ZMONL668LA01NB-IoT Module

Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. FIBOCOM NL668-LA-01 Hardware User Manua Page 1 of 60 69100.1000.00.02.61.34_DEMO" NL668- LA-01 Hardware User Manual 文档版本：V1.0.0 更新日期：2017.12.24 Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. FIBOCOM NL668-LA-01 Hardware User Manua Page 2 of 60 Applicability type No. Product model Description 1 NL668-LA-01 MCP is 4+2，support MAIN_ANT, DIV_ANT Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. FIBOCOM NL668-LA-01 Hardware User Manua Page 3 of 60 Copyright Copyright ©2019 Fibocom Wireless Inc. All rights reserved. Without the prior written permission of the copyright holder, any company or individual is prohibited to excerpt, copy any part of or the entire document, or transmit the document in any form. Notice The document is subject to update from time to time owing to the product version upgrade or other reasons. Unless otherwise specified, the document only serves as the user guide. All the statements, information and suggestions contained in the document do not constitute any explicit or implicit guarantee. Trademark The trademark is registered and owned by Fibocom Wireless Inc. Versions Version Author Assessor Approver Update Date Description V1.0.0 Gaoying Tumin Chenguojiang 2019-06-06 Initial version V1.0.1 Liuqiang Lixiyi Chenguojiang 2019-07-09 Update RF parameters V1.0.2 Tan Lefan Hu Wenkai Luke Liu 2019-10-09 Modify module size. Increase the requirements of boot_config1, 2, 3 pins forbidden to pull up externally. V1.0.3 Lee Du Hu Wenkai Luke Liu 2020-01-10 Add model NL668-LA-01 V1.0.4 Hu Wenkai Lee Du Luke Liu 2020-03-13 update Power consumption Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. FIBOCOM NL668-LA-01 Hardware User Manua Page 4 of 60 Content Figure Index ........................................................................................................................ 7 Table Index .......................................................................................................................... 8 1 Introduction ................................................................................................................ 12 1.1 Document Introduction................................................................................................ 12 1.2 Safety precautions ...................................................................................................... 12 2 Product Overview ....................................................................................................... 14 2.1 Product Introduction ................................................................................................... 14 2.2 Product Specification .................................................................................................. 14 2.3 Functional Diagram .................................................................................................... 15 2.4 Evaluation Board ........................................................................................................ 16 3 Pin Description ........................................................................................................... 17 3.1 Pin Assignment ........................................................................................................... 17 3.2 Pin function ................................................................................................................. 17 4 Electrical characteristics ........................................................................................... 24 4.1 Power ......................................................................................................................... 24 4.2 Power supply .............................................................................................................. 24 4.3 1.8V output ................................................................................................................. 25 4.4 Power consumption .................................................................................................... 25 5 Functional interface ................................................................................................... 28 5.1 Control interface ......................................................................................................... 28 5.1.1 Power on/off .................................................................................................................. 28 5.1.2 RESET .......................................................................................................................... 30 5.2 Network status indicate interface ................................................................................ 32 5.2.1 Interface status description ........................................................................................... 32 5.3 (U)SIM card interface ................................................................................................. 33 5.3.1 (U)SIM pin definition...................................................................................................... 33 5.3.2 (U)SIM interface circuit ................................................................................................. 34 5.3.3 (U)SIM hot plug ............................................................................................................. 35 5.3.4 (U)SIM design requirements ......................................................................................... 36 5.4 USB interface ............................................................................................................. 37 5.4.1 USB Pin definition ......................................................................................................... 37 5.5 UART Interface ......…

Text truncated - open the document above for the full version.

Fibocom Wireless Inc. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: ZMONL668LA01 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name ⚫ Schematic Diagram ⚫ Block Diagram ⚫ Parts List ⚫ Operational Description Schematic Diagram Block Diagram Parts List Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name ◆ External Photos ◆ Internal Photos ◆ Test Setup Photos ◆ User Manual Planned Release Date STC: 90 Days External Photos Internal Photos Test Setup Photos User Manual Sincerely, XueShan Huang / Regulatory Principal Engineer Fibocom Wireless Inc. Tel: +86-755-26525092 E-mail: [email protected]

Modular Approval Request FCC FCC ID: ZMONL668LA01 Items to be covered Answer from applicant 1. The modular transmitter must have its own RF shielding. Y The EUT provides the RF shielding. See EUT photo. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. Y The EUT has its buffered modulation. 3. The modular transmitter must have its own power supply regulation. Y The EUT has its own power supply regulation, please see the Schematic Diagram. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable).. Y The EUT meets the FCC antenna requirements; unique antenna connector and photo of antenna are shown in the test report. 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. Y The EUT was tested with a test board, Please see test report and setup photo 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. Y The FCC ID is ZMONL668LA01 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. For example, there are very strict operational and timing requirements that must be met before a transmitter is authorized for operation under Section 15.231. For instance, data transmission is prohibited, except for operation under Section 15.231(e), in which case there are separate field strength level and timing requirements. Compliance with these requirements must be assured. Y The EUT is compliant with all applicable FCC rules. Details instructions for maintaining compliance are give in the User Manual. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Modular transmitters approved under other Sections of Part 15, when necessary, may also need to address certain RF Exposure concerns, Y The EUT complies with RF exposure requirement. typically by providing specific installation and operating instructions for users, installers and other interested parties to ensure compliance. Note: If compliance with one or more of the numbered requirements, listed above, cannot be demonstrated, it may be possible to obtain a “Limited Modular Approval” (LMA). Name and surname of applicant (or authorized representative): HuangXueShan Date: 2020-05-08 Signature:

Fibocom Wireless Inc. C:\Users\eason-ys_wang\Desktop\广和通\NL668-LA\申请 list\FCC\POA_Letter_140225.docx Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: March 5, 2020 SUBJECT: FCC Application for FCC ID: ZMONL668LA01 To Whom It May Concern: We, the undersigned, hereby authorize Jim Huang at SGS-CSTC Standards Technical Services Ltd on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by SGS-CSTC Standards Technical Services Ltd on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, XueShan Huang/ Regulatory Principal Engineer Fibocom Wireless Inc. Tel: +86-755-26525092 E-mail: [email protected]

Amendment Letter Timco Engineering, Inc. This is to request report update for FCC ID: ZMONL668LA01, The Major change filed under this application and the relevant report numbers are as below: Original report number New report number Revise content ZR/2020/3002101 ZR/2020/3002101-01 1.Add test site Information in section 2, 3.2 and 3.3. 2.Update equipment list in section 5. 3.Update the report NO. of appendix B in header with “-01”. 4. Add antenna height and angle for ‘Field Strength of Spurious Radiation’ in appendix B. Setup photo Add test location. Sincerely, (signature) (printed name) Derek Yang

Label Location

本文件版权属深圳市广和通无线股份有限公司所有，未经批准，不得复制。 FIBOCOM-SAL-WI-71-Form-02 Page 1 of 2 NL668-LA-01认证标签设计文档_V1.0 工艺：打印标签 版本记录 文档版本 更新日期 说明 V1.0 2020-04-13 NA 本文件版权属深圳市广和通无线股份有限公司所有，未经批准，不得复制。 FIBOCOM-SAL-WI-71-Form-02 Page 2 of 2 说明1: SN S/N号码，10个号码，请参考《产品及包装箱SN编码规则》最新版本 IMEI IMEI号码，15位数字组成。标签样图上面只是举例号码，实际IMEI号请参照认 证部提供的信息。字体以标签样图为准 FCC ID 字体以标签样图为准 公差说明 镭雕标签公差默认为0.25mm

Page1, Total 2 Tune-up procedures of NL668-LA-01 1 Test Equipment List –Radio Communication Tester: CMU200 or CMW500 or Angilent 8960 –Dummy battery or Power Supply: Agilent 66319D –PC with serial port –GPIB card 2 The WCDMA power Output power of range： Operating Band Power(dBm) WCDMA Band I 24+1/-3dB WCDMA Band II 24+1/-3dB WCDMA Band V 24+1/-3dB WCDMA Band VIII 24+1/-3dB 3 The LTE power Output power of range： Number of timeslots in uplink assignment Power(dBm) LTE B1 23+1/-2.7dB LTE B2 23+1/-2.7dB LTE B3 23+1/-2.7dB LTE B4 23+1/-2.7dB Page2, Total 2 LTE B5 23+1/-2.7dB LTE B7 23+1/-2.7dB LTE B8 23+1/-2.7dB LTE B20 23+1/-2.7dB LTE B28 23+1/-3.2dB NOTE：For transmission bandwidths (Figure 5.4.2-1, Table 5.4.4-1) confined within F UL_low and F UL_low + 4 MHz or F UL_high – 4 MHz and F UL_high , the maximum output power requirement is relaxed by reducing the lower tolerance limit by 1.5 dB

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/3002102 Page: 1 of 7 Authorized Signature: Derek Yang Wireless Laboratory Manager Cover PRF Exposure Evaluation Report Application No.: ZR/2020/30021 Applicant: Fibocom Wireless Inc. Address of Applicant: 5/F,Tower A,Technology Building II,1057 Nanhai Avenue,Shenzhen,China Manufacturer: Fibocom Wireless Inc. Address of Manufacturer: 5/F,Tower A,Technology Building II,1057 Nanhai Avenue,Shenzhen,China Factory: Shenzhen Eternity Technology Co.,Ltd Address of Factory: 1F,2F,4F Building A2,Yingzhan Industrial Zone,Longtian Community, Longtian Road,Pingshan District,Shenzhen Guangdong Provice PR China EUT Description: LTE Module Model No.: NL668-LA-01 Trade Mark: Fibocom FCC ID: ZMONL668LA01 Standards: 47 CFR Part 2.1091 FCC KDB 447498 D01 v06 Date of Receipt: 2020/03/18 Date of Test: 2020/03/19 to 2020/04/15 Date of Issue: 2020/04/15 Test Result: PASS* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/3002102 Page: 2 of 7 1 Version Revision Record Version Chapter Date Modifier Remark 00 2020/4/15 Original Authorized for issue by: 2020/4/15 Mike Hu /Project Engineer 2020/4/15 David Chen /Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/3002102 Page: 3 of 7 Contents 1 VERSION ................................................................................................................................................................. 2 2 GENERAL INFORMATION .................................................................................................................................. 4 2.1 CLIENT INFORMATION ..................................................................................................................................... 4 2.2 TEST LOCATION .............................................................................................................................................. 4 2.3 TEST FACILITY ................................................................................................................................................. 4 2.4 GENERAL DESCRIPTION OF EUT .................................................................................................................... 5 3 RF EXPOSURE EVALUATION ........................................................................................................................... 6 3.1 RF EXPOSURE COMPLIANCE REQUIREMENT ................................................................................................. 6 3.1.1 Limits .......................................................................................................................................................... 6 3.1.2 Test Procedure ......................................................................................................................................... 6 3.1.3 EUT RF Exposure Evaluation ................................................................................................................ 7 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/3002102 Page: 4 of 7 2 General Information 2.1 Client Information Applicant: Fibocom Wireless Inc. Address of Applicant: 5/F,Tower A,Technology Building II,1057 Nanhai Avenue,Shenzhen,China Manufacturer: Fibocom Wireless Inc. Address of Manufacturer: 5/F,Tower A,Technology Building II,1057 Nanhai Avenue,Shenzhen,China Factory: Shenzhen Eternity Technology Co.,Ltd Address of Factory: 1F,2F,4F Building A2,Yingzhan Industrial Zone,Longtian Community, Longtian Road,Pingshan District,Shenzhen Guangdong Provice PR China 2.2 Test Location Company: SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Address: No. 1 Workshop, M-10, Middle section, Science & Technology Park, Shenzhen, Guangdong, China Post code: 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 E-mail: [email protected] 2.3 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • CNAS (No. CNAS L2929) CNAS has accredited SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch EMC Lab to ISO/IEC 17025:2005 General Requirements for the Competence of Testing and Calibration Laboratories (CNAS-CL01 Accreditation Criteria for the Competence of Testing and Calibration Laboratories) for the competence in the field of testing. • A2LA (Certificate No. 3816.01) SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory is accredited by the American Association for Laboratory Accreditation(A2LA). Certificate No. 3816.01. • VCCI The 3m Fully-anechoic chamber for above 1GHz, 10m Semi-anechoic chamber for below 1GHz, Shielded Room for Mains Port Conducted Interference Measurement and Telecommunication Port Conducted Interference Measurement of SGS-CSTC Standards Technical Services Co., Ltd. have been registered in accordance with the Regulations for Voluntary Control Measures with Registration No.: G-20026, R-14188, C-12383 and T-11153 respectively. • FCC –Designation Number: CN1178 SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory has been recognized as an accredited testing laboratory. Designation Number: CN1178. Test Firm Registration Number: 406779. • Industry Canada (IC) Two 3m Semi-anechoic chambers and the 10m Semi-anechoic chamber of SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch EMC Lab have been registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing with Registration No.: 4620C-1, 4620C-2, 4620C-3. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/3002102 Page: 5 of 7 2.4 General Description of EUT EUT Description: LTE Module Model No.: NL668-LA-01 Trade Mark: Fibocom Hardware Version: V1.0.0 Software Version: 19006.1000.15.02.01.03 Sample…
