ZMXKT2000CDMA Fixed Wireless phone

To reduce the risk of fire, electric shock and /or personal injury, please read this manual before using this unit. You must use the phone under the network cover. Don't use it where there is mark of close radio receiving or translating unit, including hospital, gas station and chemical storage, etc. Welcome to use the CDMA fixed wireless phone (business type), which combines phone, send and receive text messages, clock display, caller ID with other functions, It adopts advanced Module, with new appearance, good performance and reliable quality. Easily installation, more flexible and convenient compared with corded phone. It can be used as long as there is power supply, and area covered by CDMA network. This product meets the national standard indicators, the standards of implementation: YD/T1626-2007 fixed wireless telephone technical requirements and test methods. Changes or modifications made in the desktop radio phone, not expressly approved by Kaer, will void the user’s authority to operate the equipment. 1 Contents 1 SAFETY INSTRUCTIONS .................. 2 2 BEFORE GETTING STARTED .............. 3 3 PACKAGE CONTENTS .................... 4 4 FEATURES AND SPECIFICATIONS ......... 4 5 READY FOR INSTALLATION ............... 6 6 GENERAL APPEARANCES ................10 6.1 KEYS LOCATION ................................................. 10 6.2 KEYS DESCRIPTION ............................................ 10 7 FUNCTION OPERATIONS ..................12 7.1 MAKE A CALL ...................................................... 12 7.2 RECEIVING A CALL .............................................. 13 7.3 ENDING A CALL ................................................... 13 7.4 REJECT THE INCOMING CALL ............................. 13 7.5 REDIAL ................................................................ 13 7.6 DIALED CALLING ................................................. 13 7.7 HANDS FREE ....................................................... 13 7.8 SPEAKER VOLUME ............................................. 14 7.9 EDITING MESSAGE .............................................. 14 7.10 MANUALLY SETUP THE NO R-UIM ................... 14 8 COMMON PROBLEMS AND CAUSES .......15 2 1 Safety Instructions Warning: Read the safety precautions and the user guide before use. Explain their contents and the potential hazard associated with using the telephone to your children. Liquids of any kind Don’t expose your phone to water, rain, extreme humidity, sweat, or other moisture. Dust and dirt Don’t expose your phone to dust, dirt, sand, food, or other inappropriate materials. Extreme heat or cold Avoid temperatures below -10°C/14°F or above 45°C/113°F. Cleaning solutions To clean your phone, use only a dry soft cloth. Don’t use alcohol or other cleaning solutions. Microwaves Don’t try to dry your phone in a microwave oven. 3 The ground Don’t drop your phone. 2 Before Getting Started Read and understand all instructions before using the phone, follow the warnings and instructions marked on the product. ÿ This unit is an electrical device; do not use the phone when it is drenched in water or liquids. Unplug the line cord by disconnecting the modular jack before removing the phone from the liquid. ÿ Do not place the phone near by bathtub, shower or similar environments, to avoid electrical shock. ÿ Unplug the phone before cleaning it; do not use liquid cleaners or aerosol cleaners. ÿ Do not use the telephone to report a gas leak in the vicinity of the leak. ÿ Do not open the equipment ÿ Our company special 4.6V/1A power adapter and batteries should be used. Improper battery replacement or use other power supply devices will be dangerous ÿ The phone uses proprietary encryption UIM card, do not try to move the card to use it; also do not try to convert other UIM card into the phone to use, it will cause the UIM card be locked or 4 permanent damaged ÿ The charging time should be 12 hours for the first using. 3 Package contents 1) One KT2000 phone base unit 2) One handset 3) One coiled handset connecting cord 4) One antenna 5) One universal power adaptor 6) One set of battery 7) One user manual 4 Features and Specifications Basic Features 1. External antenna 2. Large 128*64 Dot-Matrix Graphic LCD 3. R-UIM or No R-UIM 4. View Size: 53.2*28.2mm 5. Yellow-Green LCD Backlight 6. Speaker Phone for Ringing and Hand-Free Mode 7. 28 Keys with On/Off Key 8. Schedule, Alarm Clock, Calculator 9. Speed-Dialing 10. Two-Way SMS Messaging 11. Adapter AC Input : 100 ~ 240 VAC, 50~60Hz 5 12. Adapter DC Output : 4.6VDC @1000mA 13. Battery Capacity : 3.7V/800mAh Li+ Battery 14. Ultra Long Battery Talk and Standby Time 15. Antenna Conn Type: TNC 16. Size: 215(L) x 172(W) x 80(H) mm 17. Weight : < 1.0kg SMS Features 1. 200-Items SMS + SMS in UIM (if used) Phonebook Features 1. 200-Entry Contacts + Contacts in UIM (if used) 2. Quick Look in Phonebook 3. Contact Group: Family, Friends, Colleagues, Business, Classmates, Others Call history 1. Incoming Calls (10pcs ) 2. Outgoing Calls (10pcs) 3. Missed Calls (10pcs) Call Features 1. Emergency call 2. Caller ID 3. Call Waiting, Forwarding Customized Features 1. Lock card 6 2. Lock phone 3. Lock zone Selectable Features 1. Desktop or Wall-mounted 2. Casing Colors: grey, black blue Technical Specifications Items Parameters Emission Power 23 dBm Frequency Range CDMA 800MHz Receiver Sensitivity < -104dBm Environment Temperature -10°C~ +50°C Humidity 0%~95% Air Pressure 86~106KPa 5 Ready for Installation ÿ Install UIM card well (Don’t install it when power on). ÿ Power on: Insert one end of adapter into power jack, the other into the phone jack. ÿ To void that the power failure stop your normal conversation, you are recommended to install private battery. ÿ Battery installation: Open the battery cover, first plug the Li-ion battery into the battery connector inside the battery compartment, and then pace it inside the battery compartment. 7 Fix the battery by foam-rubber cushion. Finally, c…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 SHANDONG KAER ELECTRIC CO., LTD No. 58, Dalian Road, Weihai, Shandong, China 2015-1-25 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, SHANDONG KAER ELECTRIC CO., LTD hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): FCC ID: ZMXKT2000 Model: KT2000 Product name: CDMA Fixed Wireless phone Sincerely, signature : name / title: Albert Fu / Department Head address: No. 58, Dalian Road, Weihai, Shandong, China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 SHANDONG KAER ELECTRIC CO., LTD No. 58, Dalian Road, Weihai, Shandong, China 2015-1-25 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: ZMXKT2000 We hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description BOM The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, signature : name / title: Albert Fu / Department Head address: No. 58, Dalian Road, Weihai, Shandong, China Tune up procedure

Label location Model No.: KT2000 FCC ID: ZMXKT2000 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Antenna

FCC ID: A7AG3100-R2 1. RF EXPOSURE EVALUATION 1.1. Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. FCC ID: A7AG3100-R2 1.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 1.3. Test Result of RF Exposure Evaluation Channel Frequency (MHz) Maximum Target Value (dBm) Maximum Target Value (mW) Antenna Gain (dBi) Power Density at R=20cm (mW/cm2) Limit (mW /cm 2 ) Res ult CDMA800 23.00 199.53 5 0.12558 0.551 Pass

FCC ID: ZMXKT2000 Keyway Testing Technology Co., Ltd. Report No. 15KWE012365F Page 1 of 23 FCC TEST REPORT for Shandong Kaer Electric Co., Ltd CDMA Fixed Wireless phone Model Number: KT2000 FCC ID: ZMXKT2000 Prepared for : Shandong Kaer Electric Co., Ltd Address : No. 58, Dalian Road, Weihai, Shandong, China Prepared by : Keyway Testing Technology Co., Ltd. Address : Baishun Industrial Zone, Zhangmutou Town, Dongguan, Guangdong, China Tel: 86-769-8718 2258 Fax: 86-769-8718 1058 Report No. : 15KWE012365F Date of Test : Jan. 19~23, 2015 Date of Report : Jan. 23, 2015 FCC ID: ZMXKT2000 Keyway Testing Technology Co., Ltd. Report No. 15KWE012365F Page 2 of 23 TABLE OF CONTENTS Test Report Declaration Page 1. TEST SUMMARY ........................................................................................................................ 4 2. GENERAL PRODUCT INFORMATION........................................................................................ 5 2.1. Product Function .................................................................................................................. 5 2.2. Description of Device (EUT) ................................................................................................. 5 2.3. Difference between Model Numbers..................................................................................... 5 2.4. Test Supporting System ....................................................................................................... 5 2.5. Independent Operation Modes ............................................................................................. 5 2.6. Test Facilities ....................................................................................................................... 5 2.7. List of Test and Measurement Instruments ........................................................................... 6 3. TEST SET-UP AND OPERATION MODES ................................................................................. 7 3.1. Principle of Configuration Selection ...................................................................................... 7 3.2. Block Diagram of Test Set-up ............................................................................................... 7 3.3. Test Operation Mode and Test Software .............................................................................. 7 3.4. Special Accessories and Auxiliary Equipment ...................................................................... 7 3.5. Countermeasures to Achieve EMC Compliance ................................................................... 7 4. EMISSION TEST RESULTS ........................................................................................................ 8 4.1. Conducted RF Output Power................................................................................................ 8 4.2. Occupied Bandwidth ............................................................................................................ 9 4.3. Frequency Stability ............................................................................................................. 11 4.4. Band Edge ......................................................................................................................... 13 4.5. Spurious Radiated Emissions .............................................................................................. 17 4.6. Spurious Emissions at Antenna Terminals ......................................................................... 20 5. PHOTOGRAPHS OF TEST SET-UP ......................................................................................... 22 6. PHOTOGRAPHS OF THE EUT ................................................................................................. 23 FCC ID: ZMXKT2000 Keyway Testing Technology Co., Ltd. Report No. 15KWE012365F Page 3 of 23 Keyway Testing Technology Co., Ltd. Applicant: Address: Shandong Kaer Electric Co., Ltd No. 58, Dalian Road, Weihai, Shandong, China Manufacturer: Address: Shandong Kaer Electric Co., Ltd No. 58, Dalian Road, Weihai, Shandong, China E.U.T: CDMA Fixed Wireless phone Model Number: KT2000 Trade Name: Serial No.: ------ Date of Receipt: Jan. 19, 2015 Date of Test: Jan. 19~23, 2015 Test Specification: FCC CFR Title 47 Part 2: 2013 FCC CFR Title 47 Part22 Subpart H: 2013 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Jan. 23, 2015 Tested by: Reviewed by: Approved by: Jack Bu / Engineer Andy Gao / Supervisor Jade Yang/ Supervisor Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Keyway Testing Technology Co., Ltd. FCC ID: ZMXKT2000 Keyway Testing Technology Co., Ltd. Report No. 15KWE012365F Page 4 of 23 1.TEST SUMMARY Test Items Test Requirement Result Conducted RF Output Power 2.1046, 22.913 PASS Occupied Bandwidth 2.1049, 22.917 PASS Spurious Radiated Emissions 2.1053, 22.917 PASS Spurious Emissions at Antenna Terminals 2.1051, 22.917 PASS Band Edge 2.1051,2.1057 22.917, 24.238 PASS Transmitter Radiated Power (EIPR/ERP) 22.913 PASS Frequency Stability 2.1055 PASS Measurement method according to TIA/EIA 603.D-2010 FCC ID: ZMXKT2000 Keyway Testing Technology Co., Ltd. Report No. 15KWE012365F Page 5 of 23 2. GENERAL PRODUCT INFORMATION 2.1. Product Function Refer to Technical Construction Form and User Manual. 2.2. Description of Device (EUT) Product Name: CDMA Fixed Wireless phone Model No.: KT2000 Operation Frequency: CDMA 800MHz: 824 - 849MH Modulation technology: QPSK Antenna Type: External Antenna Antenna gain: 5dBi Power supply: DC 4.6V from adapter Rechargeable lithium-ion battery 3.7V Adapter Manufacturer: Shandong Kaer Electric Co., Ltd Model:NLA1000…

Text truncated - open the document above for the full version.

Radiated Emission
