ZL9-M72BW2Tablet

FCC RF Exposure Information and Statement The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Tablet (FCC ID: ZL9-M72BW2) has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification for use on the body is 0.4928W/kg. This device was tested for typical body-worn operations with the back of the handset kept 0mm from the body. To maintain compliance with FCC RF exposure requirements, use accessories that maintain a 0mm separation distance between the user's body and the back of the handset. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided. FCC Warning This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

ELECTRONICS TECHNOLOGY(DONG GUAN) COMPANY LIMITED Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 12/4/2014 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: ZL9-M 72BW2 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Signature [Xiaona Liu] [QA Manger] [ELECTRONICS TECHNOLOGY(DONG GUAN) COMPANY LIMITED]

ELECTRONICS TECHNOLOGY(DONG GUAN) COMPANY LIMITED Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 12/4/2014 Request for Confidentiality Company name: ELECTRONICS TECHNOLOGY(DONG GUAN) COMPANY LIMITED FCC ID: ZL9-M 72BW2 FCC Part 15 Certification Gentlemen, In accordance with CFR 47 § 0.457 and CFR 47 § 0.459 ELECTRONICS TECHNOLOGY(DONG GUAN) COMPANY LIMITED hereby requests confidentiality of following attachments: (1) schematic diagrams, (2) detailed block diagrams, (3) detailed operational descriptions, (4) parts lists. These documents contain detailed system and equipment description and related information about the product which ELECTRONICS TECHNOLOGY(DONG GUAN) COMPANY LIMITED considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, ELECTRONICS TECHNOLOGY(DONG GUAN) COMPANY LIMITED considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Signature [Xiaona Liu] [QA Manger] ELECTRONICS TECHNOLOGY(DONG GUAN) COMPANY LIMITED No.161, Xin Min Road, Tong Luo Wei Industrial Zone

Model: M72BW2-WP(AP) REPORT NO.: STR14118242I-2 FCC PART 15.247 EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 Model: M72BW2-WP(AP) REPORT NO.: STR14118242I-2 FCC PART 15.247 EUT View 3 EUT View 4 Model: M72BW2-WP(AP) REPORT NO.: STR14118242I-2 FCC PART 15.247 EUT View 5 EUT View 6 Model: M72BW2-WP(AP) REPORT NO.: STR14118242I-2 FCC PART 15.247 EUT View 7

Model: M72BW2-WP(AP) REPORT NO.: STR14118242I-2 FCC PART 15.247 EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format Specifications: Text is Black in color and justified. Labels are printed in indelible ink on permanent adhesive silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Proposed Label Location on EUT FCC ID Label Location FCC ID: ZL9-M72BW2 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Model: M72BW2-WP(AP) REPORT NO.: STR14118242I-2 FCC PART 15.247 EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 Solder Board-Component View 1 WIFI Antenna Model: M72BW2-WP(AP) REPORT NO.: STR14118242I-2 FCC PART 15.247 Solder Board-Component View 2

Provided by Eurofins Produc t Service GmbH v.0.2 ELECTRONICS TECHNOLOGY(DONG GUAN) COMPANY LIMITED Declaration concerning Antenna Specification It is hereby declared that the product Model No.: M72BW2-WP(AP) FCC ID: ZL9- M72BW2 fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for internal antenna type described below: Model No. of antenna: WIFI/BT Antenna Type of antenna: permanently attached (has a unique connector) Peak Gain of the antenna: 0 dBi Frequency range: 2400-2500 MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: ELECTRONICS TECHNOLOGY(DONG GUAN) COMPANY LIMITED Address: No.161, Xin Min Road, Tong Luo Wei Industrial Zone City: Dong Guan ZIP / Postal code: N/A Country: China Place: Dong Guan Date: 12/04/2014 Signature:

Tune up procedure Tune up procedure shall be over the power range or at specific operating power levels. 1. It must provide an operational voltage (3.4 ~ 4.2V DC) to turn on the device and on one certain channel in service mode by means of company proprietary software. 2. Base station simulator ( CMU 200 ) measures the Tablet device specific RF characterist ics. 3. The maximum gains of each individual device are adjusted until the target value met. Tune‐up Power Mode Frequency Bands Tune‐up Power WIFI 2.4GHz 15.0dBm±1dB Then these appropriate gain settings are stored in each device individually. The user has no possibility to change these settings later on, and during manufacturing each device will be individual calibrated. The measurement is done in fully calibrated setup, which is based on a CMU 200 base station simulator. Furthermore, the highest power level is verified afterwards in a call measurement on three channels (low, middle and high).

Model: M72BW2-WP(AP) Report No.: STR14118242H Page 1 of 44 SAR Report FCC SAR Measurement and Test Report For ELECTRONICS TECHNOLOGY(DONG GUAN) COMPANY LIMITED No.161, Xin Min Road, Tong Luo Wei Industrial Zone, Dong Guan City, China FCC Rules: FCC 47 CFR Part 2 (2.1093) ANSI/IEEE C95.1-1992 IEEE 1528-2003 KDB 865664 D01 v01r03 KDB 865664 D02 v01r01 Product Description: Tablet Tested Model: M72BW2-WP(AP) Report No.: STR14118242H Max. SAR Values: Body: 0.4928 W/kg(1g) Tested Date: 2014-12-01 to 2014-12-02 Issued Date: 2014-12-03 Tested By: Lucy Wei / Engineer Reviewed By: Lahm Peng / EMC Manager Approved & Authorized By: Jandy So / PSQ Manager Prepared By: Shenzhen SEM.Test Technology Co., Ltd. 1/F, Building A, Hongwei Industrial Park, Liuxian 2nd Road, Bao'an District, Shenzhen, P.R.C.（518101） Tel.: +86-755-33663308 Fax.: +86-755-33663309 Website: www.semtest.com.cn Note: This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen SEM. Test Technology Co., Ltd. FCC ID: ZL9-M72BW2 Model: M72BW2-WP(AP) Report No.: STR14118242H Page 2 of 44 SAR Report TABLE OF CONTENTS 1. General Information ................................................................................................................................................... 3 1.1 Product Description for Equipment Under Test (EUT) ......................................................................................... 3 1.2 Test Standards .................................................................................................................................................... 4 1.3 Test Methodology ................................................................................................................................................ 4 1.4 Test Facility ......................................................................................................................................................... 4 2. Summary of Test Results .......................................................................................................................................... 5 3. Specific Absorption Rate (SAR) ................................................................................................................................ 6 3.1 Introduction .......................................................................................................................................................... 6 3.2 SAR Definition ..................................................................................................................................................... 6 4. SAR Measurement System ........................................................................................................................................ 7 4.1 The Measurement System .................................................................................................................................. 7 4.2 Probe ................................................................................................................................................................... 7 4.3 Probe Calibration Process ................................................................................................................................... 9 4.4 Phantom ............................................................................................................................................................ 10 4.5 Device Holder .................................................................................................................................................... 10 4.6 Test Equipment List ........................................................................................................................................... 11 5. Tissue Simulating Liquids ....................................................................................................................................... 12 5.1 Composition of Tissue Simulating Liquid ........................................................................................................... 12 5.2 Tissue Dielectric Parameters for Head and Body Phantoms ............................................................................. 13 5.3 Tissue Calibration Result ................................................................................................................................... 14 6. SAR Measurement Evaluation ................................................................................................................................ 15 6.1 Purpose of System Performance Check ............................................................................................................ 15 6.2 System Setup .................................................................................................................................................... 15 6.3 Validation Results .............................................................................................................................................. 16 7. EUT Testing Position ............................................................................................................................................... 17 7.1 Body Worn Position ........................................................................................................................................... 17 7.5 EUT Antenna Position ....................................................................................................................................... 17 7.6 EUT Testing Position ......................................................................................................................................... 18 8. SAR Measurement Procedures ............................................................................................................................... 19 8.1 Measurement Procedures ............…
