ZDSBTM160Module Operates as a Bluetooth transceiver for wirelessly controlling musical instruments and audio equipment.

BTM160 User's Manual 1 Revision 1.3 7-08-2011 Hardware Description Manual JULY 2011 BTM160 Bluetooth QD ID : B018233 (End Product Listing) FCC ID : ZDSBTM160 IC : 9583A-BTM160 Class 2 BC04-ext Mini Module Wireless Modules User's Manual Hardware Description Revision 1.3 BTM160 User's Manual 2 Revision 1.3 7-08-2011 Hardware Description Manual Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 List of Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 List of Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Table of Contents 1. General Device Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 1.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 1.2 Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 1.3 Pin Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 1.4 Pin Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . 7 1.5 Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 2 Basic Operating Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 2.1 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 2.2 Clocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 3 Physical Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 3.1 RF Receive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 3.1.1 Low Noise Amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 3.1.2 Analog to Digital Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 3.2 RF Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 3.2.1 IQ Modulator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 3.2.2 Power Amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 3.3 RF Synthesizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 3.4 Clock Input and Generation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 3.5 Baseband and Logic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 3.5.1 Memory Management Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 3.5.2 Burst Mode Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 3.5.3 Physical Layer Hardware Engine DSP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 3.5.4 System RAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 3.5.5 External Memory Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 3.5.6 USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 3.5.7 Synchronous Serial Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 3.5.8 UART. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 3.6 Microcontroller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 3.6.1 Programmable I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 3.6.2 802.11 Coexistence Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 4 Bluetooth Software …

Text truncated - open the document above for the full version.

file:///T|/TCB%20Projects/2011/Gibson/91250/-16-FCC%20Exhibits/ID%20Label_Location%20Info/Label%20Location%20Info.txt[7/27/2011 9:25:52 AM] 5/4/2011: Per Milo Street: BTM 160 (91250) -ID Label/Location The ID Label will be going on the outside of the final product as detailed in the User's Manual.

C:\Documents and Settings\cnicklas\My Documents\Laptop\Working on\For Eddie TCB 070811\BTM160 Connector\BTM160 (Visible layers

BTM160.GD1 (Board layer 1) Scale=1.62 Fri Jul 08 16:04:25 2011

Page 1 of 5 Report No: 91250-18A MAXIMUM PERMISSIBLE EXPOSURE ADDENDUM REPORT TO 91250 FOR THE MODEL NUMBER: BTM-160 FCC ID: ZDSBTM160 IC: 9583A-BTM160 DATE OF ISSUE: MAY 18, 2011 PREPARED FOR: Gibson Guitar Corporation 641 Massman Drive Nashville, TN 37210 PREPARED BY: E. Wong CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 W.O. No.: 91250 Report No.: 91250-18A Page 2 of 5 Report No: 91250-18A Revision History / Purpose: Original: To demonstrate compliance with United States and Canada RF Exposure requirements for Mobile Equipment (devices used > 20cm from the body), where Maximum Permissible Exposure (MPE) Calculations apply. Addendum A: This device does not fall under the Mobile Equipment category as originally stated and this report is to demonstrate compliance with United States and Canada RF Exposure exemption for Portable Equipment (devices used < 20cm from the body), where Specific Absorption Rate (SAR) Evaluations apply. Also the “Report Prepared For” section has changed from Echo Digital Audio Corporation to Gibson Guitar Corporation. United States Exemption in accordance with FCC document, KDB 447498 Thresholds for TCB SAR Exposure category low threshold high threshold general population (60/fGHz) mW, d < 2.5 cm (120/fGHz) mW, d ≥ 2.5 cm (900/fGHz) mW, d < 20 cm occupational (375/fGHz) mW, d < 2.5 cm l (900/fGHz) mW, d ≥ 2.5 cm (2250/fGHz) mW, d < 20 cm Page 3 of 5 Report No: 91250-18A Canadian exemption in accordance with RSS-102 sub clause 2.5 2.5 Exemption from Routine Evaluation Limits All transmitters are exempt from routine SAR and RF exposure evaluations provided that the output power complies with the power levels of sections 2.5.1 or 2.5.2. If the equipment under test (EUT) meets the requirements of sections 2.5.1 or 2.5.2, applicants are required to submit only a properly signed declaration of compliance. The information contained in the RF exposure technical brief may be limited to information that demonstrates how the output power of the transmitter was derived. If the EUT does not meet the appropriate exemption limit, a complete SAR or RF exposure evaluation shall be performed. It must be emphasized that the above exemption from routine evaluation is not an exemption from compliance. 2.5.1 Exemption from Routine Evaluation Limits – SAR Evaluation SAR evaluation is required if the separation distance between the user and the device’s radiating element is less than or equal to 20 cm, except when the device operates: from 3 kHz up to 1 GHz inclusively and its output power (i.e. the higher of the conducted or equivalent isotropically radiated power (e.i.r.p.) source-based, time-averaged output power) is less than or equal to 200 mW for general public use and 1000 mW for controlled use; above 1 GHz up to 2.2 GHz inclusively and its output power (i.e. the higher of the conducted or radiated (e.i.r.p.) source-based, time-averaged output power) is less than or equal to 100 mW for general public use and 500 mW for controlled use; above 2.2 GHz up to 3 GHz inclusively and its output power (i.e. the higher of the conducted or radiated (e.i.r.p.) source-based, time-averaged output power) is less than or equal to 20 mW for general public use and 100 mW for controlled use; above 3 GHz up to 6 GHz inclusively and its output power (i.e. the higher of the conducted or radiated (e.i.r.p.) source-based, time-averaged output power) is less than or equal to 10 mW for general public use and 50 mW for controlled use. Page 4 of 5 Report No: 91250-18A In these cases, the information contained in the RF exposure technical brief may be limited to information that demonstrates how the output power of the device was derived. 2.5.2 Exemption from Routine Evaluation Limits – RF Exposure Evaluation RF exposure evaluation is required if the separation distance between the user and the device’s radiating element is greater than 20 cm, except when the device operates as follows: below 1.5 GHz and its maximum e.i.r.p. is equal to or less than 2.5 W; at or above 1.5 GHz and the maximum e.i.r.p. of the device is equal to or less than 5 W. In these cases, the information contained in the RF exposure technical brief may be limited to information that demonstrates how the e.i.r.p. was derived. Page 5 of 5 Report No: 91250-18A Equipment operational details: Operating Frequency (MHz) Measured Output Power (dBm) Maximum Mobile Antenna Gain (dBi) Maximum EIRP (dBm) 2402-2408 4.9 4.9 9.8 Measurements based from EMC Test Report: 91250-12B. Device and Antenna Operating Configuration: Device operating at maximum output power with continuous transmission of modulated data. Power measured conducted at the antenna port Max antenna gain is 4.9 dBi ( 3.1 linear) . Statement of Exemption: At maximum measured conducted output power of 4.9 dBm (0.003W, 3mW), the device is exempted from routine SAR evaluation in accordance with the FCC’s RF exposure regulations. At maximum measured conducted output power of 4.9 dBm (0.003W, 3mW), the device is exempted from routine SAR evaluation in accordance with the Industry Canada’s RF exposure regulations.

This report c written cons e TE S CERT #803 803.05 ontains a total of ent of CKC Laborat Blue STING 3.01, 803.02, 5, 803.06 47 pages and ma tories, Inc. Gibso ADDE core4 Mod Te FCC Par This test rep testing perfo of ISO/IEC 1 CKC Laborato We strive t o sound, adapt our custome processes, bu ay be reproduced on Guit ENDUM TO T dule: Rays ested To The rt 15 Subpar RSS Report Date of is port bears th ormed herein 17025 under ories, Inc. o create long‐t tive, customer ers’ unique EM ut rather as th in full only. Partia tar Cor TEST REPOR on BTM‐1 e Following S rt C Section and ‐210 Issue 8 No.: 91250‐1 ssue: May 18, e accreditati o meets the tes the applicab term, trust ba r first testing MC challenges, e reason we a al reproduction m rporati RT 91250‐12 60 Bluetoo Standards: 15.207, 15.2 8 12B 2011 on symbol ind st and reporti ble scope of sed relations h services. We , not as an int are in business may only be done ion A oth Modul 247 dicating that ing requireme EMC testing hips by provid embrace each terruption to . with the le the ents for ding h of set Page 2of 47 Report No.: 91250‐12B TABLE OF CONTENTS Administrative Information ........................................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Revision History ......................................................................................................................................................... 3 Report Authorization ................................................................................................................................................. 3 Test Facility Information ............................................................................................................................................ 4 Site Registration & Accreditation Information .......................................................................................................... 4 Summary of Results ................................................................................................................................................... 5 Conditions During Testing ......................................................................................................................................... 5 Equipment Under Test ............................................................................................................................................... 6 Peripheral Devices ..................................................................................................................................................... 6 FCC Part 15 Subpart C .................................................................................................................................................... 7 15.207 AC Conducted Emissions................................................................................................................................ 7 15.247(a)(1) Frequency Separation ......................................................................................................................... 14 15.247(a)(1)(iii) Average Time of Occupancy .......................................................................................................... 19 15.247(b)(2) RF Power Output ................................................................................................................................ 25 15.247(d) Spurious Emissions .................................................................................................................................. 28 ITU‐R 55/1 Bandedge ............................................................................................................................................... 38 RSS‐210 99% Bandwidth ............................................................................................................................... ........... 42 Supplemental Information .......................................................................................................................................... 46 Measurement Uncertainty ...................................................................................................................................... 46 Emissions Test Details .............................................................................................................................................. 46 Page 3of 47 Report No.: 91250‐12B ADMINISTRATIVE INFORMATION Test Report Information REPORT PREPARED FOR: REPORT PREPARED BY: Gibson Guitar Corporation 309 Plus Park Blvd. Nashville, TN 97217 Joyce Walker CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 Representative: Milo StreetProject Number: 91250 Customer Reference Number: 000076720 DATE OF EQUIPMENT RECEIPT: October4, 2010 DATE(S) OF TESTING: October4‐18, 2010 April 6, 2011 Revision History Original: To perform the testing of the Bluecore4 Module: Rayson BTM‐160 Bluetooth Module with the requirements for FCC Part 15 Subpart C Section 15.247and RSS‐210 Issue 7 devices. Addendum A: To add FCC Part 15 Subpart C Section 15.209 AC Conducted Emissions test data of the Bluecore4 Module: Rayson BTM ‐160 Bluetooth Module performed April 6, 2011. To replace original test data FCC 15.247(b)(2)_RF Power data with new FCC 15.247(b)(2)_RF Power test data. Addendum B: In the Bandedge testing sections a horn antenna has been added to the equipment list that had been left off in error. Report Authorization The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to cla…
