ZNR-CU3000Control Unit CU3000

Proventix Systems Inc.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Jun 26, 2011
Application Purpose: Original Equipment
Date of Application: Jun 23, 2011
Equipment Note: Control Unit CU3000
Frequency Range: 2405.00000000 - 2480.00000000
Company: Proventix Systems Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: ZNR-CU3000 IC: 9675A-CU3000 FCC Rule Part: 15.247, 15.249 IC Radio Standards Specification: RSS-210 ACS Project Number: 10-0364 Manufacturer: Proventix Systems, Inc. Model: CU3000 Manual Eliminate the spread of infectious disease in healthcare and hospitals. Implementation Guide © 2010-2011 Proventix Systems, Inc. 2 4518 Valleydale Rd. Suite 201 • Birmingham Alabama • 35242 (205) 383 -1156 www.proventix.com © 2010-2011 Proventix Systems, Inc. 3 Table of Contents About nGage............................................................................................................................. 5 About Proventix Systems, Inc.................................................................................................. 5 Purpose..................................................................................................................................... 6 Implementation........................................................................................................................ 6 Outline of Implementation........................................................................................................... 7 Technical Specifications............................................................................................................... 7 Site Planning................................................................................................................................ 7 Infrastructure.............................................................................................................................. 7 Coding and Validation................................................................................................................. 7 Client Data Extraction................................................................................................................. 7 Standard Operating Procedures................................................................................................... 7 Support Procedures..................................................................................................................... 7 Terminology................................................................................................................................. 8 Implementation Plan.................................................................................................................... 9 Technical Specifications............................................................................................................... 9 Hardware.............................................................................................................................................11 nGage Client Server............................................................................................................................11 SNAP ® network..................................................................................................................................11 Control Units (CU).............................................................................................................................11 Bridge Unit..........................................................................................................................................11 System Architecture....................................................................................................................11 nGage Client Server Application........................................................................................................12 Technology.........................................................................................................................................12 Network...............................................................................................................................................12 nGage Web Server.............................................................................................................................12 Infrastructure.............................................................................................................................13 Procure & Prepare...............................................................................................................................13 nGage Client Server............................................................................................................................14 Connect to Internet..............................................................................................................................14 Install Components.............................................................................................................................14 Client Data Extraction for Tracking and Reporting............................................................................14 Site Planning...............................................................................................................................16 Floor Plan............................................................................................................................................17 Assign Locations.................................................................................................................................17 Approvals............................................................................................................................................18 Coding and Validation................................................................................................................18 © 2010-2011 Proventix Systems, Inc. 4 Code Configuration.............................................................................................................................18 Validate Configuration.........................................................................................…

Text truncated - open the document above for the full version.

Cover Letter(s)

4518 Valleydale Road, Suite 201 Birmingham, Alabama 35242 (205) 383-1156 www.proventix.com May 23, 2011 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir or Madam: I hereby appoint Sam Wismer at Advanced Compliance Solutions, Inc. to act as our agent in the preparation of an application for equipment authorization of FCC ID: ZNR-CU3000 to the FFC Rules and Regulations. I certify that all exhibits contained within this filing properly describe the device or system for which authorization is sought. I further certify that appropriate arrangements have been made to assure that production units of this equipment bearing the name and FCC IDENTIFIER listed in this application will continue to comply with the Commission’s requirements. I further certify by signature below that no party (per 47 CFR 1.2002(b)) to the application is subject to a denial of Federal benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Sincerely, Name: Avery Long Title: Sr. Design Engineer

Cover Letter(s)

4518 Valleydale Road, Suite 201 Birmingham, Alabama 35242 (205) 383-1156 www.proventix.com CONFIDENTIALITY REQUEST Federal Communications Commission Date: May 23, 2011 Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: Proventix Systems, Inc. respectfully requests confidentiality of certain materials provided with the submission of the CU3000 under FCC ID: ZNR-CU3000 in accordance with FCC Regulations 0.459. The confidentiality request applies to the schematics, block diagrams, and detailed operational description contained in this filing and included in the following files. 10-0364 – Schematics.pdf 10-0364 – System Block Diagram.pdf 10-0364 – Theory of Operation The CU3000 has been developed at considerable effort and expense by Proventix Systems, Inc. These items are considered as Trade Secrets and therefore public access to the proprietary material could possibly result in duplication of equipment that could severely damage the company’s business advantage. I appreciate your assistance in this matter. Sincerely, Name: Avery Long Signature: Title: Sr. Design Engineer Date: 5/24/2011

Cover Letter(s)

5015 B. U. Bowman Dr. Buford, GA 30518 June 16, 2011 ACS TCB 5015 B.U. Bowman Drive Buford, GA 30518 Re: FCC ID: ZNR-CU3000 To Whom It May Concern: The following application is submitted on behalf of our client, Proventix Systems, Inc., for evaluation of their model CU3000 for certification under FCC Parts 15.247 and 15.249. The CU3000 is a composite device which includes (1) DTS radio and (1) DXT radio. Each radio was evaluated in full to the appropriate rule section and found to be in compliance. Report number 10- 0364.W06.13.A addresses the DXT radio (tag radio) per 47 CFR 15.249 and report number 10- 0364.W06.23.A addresses the DTS radio (main radio) per 47 CFR 15.247. Sincerely, Sam Wismer Vice President, Technology Advanced Compliance Solutions, Inc.

External Photos

ID Label/Location Info

Internal Photos

RF Exposure Info

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: ZNR-CU3000 IC: 9675A-CU3000 FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Project Number: 10-0364 Manufacturer: Proventix Systems, Inc. Model: CU3000 RF Exposure Model: CU3000 FCC ID: ZNR-CU3000 IC: 9675A-CU3000 ACS Project: 10-0364 Advanced Compliance Solutions Page 2 General Information: Applicant: Proventix Systems, Inc. ACS Project: 10-0364 Device Category: Mobile Environment: General Population/Uncontrolled Exposure Technical Information: Antenna Type: PIFA PCB Antenna Gain: 0dBi Maximum Transmitter Conducted Power: 19.05dB Maximum System EIRP: 19.05 dBm, 80.35 mW Exposure Conditions: Greater than 20 centimeters MPE Calculation The Power Density (mW/cm 2 ) is calculated as follows: S = 2 4R PG  Where: S = power density (in appropriate units, e.g. mW/cm2) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) MPE Calculator for Mobile Equipment Limits for General Population/Uncontrolled Exposure* 240519.051.0080.3501.000 200.016 Power De nsity (mW/cm^2) Dista nce (cm) Transmit Frequency (MHz) Radio Power (dBm) Power Density Limit (mW/Cm2) Radio Power (mW) Ante nna Gain (dBi) Ante nna Gain (mW eq.) Installation Guidelines The installation manual should contain text similar to the following advising how to install the equipment to maintain compliance with the FCC RF exposure requirements: RF Exposure In accordance with FCC requirements of human exposure to radio frequency fields, the radiating element shall be installed such that a minimum separation distance of 20 centimeters will be maintained. Conclusion This device complies with the MPE requirements by providing adequate separation between the device, any radiating structure and the general population.

Test Report

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Test Report FCC ID: ZNR-CU3000 IC: 9675A-CU3000 FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Report Number: 10-0364.W06.23.A Manufacturer: Preventix Systems, Inc. Model: CU3000 Test Begin Date: October 18, 2010 Test End Date: February 3, 2010 Report Issue Date: June 22, 2011 FOR THE SCOPE OF ACCREDITATION UNDER LAB Code 200612-0 This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. Reviewed by: Kirby Munroe Director, Wireless Certifications ACS, Inc. This test report shall not be reproduced except in full. This report may be reproduced in part with prior written consent of ACS, Inc. The results contained in this report are representative of the sample(s) submitted for evaluation. This report contains 23 pages 5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 TABLE OF CONTENTS 1 GENERAL ............................................................................................................................................ 3 1.1 PURPOSE .......................................................................................................................................... 3 1.2 PRODUCT DESCRIPTION ................................................................................................................... 3 1.3 TEST METHODOLOGY AND CONSIDERATIONS ................................................................................. 3 2 TEST FACILITIES .............................................................................................................................. 4 2.1 LOCATION ....................................................................................................................................... 4 2.2 LABORATORY ACCREDITATIONS/RECOGNITIONS/CERTIFICATIONS ................................................ 4 2.3 RADIATED EMISSIONS TEST SITE DESCRIPTION .............................................................................. 5 2.3.1 Semi-Anechoic Chamber Test Site .......................................................................................... 5 2.3.2 Open Area Tests Site (OATS) ................................................................................................. 6 2.4 CONDUCTED EMISSIONS TEST SITE DESCRIPTION ........................................................................... 7 3 APPLICABLE STANDARD REFERENCES .................................................................................... 7 4 LIST OF TEST EQUIPMENT ............................................................................................................ 8 5 SUPPORT EQUIPMENT .................................................................................................................... 9 6 EQUIPMENT UNDER TEST SETUP BLOCK DIAGRAM ........................................................... 9 7 SUMMARY OF TESTS ..................................................................................................................... 10 7.1 ANTENNA REQUIREMENT – FCC: SECTION 15.203 ....................................................................... 10 7.2 POWER LINE CONDUCTED EMISSIONS – FCC: SECTION 15.207 IC: RSS-GEN 7.2.4 ...................... 10 7.2.1 Measurement Procedure ....................................................................................................... 10 7.2.2 Measurement Results ............................................................................................................ 10 7.3 6DB / 99% BANDWIDTH – FCC: SECTION 15.247(A)(2) IC: RSS-210 A8.2(A) ............................. 13 7.3.1 Measurement Procedure ....................................................................................................... 13 7.3.2 Measurement Results ............................................................................................................ 13 7.4 PEAK OUTPUT POWER REQUIREMENT - FCC SECTION 15.247(B)(3) IC: RSS-210 A8.4(4) .......... 15 7.4.1 Measurement Procedure ....................................................................................................... 15 7.4.2 Measurement Results ............................................................................................................ 15 7.5 BAND-EDGE COMPLIANCE AND SPURIOUS EMISSIONS-FCC 15.247(D) IC:RSS-210 2.2, A8.5 ..... 16 7.5.1 Band-Edge Compliance ........................................................................................................ 16 7.5.1.1 Measurement Procedure ................................................................................................................... 16 7.5.1.2 Measurement Results ....................................................................................................................... 16 7.5.2 RF Conducted Spurious Emissions ....................................................................................... 17 7.5.2.1 Measurement Procedure ................................................................................................................... 17 7.5.2.2 Measurement Results ....................................................................................................................... 17 7.5.3 Radiated Spurious Emissions (Restricted Bands) ................................................................. 20 7.5.3.1 Measurement Procedure ................................................................................................................... 20 7.5.3.2 Duty Cycle Correction ..................................................................................................................... 20 7.5.3.3 Measurement Results ....................................................................................................................... 20 7.5.3.4 Sample Calculation: ...........................…

Text truncated - open the document above for the full version.

Test Setup Photos

Contact Information

Applicant

Avery Long

[email protected]2053832105Fax: 8665714873

Test Firm

Advanced Compliance Solutions, Inc.Randy Abernathy

[email protected]770-831-8048Fax: 770-831-8598

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	800.00 mW

Confidentiality

Long Term

Grant Notes

Power listed is conducted. Output power as shown in this filing is reduced at upper channels for compliance with restricted band-edge requirements. Device must operate with a source-based, time-averaged duty cycle not to exceed 14.1%, controlled by firmware or software. The antenna(s) used for this transmitter must not be collocated or operating in conjunction with any other antenna or transmitter, except as evaluated in this composite filing. End-users must be provided with transmitter operation conditions for satisfying RF exposure compliance.
