ZJV-ENGFMT4FM Transmitter

English 简体 Product Name 品名 FM transmitter with car charger adapter 带车充的发射器 Introduction 简介 FM transmitter wirelessly connects your music phone or MP3 to your car stereo easily over FM radio waves, let you enjoy the high quality music of your phone or other devices.At the same time,it can charge for other devices by USB output slot. *FM发射器通过FM音频信号无线连接您的手机与汽 车音响，让您通过汽车音响享受到手机或其他设备 内的高品质音乐。同时具备，自带的USB输出口电 流可以为其他设备充电。 Features 特征描述 * Full frequency range(88,1MHZ to 107.9MHZ). Memory for last frequency. * High fidelity, stereo, Digital PLL. * Powered by the car’s power source. *USB output function for your other devices charge. *全频段设计，自动记忆最后使用的发射频率。 *高保真立体声，采用DIGITAL PLL 技术，让您享受 高清晰音质的音乐。 *使用汽车电源供电。 *其他设备的充电功能 Specifications 技术参数 * Frequency response: 100Hz-15000Hz * Separation: ≥30dB * Operating current: 20±3mA * Input voltage: DC 12V * 频率特性：100Hz-15000Hz *分离度：≥30dB *工作电流：20mA±3mA *输入电压：DC 12V Compatible with 适用机型 * All iPod, iPhone, iPad and other audio devices with 3.5mm audio socket *所有iPod、iPhone、iPad等带3.5mm音频接头的设 备。 Use Means 使用说明 * Connect the FM transmitter to your compatible device and plug the car charger to your cigarette lighter. * Adjust the volume of the car radio and tune it to the same frequency. * Play your music and enjoy it via car stereo. * If the FM signal is interrupted, please reset the car radio and the FM transmitter to another clear frequency. * Optional frequency : press "CH +" and "CH -" button to select different frequency. *将发射器的音频头与适用的手机连接，将车充的一 头插入汽车的点烟口。 *调节汽车音响的音量，将FM收音机调至相同频率 。 *播放音乐即可通过汽车音响收听。 *如果FM频率受干扰，请重设FMtalk和收音机至其 它频率。 *选择频率范围：按下调频的“CH +”和“CH -”两个按 键。 Th is device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help.

January 15, 2015 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: ZJV- ENGFMT4____ Product Name: FM Transmitter Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics Long-term confidential  Block diagram Long-term confidential  Operation description Long-term confidential These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this January 15, 2015 Agency agreement expiration date: Usually Give 8 - 12 Months By: Albert Esses Signature Printed Title: Manage Director On behalf of : (Company Name) Premier Accessory Group Telephone: 718-371-3634

January 15, 2015 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Alpha Product Testing Laboratory, Address: Building B, East Area of Nanchang Second, Industrial Zone, Gushu 2nd Road, Bao'an, Shenzhen, China Person: Mark Zhu (Name and address，person). to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Premier Accessory Group . Address: 11-11 44 th Drive,Long Island, New York,United States ( applicant name and address). Signature: Name Albert Esses Position Manage Director Company Name Premier Accessory Group Address 11-11 44 th Drive,Long Island, New York,United States Tel 718-371-3634 Fax 718-371-3624 Email [email protected]

January 15, 2015 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: ZJV- ENGFMT4____ Product Name: FM Transmitter Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: Schematics Long-term confidential Block diagram Long-term confidential Operation description Long-term confidential These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this January 15, 2015 Agency agreement expiration date: Usually Give 8 - 12 Months By: Albert Esses Signature Printed Title: Manage Director On behalf of : (Company Name) Premier Accessory Group Telephone: 718-371-3634 Model NoENG-FMT4 PWFMT5 EV-FMT4 We declare that all model’s the function, software and electric circuit are the same. ZJV-ENGFMT4

20mm 7mm FCC ID: ZJV-ENGFMT4

Label location

Antenna

Alpha Product Testing Laboratory TEST REPORT FCC ID: ZJV-ENGFMT4 Applicant : Premier Accessory Group Address : 11-11 44 th Drive, Long Island, New York, United States Equipment under Test (EUT): Name : FM Transmitter Model : ENG-FMT4 / PWFMT5 / EV-FMT4 Standards : FCC PART 15, SUBPART C : 2014 (Section 15.239) Report No. : A1841107 01 Date of Test: December 25- December 30, 2014 Date of Issue: January 05, 2015 Test Result : PASS * *In the configuration tested, the EUT complied with the standards specified above Authorized Signature (Mark Zhu) General Manager The manufacture should ensure that all the products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of Alpha Product Testing Laboratory. Or test done by Alpha Product Testing Laboratory. Approvals in connection with, distribution or use of the product described in this report must be approved by Alpha Product Testing Laboratory. Approvals in writing. Page 2 of 29Report No.:A1841107 01 TABLE OF CONTENT Description Page 1 General Information ----------------------------------------------------------------------------------- 3 1.1 Description of Device (EUT) ---------------------------------------------------------------- 3 1.2 Description of Test Facility ------------------------------------------------------------------ 3 2 EMC Equipment List ------------------------------------------------------------------------------- 4 3 Test Procedure ---------------------------------------------------------------------------------------- 5 4 Summary of Measurement ------------------------------------------------------------------------ 6 4.1 Summary of test result ----------------------------------------------------------------------- 6 4.2 Test mode -------------------------------------------------------------------------------------- 6 5 POWER LINE CONDUCTED EMISSION --------------------------------------------------- 8 5.1 Conducted Emission Limits(15.209&249) ------------------------------------------------ 8 5.2 Test Setup -------------------------------------------------------------------------------------- 8 5.3 Test Procedure --------------------------------------------------------------------------------- 9 5.4 Test Results ------------------------------------------------------------------------------------ 9 6 Radiation Emission -------------------------------------------------------------------------------- 10 6.1 Radiation Emission Limits(15.209&249 (a)) -------------------------------------------- 10 6.2 Test Setup ------------------------------------------------------------------------------------- 11 6.3 Test Procedure -------------------------------------------------------------------------------- 12 6.4 Test Equipment Setting For emission test. ----------------------------------------------- 13 6.5 Test Condition -------------------------------------------------------------------------------- 13 6.6 Test Result ------------------------------------------------------------------------------------ 13 7 Occupied bandwidth ------------------------------------------------------------------------------- 17 7.1 Test limit -------------------------------------------------------------------------------------- 17 7.2 Method of measurement -------------------------------------------------------------------- 17 7.3 Test Setup ------------------------------------------------------------------------------------- 17 7.4 Test Results ----------------------------------------------------------------------------------- 17 8 Band Edge Check ---------------------------------------------------------------------------------- 20 8.1 Test limit -------------------------------------------------------------------------------------- 20 8.2 Test Procedure -------------------------------------------------------------------------------- 20 8.3 Test Setup ------------------------------------------------------------------------------------- 20 8.4 Test Result ------------------------------------------------------------------------------------ 20 9 Antenna Requirement ----------------------------------------------------------------------------- 23 9.1 Standard Requirement ----------------------------------------------------------------------- 23 9.2 Antenna Connected Construction ---------------------------------------------------------- 23 9.3 Result ------------------------------------------------------------------------------------------ 23 10 Photographs of Test Setup ------------------------------------------------------------------------ 24 11 Photographs of EUT ------------------------------------------------------------------------------- 25 Page 3 of 29 Report No.:A1841107 01 1 General Information 1.1Description of Device (EUT) EUT : FM Transmitter Trade Name : N/A Model No. : ENG-FMT4 / PWFMT5 / EV-FMT4 DIFF. : All model’s the function, software and electric circuit are the same. so all the test were performed on the model ENG-FMT4. Type of Antenna : Integrated Antenna, Max. Gain: 0dBi Operation Frequency : 88.1-107.9MHz Channel number : 199 Modulation type : FM Power Supply : DC 12V Supply by battery of Car power supply system Applicant : Premier Accessory Group Address : 11-11 44 th Drive,Long Island, New York,United States Manufacturer : Premier Accessory Group Address : 11-11 44 th Drive,Long Island, New York,United States 1.2Description of Test Facility Alpha Product Testing Laboratory Building B, East Area of Nanchang Second, Industrial Zone, Gushu 2nd Road, Bao'an, Shenzhen, China August 11, 2014 File on Federal Communication Commission Registration Number: 203110 July 18, 2014 Certificated by IC Registration Number: 12135A Page 4 of 29 Report No.:A1841107 01 2 EMC Equipment List Equipment Manufacture Model No. Serial…

Text truncated - open the document above for the full version.

Radiated emission
