ZMYV2ACDB203G Femtocell

9361 Home Cell V2.0 4 Channel Small Cell Getting Started Guide 9361 Home Cell V2 - Getting Started Guide SAFETY NOTES 1 GENERAL: Please read this Getting Started Guide carefully before using the 9361 Home Cell V2. The 9361 Home Cell V2’s purpose is to provide improved mobile signal coverage inside your home. Do not use this device for any other purpose, as doing so may be dangerous. PLACEMENT: The 9361 Home Cell V2 and all its components (including cables and power adaptor) should be placed in a dry, indoor area, at elevated heights such as on top of shelves, cabinets, etc. It should be kept away from any wet or damp environments; such as kitchens, bathrooms, laundry rooms or any other areas with exposure to moisture, sprays, drips, or running water. For the safety of stored data, it should not be placed near magnetic devices such as audio or video tapes, diskettes or credit cards. While in service, people should stand back at least 20 cm from the device’s antenna and the antenna should not be collocated with any another antenna or transmitting device. MEDICAL DEVICES: The 9361 Home Cell V2 contains a radio transmitter similar to a Wi-fi transmitter. Medical devices such as pacemakers and hearing aids may be affected when using this device. Please contact your General Practitioner for additional safety guidelines. EMERGENCY: The 9361 Home Cell V2 does not operate during instances of power loss. To make emergency calls, please use a mobile or land line phones. POWER SUPPLY: Only use the Power Adaptor provided with your device; do not attempt to use another power adaptor. Ensure that the power adaptor is always easily accessible and that the voltage specified corresponds to the power socket to which you connect it. In case of power loss (and therefore loss of service), all mobile calls, including emergency calls, will be redirected automatically to the default mobile (carrier) network. If you have no mobile network coverage at home and need to make an emergency call, please use a land line. In case of a thunderstorm, please disconnect the device to avoid damaging it. DISPOSAL & RECYCLING: To facilitate disposal and/or recycling, please respect the sorting rules of your country or region for this kind of device. European regulations require the disposal of this device at sales points or at designated collection points such as drop-off centers, etc. 2 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party respon- sible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. SAFETY NOTES TX Output Power 9361 Home Cell V2.0 1700MHz 100mW Model 9361 Home Cell V2.0 1900/850MHz 100mW100mW 20mW 100mW 20mW 9361 Home Cell V2.0 1900/850MHz 20mW 9361 Home Cell V2.0 1700MHz 100mW 9361 Home Cell V2.0 1700MHz 20mW 9361 Home Cell V2 - Getting Started Guide SAFETY NOTES Industry Canada statement This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. French translation: Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable. IMPORTANT NOTE: Radiation Exposure Statement: This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. French: NOTE IMPORTANTE: (Pour l'utilisation de dispositifs mobiles) Déclaration d'exposition aux radiations: Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de distance entre la source de rayonnement et votre corps. 3 CONTENTS 4 www.alcatel-lucent.com Welcome .........................…

Text truncated - open the document above for the full version.

Federal Communications Commission Authorization and Evaluation Division Confidentiality Request FCC ID: ZMYV2ACDB20 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram/ Part List Operating description/ Tune-Up procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, _________________________________ Yi Wang/ Section Manager Telephone Number: +886-3-577-7998 Email: [email protected] MitraStar Technology Corporation 2011/6/28

Power of Attorney To whom it may concern: We, MitraStar Technology Corporation hereby authorize BV CPS (H.K.) Ltd., Taoyuan Branch of Taiwan to act on our behalf in all matters relating to all processes required in the FCC Part 22/24 approval and any communication needed with the national authority. Any and all acts carried out by BV CPS (H.K.) Ltd., Taoyuan Branch of Taiwan on our behalf shall have the same effects as acts of our own. FCC ID: ZMYV2ACDB20 If you have questions regarding the authorization or need further information, please don’t hesitate to contact us. Thank you! Sincerely yours, ___________________ Yi Wang/ Section Manager Telephone Number: +886-3-577-7998 Email: [email protected] MitraStar Technology Corporation 2011/6/28

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3

LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label here



Page 4 Page 5 Page 6 Page 7 Page 8 Page 9 Page 10 Page 11

Report No.: SA110422E04 Report Format Version 4.0.0 1 RF EXPOSURE REPORT REPORT NO.: SA110422E04 MODEL NO.: 9361 Home Cell V2.0 1900/850MHz 20mW ACCORDING: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 APPLICANT: MitraStar Technology Corporation ADDRESS: No. 6, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan (R.O.C.) ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. Report No.: SA110422E04 Report Format Version 4.0.0 2 TABLE OF CONTENTS RELEASE CONTROL RECORD................................................................................... 3 1. CERTIFICATION.................................................................................................. 4 2. RF EXPOSURE LIMIT ......................................................................................... 5 3. MPE CALCULATION FORMULA ......................................................................... 5 4. CLASSIFICATION................................................................................................ 5 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER....................... 5 Report No.: SA110422E04 Report Format Version 4.0.0 3 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED Original release NA May 17, 2011 Report No.: SA110422E04 Report Format Version 4.0.0 4 1. CERTIFICATION PRODUCT: 3G Femtocell MODEL: 9361 Home Cell V2.0 1900/850MHz 20mW BRAND: Alcatel-Lucent APPLICANT: MitraStar Technology Corporation TESTED: Apr. 27 ~ May 12, 2011 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (model: 9361 Home Cell V2.0 1900/850MHz 20mW) have been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE :May 17, 2011 Pettie Chen / Specialist APPROVED BY : , DATE :May 17, 2011 Gary Chang / Assistant Manager Report No.: SA110422E04 Report Format Version 4.0.0 5 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r2) where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER FREQUENCY BAND (MHz) ERP (dBm) EIRP (dBm) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 871.4 ~ 891.6 16.5 18.65 20 0.015 0.581 1932.4 ~ 1987.6 - 17.30 20 0.011 1.00

Report No.: RF110422E04 1 Report Format Version 4.0.0 FCC TEST REPORT (PART 22) REPORT NO.: RF110422E04 MODEL NO.: 9361 Home Cell V2.0 1900/850MHz 20mW FCC ID: ZMYV2ACDB20 RECEIVED: Apr. 22, 2011 TESTED: Apr. 27 ~ May 12, 2011 ISSUED: May 17, 2011 APPLICANT: MitraStar Technology Corporation ADDRESS: No. 6, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan (R.O.C.) ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 46 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product, certification, approval or endorsement by TAF or any government agency. The test results in the report only apply to the tested sample. Report No.: RF110422E04 2 Report Format Version 4.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD..............................................................................................4 1 CERTIFICATION ........................................................................................................5 2 SUMMARY OF TEST RESULTS ................................................................................6 2.1 MEASUREMENT UNCERTAINTY .............................................................................6 3 GENERAL INFORMATION.........................................................................................7 3.1 GENERAL DESCRIPTION OF EUT...........................................................................7 3.2 DESCRIPTION OF TEST MODES.............................................................................8 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST ........................................................8 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL.............................9 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS .......................................... 11 3.4 DESCRIPTION OF SUPPORT UNITS ..................................................................... 11 4 TEST TYPES AND RESULTS ..................................................................................12 4.1 OUTPUT POWER MEASUREMENT .......................................................................12 4.1.1 LIMITS OF OUTPUT POWER MEASUREMENT.....................................................12 4.1.2 TEST INSTRUMENTS .............................................................................................13 4.1.3 TEST PROCEDURES ..............................................................................................14 4.1.4 TEST SETUP ...........................................................................................................15 4.1.5 EUT OPERATING CONDITIONS .............................................................................15 4.1.6 TEST RESULTS .......................................................................................................16 4.2 FREQUENCY STABILITY MEASUREMENT ...........................................................17 4.2.1 LIMITS OF FREQUENCY STABILIITY MEASUREMENT ........................................17 4.2.2 TEST INSTRUMENTS .............................................................................................17 4.2.3 TEST PROCEDURE ................................................................................................18 4.2.4 TEST SETUP ...........................................................................................................18 4.2.5 TEST RESULTS .......................................................................................................19 4.3 OCCUPIED BANDWIDTH MEASUREMENT...........................................................20 4.3.1 LIMITS OF OCCUPIED BANDWIDTH MEASUREMENT ........................................20 4.3.2 TEST INSTRUMENTS .............................................................................................20 4.3.3 TEST SETUP ...........................................................................................................20 4.3.4 TEST PROCEDURES ..............................................................................................21 4.3.5 EUT OPERATING CONDITION ...............................................................................21 4.3.6 TEST RESULTS .......................................................................................................22 4.4 BAND EDGE MEASUREMENT ...............................................................................23 4.4.1 LIMITS OF BAND EDGE MEASUREMENT.............................................................23 4.4.2 TEST INSTRUMENTS .............................................................................................23 4.4.3 TEST SETUP ...........................................................................................................23 4.4.4 TEST PROCEDURES ..............................................................................................24 4.4.5 EUT OPERATING CONDITION ...............................................................................24 4.4.6 TEST RESULTS .......................................................................................................25 4.5 CONDUCTED SPURIOUS EMISSIONS..................................................................26 4.5.1 LIMITS OF CONDUCTED SPURIOUS EMISSIONS MEASUREMENT ..................26 4.5.2 TEST INSTRUMENTS .............................................................................................26 4.5.3 TEST PROCEDURE ................................................................................................27 4.5.4 TEST SETUP ........................................................................…

Text truncated - open the document above for the full version.

Report No.: RF110422E04-1 1 Report Format Version 4.0.0 FCC TEST REPORT (Part 24) REPORT NO.: RF110422E04-1 MODEL NO.: 9361 Home Cell V2.0 1900/850MHz 20mW FCC ID: ZMYV2ACDB20 RECEIVED: Apr. 22, 2011 TESTED: Apr. 27 ~ May 12, 2011 ISSUED: May 17, 2011 APPLICANT: MitraStar Technology Corporation ADDRESS: No. 6, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan (R.O.C.) ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 45 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product, certification, approval or endorsement by TAF or any government agency. The test results in the report only apply to the tested sample. Report No.: RF110422E04-1 2 Report Format Version 4.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD..............................................................................................4 1 CERTIFICATION .......................................................................................................5 2 SUMMARY OF TEST RESULTS ...............................................................................6 2.1 MEASUREMENT UNCERTAINTY ............................................................................6 3 GENERAL INFORMATION........................................................................................7 3.1 GENERAL DESCRIPTION OF EUT ..........................................................................7 3.2 DESCRIPTION OF TEST MODES ............................................................................8 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST .......................................................8 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ............................9 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ......................................... 11 3.4 DESCRIPTION OF SUPPORT UNITS .................................................................... 11 4 TEST TYPES AND RESULTS .................................................................................12 4.1 OUTPUT POWER MEASUREMENT ......................................................................12 4.1.1 LIMITS OF OUTPUT POWER MEASUREMENT....................................................12 4.1.2 TEST INSTRUMENTS.............................................................................................13 4.1.3 TEST PROCEDURES .............................................................................................14 4.1.4 TEST SETUP...........................................................................................................15 4.1.5 EUT OPERATING CONDITIONS ............................................................................15 4.1.6 TEST RESULTS ......................................................................................................16 4.2 FREQUENCY STABILITY MEASUREMENT...........................................................17 4.2.1 LIMITS OF FREQUENCY STABILIITY MEASUREMENT .......................................17 4.2.2 TEST INSTRUMENTS.............................................................................................17 4.2.3 TEST PROCEDURE................................................................................................18 4.2.4 TEST SETUP...........................................................................................................18 4.2.5 TEST RESULTS ......................................................................................................19 4.3 OCCUPIED BANDWIDTH MEASUREMENT ..........................................................20 4.3.1 LIMITS OF OCCUPIED BANDWIDTH MEASUREMENT .......................................20 4.3.2 TEST INSTRUMENTS.............................................................................................20 4.3.3 TEST SETUP...........................................................................................................20 4.3.4 TEST PROCEDURES .............................................................................................21 4.3.5 EUT OPERATING CONDITION ..............................................................................21 4.3.6 TEST RESULTS ......................................................................................................22 4.4 BAND EDGE MEASUREMENT...............................................................................23 4.4.1 LIMITS OF BAND EDGE MEASUREMENT ............................................................23 4.4.2 TEST INSTRUMENTS.............................................................................................23 Report No.: RF110422E04-1 3 Report Format Version 4.0.0 4.4.3 TEST SETUP...........................................................................................................23 4.4.4 TEST PROCEDURES .............................................................................................24 4.4.5 EUT OPERATING CONDITION ..............................................................................24 4.4.6 TEST RESULTS ......................................................................................................25 4.5 CONDUCTED SPURIOUS EMISSIONS .................................................................26 4.5.1 LIMITS OF CONDUCTED SPURIOUS EMISSIONS MEASUREMENT .................26 4.5.2 TEST INSTRUMENTS.............................................................................................26 4.5.3 TEST PROCEDURE................................................................................................27 4.5.4 TEST SETUP...............................................…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST
