ZCASMM115MMulti-band GSM/WCDMA/LTE phone with Bluetooth, WLAN

Package contents • Device • USB cable • Ejection pin • USB power adaptor • Quick start guide The items supplied with the device and their images may vary by region. Device layout To turn on the device, press and hold the Power key for a few seconds. Volume key Power key SIM card / Memory card tray Multipurpose jack Front camera Rear camera (Dual) The charger should remain close to the electric socket and easily accessible while charging. Installing a nano-SIM card • Nano-SIM cards are sold separately. • Support for single SIM and dual SIM models may vary by region. ► Single SIM models: Nano-SIM card 231 ► Dual SIM models: Nano-SIM card 2 Nano-SIM card 1 231 QUICK START GUIDE SM-M115M Visit www.samsung.com to view device information, the user manual, and more. You may incur additional charges for accessing the Internet. Printed in Korea JM19-A107M-B001 Rev.1.0 English (LTN). 10/2019 Specific Absorption Rate (SAR) certification information Your device conforms to U.S. Federal Communications Commission (FCC) standards that limit human exposure to radio frequency (RF) energy emitted by radio and telecommunications equipment. These standards prevent the sale of mobile devices that exceed a maximum exposure level (known as the Specific Absorption Rate, or SAR) of 1.6 W/kg. In normal use, the actual SAR is likely to be much lower, as the device has been designed to emit only the RF energy necessary to transmit a signal to the nearest base station. By automatically emitting lower levels when possible, your device reduces your overall exposure to RF energy. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The FCC has granted an Equipment Authorization for this model device based on the compliance of all reported SAR levels with the FCC RF exposure guidelines. Some devices are required to receive approval from the FCC. If your device required FCC approval, you can view the FCC certification by opening Settings → About phone → Status. SAR information for this and other devices can be found on the FCC website at: www.fcc.gov/oet/ea/. Follow the instructions on the website to use the FCC ID to find SAR values for the device. Safety information Read all safety information before using the device to ensure safe and proper use. You can view more safety information in the safety information menu of the Settings app. Warning Follow the warnings below to prevent incidents, such as fires or explosions, injuries, or damage to the device • Do not expose the device to physical impact or damage. • Use only Samsung-approved batteries, chargers, and cables specifically designed for your device. • Prevent the multipurpose jack and battery terminals from coming into contact with foreign materials such as metal, liquids, or dust. • If any part of the device, such as the glass or acrylic body, is broken, smokes, or emits a burning odor, stop using the device immediately. Use the device again only after it has been repaired at a Samsung Service Center. • Do not turn on or use the device when the battery compartment is exposed. • Do not disassemble or reuse the battery. • Do not allow children or animals to chew or suck the device. • The device can be used in locations with an ambient temperature of 0 °C to 35 °C. You can store the device at an ambient temperature of -20 °C to 50 °C. Using or storing the device outside of the recommended temperature ranges may damage the device or reduce the battery’s lifespan. • Do not use your device in a hot environment or near fire. • Comply with all safety warnings and regulations regarding mobile device usage while operating a vehicle. You can download and install the firmware update to upgrade your device’s software with the firmware over-the- air (FOTA) service. To check for the firmware update, launch the Settings app and tap Software update → Download and install. Some content may differ from your device depending on the region, service provider, or software version, and is subject to change without prior notice. Copyright © 2019 Samsung Electronics If your device is frozen and unresponsive, press and hold the Power key and the Volume Down key simultaneously for more than 7 seconds to restart it. The actual available capacity of the internal memory is less than the specified capacity because the operating system and default apps occupy part of the memory. The available capacity may change when you upgrade the device. • It is recommended not to use fixed graphics on part or all of the touchscreen for extended periods. Doing so may result in afterimages (screen burn-in) or ghosting. To prevent possible hearing damage when using a headset, do not listen to sound at high volume for long periods. Body-worn SAR testing has been carried out at a separation distance of 1cm. To meet RF exposure guidelines during body-worn operation, the device should be positioned at least this distance away from the body. Note: This equipment has been tested and found to comply with the limits for a Class Bdigital device, pursuant to Part 15 of the FCCRules. These limits are designed to providereasonable protection against harmfulinterference in a residential installation. Thisequipment generates, uses and can radiateradio frequency energy and, if not installed andused in accordance with the instructions, maycause harmful interference to radiocommunications.However, there is no guarantee that interferencewill not occur in a particular installation. If thisequipment does cause harmful interference to radioor television reception, which can be determined byturning the equipment off and on, the user isencouraged to try to correct the interference by oneor more of the following measures:• Reorient or relocate the receiving antenna. • Increase the separation between the equipment an…

Text truncated - open the document above for the full version.

www.samsung.com USER MANUAL SM-M115M/DS SM-M115M English. 1 1/2019. R ev.1.0 2 Table of Contents Basics 4 Read me first 6 Devic e overheating situations and solutions 9 Device layout and functions 13 Battery 15 SIM or USIM card (nano-SIM card) 18 Memor y card (microSD card) 20 Turning the device on and off 21 Initial setup 22 Samsung ac count 23 Tr ansferring data from your previous device (Smart Switch) 25 Understanding the screen 37 Notification panel 39 Entering text Apps and features 41 Installing or uninstalling apps 43 F inder 43 Phone 48 Contacts 52 M essages 55 I nternet 57 Email 58 Camera 65 G allery 70 Multi window 73 Samsung M embers 73 Samsung Notes 74 Calendar 75 Radio 77 Voice Recorder 78 My Files 78 Clock 80 C alculator 80 R eminder 83 Sharing content 84 Samsung Global G oals 84 Google apps Table of Contents 3 111 Device care 112 Optimising your device 112 Ba ttery 113 Storage 113 Memory 113 S ecurity 114 Apps 114 Gener al management 115 A ccessibility 116 Software update 116 User manual 117 About phone Appendix 118 Troubleshooting Settings 86 Introduction 86 Connections 87 W i-Fi 89 Bluetooth 90 Data saver 91 Mobile da ta only apps 91 SIM card manager (dual SIM models) 92 Mobile Hotspot and Tethering 93 More connection settings 94 Sounds and vibr ation 95 Dolb y Atmos (surround sound) 95 Notifica tions 96 Display 97 Dark mode 97 S creensaver 98 W allpapers 98 T hemes 98 Lock screen 99 Smart Lock 100 Biometrics and secur ity 100 Fac e recognition 103 Privacy 103 L ocation 104 Ac counts and backup 105 Samsung Cloud 106 G oogle 107 Advanced features 108 Motions and gestur es 108 Dual M essenger 109 Digital wellbeing & parental controls 4 Basics Read me first Please read this manual before using the device to ensure safe and proper use. • Descriptions are based on the device’s default settings. • Some content may differ from your device depending on the region, service provider, model specifications, or device’s software. • Content (high quality content) that requires high CPU and RAM usage will affect the overall performance of the device. Apps related to the content may not work properly depending on the device’s specifications and the environment that it is used in. • Samsung is not liable for performance issues caused by apps supplied by providers other than Samsung. • Samsung is not liable for performance issues or incompatibilities caused by edited registry settings or modified operating system software. Attempting to customise the operating system may cause the device or apps to work improperly. • Software, sound sources, wallpapers, images, and other media provided with this device are licensed for limited use. Extracting and using these materials for commercial or other purposes is an infringement of copyright laws. Users are entirely responsible for illegal use of media. • You may incur additional charges for data services, such as messaging, uploading and downloading, auto-syncing, or using location services depending on your data plan. For large data transfers, it is recommended to use the Wi-Fi feature. • Default apps that come with the device are subject to updates and may no longer be supported without prior notice. If you have questions about an app provided with the device, contact a Samsung Service Centre. For user-installed apps, contact service providers. • Modifying the device’s operating system or installing softwares from unofficial sources may result in device malfunctions and data corruption or loss. These actions are violations of your Samsung licence agreement and will void your warranty. Basics 5 • Depending on the region or service provider, a screen protector is attached for protection during production and distribution. Damage to the attached screen protector is not covered by the warranty. • You can see the touchscreen clearly even in strong outdoor sunlight by automatically adjusting the contrast range based on the surrounding environment. Due to the nature of the product, displaying fixed graphics for extended periods may result in afterimages (screen burn-in) or ghosting. – It is recommended not to use fixed graphics on part or all of the touchscreen for extended periods and turn off the touchscreen when not using the device. – You can set the touchscreen to turn off automatically when you are not using it. Launch the Settings app, tap Display → Screen timeout, and then select the length of time you want the device to wait before turning off the touchscreen. – To set the touchscreen to automatically adjust its brightness based on the surrounding environment, launch the Settings app, tap Display, and then tap the Adaptive brightness switch to activate it. • Depending on the region or model, some devices are required to receive approval from the Federal Communications Commission (FCC). If your device is approved by the FCC, you can view the FCC ID of the device. To view the FCC ID, launch the Settings app and tap About phone → Status. If your device does not have an FCC ID, it means that the device has not been authorised for sale in the U.S. or its territories and may only be brought to the U.S. for the owner’s personal use. • Depending on the region, you can view the regulatory information on the device. To view the information, launch the Settings app and tap About phone → Regulatory information . Instructional icons Warning: situations that could cause injury to yourself or others Caution: situations that could cause damage to your device or other equipment Notice: notes, usage tips, or additional information Basics 6 Device overheating situations and solutions When the device heats up while charging the battery While charging, the device and the charger may become hot. During wireless charging or fast charging, the device may feel hotter to the touch. This does not affect the device’s lifespan or performance and is in the device’s normal range of operation. If the battery becomes too hot, the charger may stop charging. Do the following wh…

Text truncated - open the document above for the full version.

Package contents • Device • USB cable • Ejection pin • USB power adaptor • Quick start guide The items supplied with the device and their images may vary by region. Device layout To turn on the device, press and hold the Power key for a few seconds. Volume key Power key SIM card / Memory card tray Multipurpose jack Front camera Rear camera (Dual) The charger should remain close to the electric socket and easily accessible while charging. Installing a nano-SIM card • Nano-SIM cards are sold separately. • Support for single SIM and dual SIM models may vary by region. ► Single SIM models: Nano-SIM card 231 ► Dual SIM models: Nano-SIM card 2 Nano-SIM card 1 231 QUICK START GUIDE SM-M115M/DS Visit www.samsung.com to view device information, the user manual, and more. You may incur additional charges for accessing the Internet. Printed in Korea JM19-A107M-B001 Rev.1.0 English (LTN). 10/2019 Specific Absorption Rate (SAR) certification information Your device conforms to U.S. Federal Communications Commission (FCC) standards that limit human exposure to radio frequency (RF) energy emitted by radio and telecommunications equipment. These standards prevent the sale of mobile devices that exceed a maximum exposure level (known as the Specific Absorption Rate, or SAR) of 1.6 W/kg. In normal use, the actual SAR is likely to be much lower, as the device has been designed to emit only the RF energy necessary to transmit a signal to the nearest base station. By automatically emitting lower levels when possible, your device reduces your overall exposure to RF energy. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The FCC has granted an Equipment Authorization for this model device based on the compliance of all reported SAR levels with the FCC RF exposure guidelines. Some devices are required to receive approval from the FCC. If your device required FCC approval, you can view the FCC certification by opening Settings → About phone → Status. SAR information for this and other devices can be found on the FCC website at: www.fcc.gov/oet/ea/. Follow the instructions on the website to use the FCC ID to find SAR values for the device. Safety information Read all safety information before using the device to ensure safe and proper use. You can view more safety information in the safety information menu of the Settings app. Warning Follow the warnings below to prevent incidents, such as fires or explosions, injuries, or damage to the device • Do not expose the device to physical impact or damage. • Use only Samsung-approved batteries, chargers, and cables specifically designed for your device. • Prevent the multipurpose jack and battery terminals from coming into contact with foreign materials such as metal, liquids, or dust. • If any part of the device, such as the glass or acrylic body, is broken, smokes, or emits a burning odor, stop using the device immediately. Use the device again only after it has been repaired at a Samsung Service Center. • Do not turn on or use the device when the battery compartment is exposed. • Do not disassemble or reuse the battery. • Do not allow children or animals to chew or suck the device. • The device can be used in locations with an ambient temperature of 0 °C to 35 °C. You can store the device at an ambient temperature of -20 °C to 50 °C. Using or storing the device outside of the recommended temperature ranges may damage the device or reduce the battery’s lifespan. • Do not use your device in a hot environment or near fire. • Comply with all safety warnings and regulations regarding mobile device usage while operating a vehicle. You can download and install the firmware update to upgrade your device’s software with the firmware over-the- air (FOTA) service. To check for the firmware update, launch the Settings app and tap Software update → Download and install. Some content may differ from your device depending on the region, service provider, or software version, and is subject to change without prior notice. Copyright © 2019 Samsung Electronics If your device is frozen and unresponsive, press and hold the Power key and the Volume Down key simultaneously for more than 7 seconds to restart it. The actual available capacity of the internal memory is less than the specified capacity because the operating system and default apps occupy part of the memory. The available capacity may change when you upgrade the device. • It is recommended not to use fixed graphics on part or all of the touchscreen for extended periods. Doing so may result in afterimages (screen burn-in) or ghosting. To prevent possible hearing damage when using a headset, do not listen to sound at high volume for long periods. Body-worn SAR testing has been carried out at a separation distance of 1cm. To meet RF exposure guidelines during body-worn operation, the device should be positioned at least this distance away from the body. Note: This equipment has been tested and found to comply with the limits for a Class Bdigital device, pursuant to Part 15 of the FCCRules. These limits are designed to providereasonable protection against harmfulinterference in a residential installation. Thisequipment generates, uses and can radiateradio frequency energy and, if not installed andused in accordance with the instructions, maycause harmful interference to radiocommunications.However, there is no guarantee that interferencewill not occur in a particular installation. If thisequipment does cause harmful interference to radioor television reception, which can be determined byturning the equipment off and on, the user isencouraged to try to correct the interference by oneor more of the following measures:• Reorient or relocate the receiving antenna. • Increase the separation between the equipment…

Text truncated - open the document above for the full version.

THISMUSTBESIGNEDBYTHEAPPLICANTANDSHOULDBEPLACEDON APPLICANTSLETTERHEADONLYIFAGENTISSUBMITTINGAPPLICATION 022818–11 AuthoritytoActasAgent Date:__1105,2019_____ AmericanCertificationBody,Inc. 6731WhittierAvenue SuiteC110 McLean,VA22101 ToWhomItMayConcern: ______(CTTL,TelecommunicationTechnologyLabs,CAICT)______isauthorizedtoactonourbehalf, untilotherwisenotified,forapplicationstoAmericanCertificationBody,Inc.(ACB). Wecertifythatwearenotsubjecttodenialoffederalbenefits,thatincludesFCCbenefits,pursuantto Section5301oftheAnti-DrugAbuseActof1988,21U.S.C.862.Further,noparty,asdefinedin47 CFR1.2002(b),totheapplicationissubjecttodenialoffederalbenefits,thatincludesFCCbenefits. Thankyou, AgencyAgreementExpirationDate:_____12months_____ By:_________________JenniChun_________ (Signature 1 )(Printname) Title:______GeneralManager________ Onbehalfof:__SamsungElectronicsAmerican,Inc___ (CompanyName) Telephone:___973-808-6375____ 1 -MustbesignedbyapplicantcontactgivenforapplicantontheFCCsite,orbytheauthorizedagentifanappropriate authorizedagentletterhasbeenprovided.Lettersshouldbeplacedonappropriateletterhead. THISMUSTBESIGNEDBYTHEAPPLICANT/AGENTANDSHOULDBE PLACEDONAPPROPRIATELETTERHEAD 022818–11 RequestforConfidentiality Date:_1105,2019__ Subject:ConfidentialityRequestfor:____ZCASMM115M____ PursuanttoFCC47CFR0.457(d)and0.459andICRSP-100,Section9.4,theapplicantrequeststhatapartofthe subjectFCCapplicationbeheldconfidential. TypeofConfidentialityRequestedExhibit ☐ShortTerm☒PermanentBlockDiagrams ☒ShortTermExternalPhotos ☒ShortTerm☐Permanent* 2 InternalPhotos ☐ShortTerm☒PermanentOperationDescription/TheoryofOperation ☐ShortTerm☒PermanentPartsList&Placement/BOM ☐ShortTerm☒PermanentTune-UpProcedure ☐ShortTerm☒PermanentSchematics ☒ShortTermTestSetupPhotos ☒ShortTerm☐Permanent* 3 User’sManual _____SAMSUNGElectronics______hasspentsubstantialeffortindevelopingthisproductanditisoneofthefirst ofitskindinindustry.Havingthesubjectinformationeasilyavailableto"competition"wouldnegatetheadvantage theyhaveachievedbydevelopingthisproduct.Notprotectingthedetailsofthedesignwillresultinfinancial hardship. PermanentConfidentiality: Theapplicantrequeststheexhibitslistedaboveaspermanentlyconfidentialbepermanentlywithheldfrompublic reviewduetomaterialsthatcontaintradesecretsandproprietaryinformationnotcustomarilyreleasedtothepublic. Short-TermConfidentiality: Theapplicantrequeststheexhibitsselectedaboveasshorttermconfidentialbewithheldfrompublicviewfora periodof__180___daysfromthedateoftheGrantofEquipmentAuthorizationandpriortomarketing.Thisisto avoidprematurereleaseofsensitiveinformationpriortomarketingorreleaseoftheproducttothepublic.Applicant isalsoawarethattheyareresponsibletonotifyACBintheeventinformationregardingtheproductortheproductis madeavailabletothepublicbeforetherequestedperiodhasexpired.ACBwillthenreleasethedocumentslisted aboveforpublicdisclosurepursuanttoFCCPublicNoticeDA04-1705. NOTEforIndustryCanadaApplications: ICcurrentlyonlydistinguishesPermanentConfidentialityexhibitsasshownabove.ShortTermconfidentialityisnot consideredapplicabletoICapplications. Sincerely, By:______ /GeneralManager _________JenniChun____ (Signature/Title 3 )(Printname) 2 -Theasteriskeditems(*)requirefurtherinformationtobeprovidedtoACBbeforepermanentconfidentialitywillbe extendedtotheseexhibits.PleaserefertoFCCKDB726920andthespecificDocumentlinkforD01foundat: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731andreviewsectionII,3)regarding specificinformationthatmustaccompanytheserequests. 3 -MustbesignedbyapplicantcontactgivenforapplicantontheFCCsite,orbytheauthorizedagentifanappropriate authorizedagentletterhasbeenprovided.Lettersshouldbeplacedonappropriateletterhead.

Date:Feb.18,20 To:FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Subject:RequestpermissiontouseWi-Fi/BT/USB/GSM/WCDMA/LTEparitaltest resultsfrommodelSM-A115M/DSinourapplicationsformodelSM-M115M/DS， SM-M115M FCCID:ZCASMM115M Towhomitmayconcern: WerequestpermissiontouseWi-Fi/BT/USB/GSM/WCDMA/LTE(partialbands)test resultsfrommodelSM-A115M/DS(FCCID:ZCASMA115M)inourapplicationsfor modelSM-M115M/DS，SM-M115M(FCCID:ZCASMM115M). Thedetailinformationofchangesareasbelow. SM-M115M(SingleSIM) HWversion:REV1.0 SWversion:M115M.001(M115MUBE0ATA8) FCCID:ZCASMM115M isinallrelevantpartsidenticaltotheproduct SM-M115M/DS(DualSIM) HWversion:REV1.0 SWversion:M115M.001(M115MUBE0ATA8) FCCID:ZCASMM115M isinallrelevantpartsidenticaltotheproduct SM-A115M/DS HWversion:REV1.0 SWversion:A115M.001(A115MUBU0ATA1) TheonlydifferencebetweentheSM-M115M/DSandtheSM-M115Mis: SM-M115MisaSingleSIMmodel. SM-M115M/DSisaDueSIMmodel. TheonlydifferencebetweentheSM-A115M/DSandtheSM-M115M/DSis: HW: -BatteryChanges:4000mAhbatteryreplacedwith5000mAh -Sizechange SW: -Nochange Fortheabove,weperformedthetestwhichisasbelowfortherequiredbandsofall. TheresttestresultsallcomefromtheinitialmodelSM-A115M/DS. ThedetailinformationofRetest: Retestornot 1、SAR Fulltest 2、part15CBT/BLE/WIFISpotcheckthepower 3、part15BReuse 4、Part22/24/27Spotcheckthepowerand testallTCsfornewband. SpotcheckonGSM1900 &WCDMAB4&B5.LTE B7 Sincerelyyours, YinFeng

PRODUCTEQUALITYDECLARATION We,SamsungElectronicsCo.,Ltd.,declarethatthe“SM-A115M/DS”istheparentproductofthe “SM-M115M/DS”and“SM-M115M” Anddeclareonoursoleresponsibilitythattheproduct(variant) SM-M115M(SingleSIM) HWversion:REV1.0 SWversion:M115M.001(M115MUBE0ATA8) FCCID:ZCASMM115M isinallrelevantpartsidenticaltotheproduct SM-M115M/DS(DualSIM) HWversion:REV1.0 SWversion:M115M.001(M115MUBE0ATA8) FCCID:ZCASMM115M isinallrelevantpartsidenticaltotheproduct SM-A115M/DS HWversion:REV1.0 SWversion:A115M.001(A115MUBU0ATA1) TheonlydifferencebetweentheSM-M115M/DSandtheSM-M115Mis: 1.H/W -NochangeinRF. 2.S/W SM-M115MisaSingleSIMmodel. TheonlydifferencebetweentheSM-A115M/DSandtheSM-M115M/DSis: 1.H/W -BatteryChanges:4000mAhbatteryreplacedwith5000mAh -Sizechange 2.S/W -Nochange AuthorInformationSignature NameShreyaMatta PlaceofDut y SRI-NProtocolCertificationPart Tel+91-9015-662-883 [email protected]

SM-M115M/DSLabel: SM-M115MLabel: Sample01 Sample02 Sample03 Sample04 Sample05 Sample06 Simtray1: SIM:Tray2： 数据线： CH01:英 CH02:欧 HS01: HS02:

Notes: 1. Font - SamsungOne 600 _ 3.4 pt 4mm 55..1mm1mm 77..1mm1mm

Notes: 1. Font - SamsungOne 600 _ 3.4 pt 4mm 55..1mm1mm 77..1mm1mm

SM-M115M/DS Label: SM-M115M Label: PCB01 PCB02: PCB03: PCB04: PCB05: PCB06: PCB07: Battery01: Battery02:

TEST REPORT No. I20Z70001-EMC01 for Samsung Electronics. Co., Ltd. Mobile phone Model Name: SM-M115M/DS, SM-M115M FCC ID: ZCASMM115M with Hardware Version: REV1.0 Software Version: M115M.001 (M115MUBE0ATA8) Issued Date: 2020 -02-19 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the U.S.Government. Test Laboratory: CTTL-Telecommunication Technology Labs, CAICT No. 52, Huayuan North Road, Haidian District, Beijing, P. R. China 100191. Te l:+86(0)10-62304633-2512, Fax:+86(0)10-62304633-2504 Email: [email protected], website: www.caict.ac.cn ©Copyright. All rights reserved by CTTL. No.I20Z70001-EMC01 REPORT HISTORY Report Number Revision Description Issue Date I20Z70001-EMC01 R ev.0 1 st edition 2020-02-19 ©Copyright. All rights reserved by CTTL. Page 2 of 43 No.I20Z70001-EMC01 CONTENTS 1. TEST LABORATORY ............................................................................................................... 4 1.1. INTRODUCTION & ACCREDITATION ................................................................................. 4 1.2. TESTING LOCATION ........................................................................................................... 4 1.3. TESTING ENVIRONMENT ................................................................................................... 4 1.4. PROJECT DATA ................................................................................................................... 4 1.5. SI GNATURE .......................................................................................................................... 4 2. CLIENT INFORMATION ........................................................................................................... 5 2.1. APPLICANT INFORMATION ................................................................................................ 5 2.2. MANUFACTURER INFORMATION ...................................................................................... 5 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 6 3.1. ABOUT EUT .......................................................................................................................... 6 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 6 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................... 6 3.4. EUT SET-UPS ....................................................................................................................... 7 4. REFERENCE DOCUMENTS .................................................................................................... 8 4.1. REFERENCE DOCUMENTS FOR TESTING....................................................................... 8 5. LABORATORY ENVIRONMENT .............................................................................................. 9 6. SUMMARY OF TEST RESULTS ............................................................................................ 10 7. TEST EQUIPMENTS UTILIZED ............................................................................................. 11 ANNEX A: MEASUREMENT RESULTS ....................................................................................... 12 ANNEX B: PERSONS INVOLVED IN THIS TESTING ................................................................. 43 ©Copyright. All rights reserved by CTTL. Page 3 of 43 No.I20Z70001-EMC01 1. Test Laboratory 1.1. Introduction & Accreditation Telecommunication Technology Labs, CAICT is an ISO/IEC 17025:2005 accredited test laboratory under NATIONAL VOLUNTARY LABORATORY ACCREDITATION PROGRAM (NVLAP) with lab code 600118-0, and is also an FCC accredited test laboratory (CN5017), and ISED accredited test laboratory (CN0066). The detail accreditation scope can be found on NVLAP website. 1.2. Testing Location CTTL (BDA) Address: No.18A, Kangding Street, Beijing Economic-Technology Development Area, Beijing, P. R. China 100176 1.3. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.4. Project data Testing Start Date: 2019-12-19 Testing End Date: 2020-02-19 1.5. Signature Li Yan (Prepared this test report) Zhang Ying (Reviewed this test report) Liu Baodian Deputy Director of the laboratory (Approved this test report) ©Copyright. All rights reserved by CTTL. Page 4 of 43 No.I20Z70001-EMC01 2. Client Information 2.1. Applicant Information Company Name: Samsung Electronics. Co., Ltd. Address: R5, A Tower 22 Floor A-1,(Maetan dong) 129,Samsung-ro,Yeongtong-gu, Suwon-Si, Gyeonggi-do 16677, Korea City: / Postal Code: / Country: / Contact: JP KIM Email: [email protected] Telephone: +82-10-4376-0326 2.2. Manufacturer Information Company Name: Samsung Electronics. Co., Ltd. Address: R5, A Tower 22 Floor A-1,(Maetan dong) 129,Samsung-ro,Yeongtong-gu, Suwon-Si, Gyeonggi-do 16677, Korea City: / Postal Code: / Country: / Contact: JP KIM Email: [email protected] Telephone: +82-10-4376-0326 ©Copyright. All rights reserved by CTTL. Page 5 of 43 No.I20Z70001-EMC01 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description Mobile phone Model Name SM-M115M/DS, SM-M115M FCC ID ZCASMM115M Extreme vol. Limits 3.6VDC to 4.2VDC (nominal: 3.82VDC) Note: Components list, …
