ZD7DNMM-K15G-WIFI

1 Copyright Statement No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photocopying, recording or otherwise without the prior writing of the publisher. Windows ™ 98SE/2000/ME/XP are trademarks of Microsoft ® Corp. Pentium is trademark of Intel. All copyright reserved. 2 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: ● Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and receiver. ● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ● Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter. This device is going to be operated in 5.15~5.25GHz frequency range, it is restricted in indoor environment only. 3 IMPORTANT NOTE: This module is intended for OEM integrator. The OEM integrator is still responsible for the FCC compliance requirement of the end product, which integrates this module. 20cm minimum distance has to be able to be maintained between the antenna and the users for the host this module is integrated into. Under such configuration, the FCC radiation exposure limits set forth for an population/uncontrolled environment can be satisfied. Any changes or modifications not expressly approved by the manufacturer could void the user's authority to operate this equipment. USERS MANUAL OF THE END PRODUCT: In the users manual of the end product, the end user has to be informed to keep at least 20cm separation with the antenna while this end product is installed and operated. The end user has to be informed that the FCC radio-frequency exposure guidelines for an uncontrolled environment can be satisfied. The end user has to also be informed that any changes or modifications not expressly approved by the manufacturer could void the user's authority to operate this equipment. If the size of the end product is smaller than 8x10cm, then additional FCC part 15.19 statement is required to be available in the users manual: This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. LABEL OF THE END PRODUCT: The final end product must be labeled in a visible area with the following " Contains TX FCC ID: ZD7DNMM-K1 ". If the size of the end product is larger than 8x10cm, then the following FCC part 15.19 statement has to also be available on the label: This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. 4 Table of Contents 1. INTRODUCTION 5 2. DRIVER/UTILITY INSTALLATION / UNINSTALLATION 6 2.1 INSTALLATION..........................................................................................................6 2.2 ADDITIONAL SETUP PROCESSES..............................................................................9 2.3 UNINSTALLATION...................................................................................................10 3. CONNECTING TO AN EXISTING NETWORK 11 4. CREATING AN AD HOC NEW NETWORK 16 5. MODIFYING A WIRELESS NETWORK 20 5.1 INFRASTRUCTURE MODE AND AD HOC MODE.....................................................20 5.2 MODIFYING A WIRELESS NETWORK.....................................................................21 5.3 DEFAULT SETTINGS WINDOWS XP ZERO-CONFIGURATION................................28 5.4 SUPER A/G SETTING...........................................................錯誤! 尚未定義書籤。 APPENDIX A: FAQ ABOUT WLAN 29 APPENDIX B: SPECIFICATION 31 5 1. Introduction Thank you for purchasing the WLAN mini-PCI Module that provides the easiest way to wireless networking. This User Manual contains detailed instructions in the operation of this product. Please keep this manual for future reference. System Requirements z A laptop PC contains: - 32 MB memory or greater - 300 MHz processor or higher z Microsoft ® Win ™ 2000/ME/98 Second Edition/XP 6 2. Driver/Utility Installation / Uninstallation 2.1 Installation Note! The Installation Section in this User Manual describes the first-time installation for Windows. To re-install the driver, please first uninstall the previously installed driver. See Chapter 2.3 “Uninstallation” in this User Manual. Follow the steps below to complete the driver/utility installation: 1. Insert the Ins…

Text truncated - open the document above for the full version.

Ad-hoc attestation We, Nimbus, Inc. declares that device does not “ Ad Hoc on non-US frequencies and/ or DFS frequencies” while applying for the follow product. FCC ID: ZD7DNMM-K1 If you have any questions regarding the authorization, please don’t hesitate to contact us, Thank you ----------------------------------------------- Ho Geon Kim / Manager Nimbus, Inc.

Nimbus, Inc. Suite 619 Hanshin S-meca, 1359, Gwanpyeong-dong, Yuseong-gu, Daejeon, Korea. Date: Apirl 05, 2011 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 To whom it may concern: I, the undersigned, hereby authorize Technical Manager KT Kang of THRU-KES CO., LTD. and hereafter referred to as THRU-KES CO., LTD , to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by KT Kang of THRU-KES CO., LTD. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing THRU-KES CO., LTD. as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; Nimbus, Inc. Suite 619 Hanshin S-meca, 1359, Gwanpyeong-dong, Yuseong-gu, Daejeon, Korea. h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Ho Geon Kim / Manager Nimbus, Inc. REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.

Nimbusr Inc. E-llai1 : shki-u0ninbust.con Tel. : 82-42-936-0751 Fax. : 82-42-936-0752 April 05, 2011 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: ZDTDNMM-KI Pursuant to Sections 0.457 and 0.459 of the Commission's Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Part List CONF APPENDIX _ DNMM.KI - PATI LiSI.PDF Schematics Diagram(s) CONF APPENDIX - DNMM-KI - Schemetics.PDF Block diasram CONF APPENDIX - DNMM-KI - Block diagram.PDF The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Ho Geon Kim / Manager ,4, 6O* L- /+, - of' >oit

Cover Letter We, Company Name : Nimbus, Inc. Address : Suite 619 Hanshin S-meca, 1359, Gwanpyeong-dong, Yuseong-gu, Daejeon, Country : Korea Declare that: The Nimbus 802.11N adapter model name:DNMM-K1 / FCC ID:ZD7DNMM-K1 has One mode of operation: 1) Only client also known as 802.11 station mode.(Slave) In client(slave) mode, the Nimbus 802.11N adapter has no support for 1) radar detection - This device only support HT40 of 802.11n mode - This device will not initiate any transmission on DFS frequency Ho Geon Kim / Manager Nimbus, Inc.

Applicant / Grantee Nimbus, Inc FCC ID ZD7DNMM-K1 Section 15.212 Modular Transmitters Request for Modular Approval Request for Limited Modular Approval Requirements EUT Conditions Comply (Y/N) Single Modular Approval Requirements 1 The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. The device is equipped with Metal shielding to cover RF section. Refer to the external photos Y 2 The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over- modulation. All inputs to the modules are buffered through logic or microprocessor inputs. Y 3 The modular transmitter must have its own power supply regulation.. Power supply regulation built into module. Refer to the circuit diagram. Y 4 The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. Connector is unique. Y 5 The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with Part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters Refer to the test report and setup photo. Y to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see Section 15.31(i)). 6 The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. (A) If using a permanently affixed label, the modular transmitter must be labeled with its own FCC identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. (B) If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronic display. A copy of these instructions must be included Label is to be placed on front of the EUT, and other label is to be placed in the User Manual. Refer to the FCC ID label format. Y in the application for equipment authorization. 7 The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Refer to the User manual Y 8 The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. It complies with RF exposure requirement. Y

www.kes.co.kr EUT External Photographs

www.kes.co.kr FCC ID label and Location LABEL

www.kes.co.kr EUT Internal Photographs

E - m a i l : s a l e s @ w e l l s h o w. c o m . t w Tel: +886-2-24239376 Fax: +886-2-24260387 9F., No.181, Nanrong Rd., Ren-ai Dist., Keelung City 200, Taiwan (R.O.C.) RF Connector, RF Cable & Antenna Manufacturer AR006 WLAN 2.4/5.8GHz Antenna Swivel Type Product No. AR006WSW0319N (RP-SMA Plug) AR006WSW0301N (SMA Plug) PRODUCT SPECIFICATION www.wellshow.com Rev. 2 AR006 WLAN 2.4/5.8GHz Antenna 2 / 2 WLAN 2.4/5.8GHz Antenna Swivel type P/N AR006WSW0319N (RP-SMA Plug) P/N AR006WSW0301N (SMA Plug) Structure Figure Unit: mm Mechanical Test results Electrical Antenna CoverTPEE (Black) Antenna BasePC + PBT (Black) Operating Temperature -20°C~+65°C Storage Temperature -30°C~+75°C ConnectorRP-SMA Plug (19N) SMA Plug (01N) Cable Type RG316 Frequency Range2.4/5.8 GHz Impedance50 Ω Return Loss-15.8 dB @ 2.4 Ghz -16.4 dB @ 5.8 GHz Certain directionOmni V.S.W.R< 2.0 : 1 Gain4.30dBi/2.4GHz 3.94dBi/5.8GHz Return Loss RP SMA Plug / SMA Plug www.wellshow.com Rev. 2 AR006 WLAN 2.4/5.8GHz Antenna 3 / 2 Gain

PSD8153001 Rev B MtW8150 WLAN Transceiver Detailed Datasheet CONFIDENTIAL 1 MtW8153 2x3 5GHz MIMO Wireless Transceiver Detailed Datasheet PSD8153001 Rev -B 2 CONFIDENTIAL MtW8150 WLAN Transceiver Detailed Datasheet Worldwide Technical Support: For Technical Support contact information, please visit our web site at: http://www.mtlk.com © 2008 Metalink Ltd. All rights reserved. Metalink TM and WLANPlus™ are trademarks of Metalink Ltd. All other company names, product or component names are the property of their respective companies. Patents pending. No patent rights or licenses to any of the devices or products described herein are implied or granted to any third party. THIS MATERIAL IS PROVIDED AS IS AND WITHOUT ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NON- INFRINGEMENT. Metalink Ltd. reserves the right to make changes without further notice to any device and product herein to improve reliability, function or design. Metalink Ltd. assumes no responsibility for the use of this information or use of any device, product, or component described herein. Metalink's total liability in damages or otherwise shall not exceed the payment, if any, received by Metalink for the product or service furnished or to be furnished, as the case may be, resulting in the loss or damage claimed. In no event shall Metalink be liable for any indirect, incidental, special, punitive, or consequential damages as a result of its use Metalink Ltd. products are not authorized for use as components in life support devices or systems intended for surgical implant into the body or intended to support or sustain life. The buyer agrees to notify Metalink Ltd. of any such intended end use whereupon Metalink Ltd. shall determine availability and suitability of its product or products for the use intended. PSD8153001 Rev B MtW8150 WLAN Transceiver Detailed Datasheet CONFIDENTIAL 3 Revision Record Table Rev Description of Change Revision Date - Initial release of detailed datasheet June 20, 2007 A Updates for conditional release October 3, 2007 B Updates for full release February 28,2008 PSD8153001 Rev -B 4 CONFIDENTIAL MtW8150 WLAN Transceiver Detailed Datasheet Table of Contents General Description ..................................................................................................... 5 1 Pinout Descriptions ............................................................................................... 7 2 Electrical specifications ...................................................................................... 11 2.1 Absolute Maximum Ratings ......................................................................................................... 11 2.2 Operating Conditions ................................................................................................................... 12 2.3 Thermal Conditions ...................................................................................................................... 12 3 Receiver Specifications ...................................................................................... 13 4 Transmitter Specifications .................................................................................. 13 5 Synthesizer Specifications ................................................................................. 14 6 Timing Specifications ......................................................................................... 15 7 Theory of operation ............................................................................................. 16 7.1 Overview ...................................................................................................................................... 16 7.2 Receive Path ............................................................................................................................... 16 7.3 Transmit Path .............................................................................................................................. 17 7.4 Calibration Circuits ....................................................................................................................... 17 7.5 Power Modes ............................................................................................................................... 17 7.6 Digital Interface ............................................................................................................................ 17 8 Typical peripherial circuits ................................................................................. 20 8.1 RF input ....................................................................................................................................... 20 8.2 PLL loop filter ............................................................................................................................... 20 8.3 Package Outline Drawing ............................................................................................................ 21 8.4 Marking Information ..................................................................................................................... 22 9 Ordering Information ........................................................................................... 23 PSD8153001 Rev B MtW8150 WLAN Transceiver Detailed Datasheet CONFIDENTIAL 5 General Description Overview The MtW8153 is a fully integrated single chip, triple receiver - dual Transmitter radio frequency integrated circuit (RFIC) designed to support the emerging IEEE 802.11n WLAN standard for MIMO applications. It operates in the 4.9 GHz to 5.9 GHz World Band frequency range (802.11a/n). That is making it compatible with both the new 802.11n and legacy 802.11a standards. By implementing real MIMO technology, the MtW8153 supports Phy rates in excess of 300Mbps and two to eight times extended reach. Additionally, MtW8153 offers true performance scalability to support higher …

Text truncated - open the document above for the full version.

www.kes.co.kr Page 1 of 2 RF EXPOSURE EVALUATION Applicant : Nimbus, Inc. Applicant Address : Suit 619 Hanshin S-meca, 1359 Gwanpyeon- dong,Yuseong-gu, Daejeon, Korea Kind of Product : 5G-WiFi Equipment model name : DNMM-K1 Antenna type : Chip antenna Gain: 3.94dBi Frequency Range : : 802.11a/n – Band1 _ 5150MHz ~ 5250MHz Band2 _ 5250MHz ~ 5350MHz Band4 _ 5725MHz ~ 5825MHz Number of channels : Band 1 : 2CH Band 2 : 2CH Band 4 : 2CH Channel Spacing : 40 MHz www.kes.co.kr Page 2 of 2 ** MPE Calculations ** The EUT will only be used with a separation of 20 centimeters or greater between the antenna and the body of the user. The MPE calculation for this exposure is shown below. The peak radiated output power (EIRP) is calculated as follows: EIRP = P + G Where, P = Power input to the antenna (mW) G = Power gain of the antenna (dBi) EIRP = 17.66 dBm The numeric gain(G) of the antenna with a gain specified in dB is determined by: G = Log -1 (dB antenna gain / 10) G = Log -1 (3.94/ 10) G = 2.48 Power density at the specific separation: S = PG/(4R 2 π) Where, S = Maximum power density (mW/cm 2 ) P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm = limit for MPE) S = (23.55 * 2.48 / (4 * 20 2 * π) S = 0.0116 mW/cm 2 The Maximum permissible exposure (MPE) for the general population is 1 mW/cm 2 . The power density at 20cm does not exceed the 1 mW/cm 2 limit. Estimated safe separation: R = √(PG / 4π) Where, P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20cm = limit for MPE) R = √(23.55 * 2.48/ 4π) R = 2.16 cm

DFS TEST REPORT Test Report No. : TK-FR11014 Date of Issue : 04/07/2011 Description of Product : 5G-WiFi FCC ID : ZD7DNMM-K1 Model No. : DNMM-K1 Applicant : Nimbus, Inc. Suite 619 Hanshin S-meca,1359, Gwanpyeong-dong, Yuseong-g, Daejeon, Korea Manufacturer : Wistron NeWeb Corp. NO. 10-1, Lin-hsin I Road, Science-Based Industry Park, Hsinchu 300, Taiwan, R.O.C Standards : FCC Part 15 Subpart E §15.407 Test Date : 03/30/2011 ~ 05/18/2011 Test Results : PASS FAIL The test results relate only to the items tested. Tested by: Reviewed by: Kyu -Chul Shin KT Kang Test Engineer Technical Manager Date: 05/18 /2011 Date: 05/18 /2011 THRU -KES CO.,LTD. 477 -6, Hager-Ri, Yoju-Up, Yoju-Gun Kyunggi-Do,469-803, Korea Tel: + 82 -31 -425 -6200 / Fax: + 82 -31 -424 -0450 TABLE OF CONTENTS 1.0 General Product Description ................................................................................ 3 1.1 Tested Frequency ............................................................................................... 4 2.0 TEST RESULTS .................................................................................................. 5 1.0 General Product Description Equipment model name : DNMM-K1 Serial number : Prototype EUT condition : Pre-production, not damaged Antenna type : External Antenna (Supporting MIMO) : Dipole antenna Gain 3.94dBi Frequency Range : 5250MHz ~ 5350MHz RF output power(HT40) :13.10 dBm Conducted Peak Power Number of channels : 2CH Channel Spacing : 40 MHz Transfer Rate : 270Mbps Type of Modulation : 64-QAM for OFDM _ Only HT40 Power Source : DC 3.3V 1.1 Tested Frequency Band CH Test Frequency Band 1 5250 ~ 5350 54 5270 62 5310 2.0 TEST RESULTS The manufacturer shall state whether the UUT is capable of operating as a Master and/or a Client. If the UUT is capable of operating in more than one operating mode then operating mode shall be tested separately. See tabes1 for the applicability of DFS requirements for each of the operational modes. Table 1 Requirement Operational Mode Master Client without Radar detection Client with radar detection DFS Detection Threshold ○ Not required ○ Channel closing Transmission Time ○ ○ ○ Channel Move Time ○ ○ ○ U-NII Detection Bandwidth ○ Not required ○ * In client(slave) mode, the Nimbus 802.11n adapter has no Support for radar detection 2.1 Operating Frequency of U-NII Device Table 23: Operating frequency range of UUT Operational Mode Operating Frequency Range 5250~5350MHz Master Not Apply Client without radar detection O Client with radar detection Not Apply Test Procedure Conducted setup configuration of DFS Measurement System - DFS Response Requirement Values Parameter Value Non-occupancy period Minimum 30 minutes Channel Availability Check Time 60 seconds Channel Move Time 10 seconds See Note1 Channel Closing Transmission Time 200 milliseconds + an aggregate of 60 milliseconds over remaining 10 second period. See Notes 1 and 2 U-NII Detection Bandwidth Minimum 80% of the UNII 99% transmission power bandwidth See Note3. Note1: The instant that the Channel Move Time and the Channel Closing Transmission Time begins is as follows: l For the Short Pulse Radar Test Signals this instant is the end of the Burst. l For the Frequency Hopping radar Test Signal, this instant is the end of the last radar Burst generated. l For the Long Pulse Radar Test Signal this instant is the end of the 12 second period defining the Radar Waveform Note 2: The Channel Closing Transmission Time is comprised of 200 milliseconds starting at the beginning of the Channel Move Time plus any additional intermittent control signals required to facilitate a Channel move (an aggregate of 60 milliseconds) during the remainder of the 10 second period. The aggregate duration of control signals will not count quiet periods in between transmissions. Not 3: During the U-NII Detection Bandwidth detection test, radar type1 is used and for each frequency step the minimum percentage of detection is 90 percent. Measurements are performed with no data traffic. EQUIPMENT UNDER TEST (EUT) DETAILS Operating Modes (5250-5350 MHz) Master Device Client Device (no In Service Monitoring, no Ad-Hoc mode) Client Device with In-Service Monitoring Antenna Gain / EIRP (5250-5350 MHz) 5250-5350 MHz Highest Antenna Gain(dBi) 3.94 Power can exceed 200mW eirp Channel Protocol IP Based Frame Based OTHER SUPPORT EQUIPMENT The following equipment was used as local support equipment for testing : Manufacturer Model Description Serial Number FCC ID Wistron NeWeb Corp. L D N M M-K1 EUT - - Lenovo(Singapore)Pte.Ltd. 2957 Notebook - DoC L e n o vo P A-1 4 0 0-12 DC Power Supply - Netgear Incorporated. W N D R 3 3 00 Master Wireless AP - PY308100078 The italicized device was the master device. EUT INTERFACE PORTS The I/O cabling configuration during testing was as follows : Port Connected To Cable(s) Description Shielded or Unshielded Length(m) None - - - - EUT OPERATION The EUT was operating with the following software. The software is secured by encryption to prevent the user from disabling the DFS function. During the channel moving tests the system was c…

Text truncated - open the document above for the full version.
