ZMNVT2USARemote Control

TO OPEN THE BATTERY SECTION (VT1 - VT2) AND CONTROLLER BOTTONS OF MODEL VT2, PRESS AS INDICATED AND LIFT UPWARDS. PER APRIRE IL VANO BATTERIA (VT1 - VT2) E IL VANO TASTI PER IL RADIOCOMANDO MOD. VT2 PREMERE IL PUNTO INDICATO E PREMERE VERSO L’ALTO. PARA ABRIR LA CAVIDAD DONDE SE ENCUENTRA LA BATERIA (VT1 - VT2) Y BOTONES RADIOCONTROL PARA EL MODELO VT2, APRETAR EL PUNTO INDICADO Y TIRAR HACIA EL ALTO POUR OUVRIR LE CLAPET DE LA PILE (VT1 - VT2) ET LES TOUCHES DE CONTRÔLE (MODÈLE VT2), APPUYER SUR LE POINT INDIQUÉ ET POUSSER VERS LE HAUT OM HET KLEPJE VAN DE BATTERIJ (VT1 - VT2) EN DE CONTROLEKNOPPEN (MODEL VT2) TE OPENEN: DRUK OP HET AANGEDUIDE PUNT EN DUW OMHOOG GENERAL INSTRUCTION ISTRUzIONI GENERALI INSTRUCCIONES GENERALES INSTRUCTIONS GÉNÉRALES ALGEMENE INSTRUCTIES INSTRUCTION ISTRUzIONI INSTRUCCIONES INSTRUCTIONS HANDLEIDING REMOTE CONTROLLER RADIOCOMANDO MANDO A DISTANCIA COMMANDE A DISTANCE AFSTANDSBEDIENING POWER SUPPLY: 9V BATTERY AVERAGE LIFE: 9 MONTHS OPERATING FREQUENCY: 433.92 - 868 MHZ WORKING RANGE: 1-15 MT WORKING RANGE ONLY FOR U.S.A.: 1-10 MT OPERATING TEMPERATURE: +5° / +45° POWER SUPPLY: 9V BATTERY AVERAGE LIFE: 6 MONTHS OPERATING FREQUENCY: 433.92 - 868 MHZ WORKING RANGE: 1-15 MT WORKING RANGE ONLY FOR U.S.A.: 1-10 MT OPERATING TEMPERATURE: +5° / +45° • POUR FAIRE AVANCER LE N°, APPUYER SUR LE GRAND BOUTON • POUR RÉPÉTER LE N°, APPUYER SUR LE BOUTON ON/OFF • POUR METTRE LE TABLEAU À ZÉRO, APPUYER LE BOUTON ‘ZÉRO’, PENDANT 3 SECONDES • POUR ÉTEINDRE LE OU LES TABLEAUX, APPUYER LE BOUTON ON/OFF PENDANT 3 SECONDES • POUR DIMINUER LE N° SUR LE TABLEAU MURAL, APPUYER SUR LA TOUCHE 7 CHANGER LE VOLUME DU SIGNAL SONORE: • POUR AUGMENTER OU DIMINUER LE VOLUME DU SIGNAL SONORE, AGIR SUR LES TOUCHES 2 ET 5 CHANGER LE CODE DE COMMUNICATION AVEC LE TABLEAU MURAL : 1) APPUYER SIMULTANÉMENT SUR LES TOUCHES 1, 4 ET 7 : LE CODE ACTUEL S’AFFICHE (PAR EX. C1) 2) APPUYER SUR UNE DES TOUCHES NUMÉRIQUES (1 À 8) POUR PROGRAMMER LE NOUVEAU CODE 3) ENSUITE, APPUYER LE BOUTON ‘’A’’ SUR LE TABLEAU MURAL, (VOIR INSTRUCTIONS TABLEAU MURAL) 4) LE TABLEAU MURAL AFFICHERA LE CODE DE COMMUNICATION ACTUEL (PAR EX. C1) ET ATTENDRA LE SIGNAL DE LA COMMANDE À DISTANCE PENDANT CINQ SECONDES 5) APPUYER LE GRAND BOUTON DE LA COMMANDE À DISTANCE, LE TABLEAU MURAL SERA MIS À JOUR AVEC LA COMMANDE À DISTANCE ET AFFICHERA LE NUMÉRO DE LA FILE D’ATTENTE LE SYSTÈME ’’MESSAGE VOCAL’’. • POUR AUGMENTER OU DIMINUER LE VOLUME DU MESSAGE, AGIR SUR LES TOUCHES 3 ET 6 • POUR SÉLECTIONNER UN DES MESSAGES, APPUYER SUR LA TOUCHE 8 • POUR ÉTEINDRE LE MESSAGE VOCAL, APPUYER SUR LA TOUCHE 9 INFORMATION ON THE TREATMENT OF WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT: 1) IT IS FORBIDDEN TO DISPOSE OF EEE PRODUCTS ALONG WITH NORMAL WASTES (DIRECTIVE 2002/96 CE DATED JANUARY 27 - 2003 AND FOLLOWING LEGISLATIVE DECREE ISSUED BY ALL MEMBER STATES); PLEASE NOTE THAT DISPOSING OF EEE PRODUCTS ALONG WITH NORMAL WASTES OR, WORST, ABANDONING EEE ARTICLES, IT IS NOT ONLY FORBIDDEN BUT POLUTES THE ENVIRONMENT. 2) TO ENHANCE THE SEPARATE COLLECTION SERVICE, OPEN DATA SRL INFORMS THAT YOU CAN BRING THIS PRODUCT BACK TO THE SELLER WHEN YOU BUY A NEW PRODUCT WHICH IS EQUIVALENT (AND PERFORMS THE SAME FUNCTION) TO RETURNING THE ARTICLE.. 3) THE SYMBOL (THE CROSSED WHEELEY BIN) VISIBLY PRINTED ON THE ARTICLE, INDICATES THE DUTY TO SEPARATE COLLECTIONS FOR ELECTRICAL END ELECTRONIC EQUIPMENT. 4) BY DIRECTIVE 2002/96 CE DATED JANUARY 27 - 2003 (ART. 15) AND THROUGH THE RELATIVE LEGISLATIVE DECREE ISSUED BY ANY MEMBER STATES, ALL MEMBER STATE HAVE DETERMINED EFFECTIVE, PROPORTIONATE AND DISSUASIVE PENALITIES APPLICABLE TO BREACHES OF THE NATIONAL PROVISIONS ADOPTED. ALIMENTATION: PILE 9V DURÉE DE VIE DE LA PILE: 9 MOIS FRÉQUENCE DE FONCTIONNEMENT: 433,92 - 868 MHZ COUVERTURE: 1 À 15 MÈTRES U.S.A. COUVERTURE: 1 À 10 MÈTRES TEMPÉRATURE OPÉRATIONNELLE: +5°/+45° VOEDING: BATTERIJ 9V LEVENSDUUR BATTERIJ: 9 MAANDEN WERKINGSFREQUENTIE: 433,92 MHZ / 868 MHZ BEREIK: 1 TOT 15 METER U.S.A. BEREIK: 1 TOT 10 METER WERKINGSTEMPERATUUR: +5°/+45° • VOOR HET VOLGENDE NUMMER, DRUK OP DE GROTE KNOP • NUMMER HERHALEN, DRUK OP DE AAN/UIT KNOP • OM HET NUMMERBORD OP NUL TE ZETTEN, DRUK 3 SECONDEN OP DE ‘NUL’ KNOP • NUMMERBORD(EN) UITZETTEN, DRUK 3 SECONDEN OP DE AAN/UIT KNOP • OM HET NUMMER OP HET NUMMERBORD TE VERLAGEN, DRUK OP KNOP 7 VOLUME VAN HET GELUIDSSIGNAAL WIJZIGEN: • OM HET VOLUME VAN HET GELUIDSSIGNAAL TE WIJZIGEN, DRUK OP DE KNOPPEN 2 EN 5 DE COMMUNICATIECODE MET HET NUMMERBORD WIJZIGEN: 1) DRUK GELIJKTIJDIG OP DE KNOPPEN 1, 4 EN 7:DE HUIDIGE CODE VERSCHIJNT (BIJV. C1) 2) DRUK OP ÉÉN VAN DE NUMMERKNOPPEN (1 TOT 8) OM DE NIEUWE CODE TE PROGRAMMEREN 3) DRUK VERVOLGENS OP KNOP “A” VAN HET NUMMERBORD, (ZIE HANDLEIDING NUMMERBORD) 4) HET NUMMERBORD TOONT DE HUIDIGE COMMUNICATIECODE (BIJV. C1), EN ZAL VIJF SECONDEN WACHTEN OP HET SIGNAAL VAN DE AFSTANDSBEDIENING 5) DRUK OP DE GROTE KNOP VAN DE AFSTANDSBEDIENING, HET NUMMERBORD ZAL DE CODE VAN DE AFSTANDSBEDIENING OVERNEMEN, EN HET NUMMER IN DE WACHTRIJ LATEN ZIEN HET ’’VOCAAL BERICHT’’ SYSTEEM • OM HET VOLUME VAN HET BERICHT TE VERHOGEN OF TE VERLAGEN, DRUK OP DE KNOPPEN 3 EN 6 • OM HET GEWENSTE VOCAAL BERICHT TE KIEZEN, DRUK OP KNOP 8 • OM HET VOCAAL BERICHT UIT TE ZETTEN, DRUK OP KNOP 9 ALIMENTAZIONE: BATTERIA 9V AUTONOMIA MEDIA: 9 MESI FREQUENZA DI LAVORO: 433,92 - 868 MHZ PORTATA: 1-15 MT SOLAMENTE PER GLI U.S.A. PORTATA 1-10 MT TEMPERATURA OPERATIVA: +5° / +45° TENSION DE ALIMENTATION: BATERIA 9V DURACION DE LA BATERIA: 9 MESES FRECUENCIA DE TRABAJO: 433,92 E 868 MHZ DISTANCIA DE FUNCIONAMIENTO: 1 A 15 METROS DISTANCIA DE FUNCIONAMIENTO SOLO PARA U.S.A.: 1 A 10 METROS TEMPERATURA DE FUNCIONAMIENTO: +5°/+45° ALIMENTAZIONE: BATTERIA 9V AUTONOMIA MEDIA: 6 MESI FREQUENZA DI LAVORO: 433,92 - 868 MHZ PORTATA: 1-15 MT SOLAMENTE PER GLI U.S.A. PORTATA 1-10 MT TEMPERATURA OPERATIVA: +5° / +45° TENSION DE ALIMENTATION: BATERIA 9V DURACION DE LA BATERIA: 6 MESES FRECUENCIA DE TRABAJO: 433,92 - 868 MHZ DISTANCIA DE FUNC…

Text truncated - open the document above for the full version.

Cod. Fisc./Part. IVA 01681620603 Codice CEE: ITO 1681620603 Cap. Soc. € 49.920,00 int. v ers. C.C.I.A.A. 94541 Reg. Soc. N. 61 20/89 Trib. FR Pos. Comm. Estero FR 002034 Via Anticolana Km 0.300 03012 ANAGNI (FR) Tel. 0775 77681 Fax 0775 774018 www.openitaly.com [email protected] VT2USA BLOCK DIAGRAM

1 2710 15 Narrow Bandwidth Super Regenerative Radio Receiver - Laser Trimmed Inductor RR10-XXX The RR10-XXX is a super regenerative data receiver. Sensitivity typically exceedes -100dBm (2.2uVrms) when matched to 50 ohm. Narrow Bandwidth: -3dB+/-1.5MHz -30dB+/- 5MHz -50dB+/- 7MHz The frequency accuracy is very high thanks to laser trimming process. PATENTED. General description Applications CHARACTERISTICSMINTYPMAX UNIT Electrical Characteristics V RF V AF V ol V oh I S In BLOCK DIAGRAM TYPICAL APPLICATION Mechanical Dimensions Pin Description 1RF +V9NC 2RF GND10AF +V 3IN11AF GND 4NC12AF +V 5NC13Test Point 6NC14OUT 7RF GND15AF +V 8NC CC CC CC CC RF Supply Voltage AF Supply Voltage Supply Current F W B W T OP Working Frequency Tuning Tolerance -3dB Bandwidth RF Sensitivity (100% AM) Level of Emitted Spectrum Low-Level Output Voltage High-Level Output Voltage Max Data Rate Operating Temperature Range XXX:custom-specified working frequency (200 ÷ 450 MHz) Standard European and U.S. frequencies (315MHz, 418MHz, 433.92MHz) are readly available from stock. · · · · Home security systems Car Alarm systems Remote gate controls Sensor reporting 4.5 4.5 200450 3.6 0.6 -65-60 5.5 5.5 5 5 1.5 VDC VDC V V 1.2 +/-0.2+/-0.5 +/-1.5+/-2 4.8 -100-102 mA dBm dBm MHz MHz MHz Kbit/s -25+80°C Radio Receiver LP Filter Quench Oscillator Comparator OUT GND RFAF Point AF V RF V AF GND Test GND DECODER IN OUT +5V AERIAL Pre-AmpOscillator RFRF AM Ampli I-ETS 300-220 Compliance 38.1mm 12.7mm 2.54mm 1 2710 15 Components Side 1mm RR10-XXX Ta = 25°C unless otherwise specified Telecontrolli Srl has an on going policy to improve the performance and reliability of their products; we therefore reserve the right to make changes without notice. The information contained in our data sheets is believed to be accurate, however we do not assume any liability arising from the application or use of any product or circuit. SALES OFFICE sales @ telecontrolli.com HEAD OFFICE & PLANT Via Nazionale delle Puglie, 177 80026 CASORIA (NA), Italy Tel: +39 081 7599033 Fax: +39 081 7596494 Web Site: www.telecontrolli.com 1 2710 15 Narrow Bandwidth Super Regenerative Radio Receiver - Laser Trimmed Inductor RR10-XXX The RR10-XXX is a super regenerative data receiver. Sensitivity typically exceedes -100dBm (2.2uVrms) when matched to 50 ohm. Narrow Bandwidth: -3dB+/-1.5MHz -30dB+/- 5MHz -50dB+/- 7MHz The frequency accuracy is very high thanks to laser trimming process. PATENTED. General description Applications CHARACTERISTICSMINTYPMAX UNIT Electrical Characteristics V RF V AF V ol V oh I S In BLOCK DIAGRAM TYPICAL APPLICATION Mechanical Dimensions Pin Description 1RF +V9NC 2RF GND10AF +V 3IN11AF GND 4NC12AF +V 5NC13Test Point 6NC14OUT 7RF GND15AF +V 8NC CC CC CC CC RF Supply Voltage AF Supply Voltage Supply Current F W B W T OP Working Frequency Tuning Tolerance -3dB Bandwidth RF Sensitivity (100% AM) Level of Emitted Spectrum Low-Level Output Voltage High-Level Output Voltage Max Data Rate Operating Temperature Range XXX:custom-specified working frequency (200 ÷ 450 MHz) Standard European and U.S. frequencies (315MHz, 418MHz, 433.92MHz) are readly available from stock. · · · · Home security systems Car Alarm systems Remote gate controls Sensor reporting 4.5 4.5 200450 3.6 0.6 -65-60 5.5 5.5 5 5 1.5 VDC VDC V V 1.2 +/-0.2+/-0.5 +/-1.5+/-2 4.8 -100-102 mA dBm dBm MHz MHz MHz Kbit/s -25+80°C Radio Receiver LP Filter Quench Oscillator Comparator OUT GND RFAF Point AF V RF V AF GND Test GND DECODER IN OUT +5V AERIAL Pre-AmpOscillator RFRF AM Ampli I-ETS 300-220 Compliance 38.1mm 12.7mm 2.54mm 1 2710 15 Components Side 1mm RR10-XXX Ta = 25°C unless otherwise specified Telecontrolli Srl has an on going policy to improve the performance and reliability of their products; we therefore reserve the right to make changes without notice. The information contained in our data sheets is believed to be accurate, however we do not assume any liability arising from the application or use of any product or circuit. SALES OFFICE sales @ telecontrolli.com HEAD OFFICE & PLANT Via Nazionale delle Puglie, 177 80026 CASORIA (NA), Italy Tel: +39 081 7599033 Fax: +39 081 7596494 Web Site: www.telecontrolli.com

Pag. 1/3 Cod. Fisc./Part. IVA 01681620603 Codice CEE: ITO 1681620603 Cap. Soc. € 49.920,00 int. vers. C.C.I.A.A. 94541 Reg. Soc. N. 6120/89 Trib. FR Pos. Comm. Estero FR 002034 Via Anticolana Km 0.300 03012 ANAGNI (FR) Tel. 0775 77681 Fax 0775 774018 www.openitaly.com [email protected] VT2USA

Pag. 2/3 Cod. Fisc./Part. IVA 01681620603 Codice CEE: ITO 1681620603 Cap. Soc. € 49.920,00 int. vers. C.C.I.A.A. 94541 Reg. Soc. N. 6120/89 Trib. FR Pos. Comm. Estero FR 002034 Via Anticolana Km 0.300 03012 ANAGNI (FR) Tel. 0775 77681 Fax 0775 774018 www.openitaly.com [email protected] TRANSMITTER Pag. 3/3 Cod. Fisc./Part. IVA 01681620603 Codice CEE: ITO 1681620603 Cap. Soc. € 49.920,00 int. vers. C.C.I.A.A. 94541 Reg. Soc. N. 6120/89 Trib. FR Pos. Comm. Estero FR 002034 Via Anticolana Km 0.300 03012 ANAGNI (FR) Tel. 0775 77681 Fax 0775 774018 www.openitaly.com [email protected] TRANSMITTER

Cod. Fisc./Part. IVA 01681620603 Codice CEE: ITO 1681620603 Cap. Soc. € 49.920,00 int. v ers. C.C.I.A.A. 94541 Reg. Soc. N. 6120/89 Trib. FR Pos. Comm. Estero FR 002034 Via Anticolana Km 0.300 03012 ANAGNI (FR) Tel. 0775 77681 Fax 0775 774018 www.openitaly.com [email protected] VT2 – Operating description The VT2 is an RF control device with a 2 digit LCD, used for remotely controlling the VD1 queue system display. The main function of the VT2 is to turn feed the numbers displayed by VD1 onto a local LCD display. For this purpose, the VT2 has a receiving module and a transmitting module which operate in the ISM 433.92 MHz band. In addition, the VT2 performs the following functions:
Queue number repetition
Queue number reset
Queue number decrease
Brightness intensity and beeper volume regulation
Vocal device volume regulation, VOICE model.
Audio message, reproduced by the VOICE, selection
MUTE setting of the VOICE
System code setting, with 8 valid numbers (1...8) VT2 remote control has three front buttons, that are used more frequently. The three front buttons allow:
Central button: turn feed; fast feed by applying continuous pressure (2 secs); VT2 turning ON.
Upper button: turn number repetition; display turning OFF by applying continuous pressure (2 sec)
Lower button: turn number reset by long pressure (2 secs) The less frequently used settings are made by the back keyboard which can be located by removing the cover. Apart from the above specific functions, the three front buttons control the turning ON of VT2, with a timeout of at least 30 secs (the 30 secs timeout is reloaded whenever you press a button). Cod. Fisc./Part. IVA 01681620603 Codice CEE: ITO 1681620603 Cap. Soc. € 49.920,00 int. v ers. C.C.I.A.A. 94541 Reg. Soc. N. 6120/89 Trib. FR Pos. Comm. Estero FR 002034 Via Anticolana Km 0.300 03012 ANAGNI (FR) Tel. 0775 77681 Fax 0775 774018 www.openitaly.com [email protected] Immediately after the turning on, the VT2 does not display the queue number but shows two hyphens, “—“ and transmit a command to the VD1 display with a dual purpose to increase the queue number (or reset or repeat the queue number) and receive current feedback from VD1. After receiving the VD1 state, the VT2 displays the valid queue number. VT2 – Block diagram The VT2 device has the following blocks (see drawing PN007.061.1) 1. CPU 2. 3x4 Keyboard Matrix 3. LCD display 4. Power control 5. 433MHz Receiver 6. 433MHz OOK Transmitter 1. CPU All the functions of VT2 are controlled by a 1MHz “single chip” CPU. 2. 3x4 Keyboard Matrix The keyboard is designed as a one 3x4 matrix, but due to the ergonomics of the product it is divided into a more frequently used front part with three buttons, and a back part with 9 buttons. 3. LCD Display The display is a TN (Twisted Nematic) type with static polarization which guarantees a wide angle of vision and a good contrast. 4. Power control The power supply circuit performs the following functions: • turning ON, activated by front buttons controlled by the CPU • security against accidental inversion of the battery Cod. Fisc./Part. IVA 01681620603 Codice CEE: ITO 1681620603 Cap. Soc. € 49.920,00 int. v ers. C.C.I.A.A. 94541 Reg. Soc. N. 6120/89 Trib. FR Pos. Comm. Estero FR 002034 Via Anticolana Km 0.300 03012 ANAGNI (FR) Tel. 0775 77681 Fax 0775 774018 www.openitaly.com [email protected] • power supply set at 5V • low current for stand-by mode • gate to measure the battery voltage, enabled by the CPU 5. 433MHz Receiver The data reception is performed by the RR10-433 module, a 433.92 MHz super-generative receiver (see enclosed data sheet). The data decoding is performed by the CPU. 6. 433MHz OOK Transmitter The data transmission is performed by a two-stage Colpitts oscillator, controlled by a 433.92MHz SAW resonator. ON-OFF Keying modulation is applied. The data encoding is performed by the CPU.

TEST REPORT RP010811 EMC test for FCC Certification procedure on remote controller VT2 Tecnolab del Lago Maggiore S.r.l. ISTITUTO DI PROVE, MISURE E RICERCHE, ING. MICHELE SETARO Via dell’Industria, 20 28924 Verbania Fondotoce (VB)–Italy 2011/05/19Page2di23 Table of contentsPage.n. 1.GENERAL REMARKS3 1.1Customer data3 1.2Identification of equipment and/or subsystem under test (EUT)3 1.3Identification of auxiliary equipment not under test (AE)3 1.4Identification of connecting cables3 1.5Sampling3 2.SCOPE3 3.APPLICABLE DOCUMENTS3 3.1Applicability3 3.2Definitions and glossary of terms4 3.3Other definitions and abbreviations4 4.EUT FUNCTIONAL DESCRIPTION4 4.1EUT description and operating method during tests4 4.2Test set-up and EUT configuration4 5.TECHNICAL COMPETENCE4 6.TEST PERFORMED5 6.1General5 6.1.1Test firm identification5 6.1.2List and description of tests5 6.1.3Uncertainty of measurement5 6.2Radiated Emission measurements6 6.3Occupied bandwidth7 7.ANNEXES8 TEST REPORT RP010811 EMC test for FCC Certification procedure on remote controller VT2 Tecnolab del Lago Maggiore S.r.l. ISTITUTO DI PROVE, MISURE E RICERCHE, ING. MICHELE SETARO Via dell’Industria, 20 28924 Verbania Fondotoce (VB)–Italy 2011/05/19Page3di23 1.GENERALREMARKS 1.1Customer data Customer: Open Data s.r.l. Address:Via Anticolana km 0,300 03012 Anagni (FR) Italy 1.2Identification of equipment and/or subsystem under test (EUT) EUT (equipment or subsystem) n°:1 Mark: Open Data Model:VT2 FCC IDZMNVT2USA Acceptance code:AC017711/3 Receiving date:2011/03/21 Description:The VT2 is an RF control device with a 2 digit LCD, used for remotely controlling the VD1 queue system display.See annex 1,2 and 3 of this test report. 1.3Identification of auxiliary equipment not under test (AE) EUTdoes notrequireauxiliary equipmentfor itsoperation. 1.4Identification of connecting cables EUTdoes nothave any cablefor itsoperation. EUT is powered by a 9V battery. 1.5Sampling The results shown in this Technical Report exclusively refer to the sample under test, taken away from the production by Customer. Extension of test results to the whole production is the responsibility of manufacturer/importer. 2.SCOPE Scope of the test and the measurement is to supply the Customer with useful indications in order to evaluate EUT compliance with Electromagnetic Compatibility Reference Standards; the performed test plan is required from the manufacturer. 3.APPLICABLE DOCUMENTS FCC RulesFCC Rules : Code of Federal Regulations (CFR) no. 47 Ch1 (10-1-09 Edition) PART 15-RADIO FREQUENCY DEVICES 3.1Applicability Applicablepartiesregardingthecertificationprocedureforintentionalradiator operating at frequency 433,9 MHz. According to the definition 15.3 (o)EUT is an Intentional Radiator with periodic operation at frequency 433,9 MHz so it shall fulfil provisions of 47CFR part 15 Subpart C–intentional radiators–and section 15.231.Section 15.231 is applicable because EUT is a manually operated transmitter who employ a switch that will automatically deactivate the transmitter within not more than 5 seconds after activation. TEST REPORT RP010811 EMC test for FCC Certification procedure on remote controller VT2 Tecnolab del Lago Maggiore S.r.l. ISTITUTO DI PROVE, MISURE E RICERCHE, ING. MICHELE SETARO Via dell’Industria, 20 28924 Verbania Fondotoce (VB)–Italy 2011/05/19Page4di23 3.2Definitions and glossary of terms Applicable IEC 50 IEV Standard definitions. AEAuxiliary Equipment CEConducted Emission EMCElectromagnetic Compatibility EUTEquipment Under Test RERadiated Emission 3.3Other definitions and abbreviations GRPGround reference plane BHBiconical antenna in horizontal polarization BVBiconical antenna in vertical polarization LHLog-periodic antenna in horizontal polarization LVLog-periodic antenna in vertical polarization HH Hornantenna in horizontal polarization HV Hornantenna in vertical polarization Loop F Loop antenna in frontal position Loop L Loop antenna in lateral position PassIn compliance with reference Standard Fail Not in compliance with reference Standard 4.EUT FUNCTIONAL DESCRIPTION 4.1EUT description and operating method during tests The VT2 is an RF control device with a 2 digit LCD, used for remotely controlling the VD1 queue system display. The main function of the VT2 is to turn feed the numbers displayed by VD1 onto a local LCD display. For this purpose, the VT2 has a receiving module and a transmitting module which operate in the ISM 433.92 MHz band. Thedevicewas testedby moving forwardin a progressive mannerthenumbers. 4.2Test set-up and EUT configuration EUT is poweredby a 9V battery. 5.TECHNICAL COMPETENCE Technicians qualified for the execution of the tests areengineers with at least three months of experience in Measurements and Testing. TEST REPORT RP010811 EMC test for FCC Certification procedure on remote controller VT2 Tecnolab del Lago Maggiore S.r.l. ISTITUTO DI PROVE, MISURE E RICERCHE, ING. MICHELE SETARO Via dell’Industria, 20 28924 Verbania Fondotoce (VB)–Italy 2011/05/19Page5di23 6.TEST PERFORMED 6.1General 6.1.1Test firm identification Tests were performed at laboratory: Tecnolab del Lago Maggiore S.r.l., Via dell’Industria 20, 28924 Verbania Fondotoce (VB) ITALY. REGISTRATION NUMBER:868554 6.1.2List and description of tests TestApplicable Standard PortParagraph of this test report Result Antenna requirement 47 CFR 15.203 /15.204 / /Use ofpermanently attached antenna shall be considered sufficient to comply the provisions of this section. Radiated emissions measurements 47 CFR 15.205 47 CFR 15.209 47 CFR 15.231 (b) Enclosure port6.2Pass Occupied bandwidth for device operating over 70 MHz and under 900 MHz 47 CFR 15.231 (c)Enclosure port6.3Pass 6.1.3Uncertainty of measurement The uncertainty of measurement stated in this document are expressed as expanded uncertainty obtained by multiplying the standard uncertainty by the coverage factor K = 2correspondingto a confidence level of about 95%. TEST REPORT RP010811 EMC test for FCC Cer…

Text truncated - open the document above for the full version.

Duration of busts from one button push. Less than 5 seconds.

Annex 4 of 15 of Test report n° RP010711 of 2011/05/19 Tecnolab del Lago Maggiore s.r.l 30-216 MHz 216-1000 MHz 1000-5000 MHz
