ZNR-TG3000Proventix Tag Unit

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: ZNR-TG3000 IC: 9675A-TG3000 FCC Rule Part: 15.249 IC Radio Standards Specification: RSS-210 ACS Project Number: 10-0364 Manufacturer: Proventix Systems, Inc. Model: TG3000 Manual Eliminate the spread of infectious disease in healthcare and hospitals. Implementation Guide © 2010-2011 Proventix Systems, Inc. 2 4518 Valleydale Rd. Suite 201 • Birmingham Alabama • 35242 (205) 383 -1156 www.proventix.com © 2010-2011 Proventix Systems, Inc. 3 Table of Contents About nGage............................................................................................................................. 5 About Proventix Systems, Inc.................................................................................................. 5 Purpose..................................................................................................................................... 6 Implementation........................................................................................................................ 6 Outline of Implementation........................................................................................................... 7 Technical Specifications............................................................................................................... 7 Site Planning................................................................................................................................ 7 Infrastructure.............................................................................................................................. 7 Coding and Validation................................................................................................................. 7 Client Data Extraction................................................................................................................. 7 Standard Operating Procedures................................................................................................... 7 Support Procedures..................................................................................................................... 7 Terminology................................................................................................................................. 8 Implementation Plan.................................................................................................................... 9 Technical Specifications............................................................................................................... 9 Hardware.............................................................................................................................................11 nGage Client Server............................................................................................................................11 SNAP ® network..................................................................................................................................11 Control Units (CU).............................................................................................................................11 Bridge Unit..........................................................................................................................................11 System Architecture....................................................................................................................11 nGage Client Server Application........................................................................................................12 Technology.........................................................................................................................................12 Network...............................................................................................................................................12 nGage Web Server.............................................................................................................................12 Infrastructure.............................................................................................................................13 Procure & Prepare...............................................................................................................................13 nGage Client Server............................................................................................................................14 Connect to Internet..............................................................................................................................14 Install Components.............................................................................................................................14 Client Data Extraction for Tracking and Reporting............................................................................14 Site Planning...............................................................................................................................16 Floor Plan............................................................................................................................................17 Assign Locations.................................................................................................................................17 Approvals............................................................................................................................................18 Coding and Validation................................................................................................................18 © 2010-2011 Proventix Systems, Inc. 4 Code Configuration.............................................................................................................................18 Validate Configuration.................................................................................................…

Text truncated - open the document above for the full version.

4518 Valleydale Road, Suite 201 Birmingham, Alabama 35242 (205) 383-1156 www.proventix.com May 23, 2011 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir or Madam: I hereby appoint Sam Wismer at Advanced Compliance Solutions, Inc. to act as our agent in the preparation of an application for equipment authorization of FCC ID: ZNR-TG3000 to the FFC Rules and Regulations. I certify that all exhibits contained within this filing properly describe the device or system for which authorization is sought. I further certify that appropriate arrangements have been made to assure that production units of this equipment bearing the name and FCC IDENTIFIER listed in this application will continue to comply with the Commission’s requirements. I further certify by signature below that no party (per 47 CFR 1.2002(b)) to the application is subject to a denial of Federal benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Sincerely, Name: Avery Long Title: Sr. Design Engineer

4518 Valleydale Road, Suite 201 Birmingham, Alabama 35242 (205) 383-1156 www.proventix.com CONFIDENTIALITY REQUEST Federal Communications Commission Date: May 23, 2011 Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: Proventix Systems, Inc. respectfully requests confidentiality of certain materials provided with the submission of the TG3000 under FCC ID: ZNR-TG3000 in accordance with FCC Regulations 0.459. The confidentiality request applies to the schematics, block diagrams, and detailed operational description contained in this filing and included in the following files. 10-0364 – Schematics.pdf 10-0364 – System Block Diagram.pdf 10-0364 – Theory of Operation.pdf The TG3000 has been developed at considerable effort and expense by Proventix Systems, Inc. These items are considered as Trade Secrets and therefore public access to the proprietary material could possibly result in duplication of equipment that could severely damage the company’s business advantage. I appreciate your assistance in this matter. Sincerely, Name: Avery Long Signature: Title: Sr. Design Engineer Date: 5/24/2011

5015 B. U. Bowman Dr. Buford, GA 30518 June 22, 2011 ACS TCB 5015 B.U. Bowman Drive Buford, GA 30518 Re: FCC ID: ZNR-TG3000 To Whom It May Concern: The following application is submitted on behalf of our client, Proventix Systems, Inc., for evaluation of their model TG3000 for certification under FCC Part 15.249. The TG3000 is a stand-alone active tag consisting of a single printed circuit board. The TG3000 tag is an RF device worn by an individual and is used to provide data when a person enters the room, engages an alcohol or soap dispenser, and exits the room. The TG3000 was tested in full to the requirements of the aforementioned rules and was found to be in compliance. Sincerely, Sam Wismer Vice President, Technology Advanced Compliance Solutions, Inc.

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: ZNR-TG3000 IC: 9675A-TG3000 FCC Rule Part: 15.249 IC Radio Standards Specification: RSS-210 ACS Project Number: 10-0364 Manufacturer: Proventix Systems, Inc. Model: TG3000 External Photos Model(s): TG3000 FCC ID: ZNR-TG3000 IC: 9675A-TG3000 ACS Project: 10-0364 Advanced Compliance Solutions Page 2 Figure 1: Tag Unit - Front Figure 2: Tag Unit – Back Model(s): TG3000 FCC ID: ZNR-TG3000 IC: 9675A-TG3000 ACS Project: 10-0364 Advanced Compliance Solutions Page 3 Figure 3: Tag Unit – Side Figure 4: Tag Unit – Side Model(s): TG3000 FCC ID: ZNR-TG3000 IC: 9675A-TG3000 ACS Project: 10-0364 Advanced Compliance Solutions Page 4 Figure 5: Tag Unit Figure 6: Tag Unit

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: ZNR-TG3000 IC: 9675A-TG3000 FCC Rule Part: 15.249 IC Radio Standards Specification: RSS-210 ACS Project Number: 10-0364 Manufacturer: Proventix Systems, Inc. Model: TG3000 Label Information Model: TG3000 FCC ID: ZNR-TG3000 IC: 9675A-TG3000 ACS Project: 10-0364 Advanced Compliance Solutions Page 2 Figure 1: Sample Label Figure 2: Label Placement

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: ZNR-TG3000 IC: 9675A-TG3000 FCC Rule Part: 15.249 IC Radio Standards Specification: RSS-210 ACS Project Number: 10-0364 Manufacturer: Proventix Systems, Inc. Model: TG3000 Internal Photos Model(s): TG3000 FCC ID: ZNR-TG3000 IC: 9675A-TG3000 ACS Project: 10-0364 Advanced Compliance Solutions Page 2 Figure 1: PCB – Front Figure 2: PCB – Front Model(s): TG3000 FCC ID: ZNR-TG3000 IC: 9675A-TG3000 ACS Project: 10-0364 Advanced Compliance Solutions Page 3 Figure 3: PCB – Back

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Test Report FCC ID: ZNR-TG3000 IC: 9675A-TG3000 FCC Rule Part: 15.249 IC Radio Standards Specification: RSS-210 ACS Report Number: 10-0364.W06.33.A Manufacturer: Proventix Systems, Inc. Model: TG3000 Test Begin Date: October 18, 2010 Test End Date: February 3, 2011 Report Issue Date: June 22, 2011 FOR THE SCOPE OF ACCREDITATION UNDER LAB Code 200612-0 This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. Reviewed by: Kirby Munroe Director, Wireless Certifications ACS, Inc. This test report shall not be reproduced except in full. This report may be reproduced in part with prior written consent of ACS, Inc. The results contained in this report are representative of the sample(s) submitted for evaluation. This report contains 14 pages 5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 TABLE OF CONTENTS 1 GENERAL ............................................................................................................................................ 3 1.1 PURPOSE .......................................................................................................................................... 3 1.2 PRODUCT DESCRIPTION ................................................................................................................... 3 1.3 TEST METHODOLOGY AND CONSIDERATIONS ................................................................................. 3 2 TEST FACILITIES .............................................................................................................................. 4 2.1 LOCATION ....................................................................................................................................... 4 2.2 LABORATORY ACCREDITATIONS/RECOGNITIONS/CERTIFICATIONS ................................................ 4 2.3 RADIATED EMISSIONS TEST SITE DESCRIPTION .............................................................................. 5 2.3.1 Semi-Anechoic Chamber Test Site .......................................................................................... 5 2.3.2 Open Area Tests Site (OATS) ................................................................................................. 6 2.4 CONDUCTED EMISSIONS TEST SITE DESCRIPTION ........................................................................... 7 3 APPLICABLE STANDARD REFERENCES .................................................................................... 7 4 LIST OF TEST EQUIPMENT ............................................................................................................ 8 5 SUPPORT EQUIPMENT .................................................................................................................... 9 6 EQUIPMENT UNDER TEST SETUP BLOCK DIAGRAM ........................................................... 9 7 SUMMARY OF TESTS ..................................................................................................................... 10 7.1 ANTENNA REQUIREMENT – FCC: SECTION 15.203 ....................................................................... 10 7.2 POWER LINE CONDUCTED EMISSIONS – FCC: SECTION 15.207 IC: RSS-GEN 7.2.4 ...................... 10 7.3 20DB / 99% BANDWIDTH – FCC: SECTION 15.215, IC: RSS-GEN 4.6.1 ........................................ 10 7.3.1 Measurement Procedure ....................................................................................................... 10 7.3.2 Measurement Results ............................................................................................................ 10 7.4 FUNDAMENTAL FIELD STRENGTH – FCC: SECTION 15.249(A) IC: RSS-210 A2.9(A) ................... 12 7.4.1 Measurement Procedure ....................................................................................................... 12 7.4.2 Measurement Results ............................................................................................................ 12 7.5 RADIATED SPURIOUS EMISSIONS - FCC: SECTION 15.249(A)(D)(E); IC:RSS-210 A2.9(A)(B) ....... 13 7.5.1 Measurement Procedure ....................................................................................................... 13 7.5.2 Duty Cycle Correction .......................................................................................................... 13 7.5.3 Measurement Results ............................................................................................................ 13 7.5.4 Sample Calculation: ............................................................................................................. 14 8 CONCLUSION ................................................................................................................................... 14 Model: TG3000 FCC ID: ZNR-TG3000 IC: 9675A-TG3000 ACS Report: 10-0364.W06.33.A Advanced Compliance Solutions Page 3 1 GENERAL 1.1 Purpose The purpose of this report is to demonstrate compliance with Part 15 Subpart C of the FCC’s Code of Federal Regulations and Industry Canada’s Radio Standards Specification RSS-210. 1.2 Product description The TG3000 device is intended to be used by Health Care, Restaurants, Schools, and other bodies desiring to monitor Hand Hygiene Compliance in their facilities. The TG3000 is a battery powered device that is worn by an individual and is used to provide data when a person enters the room, engages an alcohol or soap dispenser, and exits the room. The TG3000 contains an RF transceiver that is used to communicate with the Proventix CU3000 Control Unit (FCC ID: ZNR-CU3000). Technical Information: Band of operation: 2405 – 2480 MHz Number of channels: 16 Modulation format: O-QPSK Antenna Type/Gain: PIFA / 0dBi Operating Voltage: Coin Cell 3V CR2450 *The TG3000 contains two antennas that are opposite in pola…

Text truncated - open the document above for the full version.

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: ZNR-TG3000 IC: 9675A-TG3000 FCC Rule Part: 15.249 IC Radio Standards Specification: RSS-210 ACS Project Number: 10-0364 Manufacturer: Proventix Systems, Inc. Model: TG3000 Test Setup Photos Model(s): TG3000 FCC ID: ZNR-TG3000 IC: 9675A-TG3000 ACS Project: 10-0364 Advanced Compliance Solutions Page 2 Figure 1: Tag Unit – Radiated Emissions, X Position Figure 2: Tag Unit – Radiated Emissions, X Position Model(s): TG3000 FCC ID: ZNR-TG3000 IC: 9675A-TG3000 ACS Project: 10-0364 Advanced Compliance Solutions Page 3 Figure 3: Tag Unit – Radiated Emissions, Y Position Figure 4: Tag Unit – Radiated Emissions, Y Position
