ZMONL952NALTE Module

Fibocom Wireless Inc.

Click to zoom

Application Details

Equipment Class: CBE - Citizens Band End User Devices
Date of Grant: Oct 05, 2020
Application Purpose: Original Equipment
Date of Application: Oct 05, 2020
Equipment Note: LTE Module
Frequency Range: 3557.50000000 - 3692.50000000
Company: Fibocom Wireless Inc.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

FIBOCOM_NL952-EAU Hardware User Manual Version: 1.0.1 Date: 2019-12-12 FIBOCOM_NL952-NA_ Hardware_User_Manual Version: 1.0.1 Date: 2020-02-28 Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. FIBOCOM_NL952-NA_Hardware_User_Manual Page 2 of 57 Applicability Table No. Product model Description 1 NL952-NA-00 Cat20 WWAN Module 2 NL952-NA-20 Cat12 WWAN Module Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. FIBOCOM_NL952-NA_Hardware_User_Manual Page 3 of 57 Copyright Copyright © 2020 Fibocom Wireless Inc. All rights reserved. Without the prior written permission of the copyright holder, any company or individual is prohibited to excerpt, copy any part of or the entire document, or distribute the document in any form. Notice The document is subject to update from time to time owing to the product version upgrade or other reasons. Unless otherwise specified, the document only serves as the user guide. All the statements, information and suggestions contained in the document do not constitute any explicit or implicit guarantee. Warning Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End user must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The portable device is designed to meet the requirements for exposure to radio waves established by the Federal Communications Commission (USA). These requirements set a SAR limit of 1.6 W/kg averaged over one gram of tissue. The highest SAR value reported under this standard during product certification for use when properly worn on the body Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. FIBOCOM_NL952-NA_Hardware_User_Manual Page 4 of 57 This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Trademark The trademark is registered and owned by Fibocom Wireless Inc. Versions Version Author Date Remark V1.0.0 Lei Daijun 2020-01-02 Draft version V1.0.1 Xu Xialin 2020-02-28 ● Add NL952-NA-00 and NL952-NA-20 ● Add PCIe_BOOT_DISABLE definition Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. FIBOCOM_NL952-NA_Hardware_User_Manual Page 5 of 57 Contents 1 Foreword ....................................................................................................................... 8 1.1 Introduction ................................................................................................................... 8 1.2 Reference Standard ..................................................................................................... 8 1.3 Related Documents ...................................................................................................... 8 2 Overview ....................................................................................................................... 9 2.1 Introduction ................................................................................................................... 9 2.2 Specification ................................................................................................................. 9 2.3 CA combinations ......................................................................................................... 11 2.4 Application Block ........................................................................................................ 12 2.5 Antenna Configuration ................................................................................................ 12 3 Application Interface ...................................................................................................13 3.1 M.2 Interface .............................................................................................................. 13 Pin Map ......................................................................................................................... 13 Pin Definition ..........................................…

Text truncated - open the document above for the full version.

Cover Letter(s)

Amendment Letter Timco Engineering, Inc. This is to request report update for FCC ID: ZMONL952NA, The Major change filed under this application and the relevant report numbers are as below: Original report numberNew report number Revise content ZR/2020/7001701 ZR/2020/7001701-01 1.Add test site Information in section 2, 3.2 and 3.3. 2.Update equipment list in section 5. 3. Update the report NO. of appendix B in header with “-01” 4.Add antenna height and angle for ‘Field Strength of Spurious Radiation’ in appendix B Setup photo Add test location. Sincerely, (signature) (printed name) Derek Yang

External Photos

ExternalPhotos

Internal Photos

InternalPhotos

Parts List/Tune Up Info

Page1,Total7 Tune-upproceduresofNL952-NA 1.1TestEquipmentList –RadioCommunicationTester:CMW500 –DummybatteryorPowerSupply:Agilent66319D –PCwithserialport –GPIBcard 1.2TheLTEBand2poweradjustprocedure Outputpowerofrange： Modulation Channelbandwidth/Transmission bandwidthconfiguration[RB] Power (dBm) 1.4MHz3MHz5MHz10MHz15MHz20MHz QPSK111111 23+1/-1dB QPSK≤5≤4≤8≤12≤16≤18 23+1/-1dB QPSK>5>4>8>12>16>18 22+1/-1dB 16QAM≤5≤4≤8≤12≤16≤18 22+1/-1dB 16QAM>5>4>8>12>16>18 21+1/-1dB 1.3TheLTEBand4poweradjustprocedure Outputpowerofrange： Modulation Channelbandwidth/Transmission bandwidthconfiguration[RB] Power (dBm) 1.4MHz3MHz5MHz10MHz15MHz20MHz QPSK111111 23+1/-1dB QPSK≤5≤4≤8≤12≤16≤18 23+1/-1dB QPSK>5>4>8>12>16>1822+1/-1dB 16QAM≤5≤4≤8≤12≤16≤18 22+1/-1dB 16QAM>5>4>8>12>16>1821+1/-1dB Page2,Total7 1.4TheLTEBand5poweradjustprocedure Outputpowerofrange： Modulation Channelbandwidth/Transmission bandwidthconfiguration[RB] Power(dBm) 1.4MHz3MHz5MHz10MHz QPSK111123+1/-1dB QPSK≤5≤4≤8≤1223+1/-1dB QPSK>5>4>8>1222+1/-1dB 16QAM≤5≤4≤8≤1222+1/-1dB 16QAM>5>4>8>1221+1/-1dB 1.5TheLTEBand7poweradjustprocedure Outputpowerofrange： Modulation Channelbandwidth/Transmission bandwidthconfiguration[RB] Power(dBm) 5MHz10MHz15MHz20MHz QPSK1111 23+1/-1dB QPSK≤8≤12≤16≤18 23+1/-1dB QPSK>8>12>16>1822+1/-1dB 16QAM≤8≤12≤16≤18 22+1/-1dB 16QAM>8>12>16>1821+1/-1dB 1.6TheLTEBand12poweradjustprocedure Outputpowerofrange： Modulation Channelbandwidth/Transmission bandwidthconfiguration[RB] Power(dBm) 1.4MHz3MHz5MHz10MHz QPSK1111 23+1/-1dB QPSK≤5≤4≤8≤12 23+1/-1dB QPSK>5>4>8>1222+1/-1dB 16QAM≤5≤4≤8≤12 22+1/-1dB 16QAM>5>4>8>1221+1/-1dB Page3,Total7 1.7TheLTEBand13poweradjustprocedure Outputpowerofrange： Modulati on Channelbandwidth/Transmission bandwidthconfiguration[RB]Power (dBm) 1.4MH z 3MHz5MHz10MHz15MHz20MHz QPSK1123+1/-1dB QPSK≤8≤1223+1/-1dB QPSK>8>1222+1/-1dB 16QAM≤8≤1222+1/-1dB 16QAM>8>1221+1/-1dB 1.8TheLTEBand14poweradjustprocedure Outputpowerofrange： Modulati on Channelbandwidth/Transmission bandwidthconfiguration[RB]Power (dBm) 1.4MH z 3MHz5MHz10MHz15MHz20MHz QPSK1123+1/-1dB QPSK≤8≤1223+1/-1dB QPSK>8>1222+1/-1dB 16QAM≤8≤1222+1/-1dB 16QAM>8>1221+1/-1dB 1.9TheLTEBand17poweradjustprocedure Outputpowerofrange： Modulation Channelbandwidth/Transmission bandwidthconfiguration[RB] Power (dBm) 1.4MHz3MHz5MHz10MHz15MHz20MHz QPSK11 23+1/-1dB QPSK≤8≤12 23+1/-1dB QPSK>8>12 22+1/-1dB 16QAM≤8≤12 22+1/-1dB 16QAM>8>12 21+1/-1dB Page4,Total7 1.10TheLTEBand25poweradjustprocedure Outputpowerofrange： Modulation Channelbandwidth/Transmission bandwidthconfiguration[RB] Power (dBm) 1.4MHz3MHz5MHz10MHz15MHz20MHz QPSK11111123+1/-1dB QPSK≤5≤4≤8≤12≤16≤1823+1/-1dB QPSK>5>4>8>12>16>1822+1/-1dB 16QAM≤5≤4≤8≤12≤16≤1822+1/-1dB 16QAM>5>4>8>12>16>1821+1/-1dB 1.11TheLTEBand26poweradjustprocedure Outputpowerofrange： Modulation Channelbandwidth/Transmission bandwidthconfiguration[RB] Power (dBm) 1.4MHz3MHz5MHz10MHz15MHz20MHz QPSK1111123+1/-1dB QPSK≤5≤4≤8≤12≤1623+1/-1dB QPSK>5>4>8>12>1622+1/-1dB 16QAM≤5≤4≤8≤12≤1622+1/-1dB 16QAM>5>4>8>12>1621+1/-1dB 1.12TheLTEBand30poweradjustprocedure Outputpowerofrange： Modulation Channelbandwidth/Transmission bandwidthconfiguration[RB] Power (dBm) 1.4MHz3MHz5MHz10MHz15MHz20MHz QPSK11 22+1/-1dB QPSK≤8≤12 22+1/-1dB QPSK>8>12 21+1/-1dB 16QAM≤8≤12 21+1/-1dB 16QAM>8>12 20+1/-1dB Page5,Total7 1.13TheLTEBand66poweradjustprocedure Outputpowerofrange： Modulation Channelbandwidth/Transmission bandwidthconfiguration[RB] Power (dBm) 1.4MHz3MHz5MHz10MHz15MHz20MHz QPSK111111 23+1/-1dB QPSK≤5≤4≤8≤12≤16≤18 23+1/-1dB QPSK>5>4>8>12>16>1822+1/-1dB 16QAM≤5≤4≤8≤12≤16≤1822+1/-1dB 16QAM>5>4>8>12>16>1821+1/-1dB 1.14TheLTEBand71poweradjustprocedure Outputpowerofrange： Modulation Channelbandwidth/Transmission bandwidthconfiguration[RB] Power (dBm) 1.4MHz3MHz5MHz10MHz15MHz20MHz QPSK111123+1/-1dB QPSK≤8≤12≤16≤1823+1/-1dB QPSK>8>12>16>1822+1/-1dB 16QAM≤8≤12≤16≤1822+1/-1dB 16QAM>8>12>16>1821+1/-1dB 2.1TheLTEBand41poweradjustprocedure Outputpowerofrange： Modulation Channelbandwidth/Transmission bandwidthconfiguration[RB] Power (dBm) 1.4MHz3MHz5MHz10MHz15MHz20MHz QPSK111123+1/-1dB QPSK≤8≤12≤16≤18 23+1/-1dB QPSK>8>12>16>1822+1/-1dB 16QAM≤8≤12≤16≤1822+1/-1dB 16QAM>8>12>16>1821+1/-1dB Page6,Total7 2.2TheLTEBand48poweradjustprocedure Outputpowerofrange： Modulation Channelbandwidth/Transmissionbandwidth configuration[RB] Power(dBm) 5MHz10MHz15MHz20MHz QPSK111121+1/-1dB QPSK≤8≤12≤16≤1821+1/-1dB QPSK>8>12>16>1820+1/-1dB 16QAM≤8≤12≤16≤1820+1/-1dB 16QAM>8>12>16>1819+1/-1dB 3.1TheWCDMABand2,4,5poweradjustprocedure Outputpowerofrange： OperatingBand PowerClass3Power(dBm) Band223.5+1/-1dB Band423.5+1/-1dB Band523.5+1/-1dB 4.1Theinter-bandULCApoweradjustprocedure Outputpowerofrange： OperatingBand PowerClass3Power(dBm) PCC+SCCPCCSCC 2A-4A23+1/-1dB21+1/-1dB21+1/-1dB 2A-12A23+1/-1dB21+1/-1dB21+1/-1dB 2A-13A23+1/-1dB21+1/-1dB21+1/-1dB 2A-66A23+1/-1dB21+1/-1dB21+1/-1dB Page7,Total7 4A-5A23+1/-1dB21+1/-1dB21+1/-1dB 4A-12A23+1/-1dB21+1/-1dB21+1/-1dB 4A-13A23+1/-1dB21+1/-1dB21+1/-1dB 13A-66A23+1/-1dB21+1/-1dB21+1/-1dB 4.1Theintra-bandULCApoweradjustprocedure OperatingBandPowerClass3Power(dBm) 5B23+1/-1dB 66C23+1/-1dB

RF Exposure Info

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/7001703 Page: 1 of 7 Authorized Signature: Derek Yang Wireless Laboratory Manager Cover PRF Exposure Evaluation Report Application No.: ZR/2020/70017 Applicant: Fibocom Wireless Inc. Address of Applicant: 5/F,Tower A,Technology Building II,1057 Nanhai Avenue,Shenzhen,China Manufacturer: Fibocom Wireless Inc. Address of Manufacturer: 5/F,Tower A,Technology Building II,1057 Nanhai Avenue,Shenzhen,China EUT Description: LTE Module Model No.: NL952-NA Trade Mark: Fibocom FCC ID: ZMONL952NA Standards: 47 CFR Part 2.1091 FCC KDB 447498 D01 v06 Date of Receipt: 2020/7/10 Date of Test: 2020/7/10 to 2020/8/30 Date of Issue: 2020/9/1 Test Result: PASS* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/7001703 Page: 2 of 7 1 Version Revision Record Version Chapter Date Modifier Remark 01 2020/9/1 Original Authorized for issue by: Mike Hu /Project Engineer David Chen /Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/7001703 Page: 3 of 7 Contents 1 VERSION .................................................................................................................................................. 2 2 GENERAL INFORMATION........................................................................................................................ 4 2.1 CLIENT INFORMATION ............................................................................................................................ 4 2.2 TEST LOCATION .................................................................................................................................... 4 2.3 TEST FACILITY ...................................................................................................................................... 4 2.4 GENERAL DESCRIPTION OF EUT ............................................................................................................. 5 3 RF EXPOSURE EVALUATION.................................................................................................................. 6 3.1 RF EXPOSURE COMPLIANCE REQUIREMENT ............................................................................................ 6 3.1.1 Limits ........................................................................................................................................... 6 3.1.2 Test Procedure ............................................................................................................................ 7 3.1.3 EUT RF Exposure Evaluation....................................................................................................... 7 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/6002807 Page: 4 of 7 2 General Information 2.1 Client Information Applicant: Fibocom Wireless Inc. Address of Applicant: 5/F,Tower A,Technology Building II,1057 Nanhai Avenue,Shenzhen,China Manufacturer: Fibocom Wireless Inc. Address of Manufacturer: 5/F,Tower A,Technology Building II,1057 Nanhai Avenue,Shenzhen,China 2.2 Test Location Company: SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Address: No. 1 Workshop, M-10, Middle section, Science & Technology Park, Shenzhen, Guangdong, China Post code: 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 E-mail: [email protected] 2.3 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • CNAS (No. CNAS L2929) CNAS has accredited SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch EMC Lab to ISO/IEC 17025:2017 General Requirements for the Competence of Testing and Calibration Laboratories (CNAS-CL01 Accreditation Criteria for the Competence of Testing and Calibration Laboratories) for the competence in the field of testing. • A2LA (Certificate No. 3816.01) SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory is accredited by the American Association for Laboratory Accreditation(A2LA). Certificate No. 3816.01. • VCCI The 3m Fully-anechoic chamber for above 1GHz, 10m Semi-anechoic chamber for below 1GHz, Shielded Room for Mains Port Conducted Interference Measurement and Telecommunication Port Conducted Interference Measurement of SGS-CSTC Standards Technical Services Co., Ltd. have been registered in accordance with the Regulations for Voluntary Control Measures with Registration No.: G-20026, R-14188, C-12383 and T-11153 respectively. • FCC –Designation Number: CN1178 SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory has been recognized as an accredited testing laboratory. Designation Number: CN1178. Test Firm Registration Number: 406779. • Industry Canada (IC) Two 3m Semi-anechoic chambers and the 10m Semi-anechoic chamber of SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch EMC Lab have been registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing with Registration No.: 4620C-1, 4620C-2, 4620C-3. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/6002807 Page: 5 of 7 2.4 General Description of EUT EUT Description:: LTE Module Model No.: NL952-NA Trade Mark: Fibocom Hardware Version: V1.02 Software Version: 19602.7000.00.02.02.16 Sample Type: Portable Device, Module Antenna Type: External, Integrated Antenna Gain: WCDMA Band II:4dBi WCDMA Band VI:4dBi WCDMA Band V:3dBi LTE Band 2:4dBi; LTE Band 4:4dBi; LTE Band 5:3dBi; LTE Band 7: 4dBi; LTE Band 12:3dBi; LTE Band 13:2dBi; LTE Band 14:2dBi; LTE Band 17:3dBi; LTE Band 25:4dBi; LTE Band 26:3dBi; LTE Band 30:1dBi; LTE Band 41:3dBi; LTE Band 48:1dBi; LTE Band 66:4dBi; LTE Band 71:4dBi; SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/6002807 Page: 6 of 7 3 RF Exposure Evaluation 3.1 RF Exposure C…

Text truncated - open the document above for the full version.

Test Report

SGS-CSTCStandardsTechnicalServicesCo.,Ltd.Shenzhen Branch ReportNo.:ZR/2020/7001701 Page:1of123 AppendixB E-UTRABand48 SGS-CSTCStandardsTechnicalServicesCo.,Ltd.Shenzhen Branch ReportNo.:ZR/2020/7001701 Page:2of123 CONTENT 1EFFECTIVE(ISOTROPIC)RADIATEDPOWER ........................................................................................................... 3 1.1.TESTRESULT ...................................................................................................................................................... 3 2.PEAK-TO-AVERAGERATIO(CCDF) ........................................................................................................................ 11 2.1.TESTRESULT .................................................................................................................................................... 11 2.2.TESTPLOTS ..................................................................................................................................................... 11 3.MODULATIONCHARACTERISTICS ........................................................................................................................ 20 3.1.TESTMODE=LTE/TM120MHZ ...................................................................................................................... 20 3.1.1.TESTCHANNEL=MCH .................................................................................................................................. 20 3.2.TESTMODE=LTE/TM220MHZ ...................................................................................................................... 21 3.2.1.TESTCHANNEL=MCH .................................................................................................................................. 21 3.3.TESTMODE=LTE/TM320MHZ ...................................................................................................................... 22 3.3.1.TESTCHANNEL=MCH .................................................................................................................................. 22 4.26DBBANDWIDTHANDOCCUPIEDBANDWIDTH ............................................................................................... 23 4.1.TESTRESULT .................................................................................................................................................... 23 4.2.TESTPLOTS ..................................................................................................................................................... 25 5.BANDEDGECOMPLIANCE ................................................................................................................................... 61 5.1.TESTPLOTS ..................................................................................................................................................... 61 6.SPURIOUSEMISSIONATANTENNATERMINAL .................................................................................................. 109 6.1.TESTPLOTS ................................................................................................................................................... 109 7.FIELDSTRENGTHOFSPURIOUSRADIATION ...................................................................................................... 118 7.1.TESTMODE=LTE/TM120MHZ ...................................................................................................................... 118 7.1.1.TESTCHANNEL=LCH ................................................................................................................................. 118 7.1.2.TESTCHANNEL=MCH ................................................................................................................................ 118 7.1.3.TESTCHANNEL=HCH ................................................................................................................................ 119 8.FREQUENCYSTABILITY ....................................................................................................................................... 120 8.1.FREQUENCYVSVOLTAGE ................................................................................................................................. 120 8.2.FREQUENCYVSTEMPERATURE ........................................................................................................................... 121 SGS-CSTCStandardsTechnicalServicesCo.,Ltd.Shenzhen Branch ReportNo.:ZR/2020/7001701 Page:3of123 1Effective(Isotropic)RadiatedPower 1.1.TestResult BandBandwidthModulationChannel RB Configuration Conducted Power(dBm) EIRP (dBm) Verdict Band485MHzQPSK552651RB#022.0423.04PASS Band485MHzQPSK552651RB#1222.1523.15PASS Band485MHzQPSK552651RB#2422.2123.21PASS Band485MHzQPSK5526512RB#621.9322.93PASS Band485MHzQPSK5526512RB#021.5622.56PASS Band485MHzQPSK5526512RB#1322.2323.23PASS Band485MHzQPSK5526525RB#021.7922.79PASS Band485MHzQPSK559901RB#2422.2223.22PASS Band485MHzQPSK559901RB#022.2423.24PASS Band485MHzQPSK559901RB#1222.3123.31PASS Band485MHzQPSK5599012RB#021.4722.47PASS Band485MHzQPSK5599012RB#621.5622.56PASS Band485MHzQPSK5599012RB#1321.6422.64PASS Band485MHzQPSK5599025RB#021.4322.43PASS Band485MHzQPSK567151RB#1222.1823.18PASS Band485MHzQPSK567151RB#022.2823.28PASS Band485MHzQPSK567151RB#2422.3723.37PASS Band485MHzQPSK5671512RB#1322.2423.24PASS Band485MHzQPSK5671512RB#621.5822.58PASS Band485MHzQPSK5671512RB#021.5222.52PASS Band485MHzQPSK5671525RB#022.2523.25PASS Band485MHz64QAM552651RB#020.3721.37PASS Band485MHz64QAM552651RB#2420.2821.28PASS Band485MHz64QAM552651RB#1220.3221.32PASS Band485MHz64QAM5526512RB#020.3821.38PASS Band485MHz64QAM5526512RB#620.6021.6PASS Band485MHz64QAM5526512RB#1320.4421.44PASS Band485MHz64QAM5526525RB#020.5021.5PASS SGS-CSTCStandardsTechnicalServicesCo.,Ltd.Shenzhen Branch ReportNo.:ZR/2020/7001701 Page:4of123 Band485MHz64QAM559901RB#020.3721.37PASS Band485MHz64QAM559901RB#1220.7021.7PASS Band485MHz64QAM559901RB#2420.3521.35PASS Band485MHz…

Text truncated - open the document above for the full version.

Test Report

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/7001701 Page: 1 of 43 Authorized Signature: Derek Yang Wireless Laboratory Manager FCC TEST REPORT Application No:ZR/2020/70017 Applicant:Fibocom Wireless Inc. Address of Applicant5/F,Tower A,Technology Building II,1057 Nanhai Avenue,Shenzhen,China Manufacturer:Fibocom Wireless Inc. Address of Manufacturer:5/F,Tower A,Technology Building II,1057 Nanhai Avenue,Shenzhen,China Factory:Shenzhen Eternity Technology Co., Ltd Address of Factory:1F, 2F, 4F Building A2, Yingzhan Industrial Zone, Longtian Community, Longtian Road, Pingshan District, Shenzhen, Guangdong Province, P.R. China EUT Description:LTE Module Model No.:NL952-NA Trade Mark:Fibocom FCC ID:ZMONL952NA Standards:47 CFR Part 2 47 CFR Part 22 subpart H 47 CFR Part 24 subpart E 47 CFR Part 27 subpart C 47 CFR Part 90 subpart R 47 CFR Part 90 subpart S 47 CFR Part 96 subpart E Test Method: FCC KDB 971168 D01 Power Meas License Digital Systems V03r01 C63.26 (2015) Date of Receipt: 2020/7/10 Date of Test: 2020/7/10 to 2020/8/30 Date of Issue: 2020/9/1 Test Result: PASS * * In the configuration tested, the EUT detailed in this report complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/7001701 Page: 2 of 43 1 Version Revision Record VersionChapterDateModifierRemark 012020/9/1Original Authorized for issue by: Tested By (Mike Hu) /Project Engineer Checked By (David Chen) /Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/7001701 Page: 3 of 43 Content 1VERSION ............................................................................................................................................................ 2 2TEST SUMMARY ............................................................................................................................................... 5 2.1 UMTS BAND5 & LTE BAND5 / 26 ........................................................................................................... 5 2.2 UMTS BAND2 /LTE BAND2 /25 ............................................................................................................... 5 2.3 UMTS BAND4 /LTE BAND4 /66 ............................................................................................................... 6 2.4 LTE BAND7/38/41 ..................................................................................................................................... 6 2.5 LTE BAND12/17 ........................................................................................................................................ 7 2.6 LTE BAND13 .............................................................................................................................................. 7 2.7 LTE BAND14 .............................................................................................................................................. 8 2.8 LTE BAND26 ............................................................................................................................................ 10 2.9 LTE BAND30 ............................................................................................................................................ 10 2.10 LTE BAND48 ............................................................................................................................................ 12 2.11 LTE BAND71 ............................................................................................................................................ 13 3GENERAL INFORMATION ............................................................................................................................. 14 3.1 CLIENTINFORMATION ................................................................................................................................ 14 3.2 TESTLOCATION ......................................................................................................................................... 14 3.3 TESTFACILITY ........................................................................................................................................... 14 3.4 GENERALDESCRIPTION OFEUT .............................................................................................................. 15 3.5 TESTMODE ............................................................................................................................................... 15 3.6 TESTENVIRONMENT .................................................................................................................................. 16 3.7 TECHNICALSPECIFICATION ....................................................................................................................... 16 3.8 TESTFREQUENCIES .................................................................................................................................. 20 4DESCRIPTION OF TESTS ............................................................................................................................. 29 4.1 CONDUCTEDOUTPUTPOWER ................................................................................................................... 29 4.2 EFFECTIVE(ISOTROPIC) RADIATEDPOWER OFTRANSMITTER ................................................................. 29 4.3 EIRP POWERDENSITY ............................................................................................................................. 30 4.4 OCCUPIEDBANDWIDTH ............................................................................................................................. 30 4.5 BANDEDGE ATANTENNATERMINALS ....................................................................................................... 31 4.6 SPURIOUSANDHARMONICEMISSIONS ATANTENNATERMINAL ....................................................…

Text truncated - open the document above for the full version.

Test Report

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/7001701-01 Page: 1 of 123 Appendix B E-UTRA Band 48 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZR/2020/7001701-01 Page: 2 of 123 CONTENT 1 EFFECTIVE…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Patrick Ma(Certification Director)

[email protected]+8675526733555Fax: +86-755-26520841

Test Firm

SGS-CSTC Standards Technical Services Co., LtdDerek Yang

[email protected]+86 0135 6484 8721

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
3	96	3.56 GHz - 3.69 GHz	155.00 mW	13M5W7D	0.1 ppm

Modular Type

Single Modular Approval

Confidentiality

Long Term

Grant Notes

Single Modular Approval. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for mobile and fixed applications. OEM integrators must be provided labeling requirements for finished products. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. Output Power listed is the maximum conducted output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any other antenna or transmitter. The antenna installation and operating configurations of this transmitter, including any applicable source-based time-averaging duty factor, antenna gain, and cable loss must satisfy MPE categorical Exclusion Requirements of Part 2.1091. The Antenna(s) used for this transmitter must not exceed a maximum gain as described in the filing. Users must be provided with instructions and transmitter operating conditions for satisfying RF exposure compliance. RF exposure compliance may need to be addressed at the time of licensing, as required by the responsible FCC bureau(s), including antenna co-location requirements of Part 1.1307(b)(3). This device supports: LTE of 5, 10, 15, and 20 MHz bandwidth modes for LTE Band 48.
