ZMXKAERKT1000The GSM fixed wireless phone

User Manual Thank you for buying our products. KT1000 Fixed Wireless Phone User Manual V1.0 1 To reduce the risk of fire, electric shock and /or personal injury, please read this manual before using this unit. You must use the phone under the network cover. Don't use it where there is mark of close radio receiving or translating unit, including hospital, gas station and chemical storage, etc. Welcome to use the GSM fixed wireless phone (business type), which combines phone, send and receive text messages, clock display, caller ID with other functions, It adopts advanced Module, with new appearance, good performance and reliable quality. Easily installation, more flexible and convenient compared with corded phone. It can be used as long as there is power supply, and area covered by GSM network. This product meets the national standard indicators, the standards of implementation: YD/T1626-2007 fixed wireless telephone technical requirements and test methods. Changes or modifications made in the desktop radio phone, not expressly approved by Kaer, will void the user’s authority to operate the equipment. KT1000 Fixed Wireless Phone User Manual V1.0 2 Contents 1 SAFETY INSTRUCTIONS.................. .................................... .................. 3 33 3 2 BEFORE GETTING STARTED.............. ............................ .............. 4 44 4 3 PACKAGE CONTENTS.................... ........................................ .................... 5 55 5 4 FEATURES AND SPECIFICATIONS......... .................. ......... 5 55 5 5 READY FOR INSTALLATION............... .............................. ............... 8 88 8 6 GENERAL APPEARANCES............... .............................. ............... 12 1212 12 6.1 KEYS LOCATION.................................................12 6.2 KEYS DESCRIPTION............................................12 7 FUNCTION OPERATIONS................. .................................. ................. 15 1515 15 7.1 MAKE A CALL......................................................15 7.2 RECEIVE A CALL.................................................16 7.3 END A CALL.........................................................16 7.4 REJECT THE INCOMING CALL.............................16 7.5 REDIAL................................................................16 7.6 DIALED CALLING.................................................16 7.7 HANDS FREE.......................................................16 7.8 EDIT MESSAGE....................................................17 8 COMMON PROBLEMS AND CAUSES...... ............ ...... 17 1717 17 KT1000 Fixed Wireless Phone User Manual V1.0 3 1 Safety Instructions Warning: Read the safety precautions and the user guide before use. Explain their contents and the potential hazard associated with using the telephone to your children. Liquids of any kind Don’t expose your phone to water, rain, extreme humidity, sweat, or other moisture. Dust and dirt Don’t expose your phone to dust, dirt, sand, food, or other inappropriate materials. Extreme heat or cold Avoid temperatures below -10°C/14°F or above 45°C/113°F. Cleaning solutions To clean your phone, use only a dry soft cloth. Don’t use alcohol or other cleaning solutions. KT1000 Fixed Wireless Phone User Manual V1.0 4 Microwaves Don’t try to dry your phone in a microwave oven. The ground Don’t drop your phone. 2 Before Getting Started Read and understand all instructions before using the phone, follow the warnings and instructions marked on the product.
This unit is an electrical device; do not use the phone when it is drenched in water or liquids. Unplug the line cord by disconnecting the modular jack before removing the phone from the liquid.
Do not place the phone near by bathtub, shower or similar environments, to avoid electrical shock.
Unplug the phone before cleaning it; do not use liquid cleaners or aerosol cleaners.
Do not use the telephone to report a gas leak in the vicinity of the leak. KT1000 Fixed Wireless Phone User Manual V1.0 5
Do not open the equipment
Our company 4.6V/1A power adapter and batteries should be used. Improper battery replacement or use other power supply devices will be dangerous
The charging time should be 12 hours for the first using. 3 Package contents 1) One KT1000 phone base unit 2) One Handset 3) One Coiled handset connecting cord 4) One Antenna 5) One universal power adapter (Model: NLA100046W1U1; Input: 100-240V; Output: 4.6V/1A) 6) One set of Battery 7) One User Manual 4 Features and Specifications Basic Features 1. External Antenna KT1000 Fixed Wireless Phone User Manual V1.0 6 2. Large 128*64 Dot-Matrix Graphic LCD 3. View Size: 53.2*28.2mm 4. Yellow-Green LCD Backlight 5. Speaker Phone for Ringing and Hand-Free Mode 6. 28 Keys with On/Off Key 7. Alarm Clock 8. Speed-Dialing 9. Two-Way SMS Messaging 10. Adapter AC Input : 100 ~ 240 VAC, 50~60Hz 11. Adapter DC Output : 4.6VDC @1000mA 12. Battery Capacity : 3.7V/800mAh Li+ Battery 13. Ultra Long Battery Talk and Standby Time 14. Antenna Conn Type: TNC 15. Size: 220(L) x 180(W) x 90(H) mm 16. Weight : < 1.0kg SMS Features 1. Mass SMS 2. Voice SMS Phonebook Features KT1000 Fixed Wireless Phone User Manual V1.0 7 1. Quick Look in Phonebook Call history 1. Incoming Calls (10pcs ) 2. Outgoing Calls (10pcs) 3. Missed Calls (10pcs) Call Features 1. Emergency call 2. Caller ID 3. Call Waiting, Forwarding, 3-Way Calling Lock Features 1. Lock card 2. Lock phone 3. Lock net Selectable Features 1. Desktop or Wall-mounted 2. Languages: English, Russian, Spanish 3. Casing Colors: grey, black blue KT1000 Fixed Wireless Phone User Manual V1.0 8 Technical Specifications Items Parameters Emission Power 33dbm±2db@900MHz （850MHz optional） 30dbm±2db@1800MHz (1900MHz optional) Carrier Spacing 200KHz Frequency Range GSM900/1800MHz (GSM850/1900MHz optional) Receiver Sensitivity ＜-104dBm Ambient Noise ≤ 60dB(A) Environment Temperature -10°C~ +50°C Humidity 10%~95% Air Pressure 86~106KPa 5 Ready…
