FIBOCOM SU806-LA Hardware Guide Version: V2.0.2 Date: 2022-04-02 Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. FIBOCOM SU806 Series Hardware Guide Page 2 of 79 Copyright Copyright ©2021 Fibocom Wireless Inc. All rights reserved. Without the prior written permission of the copyright holder, any company or individual is prohibited to excerpt, copy any part of or the entire document, or transmit the document in any form. Notice The document is subject to update from time to time owing to the product version upgrade or other reasons. Unless otherwise specified, the document only serves as the user guide. All the statements, information and suggestions contained in the document do not constitute any explicit or implicit guarantee. Trademark The trademark is registered and owned by Fibocom Wireless Inc. FCC Regulatory Compliance Important Notice to OEM integrators 1. This module is limited to OEM installation ONLY. 2. This module is limited to installation in mobile or fixed applications, according to Part 2.1091(b). 3. The separate approval is required for all other operating configurations, including portable configurations with respect to Part 2.1093 and different antenna configurations. 4. For FCC Part 15.31 (h) and (k): The host manufacturer is responsible for additional testing to verify compliance as a composite system. When testing the host device for compliance with Part 15 Subpart B, the host manufacturer is required to show compliance with Part 15 Subpart B while the transmitter module(s) are installed and operating. The modules should be transmitting, and the evaluation should confirm that the module's intentional emissions are compliant (i.e. fundamental and out of band emissions). The host manufacturer must verify that there are no additional unintentional emissions other than what is permitted in Part 15 Subpart B or emissions are complaint with the transmitter(s) rule(s). The Grantee will provide guidance to the host manufacturer for Part 15 B requirements if needed. Important Note Notice that any deviation(s) from the defined parameters of the antenna trace, as described by the instructions, require that the host product manufacturer must notify to Fibocom wires Inc. that they wish to change the antenna trace design. In this case, a Class II permissive change application is required to be filed by the USI, or the host manufacturer can take responsibility through the change in FCC ID (new application) procedure followed by a Class II permissive change application. Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved. FIBOCOM SU806 Series Hardware Guide Page 3 of 79 End Product Labeling When the module is installed in the host device, the FCC/IC ID label must be visible through a window on the final device or it must be visible when an access panel, door or cover is easily re-moved. If not, a second label must be placed on the outside of the final device that contains the following text: “Contains FCC ID: ZMOSU806LA”. The FCC ID can be used only when all FCC compliance requirements are met. Antenna Installation (1) The antenna must be installed such that 20 cm is maintained between the antenna and users, (2) The transmitter module may not be co-located with any other transmitter or antenna. (3) Only antennas of the same type and with equal or less gains as shown below may be used with this module. Other types of antennas and/or higher gain antennas may require additional authorization for operation. In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the ZMOSU806LA cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. Manual Information to the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module. The end user manual shall include all required regulatory information/warning as show in this manual. Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Reproduction forbidden witho…

Text truncated - open the document above for the full version.

Fibocom Wireless Inc. Declaration of Authorization We Name: Fibocom Wireless Inc. Address: 1101,Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Nanshan City: ShenZhen Country: China Declare that: Name Representative of agent: Ms. Rose Liu Agent Company name: BTL Inc. Address: No.3 Jinshagang 1 st Road, Shixia, Dalang Town City: Dong Guan Country: China is authorized to apply for Certification and signing related documents of the following product(s), including 731 form(s): Product description: LTE Module Type designation: SU806-LA Trademark: Fibocom FCC ID: ZMOSU806LA on our behalf. Date: 2022-06-02 City: ShenZhen Name: Lucy Liu Function: Certification Manager Signature: .

Fibocom Wireless Inc. Date: 2022.06.02 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: ZMOSU806LA Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description 4. Schematics 5. Block Diagram 6. Operational Description Tune-up Procedure 17. Tune-up Procedure Bill(s) of Material 18. BOM The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Signature Lucy Liu

Modular Approval Request FCC (KDB 996369 D01 & Part 15.212) FCC ID: ZMOSU806LA Items to be covered by Single modular transmitters. Answer from applicant 1.The modular transmitter must have its own RF shielding. YES, Please refer to External Photos. 2.The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. YES, SU806-LA is used for the function. 3.The modular transmitter must have its own power supply regulation. YES, the modular has its own power supply regulation. 4.The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(b)(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). YES, it is Printed antenna. 5.The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. Yes, the module is tested in a stand-alone configuration as the test photos show. 6.The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number in accordance with 15.212 (a)(1)(vi)(A) / (B). YES, please refer to the exhibition label sample for this module. 7.The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. For example, there are very strict operational and timing requirements that must be met before a transmitter is authorized for operation under Section 15.231. For instance, data transmission is prohibited, except for operation under Section 15.231(e), in which case there are separate field strength level and timing requirements. Compliance with these requirements must be assured. YES, please refer to the user manual. 8.The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 1.1310, 2.1091, 2.1093, and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance. Modular transmitters approved under other Sections of Part 15, when necessary, may also need to address certain RF Exposure concerns, typically by providing specific installation and operating instructions for users, installers and other interested parties to ensure compliance. YES, RF exposure statement is attached in the user manual. Items to be covered by Split modular transmitters. Answer from applicant 1. The modular transmitter must comply with all requirements of a single modular transmitter except for items (1) & (5) of the above single modular approval requirements. 2. Only the radio front end must be shielded. The physical crystal and tuning capacitors may be located external to the shielded radio elements. The interface between the split sections of the modular system must be digital with a minimum signalling amplitude of 150 mV peak-to-peak. 3. Control information and other data may be exchanged between the transmitter control elements and radio front end. 4. The sections of a split modular transmitter must be tested installed in a host device(s) similar to that which is representative of the platform(s) intended for use. 5. Manufacturers must ensure that only transmitter control elements and radio front end components that have been approved together are capable of operating together. The transmitter module must not operate unless it has verified that the installed transmitter control elements and radio front end have been authorized together. Manufacturers may use means including, but not limited to, coding in hardware and electronic signatures in software to meet these requirements, and must describe the methods in their application for equipment authorization. Note: A limited modular approval (LMA) may be granted for single or split modular transmitters that comply partially with the requirements above. Name and surname of applicant (or authorized representative): Lucy Liu Date: 2022-06-02 Signature: ___________________________

Fibocom Wireless Inc. Wi-Fi Channel 12 and 13 Declaration Letter Date: 2022-06-02 We, the undersigned company Company Name: Fibocom Wireless Inc. Address: 1101, Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Nanshan, Shenzhen, China Declare that: Product description: LTE Module Type designation: SU806-LA Brand: Fibocom FCC ID: ZMOSU806LA Only channels 1~11 will be used in USA. Country code selection is disabled. If you have any questions regarding the authorization, please do not hesitate to contact us, thank you~ Sincerely, Signature: ________________________ Name: Lucy Liu Function: Certification Manager

Project No.: 2205C056 Page 3 of 4

Label: Label Location: On the top of the EUT Label Size: 40.5*40.5mm

Project No.: 2205C056 Page 2 of 4 WWAN Ant. WLAN Ant. Test Module Project No.: 2205C056 Page 4 of 4

Report No.: BTL-FCCP-7-2205C056 Page 1 of 6 FCC RF EXPOSURE REPORT FCC ID: ZMOSU806LA This report concerns: Original Grant Project No. : 2205C056 Equipment : LTE Module Brand Name : Fibocom Test Model : SU806-LA Series Model : N/A Applicant : Fibocom Wireless Inc. Address : 1101, Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Nanshan, Shenzhen, China Manufacturer : Fibocom Wireless Inc. Address : 1101, Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Date of Receipt : May 16, 2022 Date of Test : May 18, 2022 ~ Jun. 02, 2022 Issued Date : Jun. 13, 2022 Report Version : R00 Test Sample : Engineering Sample No.: DG20220516109 for BLE and WIFI, DG20220516107 and DG20220516110 for GSM, WCDMA and LTE. Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Grani Zhou Approved by : Steven Lu Add: No. 3 Jinshagang 1st Rd. Shixia, Dalang Town Dongguan City, Guangdong 523792 People’s Republic of China Tel: +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCCP-7-2205C056 Page 2 of 6 REPORT ISSUED HISTORY Report No. Version Description Issued Date Note BTL-FCCP-7-2205C056 R00 Original Report. Jun. 13, 2022 Valid Report No.: BTL-FCCP-7-2205C056 Page 3 of 6 1. TEST FACILITY The test facilities used to collect the test data of WLAN in this report is at the location of No. 3 Jinshagang 1st Rd. Shixia, Dalang Town, Dongguan City, Guangdong, People’s Republic of China. The test facilities used to collect the test data of WWAN in this report is at the location of Room 108, Building 2, No.1, Yile Road, Songshan Lake Zone, Dongguan City, Guangdong, People’s Republic of China. BTL's Registration Number for FCC: 357015 BTL's Designation Number for FCC: CN1240 2. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Filed Antenna: For BT&LE& WLAN 2.4GHz: Ant. Manufacturer P/N Antenna Type Connector Gain (dBi) 1 shenzhen bogesi communication technology co., ltd GHT-019A Dipole SMA Male J 2.3 Note: The antenna gain is provided by the manufacturer. For GSM: Manufacturer P/N Antenna Type Connector Gain (dBi) Note shenzhen bogesi communication technology co., ltd GHT-019A Dipole SMA Male J 1.32 GSM 850 1.93 PCS 1900 Note: The antenna gain is provided by the manufacturer. For WCDMA: Manufacturer P/N Antenna Type Connector Gain (dBi) Note shenzhen bogesi communication technology co., ltd GHT-019A Dipole SMA Male J 1.93 WCDMA Band II 2.86 WCDMA Band IV 1.32 WCDMA Band V Note: The antenna gain is provided by the manufacturer. Report No.: BTL-FCCP-7-2205C056 Page 4 of 6 For LTE: Manufacturer P/N Antenna Type Connector Gain (dBi) Note shenzhen bogesi communication technology co., ltd GHT-019A Dipole SMA Male J 1.93 LTE Band 2 2.86 LTE Band 4 1.32 LTE Band 5 1.07 LTE Band 7 1.58 LTE Band 12 1.58 LTE Band 17 1.52 LTE Band 41 Note: The antenna gain is provided by the manufacturer. Report No.: BTL-FCCP-7-2205C056 Page 5 of 6 3. TEST RESULTS For BT: Antenna Gain (dBi) Antenna Gain (numeric) Max.Tune Up Power (dBm) Max.Tune Up Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 2.3 1.6982 10 10.0000 0.00338 1 Complies For LE: Antenna Gain (dBi) Antenna Gain (numeric) Max.Tune Up Power (dBm) Max.Tune Up Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 2.3 1.6982 4.5 2.8184 0.00095 1 Complies For 2.4GHz: Antenna Gain (dBi) Antenna Gain (numeric) Max.Tune Up Power (dBm) Max.Tune Up Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 2.3 1.6982 20 100.0000 0.03380 1 Complies For GSM: GSM900 Max Burst Average Power (dBm) Max Frame Average Power (dBm) Channel/Frequency(MHz) Channel/Frequency(MHz) 128 / 824.2 128 / 824.2 GSM (CS) 35 25.81 PCS 1900 Max Burst Average Power (dBm) Max Frame Average Power (dBm) Channel/Frequency(MHz) Channel/Frequency(MHz) 512 / 1850.2 512 / 1850.2 GSM (CS) 32 22.81 Note: 1. The frame-averaged power is linearly proportion to the slot number configured and it is linearly scaled the maximum burst-averaged power based on time slots. The calculated method is shown as below: Frame-averaged power=10 x log (Burst-averaged power mW x Slot used/8) 2. Max. Output Power = Max Frame Average Power Band Frequency (MHz) Max.Tune Up Power (dBm) Antenna Gain (dBi) Antenna Gain (linear) Output Power to Antenna Power Density (mW/cm 2 ) Power Density Limit (mW/cm 2 ) Test Result GSM 850 824.2 25.81 1.32 1.36 516.42 0.1027 0.5495 Complies PCS 1900 1850.2 22.81 1.93 1.56 297.85 0.0593 1.0000 Complies Report No.: BTL-FCCP-7-2205C056 Page 6 of 6 For WCDMA: Band Frequency (MHz) Max.Tune Up Power (dBm) Antenna Gain (dBi) Antenna Gain (linear) Output Power to Antenna Power Density (mW/cm 2 ) Power Density Limit (mW/cm 2 ) Test Result WCDMA II 1852.4 25 1.93 1.56 493.17 0.0981 1.0000 Complies WCDMA IV 1712.4 25 2.86 1.93 610.94 0.1215 1.0000 Complies WCDMA V 826.4 25 1.32 1.36 428.55 0.0853 0.5509 Complies For LTE: Band Frequency (MHz) Max.Tune Up Power (dBm) Antenna Gain (dBi) Antenna Gain (linear) Output Power to Antenna Power Density (mW/cm 2 ) Power Density Limit (mW/cm 2 ) Test Result Band 2 1850.7 25 1.93 1.56 493.17 0.0981 1.0000 Complies Band 4 1710.7 25 2.86 1.93 610.94 0.1215 1.0000 Complies Band 5 824.7 25 1.32 1.36 428.55 0.0853 0.5498 Complies Band 7 2502.5 25 1.07 1.28 404.58 0.0805 1.0000 Complies Band 12 699.7 25 1.58 1.44 454.99 0.0905 0.4665 Complies Band 17 706.5 25 1.58 1.44 454.99 0.0905 0.4710 Complies Band 41 2498.5 25 1.52 1.42 448.75 0.0893 1.0000 Complies For the max simultaneous transmission MPE: Ratio Total Limit of Ratio Test Result 2.…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-5-2205C056 Page 1 of 61 FCC Radio Test Report FCC ID: ZMOSU806LA This report concerns: Original Grant Project No. : 2205C056 Equipment : LTE Module Brand Name : Fibocom Test Model : SU806-LA Series Model : N/A Applicant : Fibocom Wireless Inc. Address : 1101, Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Nanshan, Shenzhen, China Manufacturer : Fibocom Wireless Inc. Address : 1101, Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Nanshan, Shenzhen, China Date of Receipt : May 16, 2022 Date of Test : May 18, 2022 ~ Jun. 15, 2022 Issued Date : Jun. 15, 2022 Report Version : R01 Test Sample : Engineering Sample No.: DG20220516109 Standard(s) : FCC CFR Title 47, Part 15, Subpart C FCC KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10-2013 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Grani Zhou Approved by : Steven Lu Add: No. 3 Jinshagang 1st Rd. Shixia, Dalang Town Dongguan City, Guangdong 523792 People‟s Republic of China Tel: +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCCP-5-2205C056 Page 2 of 61 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture‟s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, A2LA, or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL‟s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer‟s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-5-2205C056 Page 3 of 61 Table of Contents Page REPORT ISSUED HISTORY 6 1 . SUMMARY OF TEST RESULTS 7 1.1 TEST FACILITY 8 1.2 MEASUREMENT UNCERTAINTY 8 1.3 TEST ENVIRONMENT CONDITIONS 9 2 . GENERAL INFORMATION 10 2.1 GENERAL DESCRIPTION OF EUT 10 2.2 DESCRIPTION OF TEST MODES 11 2.3 PARAMETERS OF TEST SOFTWARE 11 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 2.5 SUPPORT UNITS 12 3 . AC POWER LINE CONDUCTED EMISSIONS 13 3.1 LIMIT 13 3.2 TEST PROCEDURE 13 3.3 DEVIATION FROM TEST STANDARD 13 3.4 TEST SETUP 14 3.5 EUT OPERATING CONDITIONS 14 3.6 TEST RESULTS 14 4 . RADIATED EMISSIONS 15 4.1 LIMIT 15 4.2 TEST PROCEDURE 16 4.3 DEVIATION FROM TEST STANDARD 17 4.4 TEST SETUP 17 4.5 EUT OPERATING CONDITIONS 18 4.6 TEST RESULT - 9 KHZ TO 30 MHZ 18 4.7 TEST RESULT - 30 MHZ TO 1000 MHZ 18 4.8 TEST RESULT - ABOVE 1000 MHZ 18 5 . BANDWIDTH 19 5.1 LIMIT 19 5.2 TEST PROCEDURE 19 5.3 DEVIATION FROM STANDARD 19 5.4 TEST SETUP 19 Report No.: BTL-FCCP-5-2205C056 Page 4 of 61 Table of Contents Page 5.5 EUT OPERATION CONDITIONS 19 5.6 TEST RESULTS 19 6 . MAXIMUM OUTPUT POWER 20 6.1 LIMIT 20 6.2 TEST PROCEDURE 20 6.3 DEVIATION FROM STANDARD 20 6.4 TEST SETUP 20 6.5 EUT OPERATION CONDITIONS 20 6.6 TEST RESULTS 20 7 . CONDUCTED SPURIOUS EMISSION 21 7.1 LIMIT 21 7.2 TEST PROCEDURE 21 7.3 DEVIATION FROM STANDARD 21 7.4 TEST SETUP 21 7.5 EUT OPERATION CONDITIONS 21 7.6 TEST RESULTS 21 8 . POWER SPECTRAL DENSITY 22 8.1 LIMIT 22 8.2 TEST PROCEDURE 22 8.3 DEVIATION FROM STANDARD 22 8.4 TEST SETUP 22 8.5 EUT OPERATION CONDITIONS 22 8.6 TEST RESULTS 22 9 . MEASUREMENT INSTRUMENTS LIST 23 10 . EUT TEST PHOTO 25 APPENDIX A - AC POWER LINE CONDUCTED EMISSIONS 30 APPENDIX B - RADIATED EMISSION - 9 KHZ TO 30 MHZ 33 APPENDIX C - RADIATED EMISSION - 30 MHZ TO 1000 MHZ 38 APPENDIX D - RADIATED EMISSION - ABOVE 1000 MHZ 41 APPENDIX E - BANDWIDTH 54 APPENDIX F - MAXIMUM OUTPUT POWER 56 Report No.: BTL-FCCP-5-2205C056 Page 5 of 61 Table of Contents Page APPENDIX G - CONDUCTED SPURIOUS EMISSION 58 APPENDIX H - POWER SPECTRAL DENSITY 60 Report No.: BTL-FCCP-5-2205C056 Page 6 of 61 REPORT ISSUED HISTORY Report No. Version Description Issued Date Note BTL-FCCP-5-2205C056 R00 Original Report. Jun. 13, 2022 Invalid BTL-FCCP-5-2205C056 R01 Updated AC Power Line Conducted Emissions and Radiated Emissions(9 kHz to 30 MHz) test items. Jun. 15, 2022 Valid Report No.: BTL-FCCP-5-2205C056 Page 7 of 61 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC CFR Title 47, Part 15, Subpart C Standard(s) Section Test Item Test Result Judgment Remark 15.207 AC Power Line Conducted Emissions APPENDIX A PASS ------ 15.247(d) 15.205(a) 15.209(a) Radiated Emissions APPENDIX B APPENDIX C APPENDIX D PASS ------ 15.247(a)(2) Bandwidth APPENDIX E PASS ------ 15.247(b)(3) Maximum Output Power APPENDIX F PASS ------ 15.2…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-6-2205C056 Page 1 of 92 FCC Radio Test Report FCC ID: ZMOSU806LA This report concerns: Original Grant Project No. : 2205C056 Equipment : LTE Module Brand Name : Fibocom Test Model : SU806-LA Series Model : N/A Applicant : Fibocom Wireless Inc. Address : 1101, Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Nanshan, Shenzhen, China Manufacturer : Fibocom Wireless Inc. Address : 1101, Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Nanshan, Shenzhen, China Date of Receipt : May 16, 2022 Date of Test : May 18, 2022 ~ Jun. 15, 2022 Issued Date : Jun. 15, 2022 Report Version : R01 Test Sample : Engineering Sample No.: DG20220516109 Standard(s) : FCC CFR Title 47, Part 15, Subpart C FCC KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10-2013 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Grani Zhou Approved by : Steven Lu Add: No. 3 Jinshagang 1st Rd. Shixia, Dalang Town Dongguan City, Guangdong 523792 People‟s Republic of China Tel: +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCCP-6-2205C056 Page 2 of 92 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture‟s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, A2LA, or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL‟s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer‟s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-6-2205C056 Page 3 of 92 Table of Contents Page REPORT ISSUED HISTORY 6 1 . SUMMARY OF TEST RESULTS 7 1.1 TEST FACILITY 8 1.2 MEASUREMENT UNCERTAINTY 8 1.3 TEST ENVIRONMENT CONDITIONS 9 2 . GENERAL INFORMATION 10 2.1 GENERAL DESCRIPTION OF EUT 10 2.2 DESCRIPTION OF TEST MODES 11 2.3 PARAMETERS OF TEST SOFTWARE 12 2.4 DUTY CYCLE 13 2.5 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 14 2.6 SUPPORT UNITS 14 3 . AC POWER LINE CONDUCTED EMISSIONS 15 3.1 LIMIT 15 3.2 TEST PROCEDURE 15 3.3 DEVIATION FROM TEST STANDARD 15 3.4 TEST SETUP 16 3.5 EUT OPERATION CONDITIONS 16 3.6 TEST RESULTS 16 4 . RADIATED EMISSIONS 17 4.1 LIMIT 17 4.2 TEST PROCEDURE 18 4.3 DEVIATION FROM TEST STANDARD 19 4.4 TEST SETUP 19 4.5 EUT OPERATION CONDITIONS 20 4.6 TEST RESULTS - 9 KHZ TO 30 MHZ 20 4.7 TEST RESULTS - 30 MHZ TO 1000 MHZ 20 4.8 TEST RESULTS - ABOVE 1000 MHZ 20 5 . BANDWIDTH 21 5.1 LIMIT 21 5.2 TEST PROCEDURE 21 5.3 DEVIATION FROM STANDARD 21 5.4 TEST SETUP 21 Report No.: BTL-FCCP-6-2205C056 Page 4 of 92 Table of Contents Page 5.5 EUT OPERATION CONDITIONS 21 5.6 TEST RESULTS 21 6 . MAXIMUM OUTPUT POWER 22 6.1 LIMIT 22 6.2 TEST PROCEDURE 22 6.3 DEVIATION FROM STANDARD 22 6.4…
