ZDJE5722GSM mobile phone

Page 1 of 73 Content 1 INTRODUCTION....................................................................7 2 FOR YOUR SAFETY..............................................................9 3 ABOUT YOUR DEVICE.........................................................12 3.1 FEATURE DESCRIPTION........................................................12 3.2 EFFECTIVE DEVICE OPERATION..............................................13 3.3 YOUR DEVICE.......................................................................................14 4 GET STARTED....................................................................20 4.1 SIM CARD INSTALLATION.....................................................................20 4.2 MEMORY CARD INSTALLATION.............................................................21 4.3 BATTERY INSTALLATION........................................................................22 4.4 BATTERY CHARGING..............................................................................23 4.5 CARE AND MAINTENANCE OF THE BAT T E RY..........................................24 4.6 SWITCH THE DEVICE ON AND OFF...........................................................26 Page 2 of 73 4.7 ANSWER A CALL....................................................................................26 4.8 END A CALL...........................................................................................27 4.9 MAKE A CALL........................................................................................27 4.10 CALL WAITING.....................................................................................28 4.11 GROUP CONVERSATION.......................................................................29 4.12 WRITE TEXT........................................................................................30 4.13 KEYPAD LOCK (KEYGUARD) ...............................................................32 5 FEATURES................................................................................................33 5.1C ONTACTS.......................................................................................... 38 New.........................................................................38 Contacts search............................................................39 Write message.............................................................39 Dial up.....................................................................39 Send vcard.................................................................40 Delete.......................................................................40 Mark........................................................................40 Copy........................................................................40 Page 3 of 73 Copy All....................................................................40 Others.......................................................................41 5.2 Message....................................................................42 Write messages............................................................42 Inbox........................................................................44 Outbox.....................................................................44 Draftbox....................................................................45 Sentbox.....................................................................46 5.3Call log......................................................................50 Dialed numbers............................................................50 Received calls.............................................................51 Missed calls...............................................................51 Rejected calls..............................................................51 Delete all...................................................................51 Call timer..................................................................51 Call costs...................................................................51 GPRS flowrate............................................................51 Page 4 of 73 5.4Settings.....................................................................52 Call setup..................................................................52 Phone.......................................................................56 Display.....................................................................58 Security.....................................................................58 Profiles.....................................................................59 Link.........................................................................59 5.5Audio player...............................................................60 5.6Camera......................................................................61 5.7Bluetooth....................................................................63 5.8Media......................................................................65 Video player...............................................................66 FM radio................................................................66 5.9File manager..............................................................67 5.10Pastime.....................................................................67 Picture browser..........................................................67 E-book.....................................................................68 Page 5 of 73 Boxman...................................................................68 5.13Tools.......................................................................69 Alarm.....................................................................69 Calendar..................................................................70 Calculator.................................................................70 Recorder..................................................................70 5.14Network services.........…

Text truncated - open the document above for the full version.

Jul.22, 2011 Federal Communication Commission Authorization and Evaluation Division FCC ID: ZDJE5722 Re: Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1: Block Diagram 2: Circuit Diagram 3: Operational Description 4: Parts List 5: Tune Up Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rules 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, cellnet 7 HK limited Contact person: Daoyuan Zhan Title: Manager

TOP VIEW OF SAMPLE BOTTOM VIEW OF SAMPLE LEFT VIEW OF SAMPLE RIGHT VIEW OF SAMPLE FRONT VIEW OF SAMPLE BACK VEIW OF SAMPLE ALL VIEW OF SAMPLE

FCC ID Label Placement GSM mobile phone Model: E5I Brand: Vibe Mobility, Vibe, vibe phone FCC ID:ZDJE5722 Made In China

cellnet 7 HK limited Room 813, 8/F, Hollywood Plaza, 610 Nathan Road, Kowloon, Hong Kong Date: Jul. 29, 2011 We, cellnet Statement 7 HK limited states that our device, FCC ID: ZDJE5722, has no space to put the label except the battery compartment of this device. It is visible to the users as they purchase the products and install the battery. Sincerely yours,

OPEN VIEW OF SAMPLE-1 OPEN VIEW OF SAMPLE-2 OPEN VIEW OF SAMPLE-3 GSM Antenna INTERNAL VIEW OF SAMPLE – 1 INTERNAL VIEW OF SAMPLE – 2 BT Antenna

FCC Test Report Report No.: AGC 031110701F1 FCC ID : ZDJE5722 PRODUCT DESIGNATION : GSM mobile phone BRAND NAME : Vibe Mobility , Vibe, vibe phone MODEL NAME : E5I CLIENT : cellnet 7 HK limited DATE OF ISSUE : July 27, 2011 STANDARD(S) : FCC Part 15 Rules Attestation of Global Compliance Co., Ltd. 1. CAUTION: This report shall not be reproduced except in full without the written permission of the test laboratory and shall not be quoted out of context. Report No.: AGC031110701F1 Page 1 of 21 TABLE OF CONTENTS 1. VERIFICATION OF COMPLIANCE ................................................................................................................. 2 2. PRODUCT INFORMATION ............................................................................................................................. 3 3. TEST FACILITY ............................................................................................................................................... 4 4. SUPPORT EQUIPMENT LIST ......................................................................................................................... 5 5. SYSTEM DESCRIPTION ................................................................................................................................. 5 6 SUMMARY OF TEST RESULTS ...................................................................................................................... 6 7. FCC LINE CONDUCTED EMISSION TEST .................................................................................................... 7 7.1. TEST EQUIPMENT OF LINE CONDUCTED EMISSION TEST ................................................... 7 7.2 .LIMITS OF LINE CONDUCTED EMISSION TEST ..................................................................... 7 7.3. BLOCK DIAGRAM OF LINE CONDUCTED EMISSION TEST ..................................................... 7 7.4. PROCEDURE OF LINE CONDUCTED EMISSION TEST ........................................................... 8 7.5 TEST RESULT OF LINE CONDUCTED EMISSION TEST .......................................................... 9 8. FCC RADIATED EMISSION TEST ............................................................................................................... 11 8.1. TEST EQUIPMENT OF RADIATED EMISSION ........................................................................................... 11 8.2. LIMITS OF RADIATED EMISSION TEST ...................................................................................................... 11 8.3 BLOCK DIAGRAM OF RADIATED EMISSION TEST ................................................................................... 11 8.4 PROCEDURE OF RADIATED EMISSION TEST ........................................................................................... 11 8.4 PROCEDURE OF RADIATED EMISSION TEST ........................................................................................... 12 8.5 TEST RESULT OF RADIATED EMISSION TEST ......................................................................................... 13 APPENDIX 1 ....................................................................................................................................................... 15 PHOTOGRAPHS OF TEST SETUP ................................................................................................................... 15 APPENDIX 2 ....................................................................................................................................................... 16 PHOTOGRAPHS OF EUT .................................................................................................................................. 16 Report No.: AGC031110701F1 Page 2 of 21 1. VERIFICATION OF COMPLIANCE Applicant: cellnet 7 HK limited Room 813, 8/F, Hollywood Plaza, 610 Nathan Road, Kowloon, HongKong Manufacturer: Shenzhen wanke industrial technology Co., LTD Rm.518,1West Block, Hualizhuangshi Building, Zhenhua Road, Futian District, Shenzhen Product Designation: GSM mobile phone Brand name: Vibe Mobility , Vibe, vibe phone Model Name: E5I FCC ID: ZDJE5722 Measurement Procedure: ANSI C63.4: 2003 File Number: AGC031110701F1 Date of test: July 23, 2011 to July 27, 2011 Deviation: None Condition of Test Sample: Normal The above equipment was tested by Attestation of Global Compliance Co., Ltd. for compliance with the requirements set forth in the FCC Rules and Regulations Part 15, the measurement procedure according to ANSI C63.4:2003. This said equipment in the configuration described in this report shows the maximum emission levels emanating from equipment are within the compliance requirements. The test results of this report relate only to the tested sample identified in this report. Checked By : Angela Li July 27, 2011 Approved By : Forrest Lei July 27, 2011 Authorized By: Solger Zhang July 27, 2011 Report No.: AGC031110701F1 Page 3 of 21 2. PRODUCT INFORMATION I/O Port Information ( Applicable Not Applicable) I/O Port of EUT I/O Port Type Q’TY Cable Tested with USB port 1 0.7m, unshielded 1 DC input port 1 N/A 1 Housing Type: Plastic and metal EUT Rating Voltage: DC 3.7V by battery(or Charged by adapter) Adapter Input AC100~240V,50/60Hz Adapter Output DC5V,500mA Report No.: AGC031110701F1 Page 4 of 21 3. TEST FACILITY Facility Attestation of Global Compliance Co., Ltd. Location: 1F, No.2 Building, Huafeng No.1 Technical, Industrial Park, Sanwei, Xixiang, Baoan District, Shenzhen, China Description: The test site is constructed and calibrated to meet the FCC requirements in documents ANSI C63.4:2003. Site Filing: The FCC Registration Number is 259865 Instrument Tolerance: All measuring equipment is in accord with ANSI C63.4 requirements that meet industry regulatory agency and accreditation agency requirement. Report No.: AGC031110701F1 Page 5 of 21 4. SUPPORT EQUIPMENT LIST Device Type Manufacturer Model Name Serial No. Data Cable Power Cable PC Lenovo B450 N/A N/A 1.5m unshielded **No…

Text truncated - open the document above for the full version.

FCC LINE CONDUCTED EMISSION TEST SETUP FCC RADIATED EMISSION TEST SETUP
