SC218 Hardware Guide V1.1 Disclaimer Customers must design and develop their products referring to the information provided in the document. The Company shall not be liable for any damage caused by failure to comply with relevant operation or specifications or rules. Due to product version upgrade or other reasons, the Company reserves the right to modify any information in this document at any time without prior notice and any responsibility. Unless otherwise agreed, all statements, information and suggestions in this document do not constitute any express or implied guarantee. Copyright Notice Copyright Β© 2023 Fibocom Wireless Inc. All rights reserved. Unless specially authorized by the Company, the recipient of the documents shall keep the documents and information received confidential, and shall not use them for any purpose other than the implementation and development of this project. Without the written permission of the Company, no unit or individual shall extract or copy part or all of the contents of this document without authorization, or transmit them in any form. The Company has the right to investigate legal liabilities for any offense and tort in connection with violation of confidentiality obligations, or unauthorized use or malicious use of the said documents and information in other illegal forms. Trademark Statement The trademark is registered and owned by Fibocom Wireless Inc. Other trademarks, product names, service names and company names appearing in this document are owned by their respective owners. Contact Information Website: https://www.fibocom.com Address: 10/F-14/F, Block A, Building 6, Shenzhen International Innovation Valley, Dashi First Road, Xili Community, Xili Subdistrict, Nanshan District, Shenzhen Tel: 0755-26733555 Safety Instructions Do not operate wireless communication products in areas where the use of radio is not recommended without proper equipment certification. These areas include environments that may generate radio interference, such as flammable and explosive environments, medical devices, aircraft or any other equipment that may be subject to any form of radio interference. The driver or operator of any vehicle shall not operate wireless communication products while controlling the vehicle. Doing so will reduce the driver's or operator's control and operation of the vehicle, resulting in safety risks. Wireless communication devices do not guarantee effective connection under any circumstances, such as when the (U) SIM card is invalid or the device is in arrears. In an emergency, please use the emergency call function when the device is turned on, and ensure that the device is located in an area with sufficient signal strength. Contents Copyright Β© Fibocom Wireless Inc. 1 Contents Applicable Model ............................................................................................... 4 Change History .................................................................................................. 5 1 Foreword ......................................................................................................... 6 1.1 Description ..................................................................................................................... 6 1.2 Reference Standards .................................................................................................... 6 2 Product Overview ........................................................................................... 8 2.1 General Description ..................................................................................................... 8 2.2 Main Performance ........................................................................................................ 9 2.3 Function Block Diagram ............................................................................................ 13 2.4 Pin Definition ................................................................................................................ 15 2.4.1 Pin Assignment ..................................................................................................... 15 2.4.2 Pin Description ...................................................................................................... 16 3 Application Interfaces .................................................................................. 29 3.1 Power Supply ............................................................................................................... 29 3.1.1 Power Input ........................................................................................................... 29 3.1.2 VRTC ......................................................................................................................... 31 3.1.3 VPH_PWR ................................................................................................................ 32 3.1.4 Power Output ........................................................................................................ 32 3.2 Control Signal .............................................................................................................. 34 3.2.1 Power On/Off ........................................................................................................ 34 3.2.1.1 Power-on .......................................................................................................... 34 3.2.1.2 Power-off and Reset ...................................................................................... 36 3.2.1.3 Sleep/Wakeup ................................................................................................. 37 3.2.1.4 Volume Control .............................................................................................. 37 3.3 USB ................................................................................................................................. 37 3.4 UART ..............................................................β¦
Text truncated - open the document above for the full version.
Fibocom Wireless Inc. To: Federal Communications Commission Date: 2023/10/24 7435 Oakland Mills Road Columbia, MD 21046 USA Attestation Section 2.911(d)(5)(i) and Section 2.911(d)(5)(ii) (KDB 986446 D01 Covered Equipment) Section 2.911(d)(5)(i) Fibocom Wireless Inc. certifies that the equipment for which authorization is sought is not βcoveredβ equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Section 2.911(d)(5)(ii) Fibocom Wireless Inc. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing βcoveredβ equipment. Type of Equipment subject to FCC Certification:LTE Module FCC ID:ZMOSC218NA If you have any questions, please feel free to contact me Contact Person: Patrick Ma Position in the Company: Certification Director Date of Signature: 2023-10-24 ___________________________ Signatory (signature of the applicant)
Fibocom Wireless Inc. 1101, Tow er A, Building 6, Shenzhen International, Innovation Valle y, Dashi 1st Rd, Nanshan, ShenZhen, China Tel: +8675526733555 ; Fax: +86-755-26520841 Federal Communications Commission 7435 Oaklan d Mills Road Columbia MD 21046 Subject: Certification designating a U.S. agent for service of process pursuant to Part 2.911(d)(7) To whom it may concern, [Fibocom Wireless Inc. Grantee Code ZMO, FRN:0020891057] (βthe applicantβ) certifies that, as of the date of the filing of application, [Fibocom Wireless USA] (βthe agentβ) is designated as the U.S. agent for the purpose of accepting service of process on behalf of the applicant. The information of agent are: U.S. Agent: Fibocom Wireless USA FCC Registration Number (FRN): 0033437914 Physical U.S. address: 5909 Peachtree Dunwoody Rd Ste 910 Atlant a, GA 30328 United States Contact: Lei Yao Phone: +01 (469)463-6983 Email: [email protected] The applicant accepts to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The agent accepts the designation by (the applicant) as the U.S. agent to accept service of process includes, but is not limited to, delivery of any correspondence, notices, orders, decisions, and requirements of administrative, legal, or judicial process related to Commission proceedings. Signed by the Applicant Signed by the Agent Name: Patrick Ma Email: [email protected] Date: April 21, 2023 Name: Lei Yao Email: [email protected] Date: April 21, 2023
Fibocom Wireless Inc. Date: 2023-10-24 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The Fibocom Wireless Inc., the undersigned, hereby authorizes Miss. Wendy Zhan from Shenzhen Morlab Communications Technology Co., Ltd., to act on the behalf of the Fibocom Wireless Inc. solely in matters relating to the application for an FCC equipment authorization for FCC ID:ZMOSC218NA including the signing of documents in connection with this Application. Necessary acts carried out Shenzhen Morlab Communications Technology Co., Ltd. on our behalf of the Fibocom Wireless Inc. in connection with the Application shall have the same effect as acts of the Fibocom Wireless Inc.. Fibocom Wireless Inc. also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Thank you for your attention to this matter. Yours Sincerely, Signatory: Contact name:Patrick Ma Title:Certification Director Tel:+8675526733555 Email: [email protected] Company name: Fibocom Wireless Inc.
FibocomWirelessInc. Date:2023-10-24 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: Request of Confidentiality forFCC ID: ZMOSC218NA To Whom it may concern: Pursuant to sections 0.457 and 0.459 of Commissionβs Rules(CFR 47), and Section 552(b)(4) of the Freedom of Information Act,Fibocom Wireless Inc. hereby requests confidentiality andtreatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might beharmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-TermConfidentiality for 180 days after the grant as outlined in Public Notice DA04-1705. This provision will giveFibocom Wireless Inc.temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Short-Term Confidential exhibits are listedas follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST ExhibitDescription PERMANENT 1Block Diagram 2Operational Description 3Schematics 4BOM 5Tuneupprocedure SHORT-TERM 6External Photos 7Internal Photos 8Test-Setup Photos 9User Manual The Applicant understands that pursuantto Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Signatory: Name:Patrick Ma Company name:Fibocom Wireless Inc. Address:1101,Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Nanshan, Shenzhen, China Tel: +8675526733555 Email: [email protected]
Fibocom Wireless Inc. UNII Declaration Letter We have declared below featured for FCC equipment authorization, device FCC ID: ZMOSC218NA (1) DFS Device -- Master, Client with Radar detection capability , Client without radar detection capability, N/A (2) Active / Passive Scanning , adhoc mode access point capability Frequency Band (MHz) Active Scanning (the device can transmit a probe (beacon)) passive scanning (where the device is can listen only with no probes) Ad Hoc Mode capability Access point capability 2412 β 2472 MHz Yes, No Yes, No Yes, No Yes, No 2422 β 2462 MHz Yes, No Yes, No Yes, No Yes, No 5745 β 5825 MHz Yes, No Yes, No Yes, No Yes, No 5755 β 5795 MHz Yes, No Yes, No Yes, No Yes, No 5180 β 5240 MHz Yes, No Yes, No Yes, No Yes, No 5190 β 5230 MHz Yes, No Yes, No Yes, No Yes, No 5260 β 5320 MHz Yes, No Yes, No Yes, No Yes, No 5270 β 5310 MHz Yes, No Yes, No Yes, No Yes, No 5500 β 5720 MHz Yes, No Yes, No Yes, No Yes, No 5510 β 5670 MHz Yes, No Yes, No Yes, No Yes, No (3) Country code selection ability - Yes , No If no, pls explain how was implemented : Country is selected as US by default and user can not change the country code. (4) Meet 15.202 requirement - Yes , No , pls check below : A master device is defined as a device operating in a mode in which it has the capability to transmit without receiving an enabling signal. In this mode it is able to select a channel and initiate a network by sending enabling signals to other devices A client device is defined as a device operating in a mode in which the transmissions of the device are under control of the master. A device in client mode is not able to initiate a network. (5) For client devices that have software configuration control to operate in different modes (active scanning in some and passive scanning in others) in different bands (devices with multiple equipment classes or those that operate on non-DFS frequencies) or modular devices which configure the modes of operations through software, the application must provide software and operations description on how the software and / or hardware is implemented to ensure that proper operations modes can not be modified by end user or an installer. Apply , No Apply , (If apply , pls help to provide explanation on how it was implement (By hardware or software , and how software was controlled) The device configuration can not be modified by user as program is not exposed to user by any means. Hardware does not allow USB connection for user which is must to change the configuration. If you have any questions, please feel free to contact me at the address shown below. Yours sincerely, Signatory Printed Name : Patrick Ma Position : Certification Director
Fibocom Wireless Inc. version01 Modular Approval Request Letter Date: 2023-10-24 FCC ID: ZMOSC218NA Type of Equipment: LTE Module The following requirements according to FCC Part 15.212 are met: i RF shielding The radio portion has his own shielding (see external photos). ii Buffered modulation/data inputs has been integrated in the chipset iii Power supply regulation is integrated iv Antenna requirements section 15.203, 15.204 b and 15.204 c The module comes with one permanently attached antennas. The spurious emission requirements are fulfilled (see attached test report). v Stand alone test configuration Please referring to test set up configuration photo vi Labelling The module has its own label. The instruction for labelling rules for the host device has been stated in the users manual vii Compliance on specific rule or operating requirements The required FCC rules has been fulfilled and all instructions for maintaining compliance has been clearly stated in the users manual viii RF Exposure RF exposure requirements are fulfilled for mobile configuration. The installation of the module is restricted to mobile host devices what is clearly stated in the installation instruction of the user manual. For portable applications OEM integrators need SAR evaluation and an own FCC ID. Name: Patrick Ma Title: Certification Director Company: Fibocom Wireless Inc.
FCC ID: ZMOSC218NA IC: 21374-SC218NA External Photos 1. EUT front view 2. EUT rear view
LabelοΌ LocationοΌ(Silkscreenontheshieldcover)
FCC ID: ZMOSC218NA IC: 21374-SC218NA Internal Photos 1. EUT uncover view
MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.οΌSZ23080226S01 Annex B Conducted Power Note: Conducted power unit: dBm The target power was recorded in the manufacture document. BW [MHz]ModulationRB SizeRB Offset Low Channel Middle Channel High Channel BW [MHz] ModulationRB SizeRB Offset Low Channel Middle Channel High Channel 187001890019100200502017520300 18601880190017201732.51745 20QPSK1023.9124.0523.8420QPSK1023.6723.7123.63 20QPSK14923.8524.0123.8220QPSK14923.6023.6423.47 20QPSK19923.8123.9323.7920QPSK19923.6223.6323.67 20QPSK50022.9322.9922.8720QPSK50022.5622.6722.60 20QPSK502422.9022.9522.8420QPSK502422.7722.6622.54 20QPSK505022.8222.8822.7620QPSK505022.4322.6122.46 20QPSK100022.8522.9122.8020QPSK100022.4922.7222.62 2016QAM1023.3023.3323.252016QAM1022.9522.8822.86 2016QAM14923.1923.2723.222016QAM14922.7122.8323.00 2016QAM19923.2623.2423.182016QAM19922.8222.7322.75 2016QAM50022.0122.0421.982016QAM50021.6321.7921.60 2016QAM502421.9121.9721.902016QAM502421.5821.6221.45 2016QAM505021.8921.9021.862016QAM505021.7021.6921.45 2016QAM100021.9321.9121.942016QAM100021.7421.7021.76 2064QAM1023.2723.3023.242064QAM1022.8022.8622.82 2064QAM14923.1923.2623.192064QAM14922.7822.6922.72 2064QAM19923.1523.2223.202064QAM19922.6922.8722.68 2064QAM50022.0322.0521.972064QAM50021.8821.8221.54 2064QAM502422.0022.0121.952064QAM502421.9021.6121.60 2064QAM505021.8921.9621.902064QAM505021.5421.7121.63 2064QAM100021.9521.9321.912064QAM1000 21.7521.7321.78 18675 1890019125200252017520325 1857.518801902.51717.51732.51747.5 15QPSK1023.9624.0123.9315QPSK1023.6223.6823.54 15QPSK13723.7423.9523.8715QPSK13723.5923.5923.60 15QPSK17423.8323.8923.7515QPSK17423.6323.5423.50 15QPSK36022.8923.0922.8615QPSK36022.5822.8022.77 15QPSK362022.8423.0022.7115QPSK362022.6222.6622.71 15QPSK363922.8722.8622.7315QPSK363922.5022.5622.65 15QPSK75022.7822.8422.7915QPSK75022.5722.5822.55 1516QAM1023.1623.1823.241516QAM1022.9622.8622.97 1516QAM13723.2223.2923.081516QAM13722.9522.9022.71 1516QAM17423.1623.3523.321516QAM17423.0022.9122.78 1516QAM36022.1822.2022.171516QAM36021.7321.7921.58 1516QAM362022.0721.9122.091516QAM362021.6921.5921.65 1516QAM363922.0322.0722.001516QAM363921.5221.6121.76 1516QAM75021.7921.7821.841516QAM75021.5521.4721.69 1564QAM1023.3123.3523.291564QAM1022.7222.7422.85 1564QAM13723.2723.2423.271564QAM13722.7722.7822.83 1564QAM17423.1323.2623.211564QAM17422.7922.6022.81 1564QAM36022.1122.0521.971564QAM36021.6321.7621.70 1564QAM362022.1922.0322.081564QAM362021.6121.6321.56 1564QAM363921.8021.8221.841564QAM363921.6321.5321.54 1564QAM75022.0822.0321.801564QAM75021.7621.5321.69 186501890019150200002017520350 18551880190517151732.51750 10QPSK1023.9924.0223.7610QPSK1023.6523.6923.63 10QPSK12523.7223.9023.7110QPSK12523.5723.6223.52 10QPSK14923.71 23.8523.6710QPSK14923.6123.6023.48 10QPSK25023.1023.0922.9410QPSK25022.7122.7622.62 10QPSK251222.9322.8923.0210QPSK251222.6022.7822.51 10QPSK252522.8222.8822.6110QPSK252522.7222.5822.46 10QPSK50022.7822.9122.8110QPSK50022.6622.5722.48 1016QAM1023.2823.3623.341016QAM1022.9522.9322.89 1016QAM12523.0423.3223.281016QAM12522.8123.0022.71 1016QAM14923.4323.1623.111016QAM14922.9022.8922.85 1016QAM25021.9922.1821.891016QAM25021.6621.8221.87 1016QAM251221.7922.0022.071016QAM251221.7521.5521.76 1016QAM252522.0721.9921.921016QAM252521.7721.5721.61 1016QAM50022.0821.9621.961016QAM50021.6621.4621.73 1064QAM1023.1223.2923.191064QAM1022.9822.9122.94 1064QAM12523.3623.3923.271064QAM12522.6222.6322.66 1064QAM14923.0923.4223.331064QAM14922.6122.7422.75 1064QAM25022.0122.0122.001064QAM25021.8221.7021.56 1064QAM251222.2022.0122.151064QAM251221.8621.8121.86 1064QAM252522.0522.0721.961064QAM252521.7421.5621.62 1064QAM50021.8622.0021.801064QAM50021.8421.5021.79 186251890019175199752017520375 1852.518801907.51712.51732.51752.5 5QPSK1023.8324.0123.935QPSK1023.5623.6823.54 5QPSK11223.9323.8723.725QPSK11223.5923.6223.60 5QPSK12423.9123.9823.765QPSK12423.5423.6223.56 5QPSK12022.8423.1322.985QPSK12022.6022.7722.66 5QPSK12722.9423.1122.985QPSK12722.5922.5122.60 5QPSK1213 22.7722.8822.965 QPSK121322.6622.4922.57 5QPSK25022.8322.9522.785QPSK25022.5422.5322.51 516QAM1023.3623.4923.41516QAM1022.8222.8322.75 516QAM11223.3123.1723.17516QAM11222.6822.8222.81 516QAM12423.3823.4323.21516QAM12422.7222.7522.80 516QAM12022.0222.1421.84516QAM12021.7121.7221.63 516QAM12722.0321.8522.00516QAM12721.6021.7621.55 516QAM121321.9921.9021.90516QAM121321.7021.7221.50 516QAM25021.8622.1022.08516QAM25021.5921.6021.83 564QAM1023.3723.2123.40564QAM1022.7622.8422.92 564QAM11223.0923.1623.09564QAM11222.7522.6822.65 564QAM12423.1423.3623.37564QAM12422.7622.7022.67 564QAM12022.0222.0721.88564QAM12021.7921.8221.56 564QAM12721.9422.1822.07564QAM12721.8121.6321.61 564QAM121322.0722.0221.88564QAM121321.7921.5821.67 564QAM25022.1222.1121.80564QAM25021.8221.8421.60 186151890019185199652017520385 1851.518801908.51711.51732.51753.5 3QPSK1023.9223.9923.943QPSK1023.6623.6723.60 3QPSK1823.7023.9623.963QPSK1823.5923.6523.55 3QPSK11423.7923.9523.753QPSK11423.5423.6023.62 3QPSK8022.9423.1122.853QPSK8022.5022.8322.67 3QPSK8422.7622.9622.903QPSK8422.6822.6022.56 3QPSK8722.8223.0322.733QPSK8722.5722.5922.66 Band 2 (1900MHz Band) (dBm) Part 24E Band 4 (AWS Band) (dBm) Part 27L (only on channel required) Tune-up limit (dBm) 25 24 25 24 23 Tune-up limit (dBm) 25 24 24 23 24 23 Frequency (MHz) Tune-up limit (dBm) 25 24 24 23 24 23 Tune-up limit (dBm) 25 24 24 23 24 23 25 24 24 23 24 25 24 Tune-up limit (dBm) 25 24 24 23 24 23 Tune-up limit (dBm) 25 24 24 23 24 23 Tune-up limit (dBm) 25 24 24 23 ChannelChannel Frequency (MHz)Frequency (MHz) 23 Tune-up limit (dBm) Frequency (MHz) 24 23 Tune-up limit (dBm) Tune-up limit (dBm) 24 24 23 ChannelChannel ChannelChannel ChannelChannel Frequency (MHz)Frequency (MHz) Frequency (MHz)Frequenβ¦
Text truncated - open the document above for the full version.
NOTE: This document is issued by Shenzhen Morlab Communications Technology Co., the test report shall not be reproduced except in full without prior written permission of the company. The test results apply only to the particular sample(s) tested and to the specific tests carried out which is available on request for validation and information confirmed at our website. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 1 of 11 REPORT No.οΌSZ23080226S01 RF EXPOSURE EVALUATION REPORT APPLICANT : Fibocom Wireless Inc. PRODUCT NAME : LTE Module MODEL NAME : SC218-NA BRAND NAME : Fibocom FCC ID : ZMOSC218NA STANDARD(S) : FCC 47 CFR Part 2(2.1091) RECEIPT DATE : 2023-08-29 TEST DATE : 2023-09-12 ISSUE DATE : 2023-10-23 Edited by: Xie Yiyun (Rapporteur) Approved by: Shen Junsheng (Supervisor) MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.οΌSZ23080226S01 Page 2of 11 DIRECTORY 1. Technical Information ββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββ 3 1.1 Applicant and Manufacturer Information βββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββ 3 1.2 Equipment under Test (EUT) Description ββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββ 3 1.3 Applied Reference Documents βββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββ 5 2. Device Category and RF Exposure Limit βββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββ 6 3. Test Equipment List βββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββ 7 4. Maximum Average Power Summary βββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββ 8 5. RF Exposure Assessment ββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββ 9 Annex A General Information βββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββββ 11 Annex B Conducted Power Change History Version Date Reason for Change 1.0 2023-10-23 First edition MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.οΌSZ23080226S01 Page 3of 11 1. Technical Information Note: Provide by applicant. 1.1 Applicant and Manufacturer Information Applicant: Fibocom Wireless Inc. Applicant Address: 1101,Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Nanshan, Shenzhen, China Manufacturer: Fibocom Wireless Inc. Manufacturer Address: 1101,Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Nanshan, Shenzhen, China 1.2 Equipment under Test (EUT) Description Product Name: LTE Module Product Serial No.: 4# Hardware Version: V1.1 Software Version: SC218-T6.00.03 Frequency Bands: LTE Band 2: 1850 MHz ~ 1910 MHz LTE Band 4: 1710 MHz ~ 1755 MHz LTE Band 5: 824 MHz ~ 849 MHz LTE Band 7: 2500 MHz ~ 2570 MHz LTE Band 12: 669 MHz ~ 716 MHz LTE Band 13: 777 MHz ~ 787 MHz LTE Band 17: 704 MHz ~ 716 MHz LTE Band 25: 1850 MHz ~ 1915 MHz LTE Band 26: 814 MHz ~ 849 MHz LTE Band 41: 2496 MHz ~ 2690 MHz LTE Band 66: 1710 MHz ~ 1780 MHz LTE Band 71: 663 MHz ~ 698 MHz WLAN 2.4GHz: 2412 MHz ~ 2472 MHz WLAN 5.2GHz: 5180 MHz ~ 5240 MHz WLAN 5.3GHz: 5260 MHz ~ 5320 MHz WLAN 5.5GHz: 5500 MHz ~ 5720 MHz WLAN 5.8GHz: 5745 MHz ~ 5825 MHz Bluetooth: 2402 MHz ~ 2480 MHz Modulation Mode: LTE: QPSK, 16QAM, 64QAM 802.11b: DSSS 802.11a/g/n-HT20/40: OFDM MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.οΌSZ23080226S01 Page 4of 11 802.11ac-VHT20/40/80: OFDM BR+EDR: GFSK(1Mbps), Ο/4-DQPSK(2Mbps), 8-DPSK(3Mbps) Bluetooth LE: GFSK(1Mbps, 2Mbps) Antenna Type: WWAN: Fixed External Antenna WLAN: Fixed External Antenna Bluetooth: Fixed External Antenna Antenna Gain: Frequency Bands Antenna Gain (dBi) LTE Band 2 1.0 LTE Band 4 1.0 LTE Band 5 0.5 LTE Band 7 2.0 LTE Band 12 0.5 LTE Band 13 0.5 LTE Band 17 0.5 LTE Band 25 1.0 LTE Band 26 0.5 LTE Band 41 2.0 LTE Band 66 1.0 LTE Band 71 0.5 WLAN 2.4GHz 2.0 WLAN 5GHz 2.0 Bluetooth 2.0 Note: 1. When the test result is a critical value, we will use the measurement uncertainty give the judgment result based on the 95% confidence intervals. 2. For a more detailed description, please refer to Specification or Userβs Manual supplied by the applicant and/or manufacturer. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.οΌSZ23080226S01 Page 5of 11 1.3 Applied Reference Documents Leading reference documents for testing: Identity Document Title Method determination /Remark FCC 47 CFR Part 2(2.1091) Radio Frequency Radiation Exposure Assessment: mobile devices No deviation KDB 447498 D01v06 General RF Exposure Guidance No deviation Note: Additions to, deviation, or exclusions from the method shall be judged in the "method determination" column of add, deviate or exclude from the specific method shall be explained in tβ¦
Text truncated - open the document above for the full version.
Use rangeοΌ Applicable to Shenzhen Fibocom Wireless Co., Ltd. 5G antenna solution. Electrical SpecificationsοΌ Electrical Specifications 700-1000MHz;1400-6000MHz Material ABS input resistance 50Ξ© Plastic material Rubber cap:ABS Standing wave ratio β€3.0 Adapter 1: ABS Polarization mode Linear polarization Adapter 2:ABS Operating temperature -40 Μ C~+65 Μ C RF cable specifications RG-178 Storage temperature - 40 Μ C~+80 Μ C Connector specifications SMA Male J Connector torque test 200 ~ 1000 g.cm Joint tension test SMAβ₯3 Kg Test conditions and methods: Test conditions andinstruments Test Methods Test Results Test dataοΌ BGS- 036(700- 1000)_30du Frequency (MHz) Directivity (dBi) Avg Gain(dBi) Efficiency (%) Peak Gain(dBi) 700 5.73 -4.12 38.75 0.5 710 5.67 -4.09 39.04 0.5 720 5.17 -3.87 41.02 0.5 730 4.91 -3.71 42.52 1.2 740 4.49 -3.75 42.14 0.74 750 4.81 -3.91 40.62 0.9 760 5.13 -3.93 40.44 1.2 770 5.84 -3.9 40.76 1.94 780 5.48 -3.65 43.11 0.5 790 5.53 -3.34 46.32 2.19 800 3.84 -3.12 48.71 0.72 810 3.38 -2.97 50.49 0.5 820 3.52 -2.82 52.19 0.5 830 3.67 -2.65 54.28 0.5 840 3.67 -2.35 58.15 0.5 850 2.71 -1.91 64.47 0.5 860 1.72 -1.46 71.43 0.26 870 1.85 -1.13 77.15 0.72 880 2.19 -1.02 79.03 1.17 890 2.29 -1.21 75.66 1.08 900 2.24 -1.58 69.49 0.66 910 2.08 -1.83 65.6 0.25 920 1.94 -2.1 61.7 -0.16 930 2.01 -2.33 58.51 -0.32 940 2.29 -2.63 54.6 -0.34 950 2.63 -3.17 48.21 -0.54 960 2.83 -4.02 39.59 -1.19 970 2.86 -5.11 30.86 -2.25 980 2.83 -6.14 24.34 -3.31 990 2.96 -7.09 19.55 -4.13 1000 3.29 -7.55 17.57 -4.26 BGS- 036(1400- 1690)_30du Frequency (MHz) Directivity (dBi) Avg Gain(dBi) Efficiency (%) Peak Gain(dBi) 1400 3.67 -0.82 82.77 2.85 1410 3.49 -0.88 81.6 2.61 1420 3.34 -0.92 80.85 2.42 1430 3.35 -0.76 83.95 2.59 1440 3.51 -0.57 87.7 2.94 1450 3.47 -0.49 89.24 2.98 1460 3.19 -0.51 88.83 2.68 1470 3.48 -0.74 84.33 2.74 1480 3.81 -0.89 81.41 2.92 1490 3.68 -0.98 79.86 2.7 1500 3.63 -0.85 82.17 2.78 1510 3.7 -0.76 84.04 2.94 1520 3.36 -0.73 84.47 2.63 1530 3.61 -0.71 84.83 2.9 1540 3.91 -1.01 79.19 2.9 1β¦
Text truncated - open the document above for the full version.
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 18.75 mW |
