ZCASMA037UMulti-band GSM/WCDMA/LTE mobile phone with Bluetooth, WLAN

GH68-XXXXX Printed in Korea Rated IPXX for water and dust resistance Read this document before operating the device Terms & Conditions Read this document before operating the mobile device, accessories, or software (defined collectively and individually as the “Product”) and keep it for future reference. This document contains important Terms and Conditions. Electronic acceptance, opening the packaging, use, or retention of the Product constitutes acceptance of these Terms and Conditions. You can obtain a copy of the complete Terms and Conditions of Samsung Standard One-year Limited Warranty by contacting Samsung at the address or phone number provided in this document. Arbitration Agreement - This Product is subject to a binding Arbitration Agreement between you and SAMSUNG ELECTRONICS AMERICA, INC. (“Samsung”). You can opt out within 30 calendar days of purchase: email [email protected] or calling 1-800-SAMSUNG (726-7864) and providing the applicable information. Quick Start Guide and Terms & Conditions Do more Find the user manual on your device SettingsTips and help Approved firmware versions This device will only operate with firmware versions that have been approved for use by your wireless carrier and the device manufacturer. If unauthorized firmware is placed on the device it might not function properly. Information about safeguarding devices We encourage customers to take appropriate measures to secure their devices and invite them to take advantage of the features available on this device to help secure it from theft and/or other unauthorized access and use. This device has a locking function (e.g., user-defined codes or patterns) that can serve as a first line of defense against unauthorized use or access to stored information. Preloaded security applications that allow customers to track or locate misplaced devices can be found on several devices. Lost or stolen devices should be immediately reported to your wireless carrier so that proper measures can be taken to protect accounts. For additional information, visit your wireless carrier's Privacy Policy. Get connected Follow the setup screens and transfer content to your new device Insert the SIM card Use the SIM tool to open the SIM tray. SIM card tray SIM cardSIM tool Insert the SIM card in the tray. 2 FPO Get help samsung.com/us/support youtube.com/samsungcare samsung.com/us/support/simulators Scan the code using your old device for more information on how to switch or visit samsung.com/us/support/ switch-to-galaxy/iphone/ samsung.com/us/support/ switch-to-galaxy/android/ Quick Start Guide and Terms & Conditions Yo u r d evi ce Use only Samsung-approved chargers and cables. Damage caused by use of accessories not approved by Samsung is not covered by warranty. Camera Volume Side key Charging & Audio port SIM card tray Cameras FPO 85 Challenger Road Ridgefield Park, NJ 07660 Phone: 1.800.SAMSUNG (726-7864) Internet: www.samsung.com © 2022 Samsung Electronics America, Inc. Samsung & Samsung Galaxy are registered trademarks of Samsung Electronics Co., Ltd. Other company and product names mentioned herein may be trademarks of their respective owners. Screen images simulated. Appearance of device may vary. Images shown are for reference only. If you use a screen protector, make sure it allows for use of touch-screen features. Specific Absorption Rate (SAR) certification information For information visit: • www.fcc.gov/general/radio-frequency- safety-0 • www.fcc.gov/encyclopedia/specific- absorption-rate-sar-cellular-telephones • www.samsung.com/sar Exposure to Radio Frequency (RF) signals Radio Frequency (RF) signals Samsung mobile products and recycling WARNING! Never dispose of batteries in a fire because they may explode. Do not disassemble, crush, puncture, heat, burn or reuse batteries. For more information, visit: www.samsung.com/recycling or call 1-800-SAMSUNG. Emergency calls Emergency calls may not be possible on all wireless mobile device networks or when certain network services and/or mobile device features are in use. Check with local service providers. If certain features are in use (e.g. call blocking) you may first need to deactivate those features before you can make an emergency call. Smart practices while driving Samsung is committed to both promoting responsible driving and giving drivers tools to address distractions. For more information, visit www.samsung.com/us/support/legal/ mobile then select Health and Safety Information > Smart practices while driving Responsible listening CAUTION! Avoid potential hearing loss by not exposing yourself to loud sounds for a prolonged period of time. For more information, visit www.samsung.com/us/support/legal/ mobile then select Health and Safety Information > Responsible listening Pacemaker and implantable medical devices CAUTION! Persons who have implantable medical devices should consult their health care provider before using mobile electronic devices. For more information, visit www.samsung.com/us/support/legal/ mobile then select Health and Safety Information > Pacemaker and implantable medical devices The Arbitration Agreement, Standard One-year Limited Warranty, End User License Agreement (EULA), and additional Health, Safety and Device care information, including: • Device Temperature • Samsung Knox security platform • Maintaining Dust and Water Resistance (IP rating) • Location, Navigation, GPS and AGPS • Wireless Emergency Alerts (WEA) are available at: English: www.samsung.com/us/support/legal/mobile Spanish: www.samsung.com/us/support/legal/mobile-sp This information is also on the device: Settings > About phone or About device or About tablet > Legal information> Samsung legal o r,search for “Legal”. You can view the Federal Communications Commission (FCC) certification, if applicable, by openingSettings>About phoneor About device orAbout tablet>Statusor Status information that it uses. However, there may be some newer wireless technologies used in t…

Text truncated - open the document above for the full version.

V1.0 DFS Client Declaration Letter Date: 2021-11-01 We have declared below featured for device, FCC ID: ZCASMA037U (1) DFS Device Master Client with Radar detection capability Client without radar detection capability (2) Active / Passive Scanning, ad hoc mode access point capability Frequency Band (MHz) Scanning Plan Ad Hoc Mode Capability Access point Capability WiFi Direct Group Owner WiFi Direct Group Client 2412 - 2462 Active Yes Yes Yes Yes 5180 – 5240 Active Yes Yes Yes Yes 5260 – 5320 Passive No No No Yes 5500 – 5580 Passive No No No Yes 5660 – 5700 Passive No No No Yes 5745 - 5825 Active Yes Yes Yes Yes (3) Country code selection capability to end user- Yes, No If yes, please explain how it was implemented: (please also help to provide detail of options for each country selection) (4) Transmission in 5600 MHz to 5650 MHz is notched - Yes, No (5) Meet Part 15.202 requirement - Yes, No A master device is defined as a device operating in a mode in which it has the capability to transmit without receiving an enabling signal. In this mode it is able to select a channel and initiate a network by sending enabling signals to other devices. A client device is defined as a device operating in a mode in which the transmissions of the device are under control of the master. A device in client mode is not able to initiate a network. (6) For client devices that have software configuration control to operate in different modes (active scanning in some and passive scanning in others) in different bands (devices with multiple equipment classes or those that operate on non-DFS frequencies) or modular devices which configure the modes of operations through software, the application must provide software and operations description on how the software and / or hardware is implemented to ensure that proper operations modes cannot be modified by end user or an installer. Apply, Not Apply, (If apply, please help to provide explanation on it was implement, and how software was controlled). V1.0 Signature ____________________________ Printed Name: Jenni Chun Position: 19 Chapin Rd.,Building D Pine Brook, NJ 07058 Company: Samsung Electronics Co., Ltd.

Sample01 Sample02 Sample03 Sample04 Sample05 Sample06 Single SIM tray： Data Cable 1：R.F.Tech Electronics (HuiZhou) Co.,Ltd. (ECB-DU68WE) Data Cable 2：DONGGUAN KSD CO.,LTD. (ECB-DU68WE) HS01（EHS61ASFWE Yuenchang）：

PCB01 PCB02 PCB03 PCB04 PCB05 PCB06 PCB07 Battery 1: Battery 2:

No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. 2450 MHz Dipole Calibration Certificate No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. 2600 MHz Dipole Calibration Certificate No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. 5GHz Dipole Calibration Certificate No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL.

No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. ANNEX I Sensor Triggering Data Summary The DUT has the proximity sensors to reduce the output power. The position of the sensor and antenna are as shown in the graphic. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. Rear, Front, Bottom and Top of the DUT was placed directly below the flat phantom. The DUT was moved toward the phantom in accordance with the steps outlined in KDB 616217 to determine the trigger distance for enabling power reduction. The DUT was moved away from the phantom to determine the trigger distance for resuming full power. No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. The DUT featured a visual indicator on its display that showed the status of the proximity sensor (Triggered or not triggered). This was used to determine the status of the sensor during the proximity sensor assessment as monitoring the output power directly was not practical without affecting the measurement. It was confirmed separately that the output power according to locking the proximity sensor status. Section 11 contains both the full and reduced conducted power measurements. Blue arrow : Direction of DUT travel for determination of power reduction triggering point. Green arrow: Direction of DUT travel for determination of normal power triggering point When the visual indicator display is “Nearly”, indicates that the status of the proximity sensor is triggered (see the figure below) Fig1.ANT1/ANT2 Fig2.ANT0 No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. When the visual indicator display is “Far away”, indicates that the status of the proximity sensor is not triggered Fig3.ANT1/ANT2 Fig4.ANT0 No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. ANT0 Front Edge Moving device toward the phantom: sensor near or far Distance [mm] 9 8 7 6 5 4 3 2 1 0 Main antenna Far away Far away Far away Far away Nearly Nearly Nearly Nearly Nearly Nearly Moving device away from the phantom: sensor near or far Distance [mm] 9 8 7 6 5 4 3 2 1 0 Main antenna Far away Far away Far away Far away Nearly Nearly Nearly Nearly Nearly Nearly Rear Edge Moving device toward the phantom: sensor near or far Distance [mm] 11 10 9 8 7 6 5 4 3 2 1 Main antenna Far away Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Moving device away from the phantom: sensor near or far Distance [mm] 14 13 12 11 10 9 8 7 6 5 4 Main antenna Far away Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Bottom Edge Moving device toward the phantom: sensor near or far Distance [mm] 16 15 14 13 12 11 10 9 8 7 6 Main antenna Far away Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. Moving device away from the phantom: sensor near or far Distance [mm] 20 19 18 17 16 15 14 13 12 11 10 Main antenna Far away Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly ANT1 Front Edge Moving device toward the phantom: sensor near or far Distance [mm] 9 8 7 6 5 4 3 2 1 0 Main antenna Far away Far away Far away Nearly Nearly Nearly Nearly Nearly Nearly Nearly Moving device away from the phantom: sensor near or far Distance [mm] 9 8 7 6 5 4 3 2 1 0 Main antenna Far away Far away Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Rear Edge Moving device toward the phantom: sensor near or far Distance [mm] 14 13 12 11 10 9 8 7 6 5 4 Main antenna Far away Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Moving device away from the phantom: sensor near or far Distance [mm] 15 14 13 12 11 10 9 8 7 6 5 Main antenna Far away Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. Top Edge Moving device toward the phantom: sensor near or far Distance [mm] 11 10 9 8 7 6 5 4 3 2 1 Main antenna Far away Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Moving device away from the phantom: sensor near or far Distance [mm] 13 12 11 10 9 8 7 6 5 4 3 Main antenna Far away Far away Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly ANT2 Front Edge Moving device toward the phantom: sensor near or far Distance [mm] 19 18 17 16 15 14 13 12 11 10 9 Main antenna Far away Far away Far away Far away Far away Nearly Nearly Nearly Nearly Nearly Nearly Moving device away from the phantom: sensor near or far Distance [mm] 19 18 17 16 15 14 13 12 11 10 9 Main antenna Far away Far away Far away Far away Nearly Nearly Nearly Nearly Nearly Nearly Rear Edge Moving device toward the phantom: sensor near or far Distance [mm] 26 25 24 23 22 21 20 19 18 17 16 Main antenna Far away Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly No.I21Z70475-SEM01 ©Copyright. All rights reserved by CTTL. Moving device away from the phantom: sensor near or far Distance [mm] 30 29 28 27 26 25 24 23 22 21 20 Main antenna Far away Far away Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Top Edge Moving device toward the phantom: sensor near or far Distance [mm] 22 21 20 19 18 17 16 15 14 13 12 Main antenna Far away Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Moving device away from the phantom: sensor near or far Distance [mm] 26 25 24 23 22 21 20 19 18 17 16 Main antenna Far away Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Nearly Per FCC KDB Publication 616217 D04v01r02, the influence of table tilt angles …

Text truncated - open the document above for the full version.

No.I21Z70475-SEM03 ©Copyright. All rights reserved by CTTL. Page 1 of 62 HAC T-Coil TEST REPORT No. I21Z70475-SEM03 For Samsung Electronics Co., Ltd. Multi-band GSM/WCDMA/LTE phone with Bluetooth, WLAN Model name: SM-A037U With Hardware Version: REV1.0 Software Version: A037U.001 FCC ID: ZCASMA037U Results Summary: T Category = T3 Issued Date: 2021-10-31 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. Test Laboratory: CTTL, Telecommunication Technology Labs, CAICT No. 51, Xueyuan Road, Haidian District, Beijing, P. R. China 100191. Tel:+86(0)10-62304633-2512, Fax:+86(0)10-62304633-2504 Email: [email protected], website: www.caict.ac.cn No.I21Z70475-SEM03 ©Copyright. All rights reserved by CTTL. Page 2 of 62 REPORT HISTORY Report Number Revision Issue Date Description I21Z70475-SEM03 Rev.0 2021-10-31 Initial creation of test report No.I21Z70475-SEM03 ©Copyright. All rights reserved by CTTL. Page 3 of 62 TABLE OF CONTENT 1 TEST LABORATORY ................................................................................................................... 5 1.1 TESTING LOCATION .......................................................................................................................... 5 1.2 TESTING ENVIRONMENT ................................................................................................................... 5 1.3 PROJECT DATA ................................................................................................................................ 5 1.4 SIGNATURE ...................................................................................................................................... 5 2 CLIENT INFORMATION ............................................................................................................... 6 2.1 APPLICANT INFORMATION ................................................................................................................. 6 2.2 MANUFACTURER INFORMATION ......................................................................................................... 6 3 EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ................................ 7 3.1 ABOUT EUT ..................................................................................................................................... 7 3.2 INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................................................ 7 3.3 INTERNAL IDENTIFICATION OF AE USED DURING THE TEST................................................................... 7 3.4 AIR INTERFACES / BANDS INDICATING OPERATING MODES .................................................................. 8 4 REFERENCE DOCUMENTS ........................................................................................................ 9 5 OPERATIONAL CONDITIONS DURING TEST ......................................................................... 10 5.1 HAC MEASUREMENT SET-UP .................................................................................................. 10 5.2 AM1D PROBE ................................................................................................................................. 11 5.3 AMCC .......................................................................................................................................... 12 5.4 AMMI ............................................................................................................................................ 12 5.5 TEST ARCH PHANTOM &PHONE POSITIONER ................................................................................... 12 5.6 ROBOTIC SYSTEM SPECIFICATIONS ................................................................................................. 13 5.7 T-COIL MEASUREMENT POINTS AND REFERENCE PLANE .................................................................... 13 6 T-COIL TEST PROCEDUERES ................................................................................................. 15 7 T-COIL PERFORMANCE REQUIREMENTS ............................................................................. 16 7.1 T-COIL COUPLING FIELD INTENSITY .................................................................................................. 16 7.2 FREQUENCY RESPONSE.................................................................................................................. 16 8 CMRS VOICE DUT CONFIGURATION ...................................................................................... 18 8.1 GSM CODEC INVESTIGATION .......................................................................................................... 18 8.2 UMTS CODEC INVESTIGATION ........................................................................................................ 18 9 VOLTE TEST SYSTEM SETUP AND DUT CONFIGURATION ................................................. 19 9.1 TEST SYSTEM SETUP FOR VOLTE OVER IMS T-COIL TESTING .......................................................... 19 9.2 CODEC CONFIGURATION ................................................................................................................. 20 9.3 RADIO CONFIGURATION .................................................................................................................. 20 9.4 LTE TDD UPLINK-DOWNLINK CONFIGURATION INVESTIGATION ......................................................... 21 10 VOWIFI TEST SYSTEM SETUP AND DUT CONFIGURATION .............................................. 23 10.1 TEST SYSTEM SETUP FOR VOWIFI OVER IMS T-COIL TESTING ...................................................... 23 10.2 CODEC CONFIGURATION ............................................................................................................... 24 10.3 RADIO CONFIGURATION ...............................................…

Text truncated - open the document above for the full version.

©Copyright. All rights reserved by CTTL. FCC PART 15 TEST REPORT No. I21Z70475-IOT04 for SAMSUNG Electronics Co., Ltd Multi-band GSM/WCDMA/LTE phone with Bluetooth, WLAN SM-A037U With FCC ID: ZCASMA037U Hardware Version: REV1.0 Software Version: A037U.001 Issued Date: 2021-10-27 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the U.S.Government. Test Laboratory: CTTL-Telecommunication Technology Labs, CAICT No. 52, Huayuan North Road, Haidian District, Beijing, P. R. China 100191. Tel:+86(0)10-62304633-2512, Fax:+86(0)10-62304633-2504 Email: [email protected], website: www.caict.ac.cn NO. I21Z70475-IOT04 Page2 of 105 ©Copyright. All rights reserved by CTTL. REPORT HISTORY Report Number Revision Description Issue Date I21Z70475-IOT04 Rev.0 1st edition 2021-10-27 I21Z70475-IOT04 Rev.0 P．14 add the Note about the Power limit. 2021-10-29 NO. I21Z70475-IOT04 Page3 of 105 ©Copyright. All rights reserved by CTTL. CONTENTS CONTENTS .................................................................................................................................................. 3 1. TEST LATORATORY .................................................................................................................. 5 1.1. INTRODUCTION & ACCREDITATION ................................................................................................. 5 1.2. TESTING LOCATION ......................................................................................................................... 5 1.3. TESTING ENVIRONMENT .................................................................................................................. 5 1.4. PROJECT DATE ................................................................................................................................. 5 1.5. SIGNATURE ...................................................................................................................................... 5 2. CLIENT INFORMATION ........................................................................................................... 7 2.1. APPLICANT INFORMATION ............................................................................................................... 7 2.2. MANUFACTURER INFORMATION ...................................................................................................... 7 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARYEQUIPMENT(AE) ....................... 8 3.1. ABOUT EUT .................................................................................................................................... 8 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST .......................................................... 8 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ............................................................. 8 3.4. GENERAL DESCRIPTION ................................................................................................................... 9 3.5. INTERPRETATION OF THE TEST ENVIRONMENT ................................................................................ 9 4. REFERENCE DOCUMENTS ..................................................................................................... 9 4.1. DOCUMENTS SUPPLIED BY APPLICANT ............................................................................................ 9 4.2. REFERENCE DOCUMENTS FOR TESTING ........................................................................................... 9 5. LABORATORY ENVIRONMENT ........................................................................................... 10 6. SUMMARY OF TEST RESULTS ............................................................................................. 10 6.1. SUMMARY OF TEST RESULTS ......................................................................................................... 10 6.2. STATEMENTS .................................................................................................................................. 10 6.3. TEST CONDITIONS ..........................................................................................................................11 7. TEST EQUIPMENTS UTILIZED ............................................................................................. 11 8. MEASUREMENT UNCERTAINTY ........................................................................................ 12 8.1 TRANSMITTER OUTPUT POWER ..................................................................................................... 12 8.2 PEAK POWER SPECTRAL DENSITY ................................................................................................. 12 8.3 OCCUPIED CHANNEL BANDWIDTH ................................................................................................ 12 8.4 BAND EDGES COMPLIANCE ........................................................................................................... 12 8.5 SPURIOUS EMISSIONS .................................................................................................................... 12 8.6 AC POWER-LINE CONDUCTED EMISSION ...................................................................................... 12 ANNEX A: MEASUREMENT RESULTS ................................................................................................ 13 A.1. MEASUREMENT METHOD .................................................................................................................. 13 A.2. MAXIMUM OUTPUT POWER ............................................................................................................... 14 A.3. PEAK POWER SPECTRAL DENSITY (CONDUCTED) ...................................................…

Text truncated - open the document above for the full version.

NO. I21Z70475-IOT04 Page62 of 105 ©Copyright. All rights reserved by CTTL. Channel 52 Frequency (MHz) Measurement Result (dBuV/m) Cable Loss (dB) Antenna Factor (dB/m) Receiver Reading (dBuV) Limit (dBuV/m) Margin (dB) Antenna Pol. (H/V) 5139.250 42.5 -28.2 32.6 38.19 54.0 11.5 V 5144.750 42.6 -28.2 32.6 38.25 54.0 11.4 V 11692.600 36.1 -25.0 38.5 22.54 54.0 17.9 H 15780.200 36.9 -21.4 40.4 17.86 54.0 17.1 H 17741.500 38.2 -20.5 40.5 18.15 54.0 15.8 H 17835.000 38.1 -20.4 40.4 18.10 54.0 15.9 H Channel 56 Frequency (MHz) Measurement Result (dBuV/m) Cable Loss (dB) Antenna Factor (dB/m) Receiver Reading (dBuV) Limit (dBuV/m) Margin (dB) Antenna Pol. (H/V) 5149.750 42.5 -28.2 32.6 38.11 54.0 11.5 V 5363.000 43.5 -27.8 32.7 38.59 54.0 10.5 H 11706.900 36.0 -25.0 38.5 22.51 54.0 18.0 H 15839.600 37.5 -21.3 40.5 18.36 54.0 16.5 V 17743.700 38.2 -20.5 40.5 18.13 54.0 15.8 H 17830.600 38.1 -20.4 40.4 18.11 54.0 15.9 H Channel 64 Frequency (MHz) Measurement Result (dBuV/m) Cable Loss (dB) Antenna Factor (dB/m) Receiver Reading (dBuV) Limit (dBuV/m) Margin (dB) Antenna Pol. (H/V) 5351.000 44.3 -27.9 32.7 39.43 54.0 9.7 H 5353.000 44.1 -27.8 32.7 39.24 54.0 9.9 H 10639.900 33.7 -26.8 37.9 22.61 54.0 20.3 V 15959.500 37.5 -21.5 40.7 18.36 54.0 16.5 H 17701.900 38.1 -20.6 40.5 18.14 54.0 15.9 V 17793.200 38.3 -20.3 40.5 18.10 54.0 15.7 H NO. I21Z70475-IOT04 Page63 of 105 ©Copyright. All rights reserved by CTTL. Channel 100 Frequency (MHz) Measurement Result (dBuV/m) Cable Loss (dB) Antenna Factor (dB/m) Receiver Reading (dBuV) Limit (dBuV/m) Margin (dB) Antenna Pol. (H/V) 5457.000 43.9 -27.7 32.8 38.86 54.0 10.1 H 5459.250 44.0 -27.7 32.8 38.90 54.0 10.0 H 10999.600 33.5 -27.0 38.0 22.50 54.0 20.5 H 16143.200 37.9 -21.2 40.8 18.30 54.0 16.1 H 17837.200 38.1 -20.4 40.4 18.09 54.0 15.9 V 17741.500 38.2 -20.5 40.5 18.18 54.0 15.8 V Channel 120 Frequency (MHz) Measurement Result (dBuV/m) Cable Loss (dB) Antenna Factor (dB/m) Receiver Reading (dBuV) Limit (dBuV/m) Margin (dB) Antenna Pol. (H/V) 5433.500 42.9 -27.7 32.8 37.84 54.0 11.1 H 5439.000 42.9 -27.7 32.8 37.82 54.0 11.1 V 11199.800 33.3 -27.3 38.1 22.45 54.0 20.7 V 15544.800 37.4 -21.5 40.2 18.72 54.0 16.6 H 17750.300 38.2 -20.4 40.5 18.11 54.0 15.8 H 17875.700 37.8 -20.6 40.4 17.96 54.0 16.2 H Channel 140 Frequency (MHz) Measurement Result (dBuV/m) Cable Loss (dB) Antenna Fac…
