAN Antenna Information (English Language Required for Intel Regulatory Review / Approval) (OEM/ODM or antenna vendor is required to complete this document with platform antenna information. Remove Intel references and make this your own document) Platform information Brand ODM *****Platform model name Platform type (ex: regular NB, convertible PC, AIO...etc) ̇SAR minimum separation (mm) Samsung HuaQin NB6099 NB 5.1mm *****Please fill in exact product model name and make sure the model name is visible on product cover or any parts for end users recognize for authority inspection. Antenna information Peak gain w/ cable loss (dBi) Vendor Type Antenna Part number (Main/ Tx1) Antenna Part number (Aux/Tx2) 2.4GHz 2400-2500MHz 5.2GHz 5150-5350MH z 5.5GHz 5470-5725M Hz 5.8GHz 5725-5850M Hz SPEED PIFA F-0G-XZ-0324-000-00 -0.56 1.57 -0.03 -0.03 SPEED PIFA F-0G-XZ-0324-000-00 -2.1 2.11 0.49 2.07 Module information (Please check with "x" when applies, or to fill-in proper model in empty column) Please specify (manual key-in) if you use non-regular sku, ie. Low power sku or mid power sku. Model Form factor and suffixes 7265 (StP2) NGW D2W 9560 (JfP2) NGW D2W D2W (LTE) AN NB BN 9461 (JfP1) NGW D2W 3165 (StP1) NGW 9462 (JfP1 DIV) NGW D2W 3168 (SdP) NGW AX201(HrP2) NGW √ D2W D2W (LTE) 8265 (WsP) NGW D2W AX200(CcP2) NGW D2W (LTE) 9260 (ThP2) NGW D2W (LTE) Intel Reference Gain/Type/ Separation distance Antenna Type Antenna Peak gain (In dBi) Distance to the end user ( mm) 2.4GHz 2400-2500MH z 5.2GHz 5150-5350MHz 5.5GHz 5470-5725MHz 5.8GHz 5725-5850MHz PIFA (Tx1-Ant) 2.23 2.98 2.95 2.22 >12(8260 generic sku) >8 (generic sku) >5 (low power sku) PIFA (Tx2-Ant) 2.94 0.49 1.75 1.65 >12(8260 generic sku) >8 (generic sku) >5 (low power sku) Notes (marked with ̇) ̇SAR minimum separation (mm) - Regular NB: Minimum antenna-to-body (from antenna bottom to the bottom of the device) - Tablet / Convertible PC: Minimum antenna-to-edge (5 sides of the device) 2022-12-6 Regulatory WLAN Antenna Information 2/21 Antenna Sample / Antenna Data Requirements for worldwide regulatory approval Section Description of Required OEM / ODM Antenna Information US / IC EU Japan Taiwan S.Korea 1A Part Number for Antenna only Required Required Required Required Required 1B Antenna Manufacturer Name Required Required Required Required Required 1C Description of Antenna Type Required N/A N/A N/A N/A 1D Part number of Antenna Assembly / cable impedance, length & diameter. Required Desired Desired Desired Desired 1E Tx1, Tx2 & Tx3 antenna (Peak Gain W/ cable loss) * Required Required Required Required Required 1E OR 1F, 1G, 1H 1F Tx1, Tx2 & Tx3 antenna (Peak Gain only) * Required Required Required Required Required 1G VSWR of cable including connector Required Required Required Required Required 1H Tx1, Tx2 & Tx3 antenna (Cable loss W/ connector) * Required Required Required Required Required 2 Dimensioned Photographs and Drawings of Tx1, Tx2, and Tx3 (or Rx3) antennas Required Required Required Required Required 3 Radiation patterns of antennas loaded in the host platform. Required Desired Required NA Required 4 Platform model name / number - correlated to antenna manufacturer and antenna part number Required Required Desired Required Desired …
