ZMOMC116NALTE Wireless Module

FIBOCOM MC116-NA Hardware Guide Version: V1.0.0 Date: 2020-09-07 Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. FIBOCOM MC116-NA Series Hardware Guide Page 2 of 63 Applicability Type No. Product Model Description 1 MC116-NA MCP is 1+1, and supports MAIN_ANT, DIV_ANT, GNSS_ANT Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. FIBOCOM MC116-NA Series Hardware Guide Page 3 of 63 Copyright Copyright ©2020 Fibocom Wireless Inc. All rights reserved. Without the prior written permission of the copyright holder, any company or individual is prohibited to excerpt, copy any part of or the entire document, or transmit the document in any form. Notice The document is subject to update from time to time owing to the product version upgrade or other reasons. Unless otherwise specified, the document only serves as the user guide. All the statements, information and suggestions contained in the document do not constitute any explicit or implicit guarantee. Trademark The trademark is registered and owned by Fibocom Wireless Inc. Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. FIBOCOM MC116-NA Series Hardware Guide Page 4 of 63 Change History Version Author Reviewer Approver Update Date Description V1.0.0 Li Du Hu Wenkai Liu Ke 2020-09-07 Initial version Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. FIBOCOM MC116-NA Series Hardware Guide Page 5 of 63 Contents Contents ............................................................................................................................... 5 1 Introduction ....................................................................................................................... 8 1.1 Document Introduction ......................................................................................................... 8 1.2 Safety Precautions ............................................................................................................... 8 2 Product Overview ........................................................................................................... 10 2.1 Product Introduction ........................................................................................................... 10 2.2 Product Specification ......................................................................................................... 10 2.3 Functional Diagram ............................................................................................................ 11 2.4 Evaluation Board ................................................................................................................ 12 3 Pin Description ............................................................................................................... 13 3.1 Pin Assignment .................................................................................................................. 13 3.2 Pin Function ....................................................................................................................... 14 4 Electrical Characteristics ............................................................................................... 21 4.1 Power ................................................................................................................................. 21 4.2 Power Supply ..................................................................................................................... 21 4.3 1.8V Output ........................................................................................................................ 22 4.4 Power Consumption ........................................................................................................... 23 5 Functional Interfaces...................................................................................................... 25 5.1 Control Interfaces ............................................................................................................... 25 5.1.1 Power On/Off ...................................................................................................................... 25 5.1.1.1 Power On ....................................................................................................................................... 25 5.1.1.2 Power Off ....................................................................................................................................... 27 5.1.2 RESET ................................................................................................................................ 27 5.2 Network Status Indicator Interface ..................................................................................... 29 5.2.1 Interface Status Description ............................................................................................... 29 5.3 (U)SIM Card Interface ........................................................................................................ 30 5.3.1 (U)SIM Pin Definition .......................................................................................................... 30 5.3.2 (U)SIM Interface Circuit ...................................................................................................... 31 5.3.2.1 (U)SIM Card Connector with Card Detection Signal....................................................................... 31 5.3.2.2 (U)SIM Card Connector Without Detection Signal.......................................................................... 32 5.3.3 (U)SIM Hot Plug ................................................................................................................. 32 5.3.4 (U)SIM Design Requirements ............................................................................................ 33 Reproduction forbidden without Fibocom Wireless Inc. wri…

Text truncated - open the document above for the full version.

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. FIBOCOM MC116-NA Series Hardware Guide Page 58 of 63 transmission and reception (TDD)  3GPP TS 36.521-1 V10.6.0: User Equipment (UE) conformance specification; Radio transmission and reception; Part 1: Conformance testing  3GPP TS 21.111 V10.0.0: USIM and IC card requirements  3GPP TS 51.011 V4.15.0: Specification of the Subscriber Identity Module -Mobile Equipment (SIM-ME) interface  3GPP TS 31.102 V10.11.0: Characteristics of the Universal Subscriber Identity Module (USIM) application  3GPP TS 31.11 V10.16.0: Universal Subscriber Identity Module (USIM) Application Toolkit (USAT)  3GPP TS 36.124 V10.3.0: Electro Magnetic Compatibility (EMC) requirements for mobile terminals and ancillary equipment  3GPP TS 27.007 V10.0.8: AT command set for User Equipment (UE)  3GPP TS 27.005 V10.0.1: Use of Data Terminal Equipment - Data Circuit terminating Equipment (DTE - DCE) interface for Short Message Service (SMS) and Cell Broadcast Service (CBS) 11.4 Contact URL：http://www.fibocom.com.cn/ HQ Address：5 F Shekou Science and Technology Building, Nanhai Ave 1057, Shenzhen, Guangdong P.R.China TEL：+86 755-26733555 Fax：+86 755-26520841 12 Warnning Important Notice to OEM integrators 1. This module is limited to OEM installation ONLY. 2. This module is limited to installation in mobile or fixed applications, according to Part 2.1091(b). 3. The separate approval is required for all other operating configurations, including portable configurations with respect to Part 2.1093 and different antenna configurations 4. For FCC Part 15.31 (h) and (k): The host manufacturer is responsible for additional testing to verify compliance as a composite system. When testing the host device for compliance with Part 15 Subpart B, the host manufacturer is required to show compliance with Part 15 Subpart B while the transmitter module(s) are installed and operating. The modules should be transmitting and the evaluation should confirm that the module's intentional emissions are compliant (i.e. fundamental and out of band emissions). The host manufacturer must verify that there are no additional unintentional emissions other Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. FIBOCOM MC116-NA Series Hardware Guide Page 59 of 63 than what is permitted in Part 15 Subpart B or emissions are complaint with the transmitter(s) rule(s). The Grantee will provide guidance to the host manufacturer for Part 15 B requirements if needed. Important Note notice that any deviation(s) from the defined parameters of the antenna trace, as described by the instructions, require that the host product manufacturer must notify to Fibocom that they wish to change the antenna trace design. In this case, a Class II permissive change application is required to be filed by the USI, or the host manufacturer can take responsibility through the change in FCC ID (new application) procedure followed by a Class II permissive change application. End Product Labeling When the module is installed in the host device, the FCC/IC ID label must be visible through a window on the final device or it must be visible when an access panel, door or cover is easily re-moved. If not, a second label must be placed on the outside of the final device that contains the following text: “Contains FCC ID: ZMOMC116NA” “Contains IC: 21374-MC116NA “ The FCC ID/IC ID can be used only when all FCC/IC compliance requirements are met. Antenna Installation (1) The antenna must be installed such that 20 cm is maintained between the antenna and users, (2) The transmitter module may not be co-located with any other transmitter or antenna. (3) Only antennas of the same type and with equal or less gains as shown below may be used with this module. Other types of antennas and/or higher gain antennas may require additional authorization for operation. Antenna type LTE B2 LTE B4 LTE B5 LTE B12 LTE B13 LTE B17 LTE B66 External 1.0 dBi 1.3 dBi -1.3 dBi -1.1 dBi -0.8 dBi -1.1 dBi 0.7 dBi In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another transmitter), then the FCC/IC authorization is no longer considered valid and the FCC ID/IC ID cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC/IC authorization. Manual Information to the End User Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. FIBOCOM MC116-NA Series Hardware Guide Page 60 of 63 The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module. The end user manual shall include all required regulatory information/warning as show in this manual. Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by tu…

Text truncated - open the document above for the full version.

Rev. 1/1/03 Fibocom Wireless Inc. 1101,Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Nanshan,Shenzhen,China Tel: +8675526733555 ; Fax: +86-755-26520841 Date: November 16, 2020 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: ZMOMC116NA Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Schematics Block Diagram Parts List Operation Description Tune up Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ________________________ Lucy Liu

Fibocom Wireless Inc. 1101,Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Nanshan,Shenzhen,China Tel: +8675526733555 ; Fax: +86-755-26520841 Date: November 16, 2020 Power of Attorney To whom it may concern, Please be notified that I, Lucy Liu, have designated Jim Tsai in Sporton International Inc. as the person being responsible for this project and to sign the form 731 and other documentation. Any and all acts carried out by Jim Tsai in Sporton International Inc., on the matters of relating to all processes required in the FCC approval and any communication needed with the national authority, shall have the same legal authority as acts on our own behalf. We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002 (b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C 862. This authorization is limited to the product of as following: FCC ID: ZMOMC116NA If you have any acknowledgement and response, please send it to Sporton International Inc. directly. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely yours, ____ Contact Person: Lucy Liu E-mail: [email protected]

1/1 Fibocom Wireless Inc. 1101,Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Nanshan,Shenzhen,China Tel: +8675526733555 ; Fax: +86-755-26520841 Date: November 16, 2020 Federal Communications Commission Authorization and Evaluation Division RE : Certification Application FCC ID : ZMOMC116NA To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, Public Notice DA 04-1705 of the Commission’s policy and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 180 days:  External Photos  Internal Photos  Test set-up photos  Users Manual The application contains technical information, which Fibocom Wireless Inc. deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, ____ Contact Person: Lucy Liu E-mail: [email protected]

Applicant/Grantee Fibocom Wireless Inc. /ZMO FCC ID: ZMOMC116NA Section 15.212 Modular Transmitters Request for Modular Approval Request for Limited Modular Approval Requirements EUT Conditions Comply (Y/N) Single Modular Approval Requirements 1 The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. The radio portion of this module is shielded, please see exhibition external photos. Y 2 The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. The module has buffer modulation/data inputs. Y 3 The modular transmitter must have its own power supply regulation. The module has its own power supply regulation. Please see the schem.pdf Y 4 The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. The requirements of antenna connector and spurious emission have been fulfilled. Please refer to the Test Report exhibition. Y 5 The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with Part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting Please refer to the Setup Photo exhibition for the stand-alone test configuration. Y equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see Section 15.31(i)). 6 The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. (A) If using a permanently affixed label, the modular transmitter must be labeled with its own FCC identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. (B) If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronic display. A copy of these instructions must be included in the application for equipment authorization. The Module will be labeled with its own FCC ID, and the instruction on the labeling rule of the end product has been stated in the User Manual of this module. Please refer to the Label and User Manual exhibition. Y 7 The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. The required FCC rule has been fulfilled and all the instructions for maintaining compliance have been clearly stated in the User Manual. Y 8 The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. Please refer exhibition RF Exposure for the compliance of MPE RF exposure rule. Y _________________________________ Contact Person: Lucy Liu E-mail: [email protected]

Photographs of EUT Report No.: EP0O3026 Brand Name: Fibocom / Model Name: MC116-NA Sporton International (KunShan) Inc. Page Number : 1 of 8 TEL : 86-0512-5790-0158 Report Issued Date : Dec. 17, 2020 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : ZMOMC116NA 1. External Photograph of EUT Photographs of EUT Report No.: EP0O3026 Brand Name: Fibocom / Model Name: MC116-NA Sporton International (KunShan) Inc. Page Number : 2 of 8 TEL : 86-0512-5790-0158 Report Issued Date : Dec. 17, 2020 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : ZMOMC116NA Photographs of EUT Report No.: EP0O3026 Brand Name: Fibocom / Model Name: MC116-NA Sporton International (KunShan) Inc. Page Number : 3 of 8 TEL : 86-0512-5790-0158 Report Issued Date : Dec. 17, 2020 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : ZMOMC116NA 2. Test Jig and Antenna Module Test Jig Photographs of EUT Report No.: EP0O3026 Brand Name: Fibocom / Model Name: MC116-NA Sporton International (KunShan) Inc. Page Number : 4 of 8 TEL : 86-0512-5790-0158 Report Issued Date : Dec. 17, 2020 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : ZMOMC116NA Photographs of EUT Report No.: EP0O3026 Brand Name: Fibocom / Model Name: MC116-NA Sporton International (KunShan) Inc. Page Number : 5 of 8 TEL : 86-0512-5790-0158 Report Issued Date : Dec. 17, 2020 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : ZMOMC116NA WWAN and GNSS Antenna

Photographs of EUT Report No.: EP0O3026 Brand Name: Fibocom / Model Name: MC116-NA Sporton International (KunShan) Inc. Page Number : 6 of 8 TEL : 86-0512-5790-0158 Report Issued Date : Dec. 17, 2020 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : ZMOMC116NA 3. Internal Photograph of EUT Photographs of EUT Report No.: EP0O3026 Brand Name: Fibocom / Model Name: MC116-NA Sporton International (KunShan) Inc. Page Number : 7 of 8 TEL : 86-0512-5790-0158 Report Issued Date : Dec. 17, 2020 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : ZMOMC116NA Photographs of EUT Report No.: EP0O3026 Brand Name: Fibocom / Model Name: MC116-NA Sporton International (KunShan) Inc. Page Number : 8 of 8 TEL : 86-0512-5790-0158 Report Issued Date : Dec. 17, 2020 FAX : 86-0512-5790-0958 Report Version : Rev. 01 FCC ID : ZMOMC116NA

Sporton International (Kunshan) Inc. Page Number : 1 of 10 TEL : +86-512-57900158 Report Issued Date : Dec. 16, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : ZMOMC116NA RF Exposure Evaluation Report Report No. : FA0O3026 RF Exposure Evaluation Report APPLICANT : Fibocom Wireless Inc. EQUIPMENT : LTE Wireless Module BRAND NAME : Fibocom MODEL NAME : MC116-NA FCC ID : ZMOMC116NA STANDARD : 47 CFR Part 2.1091 FCC KDB 447498 D01 v06 We, Sporton International (Kunshan) Inc., would like to declare that the device has been evaluated in accordance with 47 CFR Part 2.1091 and FCC KDB 447498 D01 v06, and pass the limit. Without written approval of Sporton International (Kunshan) Inc., the test report shall not be reproduced except in full. Reviewed by: Rose Wang / Supervisor Approved by: Kat Yin / Manager Sporton International (Kunshan) Inc. No. 1098, Pengxi North Road, Kunshan Economic Development Zone Jiangsu Province 215300 People’s Republic of China Sporton International (Kunshan) Inc. Page Number : 2 of 10 TEL : +86-512-57900158 Report Issued Date : Dec. 16, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : ZMOMC116NA RF Exposure Evaluation Report Report No. : FA0O3026 Table of Contents 1. ADMINISTRATION DATA ........................................................................................................................... 4 1.1. Testing Laboratory ............................................................................................................................. 4 2. DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) ............................................................................. 5 3. MAXIMUM RF AVERAGE OUTPUT TUNE UP POWER AMONG PRODUCTION UNITS ....................... 6 4. RF EXPOSURE LIMIT INTRODUCTION .................................................................................................... 7 5. RADIO FREQUENCY RADIATION EXPOSURE EVALUATION ............................................................... 8 5.1. Standalone Power Density Calculation ............................................................................................. 8 5.2. Collocated Power Density Calculation ............................................................................................... 8 Sporton International (Kunshan) Inc. Page Number : 3 of 10 TEL : +86-512-57900158 Report Issued Date : Dec. 16, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : ZMOMC116NA RF Exposure Evaluation Report Report No. : FA0O3026 Revision History REPORT NO. VERSION DESCRIPTION ISSUED DATE FA0O3026 Rev. 01 Initial issue of report. Dec. 16, 2020 Sporton International (Kunshan) Inc. Page Number : 4 of 10 TEL : +86-512-57900158 Report Issued Date : Dec. 16, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : ZMOMC116NA RF Exposure Evaluation Report Report No. : FA0O3026 1. Administration Data 1.1. Testing Laboratory Sporton International (Kunshan) Inc. is accredited to ISO/IEC 17025:2017 by American Association for Laboratory Accreditation with Certificate Number 5145.02. Testing Laboratory Test Firm Sporton International (Kunshan) Inc. Test Site Location No. 1098, Pengxi North Road, Kunshan Economic Development Zone Jiangsu Province 215300 People’s Republic of China TEL : +86-512-57900158 FAX : +86-512-57900958 Test Site No. FCC Designation No. FCC Test Firm Registration No. CN1257 314309 Applicant Company Name Fibocom Wireless Inc. Address 1101,Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Nanshan,Shenzhen,China Manufacturer Company Name Fibocom Wireless Inc. Address 1101,Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Nanshan,Shenzhen,China Sporton International (Kunshan) Inc. Page Number : 5 of 10 TEL : +86-512-57900158 Report Issued Date : Dec. 16, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : ZMOMC116NA RF Exposure Evaluation Report Report No. : FA0O3026 2. Description of Equipment Under Test (EUT) Product Feature & Specification EUT Type LTE Wireless Module Brand Name Fibocom Model Name MC116-NA FCC ID ZMOMC116NA Wireless Technology and Frequency Range LTE Band 2: 1850.7 MHz ~ 1909.3 MHz LTE Band 4: 1710.7 MHz ~ 1754.3 MHz LTE Band 5: 824.7 MHz ~ 848.3 MHz LTE Band 12: 699.7 MHz ~ 715.3 MHz LTE Band 13: 779.5 MHz ~ 784.5 MHz LTE Band 17: 706.5 MHz ~ 713.5 MHz LTE Band 66: 1710.7 MHz ~ 1779.3 MHz Mode LTE: QPSK, 16QAM, 64QAM (downlink only) HW Version V1.0.0 SW Version 19001.1000.00.02.20.03 EUT Stage Identical Prototype Remark: 1. The above EUT's information was declared by manufacturer. Please refer to the specifications or user's manual for more detailed description. Comments and Explanations: 1. The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. 2. The maximum RF output tune up power, antenna gain also the safe distance used for evaluate RF exposure were declared by manufacturer. Sporton International (Kunshan) Inc. Page Number : 6 of 10 TEL : +86-512-57900158 Report Issued Date : Dec. 16, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : ZMOMC116NA RF Exposure Evaluation Report Report No. : FA0O3026 3. Maximum RF average output tune up power among production units <LTE> Mode Maximum Average power(dBm) LTE Band 2 25.00 Band 4 25.00 Band 5 25.00 Band 12 25.00 Band 13 25.00 Band 17 25.00 Band 66 25.00 Sporton International (Kunshan) Inc. Page Number : 7 of 10 TEL : +86-512-57900158 Report Issued Date : Dec. 16, 2020 FAX : +86-512-57900958 Report Version : Rev. 01 FCC ID : ZMOMC116NA RF Exposure Evaluation Report Report No. : FA0O3026 4. RF Exposure Limit Introduction According to ANSI/IEEE C95.1-1992, the criteria listed in Table 1 shall be used to evaluate the environmental impact of human exposure to radio frequency (RF) radiation as specified in §1.1310. The MPE was calculated at 20 cm to show compli…
