ZDJDG119GSM Mobile Phone

User Manual Model Name: DG119,DG109 Brand Name: VIBE MOBILITY FCC ID: ZDJDG119 I Contents 1.Getting to know your phone ............................ 1 1.1 Your Phone .................................................. 1 1.2 Status icons .................................................. 1 1.3 Installing SIM card and battery ..................... 1 1.4 Installing Storage card ................................. 2 1.5 Battery charging ........................................... 2 1.6 Power on/ off ................................................ 3 1.6.1 Power on ............................................... 3 1.6.2 Power off ............................................... 3 1.7 Using shortcut keys ...................................... 3 2.Using Call Function .......................................... 4 2.1 Making a call ................................................ 4 2.1.1 Directly call on Home Screen ................ 4 2.1.2 Make an international call ...................... 4 2.1.3 Dial an extension number ...................... 4 2.2 Answering or rejecting a call ........................ 4 2.2.1 Answer a call ......................................... 4 2.2.2 Reject a call ........................................... 4 2.3 Adjusting call volume ................................... 4 2.4 Ending a call ................................................. 4 3.Call logs ............................................................. 5 3.1 Dialed calls ................................................... 5 3.2 Received calls .............................................. 5 3.3 Missed calls .................................................. 5 3.4 Rejected calls ............................................... 5 3.5 Delete all ...................................................... 5 3.6 Call timers .................................................... 5 3.7 Call cost ....................................................... 5 4.Profiles .............................................................. 6 4.1 Standard ...................................................... 6 4.2 Silent ............................................................ 6 4.3 Vibrate .......................................................... 6 4.4 Low ring ....................................................... 6 4.5 High ring and vibrate .................................... 6 5.Contacts ............................................................ 7 5.1 View a contact .............................................. 7 5.2 Adding a new contact ................................... 7 6.Message ............................................................ 8 6.1 Write message ............................................. 8 6.2 Inbox ............................................................ 8 6.3 Outbox ......................................................... 8 6.4 Drafts ........................................................... 8 6.5 Sentbox ........................................................ 8 6.6 Message setting ........................................... 8 6.6.1 Templates .............................................. 8 6.6.2 Voicemail server .................................... 8 6.6.3 Broadcast message ............................... 9 6.6.4 SMS settings ......................................... 9 6.6.5 Message capacity .................................. 9 7.Multimedia ....................................................... 10 7.1 Audio player ............................................... 10 7.1.1 Background audio player ..................... 10 7.2 Video player ............................................... 10 7.3 FM radio ..................................................... 10 7.4 Recorder .................................................... 11 8.File list ............................................................. 12 II 9.Pastime ............................................................ 13 9.1 Image browser ........................................... 13 9.2 Sokoban ..................................................... 13 10.Tools .............................................................. 14 10.1 Alarm ........................................................ 14 10.2 Calendar .................................................. 14 10.3 Calculator ................................................. 14 11.Settings ......................................................... 15 11.1 Call settings ............................................. 15 11.1 Dual-SIM .............................................. 15 11.2 Network selection ................................. 15 11.3 Call divert ............................................. 15 11.4 Call barring ........................................... 16 11.5 Call waiting ........................................... 17 11.6 Hide ID ................................................. 17 11.7 Select line ............................................. 17 11.8 Flight mode ........................................... 17 11.9 Others ................................................... 17 11.2 Phone settings ......................................... 18 11.2.1 Time and date ................................... 18 11.2.2 Auto power on/off .............................. 18 11.2.3 Power management .......................... 18 11.2.4 Restore settings ................................ 18 11.3 Display settings ........................................ 18 11.3.1 Wallpaper settings ............................. 18 11.3.2 Backlight ............................................ 18 11.3.3 Keypad light ....................................... 18 11.4 Security settings ....................................... 18 11.4.1 PIN .................................................... 18 11.4.2 PIN2 .................................................. 19 11.4.3 Privacy .............................................. 20 11.4.4 Auto keypad lock ............................... 20 11.4.5 Lock screen by end- key ................... 2…

Text truncated - open the document above for the full version.

Jun.07, 2011 Federal Communication Commission Authorization and Evaluation Division FCC ID: ZDJDG119 Re: Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1: Block Diagram 2: Circuit Diagram 3: Operational Description 4: Parts List 5Tune up procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rules 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Cellnet 7 HK Limited Contact person: Daoyuan Zhan Title: Manager Tel: 86-13480604713

The model DG119 is electrically identical to the model DG109, they both use the plastic housing, only the color and sharp are different. TOP VIEW OF SAMPLE BOTTOM VIEW OF SAMPLE DG109 DG119 LEFT VIEW OF SAMPLE RIGHT VIEW OF SAMPLE FRONT VIEW OF SAMPLE BACK VEIW OF SAMPLE

FCC ID Label Placement Mobile Phone Model: DG119,DG109 VIBE MOBILITY FCC ID:ZDJDG119 Made In China

OPEN VIEW OF SAMPLE-1 OPEN VIEW OF SAMPLE-2 OPEN VIEW OF SAMPLE-3 INTERNAL VIEW OF SAMPLE – 1 INTERNAL VIEW OF SAMPLE – 2 GSM Antenna Bluetooth Antenna

FCC Test Report Report No.: AGC031110501F1 FCC ID : ZDJDG119 PRODUCT DESIGNATION : Mobile Phone BRAND NAME : VIBE MOBILITY MODEL NAME : DG119 CLIENT : Cellbet 7 HK limited DATE OF ISSUE : June 8,2011 STANDARD(S) : FCC Part 15 Rules Attestation of Global Compliance Co., Ltd. CAUTION: This report shall not be reproduced except in full without the written permission of the test laboratory and shall not be quoted out of context. Report No.: AGC031110501F1 Page 1 of 21 TABLE OF CONTENTS 1. VERIFICATION OF COMPLIANCE ................................................................................................................. 2 2. PRODUCT INFORMATION ............................................................................................................................. 3 3. TEST FACILITY ............................................................................................................................................... 4 4. SUPPORT EQUIPMENT LIST ......................................................................................................................... 5 5. SYSTEM DESCRIPTION ................................................................................................................................. 5 6 SUMMARY OF TEST RESULTS ...................................................................................................................... 6 7. FCC LINE CONDUCTED EMISSION TEST .................................................................................................... 7 7.1. TEST EQUIPMENT OF LINE CONDUCTED EMISSION TEST ................................................... 7 7.2 .LIMITS OF LINE CONDUCTED EMISSION TEST ..................................................................... 7 7.3. BLOCK DIAGRAM OF LINE CONDUCTED EMISSION TEST ..................................................... 7 7.4. PROCEDURE OF LINE CONDUCTED EMISSION TEST ........................................................... 8 7.5 TEST RESULT OF LINE CONDUCTED EMISSION TEST .......................................................... 9 8. FCC RADIATED EMISSION TEST ............................................................................................................... 11 8.1. TEST EQUIPMENT OF RADIATED EMISSION ........................................................................................... 11 8.2. LIMITS OF RADIATED EMISSION TEST ...................................................................................................... 11 8.3 BLOCK DIAGRAM OF RADIATED EMISSION TEST ................................................................................... 11 8.4 PROCEDURE OF RADIATED EMISSION TEST ........................................................................................... 11 8.4 PROCEDURE OF RADIATED EMISSION TEST ........................................................................................... 12 8.5 TEST RESULT OF RADIATED EMISSION TEST ......................................................................................... 13 APPENDIX 1 ....................................................................................................................................................... 15 PHOTOGRAPHS OF TEST SETUP ................................................................................................................... 15 APPENDIX 2 ....................................................................................................................................................... 16 PHOTOGRAPHS OF EUT .................................................................................................................................. 16 Report No.: AGC031110501F1 Page 2 of 21 1. VERIFICATION OF COMPLIANCE Applicant: Cellbet 7 HK limited Room 813, 8/F, Hollywood Plaza, 610 Nathan Road, Kowloon, HongKong Manufacturer: Shen Zhen Kaliho Technology Development Limited 20F. Golden Tower, Jintian Road, FuTian CBD District, Shenzhen, China Product Designation: Mobile Phone Brand name: VIBE MOBILITY Model Name: DG119, DG109 Difference Description: All the same except for the appearance, and the main test model is DG119. FCC ID: ZDJDG119 Measurement Procedure: ANSI C63.4: 2003 File Number: AGC031110501F1 Date of test: June 4, 2011 to June 7, 2011 Deviation: None Condition of Test Sample: Normal The above equipment was tested by Attestation Of Global Compliance Co., Ltd. for compliance with the requirements set forth in the FCC Rules and Regulations Part 15, the measurement procedure according to ANSI C63.4:2003. This said equipment in the configuration described in this report shows the maximum emission levels emanating from equipment are within the compliance requirements. The test results of this report relate only to the tested sample identified in this report. Checked By : Curoky Chen June 7, 2011 Authorized By : Forrest Lei June 7, 2011 Report No.: AGC031110501F1 Page 3 of 21 2. PRODUCT INFORMATION I/O Port Information ( Applicable Not Applicable) I/O Port of EUT I/O Port Type Q’TY Cable Tested with USB port 1 N/A 1 Earphone port 1 1m unshielded 1 DC input port 1 1.5 unshielded 1 Housing Type: Plastic and metal EUT Rating Voltage: DC 3.7V by battery(or Charged by adapter) Adapter Input AC100~240V,50/60Hz Adapter Output DC5V,500mA Report No.: AGC031110501F1 Page 4 of 21 3. TEST FACILITY Facility Attestation of Global Compliance Co., Ltd. Location: 1F, No.2 Building, Huafeng No.1 Technical, Industrial Park, Sanwei, Xixiang, Baoan District, Shenzhen, China Description: The test site is constructed and calibrated to meet the FCC requirements in documents ANSI C63.4:2003. Site Filing: The FCC Registration Number is 259865 Instrument Tolerance: All measuring equipment is in accord with ANSI C63.4 requirements that meet industry regulatory agency and accreditation agency requirement. Report No.: AGC031110501F1 Page 5 of 21 4. SUPPORT EQUIPMENT LIST Device Type Manufacturer Model Name Serial No. Data Cable Power Cable PC Lenovo B…

Text truncated - open the document above for the full version.

FCC LINE CONDUCTED EMISSION TEST SETUP FCC RADIATED EMISSION TEST SETUP
