ZJD-ARV5403FLIPC

Revision: 1.1 Revision Description Date 1.0 Release 2010/08/07 1.1 Modify Wifi+Bluetooth data 2011/5/24 Installation Guide AR-V5403FL 1 Revision: 1.1 2 Contents 1 .....................................................3 Introduction to AR-V5403FL 1.1 ................................................................................ 3 Specifications 1.2 ................................................................................... 3 Packing List 2 .....................................8 Procedure of Assembly/Disassembly 2.1 ............................................................ 8 2.5” Hard Disk Installation 2.2 ................................................................. 13 Accessory Installation 2.3 ........................ 16 GPS/3.5G/WiFi-Bluetooth Modules Installation 3 ..................................................................................18 Appendix 4 .....................................................20 Introductions of AR-B5403 4.1 Features........................................................................................... 20 4.3 Block Diagram................................................................................. 23 5 Hardware’s Information.............................................................24 5.1 Locations......................................................................................... 24 5.2 Connector and Jumper Setting Table........................................... 27 6 BIOS Setting...............................................................................36 6.1 Main Setup....................................................................................... 37 6.2 Advanced Chipset Setup................................................................ 39 6.3 PnP/PCI Setup................................................................................. 41 6.4 Peripherals Setup........................................................................... 42 6.5 PC Health Setup.............................................................................. 44 6.6 Boot Setup....................................................................................... 45 6.7 Exit Setup........................................................................................ 46 Revision: 1.1 3 1 Introduction to AR-V5403FL AR-V5403FL is a Fan-less system product mainly for vehicles industry PC applications. With powerful Intel CPU core & diverse memory card extension (according to CF card, SO-DIM), AR-V5403FL can satisfy the users requirements in any vehicles industry applications environment, especially in vehicles computer fields. AR-V5403FL has diverse physical interface in the front panel, such as GPIO’s terminal, 2*(10/100/1000Base-T) LANs, VGA connectors, build-in LEDs, 4 USB Ports, 2 COM ports, SIM card functions and FUSE, ATX Power Switch &Remote Switch/ Microphone/Speaker, DC inlet. In addition, the system provides the capacity for extending I/O device by options adding GPS/3.5G/WiFi Bluetooth depends on users needs. 1.1 Specifications Item Description System AR-V5403FL CPU Board AR-B5403 series System Dimensions (uncluding bracket) 285x190x67(mm) 1.2 Packing List Description Quantity AR-V5403FL 1 Terminal block (Plug-DC connecter) 1 Terminal block (Plug-GPIO connecter) 1 Wall Mount Bracket(Including label for isolation ) 2 Compact Disk 1 KB/MS Y Cable 1 Remote Switch Cable 1 2.5”HDD Bracket (Screws-4PCS) 1 Antenna for GPS external cable (Option) 1 Antenna for 3.5G external cable (Option) 1 Antenna for Wi-Fi + Bluetooth external cable (Option) 1 Fuse 7.5A for 24V vehicles 1 Revision: 1.1 System Dissection (1) Dimensions 4 Revision: 1.1 (2) Front Panel “I/O” 5 Storage Power-on status LAN1/LAN2 Antenna Inlet Speaker/Mic/Remote VGA Power Switch DC Inlet Fuse COM1/COM2 USBCF Card/HDD&POWER LED GPIO (3) System Configuration 1 3 9 8 10 13 2 7 45 6 Revision: 1.1 11 12 15 14 6 Revision: 1.1 7 Item Description Quantity 1 Upper Cover 1 2 Bottom Case 1 3 Thermal Module 1 4 Mounting Bracket 2 5 CF Card Bracket 1 6 Mother board + GPIO board 1 7 HDD/SSD Module 1 8 GPS Module 1 9 3.5G Module 1 10 Wi-Fi Module, Bluetooth Module 2 11 DDRII Lid 1 12 Hook modules of bracket 4 13 Antennas of GPS/3.5G/WiFi 1 14 Fuse 7A for 12V vehicles (default value) 1 15 SIM Card cover 1 Revision: 1.1 2 Procedure of Assembly/Disassembly 2.1 2.5” Hard Disk Installation The following instructions will guide you to install HDD step-by-step: 1. Remove the terminal plug from the AR-V5403FL. 2. Unfasten the screws from storage plate of AR-V5403FL. Unfasten the screw!! Remove the external power adapter!! Unfasten the screw!! 8 Revision: 1.1 3. Pulled the storage plate by below photo direction. Pulled 4. Inserted the storage device into the HDD plater. Install the storage device on the HDD plater with four Caution! Check the Direction is correct. Push it! Install the storage device. 9 Revision: 1.1 5. Place HDD module back into the case. 6. Fix HDD module to the chassis by two screws. Push!! Put HDD module back into the chassis. Fasten the screws!! 10 Revision: 1.1 7. Slide the top cover into or take off the bottom chassis. Fasten the screw Push Push Pay attention to make sure top cover has been installed into the notch! 11 Revision: 1.1 8. Finish the modules (3.5G/GPS/Wifi-Bluetooth) installation after fastening the screw. Push Push Fasten the screw 12 Revision: 1.1 2.2 Accessory (CF card, 3.5G, GPS, Wi-Fi Bluetooth, SIM Card, Outline bracket) Installation  Install CF Card 1. Remove the extending CF’s bracket by unfastening the screws. Unfasten the screws 2. Install CF card into bracket. Install CF card by the following direction. 13 Revision: 1.1 3. Install CF card module back to CF socket. Caution!! The snapping side is downward. Install the CF card module into CF slot.  Install SIM Card Install SIM card into the SIM socket. 14 Revision: 1.1  Install Outline Bracket 1. Install fasteners with case by 4 screws. 2. Install fasteners’ another side with Outline bracket …

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 Acrosser Technology Co., Ltd 10F.、 、、 、No.12、 、、 、Lane 609、 、、 、Sec. 5、 、、 、Chongsin Rd.、 、、 、Sanchong District、 、、 、New Taipei City 241 、 、、 、Taiwan、 、、 、R.O.C. TEL:+886-2-29999000 FAX:+886-2-29992887 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Acrosser Technology Co., Ltd hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): ( IPC , FCC ID : ZJDARV5403FL) W e affirm that between SIEMIC and Acrosser Technology Co., Ltd, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature -------------------------------------- Aaron Joue / Vice President Acrosser Technology Co., Ltd 10F.、 、、 、No.12、 、、 、Lane 609、 、、 、Sec. 5、 、、 、Chongsin Rd.、 、、 、Sanchong District、 、、 、New Taipei City 241、 、、 、Taiwan、 、、 、R.O.C.

SCS-F19: Confidentiality Request Letter Page 1 of 3 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 1.0 2.0 August – 11 - 2008 SCS-F19: Confidentiality Request Letter Page 2 of 3 Rev 2.0 Acrosser Technology Co., Ltd 10F.、No.12、Lane 609、Sec. 5、Chongsin Rd.、Sanchong District、New Taipei City 241、Taiwan、R.O.C. TEL:+886-2-29999000 FAX:+886-2-29992887 2010/05/20 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: ZJD-ARV5403FL We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematic - Operation Description - Tune up procedure - Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name / title : Aaron Chou / Vice President Contact information / address : Acrosser Technology Co., Ltd 10F.、No.12、Lane 609、Sec. 5、Chongsin Rd.、Sanchong District、New Taipei City 241、Taiwan、R.O.C. SCS-F19: Confidentiality Request Letter Page 3 of 3 Rev 2.0 Acrosser Technology Co., Ltd 10F.、No.12、Lane 609、Sec. 5、Chongsin Rd.、Sanchong District、New Taipei City 241、Taiwan、R.O.C. TEL:+886-2-29999000 FAX:+886-2-29992887 2010/05/20 To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Short Term Confidentiality Request for FCC ID: ZJD-ARV5403FL To Whom It May Concern: Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 days: - External Photos - Test Setup Photos - User’s Manual - Internal Photos The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Client’s signature : Client’s name / title : Aaron Chou / Vice President Contact information / address : Acrosser Technology Co., Ltd 10F.、No.12、Lane 609、Sec. 5、Chongsin Rd.、Sanchong District、New Taipei City 241、Taiwan、R.O.C.

Report No.: 115211R-RFUSP28V01 Page : 1 of 24 Attachment 2 : EUT Detailed Photographs (1) EUT Photo (2) EUT Photo Report No.: 115211R-RFUSP28V01 Page : 2 of 24 (3) EUT Photo (4) EUT Photo Report No.: 115211R-RFUSP28V01 Page : 3 of 24 (5) EUT Photo (6) EUT Photo

Repo rt No.: 115211 R-RFUSP28 V01 Page : 4 of 24 (7) EUT Photo (8) EUT Photo Repo rt No.: 115211 R-RFUSP28 V01 Page : 5 of 24 (9) EUT Photo (10) EUT Photo Repo rt No.: 115211 R-RFUSP28 V01 Page : 6 of 24 (11) EUT Photo (12) EUT Photo Repo rt No.: 115211 R-RFUSP28 V01 Page : 7 of 24 (13) EUT Photo (14) EUT Photo Repo rt No.: 115211 R-RFUSP28 V01 Page : 8 of 24 (15) EUT Photo (16) EUT Photo Repo rt No.: 115211 R-RFUSP28 V01 Page : 9 of 24 (17) EUT Photo (18) EUT Photo Repo rt No.: 115211 R-RFUSP28 V01 Page : 10 of 24 (19) EUT Photo (20) EUT Photo Repo rt No.: 115211 R-RFUSP28 V01 Page : 11 of 24 (21) EUT Photo (22) EUT Photo Repo rt No.: 115211 R-RFUSP28 V01 Page : 12 of 24 (23) EUT Photo (24) EUT Photo Repo rt No.: 115211 R-RFUSP28 V01 Page : 13 of 24 (25) EUT Photo (26) EUT Photo Repo rt No.: 115211 R-RFUSP28 V01 Page : 14 of 24 (27) EUT Photo (28) EUT Photo Repo rt No.: 115211 R-RFUSP28 V01 Page : 15 of 24 (29) EUT Photo (30) EUT Photo Repo rt No.: 115211 R-RFUSP28 V01 Page : 16 of 24 (31) EUT Photo (32) EUT Photo Repo rt No.: 115211 R-RFUSP28 V01 Page : 17 of 24 (33) EUT Photo (34) EUT Photo Repo rt No.: 115211 R-RFUSP28 V01 Page : 18 of 24 (35) EUT Photo (36) EUT Photo Repo rt No.: 115211 R-RFUSP28 V01 Page : 19 of 24 (37) EUT Photo (38) EUT Photo Repo rt No.: 115211 R-RFUSP28 V01 Page : 20 of 24 (39) EUT Photo (40) EUT Photo Repo rt No.: 115211 R-RFUSP28 V01 Page : 21 of 24 (41) EUT Photo (42) EUT Photo (3G Antenna) Repo rt No.: 115211 R-RFUSP28 V01 Page : 22 of 24 (43) EUT Photo (44) EUT Photo (GPS Antenna) Repo rt No.: 115211 R-RFUSP28 V01 Page : 23 of 24 (45) EUT Photo (46) EUT Photo Repo rt No.: 115211 R-RFUSP28 V01 Page : 24 of 24 (47) EUT Photo (Bluetooth and WLAN Antenna) (48) EUT Photo

Report No. 115211R-RF-US-RFEXP Page: 1 of 6 RF Exposure Evaluation declaration Product Name : IPC Model No. : AR-V5403FLxxxx ( x=0~9,A~Z or Space ) FCC ID : ZJD-ARV5403FL Applicant : Acrosser Technology Co., Ltd Address : 10F., No.12, Lane 609, Sec. 5, Chongsin Rd., Sanchong District, New Taipei City 241, Taiwan, R.O.C. Date of Receipt : May. 11, 2011 Date of Declaration : May. 24, 2011 Report No. : 115211R-RF-US-RFEXP The declaration results relate only to the samples calculated. The declaration shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Report No. 115211R-RF-US-RFEXP Page: 2 of 6 1. RF Exposure Evaluation 1.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b). LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- F/1500 30 1500-100,000 -- -- 1 30 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*Pi*R 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. 1.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. The temperature and related humidity: 23°Cand 58％ RH. Report No. 115211R-RF-US-RFEXP Page: 3 of 6 1.3. Test Result of RF Exposure Evaluation Product : IPC Test Item : RF Exposure Evaluation Test Site : N/A For 2G GSM 850 GPRS-Peak Gain: 5dBi Frequency (MHz) Conducted Power (dBm) Duty Cycle Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm 2 ) Limit (mW/cm 2 ) Pass/Fail 824.2 31.95 1/8 195.8 0.1232 0.55 Pass 836.4 31.94 1/8 195.4 0.1229 0.55 Pass 848.8 31.89 1/8 193.2 0.1215 0.55 Pass GSM 850 EGPRS-Peak Gain: 5dBi Frequency (MHz) Conducted Power (dBm) Duty Cycle Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm 2 ) Limit (mW/cm 2 ) Pass/Fail 824.2 27.09 1/8 64.0 0.0402 0.55 Pass 836.4 27.11 1/8 64.3 0.0404 0.55 Pass 848.8 27.03 1/8 63.1 0.0397 0.55 Pass PCS 1900 GPRS-Peak Gain: 5dBi Frequency (MHz) Conducted Power (dBm) Duty Cycle Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm 2 ) Limit (mW/cm 2 ) Pass/Fail 1850.2 29.35 1/8 107.6 0.0677 1 Pass 1880 29.15 1/8 102.8 0.0647 1 Pass 1909.8 29.08 1/8 101.1 0.0636 1 Pass Report No. 115211R-RF-US-RFEXP Page: 4 of 6 PCS 1900 EGPRS-Peak Gain: 5dBi Frequency (MHz) Conducted Power (dBm) Duty Cycle Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm 2 ) Limit (mW/cm 2 ) Pass/Fail 1850.2 26.50 1/8 55.8 0.0351 1 Pass 1880 26.29 1/8 53.2 0.0335 1 Pass 1909.8 26.23 1/8 52.5 0.0330 1 Pass For 3G WCDMA V-Peak Gain: 5dBi Frequency (MHz) Conducted Power (dBm) Duty Cycle Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm 2 ) Limit (mW/cm 2 ) Pass/Fail 826.4 23.11 1 204.6 0.1287 0.55 Pass 836.6 23.40 1 218.8 0.1376 0.55 Pass 846.6 23.15 1 206.5 0.1299 0.55 Pass WCDMA V HSDPA-Peak Gain: 5dBi Frequency (MHz) Conducted Power (dBm) Duty Cycle Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm 2 ) Limit (mW/cm 2 ) Pass/Fail 826.4 22.80 1 190.5 0.1199 0.55 Pass 836.6 23.16 1 207.0 0.1302 0.55 Pass 846.6 23.04 1 201.4 0.1267 0.55 Pass WCDMA V HSUPA-Peak Gain: 5dBi Frequency (MHz) Conducted Power (dBm) Duty Cycle Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm 2 ) Limit (mW/cm 2 ) Pass/Fail 826.4 22.08 1 161.4 0.1016 0.55 Pass 836.6 22.46 1 176.2 0.1108 0.55 Pass 846.6 22.84 1 192.3 0.1210 0.55 Pass Report No. 115211R-RF-US-RFEXP Page: 5 of 6 WCDMA II -Peak Gain: 5dBi Frequency (MHz) Conducted Power (dBm) Duty Cycle Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm 2 ) Limit (mW/cm 2 ) Pass/Fail 1852.4 23.59 1 228.6 0.1438 1 Pass 1880 23.33 1 215.3 0.1354 1 Pass 1907.6 23.25 1 211.3 0.1330 1 Pass WCDMA II HSDPA-Peak Gain: 5dBi Frequency (MHz) Conducted Power (dBm) Duty Cycle Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm 2 ) Limit (mW/cm 2 ) Pass/Fail 1852.4 23.66 1 232.3 0.1461 1 Pass 1880 23.37 1 217.3 0.1367 1 Pass 1907.6 23.30 1 213.8 0.1345 1 Pass WCDMA II HSUPA-Peak Gain: 5dBi Frequency (MHz) Conducted Power (dBm) Duty Cycle Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm 2 ) Limit (mW/cm 2 ) Pass/Fail 1852.4 22.82 1 191.4 0.1204 1 Pass 1880 23.12 1 205.1 0.1290 1 Pass 1907.6 22.33 1 171.0 0.1076 1 Pass Note: The conducted output power is refer to report No.: 115211R-HPUSP07V01 from the QuieTek. For WLAN / BT 802.11b- Peak Gain : 2.89 dBi Frequency (MHz) Conducted Power (dBm) Duty Cycle Output power to Antenna (mW) Power density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Pass / Fail 2412 15.1 1 32.4 0.1250 1 Pass 2437 17.9 1 61.7 0.0238 1 Pass 2462 18.2 1 66.1 0.0256 1 Pass BT- Peak Gain : 2.89 dBi Frequency (MHz) Conducted Power (dBm) Duty Cycle Output power to Antenna (mW) Power density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Pass / Fail 2402 0.66 1 1.16 0.0005 1 Pass 2441 0.06 1 1.01 0.0004 1 Pass 2480 -1.88 1 0.65 0.0003 1 Pass 802.11n (20MHz)- Peak Gain : 2.89 dBi Frequency (MHz) Conducted Power (dBm) Duty Cycle Output power to Antenna (mW) Power density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Pass / Fail 2412 16.41 1 43.8 0.0169 1 Pass 2437 17.92 1 61.9 0.0240 1 Pass 2462 17.23 1 52.8 0.020…

Text truncated - open the document above for the full version.

Report No.115211R-RFUSP24V02 Page : 1 of 33 Test Report Product Name IPC Model No. AR-V5403FLxxxx (x=0~9,A~Z or Space) FCC ID. DoC Applicant Acrosser Technology Co., Ltd Address 10F., No.12, Lane 609, Sec. 5, Chongsin Rd., Sanchong District, New Taipei City 241, Taiwan, R.O.C. Date of Receipt May 10, 2011 Issued Date May 16, 2011 Report No. 115211R-RFUSP24V02 Report Version V1.0 The Test Results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Report No.115211R-RFUSP24V02 Page : 2 of 33 Test Report Certification Issued Date: May 16, 2011 Report No.: 115211R-RFUSP24V02 Product Name IPC Applicant Acrosser Technology Co., Ltd Address 10F., No.12, Lane 609, Sec. 5, Chongsin Rd., Sanchong District, New Taipei City 241, Taiwan, R.O.C. Manufacturer Acrosser Technology Co., Ltd Model No. AR-V5403FLxxxx (x=0~9,A~Z or Space) FCC ID. DoC EUT Rated Voltage AC 100-240 V, 50-60 Hz EUT Test Voltage AC 120V/ 60Hz Trade Name Acrosser Applicable Standard FCC CFR Title 47 Part 15 Subpart B: 2010 ANSI C63.4: 2009 Test Result Complied The Test Results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Documented By : ( Senior Adm. Specialist / Rita Huang ) Tested By : ( Engineer / Vincent Chu ) Approved By : (Manager / Vincent Lin ) Report No.115211R-RFUSP24V02 Page : 3 of 33 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION ..............................................................................................................4 1.1. EUT Description ........................................................................................................................4 1.2. Test System Details....................................................................................................................7 1.3. Configuration of Test System ....................................................................................................8 1.4. EUT Exercise Software..............................................................................................................8 1.5. Test Facility................................................................................................................................9 2. Conducted Emission...........................................................................................................................10 2.1. Test Equipment ........................................................................................................................10 2.2. Test Setup.................................................................................................................................10 2.3. Limits .......................................................................................................................................10 2.4. Test Procedure..........................................................................................................................11 2.5. Uncertainty...............................................................................................................................11 2.6. Test Result of Conducted Emission .........................................................................................12 3. Radiated Emission..............................................................................................................................16 3.1. Test Equipment ........................................................................................................................16 3.2. Test Setup.................................................................................................................................16 3.3. Limits .......................................................................................................................................17 3.4. Test Procedure..........................................................................................................................18 3.5. Uncertainty...............................................................................................................................18 3.6. Test Result of Radiated Emission ............................................................................................19 4. EMI Reduction Method During Compliance Testing .....................................................................31 Attachment 1: EUT Test Photographs Attachment 2: EUT Detailed Photographs Report No.115211R-RFUSP24V02 Page : 4 of 33 1. GENERAL INFORMATION 1.1. EUT Description Product Name IPC Trade Name Acrosser Model No. AR-V5403FLxxxx (x=0~9,A~Z or Space) FCC ID. DoC Frequency Range 2412-2462MHz for 802.11b/g/n-20BW, 2422-2452MHz for 802.11n-40BW BT: 2402 – 2480MHz Number of Channels 802.11b/g/n-20MHz: 11, n-40MHz: 7 Bluetooth: 79 Data Speed 802.11b: 1-11Mbps, 802.11g: 6-54Mbps, 802.11n: 7.2-150Mbps Bluetooth: 1-3Mbps Type of Modulation WLAN: 802.11b:DSSS (DBPSK, DQPSK, CCK) WLAN: 802.11g/n: OFDM (BPSK, QPSK, 16QAM, 64QAM) Bluetooth: FHSS- GFSK(1Mbps) /π/4DQPSK(2Mbps) / 8DPSK(3Mbps) Antenna Type Dipole Antenna Gain Refer to the table “Antenna List” Channel Control Auto Power Adapter MFR: FSP, M/N: FSP096AHB Input: AC 100-240V, 50-60Hz, 2.0A Output: DC 12V-8A Cable out: Non-Shielded, 2.5m, with one ferrite core bonded. Power Cord: Non-Shielded, 0.8m Antenna List No. Manufacturer Part No. Antenna Type Peak Gain 1 KINSUN 6603803081-000 Dipole 2.89 dBi for 2.4 GHz Report No.115211R-RFUSP24V02 Page : 5 of 33 802.11b/g/n-20MHz Center Frequency of Each Channel (WLAN): Channel Frequency Channel FrequencyChannel FrequencyChannel Frequency Channel 01: 2412 MHz Channel 02: 2417 MHz Channel 03: 2422 MHz Channel 04: 242…

Text truncated - open the document above for the full version.

Report No.:115211R-HPUSP07V01 Page: 1 of 122 Test Report Product Name : IPC Model No : AR-V5403FLxxxx ( x=0~9,A~Z or Space ) FCC ID : ZJD-ARV5403FL Applicant : Acrosser Technology Co., Ltd Address : 10F., No.12, Lane 609, Sec. 5, Chongsin Rd., Sanchong District, New Taipei City 241, Taiwan, R.O.C. Date of Receipt：2011/05/10 Issued Date ：2011/05/13 Report No. ：115211R-HPUSP07V01 Report Version：V 1.0 The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of Quie Tek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Report No.:115211R-HPUSP07V01 Page: 2 of 122 Test Report Certification Issued Date : 2011/05/13 Report No.: 115211R-HPUSP07V01 Test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of Quie Tek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Product Name : IPC Applicant : Acrosser Technology Co., Ltd Address : 10F., No.12, Lane 609, Sec. 5, Chongsin Rd., Sanchong District, New Taipei City 241, Taiwan, R.O.C. Manufacturer : Acrosser Technology Co., Ltd Trade Name : Acrosser Model No. : AR-V5403FLxxxx ( x=0~9,A~Z or Space ) EUT Rated Voltage : AC 120V/60Hz EUT Test Voltage : AC 120V/60Hz Measurement Standard : FCC CFR Title 47 Part 2 22 24 Measurement Reference : TIA/EIA 603-C Test Result : Complied Documented By : (Adm. Assistant / Anny Chou) Tested By : (Engineer / Vorana Chen) Approved By : (Manager /Vincent Lin) Accredited by NIST (NVLAP) NVLAP Lab Code: 200533-0 Report No.:115211R-HPUSP07V01 Page: 3 of 122 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION ............................................................................................ 4 1.1. EUT Description ........................................................................................................... 4 1.2. Operational Description............................................................................................... 5 1.3. Configuration of tested System .................................................................................. 6 1.4. EUT Setup Procedures ................................................................................................ 6 1.5. Test Facility ...................................................................................................................7 1.6. Type of Emission .......................................................................................................... 8 1.7. DC voltages and DC currents ...................................................................................... 8 2. Peak Power Output ....................................................................................................... 9 2.1. Test Equipment.............................................................................................................9 2.2. Test Setup ..................................................................................................................... 9 2.3. Limits ........................................................................................................................... 10 2.4. Test Procedure ........................................................................................................... 10 2.5. Test Specification ....................................................................................................... 10 2.6. Test Result of Peak Power Output ............................................................................ 11 3. Occupied Bandwidth .................................................................................................. 29 3.1. Test Equipment........................................................................................................... 29 3.2. Test Setup ................................................................................................................... 29 3.3. Test Procedure ........................................................................................................... 29 3.4. Test Specification ....................................................................................................... 30 3.5. Test Result of Occupied Bandwidth ......................................................................... 31 4. Spurious Emission At Antenna Terminals (+/-1MHz) .............................................. 53 4.1. Test Equipment........................................................................................................... 53 4.2. Setup ........................................................................................................................... 53 4.3. Limits ........................................................................................................................... 54 4.4. Test Procedure ........................................................................................................... 54 4.5. Test Specification ....................................................................................................... 54 4.6. Test Result of Spurious Emission At Antenna Terminals (+/-1MHz)...................... 55 5. Spurious Emission ..............................................................................…

Text truncated - open the document above for the full version.
