ZDELB5Wi-Fi IP Camera

Rev1/26/2023 (ShenZhenFoscamIntelligentTechnologyCo.,Ltd.) FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:01-09-2026 Ref:AttestationStatementsPart2.911(d)(5)(i)Filing FCCID：ZDELB5 [ShenZhenFoscamIntelligentTechnologyCo.,Ltd.](“theapplicant”)certifiesthattheequipmentfor whichauthorizationissoughtisnot“covered”equipmentprohibitedfromreceivinganequipment authorizationpursuanttosection2.903oftheFCCrules. [ShenZhenFoscamIntelligentTechnologyCo.,Ltd.](“theapplicant”)certifiesthattheequipmentfor whichauthorizationissoughtdoesnotincludecybersecurityoranti-virussoftwareproducedorprovided byKasperskyLab,Inc.oranyofitssuccessorsandassignees,includingequipmentwithintegrated KasperskyLab,Inc.(oranyofitssuccessorsandassignees)cybersecurityoranti-virussoftwarepursuant toDA-24-886andKDB986446D01CoveredEquipmentGuidancesectionB(2a). Deviceisinherentlycompliantbasedonhardwarelimitationsorsoftwarecontrols. or ASoftwareBillofMaterials(SBOM)isprovidedtotheTCBforreview,and Theend-userorthirdpartiescannotinstalladditionalsoftwareonthisdevice. Sincerely, (Applicantsignature) (YongkunQi) Rev1/26/2023 (ShenZhenFoscamIntelligentTechnologyCo.,Ltd.) FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:01-09-2026 Ref:AttestationStatementsPart2.911(d)(5)(ii)Filing FCCID：ZDELB5 [ShenZhenFoscamIntelligentTechnologyCo.,Ltd.](“theapplicant”)certifiesthat,asofthedateofthe filingoftheapplication,theapplicantisnotidentifiedontheCoveredList(asaspecificallynamedentity oranyofitssubsidiariesoraffiliates)asanentityproducing“covered” equipment. Sincerely, (Applicantsignature) (YongkunQi)

ShenZhen Foscam Intelligent Technology Co., Ltd. U.S. Agent Designation for Service of Process - Certification Attestation Letter 1/9/2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID:ZDELB5 Applicant FRN: 0022772438 ShenZhen Foscam Intelligent Technology Co., Ltd.(“the applicant”) certifies that, as of the date of the filing of the application,Global Product Services and Consultation LLCis our designated U.S. agent for service of process for the above referenced FCC ID.ShenZhen Foscam Intelligent Technology Co., Ltd.accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Global Product Services and Consultation LLCaccepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Company Name: Global Product Services and Consultation LLC FCC Registration Number (FRN): 0033406703 Physical U.S. Company Address: 328 W Palm Ave. Monrovia, CA91016, USA Contact Person: Mr Michael Chan Contact No.: 626-366-4358 Agent Email Address: [email protected] Sincerely, Company: ShenZhen Foscam Intelligent Technology Co., Ltd. Designated Agent: Global Product Services and Consultation LLC Company Representative: Yongkun QiDesignated Agent Representative: Michael Chan Title: ManagerTitle:Technical Director Signature: Signature: Date : 01/102026 SC6015002

ShenZhenFoscamIntelligentTechnologyCo.,Ltd. FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Date:01-09-2026 SUBJECT:FCCID:ZDELB5 ToWhomItMayConcern: I,theundersigned,herebystatesthisequipmenthasbeentestedandfoundtocomply withthelimitsforaClassBdigitaldevice,pursuanttopart15oftheFCCRules,and willapplytheSupplier'sDeclarationofConformityproceduretotheclassB computerperipheralportionofthiscompositedevice.IunderstandthefollowingFCC requirements: 1.DevicessubjecttotheSDoCprocedurearerequiredtobetestedtoshow compliancewiththeFCCtechnicalregulationsbyarecognizedaccreditedtesting laboratory.ThetestinglaboratorymustbeaccreditedbyaCommissionapproved accreditationbodyordesignatedunderthetermsofagovernment-to-government MutualRecognitionAgreement(MRA).Alistingofthoseaccreditedtesting laboratoriesthathavebeenrecognizedbytheCommissionispublishedontheFCC Webpage:https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm(Selectthe "accredited"optiontosearchforFCCrecognizedaccreditedtestfirms.) 2.Pt2.1077containsthelistofinformationthatmustbeincludedintheSupplier's DeclarationofConformity,whichmustbesuppliedwitheachproductsold.The SDoCcomplianceinfoshallbeincludedintheUser’sManualorasaseparate sheet.Theinfomustcontainthename,address,andphonenumberofthe responsibleparty,whichmustbelocatedwithintheUnitedStates.Accordingto 2.909(b),theresponsiblepartyiseithertheManufactureroriftheproductis importedtheImporter. Regards, ShenZhenFoscamIntelligentTechnologyCo.,Ltd. ------------------------------- （ YongkunQi ）

ShenZhenFoscamIntelligentTechnologyCo.,Ltd. Rev11/20/07 FederalCommunicationsCommission AuthorizationandEvaluationDivision ConfidentialityRequestregardingapplicationforcertificationofFCCID:ZDELB5 PursuanttoSections0.457and0.459oftheCommission’sRules,weherebyrequestconfidential treatmentofinformationaccompanyingthisapplicationasoutlinedbelow: ExhibitTypeFileName BlockDiagram Schematics OperationalDescription BlockDiagram Schematics OperationalDescription Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedto thepublic.Thepublicdisclosureofthesematerialsmaybeharmfultotheapplicantandprovide unjustifiedbenefitstoitscompetitors. TheapplicantunderstandsthatpursuanttoSection0.457oftheRules,disclosureofthis applicationandallaccompanyingdocumentationwillnotbemadebeforethedateoftheGrant forthisapplication. PursuanttoDA04-1705June15,2004oftheCommission’spublicnotice,Wealsorequestingthe commissiontograntshort-termconfidentialityrequestonthefollowingattachmentsuntil180 daysaftertheGrantDateofEquipmentAuthorizations. ExhibitTypeFileName Sincerely, YongkunQi 01-09-2026

ShenZhenFoscamIntelligentTechnologyCo.,Ltd. Declarationonmodeldifference Wetheundersignedherebyconfirmthatthesemodelsareidentical,andallmodelshavethesame RFmodule,PCBlayout,Antenna,schematicsandcomponent.Onlydifferentonmodelnumber. ProductionnameTrademarkFCCModelno. Wi-FiIPCameraFOSCAMZDELB5LB5,LB4,LB3,LS5,O5P, O5S,A07W Confirmedby: YongkunQi ShenZhenFoscamIntelligentTechnologyCo.,Ltd. 01-09-2026

ShenZhenFoscamIntelligentTechnologyCo.,Ltd. FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Date:01-09-2026 SUBJECT:FCCApplicationforFCCID:ZDELB5 ToWhomItMayConcern: We,theundersigned,herebyauthorizeSamLv.atEMTEK(DONGGUAN)CO.,LTD.on ourbehalf,toapplytotheFederalCommunicationsCommissiononourequipment.Any andallactscarriedoutbyEMTEK(DONGGUAN)CO.,LTD.onourbehalfshallhave thesameeffectasactsofourown. ThisistoadvisethatweareinfullcompliancewiththeAnti-DrugAbuseAct.We,the applicant,arenotsubjecttoadenialoffederalbenefitspursuanttoSection5301ofthe Anti-DrugActof1988,21USC853a,andnopartytotheapplicationissubjecttoadenial offederalbenefitspursuanttothatsection. Regards, Sincerely, YongkunQi 01-09-2026

ReportNo.ENS2509110043W005Page1of7Ver.1.0 FCCID:ZDELB5 ReportNo.ENS2509110043W005Page2of7Ver.1.0 ReportNo.ENS2509110043W005Page3of7Ver.1.0 ReportNo.ENS2509110043W005Page4of7Ver.1.0 ReportNo.ENS2509110043W005Page5of7Ver.1.0 ReportNo.ENS2509110043W005Page6of7Ver.1.0 ReportNo.ENS2509110043W005Page7of7Ver.1.0

ReportNo.ENS2509110043W005Page1of5Ver.1.0 FCCID:ZDELB5 ReportNo.ENS2509110043W005Page2of5Ver.1.0 ReportNo.ENS2509110043W005Page3of5Ver.1.0 ANT ReportNo.ENS2509110043W005Page4of5Ver.1.0 ReportNo.ENS2509110043W005Page5of5Ver.1.0

ReportNo.ENS2509110043W00503RPage1of7Ver.1.0 TESTREPORT ProductName：Wi-FiIPCamera ModelNumber：LB5,LB4,LB3,LS5,O5P,O5S,A07W FCCID：ZDELB5 Preparedfor:ShenZhenFoscamIntelligentTechnologyCo.,Ltd. Address:Room902,Building1B,ShenzhenInternational innovationValley,Xingke1stStreet,NanshanDistrict, Shenzhen,Guangdong,China,518055. Preparedby:EMTEK(SHENZHEN)CO.,LTD. Address:Building69,MajialongIndustryZone,NanshanDistrict, Shenzhen,Guangdong,China TEL:(0755)26954280 FAX:(0755)26954282 ReportNumber:ENS2509110043W00503R Dateofsamplereceipt:September11,2025 Date(s)ofTests:September11,2025toDecember30,2025 Dateofissue: December30,2025 ReportNo.ENS2509110043W00503RPage2of7Ver.1.0 TableofContents 1.TESTRESULTCERTIFICATION...............................................................................................................................................3 2.EUTSPECIFICATION.................................................................................................................................................................5 3.TESTREQUIREMENT................................................................................................................................................................6 4.MEASUREMENTRESULT.........................................................................................................................................................7 ReportNo.ENS2509110043W00503RPage3of7Ver.1.0 1.TESTRESULTCERTIFICATION Applicant:ShenZhenFoscamIntelligentTechnologyCo.,Ltd. Address: Room902,Building1B,ShenzhenInternationalinnovationValley,Xingke1st Street,NanshanDistrict,Shenzhen,Guangdong,China,518055. Manufacturer:ShenZhenFoscamIntelligentTechnologyCo.,Ltd. Address: Room902,Building1B,ShenzhenInternationalinnovationValley,Xingke1st Street,NanshanDistrict,Shenzhen,Guangdong,China,518055. Factory:ShenZhenFoscamIntelligentTechnologyCo.,Ltd. Address: 701,7thFloor,BuildingD,GuangmingPortIntelligentManufacturingInnovation Park,No.8JinjunRoad,HuangjiangTown,Dongguan,Guangdong,China, 523769 EUT:Wi-FiIPCamera ModelName:LB5,LB4,LB3,LS5,O5P,O5S,A07W Trademark:FOSCAM MeasurementProcedureUsed: APPLICABLESTANDARDS STANDARDTESTRESULT §15.247(i),§2.1093 PASS TheaboveequipmentwastestedbyEMTEK(DONGGUAN)CO.,LTD.Thetestdata,dataevaluation,test procedures,andequipmentconfigurationsshowninthisreportweremadeinaccordancewiththeprocedures giveninANSIC63.10(2020)andtheenergyemittedbythesampleEUTtestedasdescribedinthisreportisin compliancewiththerequirementsofFCCRules FCC§15.247(i),§2.1093 . Thetestresultsofthisreportrelateonlytothetestedsampleidentifiedinthisreport DateofTest:September11,2025toDecember30,2025 Preparedby: YuXiaolan/Editor Reviewer: XiaLilu/Supervisor Approve&AuthorizedSigner:WangLi/Manager ReportNo.ENS2509110043W00503RPage4of7Ver.1.0 ModifiedHistory VersionReportNo.RevisionDateSummary ENS2509110043W00502R/OriginalReport ReportNo.ENS2509110043W00503RPage5of7Ver.1.0 2. EUTSpecification CharacteristicsDescription Product:Wi-FiIPCamera ModelNumber: LB5,LB4,LB3,LS5,O5P,O5S,A07W (Note:TheModel:LB5isthesameastheModel:LB4,LB3,LS5,O5P,O5S andA07Winhardwareaspect.Thedifferenceinmodelnumberservesas marketingstrategy.) Sample:1# DataRate: 2.4GWIFI: 802.11b 802.11g 802.11n(20MHzchannelbandwidth) Modulation: 2.4GWIFI: DSSSwithDBPSK/DQPSK/CCKfor802.11b; OFDMwithBPSK/QPSK/16QAM/64QAMfor802.11g/n; OperatingFrequency Range(s): 2412-2462MHzfor2.4GWIFI NumberofChannels: 11channelsfor2.4GWIFI TransmitPowerMax: 18.23dBm(0.066527W)forWiFi2.4G; AntennaGain:4.87dBi Powersupply:AC100-240V50/60Hz Evaluationapplied:MPEEvaluation SAREvaluation ReportNo.ENS2509110043W00503RPage6of7Ver.1.0 3. TestRequirement RFEXPOSUREEVALUATION AccordingtoFCC1.1310:Thecriterialistedinthefollowingtableshallbeusedtoevaluatetheenvironment impactofhumanexposuretoradiofrequency(RF)Radiationasspecifiedin§1.1307(b) LimitsforMaximumPermissibleExposure(MPE) Frequency Range(MHz) ElectricField Strength(V/m) MagneticField Strength(A/m) Power Density(mW/cm 2 ) Average Time (A)LimitsforOccupational/ControlExposures 300-1500----F/3006 1500-100000----56 (B)LimitsforGeneralPopulation/UncontrolExposures 300-1500----F/15006 1500-100000----130 Friistransmissionformula:Pd=(Pout*G)\(4*pi*R 2 ) Where Pd=PowerdensityinmW/cm 2 Pout=outputpowertoantennainmW G=Numericgainoftheantennarelativetoisotropicantenna Pi=3.1416 R=distancebetweenobservationpointandcenteroftheradiatorincm PdthelimitofMPE,1mW/cm 2 .Ifweknowthemaximumgainofthendtotalpowerinputtotheantenna,through thecalculation,wewillknowthedistancewheretheMPElimitisreached. ReportNo.ENS2509110043W00503RPage7of7Ver.1.0 4. MeasurementResult gain:4.87FCCMPE Frequency (MHz) Output Power(dB m) E.I.R.P(dB m) Target Power W/toleranc e(dBm) Maxtune up power(dB m) tolerance Max tuneup power(m W) tolerance Power Density at R=20cm (mW/cm 2) Limit (mW/cm 2) Verdic t 802.11b 240217.7222.5922±1230.121823 1 PASS 244118.2323.123±1240.153366 1PASS 248016.9621.8321±1220.096767 1PASS 802.11g 240216.321.1721±1220.096767 1PASS 244116.521.3721±1220.096767 1PASS 248015.2420.1120±1210.076865 1PASS 802.11n(20M Hzchannel bandwidth) 240216.3921.2621±1220.096767 1PASS 244116.4721.3421±1220.096767 1PASS 248015.1720.0420±1210.076865 1PASS AccordingtoKDB447498,nostand-alonerequiredfor2.4GWiFiantenna,andnosimultaneousSAR measurement ***EndofReport***

1 东莞市乔木电子科技有限公司 规格书 SPECIFICATIONFORAPPROVAL 客户名称： 客戶项目名称： 客户料号： 物料名称： 乔木料号： 2.4GWiFibrassantenna 日期： 版别： Manufacturer:DongguanQiaomuElectronicTechnologyCo.,Ltd. CompanyAddress:Floor2,XinhuiBuilding,No.48FuminSouthRoad,DalangTown, Dongguan Email:[email protected] MANUFACTURE SIGNATURE CUSTOMER SIGNATURE CHECKEDBAY: 周文彬 AUDITORBAY: APPROVEDBAY 谭文锋 DATE: 2023-04-27 2 ProductNumber:DF5DBI82564/5-40 ProductName:Antenna Index: 1.RevisionHistory/Page3 2.Specification/Page4 3.CharacteristicsandReliabilityTest/Page5~6 4.Antenna-SParameterTestData/Page7 5.Antenna-RadiationPatternTestData/Page8 6.MechanicalandPackingDrawing/Page9 3 ProductNumber:DF5DBI82564/5-40 ProductName:Antenna 1.RevisionHistory RevisionDateChangeNotificationDescription 1.02023-04-27 初版 ProductNumber:DF5DBI82564/5-40 ProductName:Antenna 4 2.Specification SamplePhoto A.ElectricalCharacteristics Frequency2400~2500MHz S.W.R.<=2.0 AntennaGain 4.87dBi@2450MHz PolarizationLinear Impedance50Ohm B.Material&MechanicalCharacteristics MaterialofRadiator MaterialofPlastic Body:ABS Hinge:ABS Base:PC+PBT CableType 1.13黑色线120MM一代端子 ConnectorType C.Environmental OperationTemperature-40°C~+65°C StorageTemperature-40°C~+80°C AntennaColorStoragelife <2year φ1.13BlacklineLengthis120MM ProductNumber:DF5DBI82564/5-40 ProductName:Antenna 5 3.CharacteristicsandReliabilityTest TestItems測試 項目 TestConditionandProcedure測試方法Requirements要求 Result 結果 C1V.S.W.R. 電壓駐波比 SetDUTonNetworkAnalyzer;makeindividual calibrationtotest設置網路分析儀參數進行測試 DirectiveDUTspecification 符合待測物規範 PASS C2Insertion Loss插入損 失 SetDUTonNetworkAnalyzer;makeindividual calibrationtotest設置網路分析儀參數進行測試 DirectiveDUTspecification 符合待測物規範 N/A C3Antenna Gain 天線增益 SetDUTonAntennaChamber;makeindividual calibrationtotest設置天線暗室參數進行測試 DirectiveDUTspecification 符合待測物規範 PASS C4Voltage Breakdown 耐電壓 Testvoltageshouldbeappliedbetweeninsulated portions,orbetweengroundasspecified. 在绝缘部分测试电压,或指定接地面之间 MaxVoltage≥500Vor directivematerial specification最大電壓≥500V 或符合材料規範 N/A C5Insulation Resistance 絕緣阻抗 SetVoltage:500±50V;betweentheinsulated portions,orbetweengroundasspecified. 設置電壓500±50V,在绝缘部份測試或指定接地面之 间 Resistance≥500Mohm ordirectivematerial specification 阻抗 ≥500Mohm 或符合材料規範 N/A C6Contact Resistance 接觸阻抗 AirTemp:26°C;measuredwithtestequipment 室溫 26 ° C ，指定量測設備 Directivematerial specification 符合材料規範 N/A M1Vibration 震動 GB/T2423.48-2008 Amplitude:0.03inch(1.5mm);Freq:20to80to20 Hz 3directions;2hoursforeachdirection 振幅1.5mm；頻率20~80~20Hz；3個方向各2H 1.NoVisualDamage 2.FrequencyTol.≤5% 無明顯外觀不良;頻率偏移≤5% PASS M2Random Drop 跌落 GB/T2423.8-1995 Single ： Height:1.0Meter;3directions;1timefor eachdirection 單支天線，高 1m ； 3 個方向各 1 次 1.Nopartsseparated、fracture 2.FrequencyTol.≤5% 產品無脫落、斷裂;頻率偏移≤5% PASS ProductNumber:DF5DBI82564/5-40 ProductName:Antenna 6 Packing ： Height:0.76Meter;1corner,3edges,6 surface 包裝：高 0.76m ，一角、三棱、六面各一次 PASS Antenna+Machine:Height:0.76Meter;1corner,3 edges,6surface. 整機：高 0.76m ，一角、三棱、六面 各一次 N/A M3SolderabilityGB/T2423.28-2005TinevenlyonfullN/A h 可焊性Temp:260±5°C;Duration:5seconds溫度260± 5°C;持續5秒 上錫均勻飽滿 M4 P ullTest 拉力 Holdingwithindividualspecification;forceapplied toaxisofterminal.單獨定義產品端子拉力 DirectiveDUTspecification FrequencyTol.≤5% 符合待測物規範;頻率偏移≤5% PASS M5 T orque Test 扭力 Holdingwithindividualspecification;applied clockwiseandcounterclockwisetotheaxisof terminal 單獨定義產品端子之順時針及逆時針扭力 DirectiveDUTspecification FrequencyTol.≤5% 符合待測物規範;頻率偏移≤5% N/A M6 D imension 尺寸 Inspectionofdimension,color,material,package, surfaceprocess.检查尺寸,颜色,材料,包装,表面處理 DirectiveDUTspecification 符合待測物規範 PASS E1 W aterproof 防水 WithReferencetoIEC60529//IPCodeDefinition 參考IEC60529IP定義 DirectiveDUTspecification 符合待測物規範 N/A E2 SaltSpray鹽 霧 GB/T2423.17-2008 Temp:35°C;RH:≥95%;NaClsolution:≥ 5%;Time:24H 溫度35°C；濕度≥95%;鹽水濃度≥5%；測試24H NoVisualDamage FrequencyTol.≤5% 無明顯外觀不良;頻率偏移≤5% PASS E3Temperature andHumidity Chamber 恒溫恒濕 GB/T2423.3-2006 Temp:80°C/12H;-40°C/12HRH:≥90%;Time: 24H 溫度80°C測試12H轉-40°C測試12H；濕度≥ 90%； 時間24H After2HoursRecovery NoVisualDamage FrequencyTol.≤5% 恢復2H后，無明顯外觀不良;頻 率偏移≤5% PASS E4TermalShock 冷熱衝擊 GB/T2423.22-2008 40°C(30minutes)to+80°C(30minutes)；Cycles: 24 40°C測試30分轉80°C測試30分為一個週期；共24 週期 After2HoursRecovery NoVisualDamage FrequencyTol.≤5% 恢復2H后，無明顯外觀不良;頻 率偏移≤5% PASS E5Agingtest 老化 GB/T2423.2-2008 Temp:80°C;Time:24hours 溫度80°C，測試24H After2HoursRecovery NoVisualDamage FrequencyTol.≤5% 無明顯外觀不良;頻率偏移≤5% PASS E6HighTemp. 高溫 Temp.270±10°C；Times：120seconds 溫度270±10°C，測試時間120秒 NoVisualDamage 無明顯外觀不良 N/A R1RoHSWithReferencetoIEC62321:2008withflowchart 參考IEC62321測試流程 DirectiveRoHS2011/65/EU 符合RoHS2011/65/EU標準 PASS R2PFOSWithReferencetoUSAEPA3550C:1996byLC/MS 參考USAEPA3550C測試流程 DirectiveRoHS2006/122/EC 符合RoHS2011/65/EU標準 PASS ProductNumber:DF5DBI82564/5-40 ProductName:Antenna 7 4.Antenna-SParameterTestData 8 5.Antenna-RadiationPatternTestData

ReportNo.ENS2509110043W00501RPage1of76Ver.1.0 TESTREPORT ProductName：Wi-FiIPCamera ModelNumber：LB5,LB4,LB3,LS5,O5P,O5S,A07W FCCID：ZDELB5 Preparedfor:ShenZhenFoscamIntelligentTechnologyCo.,Ltd. Address:Room902,Building1B,ShenzhenInternational innovationValley,Xingke1stStreet,NanshanDistrict, Shenzhen,Guangdong,China,518055. Preparedby:EMTEK(SHENZHEN)CO.,LTD. Address:Building69,MajialongIndustryZone,Nanshan District,Shenzhen,Guangdong,China TEL:(0755)26954280 FAX:(0755)26954282 ReportNumber:ENS2509110043W00501R Dateofsamplereceipt:September11,2025 Date(s)ofTests:September11,2025toDecember30,2025 Dateofissue:December30,2025 $二维码$ ReportNo.ENS2509110043W00501RPage2of76Ver.1.0 TABLEOFCONTENTS 1TESTRESULTCERTIFICATION........................................................................................................................3 2EUTTECHNICALDESCRIPTION......................................................................................................................5 3SUMMARYOFTESTRESULT.............................................................................................................................6 4TESTMETHODOLOGY........................................................................................................................................7 4.1GENERALDESCRIPTIONOFAPPLIEDSTANDARDS...............................................................................7 4.2MEASUREMENTEQUIPMENTUSED...........................................................................................................7 4.3DESCRIPTIONOFTESTMODES...................................................................................................................8 5FACILITIESANDACCREDITATIONS...............................................................................................................9 5.1FACILITIES........................................................................................................................................................9 Building69,MajialongIndustryZone,NanshanDistrict,Shenzhen,Guangdong,China.......................................9 5.2EQUIPMENT.....................................................................................................................................................9 5.3LABORATORYACCREDITATIONSANDLISTINGS...................................................................................9 6TESTSYSTEMUNCERTAINTY........................................................................................................................10 7SETUPOFEQUIPMENTUNDERTEST...........................................................................................................11 7.1RADIOFREQUENCYTESTSETUP1...........................................................................................................11 7.2RADIOFREQUENCYTESTSETUP2...........................................................................................................11 7.3CONDUCTEDEMISSIONTESTSETUP......................................................................................................14 7.4BLOCKDIAGRAMCONFIGURATIONOFTESTSYSTEM......................................................................15 7.5SUPPORTEQUIPMENT.................................................................................................................................15 8TESTREQUIREMENTS......................................................................................................................................16 8.1DTS6DBBANDWIDTH.................................................................................................................................16 8.2DTS99%BANDWIDTH.................................................................................................................................23 8.3MAXIMUMPEAKCONDUCTEDOUTPUTPOWER.................................................................................30 8.4MAXIMUMPOWERSPECTRALDENSITY................................................................................................37 8.5UNWANTEDEMISSIONSINNON-RESTRICTEDFREQUENCYBANDS..............................................44 8.6RADIATEDSPURIOUSEMISSION..............................................................................................................64 8.7CONDUCTEDEMISSIONTEST....................................................................................................................72 8.8ANTENNAAPPLICATION.............................................................................................................................75 ReportNo.ENS2509110043W00501RPage3of76Ver.1.0 1TESTRESULTCERTIFICATION Applicant:ShenZhenFoscamIntelligentTechnologyCo.,Ltd. Address: Room902,Building1B,ShenzhenInternationalinnovationValley,Xingke1st Street,NanshanDistrict,Shenzhen,Guangdong,China,518055. Manufacturer:ShenZhenFoscamIntelligentTechnologyCo.,Ltd. Address: Room902,Building1B,ShenzhenInternationalinnovationValley,Xingke1st Street,NanshanDistrict,Shenzhen,Guangdong,China,518055. Factory:ShenZhenFoscamIntelligentTechnologyCo.,Ltd. Address: 701,7thFloor,BuildingD,GuangmingPortIntelligentManufacturingInnovation Park,No.8JinjunRoad,HuangjiangTown,Dongguan,Guangdong,China, 523769 EUT:Wi-FiIPCamera ModelName:LB5,LB4,LB3,LS5,O5P,O5S,A07W Trademark:FOSCAM MeasurementProcedureUsed: APPLICABLESTANDARDS STANDARDTESTRESULT FCC47CFRPart2,SubpartJ FCC47CFRPart15,SubpartC PASS ICRSS-GEN,Issue5(04-2018)+A1(03-2019)+A2(02-2021) ICRSS-247Issue4(07-2025) PASS TheaboveequipmentwastestedbyEMTEK(SHENZHEN)CO.,LTD.Thetestdata,dataevaluation,test procedures,andequipmentconfigurationsshowninthisreportweremadeinaccordancewiththe proceduresgiveninANSIC63.10(2020)andtheenergyemittedbythesampleEUTtestedasdescribed inthisreportisincompliancewiththerequirementsofFCCRulesPart2,Part15.247,ICRSS-247Issue 2andICRSS-GEN,Issue5. DateofTest:September11,2025toDecember30,2025 Preparedby: YuXiaolan/Editor Reviewer: XiaLilu/Supervisor Approve&AuthorizedSigner:WangLi/Manager Rep…

Text truncated - open the document above for the full version.

ReportNo.ENS2509110043W00501RPage37of76Ver.1.0 8.4MAXIMUMPOWERSPECTRALDENSITY 8.4.1ApplicableStandard AccordingtoFCCPart15.247(e)andKDB558074D0115.247MeasGuidancev05r02 AccordingtoRSS-2475.2(b)andRSS-Gen6.12 8.4.2ConformanceLimit Thetransmitterpowerspectraldensityconductedfromthetransmittertotheantennashallnotbegreater than8dBminany3kHzbandduringanytimeintervalofcontinuoustransmission.Thispowerspectral densityshallbedeterminedinaccordancewiththeprovisionsofsection5.4(d),(i.e.thepowerspectral densityshallbedeterminedusingthesamemethodasisusedtodeterminetheconductedoutputpower). 8.4.3TestConfiguration Testaccordingtoclause6.1radiofrequencytestsetup 8.4.4TestProcedure Thisprocedureshallbeusedifmaximumpeakconductedoutputpowerwasusedtodemonstrate compliance Thetransmitteroutput(antennaport)wasconnectedtothespectrumanalyzer SetanalyzercenterfrequencytoDTSchannelcenterfrequency. Setthespanto1.5timestheDTSbandwidth. SettheRBWto:3kHz SettheVBWto:10kHz. SetDetector=peak. SetSweeptime=autocouple. SetTracemode=maxhold. Allowtracetofullystabilize. UsethepeakmarkerfunctiontodeterminethemaximumamplitudelevelwithintheRBW. 8.4.5TestResults Temperature: 25 ̊C RelativeHumidity: 45  ATMPressure:1011mbar Note:N/A ReportNo.ENS2509110043W00501RPage38of76Ver.1.0 TestModeAntennaFrequency[MHz]Result[dBm/3-100kHz]Limit[dBm/3kHz]Verdict 11BAnt12412-4.99≤8.00PASS 11BAnt12437-4.68≤8.00PASS 11BAnt12462-5.58≤8.00PASS 11GAnt12412-17.57≤8.00PASS 11GAnt12437-17.31≤8.00PASS 11GAnt12462-18.74≤8.00PASS 11N20SISOAnt12412-17.79≤8.00PASS 11N20SISOAnt12437-17.77≤8.00PASS 11N20SISOAnt12462-19.13≤8.00PASS ReportNo.ENS2509110043W00501RPage39of76Ver.1.0 11B-Ant1-2412-PASS 11B-Ant1-2437-PASS ReportNo.ENS2509110043W00501RPage40of76Ver.1.0 11B-Ant1-2462-PASS 11G-Ant1-2412-PASS ReportNo.ENS2509110043W00501RPage41of76Ver.1.0 11G-Ant1-2437-PASS 11G-Ant1-2462-PASS ReportNo.ENS2509110043W00501RPage42of76Ver.1.0 11N20SISO-Ant1-2412-PASS 11N20SISO-Ant1-2437-PASS ReportNo.ENS2509110043W00501RPage43of76Ver.1.0 11N20SISO-Ant1-2462-PASS ReportNo.ENS2509110043W00501RPage44of76Ver.1.0 8.5UNWANTEDEMISSIONSINNON-RESTRICTEDFREQUENCYBANDS 8.5.1ApplicableStandard AccordingtoFCCPart15.247(d)andKDB558074D0115.247MeasGuidancev05r02 AccordingtoRSS-2475.5 8.5.2ConformanceLimit AccordingtoFCCPart15.247(d): Inany100kHzbandwidthoutsidethefrequencybandinwhichthespreadspectrumordigitally modulateddeviceisoperating,theRFpowerthatisproducedshallbeatleast20dBbelowthatinthe100 kHzbandwidthwithinthebandthatcontainsthehighestlevelofthedesiredpower,basedoneitheranRF conductedoraradiatedmeasurement,providedthatthetransmitterdemonstratescompliancewiththe peakconductedpowerlimits.Ifthetransmittercomplieswiththeconductedpowerlimitsbasedontheuse ofroot-mean-squareaveragingoveratimeinterval,aspermittedundersection5.4(d),theattenuation requiredshallbe30dBinsteadof20dB.Attenuationbelowthegeneralfieldstrengthlimitsspecified inRSS-Genisnotrequired. 8.5.3TestConfiguration Testaccordingtoclause6.1radiofrequencytestsetup 8.5.4TestProcedure Thetransmitteroutput(antennaport)wasconnectedtothespectrumanalyzer Referencelevelmeasurement Establishareferencelevelbyusingthefollowingprocedure: SetinstrumentcenterfrequencytoDTSchannelcenterfrequency. Setthespanto≥1.5timestheDTSbandwidth. SettheRBW=100kHz. SettheVBW≥3xRBW. SetDetector=peak. SetSweeptime=autocouple. SetTracemode=maxhold. Allowtracetofullystabilize. UsethepeakmarkerfunctiontodeterminethemaximumPSDlevel. NotethatthechannelfoundtocontainthemaximumPSDlevelcanbeusedtoestablishthereference level. Band-edgemeasurement Usethefollowingspectrumanalyzersettings: Span=wideenoughtocapturethepeakleveloftheemissionoperatingonthechannelclosesttothe band-edge,aswellasanymodulationproductswhichfalloutsideoftheauthorizedbandofoperation SetRBW  1%ofthespan=100kHzSetVBW  3xRBW SetSweep=autoSetDetectorfunction=peakSetTrace=maxhold Allowthetracetostabilize.Setthemarkerontheemissionatthebandedge,oronthehighest modulationproductoutsideoftheband,ifthislevelisgreaterthanthatatthebandedge.Enablethe marker-deltafunction,thenusethemarker-to-peakfunctiontomovethemarkertothepeakofthein-band emission.Themarker-deltavaluenowdisplayedmustcomplywiththelimitspecifiedinthisSection. Emissionlevelmeasurement Setthecenterfrequencyandspantoencompassfrequencyrangetobemeasured. SettheRBW=100kHz. SettheVBW=300kHz. SetDetector=peak Sweeptime=autocouple. Tracemode=maxhold. Allowtracetofullystabilize. Usethepeakmarkerfunctiontodeterminethemaximumamplitudelevel. Ensurethattheamplitudeofallunwantedemissionsoutsideoftheauthorizedfrequencyband(excluding restrictedfrequencybands)areattenuatedbyatleasttheminimumrequirements.Reportthethree highestemissionsrelativetothelimit. ReportNo.ENS2509110043W00501RPage45of76Ver.1.0 8.5.5TestResults Temperature: 25 ̊ C RelativeHumidity: 45  ATMPressure:1011mbar Note:N/A Bandedgemeasurements TestModeAntennaChNameFrequency[MHz]RefLevel[dBm]Result[dBm]Limit[dBm]Verdict 11BAnt1Low24127.03-39.22≤-22.97PASS 11BAnt1High24626.47-43.35≤-23.53PASS 11GAnt1Low24124.81-31.44≤-25.19PASS 11GAnt1High24622.18-41.14≤-27.83PASS 11N20SISOAnt1Low24121.55-32.95≤-28.45PASS 11N20SISOAnt1High24623.16-42.32≤-26.84PASS ReportNo.ENS2509110043W00501RPage46of76Ver.1.0 11B-Ant1-2412-PASS 11B-Ant1-2462-PASS ReportNo.ENS2509110043W00501RPage47of76Ver.1.0 11G-Ant1-2412-PASS 11G-Ant1-2462-PASS ReportNo.ENS2509110043W00501RPage48of76Ver.1.0 11N20SISO-Ant1-2412-PASS 11N20SISO-Ant1-2462-PASS ReportNo.ENS2509110043W00501RPage49of76Ver.1.0 ConductedSpuriousEmission TestModeAntennaFrequency[MHz] FreqRange [Mhz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 11BAnt124120~Reference6.336.33---PASS 11BAnt1241230~10006.33-56.48≤-23.67PASS 11BAnt124121000~265006.33-48.75≤-23.67PASS 11BAnt124370~Reference7.487.48---PASS 11BAnt1243730~10007.48-55.18≤-22.52PASS 11BAnt124371000~265007.48-47.36≤-22.52PASS 11BAnt124620~Reference5.325.32---PASS 11BAnt1246230~10005.32-57.38≤-24.68PASS 11BAnt124621000~265005.32-48.56≤-24.68PASS 11GAnt124120~Reference1.751.75---PASS 11GAnt1241230~10001.75-59.…

Text truncated - open the document above for the full version.

ReportNo.ENS2509110043W00501RPage61of76Ver.1.0 11N20SISO-Ant1-2437-30~1000-PASS 11N20SISO-Ant1-2437-1000~26500-PASS ReportNo.ENS2509110043W00501RPage62of76Ver.1.0 11N20SISO-Ant1-2462-0~Reference-PASS 11N2…
